Used Cnc Hardware Drill And Insertion Machine for sale (70,855)

Condition: refurbished (used), Year of construction: 2014, travel distance X-axis: 12,000 mm, travel distance Y-axis: 4,050 mm, travel distance Z-axis: 1,600 mm, spindle speed (max.): 625 rpm, spindle diameter: 200 mm, Schiess AR-601/142 – completely overhauled in 2014 Main data: X (longitudinal travel of column): 12,000 mm Y (vertical travel): 4,050 mm Bsdoyxa E Rspfx Amzolk Drilling spindle travel: 1,600 mm Milling spindle travel: 900 mm Spindle diameter: 200 mm Spindle power: 91 kW Spindle speed: 1.18 – 625 rpm Capacity: Max. drilling diameter: 1,600 mm Max. machining diameter: 3,000 mm Lifting capacity: 120 tons Rotary table: Diameter: 3,000 mm Max. load: 100 tons Accessories included: Steadies Clamping plates: • 2 units – 8 x 5 m • 1 unit – 6 x 3 m Angle plates

Condition: used, Year of construction: 2015, Mazak Vertical Centre Smart 530C CNC Vertical Machining Centre with Mazatrol Matrix 2 Control. S/No. 259026 (2015), Table Size 1300mm x 550mm, Spindle Speed Max 12,000rpm, 30 Tool Drum Type ATC Fitted with Various Tool Holders and Renishaw Probe, CAT40 Spindle Taper, LNS Turbo MH500 Swarf Conveyor, Machine Weight 6800kg, User Manual on CD. Country of Origin: United Kingdom Location: These lots are located in Gateshead, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described. Bsdsznllxepfx Amzelk

Condition: used, Year of construction: 2015, Mazak Vertical Centre Smart 530C CNC Vertical Machining Centre with Mazatrol Matrix 2 Control. S/No. 264426 (2015), Table Size 1300mm x 550mm, Spindle Speed Max 12,000rpm, 30 Tool Drum Type ATC Fitted with Various Tool Holders and Renishaw Probe, CAT40 Spindle Taper, LNS Turbo MH500 Swarf Conveyor, Machine Weight 6800kg, User Manual on CD. Country of Origin: United Kingdom Blodpfjznlllex Amzjk Location: These lots are located in Gateshead, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: new, functionality: fully functional, travel distance X-axis: 565 mm, travel distance Y-axis: 210 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 50 rpm, total height: 1,120 mm, total length: 710 mm, total width: 890 mm, type of input current: DC, overall weight: 240 kg, table length: 840 mm, table width: 210 mm, power: 1.5 kW (2.04 HP), distance table to spindle center: 360 mm, WMD30LV - 230V / 1Ph Drilling capacity in steel ----- 32 mm Milling capacity in steel ----- 20 mm Face milling ----- 76 mm Motor ----- brushless 1.5 kW Spindle speed, stepless 50 - 3000 rpm Spindle travel ----- 70 mm Spindle mount ----- ISO 30 Work table ----- 840 x 210 mm Cross travel ----- 220 mm Longitudinal travel ----- 565 mm T-slots ----- 3x14 mm Overhang ----- 240 mm Distance spindle - table ----- 470 mm Weight ----- 230 KG STANDARD ACCESSORIES Bsdpfx Aega T Agemzolk * Drill chuck incl. drill shank * Digital depth stop * Digital spindle display * Fine adjustment * Left / Right switch * Milling head, left / right, rotatable 90 degrees * Toolbox OPTIONS * 3-axis digital readout * Base cabinet * Automatic longitudinal feed * Milling vice * ISO30 collet chuck & 12 collets in case * Milling set

Condition: like new (used), Year of construction: 2004, Retrofitted: 2025 Numerical control: HEIDENHAIN TNC-530 Technical features Dimensions Table dimensions: 4500 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmVertical capacity (VC): 500 / 1500 mm  (in direct exit)Distance between columns: 2500 mm Milling head Universal manual UM40Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871)  /  Pull stud: DIN69872Speed range: 20 - 3.000 rpm (5.000 rpm direct exit)Spindle power: 30 kW Feedrates Feedrate: 7000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 45300 KgMachine dimensions approximate: 10926 x 4768 x 5110 mm Accessories Guarding: 2 sliding doors and new perimetral wire-mesh fenceElectronic handwheel: New HR-510External coolant Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features Blodpsyf Rqvjfx Amzok

Condition: used, Year of construction: 2012, CNC laser cutting machine Manufacturer: Microstep Type: FibreLas MSF 3001.15L Year of manufacture: 2012 CNC control: iMSNC Windows Approximate laser operating hours: 4,000 - 5,000 Laser power: 2.5 kW Working area: 3,000 x 1,500 mm Sheet metal thickness, steel (max.): 15 mm Sheet metal thickness, stainless steel (max.): 8 mm Sheet metal thickness, aluminum (max.): 8 mm Operating temperature: +10 to +30 °C and max. 90% humidity (at 20°C) Extraction duct (left and right): outlet on the left, diameter 250 mm Laser source: IPG Ytterbium laser system YLS 2.5 kW Laser cooler: LC 170.01-A.3.5 Voltage: 400 V / 3-phase / 50 Hz Filter system: TEKA 4H 5.5 kW External dimensions of the complete system: approx. 10,400 x 3,610 mm 3826 Bodpfx Asx Eh Drsmzolk

Condition: used, Year of construction: 2006, CNC gantry cutting machine Manufacturer: Bach Blodpfxew El Udo Amzjk Type: ACK-2D Year of manufacture: 2006 CNC control: NBS300 Work table: 1.5 x 6 m 2 oxy-fuel torches 3826

Condition: good (used), Year of construction: 2008, Siemens 840-D Machine equipped with water and oil cooling for deep drilling; deep drilling of D 80 mm x L 600 mm is possible. Travel ranges: Table traverse X-axis: 4,000 mm Drill head traverse Y-axis: 2,500 mm Drill spindle stroke Z-axis: 500 mm Cross beam stroke W-axis: 1,500 mm Working area: Free passage between columns: 3,250 mm Distance table – lower edge of drill spindle: max. 1,600 mm / min. 100 mm Table clamping surface: 4,250 x 2,500 mm T-slots: 12 pieces, 22 mm, spacing 200 mm Max. workpiece weight: 18,000 kg Speeds: Rapid traverse (positioning) X, Y, Z-axis: 10,000 mm/min Feed rate, stepless X, Y-axis: 1 – 2,000 mm/min Cross beam height adjustment: 300 mm/min Spindle feeds Z-axis: 1 – 2,000 mm/min, adjustable in 1 mm increments Blsdpfx Amozq Efdezsk Performance data: Drive power drilling motor (S6-80 % duty cycle): max. 36 kW Spindle speeds: 41 steps, range 20 – 2,000 min⁻¹, step size 1.12 Tailstock diameter: 180 mm Drill spindle diameter in the front bearing: 100 mm Max. spindle torque: 840 Nm Max. drilling pressure: 40,000 N Spindle mount: SK 50 DIN 2079 Largest collet: SK 50 x MK 5 Tool draw-in force: 16,000 N Cutting performance in St 60 steel: Drilling through (spiral drill): 80 mm Reaming: 200 mm Thread cutting (in a balancing chuck): M 68 x 3 mm Milling (tailstock 1/3 extended): Cutter head diameter max. 200 mm (2/3 engaged), cutting depth max. 5 mm, feed rate max. 800 mm/min, milling performance 530 cm³/min.

Condition: used, Kitamura JigCentre 7 CNC Machining Centre. Serial No. 50274 with Fanuc System 11m CNC Control (Tape), Table Working Area 1500mm x 800mm, Load Capacity 2000kg, Travels X Axis 1100mm, Y Axis 850mm, Z Axis 460mm, Spindle Speeds 60 - 6000rpm, 30 Tool ATC, BT40 Spindle Taper, Rapid Feeds X & Y 12,000mm/min, Z 9,000mm/min, Cutting Feeds 0 - 5000mm/min, Tsudakoma Powered Rotary Table (300 Ø), Machine Weight 8300kg Blsdsznkmuepfx Amzek Location: This lot is located in Birmingham, UK. A charge of £450 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchase

Condition: ready for operation (used), Year of construction: 2002, Professional, heavy-duty version by HANG (German quality) in neat, complete condition. Highly suitable for binderies, printing shops, and print departments. ⸻ Specifications • Brand / Model: HANG 107-30 electronic • Serial number: 102553 • Year of manufacture: 2002 • Number of drilling heads: 4 pieces, individually adjustable • Electronic control, automatic drilling cycle • Power connection: 400V – 50Hz – 6A • CE certification present • Cast iron frame, extremely robust construction • Manual and automatic operation • Adjustable stops with fine adjustment • Machine is mounted on swivel casters (easily movable) ⸻ Condition • Removed from production in working order • Drill spindles and guides run smoothly • No damages, normal signs of use • Immediately ready for operation • Complete, as shown in the photos ⸻ Description The HANG 107-30 is one of the most robust paper drilling machines on the market. Heavier-duty and more professional version than the standard models, thanks to the sturdy drilling heads, automatic drilling cycle, and reliable electronic control system. Perfect for calendar production, book blocks, brochures, index tabs, and more. ⸻ Price 👉 € 3,250 net (0% VAT export possible) Bodsx A Izljpfx Amzslk

Condition: used, Year of construction: 1995, CNC Milling Machine, Universal Manufacturer: HERMLE Type: UWF 902 S Year of Construction: 1995 Operating Hours: 65,071 Control System: HEIDENHAIN TNC 426 Working Area X/Y/Z: 600 x 450 x 500 mm Spindle Speed Range: 20 - 6,300 RPM Tool Holder: SK 40 M & H 3D Probe (for workpiece probing) Vertical-Horizontal Milling Attachment Drilling Spindle Coolant System Rotary Table: 900 x 458 Bjdpfx Aev Rxa Sjmzolk Weight: 4,000 kg Machine Dimensions: L x W x H approx.: 3,900 x 2,000 x 2,000 mm ä3826

Condition: used, Year of construction: 1995, CNC Milling Machine, Universal Manufacturer: HERMLE Type: UWF 902 H Year of manufacture: 1995 Operating hours: 46,680 Control system: HEIDENHAIN TNC 426 Travel ranges X/Y/Z: 600 x 450 x 500 mm Rotary table: 900 x 458 mm Bodov Rpr Sspfx Amzslk Renishaw 3D probe Spindle speed range: 20 to 6,300 rpm Tool holder: SK 40 Coolant tank Drive power: 8.6 kW Weight approx.: 4,500 kg Machine dimensions L x W x H approx.: 2,950 x 2,200 x 2,300 mm 3826ä

Condition: good (used), Year of construction: 2016, CNC Portal flame cutting machine Manufacturer: Sato Type: Satronik D5765 Manufacture: 2016 CNC control: Satocontrol CNC 3010 Track width: 5.750 mm 6 x oxyfuel torche without tracks without table without filter Bjdpfx Amogqkc Njzolk

Condition: used, Year of construction: 2003, CNC machining center, universal Bsdpfowwt Nmjx Amzolk Manufacturer: AXA Type: VPC 40 U Year of manufacture: 2003 CNC control: Heidenhain TNC 430 Travel distances: X/Y/Z = 2,300 x 1,200 x 600 mm NC rotary table dimensions: 1,100 x 1,100 mm Fixed table dimensions: 1,100 x 1,100 mm Tool holder: SK40 Tool magazine: 60 positions Spindle speed: 10,000 rpm Weight: approx. 20 tons 3826ä

Condition: used, Year of construction: 2012, CNC machining center Manufacturer: Unverzagt Type: UVA 550 Plus Year of manufacture: 2012 Control system: Siemens 828D Operating hours: approx. 3,000 Travel ranges: X/Y/Z: 600 x 400 x 500 mm Tool positions: 20 Tool holder: SK40 Spindle speed range: 10,000 rpm Hexagon probing system Chip conveyor Spindle cooler IKZ (internal cooling system) 3826ä Bedpjwv Tm Njfx Amzolk

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Bjdpexy Tmnsfx Amzelk

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Clearance height Operator terminal: 24" LED colour display Handheld terminal for axis speed control Software: "Woodflash Vacuum pump 90 m³/h/50 Hz or 108 m³/h/60 Hz Milling spindle 12 kW HSK F63 (12,000 rpm) 12-position linear tool changer on the left of the machine frame + pickup station Drilling head DH 16 4H 2S: Vertical 12 spindles Horizontal 4 spindles 2 grooving saws Storage location: Nattheim Bedpfx Amjxy Tlwszelk

Condition: used, Year of construction: 2011, AXES Working area X-Y-Z axes * mm 3050-1300-180 Workpiece length in swivel machining mm 1390 Stroke X-Y-Z axes mm 3460-1735-250 Max. travel speed of the X-Y axes m/min 60 WORKING TABLE Number of workpiece supports and vacuum cups 6 / 2 Standard type Standard End stops / Position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles Std/Number/Speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles Std/Number/Speed 1/min 6 (4X-2Y) / 4000 Integrated slotting/sawing unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power Std. / Opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer mounted on the unit carrier in X 4 positions, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction nozzle diameter mm 150+150 (200) Machine weight Kg 3000 * X Distance between the stops - Y Milling center as reference point; Z Workpiece passage Blodpoyymz Uefx Amzsk GENERAL FEATURES CNC-controlled boring and milling center, in C-frame design and working table with adjustable workpiece supports and vacuum cups, for performing: - Vertical drilling on the surface of the panel - Horizontal drilling on all four sides of the workpiece - Slot milling with disc cutter in "X" direction - General milling operations Self-supporting structure and working table Structure made of a steel welded construction with the control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV supports. Movable unit carrier Box construction made of cold-rolled steel with internal reinforcing ribs, protective devices with bumpers. Working unit Consisting of a drilling head with vertical spindles, horizontal spindles, an integrated slotting and sawing unit and an SCM electrospindle with tool quick-change system type HSK 63 F. Travel paths of the portal and the unit carrier Movement in the X, Y and Z axis takes place on linear prismatic ball-bearing guides with the aid of pre-tensioned linear guides. The power transmission of the X-axis (movable stand) takes place via a pre-tensioned, backlash-free rack and pinion drive with diagonal movement. The movement of the unit carrier in Y and Z direction takes place via pre-tensioned linear guides. The positioning of the working units and the control of the machine functions takes place via "Brushless" three-phase servomotors and digital drives. CNC CONTROL The control unit consists of a numerical control for the milling and drilling machines and a pre-connected personal computer with a graphical user interface "XILOG PLUS". PC -Office- operating system Windows XP - LCD color screen 17 - Qwerty keyboard - Swiveling control panel - Machine interface software Xilog Plus Xilog Plus features Programming - parametric, graphical and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation in three axes, linear in space, spiral in the chosen plane - Supported programming with graphic and syntax aids for drilling and milling operations - Automatic optimization of drilling operations and tool changes - cycles - Possibility of plate zero-point shift for performing drilling on inclined or curved plate sides - Complete compatibility with CAD/CAM Routocam (SCM) - AlphaCam Integrated additional functions - Calculator for direct transfer of the calculated data.

Condition: used, Year of construction: 2005, functionality: fully functional, empty load weight: 1,300 kg, Horizontal drilling/pushing rig, complete with numerous extension rods. Bjdpfezp Sa Eox Amzslk Bohrtec PZ 120/80. Year of manufacture: 2005. Weight: 1300 kg. Pushing force: 1200 kN. Pulling force: 800 kN. Length: 325 cm. Width: 60 cm. 46 x extension rod, 100 cm long, 22 cm diameter. 72 x extension rod, 100 cm long, 6 cm diameter. Crate with couplings and various accessories. See photos. Price net + 21% VAT or net for export. Calling or sending a WhatsApp message is the fastest way to contact us. We speak Dutch. We speak German. We speak English.

Condition: used, Year of construction: 2002, Tiger TFA 5 RT CNC Bed Milling Machine Manufacturer: Tiger S.p.A. (Italy) Model: TFA 5 RT Machine Type: CNC Bed Milling Machine with Rotary Table Year of Manufacture: 2002 Serial Number: 4211 Order No.: 2507 Working Area X-axis travel: 1,500 mm Y-axis travel: 800 mm Z-axis travel: 1,300 mm Rotary Table Table size: 1,020 × 1,200 mm T-slot width: 22 mm (H7 reference slot) Number of T-slots: 7 T-slot spacing: 140 mm Maximum table load: 5,500 kg Feed Rates Bjdpfszqcy Sox Amzjlk Working feed: 0–4,000 mm/min Rapid traverse: 12,000 mm/min Axis Drive Torque X-axis: 18–33 Nm Y-axis: 14 Nm Z-axis: 27–33 Nm Spindle Spindle taper: ISO 50 Tool clamping force: 15,000 N Spindle motor power: 20 kW Maximum spindle speed: 2,500 rpm Number of speed ranges: 2 Spindle Speed Ranges Constant torque Range I: 10–272 rpm Range II: 10–658 rpm Constant power Range I: 272–518 rpm Range II: 658–2,500 rpm Accuracy Ballscrew precision class: IT5 (ISO 3408/3) Electrical Specifications Supply voltage: 400 V Power supply: 3-phase Frequency: 50 Hz Installed power: 30 kW Maximum installed power (nameplate): 50 kW Rated current: 40 A Maximum current: 80 A Control voltage: 24 V DC Auxiliary voltage: 220 V Electrical protection: IP54 Motor protection: IP54 Pneumatics Air consumption (6 bar): 600 Nl/min General Machine weight: 12,000 kg Documentation reference weight: 12,500 kg

Condition: like new (used), Year of construction: 2019, functionality: fully functional, FICEP TIPO G25LG - CNC PLATE PROCESSING LINE (DRILLING, MILLING, THERMAL CUTTING) | YEAR 2019 The Ficep Tipo G25LG is a CNC plate processing line for combined drilling, milling, tapping and thermal cutting of steel plates in structural steel fabrication. Built in 2019 - a young machine in its class on the used market. All processes run in a single pass on a rigid double-bridge gantry frame. CONDITION & REFURBISHMENT Refurbished and inspected by a certified technician, ready for operation. - The exact scope of reconditioning varies from machine to machine and is disclosed individually upon serious interest. - Viewing possible by arrangement (machine reconditioned - no demonstration under power). FUNCTION & APPLICATION The vertical mono drilling unit with automatic tool changer (ISO 40) performs drilling, milling, tapping, centre-punching and countersinking. The Hypertherm XPR300 plasma torch and the integrated oxy-fuel cutting unit handle thermal cutting - from thin sheet to heavy plate. The line is operated via the Ficep Pegaso CNC control. Infeed and outfeed roller conveyors with material transfer (8 m each) ensure continuous material flow. Typical applications: structural steel fabrication, steel trading and plant engineering. TECHNICAL DATA - Manufacturer: Ficep | Model: Tipo G25LG | Year: 2019 | Serial number: 36098 - Machine type: CNC plate processing line (drilling / milling / thermal cutting) - Condition: used, refurbished by certified technician - Frame design: double-bridge gantry frame, welded | Machine weight: 8,000 kg - Plate width: max. approx. 2,540 mm, min. 200 mm - Plate thickness: max. 45 mm (plasma cutting), max. 100 mm (drilling) - Drilling heads: 1 (vertical mono drilling unit) | Tool holder: ISO 40 - Max. drilling diameter: 40 mm | Max. drilling/milling depth: 100 mm - Max. spindle speed: 7,000 rpm | Spindle power: 15 kW - Plasma cutting torch (straight): 1 | Plasma source: Hypertherm XPR300 | 300 A - Oxy-fuel cutting unit: included - CNC control: Ficep Pegaso CNC - Processes: drilling, milling (incl. straight/curved slots, Y/J weld-edge preparation), tapping, centre-punching, countersinking, marking, scribing, straight plasma cutting, oxy-fuel cutting On request (to be confirmed bindingly during inspection): processing length, tool magazine stations, min. plate thickness for drilling, min. drilling diameter, pass line height, longitudinal and cross positioning speeds, connected load and machine dimensions. SCOPE OF DELIVERY - 1 x Ficep Tipo G25LG CNC drilling, milling and thermal cutting line (year 2019) - 1 x Ficep Pegaso CNC control - 1 x Vertical mono drilling unit with automatic tool changer (ISO 40) - 1 x Plasma cutting torch (straight) | 1 x Hypertherm XPR300 plasma source (300 A) - 1 x Oxy-fuel cutting unit - 1 x Infeed roller conveyor with material transfer (8 m) | 1 x Outfeed roller conveyor (8 m) - 1 x Extraction system for plasma cutting LOGISTICS & LOCATION Location: Ulft (Netherlands), directly at the German border. Dismantling, transport, installation and commissioning by ASM by arrangement - individually calculated upon request. ABOUT ASM Arendsen Steel Machinery (ASM): specialist for refurbished Ficep structural-steel machinery. Further machines on request. CONTACT / INQUIRY Viewing by arrangement | Price on request. Bledpfxeu Dw I Eo Amzek Sale exclusively to commercial customers (B2B).

Condition: ready for operation (used), Year of construction: 1975, arm 1200MM stroke head on bench 1400MM Bodpfjvm Akgex Amzslk universal head portable radial

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 10 m/min, workpiece weight (max.): 20,000 kg, Travel X-axis – Longitudinal column: 8,000 mm Y-axis – Vertical: 2,500 mm Z-axis – Ram extension: 1,000 mm W-axis – Spindle extension: 800 mm Headstock Spindle diameter: 150 mm Revolutions: 2,500 rpm Power: 40 kW Ram section: 460x520 mm Blodpfxjzqlgzo Amzjk Rapid traverse X and Y axes: 20 m/min Z-axis: 10 m/min MG 20 rotary table Table dimensions: 1,600x2,000 mm Longitudinal movement, travel: 1,500 mm Maximum centered load capacity: 20 tons Accessories Automatic indexing headstock 1ºx1º (Power 37 kW) Heidenhain measuring scales on all axes Operator platform Chip conveyor Floor plates (2 units)

Condition: used, Year of construction: 1995, CNC portal cutting machine Manufacturer: Messer Type: Omnimat P 7000 Year of construction: 1995 CNC control: Global Control Plus Track gauge: 7,000 mm 8 x oxy-fuel torches, type ALFA 8 x Omnilift 200 Without track Without table Without filter 3826ä Bjdpfx Ajyay Dhjmzjlk

Year of construction: 2009, condition: ready for operation (used), A Primacon CNC high-precision vertical machining center for machining small workpieces in the medical sector is available. Axis travels X/Y/Z: 240mm/240mm/240mm, table dimensions X/Y: 350mm/300mm, max. table load: 60kg, spindle speed: 40000rpm, tool holder: HSK-25, feed rate: 12m/min, rapid traverse: 12m/min, positioning accuracy: +/-0.001mm, repeatability: +/-0.0005mm. Machine dimensions X/Y/Z: approx. 1900mm/1600mm/2200mm, weight: approx. 1000kg, control: Heidenhain. The spindle is occasionally not clamped correctly during the tool change process. The ventilation hose of the Z-axis rubs against the A-axis block. Documentation available. An on-site inspection is possible. Blodpfxezq Eb Sj Amzok
