Used Cnc Panel Drilling Machine for sale (72,082)

Condition: ready for operation (used), Year of construction: 1996, Immediately available ex location: CNC universal milling machine Reckermann Hodpszwudvsfx Ab Tet Type: Primo II Year of manufacture: 1996 Heidenhain TNC 430 control Spindle taper SK 50 Infinitely variable spindle speeds: 20 – 2,000 rpm Table load capacity: 1,000 kg Stepless feed rates: 20 – 6,000 mm/min Travel (X / Y / Z): 1,000 / 400 / 350 mm Drive: 7.5 kW Weight: 4 t Price: EUR 2,500 plus VAT, ex location

Condition: ready for operation (used), Year of construction: 2003, CNC Milling Machine OPS Hjdpszwudisfx Ab Tjt Type OPS HSC 600 Year of manufacture 2003 CNC control Andronic 3D path control with Ethernet interface Travel distances X/Y/Z 625/375/350 mm Tool changer based on Erowa system, 40 positions Spindle speeds 5,000 – 40,000 rpm Fixed table, load capacity up to 600 kg Travel speed up to 20 m/min Repeatability 0.002 mm Tool changer, 32 positions Spindle HSK 32 E Drive power 9 kW Weight 3,500 kg Price: Euro 4,500.00 (plus VAT), ex works.

Condition: ready for operation (used), Year of construction: 1995, Available immediately ex location: CNC tool milling machine Deckel, type FP 5–80, year of manufacture 1995, CNC control Dialog 12, universal table 750 x 520 mm. Travels X/Y/Z: 800/550/500 mm. Drive power: 9 kW. Quill stroke: 80 mm. Electronic handwheel. Spindle speeds: 32–5000 rpm. Feeds: 0–6000 mm/min. Weight: 4.5 t. Price: EUR 2,750 plus VAT, ex location. Hodpfjzwuc Eox Ab Tet

Condition: used, Year of construction: 2009, turning diameter: 2,000 mm, travel distance X-axis: 1,875 mm, travel distance Y-axis: 1,550 mm, travel distance Z-axis: 1,345 mm, rotational speed (max.): 300 rpm, rotational speed (min.): 10 rpm, Equipment: documentation/manual, CNC Vertical Multitasking Machine CNC Control Mazatrol Matrix 2 Turning diameter 2000 mm Turning speed 10-300 R/min Milling head speed 25-5000 R/Min Movement X-Y-X-axis 1875-1550-1345 mm B-axis travel -30/120° Hodpfx Abozv T D Eo Tot C-axis indexing 360/0,0001° Tool taper Capto C8 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, total width: 1,400 mm, total length: 1,000 mm, total height: 2,700 mm, Colour: Green Empty weight: 1.500 kg - Documentation available: No - CE certificate present: No - Drive system: Conventional - Drive system: Gear drive - Power [kW]: 3 - Table type: Fixed table - Table length [mm]: 650 - Table width [mm]: 540 - Drilling depth [mm]: 280 - Drilling capacity [mm]: 40 - Reach [mm]: 315 - Tool holder: MK4 - Main spindle power [kW]: 3.0 - Min. spindle speed [rpm]: 1 - Max. spindle speed [rpm]: 1000 - Options: Tapping function, Drill unit feed - Transport dimensions: 1000mm x 1400mm x 2700mm (l x w x h) - Transport weight [kg]: 1500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Hodpozwc Sbsfx Ab Tjt Lukas van Rossum

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Hodpfjvvi I Rox Ab Tet

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Hedovwbp Aepfx Ab Tet

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Main spindle power: 11.0 kW Hodpfx Abovvi Hto Tot Main spindle speed: 1500 - 24000 rpm Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Safety: Safety tread mats Storage location: Sonnefeld

Condition: used, Year of construction: 2004, Storage location: Nattheim Hodpfx Abjvvi Hyo Tst

Condition: used, Year of construction: 1994, Storage location: Nattheim Hedpfewmm Nrox Ab Tet

Condition: used, Year of construction: 2002, Machining dimensions (tool diameter 25mm): X=3015 mm Y=1483 mm Z=325 mm Max. travels: X=3268 mm Y=1483 mm Z=325 mm Max. programming speed: X/Y = 75 m/min / Z = 30m/min Tool holder HSK 63F Drilling unit 7964, 14 vertical drilling spindles with 32 mm grid (10 in x / 4 in y) Sawing unit 7946 3.6 kW, 90° pneumatically pivotable Milling unit 7933 9 kW Wood Her Vector axis (C-axis) Tool magazine (6 disk places) Hand control unit Laser device (positioning of the suction cups) PC control panel with 17" monitor Operating system Windows 2000 Software: TwinCAM32 - office version Vacuum pump 100 m³/h Dry running Selective safety mats (3-field division) Storage location: Nattheim Hodpfx Aevvi Nbsb Tjt

Condition: used, Year of construction: 2022, Plus freight 4,000.00 € and installation and commissioning 5,000.00 € Grinding system B Sand 5 with partial lathe Working principle The panel is placed on the infeed table. It goes into the partial lathe and centered. It is ground in the grinding system, through and back. The panel is turned in the partial lathe. It is ground on the other side in the grinding system. Then there are two options: either the panel goes onto the outfeed table and unloaded or it comes back onto the infeed table and is unloaded there (the second option extends the working time). Grinding system equipment 1 upper grinding lamella roller suitable for surfaces. Power 3 kW; D 420 mm; L 1300 mm. Cross brush suitable for grinding the cross fibers. D 420 mm; L 300 mm. Power 1.1 kW. Cross brush suitable for grinding the cross fibers. D 420 mm; L 300 mm. Power 1.1 kW. 3 upper sanding discs for perfectly trimming the longitudinal and transverse wood fibers. Power 1.5 kW each; D 400 mm. Disc brush for beveling edges. The unit functions as a deep brush. After detecting the panel edges, it will follow the door edges. Power 0.75 kW; D 250 mm. Machine features: -The unique sanding system of this machine guarantees perfect wood sanding and/or intermediate sanding of the panels. -All tools are controlled by frequency converters. -All brushes are equipped with quick-release sanding strips without replacing the hub. -The discs are equipped with air bladders to optimize cleaning and service life. -Sanding discs are equipped with a Velcro fastening system. -The feed and rotation speed are PLC-controlled to prevent edge breakage. -High-quality sanding on 4 sides thanks to the system's constant removal rate. -Automatic and rapid unit changeover. - Constant throughput height, PLC and industrial software enable interlinking in a surface line. - Continuously variable speed of the discs, brushes and feed thanks to the fully equipped frequency converter. - Right/left rotation of the discs and brushes with different abrasive grits. - Individually driven feed of the discs, rollers and belts. - Additional adjustment of the brushes and discs to balance the use of the abrasive and to allow for changing the grinding pressure on the surfaces. - Strong support bed made of tubular steel guarantees the best rigidity, stability and flatness. - Planed upper support bed to ensure the best parallelism of the working surface for the grinding discs. - All unit carriages are designed with linear recirculating ball bearing guides, thus high load capacity and high precision. - Motorized feed belt controlled by a frequency converter, 0.55 kW. Machine doors equipped with safety devices. - Machine doors equipped with windows to observe the workpieces during operation. - Under the units, there are 80 mm rubber-coated pressure rollers to hold the workpieces in place during processing. · Low follow-up costs thanks to individual blade replacement. · Low running noise thanks to the enclosed system housing. · All units have suction housings with their respective suction supports. Cover plate with suction nozzle. · Completely encapsulated machine housing for a clean environment. Hedevvkipjpfx Ab Tjt

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground ball screws of the highest precision class. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. Such characteristics are important for ensuring balanced movement even in more complex tasks. The movement of the various axes is controlled by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters that can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different P Hedpovvi Nzjfx Ab Tot

Condition: used, Year of construction: 2020, CNC-CONTROLLED MACHINING CENTER WITH MULTIFUNCTIONAL TABLE - WORK CELL VERSIONX400 CELLDrilling and milling made for you!The numerically controlled machining center is equipped with a wide range of milling/drilling tools to meet every need in the processing of wood and similar materials.- More powerful, with drilling spindles with 8,000 rpm and . Technology, the toughest spindle available on the market, with over 1,000 maintenance-free hours of use. Better and more comprehensively equipped, with various configuration options thanks to the multifunctional table to optimally equip the machine according to your needs. Easier and more understandable programming thanks to the integrated MAESTRO CNC CAD-CAM module. Easier to use: the work table is accessible at all times, the electrical cabinet and vacuum pump are integrated, and in the PRO SPACE configuration there are no guards. Supporting structure. The supporting structure consists of a particularly strong monolithic steel base, heavily ribbed and very rigid. The particularly wide support was specifically designed to give the machine stability, ensuring consistent precision regardless of the working conditions and eliminating the need to anchor the machine to the floor. The base forms a large and solid support for the mobile column: the work unit is thus equipped with a balanced, stable, and durable support that can withstand the most extreme stresses, ensuring higher quality performance and greater precision. The mobile gantry consists of a single, solid unit anchored to the base on both sides and slides on pyrotechnic guides with top-quality ball-return slides. The dual motorization along the X-axis ensures top performance even under demanding working conditions. The movement of the lower moving unit (X-axis) and the working unit along the rod of the moving unit (Y-axis) is achieved thanks to a rack/pinion transmission with helical teeth. this creates a greater tooth-to-tooth thrust which achieves greater acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures less wear on the mechanical components and less noise. The vertical Z axis is driven by a screw with ball return which ensures perfect balance with dynamic loading and strong acceleration and deceleration. The main milling unit is directly coupled to the Z axis carriage and ensures absolute quality of finishes as any vibrations are completely eliminated. Translation along the X-Y-Z axes is carried out by brushless motors driven by static inverters; These ensure: - Reduced processing times thanks to improved acceleration - Better positioning accuracy thanks to the high-resolution encoder - Zeroing of setup operations when switching on the machine thanks to absolute encoders - Zeroing of general maintenance operations since there are no brushes with the "brushless" system The management of the axis displacement and, in general, of the machine's working elements is carried out by an industrial NS module with digital D Hjdpfx Aovvi N Isb Tjt

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground, high-precision recirculating ball screws. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. This characteristic is important for ensuring balanced movement even in more complex tasks. The various axes are driven by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters, which can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different Hodpfx Abevvi Rfo Tot

Condition: used, Year of construction: 1999, Storage location: Nattheim Hedpfx Abovvi Rxe Tjt

Condition: used, Year of construction: 2002, Drilling capacity: 25 mm, spindle mount: MK 3 Hedpjvvi Auofx Ab Tjt Storage location: Nattheim

Condition: used, Year of construction: 1995, Storage location: Nattheim Hodpfowkirqex Ab Tet

Condition: used, Year of construction: 2009, Automatic central lubrication Milling unit 7833 2-stage, 11 kW power 1000 - 24000 rpm 1 double drilling spindle in X-direction 1 integrated sawing unit for sawing / grooving in X-direction, traveling Tool changer 7892, 16-way Linear Pick-up changer, permanently installed on the right-hand side of the machine Laser pointer consisting of 2 laser pointers for positioning the vacuum suction cups or tracing the workpiece contour Automatic console - suction cup positioning 6 consoles including 3 suction cup holders per console including 1 vacuum suction cup 80x80 mm per suction cup holder including 4 feeding aids Additional processing fields at the front for 6 consoles Basic unit pneumatics for frame clamping system 7974 (6 consoles) 2D barcode scanner Video camera in the processing head Vacuum pump 140 m³/h Vario tool Change changing unit package consisting of Consists of: Vector axis 7899 (C-axis), fully interpolating, 0-360° continuously rotatable, including pneumatic tool changer 7890, single-slot magazine pick-up system, permanently installed in front of the machine frame on the left. Tool changer 7894, 6-slot pick-up magazine specifically for Vario Tool Change tool holders, permanently installed in the machine frame on the left, can be equipped with a Vario Grip KSJ F 40 collet chuck, 3 Vario Grip KSJ F 40 tool holders (for 2-20 mm ER32 collets), 1 saw blade holder, 3 collets according to customer selection, 1 carbide circular saw blade, max. 220 mm diameter. Hodpfxevvi Spj Ab Tjt Storage location: Nattheim

Condition: used, Year of construction: 2005, Working area: X=2970 mm / Y=1725 mm Axis travel speeds: X=60 Y=45 Z=25 m/min Weight: 3200 kg Storage location: Nattheim Hedpfx Abjw Dcccs Tjt

Condition: used, Year of construction: 2007, Travel range: X=4400 Y=2195 Z=440 mm Working area in X=3650 mm Y=1560 mm Clearance: 330 mm Electrospindle SCM Power 2000, high speed milling spindle with 13 kW power Rotary axis Vector (C-axis) Cleaning blower for tool on the milling unit Tool holder HSK 63 F Speed range 600 - 24,000 rpm, stepless via inverter Motor power 8.5 kW Tool holders: 6 pcs Tool changer: Rapid 12 (12 positions) Vacuum pump 250 m³/h / 5.5 kW Max. vacuum: 0.9 bar Reference stop at the sides of the table Drilling unit with 11 spindles (7 vertical / 4 horizontal) Control: NUM Series 1000 User interface: XILOG Plus PC Office hardware WINDOWS XP Professional Total connected load: max. 27.5 kW Weight: 5200 kg Storage location: Nattheim Hedpfsw Dcb Sox Ab Tot

Condition: good (used), Year of construction: 2008, Ref. -No.: 10660 Manufacturer: DECKEL MAHO Type: DMC 835 V Hodpfx Aezw Txfeb Tst Year of construction: 2008 Type of control: CNC Control: Siemens 840D mit Shopmill Storage location: Halberstadt Country of origin: Germany X-Travel: 835 mm Y-Travel: 510 mm Z-Travel: 510 mm Main spindle drive power: 14 kW Table Dimensions (Lengthxwidth): 1000 x 560 mm Table Load: 800 kg Tool Taper: SK 40 Numbers Of Tools In Magazin: 20 Turning Speeds: 10000 RPM Max. Workpiece Weight: 4,5 t Further information: - Chip conveyor - Handwheel The machine can be inspected while powered on by prior arrangement.

Condition: good (used), Year of construction: 2012, Ref. -No.: 10659 Manufacturer: DECKEL MAHO Type: DMC 835V Year of construction: 2012 Type of control: CNC Hodpfezw Tw Usx Ab Tet Control: Haidenhein iTNC 530 Storage location: Halberstadt Country of origin: Germany Machine-No.: 1541XXX X-Travel: 835 mm Y-Travel: 510 mm Z-Travel: 510 mm Number of T-slots: 5 Max. Tool Weight: 6 kg Max. Tool Length: 250 mm Max. Tool Diameter: 80 mm Tool change time: 1,6 s T - groove width: 14 mm T - slot spacing: 100 mm Tool Taper: SK40 Numbers Of Tools In Magazin: 30 Spindle Speed: 12000 RPM Max. Torque: 130 / 87 Nm Turning Speed Range - Stepless: 30 mm / min Total Power Requirement: 35 kW Dimensions Of The Machine Ca.: 4,5 x 3,5 x 2,7 m Weight Of The Machine Ca.: 5 t Changeover time chip - chip: 6 sec Feed rate: 1 - 20.000 (X / Y / Z) High pressure cooling: 20 bar Further information: The machine can be inspected while powered on by prior arrangement.

Condition: excellent (used), Catalogue number: 7859 Hjdpfx Aozxg A Tob Tst ADVANTAGES – 8 spindles – with oscillation – variable spindle spacing (adjustable) – 2 work tables – unpainted – used drilling machine, in very good condition TECHNICAL DATA Drilling spindles: 2x4 pcs Oscillation range left/right: 40mm per side Oscillation speed adjustment on inverter Spindle head adjustment: up/down Each pair of spindles (2 pcs) adjustable: left/right 2 rotation speed options + left/right Max tool diameter: 15mm Table adjustment: up/down Table dimensions: 700x200mm 4 hydraulic cylinders Motor power: 2x 2kW Oscillation motor: 0.75kW Dimensions (L/W/H): 1800x1350x1300mm Weight: 862kg Net price: 16,900 PLN Net price: 4,020 EUR Net price calculated at exchange rate 4.2 PLN/EUR (In case of significant exchange rate fluctuations, the price may change)

Condition: used, bore capacity in steel (diameter) 32 mm arm length 1230 mm table surface area 1200 x 500 mm bore stroke 180 mm feed - independent 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds 45 - 1370 U/min taper MK 4 Hjdpfszwg Rusx Ab Tet total power requirement 2,7 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 2,2 x 1,8 x 2,3 m Quick radial with: - Feed - Thread cutting device
