Used Cnc Turning-Milling Machine for sale (68,469)

Condition: used, Year of construction: 1987, Universal CNC Milling Machine CNC MAHO MH 400 E Travel X: 400 mm Travel Y: 375 mm Travel Z: 250 mm Numerical Command CNC PHILIPS 432 Table: 700 x 270 mm Cone: SA40 Spindle speed: from 80 to 4000 RPM Year of construction: 1987 Central lubrication Manually swivel head Supplied with doc + machine parameters Voltage: 380 V Width: 2200 mm Depth: 2000 mm Total height: 2000 mm Itodpozm Spzjfx Aayek Weight: approx 1,5 T

Condition: excellent (used), functionality: fully functional, feed length X-axis: 700 mm, feed length Y-axis: 550 mm, feed length Z-axis: 550 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 550 mm, HERMLE UWF 1001 CNC milling machine With CNC control, HEIDENHAIN / Type: TNC 155 Measuring probe / Coolant system / Chip conveyor Enclosure / Cabin / Control cabinet: 1260 x 500 x 1700 mm Travel paths: 700 x 550 x 550 mm / Clamping table area: 1000 x 490 mm Isdpfx Aaezcmz Ejyetk

Condition: used, Year of construction: 2019, operating hours: 4,500 h, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 800 mm, rotational speed (max.): 12,000 rpm, total length: 4,000 mm, tool holder type of tool turret 2: BT 40, Doosan VCF850 machining center, continuous 5-axis operation, rotary table, Fanuc control. Ijdpfszihg Uex Aayjtk

Condition: excellent (used), With C-axis With driven tools FANUC 21i TB Manual Guide control Turning diameter max 355 mm Turning length -1330 mm Spindle speeds -2'800 rpm Top turret tool holders 12 driven positions Misc. accessories MARCELS MASCHINEN CH Itodezhmnbspfx Aayek

Condition: used, Year of construction: 1991, CNC Vertical Milling Machine RAMBAUDI type RAMMATIC 600 Travel X 1260 mm Travel Y 690 mm Travel Z 600 mm Numerical Command NUM 1060 Cone SA 50 Table size 2000 x 600 mm Year of construction 1991 Voltage 380 V Depth 2500 mm Total height 4000 mm Weight: approx 9 T Iedjzmycvspfx Aayotk

Condition: used, CNC 5-Axis HMC – Horizontal Machining Center, Milling Center, Manufacturing Center Manufacturer: LICON Model: Liflex 1266 PC B1 Year of construction: 2016, Commissioned: 2017 Equipped with SIEMENS 840D SL (Solution Line) CNC path control, with 5 simultaneously controlled axes Travel paths X: 1200 mm, Y: 660 mm, Z: 650 mm A-axis as swivel bridge +/– 135° (270°) B-axis 360° continuous Axis acceleration X + Y-axis 6 m/s² Axis acceleration Z-axis 9 m/s² Feed force X + Y-axis 7500 N Feed force Z-axis 10000 N Positioning tolerance (X/Y/Z) 0.008 mm A-axis swivel speed 180° rotation in 4 sec. Interference diameter on the swivel bridge max. 1400 mm Transport load on the swivel bridge max. 700 kg Tool holder HSK 63 Spindle speed max. 12,000 rpm, stepless Spindle power 37kW at 40% duty cycle Spindle torque at 40% duty cycle 85 Nm Maximum spindle torque 100 Nm Tool change time (chip-to-chip) approx. 3.7 sec. Tool diameter with adjacent slots occupied Ø 140 mm Tool diameter with adjacent slots free Ø 250 mm Maximum tool length 400 mm Maximum tool weight 20 kg Power supply 400 Volt, 50 Hz Connected load 80 kVA Compressed air connection 5-8 bar - LIFLEX MSP 80/63/85/12,000 motor spindle (output 37kW/40% duty cycle) with liquid cooling and recooling unit - 2-axis rotary tilting table LICON as B- and C-axis, with hydraulic axis clamping - Zero-point clamping system on the swivel axis turntable - Dual pallet changer, without pallets (these need to be newly sourced) - Media transfer of 5 single-action pressure lines for oil or air, for workpiece clamping on the pallets Iedpfx Aajt Ac Efjystk Hydraulic functions from 30-150 bar, with pressure monitoring (controllable via M-functions) - Tool changer with 30 tool positions, disc turret type - Machine designed for dry machining with minimal quantity lubrication (MQL) system - MQL-TSC, internal MQL lubrication supply through the spindle - Scraper belt chip conveyor, discharge height 1150 mm - Licon ECO-Mode (energy-efficient aggregate operation) - Direct linear measurement system on all axes - Operating hours (control voltage on) ≈ 7,500 h Space required for operation L x W x H 9,000 x 5,000 x 3,800 mm Space required for transport L x W x H 6,100 x 4,400 x 3,600 mm Base machine weight approx. 21 tons Total weight: approx. 24 tons Very good condition

Condition: used, CNC Tool Milling Machine MIKRON Type WF 40C/3M with Heidenhain TNC 310 CNC path control Machine No. 440911 Year approx. 1985, overhauled and control retrofit in 11/2000 Travel distances X: 600 mm Y: 600 mm Z: 460 mm Table size 900 x 550 mm Spindle taper ISO 40 Distance spindle nose - table max. 520 mm Spindle speed 31.5 - 3150 rpm, 21 steps Feed rate 1 - 2000 mm/min. Isdpfx Asw A Af Ijayotk Rapid traverse speed X and Y = 5000 mm/min; Z = 4000 mm/min Quill stroke 100 mm Main spindle drive 4 and 5 kW Power connection 400 Volt, 50 Hz, 10.5 kW, 25 Amp. - CNC path control Heidenhain TNC 310, NC software: 286140 07, PLC software: MIKR1 - Spindle speed via 21 gear steps - Vertical milling head swivels left and right - Hydro-mechanical tool clamping vertical and horizontal - Central lubrication - Electronic handwheel - 62,815 operating hours shown - Control cabinet permanently attached to the machine rear - Coolant system integrated in the machine base - Swiveling operator panel - Electrical diagram, control manual available Space requirement L x W x H 2300 x 2000 x 2150 mm Weight 2900 kg Good condition

Year of construction: 2021, condition: ready for operation (used), A Takamatsu CNC twin-spindle turning and milling center is available. 1) Turning diameter: 190mm, turning length: 150mm, max. one-sided machining length: 440mm, max. bar diameter main spindle/counter spindle: 51mm/42mm, spindle nose 1/2: A2-6/A2-5, spindle bearing 1/2: 100mm/85mm, main spindle bore 1/2: 52mm/43mm, spindle speed: 5000rpm, tool stations: 2×12, travel X1/X2: 162.5mm/170mm, travel Z1/Z2: 500mm/500mm, travel Y: +/-35mm, travel A: 550mm, machine dimensions X/Y/Z: approx. 3000mm/2250mm/2100mm, weight: approx. 7400kg, control: Fanuc 32i-B. 2) TOP Automazioni FU350SX bar feeder, max. bar capacity: 52mm, max. bar length: 3200mm, max. remnant length: 300mm, max. feed rate: 30m/min, max. bundle weight: 2000kg, machine dimensions X/Y/Z: approx. 4300mm/1400mm/1200mm, weight: approx. 1200kg. 3) LTA E 120-X-2-H filtration system, year of manufacture: 2022, filter stages: 2, extraction capacity: 1200m³/h, blower capacity: 2400m³/h, differential pressure: 840Pa, max. separation efficiency: 99.8%, machine dimensions X/Y/Z: approx. 1150mm/620mm/650mm, weight: approx. 125kg. Documentation available. An on-site inspection is possible. Itodpfx Aaozl Enzeyok

Condition: excellent (used), With sub-spindle With C-axis With Y-axis FANUC 18i TB Manual Guide control Turning diameter max 280 mm Turning length -400 mm Spindle speeds -6'000 rpm each C-axis dividing 0.001 ° Spindle taper ASA A2-5 Top turret tool holders 12 driven positions Barloader Piece catcher attachement Itsdpfx Aozhmi Ssaysk Chip conveyor Misc. accessories MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Traub CNC turning machine TNC65DGY, TX8I, year of manufacture 2006, serial no. 1191 Description: Y-axis on S1, V-axis, 2 x C-axis, 2 x rotary tool drive, 2 turrets VDI30, Hainbuch BZI65 on main and counter spindle, parts gripper, Hydrafeed Multifeed bar feeder magazine. Condition: Very well maintained, good condition, maintenance performed. Machine geometry has been checked and corrected/adjusted. Machines can be inspected while powered on – or a video is available. Delivery time: Itjdpfx Aaezrk I Heysk approx. 4 weeks from order.

Condition: good (used), Year of construction: 1997, - Control system: SIEMENS SINUMERIK 840-C - Max. bar diameter: 65 mm - C-axis - Main spindle speed: 31 - 6,300 rpm - Turret 1: 8 stations, 4 of which are powered - Turret 2: 8 stations, 4 of which are powered - Driven tool speed: 4,000 rpm Iedpfjxa Epbjx Aayjtk - Both turrets with internal cooling - High-pressure unit - Chip conveyor - Bar feeder IRCO SiMag 65 - Max. bar length: 3,200 mm Dimensions LxWxH: - Machine: 3,400 x 1,700 x 1,800 mm - Bar feeder: 4,000 x 1,000 x 1,400 mm - Chip conveyor: 3,000 x 1,100 x 1,600 mm Total weight: approx. 6,000 kg

Condition: used, Year of construction: 2013, functionality: fully functional, machine/vehicle number: 15995729164, spindle speed (min.): 24,000 rpm, travel distance X-axis: 700 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 380 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, overall weight: 3,400 kg, controller manufacturer: Siemens, controller model: 840D, workpiece length (max.): 2,340 mm, workpiece width (max.): 1,650 mm, workpiece height (max.): 2,500 mm, 2013 DMG Mill Tap 700 Made in Germany. Equipped with below options 24000rpm spindle, 25 tool station (5th Axis) LEHMANN EA-507 CNC Rotary Table Production package TSC 20bar Chip conveyor Renishaw probe OMP 60 + OTS tool setter Main Spindle needs repair Technical Specifications Year of Manufacture: 2013 Iedpfxszmggne Aayjtk Control Unit: Siemens 840D Solution line X-Axis Travel: 700 mm Y-Axis Travel: 420 mm Z-Axis Travel: 380 mm Table Size: 840 x 420 mm (Max load: 400 kg) Spindle Taper: BT 30 / BBT 30Spindle Speed: 24,000 rpm Tool Changer (ATC): 25-station pick-up system Rapid Traverse (X/Y/Z): 60 / 60 / 60 m/min Machine Weight: Approx. 3,400 kg Overall Dimensions: 1,650 x 2,340 x 2,500 mm Included Accessories / Equipment pL LEHMANN EA-507 CNC Rotary Table (5th Axis) with complete cabling/integration.

Year of construction: 2017, condition: ready for operation (used), X-axis: 550mm, y-axis: 305mm, z-axis: 460mm, milling table dimensions: 800x320mm, T slots: 14mm/3 pieces/distance 100mm, max. table load: 300kg, spindle to table distance: 100-600mm, number of tool positions: 12, max. tool diameter: 70mm, max. tool length: 300mm, max. tool weight: 6kg, tool change time (T to T): 7s, milling spindle power S1 operation: 5.5kW, power S6 30% operation: 7.8kW, torque S1 operation: 35Nm, torque S6 30% operation: 50Nm, spindle holder: ISO 40/BT40x45°, coolant system pump output: 650W, tank capacity: 120l, compressed air minimum connection pressure: 0.6MPa (6bar), air consumption: 0.1-0.15m³/h at 0.6MPa, compressed air quality: ISO 8573.1 class 2, compressed air connection: 3/8 inch, connected load: 12.5kVA, control: Siemens SINUMERIK 808D MILLING, length: 2164mm, front width: 1520mm, side width: 1860mm, height: 2200mm, door opening range: 760mm, door opening width: 1055mm, foundation/installation area: 1520x2080mm, weight: 2.8t. An on site inspection is possible. Itsdpfx Aaozcfk Ejyjk

Condition: used, Year of construction: 2008, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 510 mm, total height: 3,250 mm, total length: 3,545 mm, total width: 3,970 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 48, Equipment: chip conveyor, For sale is a high-precision Hurco VTXU vertical 5-axis machining center with a swivel rotary table. The machine is in very good cosmetic condition. Technical data: Year of manufacture: July 2008 Control: WinMax (dual-screen) Travel distances X / Y / Z: 800 x 700 x 510 mm Swivel range A-axis (tilting axis): -30° to +110° Rotation range C-axis (rotary table): 360° (full range) Rotary table diameter: 610 mm Table load: max. 400 kg Distance spindle nose - table: 150 - 660 mm Max. spindle speed: 12,000 rpm Spindle power: 18 kW Torque: 237 Nm Tool holder: SK 40 Magazine capacity: 48 tools Max. tool length: 280 mm Max. tool weight: 7 kg Tool change time chip-to-chip: 8 sec. Voltage: 400 V / 50 Hz Connected load: 55 kVA Compressed air requirement: 6 - 8 bar Machine dimensions (W x D x H): 3,545 x 3,970 x 3,250 mm Itedpfx Aaozvd U Ueyok Upon request, transport and loading can be arranged throughout Europe for an additional fee. Prices plus VAT. Inspection possible by appointment. Contact us, our team will be happy to assist you. Trade-in or exchange possible! Machine buying and selling PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Do you need a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: used, Year of construction: 2009, operating hours: 3,483 h, functionality: fully functional, total length: 5,550 mm, total width: 2,250 mm, bar diameter (max.): 95 mm, overall weight: 8,400 kg, Max. workable diameter from bar mm 95 Iedovv Ud Rjpfx Aayetk Max. workable diameter from recovery mm 500 Max. workable length mm 1250 Max. rotating diameter mm 700 MAIN ELECTROSPINDLE: Variable rotation range rpm 40-2800 ASA spindle nose 8" Spindle hole mm 111 Internal diameter of bearings mm 150 Self-centering diameter mm 315 Motor power kW 30 TAILSTOCK TO FOLLOW: Positioning stroke mm 1,100 Quilt stroke mm 150 Quilt diameter mm 115 MOTORIZED ELECTROSPINDLE HEAD: Type of attachment HSK-63 Max. revolutions RPM 6,000 Electrospindle motor power Kw 9 B AXIS UNIT: Total rotation range 205° Rotation range beyond the tailstock axis 15° Rotation range beyond the spindle axis 10° Angular position with mechanical block Every 5° CROSS SLIDE Max. Z stroke mm 1300 Max. X stroke mm 520 Max. stroke Y mm 210 (+120 – 90) TOOL MAGAZINE Magazine capacity 40 pos Max. diameter of tools with adjacent tools mm 80 Max. diameter of tools without adjacent tools mm 140

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, overall weight: 4,400 kg, Equipped with Iemca Boss 545 barfeed and Mitsubishi M700 Control - the lathe has always operated with oil, in regular working order (bearings and ball screws of the X1/Z1 axes and 2 drives have just been replaced). Itodpfoynt U Aox Aayek

Condition: used, Year of construction: 2022, functionality: fully functional, DOOSAN PUMA GT 3100 M – UNUSED, PRE-OWNED MACHINE WITH ROBOT CELL A Doosan Puma GT 3100 M, manufactured in 04/2022, which has never been used in production after commissioning by the supplier (February 13, 2023). 0 production hours, no workpiece contact, technically and visually in new condition. Includes a factory-installed robot cell for automated loading. Origin: Liquidation of a user's operations in the Nuremberg area. On-site or video call inspection possible. KEY FEATURES - 12″ main spindle, high power and high torque for steel and stainless steel machining - Driven tools VDI40/BMT 65P, milling, drilling and threading from the turret, complete machining in a single setup - Programmable tailstock with servo drive (Z2 axis) - Siemens Sinumerik 828D with 15″ touchscreen and ShopTurn workshop programming - 30° inclined bed, FEM optimized, cast iron - Halter LoadAssistant Universal Big 70 robot cell, mounted and ready for operation (see photos) FACTORY-INSTALLED SPECIAL EQUIPMENT (installed on the machine) - 24-tool turret BMT 65, Hirth gearing (1 s/position) - Automatic tool measuring arm (tool setter) - Tailstock programmable, hydraulic clamping, mount for rotating center - Auto-power-off after program end - Automatic door with servo drive - Three-jaw power chuck Ø 305 mm (12″) with hydraulic draw-in mechanism - 3x Eppinger driven tool holders (drilling/milling head, VDI40/BMT 65) Itsdpjzi Da Rofx Aayok - LNS hinged belt chip conveyor and LNS Turbo HB coolant filtration system - Dormatec ADF oil mist extraction system (filter level 99.97 %, 65 dB) - 20 kVA transformer separately wired - Absolute encoder on all axes HALTER LOADASSISTANT UNIVERSAL BIG 70 (Automation) A Halter robot cell with a Fanuc six-axis robot M-710iC/70 is mounted on the machine (see photos: robot arm with Halter lettering directly on the machine). Cell equipment: - Fanuc robot M-710iC/70, payload up to 70 kg - Workpiece placement via rotary table/loading tray - Workpiece-specific grippers for loading the main spindle - Safety enclosure The cell is designed for this machine and is ready for operation, eliminating the need for additional investment in automation. CONDITION Used machine, unused, no operating hours since installation at the original buyer. Sold "as is", warranty excluded (used machine). Inspection recommended before placing an order. OUR SERVICE On-site or online inspection in the Nuremberg area, transport, installation and commissioning as a separate package upon request, direct German-speaking contact person for spare parts and support, financing possible via leasing/hire-purchase partners, member of the FDM, the German trade association for wholesale trade in machinery and tools. Since this is a single unit, subject to prior sale. Call or write to us, and we will arrange an inspection appointment as soon as possible.

Condition: good (used), Year of construction: 1997, Mazak VTC-30C – Technical Specifications X-axis travel: 1,660 mm Y-axis travel: 760 mm Iodezvffbspfx Aaystk Z-axis travel: 660 mm Table size: 2,000 × 760 mm Spindle speed: 7,000 rpm Spindle taper: CAT 50 / ISO 50 Tool magazine capacity: 24 tools Max. table load: approx. 1,200 kg Control: Mazatrol Machine type: Vertical Machining Center Moving column design Long table suitable for large workpieces and pendulum machining

Condition: ready for operation (used), Year of construction: 2003, CNC Milling Machine OPS Type OPS HSC 600 Year of manufacture 2003 CNC control Andronic 3D path control with Ethernet interface Itedpfozvax Nex Aayjk Travel distances X/Y/Z 625/375/350 mm Tool changer based on Erowa system, 40 positions Spindle speeds 5,000 – 40,000 rpm Fixed table, load capacity up to 600 kg Travel speed up to 20 m/min Repeatability 0.002 mm Tool changer, 32 positions Spindle HSK 32 E Drive power 9 kW Weight 3,500 kg Price: Euro 4,500.00 (plus VAT), ex works.

Condition: used, Year of construction: 2001, functionality: fully functional, Machine Data • Gantry system with fixed table and moving portal for minimal footprint • Base, bridge, and bridge columns made from steel, welded in one piece, stress-relieved and machined • Main machine assemblies are ribbed welded constructions, optimized for the best stiffness-to-weight ratio, vibration damping, and high acceleration • Each machine design is verified and optimized via finite element analysis (FEA) to ensure maximum quality, performance, and safety • Easily accessible machine table for straightforward loading and unloading with forklift or overhead crane • Ground precision linear guides with high preload and additional cover bands for optimal chip removal on all axes • Brushless digital A/C servo motors and controllers on all axes • Dual-sided, synchronized drive on the X-axis (gantry drive) • Rack and pinion drive on X and Y axes • Precision ball screws with double pillow block support on the Z-axis • Precision planetary gearboxes with low backlash • Fully enclosed cable drag chains protect cable harnesses from chips and dust • High-quality shielded cable drag chain wiring ensures superior protection against faults and failures • X-axis working area: 1,540 mm • Y-axis working area: 1,540 mm • Z-axis clearance: 150 mm • Z-axis travel: 200 mm • Network connection via Ethernet • Remote maintenance via Internet FlexiCAM Control • DIN-ISO 66025 G-code compatible • Includes TCP/IP network interface • 256 MB RAM • Simple operation via handheld control unit with display Spindle with Manual Tool Change • Power consumption: 2.2 kW • 5,000–24,000 rpm, steplessly programmable Itsdpfx Aex E Ttboayjk • Cooling by integrated electric fan Extraction System for Manual Tool Change • Hose connection diameter: 80–90 mm FlexiCAM Midrange Vacuum Table (Side Channel Blower) • T-slot profiles, individual ball valves, 6 zones • Side channel blower: 7.5 / 9 kW • Approx. 558 m³/h (50 Hz) or 654 m³/h (60 Hz) Safety Devices • CE-compliant to DIN EN 13849 • Includes EMC filter, emergency stop • Light barrier system controlled by machine controller

Condition: excellent (used), Year of construction: 2025, Year of manufacture 2025, low operating hours Fanuc 0i-TF Turning diameter: 400 mm Turning length: 850 mm Main spindle: 3,500 rpm, 22 kW Turret: 12/24 stations, BMT65 Driven tools: 6,000 rpm Y-axis: +/- 55 mm C-axis Chuck: 250 mm Coolant: 6.5 bar Chip conveyor Tool measurement Programmable tailstock Commercial sale with invoice from our warehouse in 73061 Ebersbach For an exact price and in case of questions, please send a message with your email. Please understand that a quotation will only be sent upon receipt of your complete data. Isdpfx Asyuuibjaystk Loading and shipping possible.

Condition: used, Year of construction: 2015, Technical details: turning diameter: 65 mm turning length: 120 mm control: Index C200-4D SL z-axis main spindle travel: 390 mm z-axis subspindle travel: 390 mm x-axis subspindle travel: 600 mm Travel Y1: ± 80 mm Travel y2: ± 80 mm x-axis rapids: 45 m/min y-axis rapids: 15 m/min Isdpfxsyxpads Aayjtk z-axis rapid travel: 45 m/min Spindle 1 RPM: 5000 1/min Spindle 1 Power: 35,5/27,5 kW Spindle 1 Torque: 170 /125 Nm Spindle 2 RPM: 5000 1/min Spindle 2 power: 35,5/27,5 kW Spindle 2 torque: 170/125 Nm c-axis: 0,00014 ° bar material dia.: 65 mm spindle nose: AD 140 spindle bore: 85 mm Milling spindle 1 RPM: 18000 1/min Milling spindle 1 power: 11 kW Milling Spindle1 torque: 19 Nm Milling spindle 2 RPM: 18000 1/min Milling Spindle 2 power: 11 kW Milling spindle 2 torque: 19 Nm B-axes swivel angle: 230 ° B-axes torque: 440 Nm B-axes angle resolution: 0,001 ° Milling spindle 1 & 2 tool magazine: 80 HSK A40 Milling spindle 2 tool magazine static tools : 6 x VDI 25 internal coolant system feed: Knoll 80 bar / Ecofluid weight of the machine ca.: 16,3 t dimensions of the machine ca.: 3,73x2,92x2,58 m Accerories Chip conveyor Spindle 1 Chuck SMW HFKN 165-46 mm Spindle 2 Chuck SMW HFKN 165-46 mm Collet chuck main spindle Hainbuch Spanntop Collet chuck subspindle Hainbuch Spanntop Barfeeder Interface Unimag Short bar loader IRCO ILS RBK 10016 Parts catcher for main- and sub-spindle Conveyor for partsdisposal Air Filter Büchel High performance heavy duty turning and milling center with 2 multi axis milling heads and two spindles. Both milling heads are full 5-axis. The z-axes are installed in the spindle heads The x2 axis is installed in the spindle head of the subspindle Milling1 head has x/y/b -axes Milling head 2 has y/b-axes Both milling heads have B-(Swivel-)axis 230° The machine is equipped with an IRCO short barfeeder and parts gripper for finished parts. Max. dim for finished parts: Ø 65 mm, length 120 mm, weight 5 kg. Rest piece length 200 mm All linear- axes are equipped with linear scales. Coolant through main and subspindle. Tool breakage control from drill Ø 1mm All existing tool from machine are part of delivery Machine is in excellenten Condition! *

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, * Mori Seiki NL 2500 SY. * Year 2009. * Y-axis. * C-axis. * 5-axis machine. * 1.5-meter Lns Quick Load bar loader. * Sub-spindle. * 12-station turret, all stations motorized. * Y-axis travel: ±60 mm. * C-axis on both spindles. * Integrated main spindle motor: 18 kW. * Integrated sub-spindle motor: 15 kW. * Direct-drive motor for powered tools: 5.5 kW. * Motor starting torque: 640 N·m. * Motors without belts or gear stages. * Main spindle size: A2-8. * Sub-spindle size: A2-6. * Bar capacity: 80 mm. * 250 mm Kitagawa B-210 main spindle chuck with metric system. * 210 mm Kitagawa B-208 sub-spindle chuck with metric system. * Prismatic guides on all axes. * Main spindle speed: 4,000 rpm. * Motorized tool speed: 6,000 rpm. * Daikin oil cooler for both spindles. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitor. * Rapid traverse speed: 30 m/min on the X and Z axes. * Turret indexing time: 0.2 seconds. * Two Renishaw arms for automatic tool measurement. * Communication ports via USB, PCMCIA card, and RS-232. * Installation interface for bar loader. * Automatic workpiece collector. * Dual pedal for independent opening and closing of the main spindle and sub-spindle. * Side-mounted hinged chip extractor. * Extensive range of static and motorized tool holders. * Electrical transformer. * Documentation, parts list, electrical schematics, programming, and operating manual. * Weight: 5,800 kg. * Machine is currently in operation. * It is essential to check the precision videos. * Immediate delivery, unless sold immediately. Itjdpfxszuxm As Aaysk

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, machine/vehicle number: TJGP2065, TAKISAWA TM-4000Y2 FANUC 31i B2 - TOTALLY AS NEW BUILT 2023 CNC MULTITASKING LATHE WITH UPPER & LOWER Y-AXES 10 INCH + 8 INCH STANDARD CHUCK SIZE. WITH:- Y-AXIS TRAVEL -50 +70 MM - UPPER TURRET (Y1 AXIS) Y-AXIS TRAVEL -50 +30 MM - LOWER TURRET (Y2 AXIS) CHIP CONVEYOR - RIGHT SIDE DISCHARGE HINGE TYPE (MORETECH JAPAN) AIR BLOW SYSTEM - RH SPINDLE ABNORMAL LOAD DETECTION FUNCTION WORK PHASE POSITIONING FUNCTION (C-AXIS TORQUE SKIP FUNCTION) COOLANT DELIVERY PIPE ABOVE THE SPINDLE - LH & RH SPINDLE COOLANT PUMP - 400W - 3 OFF OIL SKIMMER (OIL / WATER SEPARATOR) OIL SEPERATOR BOX HYDRAULIC PRESSURE SWITCH LED LIGHTING AUTO LUBRICATION SYSTEM AND COLLECTOR MACHINE MANUALS & OPERATOR HANDBOOKS TURRET MOUNTED MACHINE LEVELLING PLATE AUTO POWER OFF TRANSFORMER - 415V / 3PH / 50HZ STANDARD TOOLING PACKAGE Ijdpfx Aexrnwleaystk TURRET COVER (6 EA) X 2 SERVO TURRET (LOWER) Y2 AXIS - 12 STATION WITH DRIVEN TOOLS SERVO TURRET (UPPER) Y1 AXIS - 12 STATION WITH DRIVEN TOOLS 8" 3-JAW THRU-BORE HYDRAULIC CHUCK ~ KITAGAWA BR-08 RH SPINDLE 10" 3-JAW THRU BORE HYDRAULIC CHUCK (KITAGAWA BR-10) - LH SPINDLE DIRECT DRAWING DIMENSION INPUT HELICAL INTERPOLATION FUNCTION RAKU-RAKU MONITORING SYSTEM BAR HI PRESS COOLANT PUMP (NIHON) 2 OFF CALL LAMP (3 COLOUR) BAR FEEDER INTERFACE FOR MULTI BAR MAGAZINE UNLOADER WITH PARTS DISCHARGE CONVEYOR QUICK TOOL SETTING DEVICE - MANUAL TYPE BOTH TURRETS AI CONTOUR CONTROL II CHIP CONVEYOR UPGRADE (MORETECH JAPAN) AXIAL DRIVEN TH, ER32 OUTPUT, 6000 RPM, 1:1 RATIO, EXT COOLANT - 4 OFF RADIAL DRIVEN TH, ER32 OUTPUT, 6000 RPM, 1:1 RATIO, EXT COOLANT - 4 OFF MACHINE FEATURES TWIN SPINDLE, TWIN TURRET Y-AXIS CNC TURNING CENTRE. 2 OFF 12 STATION HIGH ACCURACY SERVO TURRETS LEFT HAND SPINDLE – 4,200 RPM RIGHT HAND SPINDLE - 5,000 RPM UPPER & LOWER TURRETS - 6,000 RPM LIVE TOOLING SPEED UPPER TURRET Y1-AXIS (- 50 + 70 MM) LOWER TURRET Y2-AXIS (- 50 + 30 MM) 10” + 8” STANDARD CHUCK SIZE MACHINE CAPACITIES Standard Turning Diameter Ø 215 MM Maximum Turning Diameter Ø 215 MM Maximum Turning Length 800 MM Bar Capacity Left Spindle Ø 82 MM Bar Capacity Right Spindle Ø 65 MM AXIS TRAVELS Upper Turret Travel X1 230 / 120 MM Upper Turret Travel Y1 120 (- 50 + 70) MM Upper Turret Travel Z1 800 MM Lower Turret Travel X2 210 / 80 MM Lower Turret Travel Y2 80 (- 50 + 30) MM Lower Turret Travel Z2 800 MM Travel A (RH Spindle) 900 MM LEFT SPINDLE Chuck Size Ø (10”) 254 MM Spindle Speed (RPM) 4,200 RPM Min. Indexing Angle (C-Axis) 0.001 DEG Spindle Nose A2-8 Spindle Bore Ø 94 MM RIGHT SPINDLE Chuck Size Ø (8”) 203 MM Spindle Speed 5,000 RPM Min. Indexing Angle (C-Axis) 0.001 DEG Spindle Nose A2-6 Spindle Bore Ø 77 MM Inner Bearing Dia.120 TURRETS Number of Tools (Upper/Lower) 12 Turning Tool Shank 25 MM Boring Bar Shank Dia. 40 MM Milling Shank Diameter 20 MM Driven Tool Speed 6,000 RPM Number of Driven Tools (Upper & Lower) 12 FEEDRATES Upper Turret Rapids- X1 / Y1 / Z1 20 / 12 / 30 M / MIN Lower Turret Rapids - X2 / Y2 / Z2 20 / 12 / 30 M / MIN Rapids on A (Right Spindle) 30 M / MIN MOTORS Spindle Motor - LH 18.5 / 15.0 KW Spindle Motor - RH 15.0 / 11.0 KW Turret Driven Tool Motor 7.5 / 3.7 KW Axis Feed Motors - X1 / Y1 / Z1 2.5 / 2.5 / 2.5 KW Axis Feed Motors - X2 / Y2 / Z2 2.5 / 1.2 / 2.5 KW SUPPLY 50 KVA MACHINE L 4,741 MM W 2,748 MM H 2,444 MM 9,370 KG

Year of construction: 1989, condition: ready for operation (used), X-axis travel: 700 mm, Y-axis travel: 550 mm, Z-axis travel: 500 mm, spindle speed: 25 to 4200 rpm, three speed ranges, feed rate: 1 to 5000 mm/min, rapid traverse in X, Y and Z: 10 m/min, vertical quill travel: 95 mm, clamping table dimensions: 1000 x 500 mm, spindle motor power: 12 kW, connected load: 18 kW, control system: Heidenhain TNC 355, length: 4260 mm, width: 4400 mm, height: 2300 mm, weight: 3.5 t, operating hours: 31,248 h. The machine is equipped with an SK40 tool spindle in accordance with DIN 2079, a swivelling spindle head, a spindle head that can be swung away for machining with the horizontal spindle, an outboard support for horizontal machining, direct measuring systems, a coolant system with a 100 litre reservoir, approximately 38 tool holders, most of which are fitted with tools, a table with tool holders, a workbench with cabinet, various hand tools, various clamping devices, a three-jaw chuck with clamping ring and documentation. The screen has burn-in marks but is still readable. An on-site inspection is possible. Itodpfezrn Ikex Aaysk
