Used Emag Vl5I F. for sale (34,148)

Condition: used, Year of construction: 2017, control Fanuc - - - - - - - - - - - - - - - - - - Dedpfx Aey N D Svod Nocg Vertical Turning Machine | EMAG - VL 4 with driven tools, equipped with a workpiece conveyor belt, a chip conveyor, and a coolant system The machine is in a well-maintained condition. Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL4 | VL-4

Condition: used, Year of construction: 2017, control Fanuc - - - - - - - - - - - - - - - - - - Vertical Turning Machine | EMAG - VL 4 with driven tools, equipped with a workpiece conveyor belt, a chip conveyor, and a coolant system The machine is in a well-maintained condition. Dcjdpjy N D Spsfx Ad Njg Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL4 | VL-4

Condition: used, F J Edwards Ltd Sheet Metal Bender, Max Material Width 1850mm, Cast Iron Construction Dodpfx Asy H Ifnjd Nocg Location: These lots are located in High Wycombe, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser.

Condition: used, Year of construction: 2011, Vertical Twin-Spindle Turning Center - Siemens 840 D CNC control - VSC 400 Duo machine bed - 2 x disc turrets, 12 station, dia. 40 mm, driven - 2 x additional drilling and countersinking stations - Open workpiece transport system - Transfer and turning unit - Interface for an external handling system - Central high-pressure coolant supply with pump, 70 bar - Air blow-off for pick-up unit and clamping devices Dcodsy N Snxjpfx Ad Nog - Workpiece measurement system - Tool monitoring - Emag network option - Sister tool management system Swing diameter: 260 mm X travel: 860 mm Z travel: 200 mm Main spindles: 2 Max spindle speed: up to 4,500 rpm Spindle distance: 1,055 mm Main drive: 2 AC asynchronous motor 60% / 100% duty cycle: 39 / 28 kW Max torque: 460 Nm Rapid traverse (X / Z): 45 / 30 m/min

Condition: used, Year of construction: 2015, Technical details: turning diameter: 200 mm swing diameter: 260 mm Djdpeq Sc Hujfx Ad Njcg turning height: 60 mm

Condition: used, Year of construction: 2017, Machine type Vertical CNC turning center Manufacturer EMAG GmbH & Co. KG Model VL 4 Year of manufacture 2017 Control system Fanuc 32i-B CNC Number of axes 3 (X, Z, Y-Axis) Tool turret 12 stations, including fixed and driven holders (BMT65) Max. chuck diameter 260 mm (10.2 inches) Max. workpiece diameter 200 mm (7.9 inches) Dedpfx Asyyazbjd Nocg Max. workpiece length 200 mm (7.9 inches) X-axis 740 mm (29.1 inches) Z-axis 400 mm (15.7 inches) Y-axis ±30 mm (±1.18 inches) Rapid traverse X-axis 60 m/min Rapid traverse Y-axis 15 m/min Rapid traverse Z-axis 30 m/min Power (40% cycle) 25 kW (33.5 hp) Power (100% cycle) 18 kW (24 hp) Torque (40% duty cycle) 280 Nm Torque (100% duty cycle) 202 Nm Max. speed 4,500 rpm Machine weight Approx 10,000 kg Machine dimensions (L × W) Approx 6,000 mm × 3,600 mm

Condition: good (used), Year of construction: 2007, travel distance X-axis: 6,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 200 mm, - Speed range: [rpm]: 6,000 - Torque: [Nm]: 480 - Max. turning diameter over bed: 290 mm - Chuck diameter: 200 mm - Turret: 12-position, VDI 40, Sauter - Driven tools: 7.8 kW - Travel: - X-axis: 550 mm - Z-axis: 200 mm - Rapid traverse (X/Z) [m/min]: 30 / 20 - Feed (X/Z): [m/min.] 11 kN - Features: - Left-hand chip conveyor; 300 mm wide; ejection height 800 mm - Probe; direct linear measuring system; glass scales on all axes - Heidenhain circulating pickup tape - Machine with feed belt for part loading - Specification: Dcedey Iw Nfspfx Ad Neg - Overhauled in 2007 for approx. €50,000, complete headstock replaced. - Feed unit exchanged.

Year of construction: 1994, condition: used, We offer this used F. Zambon Rover 35 bridge saw, year of construction 1994. Manufacturer: F. Zambon Model: Rover 35 Year of manufacture: 1994 Condition: used Category ID: 431 Type: Bridge saw Dedeyuuudjpfx Ad Necg If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2014. It features a powerful main spindle drive with up to 28kW power at 40% duty cycle and a speed range of 0-4500 rpm. Equipped with a Siemens SINUMERIK 840Dsl control system and a robust 12-position EMAG flange turret, it ensures precise and efficient operations. Ideal for handling workpieces up to 6kg with its specialized hydraulic chuck. For more information about this vertical turning machine, please reach out to us. Additional equipment • Coolant tank capacity: 360 liters Machine Benefits Technical Machine Benefits • High working accuracy, rapid traverse speeds, high maximum speed of driven tools • Machine from single shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78db(a) Extra Information Dedsytfppepfx Ad Necg Machine still under power Dimensions Machine Depth 3900 mm Technical Specification Through-spindle Coolant Yes

Condition: new, For sale: industrial twin screw pump (twin spindle) by the renowned manufacturer Leistritz Nürnberg. The pump is new / stock item, unused – in excellent condition, as pictured. Identification data (from nameplate): • Manufacturer: Leistritz Nürnberg • Type / Series: LN • Model: 48/80-F-C • Serial number: 6812.129 • Design: twin screw pump (twin screw / twin spindle) Features and advantages: • Two intermeshing screws (no metal-to-metal contact) • Very low flow pulsation • Suitable for various media viscosities • High operational reliability and durability • Bidirectional operation possible • Industrial-grade continuous operation Applications: • Oils and lubricating media Dcedoyga U Hjpfx Ad Neg • Industrial and process installations • Hydraulics, power industry • Cooling / lubrication systems • Process applications Condition: • New • No damage • Ports sealed with caps • Price listed is for 1 piece.

Condition: good (used), TMZ F-102 76x106cm die cutting machine The machine is fully operational, ready to work. Made in Spain. Format 760x1060mm Weight 3600kg Power supply 380V Installed power 4.5 kW Equipment: – pneumatic clutch – control panel Dodpfjy Nfhxjx Ad Nscg – mounting frame – 3 operating modes: continuous, with time delay, manual – central lubrication – safety guards – operating tools – sheet metal for pressure

Condition: used, Year of construction: 2014, 2 Vertical Turning Machines (Tandem) Manufacturer: EMAG Model: VL 3 Year: 2014 Control: Fanuc 31/32i TECHNICAL SPECIFICATIONS FOR THE VL3 MACHINE (Subject to errors and omissions) WORKING AREA Chuck diameter: 170 mm Swing diameter: 210 mm X-travel: 400 mm Z-travel: 200 mm Dsdpfx Aoytn Emjd Nscg Loading time (depending on clamping device): 2–4 sec MAIN SPINDLE Spindle flange to DIN 55026, size 5 Spindle bearing diameter (front): 80 mm Maximum spindle speed: 7,500 rpm MAIN DRIVE AC asynchronous motor Power at 40/100% duty cycle: 25/16 kW Full power from spindle speed (100% ED): 1,800 rpm Torque at 40/100% duty cycle: 134/85 Nm FEED DRIVE Rapid traverse speed, X axis: 60 m/min Rapid traverse speed, Z axis: 30 m/min Feed force (X and Z): 5 kN Ball screw diameter (X/Z): 40 mm TURRET Cylinder shank mount DIN 69880, 12 positions Shank diameter: 40 mm ELECTRICAL EQUIPMENT according to VDE 0113 Operating voltage: 400 V Control voltage – DC: 24 V; AC: 230 V Frequency: 50 Hz Connected load without/with live tool: 28 / 31 kW Supply line protection: 50 A DIMENSIONS & WEIGHT Length: 2,500 mm Length incl. chip conveyor: 3,600 mm Width: 1,900 mm Height: 2,300 mm Weight: approx. 5,500 kg Linear roller guides in the X-axis located outside the machining area. GANTRY SLIDE INCLUDING SLIDE GUIDE Motor spindle mounting AC synchronous drives for X and Z axes Encapsulated linear measuring systems Resolution all longitudinal axes: 0.001 mm (absolute measurement) Rapid traverse: X axis 60 m/min, Z axis 30 m/min 1 MOTOR SPINDLE size 5 DIN 55026 Max. speed: 7,500 rpm Power at 40/100% duty cycle: 25/16 kW Torque at 40/100% duty cycle: 134/85 Nm HYDRAULIC UNIT with gear pump. CENTRALIZED OIL SUPPLY for lubrication of ball screws and roller guides COOLING UNIT Controls the machine’s thermal balance. Keeps motor spindle, turret, and control cabinet at ambient temperature. TOOL CARRIER SYSTEM 1 12-STATION TURRET with mounting holes Ø40 DIN 69880 Shortest indexing time via electric motor drive Cooled for consistent accuracy Internal coolant supply to tool in cut position WORKPIECE STORAGE & TRANSPORT SYSTEM 1 CIRCULATING WORKPIECE FEEDER Storage capacity: 27 workpieces (Ø 30–85 mm), or 18 workpieces (Ø 30–130 mm), Max. workpiece height: 100 mm Loading height: 1020 mm Chain-type accumulating conveyor with transport prisms Workpieces are NC-positioned for clamping device take-over. The pick-up spindle retrieves blanks from the conversion-free storage and conveyor system. COOLANT AND CHIP REMOVAL SYSTEM 1 COOLANT SUPPLY with integrated coolant tank, capacity approx. 300 l, coolant filter Coolant pump delivery rate: approx. 80 l/min at 7 bar 1 CHIP CONVEYOR Discharge height: 1,250 mm, hinge belt design 1 EMULSION MIST EXTRACTION from the machining area ADDITIONAL EQUIPMENT AND EXPANSIONS WORKPIECE STORAGE & TRANSPORT SYSTEM 1 INTERFACE FOR EMAG TRANSFER AND FLIP UNIT OP20 COOLANT AND CHIP REMOVAL SYSTEM 1 FLUSHING NOZZLES: 2x in working area, 1x in machine base HYDRAULICS & PNEUMATICS 1 MAINTENANCE UNIT FOR COMPRESSED AIR with mounting 1 PICK-UP DEVICE BLOW-OFF (2 nozzles, WITHOUT maintenance unit – see maintenance unit compressed air)

Condition: excellent (used), Catalogue number: 7983 TECHNICAL DATA Equipment: - Disc - Pre-milling unit - Tape feeder - Guillotine - Glue tank (granulate) - 4 pressure rollers (1 rubber, 3 metal) - End trimming unit with saw blades front/rear - 2 edge milling units, top/bottom with radius cutters - 2 scrapers for removing excess glue, radius, top/bottom - Corner rounding unit - Straight scraper, top/bottom Dcedpsy Id Nlsfx Ad Neg - 2 polishers - Max feed speed: 10 m/min - Min workpiece length: 260 mm - Min workpiece width: 90 mm - Workpiece thickness: 10–60 mm - Edge banding tape thickness: 0.5–3 mm - Pull-out workpiece support from the table - Total power: 12.3 kW - Extraction nozzle diameter: 140 mm - Dimensions (LxWxH): 5000x1520x1600 mm - Weight: 1295 kg ADVANTAGES - Not repainted / original paint - Pre-milling, corner rounding - Control panel with quick selection of pre-set work programs - German made - Full technical documentation (DTR) - Machine after service (inspection date: 17.10.2025, next inspection: 17.10.2026) - Very good condition - Used edgebander Net price: 38,900 PLN Net price: 9,260 EUR (based on exchange rate 4.2 EUR) (Prices may vary depending on exchange rate fluctuations)

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 6,000 rpm, overall weight: 6,500 kg, Fanuc 18ITB parts diameter 130 mm, length 110 mm spindle speed 7500 rpm 12-station turret max tool speed 6000 rpm Dsdpfxex Irzvs Ad Nscg power 24 kW, chip conveyor

Condition: used, Year of construction: 2019, Overview This keg handling package consists of a M+F Keg Technik Monomat + RMT keg washing system, a keg filling unit, and a large quantity of stainless steel kegs in various sizes, complemented by beer taps. The system is suitable for small to medium-scale brewery operations, enabling cleaning and filling of kegs for beer distribution. The washer was manufactured in 2019 and offers a compact and efficient solution for keg processing. Technical data Keg washer manufacturer: M+F Keg Technik Keg washer model: Monomat + RMT Year of manufacture: 2019 Capacity: approx. 12 kegs/hour Keg filler: Included (manufacturer unknown) System type: Semi-automatic keg washing and filling setup Equipment Keg Technik Monomat + RMT keg washer Keg filling system (standalone unit) 195 x 30 L stainless steel kegs (Type S/A) 39 x 50 L stainless steel kegs (Type S) 22 x 20 L stainless steel kegs (Type A) 22 x 10 L stainless steel kegs (Type S) 10 x beer taps (various manufacturers) Dcedpfsy D Ertjx Ad Nog

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 850 mm, travel distance Z-axis: 315 mm, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 3, Vertical turning machine manufactured in 2000. This EMAG VSC 400 features an X-axis travel of 850 mm and a Z-axis travel of 315 mm. It is equipped with live tools for enhanced functionality and track motion loading for efficient operation. If you are looking to get high-quality turning capabilities, consider the EMAG VSC 400 machine we have for sale. Contact us for further details. Dedpfjy Enpkjx Ad Nocg • Track motion loading (automation/loader) Technical Specification Driven Tools Yes

Condition: ready for operation (used), Year of construction: 1999, travel distance X-axis: 680 mm, travel distance Z-axis: 250 mm, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 3, This 3-axis EMAG VSC 315 vertical turning machine was manufactured in 1999. It features an X-axis travel of 680 mm and a Y-axis travel of 250 mm, along with live tooling capabilities. If you are looking to get high-quality turning capabilities, consider the EMAG VSC 315 machine we have for sale. Contact us for further details. Technical Specification Dedpey Enntefx Ad Necg Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2011, operating hours: 38,546 h, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, total width: 1,500 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl with integrated PLC S7-300, positioning accuracy: 1 mm, product length (max.): 3,900 mm, number of slots in tool magazine: 12, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2011. It features a Siemens SINUMERIK 840Dsl control system, a robust hydraulic 6-jaw chuck, and a flange turret with 12 tool positions. With a spindle speed up to 4500 rpm and a main spindle drive power of 28kW at 40% duty cycle, it's ideal for precise, efficient operations. For more information about this vertical turning machine, please reach out to us. Additional equipment • Hydraulic 6-jaw special chuck from EMAG with face clamping device and central lubrication • 15-inch TFT monitor • V24 interface Machine Benefits Qualitative Machine Benefits • Machine from single-shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78 db(a) • 2nd unit with yom 2014 available Technical Machine Benefits • Spindle torque: 300 nm • Vdi shaft diameter: 40 mm • Maximum speed of driven tools: 6000 rpm • Maximum torque of driven tools: 40 nm / 8. 5 kw • Coolant system standard delivery pressure: 7 bar maximum delivery pressure: 7 bar internal coolant supply pressure range: 7 bar (non-adjustable) coolant tank capacity: 360 liters • Chuck model: 6agf 260 k6 k14 • Chuck diameter: 260 mm • Chuck weight: 57 kg • Maximum clamping force for internal clamping (50 bar): 12. 8 kn • Maximum clamping force for external clamping (50 bar): 4. 2 kn Extra Information Machine still under power Dcsdpfx Ajy Ehckjd Nog Dimensions Machine Depth 3900 mm Technical Specification Driven Tools Yes

Condition: used, Year of construction: 2013, functionality: limited functionality, machine/vehicle number: 105032, Technical characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse in Z: 30 m/min - Standard integrated automation (number of loading nests by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle according to DIN 55026: Size A5 - Maximum spindle speed: 6,000 rpm - Spindle power (100%/40% duty cycle): 18.1 / 13.9 kW - Spindle torque (100%/40% duty cycle): 77 / 59 Nm Tool Turret with Driven Tools - Tool holders according to DIN 69880: 12 positions - BMT65 - Maximum tool length including holder: 190 mm - Maximum tool speed: 6,000 rpm - Maximum torque: 27 Nm (10% duty cycle), 14 Nm (100% duty cycle) Electrical Equipment - Operating voltage: 400–480 V, 80 A - Connected load: 27 kVA Dimensions - Overall dimensions: Length = 4,350 mm (with chip conveyor), Width = 1,600 mm, Height = 2,500 mm - Weight: 5,500 kg Main Features and Capabilities: - Vertical Design: Optimised for chip evacuation and easy loading/unloading - Control: GE Fanuc FS 32i B - High Precision: Positioning accuracy on X and Z axes ±0.001 mm, Haidenhain linear scales - Main Spindle: High power output and wide speed range - In-process Control: Marposs T25 measurement probe Dedpfx Ajxxwztod Nscg - Automated Loading/Unloading: Parts are automatically loaded and unloaded by integrated automation - Live Tooling: Capable of drilling and milling with driven tools - Tool Life Monitoring with Sister Tool Management - Chip Conveyor, Coolant System, Switchable Dual Cartridge Filter, High Pressure Pump (15 bar) - Fully Enclosed Work Area, Work Area Lighting - Documentation: Electronic available; paper manual not complete Machine Condition: WORKING - Operator panel safety switch is broken

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: P-30010521, Technical specifications: Djdpfjxxt D Rox Ad Njcg Work Area - Maximum diameter of clamping plate: 260 mm - Maximum turning diameter: 260 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 110 mm - X-axis travel: 570 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 200 mm / Rapid traverse in Z: 30 m/min - Y-axis travel: 40 mm / Rapid traverse in Y: 30 m/min - Standard closed automation (number of loading magazines by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle according to DIN 55026: Size 6 - Maximum spindle speed: 4500 rpm - Power at 100% / 40% duty cycle: 18 / 27 kW - Torque at 100% / 40% duty cycle: 202 / 303 Nm Tool Turret with Driven Tools - Tool holder for cylindrical shank DIN 69880: 12 - VDI40 - Number of turret stations: 12 - Max. tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm, 100% duty cycle: 14 Nm Electrical Equipment - Operating voltage: 400 - 480 V - Connected load: 42 kW Dimensions - Total machine dimensions: Length = 2680 mm (3820 mm with chip conveyor), Width = 2040 mm, Height = 2400 mm - Weight: 6500 kg Main Features and Capabilities - Vertical design: Enables optimal chip removal and easy loading/unloading - Control system: GE Fanuc Series 18i TB - High precision: Positioning accuracy on X/Z axes is ±0.001 mm thanks to Heidenhain linear scales - Main spindle: High power and wide speed range - Automated loading/unloading: Parts are loaded and unloaded via integrated automation - Driven tools: Enables drilling and milling operations - Chip conveyor - Documentation: Electronic version not available, printed manual incomplete Machine status: NOT WORKING - Spindle drive - X-axis linear scale - Safety access door (Euchner) - Emulsion solenoid valves x2

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 108113, Technical Characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse Z: 30 m/min - Standard automation with closed system (number of loading nests by workpiece diameter: 14/(80–200), 18/(30–160), 30/(30–85)) Main Spindle - Spindle interface per DIN 55026: Size A5 - Maximum spindle speed: 6000 rpm - Power (100% / 40% duty cycle): 18.1 / 13.9 kW - Torque (100% / 40% duty cycle): 77 / 59 Nm Tool Holder with Driven Tools - Tool shank per DIN 69880: 12 – BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque (10% duty cycle): 27 Nm; (100% duty cycle): 14 Nm Electrical Equipment - Operating voltage: 400–480 V, 80 A - Connected load: 27 kVA Dimensions - Total dimensions (L x W x H): 4350 mm (with chip conveyor) x 1600 mm x 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical Design: Optimized for chip removal and easy loading/unloading - CNC Controller: GE Fanuc FS 32i B - High precision: Positioning accuracy in X and Z axes ±0.001 mm with Heidenhain linear scales - Main spindle: High power and broad speed range - In-process control: Marposs T25 measuring probe - Automated loading/unloading: Integrated automation for feeding and removing parts - Live tools: Capability for drilling and milling operations - Tool life monitoring and sister tool management Dcsdpfxsxxip Aj Ad Nog - Chip conveyor & Knoll coolant filtration unit with paper filter and 40 bar pumps (suitable for filtering two machines) - Fully enclosed work area, with work area lighting - Documentation: Electronic version available, printed booklet incomplete Machine Status: - NOT WORKING - LT motor defective, repairable - Operator panel, safety switch, and two buttons broken and need replacement

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: 107786, Technical characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse in X: 60 m/min Djdpfoxw Slkjx Ad Njcg - Z-axis travel: 375 mm / Rapid traverse in Z: 30 m/min - Standard closed automation (number of loading stations per workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle as per DIN 55026: Size A5 - Max. speed: 6000 rpm - Power at 100 / 40% duty cycle: 18.1 / 13.9 kW - Torque at 100 / 40% duty cycle: 77 / 59 Nm Tool Turret with Driven Tools - Toolholders per DIN 69880: 12 × BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque at 10% duty cycle: 27 Nm; 100% duty cycle: 14 Nm Electrical Equipment - Operating voltage: 400 - 480 V, 80 A - Connected load: 27 kVA Dimensions - Overall dimensions: Length = 4350 mm (with chip conveyor), Width = 1600 mm, Height = 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical construction: optimal chip evacuation and easy part loading/unloading - Control: GE Fanuc FS 32i B - High precision: positioning accuracy in X and Z axes ±0.001 mm (Heidenhain linear scales) - Main spindle: high power and wide speed range - In-process control: Marposs T25 measurement probe - Automated loading/unloading: integrated automation feeds and removes workpieces - Driven tools: enhances machining capabilities for drilling and milling - Tool life monitoring with sister tool management - Chip conveyor - Fully enclosed work area; workspace lighting - Documentation: Electronic available; physical manual incomplete Machine Condition: NOT WORKING - Operator panel touchscreen needs replacement - Hydraulic cylinder for loading door broken - Emulsion pump - Hydraulic pump - Spindle clamp/unclamp sensor - Hydraulic accumulator - Turret motor

Condition: repair required (used), Year of construction: 2008, functionality: not functional, machine/vehicle number: 101850, Technical characteristics: Work Area - Maximum clamping plate diameter: 260 mm - Maximum turning diameter: 260 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 110 mm - X-axis travel: 570 mm / Rapid traverse (X): 60 m/min - Z-axis travel: 200 mm / Rapid traverse (Z): 30 m/min - Y-axis travel: 40 mm / Rapid traverse (Y): 30 m/min - Standard enclosed automation (number of loading nests according to workpiece diameter: 14/(80–200 mm), 18/(30–160 mm), 30/(30–85 mm)) Main Spindle - Spindle according to DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Power at 100% / 40% duty cycle: 18 / 27 kW - Torque at 100% / 40% duty cycle: 202 / 303 Nm Tool Carrier With Live Tools - Cylindrical shank holders per DIN 69880: 12 – VDI40 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6,000 rpm - Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm, 100% duty cycle: 14 Nm Electrical System - Operating voltage: 400–480 V - Connected load: 42 kW Dimensions - Overall dimensions: Length = 2,680 mm (3,820 mm with chip conveyor), Width = 2,040 mm, Height = 2,400 mm - Weight: 6,500 kg Main Features & Capabilities: - Vertical design: Ensures optimal chip evacuation and easy part handling. - CNC control: GE Fanuc Series 18i TB. Dcedpfx Aoxvyh Red Njg - High precision: Positioning accuracy in X, Z, and Y axes ±0.001 mm with Heidenhain linear scales. - Main spindle: Delivers high power and a wide speed range. - Automated loading/unloading: Integrated automation system for parts feed and retrieval. - Live tooling: Supports live tools for extended machining operations including drilling and milling. - Chip conveyor. Machine Condition: NOT WORKING - Live tool drive motor - X-axis optical scale - Z-axis optical scale - Z-axis belt - Z–X-axis servo drive - X, Z-axis optical scale cables - Coolant pump

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: M250.81009, Technical characteristics: # Main Drive: * Connected Load: 400 V/50 Hz / 43 kW * Main Spindle Drive Power (100% duty cycle / 40% duty cycle): 18 kW / 28 kW * Main Spindle Torque: 300 Nm * Spindle Speed Range: 0-4500 rpm * Spindle Nose: DIN 55026-A6 # Working Area: * Rapid traverse, X-axis: 60 m/min * Rapid traverse, Z-axis: 30 m/min * Feed force, X-axis: 10 kN * Feed force, Z-axis: 10 kN # Control System: * Siemens SINUMERIK 840Dsl * 15'' TFT monitor # Working Accuracy: * Axes (X / Z): ±0.001 mm * Spindle (C-axis): ±0.01° # Tool Carrier: * EMAG Flange Turret, Generation C361 - Capto C5 * Tool shank diameter: TN340009 * Max. tool dimensions: Workpiece-dependent * Tool change times (turret / driven tool): 0.03 min / 0.04 min * Max. speed, driven tool: 6000 rpm * Max. torque, driven tool (100% duty cycle / 10% duty cycle): 15 Nm / 3.5 kW / 40 Nm / 8.5 kW # Coolant System: * Standard delivery pressure / Max. delivery pressure: 7 bar * Pressure range for internal coolant supply: 7 bar (non-adjustable) * Coolant tank capacity: 360 liters # Part Handling: * No part catcher installed. Parts are loaded and unloaded via automation. * Ambient conditions (Room temperature / Humidity): up to approx. 30°C / max. 50% * Noise levels (Sound pressure / Sound power): 78 dB(A) # General Data: * Machine dimensions (L x W x H): 3900 mm x 1500 mm x 3200 mm * Machine weight: approx. 7,000 kg Main Features and Capabilities: Djdpfxjxvx T So Ad Njcg # Vertical Design: Optimized for chip evacuation and convenient loading/unloading. # Control: Siemens SINUMERIK 840Dsl with integrated S7-300 PLC and 15'' TFT monitor. # High Precision: Positioning accuracy in X and Z axes of ±0.001 mm. # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Workpieces are handled automatically through integrated automation systems. # Driven Tools: Capability to use driven tools for extended machining, including drilling and milling operations. # Chip Conveyor # Equipped Chuck: EMB3 Expanding Mandrel (Autoblock) # Capto C5 Tool Holders on Turret (for external/internal machining, 2 units & 2 driven tools) # Tool Load Monitoring: Artis system capability available

Condition: used, Year of construction: 2007, functionality: fully functional, machine/vehicle number: 100864, Technical Specifications: Work Area - Maximum clamping plate diameter: 260 mm - Maximum turning diameter: 260 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 110 mm - X-axis travel: 570 mm / Rapid traverse X: 60 m/min - Z-axis travel: 200 mm / Rapid traverse Z: 30 m/min - Y-axis travel: 40 mm / Rapid traverse Y: 30 m/min - Standard closed automation (number of loading nests per workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle according to DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Power at 100/40% duty cycle: 18 / 27 kW - Torque at 100/40% duty cycle: 202 / 303 Nm Dcjdpfjxxttfox Ad Nsg Tool Turret with Driven Tools - Tool holder shank according to DIN 69880: 12 - VDI40 - Number of turret positions: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6,000 rpm - Maximum torque: 37 Nm (10% duty cycle), 26 Nm (25% duty cycle), 14 Nm (100% duty cycle) Electrical Equipment - Operating voltage: 400 - 480 V - Connected load: 42 kW Dimensions - Overall dimensions: Length = 2,680 mm (3,820 mm with chip conveyor), Width = 2,040 mm, Height = 2,400 mm - Weight: 6,500 kg Main Features and Capabilities: - Vertical Design: Ensures optimal chip evacuation and easy loading/unloading operations. - Control System: GE Fanuc Series 18i TB. - High Precision: Positioning accuracy in X and Z axes: ±0.001 mm (Heidenhain linear scales). - Main Spindle: High power and wide speed range. - Automated Loading/Unloading: Parts are automatically fed and removed via integrated automation. - Driven (live) tools: Enables drilling and milling operations in addition to turning. - Chip conveyor included. - Documentation: Electronic manual not available; printed book manual available. Machine Status: Operational, in working condition.
