Used Fmb Phoenix for sale (260)

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, Machine description and equipment* Max. diameter: 26 mm Max. turning length (fixed guide bushing): 320 mm Rapid traverse: 32 m/min Main spindle power: 5.5 kW Main spindle speed: 0 – 8000 rpm C-axis (main spindle): 5° Max. diameter of sub-spindle: 26 mm Number of controlled axes: 9 Bar feeder: FMB Turbo 3-32 Specific details Turning length: 320 mm Turning diameter: 26 mm Spindle power: 5.5 kW Speed min-1: 8000 Tedpszg Nuusfx Afweb Number of axes: 9 Bar feeder magazine: FMB Turbo 3-32

Year of construction: 2023, condition: new, ! Machine offer for customers in Lithuania / Latvia / Estonia. The LVD PHOENIX laser is fiber laser cutting machine which combines high dynamics with flexibility for cutting thick material. PHOENIX is available in different sizes: 3m x 1,5 m, 4m x 2 m and 6m x 2m. Power source varies from 4kW to 20 kW. As standard machine is equipped with automatic shuttle tables, cutting head, adaptive collimation unit (until 12kW), capacitive height sensing, automatic nozzle cleaning, automatic sheet referencing, automatic cutting gas selection (oxygen, nitrogen and compressed air), chiller and fume extraction, SIEMENS control unit. The PHONEX laser cutting machines are compatible with huge range of automatization solutions such as loading / unloading and sheet storage (up to 6 meters), nozzles changer. Shuttle table All PHOENIX lasers come with automatic shuttle tables. The height of the table is 930 mm. The speed of table change depends on laser size: for 3015 – 35 sec., for 4020 -39 sec. and for 6020 – 48 sec. Tables on PHOENIX 4020 and 6020 models are split into 2m x 1m modules for easy replacement. Cutting head Laser source power on PHOENIX laser cutting machines varies from 4 to 20 KW (available: 4kW, 6kW, 10kW, 12kW, 20kW). The cutting head for 4 – 12 kW lasers could be equipped with 150 or 200 mm focusing lens, for powerful 20kW lasers – 250 mm focusing lens are used. Todpsiy N Npofx Afwjb Frame The PHOENIX 3015 model has a welded steel mono frame construction. This allows high accelerations without losing the accuracy. Due to the high frame rigidity, no special foundations are requested. The frame of PHOENIX 4020 and 6020 exists out of 4 parts. One rigid left and right frame that are connected with two bolted beams.

Condition: excellent (used), Interface converter, converter module, FL Comserver, interface converter, interface converter, interface converter -Manufacturer: Phoenix Contact, Interface converter, original packaging -Type: PSM-EG-RS232/TTY-P/2K Ord.-No. 27 61 253 -Quantity: 1x Converter available -Cardboard dimensions: 120/90/H70 mm -Weight: 0.3 kg Tedpfxeldk H Uj Afwob

Condition: used, mileage: 171,050 km, power: 120 kW (163.15 HP), first registration: 08/2021, fuel type: diesel, overall weight: 3,500 kg, color: white, gearing type: mechanical, emission class: euro6, number of seats: 3, total length: 6,946 mm, total width: 2,035 mm, total height: 2,455 mm, loading space length: 4,200 mm, loading space width: 2,100 mm, loading space height: 2,100 mm, Equipment: ABS, air conditioning, central locking, electronic stability program (ESP), soot filter, tail-lift, Internal vehicle number: 3350 ----Why autonext? Over 400 cars & commercial vehicles immediately available. One of the largest vehicle showrooms in the region. Over 1,000 satisfied customers annually - top customer ratings. Attractive financing & trade-in options possible. Complete vehicle selection at autonext. Mobility made easy. Tjdpfxozaqwlo Afwsb WhatsApp Chat: ### Offer: Financing from 4.99% ### ----Get a clear picture now: See the vehicle completely from the outside and inside via the YouTube link: Good and well-maintained condition. 1st owner, German vehicle, non-smoker vehicle. Complete service history, only serviced at Mercedes Benz. Like-new all-weather tires on the front. Body: Maxi (wheelbase 4325 mm) Hydraulic loading platform "Bär" Rear view camera Integrated Phoenix safe with numeric code in the driver's cab Regulated air conditioning (Tempmatik) Bumpers and radiator grille frame in vehicle color Comfort driver's seat Roof spoiler Loading area length: 4.20m Loading area height: 2.10m Loading area width: 2.10m ---- Special equipment: * Multimedia system MBUX (touchscreen 7") * Bluetooth hands-free system * Steering wheel with multifunction buttons * 2nd battery (auxiliary battery) interior * Extended exterior mirror base left/right * Passenger-optimized center console (without storage compartment in the center console on the right) * DAB tuner (digital radio reception) * Chassis: Stabilization level II * Generator 250 A * Folding cover for storage compartment * Regulated air conditioning (Tempmatik) * Chrome radiator grille * Radiator grille frame in vehicle color * Smoker's package * Seats in the driver's cab: passenger double seat * Seats in the driver's cab: comfort driver's seat * Red fuel filler cap * Additional battery relay * Rear wall cladding Standard equipment: Storage compartment above the windshield, storage compartment below the dashboard on the passenger side, towing eye at the rear, adaptive brake light, airbag driver side, Anti-lock Braking System (ABS), Anti-slip regulation (ASR), drive type: rear-wheel drive, display for windshield washer fluid level, exterior mirrors electrically adjustable and heated, both, outside temperature display, brake assist, headliner in the driver's cab, automatic activation for driving lights, electronic brake force distribution (EBV), electronic stability program (ESP), driving assistance system: side wind assist, power windows electric 2-fold, transmission 6-speed - TSG (Eco Gear), body/structure: standard platform, keyless start, communication module (LTE) for digital services, fuel tank: main tank 71 L, steering wheel (steering column mechanically adjustable), headlight range adjustment, truck approval, marker lights on the side, Mercedes-Benz emergency call system, engine 2.1 L - 120 kW CDI CAT, particulate filter, wheelbase 4325 mm, low pollutant emissions according to exhaust standard Euro 6, safety belt system with warning system (driver side), seat cover / upholstery: fabric, seats in the driver's cab: driver's seat with armrest, start/stop system, daytime running lights, fleece battery 92 Ah, service interval display Assyst, immobilizer, heat-insulating glazing, central locking with remote control, permissible total weight 3.50 t. ----MOT/emissions test can be done upon request. ----Warranty & "TÜV Profi Check" are of course available from us! We will also gladly accept your vehicle in trade! We will also create an individual financing or leasing offer for you! Without down payment,

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 187859, turning diameter: 380 mm, spindle speed (max.): 5,000 rpm, rotational speed (max.): 4,500 rpm, bar passage: 65 mm, overall weight: 4,900 kg, Mazak QTN-200MS CNC turning and milling center, manufactured in 2006 with subspindle and driven tools Main spindle with Kitagawa chuck and Hainbuch collet chuck, 35-5000 rpm. Subspindle with Kitagawa chuck, 35-6000 rpm. All 19 tool holders, including 5 driven tools Jaws, collet chucks, wrenches and accessories shown in the photo are included. 12-position turret Todpey Tb D Dsfx Afwob Parts catcher, chip conveyor >>Bar feeder FMB SL80 V (year 2020) >>Conveyor belt The machine has been very well maintained. Hydraulic oil, lubricants, and operating fluids have been recently changed. The machine can be inspected while in operation. Model: QTN-200MS Serial number: 187859 Weight: 4900 kg Weight: 10780 lbs Year of manufacture: 2006 If you have any questions or require further information, please send us a message or call us.

Year of construction: 2010, condition: ready for operation (used), Offered is a robot-assisted laser welding system with fiber laser. Robot radius approx. 2000mm on linear axis, robot manufacturer: laser type: ytterbium fiber laser YLS, number of axes: 6 + linear travel axis, application: laser welding and surface processing, extraction: Plymovent extraction arm, control: KRC. Equipped with YLS laser source, linear axis, processing optics, Plymovent extraction, system table, control cabinet. Accessories: wire feeder: EWM Phoenix Drive 4 Rob MF. Weight: approx. 3500kg, overall dimensions X/Y/Z: approx. 5000mm/3000mm/2800mm. Inspection possible by arrangement. Tjdpfsy T N Iwex Afweb

Condition: good (used), Year of construction: 1998, INDEX ABC multi-spindle automatic lathe with INDEX C 200-4 control, serial number 400923, year of manufacture 1998, operating hours estimated at approximately 52,924 hours according to management. Includes chip conveyor DGS and bar feeder FMB 5-42. Tsdpfxeztc Rps Afwsb

Condition: new, Phoenix Contact FL SWITCH LM 4TX/2FX SN:2002362451 ,unused, 100% functional, scope of delivery according to photos Tjdpfx Afspf Arqowob

Condition: used, Year of construction: 1996, INDEX ABC multi-spindle automatic lathe with INDEX control system, serial number 400923, year of manufacture 1996, operating hours estimated at approximately 57,805 hours according to management; chip conveyor by KNOLL; bar feeder FMB Turbo 5-42/3200; known damage and defects: defective. Tsdpjztc N Eofx Afwjb

Year of construction: 2017, condition: ready for operation (used), X-axis: 607mm, z-axis: 286mm, spindle speed: max. 6000/min, control: Fanuc 32i A, length: 4600mm, width: 1600mm, height: 2700mm, weight: 2.1t, operating hours: 34,536h. With automation FMB Unirobot LR MATE 200iD7L-P2TB, grinding spindle Jäger HF-Spindle, chuck MicroCentric 4-410-3-QC, MARPOSS measuring system with automated dimensional compensation, oil mist filter S400, belt filter Knoll KF110/500, hinged belt conveyor 320 S1 and other accessories. On-site inspection is possible. Tjdpfsv Uz Akox Afwob

Condition: used, Year of construction: 2019, turning diameter over bed 32 mm spindle passage 32 mm control SIEMENS 840-D-SL spindle stroke 220 mm main spindle speeds: 6000 U/min spindle drive 5,5 / 3,7 kW Sub - spindle - bar diameter 32 mm turning speed range sub spindle 8000 U/min turning length 220 mm collets 1536E motor power 5,5 / 3,5 kW total power requirement 16 kVA weight of the machine ca. 4,3 t dimensions of the machine ca. 6,40 x 1,60 x 2,10 m MAIER Swiss lathe in very good condition with SIEMENS 840-D-SL 3-channel control system, equipped with: - 2 counter spindles - NC C-axis on main and both counter spindles - Additional 3rd channel in the form of a second counter spindle - Channel 1 with Y1 and 4 driven tool holders - Channel 2 - Back side machining, tool carrier with 4 driven and 4 fixed tool stations - Tool holders for 4 fixed turning tool holders, cross-section 16 x 16 mm - Bar loading magazine, manufacturer FMB Turbo Ø 3-36 / 3200 C - Stack magazine for holding a complete bundle of bars - Chip conveyor - Electronic handwheel - KNOLL high-pressure system 50 bar with paper belt filter system - Fire protection system, manufacturer KRAFT & BAUER - Table for removing long parts - Removal of long parts (flange + pipe) Tedpjytx Sksfx Afwjb - ARTIS - Tool and process monitoring “Genior Modular fully automatic tool and process monitoring” The machine can be inspected under power!

Condition: good (used), Year of construction: 2005, operating hours: 32,870 h, functionality: fully functional, machine/vehicle number: 6030578, turning diameter: 32 mm, spindle speed (max.): 8,000 rpm, bar diameter (max.): 32 mm, We offer for sale Traub TNL26K automatic cnc lathe. Machine is connected to power and can be inpected every time by prior appointment. Year of built: 2005 Spindle passage 32mm Main spindle: 6.7/10.7kW; 8000rpm Counter spindle: 6.7/10.7kW; 8000rpm Upper turret: 12pos. 12x12/16x16, driven tools 2/5.5kW, 0-6000 rpm, 6.4/21 Nm Lower turret: 12pos. 12x12/16x16, driven tools 2/5.5kW, 0-6000 rpm, 6.4/21 Nm Connected load: 24kW Barfeeder: FMB Turbo 5-42/4200mm Swarf conweyor: Knoll 240 S1/100 Coolant Kompaktbandfilter: Resy Tjdevldx Aspfx Afwjb Machine is sold with a lot of toolholders not driven and driven - list on attached photo.

Condition: good (used), Year of construction: 2008, CNC Swiss turn Machine type: Citizen C-32 VIII 2M8 Year: 2008 SPECIFICATIONS Main Spindle Max. turning length: 320 mm Turningdiameter: 32 mm Spindle speeds: 200 - 8.000 rpm Subspindle Spindle speeds: 200 - 7.000 rpm Driven Tools Equipment Bar loader magazine: FMB turbo 3-36 Todozim Evepfx Afweb

Condition: good (used), Year of construction: 2007, CNC Long Turning Lathe Manufacturer: Traub Machine Model: TNL 12 Control System: Traub Year of Manufacture: 2007 TECHNICAL DATA Headstock - Max. bar diameter (mm) 12.7 - Quality of round material (DIN 671) (mm) Ø Xh9 - Max. speed (rpm) 12,000 Max. turning length / headstock travel - with fixed guide bushing (mm) 130 - with rotating guide bushing (mm) 80 - with programmable guide bushing (mm) 80 C-axis resolution (degrees) 0.001 Rapid traverse Z1 (m/min) 30 Tool turret 1 - Slide travel X1 (mm) 35 - Slide travel Y1 (mm) 38 (-10 +28) - Rapid traverse X1 / Y1 (m/min) 15 - Chip-to-chip time (s) 0.3 Tool turret 2 - Slide travel X2 (mm) 35 - Slide travel Z2 (mm) 50 - Rapid traverse X2/Z2 (m/min) 15 - Chip-to-chip time (s) 0.3 Tool drive for tool turret 1 and 2 - Max. speed (rpm) 8,000 - Tools max. (number) 2xG - Clamping diameter for drilling tools (mm) 0.5-7 Counter spindle / front tool holder - Max. bar diameter (mm) 12.7 - Max. longitudinal travel 23, 24 / Xg (mm) 140 / 228 - Rapid traverse 23, 24 / X3 (m/min) 30 Tjdpfxjzr Uvhe Afwjb - Tool holders (number) 4 - Max. speed (rpm) 12,000 - C-axis resolution (GSP) (degrees) 0.001 Rear tool holder, driven / fixed - Z-axis travel with work spindle (mm) 80 - Tool holder diameter (mm) 20 - Tool holders (number) 3 Rear tool holder (X4 axis) - X4-axis travel (mm) 39 - Rapid traverse speed (m/min) 15 - Tool holder diameter (mm) 28 - Tool holders (number) 4 Tool drive for rear tool holder (with X4 axis) - Max. speed (rpm) 10,000 - Driven tools max. (number) 4 - Clamping diameter for drilling tools - Driven (mm) 0.5 - 7 - Non-driven (mm) 0.5 - 10 Coolant system - Pump pressure, single-stage (bar) 3 - Tank capacity (l) 180 - Delivery rate (l/min) 40 EQUIPMENT FEATURES - Chip conveyor - Bar loader FMB Minimag 18 - High-pressure system - Fire extinguishing system Subject to change and errors in technical data and specifications.

Condition: used, Year of construction: 1989, functionality: unexamined, Star SR-20 type 530J sliding head CNC lathe Year (1989) with Fanuc Series 16-T control Parts conveyor (belt missing) Cromer swarf conveyor (1995) Donaldson Torit oil mist filter Tsdozmamnspfx Afwjb FMB Turbo 3-26 barfeed

Condition: ready for operation (used), Year of construction: 2011, operating hours: 8,733 h, functionality: fully functional, spindle bore: 26 mm, rotational speed (max.): 7,200 rpm, number of axes: 5, number of tool turrets: 2, Long-turn lathe with an extended accessory package and spare parts! Counter-spindle: Completely re-conditioned 05/2026 Tedpjztn Imefx Afweb TECHNICAL DETAILS CNC control: GE Fanuc Series 18i-TB Number of axes: 5 Axes: X1, X2, Y, Z, C Spindle Spindle speed: 50–7,200 rpm Spindle bore: 26 mm Spindle stroke: 160 mm TURRET Number of turrets: 2 Positions per turret: 6 MACHINE DETAILS Motor power: 3.7 kW Weight: 2,600 kg Spindle hours: 8,733 h Control on: 10,642 h Feed time: 3,257 h Part counter: 478,135 EQUIPMENT - Bar feeder FMB Turbo 3-36, year of manufacture 2011 - Chip conveyor - Package of fixed and powered tool holders - Package of collets and guide bushings - Discharge system for long parts including reduction sleeves - Double-cone clamping system on the main spindle, system JBS - Breakage detection for cut-off tools, Detector France - Ejection control, Detector France - JBS guide bushing, not yet installed - Tool presetting device with optics for external tool setup - Replacement worms for chip conveyor - Mounting device for adjusting the cylinder of the working hood - Various spare parts

Year of construction: 2003, condition: ready for operation (used), Tool monitoring, thread cutting without compensating chuck, main spindle: spindle bore: 36mm, max. speed: 6300rpm, drive power: AC 6.7/10.7kW, C-axis, Hainbuch change parts, installation aid base body, Hainbuch manual changing device, counter spindle: counter spindle as motor spindle, C-axis, device for counter clamping pressure, workpiece ejector device, Hainbuch Axfix chuck, upper tool carrier, driven tools, electronic gearbox, X3 cross axis for front attachment, 5-position front attachment and cut-off side machining station with driven tools, machine and control cabinet RAL 7037 (dust grey), covers RAL 7035 (light grey), workpiece discharge device: workpiece gripper, gripper jaws D5-8, D8-20, D20-36, coolant lubrication system: tank 230l/7bar/50l/min, internal coolant supply 30bar, high pressure 120bar at the front and rear machining station, Knoll VRF 150/750 vacuum rotary filter (suitable for aluminum, plastic, brass and steel), flushing gun, connected load: 33kW, control system: TX8i (64bit), flat screen 10.4 inch, additional piece counter, V24 RS232 and MDE interface in the control cabinet, operating hours: 124,705h, with FMB TURBO 5-42XT/3200/C bar feeder magazine, chip conveyor, coolant unit and basic equipment of static and driven tool holders. An on-site inspection is possible. Tsdpfx Aoy U Nq Isfwjb

Condition: new,

Condition: excellent (used), Year of construction: 2008, operating hours: 9,000 h, functionality: fully functional, TECHNICAL DETAILS Control: Mitsubishi Meldas 700 Main Spindle Machining diameter: 20 mm Machining length without repositioning: 200 mm Spindle bore: 24 mm Spindle speed: 200 - 10,000 rpm Spindle indexing C-axis: 0.001° Motor power (built-in motor): 2.2 / 3.7 kW Sub-Spindle Machining diameter: 20 mm Spindle speed: 200 - 8,000 rpm Spindle indexing C-axis: 0.001° Motor power: 0.75 / 1.5 kW Driven Tools at Vertical Holder Speed: 200 - 4,500 rpm Motor power (AC servo motor): 1.0 kW Number of tools: 6 Tool System Turning tools (12x12x130): 5 Tool holder/parting-off blade (16x12x130): 1 Drilling tools (front): min. 3 Drilling tools (rear): 5 Tool holders, quills (diameter): 19.05 mm Tool holders, turning tools (shank cross-section): 12 mm Collets and Guide Bush Collet main/sub-spindle: F25 (145E) Guide bush (Neukomm): T223 (22.001) Rapid Traverse All axes: 32 m/min Machine Specification Required space (without magazine) L/W/H: 2,430 x 1,085 x 1,770 mm Spindle height: 1,050 mm Machine weight: 2,150 kg Power supply: 8 kVA EQUIPMENT - 6 turning tools (12 mm shank cross-section), - 3 driven tools for cross machining - 3 driven tools for face machining on the main spindle - 3 driven tools for face machining on the sub-spindle - Main spindle with C-axis - Sub-spindle with C-axis - 3x powered tool rear side machining - Yellow warning light - Interior lighting - Workpiece conveyor belt - FMB Turbo 3-26 bar feeder Tsdpfoxf Hqqox Afwsb - Option for long parts - Spindle flushing (Scherzinger pump)

Year of construction: 2002, condition: ready for operation (used), A factory-reconditioned CNC counter-spindle lathe from Traub, overhauled in 2018, including a bar feeder, is available. Main spindle bore: 36mm, speed: 6300rpm, counter spindle bore: 32mm, speed: 6300rpm, Z4 travel: 250mm, rapid traverse Z4: 30m/min, max. workpiece length: 200mm, max. workpiece diameter: 32mm, control system: Traub/Index TX8i, operating hours: approx. 147000h. Upper tool carrier: X2 travel: 50mm, Y2 travel: +/-20mm, Z2 travel: 100mm, rapid traverse X2/Y2/Z2: 15m/min, tool stations: 12, speed: 6000rpm. Front tool carrier: tool stations: 5, X3 travel: 370mm, Z3 travel: 250mm, rapid traverse X3/Z3: 30m/min, max. tool diameter: 40mm, speed: 6000rpm. Rear tool carrier: X4 travel: 73mm, Y4 travel: +/-150mm, tool stations: 5, rapid traverse X4/Y4: 15m/min, tool diameter: 40mm, speed: 6000rpm. Including Resy compact belt filter, Knoll 240S-1/100 hinge-belt conveyor, travelling workpiece stop, bar magazine mounting preparation, Brankamp CSM 100 collision monitoring system and FMB Turbo 5-42 X bar magazine, year of manufacture: 2002. Documentation available. An on-site inspection is possible. Tsdpjzkld Hjfx Afweb

Year of construction: 2013, condition: ready for operation (used), X-axis: 607mm, z-axis: 286mm, spindle speed: max. 6000/min, control: Fanuc 32i A, length: 1850mm, width: 1750mm, height: 1750mm, weight: 2.1t, operating hours: 59,861h. With automation FMB Unirobot MH5LS-SP, grinding spindle Jäger HF-Spindle, chuck MicroCentric 4-410-3-QC, MARPOSS measuring system with automated dimensional compensation, oil mist filter S400, Liqui gravity filter UR1020 with clean tank and other accessories. On-site inspection is possible. Tsdpfev Uz Adjx Afwjb

Year of construction: 2008, condition: ready for operation (used), Main spindle: max. bar capacity: 65mm, draw tube bore: 75mm, collet holder diameter: 160mm, centering chuck diameter: 175mm, spindle nose: 140mm, max. speed: 5000/min, nominal torque (S1): 150Nm, nominal power (S1): 22kW. Counter spindle: draw tube bore: 45mm, centering chuck diameter: 175mm, spindle nose: 140mm, max. speed: 5000/min, nominal torque (S1): 100Nm, nominal power (S1): 16.8kW. W2 axis counter spindle: travel: 690mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X1 axis: travel: 165mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Z1 axis: travel: 220mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X2 axis: travel: 165mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Z2 axis: travel: 150mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X3 axis: travel: 165mm, max. speed: 40m/min, max. acceleration: 10m/s², nominal thrust (S1): 2400N. Z3 axis: travel: 678mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Y3 axis: travel: 80mm (+50/-30), max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Workpiece unloading (UA-WA): max. unloading weight: 4daN, max. unloading diameter: 70mm. Total number of tool stations: 12, tool holder diameter: 30mm, driven positions: 12, max. speed of driven tools: 4000/min, nominal torque (S1-n = 0/min): 17Nm, nominal power (S1-n = 4000/min): 2.9kW, control: Siemens 840D, operator panel: ErgoLine, screen: color TFT 19 inch, number of spindles (C-axes): 2, number of axes: 10, number of channels: 4. Operating hours: 70,035h power on, 48,657h in production, machine operates with cutting oil. With documentation and Bar Loader FMB Turbo 8-80 XT 3200. An on-site inspection is possible. Tjdpfx Afsyln Ekjwsb

Condition: used, Year of construction: 1997, max. wheel diameter 215 mm gear width 40,65 mm max. module total power requirement 20 kW weight of the machine ca. 10 t Max. external Ø of workpiece 215 mm Tooth profile, height x width 16 x 40.65 mm No. of teeth 5 - 200 Max. tooth ratio 1 : 10 Grinding wheel Ø 51 - 190 mm Grinding wheel speeds 1,000 - 6,000 rpm X Axis (horizontal) 152 mm Y Axis (vertical) 178 mm Z Axis (slide base plate) 304 mm Distance from middle of machine to middle of workspindle 115 mm Axial speed 125 mm/sec Workpiece speeds 0 - 30 rpm Workspindle bore, conical 3 29/32 inch Todpfxot Hwxho Afwsb Total electrical load 20 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features * FANUC CNC Control, Model 150 MB, for 7 axes, with monitor and direct input. Automatic calculation of all workpiece and grinding parameters. * Extensive coolant equipment with filter system, band filter, etc. * Driven grinding wheel dressing device with CNC dressing control for automatic compensation of form and diameter after every dressing. * Gear grinding is effected either in single component operation using a conical cup wheel (Gleason 30°), or with a cylindrical cup wheel. These grinding wheels can be made of CBN, or of traditional "dressable" aluminium oxide material (question of cost). Grinding with a conical grinding wheel is of advantage with regard to heat build-up and quality of tooth contact pattern. Therefore these pairs of bevel gears (for automotive industry) can be generated in high quality with consistent accuracy, economically, and with short set-up times. Condition : Very good - machine can be inspected here under power Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.

Year of construction: 2021, condition: ready for operation (used), X-axis: 607mm, z-axis: 286mm, spindle speed: max. 6000/min, control: Fanuc 32i A, length: 1850mm, width: 1750mm, height: 1750mm, weight: 2.1t, operating hours: 14,841h. With FMB Unirobot GP7-5Pkhs automation system, Jäger HF spindle grinding spindle, MicroCentric 4-410-3-QC chuck, MARPOSS measuring system with automated dimensional compensation, S400 oil mist filter, Knoll KF110/500 belt filter, 320 S1 hinged belt conveyor and other accessories. On-site inspection is possible. Tsdpfx Afov Uz Aqowjb

Condition: good (used), Year of construction: 2001, INDEX ABC multi-spindle automatic lathe with INDEX control, serial number 401566, year of manufacture 2001, operating hours estimated at approximately 44,285 hours according to management, chip conveyor DGS, bar feeder FMB 5-42/322/A. Tsdpsztc Rvsfx Afweb
