Used Hybrid Press Brake 4100 X 220 Ton for sale (78,597)

Condition: used, Year of construction: 2023, Dener XF 30125 - Hydraulic CNC Press Brake - Control unit (swiveling): ESA S640 CNC 15" 2D graphical display / touchscreen - CNC axes: Y1, Y2 and X - Motorized crowning system with CNC control - Hydraulic press brake valve with CE safety signals - MCS PLC safety control - Laser safety system - Backgauge X-axis: 500 mm (manually adjustable) Hnjdsy A Rc Uepfx Agyjk - Upper tool clamping: L = 150 mm (Promecam) - Upper tool: Eurostamp 1260 / standard (835 & 805 mm, divided into 595 & 210 mm) - Lower die holder: standard width (Promecam) - Lower die: Eurostamp 2067 / standard (835 & 805 mm, divided into 100 mm left, 395 mm, 210 mm & 100 mm right) - 2 front supports, manually adjustable in height and lateral position - Power-on hours: 1184 h - Operating hours: 673 h - Year of manufacture: 2023 Technical data: - Press force: 125 t - Bending length: 3020 mm - Distance between uprights: 3050 mm - Number of axes: 3 - Oil capacity: 200 l - Total power requirement: 11 kW - Dimensions (W x H x D): 3660 x 2500 x 1340 mm - Weight: approx. 7000 kg

Condition: new, Year of construction: 2025, functionality: fully functional, Equipment: CE marking, Stock machine // Subject to prior sale CNC-controlled press brake in all-steel welded construction with DELEM DA66S control, HAWE hydraulics, Fiessler AKAS II laser safety system, and CNC-controlled table crowning Technical data: - Maximum pressing force: 160 tons - Bending length: 3100 mm - Bending length between uprights: 2550 mm - Throat depth: 410 mm - Table width: 60 mm - Table height from floor: 870 mm - Installation height: 530 mm - Max. ram stroke: 260 mm - Closing speed: 200 mm/sec - Pressing speed: 10 mm/sec - Return speed: 160 mm/sec - Max. backgauge travel (X axis): 750 mm - Max. backgauge travel (R axis): 150 mm - Backgauge traverse speed in X axis, servomotor: 330 mm/sec - Backgauge positioning accuracy: +/- 0.03 mm - Motor power: 15.0 kW - Oil tank capacity: 180 l Equipment / Standard accessories: Hnsdpfx Aey Anftegysk - CNC control “DELEM DA66S” for user-friendly graphical product programming. The controller calculates the bending sequence and all axis positions (including collision warning) at the push of a button, 24” TFT color touchscreen display, USB interface, network connectivity, and tool database for 100 punches and dies each. Graphical 2D programming, 2D preview during operation, up to 12 axes plus auxiliary functions. Includes PC programming software “Profile - TL" and remote service (teleservice) via TeamViewer. - Manual quick-clamp system for upper tools, Promecam/AMADA type, with screw lever, safety nose, and plastic pressure bar for secure clamping, even with narrow tools. Max. load: 100 t/meter - Split upper tool, "Amada System," manufacturer Italy, material C 50 (HRC 50-52), induction hardened and ground on work faces. Bending capacity: 100 t/meter. Standard delivery, division: 3 x 835 mm, horns left and right 100 mm each, remainder in smaller segments. Height: 66.6 mm - Lower tool / 4-way prism block CroMo 4, ground, 60x60 mm, standard V-openings: 16 - 22 - 35 - 50 mm - Modern design for side and top covers - Side safety covers with magnetic closure for quick opening/closing during tool changes - 2-axis backgauge system with ball screw drives and servo motors, CNC controlled, max. X-axis range 750 mm, R-axis 150 mm. Positioning accuracy +/- 0.03 mm, traverse speed: 330 mm/sec. Includes 2 laterally adjustable stop fingers. - "FIESSLER" double-beam laser safety system, type AKAS/LCII. Operation of the press only possible via foot pedal. Manually adjustable via linear guides in both vertical and horizontal axes for extremely easy and quick adjustment after tool changes. - Automatic motorized table crowning system WILA, integrated into the CNC - Front sheet supports (2 pcs) laterally movable on linear guides, height-adjustable by handwheel - Central lubrication with hand pump - Spring-back compensation via CNC - Oil fill - Operating manual in German with spare parts list - Hydraulic manifold, valves by HAWE/HOERBIGER - Hydraulic pump: tandem pump by HAWE - Relays and contacts: Schrak, Pilz, Siemens, Eaton or Telemecanique - CE conformity - Operating hours counter - Dual-color paintwork: Body RAL7015 slate grey; covers, swing arm and controller housing: RAL7035 light grey; support arms and front of side covers

Condition: used, This press brake will be auctioned online in our industrial/machinery auction due to the closure of the ContiTech Transportsysteme site. Hnsdoyzdlmspfx Agysk

Condition: used, Single-column hydraulic press EXNER Type EEX 20 S - Machine no.: 1615 Year of manufacture: 1980 - Pressing force: 20 tons - Throat depth: 180 mm - Table size: 380 x 350 mm - Table opening: Ø 50 mm - Ram surface: 310 x 250 mm - Clamping shank: Ø 35 mm - Ram stroke: 100 mm - Max. installation height: 250 mm - Table height above floor: 900 mm - Descent speed: approx. 480 mm/s - Return speed: approx. 480 mm/s - Working speed: 20 mm/s - Hydraulic tank capacity: 110 liters - Hydraulic operating pressure at 20 tons: 200 bar - Motor output: 4 kW - Power connection: 400 Volt, 50 Hz Hsdpfx Agoyz Dtdeyonk - Stroke release via two-hand control or light barrier - Operating modes: setup, two-hand operation, BWS - SICK light curtain, type LVU, with single- and double-stroke settings and safety function - Rapid approach and working stroke - Stroke limitation dependent on pressure or travel - Mechanically adjustable solid stop - Press force adjustment manually via knurled wheel - Control cabinet mounted on the side of the machine - Operating manual and electrical schematics included - Stroke counter - Space requirement (L x W x H): 1250 x 750 x 2000 mm - Weight: 1.4 tons In good condition

Condition: excellent (used), Year of construction: 1993, AMADA MODEL ITS2 50-20 50 TONS X 2000 HYDRAULIC UP STROKING 5 AXIS CNC PRESS BRAKE COMPLETE WITH OPERATEUR 1 4 AXIS CNC CONTROL Erwin Sick machine mounted electronic guards , side and rear interlocked fencing year 1993 description TYPE HYDRAULIC UPSTROKING BENDING PRESSURE 50 TONS BENDING LENGTH 2000 OPEN HEIGHT 370 STROKE LENGTH 100 Hjdpfxopygyds Agyenk THROAT DEPTH 400 TABLE WIDTH 60 NO. OF AXIS 4 AXIS CONFIGURATIONS X1-X YI-Y2 RI-R2 BACKGUAGE can be demonstrated under power BROCHURE AND FURTHER INFORATION AVAILABLE UPON REQUEST

Condition: excellent (used), Year of construction: 2004, specification 150 TONS X 4000 4 AXIS CNC HYDRAULIC DOWN STROKING PRESS BRAKE COMPLETE WITH FULL LENGTH TOP AND BOTTOM TOOLING INCLUDING A BOTTOM MULTI VEE BLOCK Hnodpfxsh N Dqrs Agyek description TYPE HYDRAULIC DOWNSTROKING BENDING LENGTH 4000 BENDING PRESSURE 150 TONS CONTROL CYBELEC DNC 60 NO OF AXIS 4 AXIS CONFIGURATION X1 Y1 R MAX SPEED 80mm/SEC STROKE 180 mm GUARDS MACHINE MOUNTED ELECTRONIC GUARDS SIDE AND REAR INTERLOCKED FENCING WEIGHT 11200 KG SERIAL NO. 6150/11324 MOTOR SIZE 7.5 KW YEAR OF MAUFACTURER 2004

Condition: excellent (used), Year of construction: 1991, AMADA MODEL HFBE 170-3 170 tons x 3000 complete with DELEM DA 58 MULTI AXIS CNC CONTROL ERWIN SICK MACHINE MOUNTER ELECTRONIC GUARDING SUYSTEM SIDE AND REAR INTERLOCKED FENCING Bending force: 170 T Bending length: 3100 mm Distance between uprights: 2650 mm Cnc control: DELEM DA 58 Throat: 410 mm Vertical stroke: 180 mm Hnjdpfxjwcd Spo Agyek Working speed: 10 mm/s Axis number: 6 Including Z axis Motor Power: 13 kW Machine weight: 10500 kg Machine dimensions (LxWxH): 3200 x 1700 x 2500 mm

Condition: excellent (used), Technical Data: Working length: 3100 mm Distance between uprights: 2560 mm Pressing force: 220 t CNC control: OPERATOR II grafic Hnsdpfx Agjyzm Nhoysk Controlled axes: Y1/Y2; X1/X2; R1/R2; Z1/Z2 Bending simulation automatic crowning motorized adjustable backgauge Throat depth: 650 mm Stroke: 200 mm Working height: 960 mm Laser safety system: FIESSLER Motor power: 17 kW CE marking Dimensions (LxWxH): approx. 3700 x 2400 x 2900 mm Weight: approx. 15 tons Accessories: 1 set of tooling: 1 upper tool 120 mm 1 lower tool, segmented die: V 50, 35, 22, 16 Condition: Very good condition, complete overhaul in 2026 The seller is not liable for typing or data transmission errors. The machine's appearance, technology, and wear are age-appropriate; used machines are sold without any warranty.

Condition: new, functionality: fully functional, Year of construction: 2026, overall weight: 3,580 kg, input voltage: 400 V, total length: 1,180 mm, total width: 1,600 mm, total height: 2,310 mm, Press Characteristics open back design fixed table crankshaft mounted transversely friction clutch rigid and durable machine construction horizontally mounted crankshaft dry pneumatic clutch lifting balance device safety valves manual control adjustable stroke Technical Specifications Press force: 40 t Stroke under nominal load: 6 mm Slide stroke: 120 mm Number of strokes: 55 strokes/min Max. die set height: 220 mm Die height adjustment: 80 mm Throat depth: 260 mm Working table width: 480 mm Working table length: 710 mm Working table thickness: 80 mm Table hole diameter: Ø180 mm Bed opening dimensions (diameter × front–back × left–right): Ø200 mm × 150 mm × 300 mm Slide bottom surface width: 270 mm Slide bottom surface length: 320 mm Max. body inclination angle: 25° Distance between columns: 300 mm Hnodpfx Aeytdl Aegyjk Punch hole diameter: Ø50 mm Punch hole depth: 70 mm Motor power: 4 kW Overall dimensions (W × L × H): 1600 × 1180 × 2310 mm Weight: 3580 kg Equipment light curtains mechanical guards ejector in the lower table Delivery Delivery to the customer is possible. The delivery cost is determined individually according to the carrier’s quotation. Additional Information If you are interested in other machines, we encourage you to visit our website.

Condition: new, functionality: fully functional, Year of construction: 2026, overall weight: 3,100 kg, input voltage: 400 V, total length: 950 mm, total width: 1,460 mm, total height: 2,380 mm, Press Characteristics open back design fixed table crankshaft mounted transversely friction clutch rigid and durable machine construction horizontally mounted crankshaft dry pneumatic clutch lifting balance device safety valves manual control Technical Specifications Press force: 25 t Stroke under nominal load: 3 mm Slide stroke: 10 – 110 mm Number of strokes: 80 – 120 strokes/min Max. die set height: 250 mm Die height adjustment: 50 mm Throat depth: 210 mm Hodpfxeytcvge Agyenk Distance between frame columns: 450 mm Working table width: 700 mm Working table length: 400 mm Working table thickness: 80 mm Table hole diameter (outer): Ø170 mm Table hole depth: 20 mm Table hole diameter (inner): Ø150 mm Slide bottom surface width: 360 mm Slide bottom surface length: 300 mm Punch hole diameter: Ø40 mm Punch hole depth: 60 mm Motor power: 3 kW Overall dimensions (W × L × H): 1460 × 950 × 2380 mm Weight: 3100 kg Equipment light curtains mechanical guards ejector in the lower table Delivery Delivery to the customer is possible. The delivery cost is determined individually based on the carrier’s quotation. Additional Information If you are interested in other machines, we encourage you to visit our website.

Condition: new, functionality: fully functional, Year of construction: 2026, overall weight: 1,400 kg, input voltage: 400 V, total length: 1,150 mm, total width: 900 mm, total height: 1,910 mm, Eccentric Press – 16 Ton Capacity Press Characteristics open back design fixed table crankshaft mounted in a transverse direction friction clutch rigid and durable machine construction horizontally mounted crankshaft dry pneumatic clutch lifting balance device safety valves Hodpfsyrr E Iox Agysnk manual control Technical Specifications Pressing force: 16 t Stroke under load: 2 mm Slide stroke: 0–70 mm Number of strokes per minute: 125 min⁻¹ Maximum die height: 170 mm Distance from slide block to frame: 170 mm Working table dimensions (W × L): 320 × 480 mm Diameter of hole in the worktable: Ø100 mm Opening dimensions (W × L × Ø): 160 × 240 × Ø210 mm Slide dimensions (W × L): 180 × 200 mm Shank hole size (Ø × depth): Ø40 × 60 mm Distance between columns: 220 mm Table thickness: 60 mm Maximum tilt angle: 25° Motor power: 1.5 kW Machine dimensions: 1150 × 900 × 1910 mm Weight: 1400 kg Equipment light curtains mechanical guards ejector in the lower table Delivery to the customer is possible. Shipping cost is calculated individually by the transport company.

Year of construction: 2002, condition: ready for operation (used), A repair-required Safan CNC press brake is available. Working width: 2050mm, press force: 400kN, ram stroke: 180mm, installation height: 450mm, closing speed: 90mm/s, working speed: 20mm/s, machine dimensions X/Y/Z: approx. 3000mm/1500mm/2500mm, weight: approx. 5000kg. The tool clamping system of the machine is defective. Documentation available. An on-site inspection is possible. Hedpeyz Anasfx Agyjnk

Year of construction: 1965, condition: used, Press brake Factory Wilhelm Jonescheit type HYPM 125 -300 stroke 30 - 70 mm pressure 125 t Hedpfxoillxye Agyonk weight 9150 kg

Condition: new, Year of construction: 2026, functionality: fully functional, total length: 3,280 mm, total height: 2,700 mm, total width: 2,000 mm, overall weight: 11,000 kg, input voltage: 400 V, type of input current: three-phase, warranty duration: 12 months, PRESS BRAKE 200T × 3200 mm The press brake is used for forming sheet metal. During the slider cycle, the sheet metal can be bent to match the required geometric cross-section. The machine can be used in many industries – electromechanical industry, light industry, agricultural machinery manufacturing, shipbuilding, automotive industry, aerospace industry, etc. Machine Functions Hnedpfxjyttbme Agyok Back gauge position control Intelligent position control Recall functions Automatic reference point search Backup and restore parameters with a single identifier Fast position indexing Memory for 40 machining programs, each with 25 steps Power failure protection Technical Data Pressing force: 200 T Maximum workpiece length: 3200 mm Distance between columns: 2530 mm Throat depth: 320 mm Ram stroke: 200 mm Maximum opening height: 455 mm Motor power: 11 kW Weight: 11000 kg Machine dimensions (L × W × H): 3280 × 2000 × 2700 mm Equipment Controller MTP-3212 Ball guides for back gauge Two back gauge fingers Two front supports Cylinder covers Optical light curtains (front) Safety gates (rear) Foot pedal AMADA-type punch holder Four-side lower die prism Back gauge driven by electric motor Segmented punch with possibility to remove a damaged segment Delivery Conditions The machine is brand new 12-month warranty Warranty service Post-warranty service CE declaration of conformity Operation manual in English Delivery to the customer is possible. Delivery cost according to an individual quotation from the transport company. If you are interested in other machines, we encourage you to visit our website.

Condition: new, Year of construction: 2026, functionality: fully functional, warranty duration: 12 months, The press brake is designed for bending sheet metal. During the ram stroke, the sheet can be bent and formed to the required geometric profile. The machine can be used in many industries, including electromechanical engineering, light industry, agricultural machinery production, shipbuilding, automotive industry, aerospace industry, and many others. Technical data Maximum sheet thickness: up to 6 mm Press force: 125 t Maximum bending length: 3200 mm Distance between columns: 2700 mm Throat depth: 320 mm Ram stroke: 120 mm Maximum opening height: 390 mm Back gauge travel: 600 mm Motor power: 7.5 kW Weight: 7500 kg Dimensions (L × W × H): 3870 × 1550 × 2400 mm Equipment Tools Front supports: 2 pcs Back gauge adjustment (X axis): servo drive Beam adjustment (Y axis): servo drive Back gauge finger height adjustment (R axis): manual Punch clamping system: AMADA-type quick clamping Controller: MTP-3212 The CNC controller features an intuitive and user-friendly menu. The software automatically calculates the bending angle. Possibility to store up to 40 punch types. Large color touchscreen display readable from any angle. High-quality components High-quality German Rexroth hydraulic valves Electrical components from Schneider Electric Safety components from Omron and Schneider Steel hydraulic connections The use of steel hydraulic connections significantly reduces the risk of leaks in the future. Ergonomics Thanks to the mobile controller and the control panel mounted on a movable arm, the operator can work flexibly across the entire working area of the machine. Additional LED lighting ensures excellent visibility of the workpiece in all conditions. Discover a new level of comfort and efficiency with our innovative solutions. Safety Our press brakes are designed with maximum operator safety in mind. They are equipped with: clearly visible markings side guards rear safety gate easily accessible emergency switches light curtain preventing accidental access of hands between the punch and die during operation The machine is supplied with a Polish-language user manual, ensuring full understanding of safe operation. The machine also has a CE Declaration of Conformity, confirming compliance with all European safety and quality standards. Specialist assistance Hsdpfx Agsytp N Heyonk We maintain continuous contact with our customers. For every machine we provide technical support from our service engineers and specialists. Our specialists can: assist in determining bending steps for complex parts provide professional advice on selecting suitable materials and tools assist in selecting optimal working parameters for different materials We are here to support you at every stage of the process. Technical consulting Our specialists are available before purchase to help you select the right machine and accessories. Delivery to the customer is possible. Delivery cost according to the individual quotation of the transport company. If you are interested in other machines, please visit our website.

Condition: new, Year of construction: 2026, functionality: fully functional, total length: 2,155 mm, total height: 2,000 mm, total width: 1,469 mm, overall weight: 3,300 kg, input voltage: 400 V, type of input current: three-phase, warranty duration: 12 months, PRESS BRAKE 40T × 2000 mm Hjdpoyttfrjfx Agysnk The press brake is used for forming sheet metal. During the slider cycle, the sheet metal can be bent to match the required geometric cross-section. The machine can be used in many industries – electromechanical industry, light industry, agricultural machinery manufacturing, shipbuilding, automotive industry, aerospace industry, etc. Machine Functions Back gauge position control Intelligent position control Recall functions Automatic reference point search Backup and restore parameters with a single identifier Fast position indexing Memory for 40 machining programs, each with 25 steps Power failure protection Technical Data Pressing force: 40 T Maximum workpiece length: 2000 mm Distance between columns: 1650 mm Throat depth: 200 mm Ram stroke: 100 mm Maximum opening height: 340 mm Motor power: 4 kW Weight: 3300 kg Machine dimensions (L × W × H): 2155 × 1469 × 2000 mm Equipment Controller E21 Ball guides for back gauge Two back gauge fingers Two front supports Cylinder covers Optical light curtains (front) Safety gates (rear) Foot pedal AMADA-type punch holder Four-side lower die prism Back gauge driven by electric motor Segmented punch with possibility to remove a damaged segment Delivery Conditions The machine is brand new 12-month warranty Warranty service Post-warranty service CE declaration of conformity Operation manual in English Delivery to the customer is possible. Delivery cost according to an individual quotation from the transport company. If you are interested in other machines, we encourage you to visit our website.

Condition: used, Year of construction: 2003, pressing force: 120 t, table length: 3,000 mm, throat depth: 300 mm, clearance between the columns: 2,600 mm, total length: 3,460 mm, total width: 1,800 mm, total height: 2,600 mm, overall weight: 10,500 kg, Equipment: safety light barrier, Brand: DENER Model: DMP NC120-30 Pressing force: 120 tons Working width: 3000 mm Working width between columns: 2600 mm Throat depth: 300 mm Year of manufacture: 2003 Back gauge: electrically adjustable Hjdpfx Agoyzanwoysnk Includes safety light curtain Control: NC control Neat machine, price excludes 21% VAT and excludes tools.

Condition: used, #200112 Trumpf OW200/S - press brake tools / upper tools 86.00° R4.00 / H=218.30 / 800 kN/m Segment lengths: 2x 25 mm 1x 30 mm 1x 40 mm 2x 100 mm (reduced body 70 mm 1x left / 1x right) 5x 200 mm 5x 300 mm ----- #200113 Trumpf OW201/S 86.00° R1.00 / H=220.00 / 800 kN/m Segment lengths: 2x 25 mm Hnsdjy Anydepfx Agyok 1x 30 mm 1x 35 mm 1x 40 mm 1x 45 mm 1x 50 mm 3x 100 mm (2x reduced body 70 mm 1x left / 1x right) 1x 200 mm 7x 300 mm

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, controller manufacturer: Bystronic, controller model: Byvision, bending force (max.): 225 t, control type: CNC control, number of axes: 6, type of crowning: CNC-controlled, Equipment: CE marking, documentation/manual, emergency stop, european tool clamping system, foot remote control, lower tooling, safety light barrier, upper tooling, 1 Used High quality fully serviced Bystronic Xact Smart 225/4100 4metre x 225ton hydraulic downstroke cnc pressbrake for sale Xact Smart 225/4100 Make: Bystronic Model: Xact Smart 225/4100 Year / new: 2016 Total axis: 6 – 4axis back gauge X R Z1 Z2 Hjdpfx Ajyxqzvsgysnk Hydraulic crowning Free standing no pit required Capacity / bed size / tonnage: 4metre x 4100mm x 225ton Cnc control: ByVision touch screen

Condition: excellent (used), functionality: fully functional, Year of construction: 2005, Pressure: 225 t Hsdpfoyz S Ngox Agysnk Bending length: 4050 mm Control: DA 69 TW Oil capacity: 400 l Total power requirement: 17 kW Machine weight approx.: 18,100 kg Dimensions: 5700 x 2610 x 3300 mm

Condition: excellent (used), Year of construction: 2026, functionality: fully functional, Press force: 25 t Bending length: 1250 mm Hodpfx Asyz Sw Regyjnk Distance between uprights: 1200 mm Control: Cybelec CybTouch 12 Stroke: 150 mm Installation height: 340 mm Rapid down speed: 220 mm/s Bending speed: 0-12 mm/s Total power requirement: 5.5 kW Machine weight approx.: 2,500 kg Dimensions: 1980 x 1170 x 2185 mm Standard equipment: Basic features: • CNC control Cybelec CybTouch 12 • 4 axes: Y1-Y2-X-R • Backgauge system model GHP-2 • Servo-driven main motor • Safety system: DSP AP+MCS • HAWE hydraulic system • CE standard

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, Press force: 36 t Hedpfoyz Rwisx Agyonk Bending length: 1020 mm Clearance between frames: 932 mm Throat depth: 150 mm Stroke: 120 mm Usable installation height: 295 mm Y-working speed: 10/25 mm/sec Y-rapid traverse: 220 mm/sec Working height: 1150 mm Machine weight approx.: 2,600 kg Space requirement approx.: 1805x1330x2380 mm Operating hours: 3,297 h

Condition: good (used), Year of construction: 1987, machine/vehicle number: 8754-08, Offer 26124 Hnsdpfoyzgqlex Agysk Technical Data: - Max. working width: 6050 mm - Max. material thickness at 40 kp/mm² tensile strength, steel: 1.0 mm - at 20 kp/mm² tensile strength, aluminium: 1.5 mm - at 80 kp/mm² tensile strength, V4A: up to 0.6 mm - Electronic bending angle preselection - Hydraulic lifting and lowering of the upper beam and bending beam - Manual rotary shear - Drive: 400 V - Space required: approx. W 6800 x H 1550 x D 1700 mm - Weight: approx. 1900 kg

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, operating hours: 2,375 h, input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, pressing force: 175 t, stroke length: 160 mm, operating speed: 10 mm/s, reverse speed: 140 mm/s, table width: 3,400 mm, table length: 3,400 mm, total length: 4,400 mm, total width: 1,800 mm, total height: 2,950 mm, overall weight: 12,500 kg, Equipment: CE marking, BOSCHERT – GIZELIS G-BEND PLUS 3175 CNC Controlled Press Brake Machine available for collection in June. 1. Features and Capabilities: ■ Modern machine frame design ensures an optimal installation footprint. ■ Compact build with high operational safety, resistant to external influences. ■ Reinforced, heavy-duty sidewalls for added structural rigidity. ■ Maintenance-free, dual ram guiding system, independently controlled for Y1 and Y2 axes. ■ Advanced hydraulic system featuring a proportional multi-valve configuration and pressure management, equipped with an energy-efficient STOP&GO function during operation. ■ High-precision, dual active ram position measurement system ensuring top bending accuracy. The system includes a minimum of two independent, highly accurate linear encoders installed on mounts decoupled from the frame. Ram positioning accuracy is +/- 0.01 mm. Provides full electro-hydraulic frame synchronization (Y1, Y2). ■ Ram parallelism to the bending axis is maintained by a double roller guide on both sides of the internal frame section, supplemented by crosswise ram reinforcements. ■ Cylinders and pistons are made from high-strength steel with chrome-plated piston surfaces. ■ The machine and its accessories are intuitive to operate and designed for easy maintenance. ■ Provisions are made for future upgrades with new technical innovations. ■ All digital axis drives are powered by premium, maintenance-free AC servomotors. ■ The rear backgauge utilizes dual linear guides for precise bilateral movement. Hnjdpoy Am Nqjfx Agyjk ■ An extensive and versatile tooling portfolio enables flexible processing of a wide range of workpieces. ■ The design and construction comply with EU health and safety directives in line with the CE mark. The machine is CE-certified and built according to Directive 2006/42/EC. 2. Technical Data: Model/data 3175 Press force 175 ton Max. working length 3,400 mm Working length between uprights 3,050 mm Throat depth in side frames 400 mm Opening between table and ram 615 mm Ram stroke 350 mm Maximum X-axis backgauge travel 1,200 mm Ram speed: Y rapid traverse (unloaded) 0-160 mm/s Y working (under load) 10.0 mm/s Y return 0-140 mm/s Electrical Specification (others on request): Voltage 400 V Frequency 50 Hz Motor (flange-mounted AC, incl. controller) 22 kW Approximate Dimensions: Machine height approx. 2,950 mm Machine width approx. 1,800 mm Machine length approx. 4,400 mm Max. weight (with accessories) 12,500 kg 3.6 5-Axis CNC Backgauge System: X-ΔX-R-Z1-Z2 X axis: Parallel movement of the backgauge beam ΔX axis: Adjustable backgauge finger for angled (skew) bends. Adjustment range +/- 175 mm (total 350 mm). R axis: Vertical adjustment of the backgauge beam Z1, Z2 axes: Automatic lateral travel of backgauge fingers along the beam. All axes are powered by AC servo drives. Two backgauge fingers on the beam with integrated sheet support feature. All axes are CNC controlled by the DNC system. Tooling: Punch: TOP.175.60.R08 60° R0.8MM H=175 L=5x525 mm TOP.175.60.R08 60° R0.8MM H=175 L=1x495 mm Segmented: 25/30/35/40/45/50/100/170 mm TOP.175.60.R08 60° R0.8MM H=175 L=1x500 mm Segmented: 100/300/100 mm Die: Multi-V die M.460.60 V=10-16-22-35 (60°), L=4x835 mm

Condition: excellent (used), functionality: fully functional, stroke length: 310 mm, controller manufacturer: Cybelec, controller model: DNC 1200, working width: 3,100 mm, bending force (max.): 100 t, distance between stands: 2,550 mm, control type: CNC control, back gauge adjustment: CNC-controlled, number of axes: 7, type of crowning: CNC-controlled, actuation type: hydraulic, Equipment: CE marking, documentation/manual, emergency stop, finger protection, foot remote control, lower tooling, upper tooling, Bystronic 100 ton x 3100 mm PR6. Hnjdpfxsyxhhme Agyek 7 Axis X. R. Z1. Z2. X1 100 mm Extra Daylight & Stroke Hydraulic Crowning Hydraulic Upper Tool Clamping Full Upper & Lower Tooling Cybelec 1200 Colour Graphic Control
