Used Kms Conventional Lathe for sale (14,475)

Condition: like new (used), Year of construction: 2024, Max. turning diameter: 400 mm Turning length: 650 mm Swing diameter: 600 mm X-axis travel: 275 mm Z-axis travel: 700 mm Bar capacity: 85 mm Main spindle: 3,400 rpm at 85 mm bore* Tedsz E Dcnepfx Ahmoc Spindle nose: A8 / DIN A8 Chuck Driven tools: MC = Milling/driven tools Control system: Siemens 16-station BMT45 turret, axial - all stations driven Chip conveyor in the tailstock High-pressure pump, 15 bar Siemens Sinumerik One Measuring probe for tool measurement in the work area Direct measuring system in the X-axis Automatic door system

Condition: good (used), functionality: fully functional, Schaublin 125-CCN high-precision lathe with FANUC 20-T numerical control – A LOT of accessories – CE compliant!!!! Tjdpfxez Ezc Ss Ahmsc Technical data: >> Machine no. 334511, year of manufacture approx. 1995 Working area: Maximum diameter: Over the cross slide 270 mm Over the carriage 115 mm In the spindle bore 28 mm Largest chuck size 130 mm Spindle nose Camlock D1-3 AC drive Power at 50%/100% duty cycle 7.5/5.5 kW Spindle speeds 0-5000 rpm Longitudinal travel Z-axis 400 mm Feeds Working feeds X / Z axis, stepless 0-5000 mm/min Rapid traverse X / Z axis 7.5 m/min Tailstock Mk3 Weight approx. 1500 kg Accessories: 1 pallet, see photo About the machine: Offered is a fully functional Schaublin 125-CCN high-precision lathe with FANUC 20-T numerical control. The machine was manufactured around 1995 and comes with a large number of accessories. Take the opportunity to inspect this machine on-site while it is powered up and to verify its condition.

Condition: good (used), Year of construction: 2000, functionality: fully functional, ET 332 MC with LM800. Todpez Ehnbefx Ahmsc

Condition: good (used), Year of construction: 2003, Machine is in good working condition. Parts shown by hand not come. Tsdpfoz Egxfex Ahmec

Condition: used, Year of construction: 2011, control FANUC Series 31i-MODEL A max. turning diameter 230 mm max. turning length 230 mm x-axis 165 mm y-axis 165 mm z-axis 700 mm rapid traverse (x/z) 20/40 m/min Spindle speed - main spindle 5.000 U/min drive capacity - main spindle 22 kW Torque – Main Spindle 208 Nm Spindle speed - counter spindle 5.000 U/min Drive power - sub spindle 22 kW Feed size 8" spindle nose A2-6 bar passage 65 mm number of tool places 2 x 12 Pos. Rotary tool 6.000 U/min weight approx. 9.000 kg rated capacity 75,21 kVA In our assessment, the machine is in good used condition and can be inspected Tsdpfez Dbyzex Ahmec under power by appointment. A wide range of accessories is available: static and driven tool holders. Technical features & accessories: - Bar loader Accessories, tools, and work-holding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Year of construction: 2001, turning diameter 400 mm turning length 549 mm control HEIDENHAIN Eltropilot swing over bed 570 mm travel -x axis 220 mm travel -z axis 635 mm main spindle bore 79 mm main spindle speed 25 - 5000 U/min main spindle drive 21 kW max. torque on the spindle max. 240 Nm 120 mm c-axis, speed 100 U/min C-axis Haltemoment 200 Nm C-axis resolution < 0,04 ° sub spindle bore 56 mm sub spindle speed 25 - 5000 U/min sub spindle drive 9 kW max. torque on the spindle max. 72 Nm 90 mm c-axis, speed 100 U/min C-axis Haltemoment 150 Nm C-axis resolution < 0,04 ° feed power X/Z axis 3,5 / 7 Nm Tedjz Ekzwjpfx Ahmjc rapid traverse X-axis 20 m/min rapid traverse Z-axis 24 m/min tool turret 1 x 12 Stationen number of driven tool stations 12 speed of driven tools 4.000 U/min total power requirement 44 kVA Accessories: collet fixture HAINBUCH on main spindle, 3-jaw chuck RÖHM, 140 mmø, on sub spindle, 3 collets, chip conveyor, coolant with band filter device

Condition: used, Mechanic lathe LESTO Scintilla (Switzerland), model GD 1124 CR Machine no. 6T 7868, year of manufacture approx. 1975 Electrical problems with the capacitor motor Tjdsz Ek Rxspfx Ahmoc Drive power: 0.44 kW Mains connection: 230 volts, 50 Hz - Fixed steady rest - Collets - Faceplate Space required L x W x H: 1100 x 500 x 400 mm Weight: approx. 90 kg Good condition - Electrical problems with the capacitor motor

Condition: excellent (used), Year of construction: 1979, Manufacturer: Weiler Type: Commador II L+Z lathe Year of manufacture: 1979 L x W x H: approx. 2500 x 1200 x 1800 mm Weight: approx. 1500 kg Technical data: Tedpfelp Ircsx Ahmec Max. turning diameter over bed: approx. Ø 380 mm Max. turning diameter over cross slide: approx. Ø 190 mm Max. turning length: approx. 1000 mm Bar passage: approx. Ø 56 mm Spindle: Speed range: approx. 25 – 2000 rpm Spindle nose: A 2 – 6 Drive power: approx. 4.0 kW Automatic longitudinal and facing feeds: Feed range: approx. 0.026 – 1.253 mm/rev Suitable for threads: – metric 0.35 – 12 mm – inch 44 – 2 TPI – diametral – pitch threads 88 – 5 DP – module 0.2 – 4 Tailstock: MK 4 Without tool holder

Condition: used, Year of construction: 2007, greates pass round over bed 650 mm Swing dia. over traverse guideway 420 mm Distance between centres 2.000 mm control Sinumerik Siemens slide travel X-axis 440 mm slide travel Z-axis 2.000 mm turning speed range - main spindle 1 - 3.000 min/-1 power capacity - main spindel 33 / 27 / 22 kW transmission ratio 2 spindle diameter in front bearing 140 mm spindle bore 106 mm standard chuck diameter 250 - 400 mm Todszp Rvlspfx Ahmec spindle head DIN 55026 / A8 turret head 12 pos. turning tool - shaft cross cut 32 x 32 mm rapid traverse X: 5 m/min rapid traverse Z: 10 m/min feed range X: 0,001 - 1.000 mm/min feed range Z: 0,001 - 2.000 mm/min power feed coss 9.000 N power feed longitudinal 12.000 N diameter of quill 100 mm quill travel 200 mm taper of center MK 6 total power requirement 38 kW weight of the machine ca. 6,0 t dimensions of the machine ca. 6,0 x 2,5 x 2,0 m CNC - Lathe DMT KERN - CD 650 / 2000 - only 3,446 operating hours - incl. boring bar with holder for cross slide - incl. face plate 600 mm - incl. traveling steady rest max. 160 mm - incl. fixed steady rest max. 160 mm - incl. fixed steady rest max. 250 mm (not pictured) - incl. fixed steady rest max. 350 mm (not pictured) - incl. spare parts package - NO additional tools included

Condition: used, Year of construction: 1970, Technical details: turning diameter over bed: 500 mm turning diameter over support: 300 mm turning length: 1000 mm center height measured in bed: 250 mm centre distance: 1000 mm revolution per minute: 18...1800 / 21 step U/min spindle bore of work spindle: 56 mm tailstock quill adjustment:: 180 mm Tsdpovvrpksfx Ahmec longitudinal feeds:: 0,08 - 3,26 mm/U cross feed: 0,04 - 1,63 mm/U Rapid feed X axis: 4,2 m/min. total power requirement: 7,5 kW weight of the machine ca.: 2,9 t dimension machine xH: 2,6 x 1,1 x 1,3 m 4-jaw chuckØ 250mm with internal jaws live center in tailstock 4-fold quick-clamping tool holder coolant system Accessories: various reduction sleeves MK3-MK5-MK4 revolving tip "Clamping heart" 3-jaw chuck Ø 250mm with inner jaws The machine does not comply with APR (accident preventing regulations) *

Condition: ready for operation (used), Bar Capacity: 0.63" (16 mm) Spindle Speed: 10,000 RPM Max. Headstock Stroke in one chucking: 12" (305 mm) Max. Drilling Diameter: 5/16" (8 mm) Max. Milling Diameter: 2/5" (10 mm) Max. Slotting Capacity: 1.5 mm x 4 mm Spindle Indexing: 15 degrees Main Spindle Motor: 2.2 kW / 3.7 kW Power Driven Attachment Motor: 0.4 kW Number of Tools: 9 Number of Live/Rotary Tools: 2 Rotary Tool Speeds: 350 – 5,000 RPM Max. Chucking Diameter: 5/8" (16 mm) Max. Length for Front Ejection: 5" (127 mm) Max. Drilling Diameter: 1/4" (6.5 mm) Number of Tools: 3 Sub-spindle Speed: 400 – 6,000 RPM Sub-spindle Motor: 1.5 kW Dimensions: 81" x 46" x 67" (2,057 mm x 1,168 mm x 1,702 mm) Weight: 5,100 lbs (2,313 kg) Options: Fanuc Bar Feeder IEMCA MINI BOSS 325r Live Tooling (not working) Sub Spindle Tsdpfx Ahow Rfcqemjc

Condition: used, Year of construction: 2016, DOOSAN LYNX 300M YEAR OF MANUFACTURE: 2016 Machine equipped with a C-axis and powered tools. Model: LYNX 300 M, FANUC 0i TF–s control (10.4” LCD display + Manual Guide) Standard equipment: Spindle speed: 3500 rpm Main motor power: AC 15/11 kW Rapid traverse rate (X / Z axes): 24 / 30 m/min Tsdpfez E Rv Iex Ahmsc Hydraulic 3-jaw chuck, 255 mm Power of tool drive: 5.5 kW (5000 rpm) Max. turning diameter: 370 mm Max. turning diameter over the carriage: 651 mm Max. turning length: 712 mm Spindle bore (max. bar diameter): 76 mm Tool shank cross-section: 25 x 25 mm (Ø40 mm) Number of tool positions: 12 (tool change time: 0.15 s) Tailstock, CE certificate, transformer 2 axial (vertical) powered tool holders + 2 radial tool holders, basic tool holder set Optional equipment: · Chip conveyor · Tool load monitoring system · Preparation for bar feeder · Part catcher (box version) · Automatic tool measuring system · High-pressure coolant system (7 bar) · Oil separator · Three-color status indicator lamp · Fast Ethernet + 2 GB memory in the control

Condition: ready for operation (used), Year of construction: 2016, operating hours: 23,500 h, functionality: fully functional, machine/vehicle number: 8107000021B, spindle bore: 32 mm, spindle speed (max.): 8,500 rpm, overall weight: 4,300 kg, controller model: FANUC 32i MB, bar length: 3,200 mm, DMG MORI GILDEMEISTER SPRINT 32/5 – Short/Long Turning Automaton Well-maintained machine, low operating hours, including IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016, as well as a conversion kit to a long turning automaton (Swisstype kit) for short and long turning on a single machine. Delivery terms: Free on truck Availability: Immediate - subject to agreement NOTE: The machine must be picked up on a fixed date in mid/late October 2026; we will provide the exact date in advance! Technical data: Control: FANUC 32i MB Operating hours recorded: 25,263 Spindle hours recorded: 22,772 MAIN SPINDLE DATA: Max. turning diameter: 32 mm (guide bushing bore: 38 mm) Stroke Z1: 100 mm Max. speed: 8,500 RPM Drive power S1: 5.5 kW TAILSTOCK SPINDLE DATA: Max. turning diameter: 32 mm (guide bushing bore: 38 mm) Stroke Z2: 200 mm Max. speed: 8,500 RPM Drive power S1: 2.2 kW AXIS DATA X1: Travel: 70 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² AXIS DATA Y1: Travel: 405 mm Max. speed: 30 m/min Max. acceleration: 5 m/s² AXIS DATA X2: Travel: 300 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² TOOL HOLDER DATA – SLIDE 1: Tool holder diameter: 25 mm Number of fixed tools for external machining: 6 Tool holder size: 16 × 16 mm Number of driven tools: 4 Collet type: ESX20 TOOL HOLDER DATA – SLIDE 2: Number of fixed tools for internal machining: 4 Tool holder diameter: 25 mm Scope of delivery: IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016 Chip conveyor Available manuals Accessories as shown in the pictures Dimensions & Weight Footprint (L x W x H): approx. 7500 x 1600 x 2500 mm Weight: approx. 4300 kg Attention: Disc damaged! If you have any questions or would like to arrange a viewing, please do not hesitate to contact us! Additional notes: ► Upon request, we can offer transport to your destination. ► The goods are sold without any warranty. ► Technical data is subject to change. Tedoz A Tbuopfx Ahmec

Condition: used, Year of construction: 2001, Technical details: turning diameter over bed: 410 mm turning dia. over face-slide: 200 mm turning length: 950 mm bed width: 330 mm turning diameter over support: 410 mm face slide travel: 630 mm centre height: 200 mm Tsdpfx Aezd Sg Ijhmec control: Siemens/Weiler D2 milling spindle dia. in forward position: 90 mm spindle bore: 54 mm range of revolution per miute: 1 - 3000 U/min feed speed: 0 - 20 mm/U rapid travel - longitudinal/face: 10/5 m/min tailstock taper MT: 4 diameter of quill: 65 mm quill stroke: 120 mm weight of the machine ca.: 2,1 t dimension machine approx.LxWxH: 2,3 x 1,4 x 1,7 m The E35 is neither a purely manual machine nor a classic CNC, but a hybrid: Work like on a conventional lathe Automatic cycles at the push of a button No complex programming required Extremely fast for single parts & small batch production Also suitable for operators without CNC knowledge Weiler describes it as follows: Simple parts like conventional machining Complex parts like CNC, but easier *

Condition: used, Year of construction: 1998, Technical details: Todpszu Ndlsfx Ahmjc turning diameter over bed: 500 mm turning dia. over face-slide: 340 mm turning length: - mm centre distance: 1500 mm swing diameter: 500 mm centre height: 250 mm control: Heidehain Plus spindle bore: 80 mm range of revolution per miute: 20 - 2400 U/min total power requirement: 11 kW weight of the machine ca.: 0,25 t dimension machine approx.LxWxH: 3,2 x 1,7 x 1,8 m

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 180 mm turning dia. over face-slide: 75 mm turning length: 325 mm facing movement (x-axis): 56 mm longitudinal traverse (z-axis): 176 mm control: FANUC 21T revolution per minute: 50 - 3000 U/min external spindle dia. in forward position: 50 mm feed force Z - max.: 3000 N spindle bore: 30 mm Main spindle capacity: max. 3,7 KW kW electrics - voltage/frequency: 400 / 50 -60 V/Hz Weight approx.: 1,0 t Tsdpfsy Emfqox Ahmjc dimension machine approx.LxWxH: 2,2 x 1,0 x1,62 m The EMCO TURN 325 is a universal CNC/conventional lathe from the EMCO Group (Austria). It is positioned in the mid-range performance and size segment and is frequently used in training, workshops, and production. It is particularly designed for the precision machining of small parts, shafts, and chuck components. Automatic chuck Interface for bar feeder available Various accessories *

Condition: used, Year of construction: 2005, Technical details: spindle passage: 54 mm z-axis: 900 mm turning length: 900 mm swing diameter: 560 mm facing movement (x-axis): 290 mm control: Simens Sinumerik 840D sl spindle turning speed - continuous: 0 - 6000 U/min diameter of main spindle: 120 mm max. torque on the spindle: 190 Nm tool turret: Typ Sauter number of tool tapers: 12 operating pressure: 5 - 6 bar quill stroke: 130 mm diameter of quill: 110 mm rapid traverse: 40 - 50 m/min total power requirement: 37,5 KW weight of the machine ca.: 8,0 t dimension machine approx.LxWxH: 4,8 x 2,4 x 2,3 m Todpfxjy Ttyqs Ahmjc • Modular machine design for efficient 2-axis and 4-axis shaft machining as well as chucking part machining • Equipped with pick-up spindle • High basic accuracy and thermal stability as prerequisites for hard turning and precision machining • Prepared for automatic loading and unloading via gantry loader or integrated loading system • Separable machining area for simultaneous two-stage machining on the left and right main spindles • Lowerable tailstock can be combined with a counter spindle • Supports in-process and post-process measurement strategies *

Condition: used, Year of construction: 1999, Technical details: Tjdpsv Azdwofx Ahmec turning diameter over bed: 554 mm turning dia. over face-slide: 370 mm turning length: 1000 mm turning dia. in gap: 860 mm centre distance: 1100 mm control: Fanuc 210i longitudinal traverse (z-axis): 1000 mm Transversal stroke (x-axis): 290 mm revolution per minute: 16 - 1800 U/min spindle stroke: 178 mm feed:: 10 m/min. spindle passage: 104 mm spindle nose: D1 - 11 tailstock taper ISO: 6 MT spindle drive: 11/7,5 kW connection voltage: 380 V electrics - voltage/frequency: 3 Ph / 400 V / 50 Hz V/Hz total power requirement: 11 kW Weight approx.: 4,0 t dimension machine approx.LxWxH: 3,3 x 1,8 x 1,7 m

Condition: used, Technical details: turning diameter over bed: 830 mm turning dia. over face-slide: 540 mm turning length: 3000 mm turning diameter over support: 540 mm Tsdpowmlknofx Ahmoc centre distance: 3000 mm faceplate diameter: 800 mm Rapid feed X axis: 4 m/min. control: MTC K (Monforts) range of revolution per miute: 2 -1.600 U/min spindle passage: 88 mm tailstock taper ISO: MK6 tailstock quill stroke: 200 mm max. workpiece weight between centers: 1250 kg max. workpiece weight -without tailstock: 3000 kg turning dia. in gap: 1.200 mm length of gap: 310 mm Weight approx.: ca. 6.85 (ohne Späneförderer und Kühlmittelbehälter) t dimension machine xH: 2,55 x 1,1 x 1,29 m Cycle lathe Machine overhauled in 2010 Operation via control panel Thread cutting by calculation Interpolator of NC control Chip conveyor manufacturer Cable drag Three-jaw chuck D=500mm without clamping jaws Various accessories *

Condition: used, Year of construction: 1998, Technical details: Todpou Ngcijfx Ahmjc internal diameter: 63 mm swing diameter: 320 - 800 mm grinding depth: 380 mm total power requirement: ca. 1,1 kW feed:: 0,05 - 0,40 mm/U / 8 step U/min weight approx.: 1060 kg dimension machine xH: 1,1 x 1,1 x 1,4 m Brake Drum Grinding Machine - turning Ø max./min.: 800 / 320mm - brake drum holder: 63mm, quill stroke 120mm - turning support: longitudinal travel 380mm; transverse travel 200mm - steel holder holder: 180 x 140mm, steel holder 58mm, turning tool for insert holder 20 x 20mm - operation via control panel *

Condition: used, Year of construction: 2014, Technical details: turning diameter over bed: 660 mm turning dia. over face-slide: 460 mm turning length: 1650 mm centre distance: ca. 2200 mm swing over bed: 660 mm swing diameter over slide rest: 460 mm swing diameter: in Kröpfung: 960 mm centre height: 320 mm control: Siemens 828 D ShopTurn x-axis: ca. 350 (plan) mm spindle bore: Ø 105 mm range of revolution per miute: 26-224 / 225-670 / 671-2.000 stufenlos U/min Tsdpfx Aeu Ix Nrehmec feed continuous: X: 0,5 - 3.000 mm/min feed continuous: Z: 1 - 3.000 rapid traverse x + z axis: 6 m/min tailstock taper MT: MK 6 quill stroke: 300 mm total power requirement: ca. 23 kW dimension machine xH: 4,2 x 2,3 x 2,3 m dimension swarf conveyor LxWxH: 2,3 x 1,7 x 1,3 m Chip conveyor includes cooling water tank with pump 3-speed manual gearbox with electronic gear shifting Tool holder according to/with Silent Tool Technology equipped (Capto C6) Manual control unit Foot switch Control panel Hydraulics automatic door closing (pneumatic) Accessories see comparable in the photo. *

Condition: used, Technical details: faceplate diameter: 1500 mm center height: über Fundament: 1250 mm revolution per minute: 2,1 ... 96 / 12 step U/min feed min/max: 0,3 ... 2,5 / 18 step mm/min. spindle bore: Ø 82 mm tailstock adjustment - manual: quer: 55 mm Tedpfx Aju Ix Sgohmjc tailstock quill stroke: 400 mm tailstock taper MT: 6 weight of the machine ca.: 15 t dimensions L x W x H: Spindelkasten: ca. 2,0 x 1,6 x 2,1 m dimensions L x W x H: Support: ca. 6,0 x 2,1 x 1,6 m Stand support with bed slide: -bed slide travel 4,300mm motorized -cross slide 1500mm -Cross slide 600mm -Top slide 250mm -Tool holder with clamping claw Bed guide dimensions LxW: 6000 x 1500mm 4 base plates each 6000x2050x200mm *

Condition: used, Technical details: number of spindles: 15 Stück number of stations: 8 Stück control: PS 2000 total power requirement: 83,0 kW weight of the machine ca.: 17,0 t space requirement of the machine approx.: LxBxH: 5,0 x 6,2 x 3,8 m dimensions of machine: LxBxH: 2400x2800x2800 mm dimensions electric cabinet: Nr.1: LxBxH: 1000x850x2350 mm dimensions electric cabinet: Nr.2: LxBxH: 1250x650x2230 mm dimensions electric cabinet: Nr.3: LxB.H: 650x600x2300 mm dimensions electric cabinet: Nr.4: LxBxH: 1300x650x2350 mm Tedpfx Aheu Idxremjc TRANSFER MACHINE with 3 work station and 15 drill & mill spindles - for example the production of a high quantity of armatures Other technical information about the machine: - workpiece carrier: workpiece holding barrel Ø 800mm for 8 work piece - clamping station, clock cycle of 10 sec. - drilling and milling unit: SK 40 intake; spindle stroke 125 mm; standard feed rate 1m/min; rapid traverse feed rate 4m/min; RPM max. 2240 rpm - right 4x drill-& mill spindle with 18 stages and 1x thread cutting spindle hydr. 14 up to 224 U/min, left 4x drill and mill spindle with 18 stages and 1x thread cutting spindle hydr. from 14 up to 224 U/min such as radial 3x drill -and mill spindle from that 1x U-Axis and 1x thread cutting spindle 1.Thread-cutting unit: SK 40 Intake; Quill Ø 125 mm; quill-stroke 125mm; RPM 35.5 - 900 rpm; right/left 2.Thread-cutting unit: SK 40 Intake; Quill Ø 125 mm; quill-stroke 80mm; RPM 45 - 560 rpm; right/left Equipment: - 2 hydraulic aggregate - chip conveyor - belt filter produced by Filtertechnik Gera (fleece band 430mm) - control panel - manual switch i.D. *

Condition: used, Technical details: spindle taper: SK40 spindle stroke: 175 mm Tsdpfxju Idyco Ahmjc number of spindles: 8 Stück number of stations: 5 Stück cycle time: 15-20 sec revolutions per minute: bohren/drill/taladrar 225...1037 U/min. revolutions per minute: gewinde/threading/roscar 50...316 U/min. feed: 0,2 m/min total power requirement: 30 (40PS) kW weight of the machine ca.: 9,0 t space requirements of the machine approx.: 3,9x2,4x2,5 m dimensions of machine: L:3,9xB:2,2xH:2,7 m dimensions L x W x H: +Anlage/plant/planta 2,7x2,52x2,25 m The machine will be on a General overhaul (pictures from original condition at the former Company) The machine has been constructed for the metal cutting process of workpieces in one clamping session. Especially blanks made of brass with a diameter 90mm x approx 100mm length would be machined with this machine. description: - workpiece support with switch plate with clamping station type round table with horizontal axis with 5 workpiece stations processing units: - drill spindle and thread cutting units - drill capacity up to 2 3/4" and 81,53mm in brass - thread cutting up to 2 1/2" und metric thread Machine is equipped with a feeding-and unloading unit for workpieces. ( feed capacity 3 -4 pieces/min and cycle time 15 - 20 sec.) furthermore incl. coolant device i.D. *

Condition: used, Year of construction: 1968, Technical details: Todpfxsu Iwwzo Ahmsc bore capacity in St 60 - full boring: 40 mm drill capacity in cast iron: 55 mm turning diameter over bed: Ø 22 - 2200 mm clamping diameter: ca.: Ø 100 innen / Ø 200 außen mm Total power requirement: 5,0 kW machine weight approx.: 1,2 t dimension machine xH: 1,70 x 0,80 x 1,40 m Relieving lathe This machine can also be used as a milling head (as a side support). Designation: horizontal unit drilling machine with EB 40 Design: drilling other technical features: Headstock: - Speed 22 - 2000 rpm - feed rate range 0,025 - 0,5 U/mm - three-jaw chuck Ø 190mm with bore Ø 54mm, equipped with internal jaws - headstock bore 45mm - drilling spindle taper MK 5 Operation via control panel on the side of the machine. By removing the lathe chuck, the spindle can be used as a drilling unit. max. slide adjustment 300 mm accessories: -div. outer jaws for lathe chuck i.D. *
