Used Morbidelli Machining Centre for sale (66,674)

Year of construction: 2011, condition: ready for operation (used), Horizontal machining center with 5-axis Fanuc CNC, tilting table with 120° and continuous B-axis. Lrodpfx Agjku A A Horst Pallet magazine with 10 stations, automatic tool changer with 199 stations. Accessories included with the machine: Chip conveyor, high pressure coolant system through the spindle line with separate tank and paper filter.

Condition: new, Year of construction: 2022, Demonstration machine Year of manufacture: 2022 Ledpowt E Tvofx Agrert Equipment and technical data: Base machine 7402 with Pin-Jet dowel insertion function Handheld control device 2D barcode scanner Uninterruptible power supply (UPS) Quattro-HSK package incl. 4-position tool changer XL drilling head Double drill spindle in Y-axis Automatic central lubrication Availability: short notice Location: Flörsheim

Condition: used, machine/vehicle number: 008495, X axis working area: 4175 mm Y axis working area: 1550 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Lredpfx Ajy Edqqegrjt Number of controlled axes: 4 axes Maximum edge height: 45 mm Total number of drilling spindles: 21 Total number of tool changer positions: 12

Condition: used, machine/vehicle number: 008594, X axis working area: 3100 mm Y axis working area: 2200 mm Working Table: Flat table Main Electrospindle power: 8.5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 18 Ledpfx Agozvwqverert Total number of tool changer positions: 20

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, operating hours: 175 h, input frequency: 50 Hz, type of input current: three-phase, workpiece length (max.): 3,700 mm, workpiece width (max.): 950 mm, overall weight: 2,500 kg, table width: 950 mm, working width: 950 mm, air pressure: 6 bar, feed length X-axis: 3,700 mm, feed length Z-axis: 80 mm, power of the milling unit: 12,000 W, rotational speed (max.): 24,000 rpm, Equipment: rotational speed infinitely variable, Lightly used 3-axis CNC machine available immediately! 4-sided formatting 12kW main motor HSK 63F Automatic 4-position tool changer Pickup station for additional tools Drilling head DH17 2 alignment stops in X-direction for short/long panels Foldable tables at front and rear Software on the machine AND in the office with dedicated license Lredpfoxmbm Aox Agret DXF import Modern, fully-featured CNC machine with low operating hours – immediately available!

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, Digital automatic drilling machine BIESSE SKIPPER 130 Ledpfxerkm R He Agrsrt Working condition. Free for loading.

Year of construction: 2004, condition: good (used), Traverses X Y Z; 680 x 394 x 625mm, B axis -110/+ 65 degrees, C axis 0.001 degrees, pallet diameter 130mm, maximum workpiece diameter 300mm, maximum workpiece height 250mm, number of pallets 40, Ljdpsm H Uyzofx Agrort spindle taper BT40, 240 Station ATC, spindle speed 12000rpm, Fanuc G-Tech 16I control, through spindle coolant, and swarf conveyor.

Condition: ready for operation (used), Year of construction: 2009, number of axes: 3, This 3-axis MORBIDELLI UNIX KBT was manufactured in 2009. It features a CNC control system, a working area of 3000 × 1000 mm, and a maximum panel thickness of 60 mm. Equipped with multiple drilling and milling units, including 24 vertical and 4 horizontal spindles, it also has a fixed saw unit and supports both manual and automatic panel handling. Consider the opportunity to buy this MORBIDELLI UNIX KBT CNC Wood Machining Centre. Contact us for more information. • Working area: 3000 × 1000 mm • Maximum panel thickness: 60 mmUpper drilling and milling units: • 24 independent vertical spindles • 2 independent horizontal spindles with double output in X direction • 2 independent horizontal spindles with double output in Y direction • 1 independent fixed saw unit in X direction (motor power 2.2 kW)Lower drilling and milling units: Lrjdpfx Aszug R Aegret • 24 independent vertical spindles • 2 independent horizontal spindles with double output in X direction • 2 independent horizontal spindles with double output in Y direction • 1 independent fixed saw unit in X direction (motor power 2.2 kW) • 2 lateral panel clamping clamps • Automatic lubrication • Protective and soundproofing structure for operating units • Safety networks • CE marking Additional equipment • FLOTEX table for manual panel loading • Motorized transfer for automatic panel unloading

Condition: used, Year of construction: 2006, travel distance X-axis: 1,050 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 560 mm, controller manufacturer: Mazatrol, total height: 2,700 mm, total length: 3,445 mm, total width: 3,301 mm, overall weight: 8,900 kg, table length: 550 mm, table width: 1,300 mm, controller model: 640 M, spindle speed (max.): 6,000 rpm, spindle speed (min.): 25 rpm, Equipment: documentation/manual, CNC Vertical Machining Centre CNC Control: Mazatrol 640M Table size: 1300 x 550 mm Table load: 1500 kg Movement X-Axis: 1050 mm Movement Y-Axis: 510 mm Movement Z-Axis: 560 mm Lrodpfxoy Nz Eto Agrjt Spindle taper: MAS BT 50 Spindle speed: 25 -6000 1/min. Magazine capacity: 30 positions Weight of the machine: 8900 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2016, General technical data: Panel width min. 250 mm, max. 3000 mm Panel depth min. 100 mm, max. 900 mm Panel thickness min. 12 mm, max. 60 mm Max. weight per panel 50 kg Work surface height 1060 mm Linear speed of panel conveyor with inverter 20 - 95 m/min For panels weighing more than 50 kg, the speed must not exceed 50 m/min Line production capacity up to 25 pieces/minute MORBIDELLI POWERFLEX flexible drilling machine - 5 split lower vertical drilling heads automatic flexible drilling heads with NC control - with 26 independent spindles for each drilling head - 5 split lower vertical drilling heads 3 automatic, flexible, split upper vertical drilling heads with NC control - with 26 independent spindles per drilling head - 2 horizontal drilling heads with split heads and 28 + 28 spindles (per side), each independent (arranged on two levels) code MMA004.03 TECHNICAL DETAILS TO BE VERIFIED Lsdpfjw Dba Hox Agrsrt

Condition: used, Year of construction: 2007, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 740 mm, workpiece weight (max.): 700 kg, controller manufacturer: Mazatrol, total height: 2,813 mm, total length: 5,985 mm, total width: 3,056 mm, overall weight: 11,000 kg, table length: 500 mm, table width: 500 mm, controller model: Matrix Nexus, spindle speed (max.): 18,000 rpm, Equipment: documentation/manual, CNC Horizontal Machining Centre CNC Control Mazatrol Matrix Pallet table size 500 x 500 mm Number of pallets 2 Table load 700 kg Movement X-Y-Z-axis 730x730x740 mm Table indexing 0,001 ° Spindle taper DIN 69871A-40 Spindle speed 18.000 1/Min Spindle motor 35-26 kW Magazin capacity 80 Lrodpfxey N Addo Agrjt If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° Lredpfx Agsvt D D Uorjt - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: used, Year of construction: 2001, travel distance X-axis: 710 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 660 mm, controller manufacturer: Mazatrol, total height: 3,050 mm, total length: 7,109 mm, total width: 7,805 mm, overall weight: 11,600 kg, table length: 500 mm, table width: 500 mm, controller model: Fusion 640 M, rotational speed (max.): 15,000 rpm, rotational speed (min.): 35 rpm, spindle speed (max.): 15,000 rpm, spindle speed (min.): 35 rpm, table load: 500 kg, Horizontal Machining Centre with Palletech Lrsdpjy Nz Iuefx Agrjt CNC Control Mazatrol Fusion 640M Pallet table size 500 x 500 mm Number of pallets 10x Table load 500 kg Movement X-axis 710 mm Movement Y-axis 610 mm Movement Z-axis 660 mm Table indexing 360 x 1° Spindle Taper DIN 69871A Spindle speed 35 - 15.000 R/min Magazin capacity 120 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2008, 3650 x 1560mm Matrix Table 4455mm x axis stroke [for routing] 1930mm y axis stroke [for routing] 250mm z axis stroke 150mm Max panel clearance X / Y Axes vectorial speeds 43m/min Z axis speed 15m/min Power 2000 Routing Unit 9 / 10hp for HSK63F toolholders. Speeds from 12000 to 18000rpm Lrodjzd Utwspfx Agret 250m3 / hr vacuum pump Telesolve long distance remote diagnostic system Fitted with following options Interpolating Z axis Centralised dust extraction system Pre-setting for angle driven heads TR10 Fixed 10 position toolchanger [ mounted on side of table ] R8 Rapid 8 position rotary toolchanger [ mounted on operating unit support beam ] 2 x Electronic detecting systems for panel height and tool length 3 x Additional rear stops Automatic centralised lubrication "PC Office" Console for easy movement around machine. Including Windows XP operating system 15" Colour monitor Keyboard CD Rom drive 40 Gbyte hard disk 128MB Ram Serial nr - AA2 / 000268? Year - 2008 CE Compliant Condition - Good

Condition: ready for operation (used), Year of construction: 2009, - USED - 3-AXIS VERTICAL MACHINING CENTRE   X-AXIS TRAVEL: 635 mm Y-AXIS TRAVEL: 510 mm Lsdpfx Agezlu S Nsrsrt Z-AXIS TRAVEL: 460 mm RAPID FEEDS X-Y-Z: 30 m/min SPINDLE: 10000 rpm; 9 - 13 kW; 57 - 83 Nm; SK-40 TABLE SIZE: 790 x 560 mm MAX ADMITTED LOAD: 600 Kg TOOL MAGAZINE: BASKET-TYPE ; 20 POS MAX TOOL DIAMETER: 80 (130) mm MAX TOOL LENGHT: 300 mm MAX TOOL WEIGHT: 6 Kg CONTROL UNIT: HEIDENHAIN iTNC 530 WEIGHT: 3650 Kg OVERALL DIMENSIONS: 3375 x 2440 x 2665 mm ACCESSORIES: SWARF CONVEYOR ; PORTABLE HANDWHEEL

Condition: good (used), Year of construction: 1998, operating hours: 6,000 h, functionality: fully functional, machine/vehicle number: 107.40.98.165, Year 1998 Heidenhain TNC 430 710x500x500 mm - 42000 RPM Netweight 5670 kg Dimensions 2794x2997x3035* mm TECHNICAL DATA Table Dimensions 1220 x 457 mm Admitted load 1575 kg T-grooves 14 mm Number of T-grooves 5 Travels Longitudinal X 1016 mm Transverse Y 508 mm Vertical Z 635 mm Workspindle Power of AC-motor, 2-stepped gears 11kW Speed range, continuous 10-7500 min-1 Spindle speed (option) 10'000 rpm Taper ISO40 Lrjdecl Ruropfx Agrot Feeds drive Feed programmable axes X, Y & Z 0 – 7620 mm/min Rapid feed axes X, Y, Z 18,0 m/min Automatisation Tool changer 20 pos Tool changing time (for nearby posts) 5,0 sec. errors and omissions excepted-data given without obligation Inventory Nr.4112006, machine equipped with  : NC Heidenhain TNC430M Milling spindle 42’000 min-1, HSK 40 E 36 tool positions Electronical handwheel Tool measuring Renishaw TS27 Ethernet card Minimal quantities greasing Unilube Aspiration Lumestat Protection cabin Rotary table Air passage through rotary table Vacuum clamping (by external provider) Spray gun Chips conveyor

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 15 h, YCM UV650 Lrodpfx Agjuxbciorjt Spindle: SK40 / 15.000 rpm, 17kW toolchanger places: 60 control: Heidenhain TNC640 travel: X:620mm Y:520mm Z:460mm B:-50 / +110 C:360 spindle cooling system Blum laser for tool length measurement 3D probe el. hand wheel Emulsion cooling ICS 20bar outer cooling cooling gun chip conveyor machine dimensions: L:4250mm W:2310mm H:2.560mm weight: appr. 12.500kg

Condition: used, Work area and workpiece capacity Travel range X-axis: 3110 mm Travel range Y-axis: 1620 mm Workpiece passage Y: 1,900 mm Workpiece passage Z: 180 mm Workpiece length in shuttle mode: 1,400 mm Table design: TV FLEX 1600 / FLEXMATIC Number of cross traverses: 6 Positions of traverses: 6 to 12 positions Axis speeds and drive data Maximum vector speed X/Y (PRO-SPACE): 56 m/min Maximum vector speed X/Y (PRO-SPEED): 78 m/min Speed of vertical drilling spindles: up to 8,000 RPM Speed of horizontal drilling spindles: up to 8,000 RPM Max. speed of main spindle: 24,000 RPM Speed of grooving unit/circular saw: frequency-controlled, approx. 2,500-8,000 RPM CNC control and software Operating system: Windows 7 Display: 21.5" LCD Full-HD (16:9) Operation: Keyboard, mouse and machine control panel Software: Maestro CNC Programming: Parametric programming, graphic programming, ISO code, DXF import Machining functions: Milling, drilling, tool management, machining programs Simulation: Graphic simulation of drilling and milling operations TECPAD: 7" touchscreen for machine functions and error messages Mobile operation: Portable control panel for operation along the machine Drilling and grooving unit F23L Vertical drilling spindles: 13 independent spindles (7 clockwise, 6 counterclockwise) Horizontal drilling spindles: 10 independent spindles Arrangement of horizontal spindles: 4 spindles in the X direction on one side, 3 spindles in the X direction on the opposite side, 2 spindles in the Y direction Integrated sawing unit: Grooving and circular saw unit in the X direction Saw blade diameter: 125 mm Motor power of sawing unit: 2.2 kW (approx. 3 hp) Stroke of vertical drilling unit: 75 mm pneumatic stroke Stroke of horizontal drilling unit: 75 mm pneumatic stroke Frequency inverter: Programmable speed control up to 8,000 RPM 5-axis milling unit and tool changing system Main unit: JQX 5-axis milling unit Lsdjzuwurspfx Agrort Spindle type: Hiteco HSK-F63 electric spindle Power: 10 kW rated power Peak power (S6): approx. 9.5-15 kW Maximum speed: 24,000 RPM Bearings: Ceramic bearings Cooling: Liquid-cooled spindle Lubrication: Central automatic lubrication system Rear tool magazine TRB 14 Magazine positions: 14 Travel range: 350 mm Pitch: 115 mm Max. tool diameter: 240 mm Max. total tool weight: 70 kg Front tool magazine FAST 14 Magazine positions: 14 Max. tool diameter: 130 mm Max. tool weight per position: 8 kg Max. total weight: 24 kg Vacuum system, workpiece clamping and positioning Vacuum cups: 12 pcs, permanently mounted Dimensions of cups: 145 x 145 mm Height of cups: 75 mm Vacuum pump: Standard 1 vacuum pump Additional vacuum pump: 90 m³/h Workpiece supports: 4 pneumatic workpiece supports Rear stops: 8 aluminum stops Intermediate stops: 8 aluminum stops Side stop: Left reference stop with laser positioning Preparation for clamping cylinders: Prepared for 6 pneumatic clamping cylinders Extraction and compressed air Connection power: 23 + 28.5 kVA Compressed air consumption: 450 l/min Required extraction capacity: 4,500 m³/h Air velocity in extraction: 25 m/s Extraction nozzle: 250 mm

Condition: ready for operation (used), Year of construction: 2011, - USED - TWIN-SPINDLE HEAD 3-AXIS VERTICAL MACHINING CENTRE WITH ROTOPALLET X-AXIS TRAVEL: 520 mm Y-AXIS TRAVEL: 360 mm Z-AXIS TRAVEL: 360 mm DISTANCE SPINDLE NOSE-TABLE: 200-560 mm RAPID FEEDS X-Y-Z: 60 m/min SPINDLE: 36 - 10500 rpm; 30 - 35 kW; HSK A63 PALLET: N.2 MAX ADMITTED LOAD: 450 Kg TOOL MAGAZINE: 21X2 POS MAX TOOL DIAMETER: 88 (125) mm MAX TOOL LENGHT: 250 mm CONTROL UNIT: FANUC 31i A5 WEIGHT: 5300 Kg OVERALL DIMENSIONS: 3200 x 3250 x 3245 mm ACCESSORIES: SWARF CONVEYOR ; HIGH PRESSURE COOLANT PUMP ; Lsdpfx Agsx U E Szsrert PAPER FILTER ; TOOL SETTER NOTE: WITH No 1 4th AXIS TABLE

Condition: used, Year of construction: 1997, Haas VF-2 CNC Vertical Machining Centre with Haas Control. S/No. 10064 (04/1997), Table size 915mm x 355mm, 20 Tool ATC, BT40 Spindle Taper Location: These lots are located in Andover, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. Lrodpfx Aszy N H Degrst

Condition: used, Year of construction: 2017, functionality: fully functional, For sale: CNC drilling and milling center Morbidelli Uniflex S (SCM Group), year 2017, serial number AA2/004505. Weight 4,450 kg, power supply 400V/3-phase, 46A/50Hz. The machine is in working condition. Contact us for more information and price. Lrsdpfxjy N Tmps Agret

Condition: like new (used), Year of construction: 2020, functionality: fully functional, operating hours: 480 h, workpiece length (max.): 3,715 mm, workpiece width (max.): 1,320 mm, workpiece height (max.): 180 mm, overall weight: 6,060 kg, spindle speed (max.): 24,000 rpm, Equipment: documentation/manual, rotational speed infinitely variable, The machine has 270 operating hours, almost like new; features laser positioning. Technical data: Brand: Busellato JET Master T 4 Technical specifications: - Machining area: 3715x1320 mm (X,Y) - Workpiece height: 180 mm - Motor power: 9.5 kW - Max spindle speed: 24,000 rpm - C axis: available - Drilling unit: 19 spindles - 1 sawing unit - 16-position plate tool magazine - 3-part safety mat - Automatic central lubrication Vacuum pump capacity (m3/h): 244/286 Payment in euros or forints, price is net. Machine new price: €125,675. Sale price: €47,500 +36-30-9198-716 Lrjdpfxoxawlbo Agrjt

Condition: used, machine/vehicle number: 008377, X axis working area: 3390 mm Y axis working area: 1570 mm Working Table: Pod and Rail Main Electrospindle power: 13 KW Number of controlled axes: 4 axes Total number of drilling spindles: 32 Total number of tool changer positions: 10 Lrjdpfx Agox Swb Ajret

Condition: ready for operation (used), Year of construction: 2018, - USED - 3-AXIS VERTICAL MACHINING CENTRE   X-AXIS TRAVEL: 1100 mm Y-AXIS TRAVEL: 560 mm Z-AXIS TRAVEL: 510 mm Lodswh Dg Ropfx Agrsrt DISTANCE SPINDLE NOSE-TABLE: 120-630 mm RAPID FEEDS X-Y-Z: 30 m/min SPINDLE: 20 - 12000 rpm; 9 - 13 kW; ISO 40 - DIN TABLE SIZE: 1400 x 560 mm MAX ADMITTED LOAD: 1000 Kg HIGH PRESSURE COOLANT: 12 Bar TOOL MAGAZINE: CHAIN-TYPE ; 30 POS CONTROL UNIT: HEIDENHAIN TNC 620 WEIGHT: 5830 Kg OVERALL DIMENSIONS: 4028 x 2750 x 2950 mm ACCESSORIES: SWARF CONVEYOR ; PORTABLE HANDWHEEL NOTE: WITH No 30 TOOLS-HOLDERS ISO 40

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Work in X, Y, Z axes Working area 3100 x 1340, Z axis = 180 mm Horizontal drills on X axis – 6 pcs Horizontal drills on Y axis – 4 pcs Vertical drills on X axis – 8 pcs Vertical drills on Y axis – 6 pcs Two tool magazines: side – 11 positions and transfer – 14 positions Grooving saw on X axis Spindle 8 kW, air-cooled, 600–24,000 RPM, HSKF63 Becker Vacuum Pump 2.2 kW Option for dual-field operation X axis speed – 25 m/min (programmable) – 56 m/min (vector) Ledpjz D Tggefx Agrert Y axis speed – 50 m/min (programmable) – 56 m/min (vector) Z axis speed – 15 m/min
