Used Precitrame Cnc Horizontal Transfer Machine for sale (69,072)

Condition: used, Year of construction: 2020, includes accessories Working width 950 mm 4-position tool changer, side-mounted Lodpfx Ajzn N Iqja Rjrr Location: Nattheim

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 31-44336, travel distance X-axis: 630 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, workpiece weight (max.): 500 kg, spindle speed (max.): 24,000 rpm, No minimum price – guaranteed sale to the highest bidder! The machine spindle has been completely overhauled! TECHNICAL DETAILS Travel range X-axis: 630 mm Travel range Y-axis: 630 mm Travel range Z-axis: 630 mm Pallet size: 400 × 500 mm Number of pallets: 6 Pallet change time: 9 s Max. workpiece size: 720 × 800 mm Max. workpiece weight: 500 kg NC rotary table: B-axis B-axis rotation range: 360,000 × 0.001° B-axis rotation speed: 40 rpm Tool holder: SK 63 Max. tool diameter: 150 mm Max. tool length: 227 mm Max. tool weight: 12 kg Spindle speed: 45–24,000 rpm Spindle torque: 48/72 Nm Spindle drive: 30 kW Feed rate X/Y/Z: 1–60,000 mm/min Rapid traverse X/Y/Z: 60,000 mm/min Feed force: 10,000 Nm MACHINE DETAILS Total connected load: approx. 60 kW Connection voltage: 400 V Mains frequency: 50 Hz Total weight: approx. 12,500 kg EQUIPMENT Chip conveyor Documentation/Manual Ljdpfx Ajzwd Htsa Rjrr

Year of construction: 2000, condition: used, X-axis: 1000/1245mm, Y-axis: 630mm, Z-axis: 550mm, angle table: 1200x630mm, quill stroke: 75mm, tool holder: SK40, drive power: 7.5kW, spindle speed (continuously variable): 20-7,000/min, feeds: 1-20,000mm/min, rapid traverse: 20,000mm/min, connected load: 14kW, rated current: 24A, control: HEIDENHAIN TNC 426 with hand-held control unit, total connected load: 17kVA, weight: 6t, operating hours, machine on: 122,355h, control on: 18,579h, program run: 36,747h, with Knoll 400 K-1 scraper belt conveyor. Equipment: manually swivelling vertical milling head, protective enclosure with viewing window, coolant system, chip conveyor, HEIDENHAIN 3D touch probe TS 642. An on-site inspection is possible. Ljdpfezvv I Tex Aa Rorr

Condition: used, Year of construction: 2002, Working range: 5mm-50mm, max. tool spindle speed: 25000rpm, geometries: spheres/aspheres, operating modes: manual/automatic, collision avoidance and precision via integrated center thickness measurement, control: CNC. Machine dimensions X/Y/Z: approx. 700mm/1350mm/1950mm, weight: approx. 850kg. Documentation available. Inspection possible by arrangement. Lredezvv I Hspfx Aa Ror

Condition: used, 4-axis CNC milling machine Manufacturer: Quick Type: UA-481 New machine Technical data: 380 V-3-phase Working area: 2100 x 3050 x 400 mm 9 kW HSD/HSK-F-63 spindle Ljdpfjzvgmyjx Aa Rerr NC Studio control 10 linear tool changers Double-layer vacuum table with 6 zones Yaskawa servomotor 2 Becker pumps (250 m³/h) NC Studio control with German language Optionally available at an extra charge: - 10-position rotary tool changer on the gantry - 12-position rotary tool changer on the gantry - 2 pneumatic pressure rollers for multiple part clamping - Vacuum table with T-slot for manual fixing of components Other configurations available upon request.

Condition: new, 3-axis CNC milling machine Manufacturer: Quick Type: UE-481PL New machine Technical data: - PC with Windows 11 - CAD-CAM connection as desired - NC Studio control software - Heavy-duty machine base - Working area: 2100 x 3050 x 200 mm - Double-layer phenolic resin table - grid table - 9 kW HSD milling spindle with 24,000 RPM - 9-position HSD drilling unit - 90° rotatable sawing unit - 12-position linear tool changer - Automatic tool length measurement - Wireless control panel Lredszvgmtopfx Aa Rsr - 3 stops in X, 2 in Y - 2 units of 250 m3/h Becker vacuum pump - Automatic central lubrication - Safety via light curtain - Lifting table loading - Unloading table

Condition: new, CNC Machining Center Manufacturer: COMEC Type: MD TOP XL The ideal solution for CNC machining of narrow, complex workpieces. COMEC makes it easy for you. Head configurations can be individually configured for: - Sawing with a 360-degree axis - Milling heads for horizontal and vertical machining - Drilling heads with individually selectable spindles, vertical and horizontal - Multi-spindle row drilling heads, individually selectable, also horizontally - Horizontal milling head with a 360-degree C-axis Specially designed clamping table, travels in the X direction automatically and is program-controlled. Individual equipment options are available, for example: Base frame Heavy-duty base machine stand, electrically welded. Maximum workpiece sizes: X-axis 3350 mm (or 1500 + 1500 mm in two working areas) Y-axis 200 mm Z-axis 180 mm Traversing tool carrier 3 axes CNC controlled. Linear and interpolating. Positioning speed of the tool carrier max. 70 m/min. Vertical drive spindles Lrjdpfx Aajzvgl No Ror 1 drive spindle for 1 drilling head with individually selectable drilling spindles 5 vertical drilling spindles, spacing 32 mm 3 horizontal double-output spindles on the Y-axis, spacing 32 mm 3 horizontal double-output spindles on the X-axis, spacing 32 mm 1 Vertical milling electro-spindle 8.0 KW, 12,000/18,000 RPM. Tool holder ISO 30 taper + ER 32 collet for manual tool change with quick release. 1 Milling / Sawing / Drilling spindle With motor 7.0 KW, 8,000 - 12,000 RPM. 360 C-axis, interpolating With attachment with 180 double output for saw blade and drilling/milling tool Horizontal electro-spindle 1 Milling spindle With motor 5.6 KW / 12,000 - 18,000 RPM With ER 32 collet 4 + 4 workpiece supports Adjustable on guides with 4+4 pneumatic clamping cylinders, with 2+2 horizontal clamping cylinders and front and side stops. Automatic magazine CA 2 Adjustable on linear guides, fixed on the left (zero) With easy access for the operator and a high degree of autonomous operation. With coated discharge chute for the machined workpieces. CONTROL UNIT - CAD CAM Free-standing control cabinet next to the machine Industrial PC with operator interface with 17" color touchscreen. SSD 120 GB, interface: Ethernet USB / RS 232 Programming with 3-D supported display Option for network connection for programming and remote support. Remote control console for controlling the machine by the operator during tests and setup. PROTECTIVE CABIN Surrounded with solid sheet metal panels With front protective screens, controlled by the work cycle Chip conveyor With outlet to the right side, with motor 0.37 KW Connection 400 V / 50 Hz Find it quickly Offer machines Subscribe to newsletter Unsubscribe from newsletter Contact us Overview

Condition: used, Year of construction: 2020, workpiece weight (max.): 35,000 kg, total length: 15,600 mm, total height: 6,000 mm, total width: 6,000 mm, overall weight: 155,000 kg, The Pittler WMZ PV4000 / 1-2 is a heavy CNC vertical turning machine with a portal design, featuring one workpiece spindle and two independently movable tool carriers. The machine enables turning, drilling, milling, and grooving. The right tool carrier is designed as a swiveling multifunction head with a B-axis and driven tools. Two separate chain magazines provide a total of 94 tool positions. Technical Data Machine Number: ZV029 Machine Concept: Portal machine with one workpiece spindle and two tool carriers Machining Processes: Turning, drilling, milling, and grooving Maximum Swing Diameter: 3800 mm Maximum Workpiece Diameter: 3800 mm Maximum Workpiece Speed: 100 min-1 Rated Speed: 36.7 min-1 Workpiece Clamping: Manual Chuck: Röhm Tool Holder: Capto C8 Tool Magazines: 2 chain magazines Tool Positions: 2 x 47 Total Number of Tool Positions: 94 Maximum Tool Diameter: 120 mm according to the operating manual Maximum Tool Diameter: 150 mm according to the order confirmation with appropriate magazine loading Maximum Tool Length: 400 mm Lrjdpfx Aezu S U Hea Rer Maximum Tool Weight: 20 kg Travel Paths X1-Axis Right Tool Carrier: 3200 mm X2-Axis Left Tool Carrier: 2800 mm Z1-Axis Right Tool Carrier: 1000 mm Z2-Axis Left Tool Carrier: 1000 mm Rapid Traverse X-Axes: up to 32 m/min Rapid Traverse Z-Axes: up to 20 m/min Workpiece Spindle Gear Reduction: 1 to 30 Maximum Speed: 100 min-1 Rated Speed: 36.7 min-1 Rated Power: 67.4 kW Short-Term Total Power: 202.2 kW Rated Torque: 52.65 kNm Maximum Drive Torque: 71.55 kNm Torque according to Order Confirmation: 67000 Nm at 40% duty cycle Motor Spindle Power according to Order Confirmation: 200 kW at 100% duty cycle Maximum Spindle Load Capacity including Chuck, Clamping Jaws, and Workpiece: 35000 kg Spindle Flange Diameter: 1900 mm Thrust Bearing Diameter: 1400 mm The workpiece spindle is designed as a water-cooled motor spindle with precision axial deep groove ball bearings. Tool Carrier and Multifunction Head The right tool carrier features a swiveling multifunction head with two Capto C8 holders for turning tools as well as drilling and milling tools. B-Axis for Stepless Positioning Swivel Range: 180 degrees Speed of Driven Tools: up to 6000 min-1 Tool Spindle Torque: approx. 120 Nm at 100% duty cycle Hydraulic Clamping Direct Measurement System Direct Coolant Supply High-Pressure Coolant Supply: up to 70 bar Tool Magazines Two chain magazines with 47 tool positions each Tool Holder: Capto C8 Maximum Tool Diameter: 120 mm Up to 150 mm with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Tool Cleaning with Blowing Air Manual Magazine Loading Coolant and Chip Disposal Two Knoll Chip Conveyors Type 600 S-2/120 Knoll Band Filter Type KF400-2300 Additional Equipment Röhm Chuck Spindle Cooling Hydac FLKS-4S Hydraulic Unit Hydac TBM20 Electrical Data Operating Voltage: 3 x 400 VAC Protection Class: IP55 Maximum Power Consumption: 280 kVA Component weight max.: 35,000 kg Weight approx.: 155,000 kg Rotation height max.: 2,100 mm Table diameter: 3,800 mm Swing: 3,800 mm Control: Siemens SINUMERIK 840D sl Dimensions (LxWxH) approx.: 15600 x 6000 x 6000 mm Year of construction: 2,020 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: new, CNC machine Lodpjzvfl Isfx Aa Rsrr Manufacturer: Comec Type: MD JAMB New machine 3 machining supports for cutting to miter angles, milling recesses for corner connectors, and door lock plates. A complete door frame element with decorative trim and rabbet trim is machined in a single clamping operation. This allows a complete door frame to be machined in approximately 2.5 to 3 minutes. The machining equipment can be individually adapted to customer requirements. Quick search Offer machines Sign up for newsletter Unsubscribe from newsletter Contact us Overview

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm - Feed rate: 25 m/min - Spindle speed: 3600 RPM - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting - CE compliant Optional against additional charge Ljdpfx Aaezvduuj Rorr

Condition: used, Year of construction: 1998, WEEKE BP 150/K Manufacturer: WEEKE Type: BP 150/K Year of construction: 1998 Machine type: CNC machining center / Point-to-point cantilever machine Working area X approx. 3,645 mm* Working area Y approx. 1,250 mm* Working area Z approx. 250 mm* 1 main spindle power: 10 kW Main spindle speed max. 24,000 rpm Tool holder: HSK-F63 Tool changer: 8-position 4th axis Ljdpfezvbhrox Aa Rorr 30 vertical drilling spindles 6 horizontal drilling spindles Table system: Console table Number of consoles: 8 Vacuum pump Safety device Control system: HOMAG HOMATIC 2000 / HOMATIC 2000 IPC* Software: HOMAG woodWOP 4.5 4th axis: C-axis / NC-controlled auxiliary axis*

Condition: excellent (used), functionality: fully functional, * Mori Seiki NMV 5000 DCG. * Year: 2008. * Equipment value, including zero points, chucks, BT taper chucks, turning tool chucks, and pallets: 50,000–55,000 euros. * 5-axis continuous machining center. * High-precision Heidenhain linear guides. * Interface for connecting a pallet loader and robot. * Table with turning function. * Independent high-pressure cooling system at 40 bar. * Spindle oil cooling system. * BT 40 tool magazine. * Magazine capacity: 60 tools. * Maximum tool diameter: 125 mm. * Maximum tool length: 300 mm. * Maximum tool weight: 8 kg. * Travel on the X-axis: 730 mm. * Travel on the Y-axis: 510 mm. * Travel on the Z-axis: 510 mm. * Table with turning function. * Maximum workpiece diameter in turning mode: 450 mm. * Maximum turning diameter in turning mode: 700 mm. * Mori Seiki Mapps 4 conversational control. * Spindle speed: 20,000 rpm. * Spindle motor power: 18.5 / 15 kW. * Maximum cutting torque: 135 Nm. * C-axis table: 360,000 x 0.001 * B-axis rotation: +160 / -180 * Rapid traverse X/Y/Z: 50 / 50 / 50 m/min * Renishaw tool measurement system. * Renishaw workpiece measurement system. * Automatic zero-point adjustment. * Automatic cutting power control. * Program memory: 2 MB. * Dynamic zero-point correction (up to 8 points). * Pre-check of tool availability. * Custom macro (999 variables). * Rear chip conveyor. * Tool life management (128 x 2 groups). * Electrical transformer. * Documentation, parts list, electrical diagrams, programming, and instruction manual. Lsdpfx Ajzuxntea Rsrr * Weight: 13,500 kg. * Machine is currently in operation. * Available for inspection by an authorized Mori Seiki technician. * Immediate delivery, subject to immediate sale.

Condition: good (used), Year of construction: 1996, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, Travel distances: X= 600, Y= 400, Z= 400 mm Table size: 900 x 480 mm Spindle speed: 40 - 4,000 rpm Lredpfey Eyfwsx Aa Rer Dimensions LxWxH: 2500 x 2200 x 2200 mm Weight: approx. 3,000 kg

Condition: used, Year of construction: 2003, Technical details: x-travel: 450 mm y-travel: 450 mm z-travel: 450 mm b-axis: 360.000 x 0.001 ° main spindle speeds:: 45-10000 1/min weight of the machine ca.: 14 t dimensions of the machine ca.: 7 x 2.45 x 3.4 m size of pallet: 320 x 320 mm number of spindles: 2 tool taper: HSK63 tool numbers: 2 x 40 spindle drive motor: 25/36 (100% / 40% ED) kW Double spindle 4-axis machining center Horizontal 4 machine plates Renishaw probe Control Siemens Sinumerik 840D Working space (X / Y / Z): 450x450x450 mm Load pallet / table max .: 300 kg Acceleration: 10 m / s² Rapid traverse: 60 m / min Pallet size: 320 x 320 mm Lrodpfx Aaew Ng D Ho Rjr Chip-to-chip time: 2.6 s Workpiece height max .: 700 mm Tool holder: HSK 63 Tool places: 2x 60 Tool spindle: 10,000 rpm, 95 Nm Speed ??increase to 18,000 rpm Infrared receiver for probe, Make Renishaw Vaf72a0p Tool magazine with 60 places Control panel on the workstation Control panel on the tool installation site Workpiece positioning stations can be rotated manually with hydraulic workpiece clamping 60 bar Pneumatic support control on the workstation Automatic swing gate Extended coolant layer 70 bar / 1500I / VF 250 Coolant Cooler Working space flushing Emulsion mist suction Roto - Clear Automatic setup process Automatic disarming process Runtime and quantity recording Status lamp 3-color modem for remote diagnosis control cabinet lighting *

Condition: ready for operation (used), Year of construction: 2015, CNC Control: F31iA X mm: 560 Y mm: 560 Z mm: 630 B mm: 360.000 Table load capacity kg: 400 Cutting feed rate mm/min X, Y, Z: 50,000 Maximum rapid traverse rate m/min X, Y, Z: 50 Spindle speed rpm: 14,000 Ljdpfx Aajzu Tryo Rorr Spindle power kW: 18.5 Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Number of positions in tool changer: 60 Maximum tool diameter: mm 70 Maximum tool diameter with adjacent positions empty: 140 Maximum tool length mm: 400 Maximum tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant: Yes

Condition: used, Year of construction: 2012, total height: 4,500 mm, total length: 8,000 mm, total width: 6,000 mm, overall weight: 50,000 kg, Machine No.: 11720001123 Control Heidenhain iTNC 530 HSCI (3D path control) Travel Paths X: 1,850 mm Y: 2,100 mm Z: 1,250 mm B-axis: controlled universal swivel milling head C-axis: NC rotary table Ø 1,700 mm 5-axis simultaneous machining Spindle Motor spindle SK50 Speed: 20–12,000 min⁻¹ Power: 44 kW (40% duty cycle) / 32 kW (100% duty cycle) Torque: 288 / 187 Nm Tool holder: SK50 according to DIN 69871 Tool Changer 60-fold chain magazine Double gripper Lodpfjzv A Aksx Aa Rsrr Equipment IKZ 40 bar Chip conveyor Tool measurement system Blum Laser NT Hybrid Heidenhain TS 640 infrared probe Electronic handwheel Minimum quantity lubrication (MQL) Oil/emulsion mist separator Coolant through spindle Coolant tank 980 l Rotating viewing window 3D quickSET Machine Protection Control (MPC) Adaptive Feed Control (AFC) ATC (Application Tuning Cycle) DMG MORI NetService DMG MORI SMARTkey Documentation and electrical schematic (German) Travel X-axis: 1850 - mm Dimensions (LxWxH) approx.: 8000 x 6000 x 4500 mm Travel Y-axis: 2100 - mm Weight approx.: 50,000 kg Travel Z-axis: 1250 - mm Year of construction: 2,012 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: good (used), Year of construction: 2008, Offer 26696 Lredpfxozvnb So Aa Rjr Technical specifications (approximate): - CNC flame cutting machine with 2 torches, as shown in the image - 2 torches with adjustable height and inclination - Track gauge approx. 4.2 m - Track length approx. 7.5 m - Track height approx. 0.5 m - Support table - Space requirement approx. L 8 x W 7.5 x H 2.3 m - Weight approx. 3 tons

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, CNC Machining Centre – Horizontal | Brand: HÜLLER HILLE | Type: nbh 170R Year of manufacture: 2005 The machine can be inspected under power by prior appointment. Condition: In working order / ready for operation. TECHNICAL SPECIFICATIONS: Working area - X/Y/Z axes: 1.000/800/800 mm - Workpiece swivel range within the working area: Ø 900 mm - Distance from table centre to spindle nose in Z: 138.9 (HSK-A 100) mm Position measurement system - Encoder scales: direct (measurement method) - Position uncertainty A according to DIN ISO 230-2: 0.007 mm 180-degree pallet changer with 4 x 90-degree pallet rotators Pallet - Pallet clamping surface to DIN 55201, Form A2: 500 x 630 mm - Transport load per pallet: approx. 0,8 tons - Height of the system: 1.100 mm NC rotary table (B-axis) - Smallest incremental step: 0,001 degrees - Repeatability: ± 0,001 degrees - Accuracy across all positions: ± 0,002 degrees - Permissible torques on the clamped table: * Tangential torque: max. 7.000 Nm * Tilting moment: max. 16.000 Nm - Clamping forces: * on the table: 147.000 Nm * on the pallet: 84.600 Nm Working spindle / gear head - Tool holder to ISO 12164 (DIN 69893): HSK-A 100 - Diameter at front bearing: 100 mm - Drive power 100% duty cycle/60% duty cycle: 37/46 kW - Speed range: 25 – 10.000 rpm Feed / Feed force / Rapid traverse: - Feed range X/Y/Z axes: 1 – 60.000 mm/min Lsdpfx Aozviaija Rerr - Feed force on X/Y/Z axes, 25% duty cycle: approx. 15.000 N - Rapid traverse speed, X/Y/Z axes: 60 m/min - Rapid traverse, rotary table: 30 rpm - Acceleration: approx. 6 m/s² - Ball screw (pitch): Ø 50 (30) mm Tool magazine for 4 magazine cassettes, including two additional magazine cassettes. Electrical - Rated power: 74 kVA Compressed air Coolant system, make: KNOLL The internal coolant supply can be switched to compressed air. - Coolant pump 20–70 bar - Coolant tank, 2.500 l Machine layout - Space requirements, L x W x H: approx. 8 x 3.5 x 3.5 m - Weight: approx. 24 tons ACCESSORIES / EQUIPMENT: - Control system: Siemens SINUMERIK 840D ADDITIONAL EQUIPMENT FOR AUTOMATED MANUFACTURING PALLET STORAGE SYSTEM Technical data sheet with full details, including information on the wide range of features, available on request. No guarantee is given as to the completeness or accuracy of the technical specifications and specifications. – Subject to prior sale –

Condition: new, functionality: fully functional, Topking X-25 CNC Cylindrical Grinding Machine Topking “The X-25 CNC cylindrical grinding machine is the perfect answer for UK manufacturers facing space constraints,” explains Simon Rood. “Unlike traditional T-type base designs, the X-Series utilises a revolutionary cross-slide structure. This design allows the X-25 to reduce floor space requirements by over 30% while significantly enhancing stability. It is a superior choice when space is limited, making it ideal for busy production environments where every square metre counts.” Machine overview INTRODUCTION Ledpfxsubbqis Aa Rjrr Compact CNC cylindrical grinding machine with an impressive capacity. The X series CNC cylindrical grinding machine integrates advanced design and innovative features, offering efficient, precise, and flexible machining solutions. This grinder can meet various processing needs and ensure high-quality results for small or large components. The X-axis and Z-axis of the X-series CNC cylindrical grinding machine adopt a cross-slide design, effectively reducing the footprint and axial travel, thereby saving production space. The high-rigidity machine body and the heavy-duty spindle and tailstock significantly increase the component load capacity. The high rigidity machine body ensures stability during grinding, providing high-quality machining results. The operating system is equipped with a high-performance CNC control system and a built-in graphical user interface (GUI), making setup easy and enabling users to operate with ease. The grinding applications are extensive, offering customers the most suitable machining solutions. Specification Swing (Max) 270mm Distance between centres 200mm Grinding Diameter (Max) 250mm Weight between centres (Max) 5kg CNC Control System FANUC or Mitsubishi CNC Controls

Condition: used, Year of construction: 2014, Working dimensions: X = 3425 mm, Y = 1287 mm, Z = 325 mm. Max. workpiece height: 180 mm. Max. clearance under the hood: Y = 1450 mm / Bumper version = 1370 mm. Includes CabinetControl Base, 1 machine license, and 1 office license. Milling head 7830, 1-stage, power 6.5 kW, air-cooled, n(max.) 1000 - 18000 min-1, infinitely adjustable. Max. power at 12000 min-1 to 18000 min-1 with HSK-F 63 tool holder, with collet chuck with HSK shank. Drilling unit 7884, 14 spindles, 10 vertical spindles individually accessible, arranged in an L-shape, 6 in the X direction and 4 in the Y direction. Drive power 3 kW, 32 mm pitch. Sawing unit: Integrated sawing unit for sawing/grooving in the X direction, n(max.) 1000 - 5650 min-1, infinitely adjustable. Tool holder: A = max. DM = 125 mm. Lrsdpfey Tpz Rsx Aa Rsr Location: Supplier.

Condition: excellent (used), Year of construction: 2014, 2014 DMG MORI NHX 5000 CNC Horizontal Machining Centre with Siemens 840D SL Control Lsdszvcl Sepfx Aa Rerr High-Performance DMG MORI NHX 5000 CNC Horizontal Machining Centre, Manufactured In 2014 & Equipped With Siemens 840D sl CNC Control. The machine Has Recorded 23,262 Power-On Hours, 15,894 Spindle Hours And Is Available For Inspection Under Power. Designed For Precision Machining, The Machine Features A 12,000rpm (30kW Motor) SK40 Spindle, 2-Pallet Changer (500 × 500mm (5 'T' Slots), 40-Position Automatic Tool Changer, 1° Indexed B-Axis Table. Axis Travel 'X'=730mm, 'Y'=730mm, 'Z'=880mm. Rapid Traverse 'X,Y & Z'=60m/min. Maximum Spindle Torque 102 Nm. Twin 500 × 500 mm Pallet Changer. Maximum Pallet Load 500 kg. Maximum Workpiece Ø630 x 900mm High. Total Connected Power Load 57 kVA. S/No. 1229000053 (2014) With 40 bar High Pressure Through Coolant System, Chip Conveyor, Renishaw PP60 Touch Spindle Probe & Machine Documentation. Machine Weight Approx. 11.5 Tonnes.

Year of construction: 2016, condition: used, overall weight: 300,000 kg, total length: 16,000 mm, total width: 9,000 mm, total height: 8,000 mm, Waldrich Coburg 17 S-10 FP 300 NC / 5 m – CNC Gantry Milling Machine Machine: 17-10 FP 300 NC / 5 m Serial Number: 2.8304.06 Original Year of Manufacture: 1983 In 2016, it was comprehensively overhauled and modernized by the manufacturer Waldrich Coburg. The machine is equipped with a modern Siemens SINUMERIK 840D sl control system and is ideally suited for heavy-duty machining of large and complex workpieces in machine, tool, mold, and power plant construction. The delivery includes a Universal Fork Milling Head USP 300 C 350 with B-axis as well as an additional Angle Milling Head WFU 500 SZ 400 F17, ensuring versatile machining capabilities for demanding milling tasks. The machine features a modern full protective enclosure, coolant system, chip conveyor technology, and extensive technical documentation including circuit diagrams and overhaul documentation. The system has been professionally dismantled and packed in containers. It is located at the Port of Hamburg and is immediately available and ready for worldwide shipment. Ljdpfx Ajzc Sagsa Rsrr Manufacturer: Waldrich Coburg Overhauled by Waldrich Coburg (2016) Siemens SINUMERIK 840D sl Universal Fork Milling Head USP 300 C 350 Additional Angle Milling Head WFU 500 SZ 400 F17 Workpiece weight up to 100 t Full protective enclosure Extensive technical documentation available Dismantled and ready for loading Location: Port of Hamburg, Germany Immediately available Tool holder type: ISO 50 Travel X-axis: 5700 - mm Movement B-axis: 0 - 180 ° Dimensions (LxWxH) approx.: 16000 x 9000 x 8000 mm Passage between the uprights: 3,500 mm 5-axis machining: Yes Travel Y-axis: 3500 - mm Weight approx.: 300,000 kg Travel W-axis: 800 - mm Travel Z-axis: 2050 - mm Year of construction: 2,016 Condition: unchecked Terms of payment: 100% prepayment before pick-up Terms of delivery: FOB Free On Board under power: No

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 1205-H740-00, overall weight: 6,000 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 50 mm, controller model: ANDRONIC 2060, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item within the specified period, between October 7, 2026, and October 14, 2026! TECHNICAL DETAILS Travel range, X-axis: 500 mm Travel range, Y-axis: 100 mm Travel range, Z-axis: 50 mm Travel range, Z-axis: ±50 mm, relative to the central axis of the rotary indexing table / 200 mm Travel speed, X-axis: max. 30 m/min Travel speed, Y-axis: max. 20 m/min Travel speed, Z-axis: max. 30 m/min Acceleration, X/Y/Z-axis: 10 m/s² MACHINE DETAILS Control model: ANDRONIC 2060 Dimensions & Weight Dimensions (L x W x H): 2,500 x 1,650 x 2,700 mm Total weight: 6,000 kg Lsdpfx Aezu Iwwoa Rerr Operating voltage: 230/400 V Frequency: 50 Hz Rated apparent power: 12 kVA Swivel radius, control panel: approx. 1,050 mm

Condition: used, Year of construction: 2001, - X = 2 x 2,400 - Y = 1,800 mm - Main spindle 12 kW - 18-position tool changer - Gluing unit with 6-position coil magazine Used CNC machining center Manufacturer: IMA Type: BIMA P 480 V, 180/480 Year of manufacture: 2001 Alternative processing: - X = 2 x 2,400 - Y = 1,800 mm - Main spindle 12 kW - 18-position tool changer - Gluing unit with 6-position coil magazine Working area: For standard machines, Y = 1,800 mm Changing table area for alternating machining: X = 2 x 2,400 mm / Milling and drilling X = 2 x 2,100 mm / Gluing CNC line control IMATRONIC NT 231 Automatic adjustment table with clamping plates Main spindle 12 kW With integrated C-axis, 360 degrees Automatic tool/adapter unit changer, 18-position 1 edge banding unit VT100 With glue application device Edge thickness: 0.4 - 3 mm For 4-sided edge banding and all-round edge banding with butt joint 6-position roller magazine 1 trimming unit 0.8 kW Including adapter unit - Saw, fixed at 90 degrees - Horizontal milling unit (corner release) - Chamfer milling unit - Straight milling unit - Profile drawing blade Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding. Lredszux Uaepfx Aa Rjr

Condition: used, Year of construction: 2003, - Workpiece length: 800 - 3000 mm - Workpiece width: 350 - 1400 mm - Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling - Main spindle 12 kW - Tool changer, 18-position CNC machining center Manufacturer: Homag Type: PROFI BAZ20/30/16/V/D Year of manufacture: 2003 Technical data Homatic - CNC control CNC programming system WOODWOP Postprocessor Workpiece dimensions - Workpiece length: 800 - 3000 mm - Workpiece width: 350 - 1400 mm - Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling - Edge band width: min. 120 mm - Weight: max. 150 kg Throughfeed table - Longitudinal console 1, fixed installation - Longitudinal console 2, manually adjustable via width adjustment in the Y-direction - 8 vacuum clamps 125 x 50 x 100 mm - Working height, bottom edge of workpiece: 950 mm Motor, width adjustment, longitudinal console, traversing table - For different workpiece widths via servo drive for throughfeed table - Per longitudinal console Chip conveyor - Chip and waste disposal via integrated chip conveyor under the longitudinal traverse Stop pins for top layer overhang - Stop pins with lifting-rotating mechanism for workpieces with max. 20 mm top layer overhang - Individually selectable, end position monitored, stroke 110 mm - For manual placement of doors Vacuum pump 100/140 m3/h Unit for positioning the vacuum clamps - Mounted on the unit carrier with pneumatic extension console - For max. 4 vacuum clamps per longitudinal console Main spindle 12 kW - Tool holder HSK F63 - Extraction system for all tools and units - Three-phase asynchronous motor 12 kW at S1, water-cooled - Tool weight: max 6 kg incl. holder - Tool length: max. 200 mm from the motor spindle bottom edge - Tool diameter: max. 180 mm for milling tools / max 200 mm for sanding tools - Frequency converter: 15 kW - Speed range: 1500 - 18000 rpm, stepless, programmable - Full rated power from 12000 rpm Unit interface for the main spindle - For connecting the machining units - Pneumatic and swivel drive interface - C-axis with torque transmission and 3-point support Tool changer, 18-position For tools and units with HSK F63 Tool weight: 6 kg Tool length: max. 200 mm from the motor spindle bottom edge The following tool and unit configurations are possible - 18 x max. 130 mm - 9 x max. 180 mm and 9 x max. 70 mm - Tool diameter max. 200 mm for sanding tools - Tool changer can be raised for a moving pick-up station on the left side Drilling/milling unit, 4 spindles, for tool changer - For automatic changing in the main spindle - Collet holder ER25 up to max. 16 mm shank diameter - Tool protrusion max. 50 mm - Speed: max. 13500 rpm - Standard collet 10 mm - Infinitely swiveling via the C-axis - Without tool Lock case milling unit, 2 spindles, D=16/20 - With integrated blow-out nozzle - Two-sided spindle outlet with counter-rotating direction - Speed: 12000 rpm - Infinitely swiveling via the C-axis - Without tool 1x Weldon chuck: 20 mm - Reducing sleeve for tool 16 mm - Total tool length: 180 mm - Tool protrusion: max. 135 mm 1x ER16 collet with 10 mm - Total tool length: max. 70 mm - Tool protrusion: max. 40 mm Sawing/drilling unit, swiveling, for tool changer Lrodpszux Tpsfx Aa Rjr - For miter cuts and angled drilling - Manually swiveling 0 - 90 degrees - Mounting flange 30 mm with countersunk head screws - Tool diameter 52 mm - Prepared for miter saw: max. 180 mm - Drill chuck with Weldon chuck: D=10 mm - Speed: max. 9000 rpm - Infinitely swiveling via the C-axis -
