Used Pro Richyoung Column Drilling Machine for sale (70,338)

Condition: new, Year of construction: 2024, functionality: fully functional, - FAGOR 3-axis position indicator, Mod.: 400iB INNOVA - Milling head +- 90° manually swiveling - Manual tool clamping using M 16 tightening screw for vertical and horizontal spindle - Swiveling control panel - Motor for horizontal and vertical spindle - Feed motors with inverter for X/Y/Z axis - Ball screw spindles in the X/Y/Z axes - Gearbox for 12 spindle speeds - Counterholder with support bearing - 1 long milling mandrel 27 mm - 3 reducing sleeves (MK1, MK2, MK3) - Spindle protection with safety switch - Splash protection on the 3 sides of the horizontal table - LED work light - Automatic lubrication for X/Y/Z guides - Mechanical handwheels for X/Y/Z axes - Coolant system - Cover for X/Z axes - Operating tool - Technical Documentation - CE version Colors: - RAL 7024 – graphite gray - RAL 7035 – light gray Technical data: Fixed angle table: - Dimensions of the work surface: 845 x 390 mm - T-slots: number / width x distance: 5 pcs. / 14 x 63 mm - Max. table load: 250 kg Vertical table: - Dimensions of the work surface: 950 x 250 mm - T-slots: number / width x distance: 3 pcs. / 14 x 63 mm Travel paths: - Axis travel paths: automatic/manual - Longitudinal (X): 420 mm - Transverse (Y): 220 mm - Vertical (Z): 380 mm Vertical milling head: Ijdpfjvt Tn Aex Aayotk - Tool holder: ISO 40 / DIN 2080 - Speed range: 65 - 2,600 rpm. - Number of spindle speeds: 12 (65 – 100 – 130 – 175 – 260 – 357 – 485 - 690 – 950 – 1,325 – 1,870 – 2,600) - Quill stroke, manual: 100 mm - Head swivel: +- 90° - Distance spindle nose/table: 90 - 470 mm - Distance spindle center to column - min./max.: 120 - 340 mm Horizontal spindle: - Tool holder: ISO 40 / DIN 2080 - Gear stages: 12 - Speed range: 65 - 2,600 rpm. - Distance spindle center / table: 100 - 480 mm Feeds: - Control: stepless - Range (X,Y,Z): 0 - 1,000 mm/min. - Rapid traverse (X,Y,Z axes): 1,000 mm/min. Motors: - Main drive power: 2.2 kW - Feed motor power (X-Y-Z): 0.35 kW - Coolant pump: 0.09 kW Dimensions and weight - Dimensions (W x D x H): 1,621 x 1,527 x 1,938 mm - Weight: 1,300 kg

Condition: new, Year of construction: 2024, - FAGOR 3-axis position indicator, Mod.: 400iB INNOVA - Milling head +- 90° manually swiveling - Manual tool clamping using M 16 tightening screw for vertical and horizontal spindle - Swiveling control panel - Motor for horizontal and vertical spindle - Feed motors with inverter for X/Y/Z axis - Ball screw spindles in the X/Y/Z axes - Gearbox for 18 spindle speeds - Counterholder with support bearing - 1 long milling mandrel 27 mm - 3 reducing sleeves (MK1, MK2, MK3) - Spindle protection with safety switch - Splash protection on the 3 sides of the horizontal table - LED work light - Automatic lubrication for X/Y/Z guides - Mechanical handwheels for X/Y/Z axes - Coolant system - Cover for X/Z axes - Operating tool - Technical Documentation - CE version Colors: - RAL 7024 – graphite gray - RAL 7035 – light gray Technical data: Fixed angle table: - Dimensions of the work surface: 1,000 x 540 mm - T-slots: Number / width x distance: 8 pcs. / 14 x 63 mm - Max. table load: 300 kg Vertical table: - Dimensions of the work surface: 1,200 x 250 mm - T-slots: Number / width x distance: 8 pcs. / 14 x 63 mm Travel paths: - Axis travel paths: automatic/manual - Longitudinal (X): 600 mm Ijdevunrfjpfx Aayjtk - Transverse (Y): 500 mm - Vertical (Z): 400 mm Vertical milling head: - Tool holder: ISO 40 / DIN 2080 - Speed range: 40 - 3,200 rpm. - Number of spindle speeds: 18 (40 - 65 – 83 – 100 - 130 – 160 – 200 – 250 - 400 - 330 520 – 650 – 820 – 1,020 – 1,280 – 1,600 – 2,000 – 3,200) - Quill stroke, manual: 100 mm - Head swivel: +- 90° - Distance spindle nose/table: 70 - 470 mm - Distance spindle center to column - min./max.: 160 / 660 mm Horizontal spindle: - Tool holder: ISO 40 / DIN 2080 - Gear stages: 18 - Speed range: 40 - 3,200 rpm. - Distance from spindle center / to 2nd T-slot: 95 - 495 mm - Distance from spindle center / to 3rd T-slot: 180 - 580 mm Feeds: - Control: stepless - Range (X,Y,Z): 0 - 600 mm/min. - Rapid traverse (X,Y,Z axes): 600 mm/min. Motors: - Main drive power: 3.75 kW - Feed motor power (X-Y-Z): 0.35 kW - Coolant pump: 0.09 kW Dimensions and weight - Dimensions (W x D x H): 1,881 x 1,813 x 1,916 mm - Weight: 1,600 kg

Condition: new, functionality: fully functional, Year of construction: 2025, laser power: 30,000 W, travel distance X-axis: 3,050 mm, travel distance Y-axis: 13,050 mm, travel distance Z-axis: 450 mm, positioning accuracy: 0.03 mm, repeat accuracy: 0.02 mm, workpiece weight (max.): 2,000 kg, input voltage: 380 V, input frequency: 50 Hz, total length: 16,800 mm, total width: 2,200 mm, total height: 5,120 mm, warranty duration: 24 months, working range: 13,000 mm, Equipment: cooling unit, All New Full Cover Fiber Laser Cutting Machine | GS-CE PRO Series | 6000-40000W MACHINE AVAILABLE ON HAND This GS-CE series FULL COVER FIBER LASER CUTTING MACHINE offers maximum safety for metals cutting. Thanks to its full cover structure and protective glass observation window, you can observe the operation and avoid hazards such as laser radiation, sparks, etc. It also has a fast exchange table, and the exchange is within 10s. It will be your ideal solution for safe and efficient metal cutting! Working platform size: 4000mm*2000mm Laser power 6KW-40KW GS-4020CE PRO Intelligent anti-collision function Automatic lubrication Laser fault alarm Cooling fault alarm Laser protection glass Water cooler TÜV CE certificate Optional function: automatic loading and unloading system Isdpfev Hnl Asx Aaystk Control unit supports graphic formats: AI, BMP, Dst, Dwg, DXF, DXP External programming System complete incl. cooler, extraction system and safety light barriers

Condition: new, functionality: fully functional, Year of construction: 2025, control type: CNC control, laser type: fiber laser, laser power: 3,000 W, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Type: Two chucks Groove function: Standard Power range: 3KW, 6KW Round tube processing range: 10mm~160mm Itsdpfx Aaewwz Dloysk Square tube processing range: 10mm~160mm Chuck maximum speed: 130r/min Machine weight: 3T Power specification: 380VAC, 50Hz Optional loading rack: G16pro-automatic loading, G16pro-semi-automatic loading Optional unloading rack: servo unloading rack, cylinder unloading rack Standard: System 3000DE-DH, including nesting, supports servo, dustproof (Y axis), dustproof (X axis), dustproof (Z axis), rear card hollow dust removal, short tail material Optional: safety fence (light curtain), radiation-proof glass

Condition: new, Year of construction: 2026, functionality: fully functional, power: 22 kW (29.91 HP), input voltage: 400 V, input current: 30 A, input frequency: 50 Hz, type of input current: three-phase, pressing force: 315 t, stroke length: 800 mm, operating speed: 120 mm/s, reverse speed: 100 mm/s, table width: 1,160 mm, table length: 1,260 mm, table height: 600 mm, ram plate width: 1,160 mm, ram plate length: 1,260 mm, distance table to ram: 1,250 mm, clearance between the columns: 1,160 mm, retraction force: 30 t, oil tank capacity: 510 l, total length: 2,000 mm, total width: 1,250 mm, total height: 3,500 mm, overall weight: 13,000 kg, Equipment: CE marking, documentation/manual, safety light barrier, YQ32-315T Hydraulic Press This series of presses are general-purpose hydraulic presses, widely used in machinery manufacturing, automotive, motor, electrical appliance, light industry and other industries. They are suitable for metal processing procedures including drawing, bending, flanging, cold extrusion and blanking. The machines also perform straightening, press fitting, as well as compression molding of powder products, abrasive products, plastic products and insulating materials. Iodpfx Aoy Uiyveayjtk The working pressure, pressing speed and stroke can all be adjusted within the specified parameter range according to process requirements. Equipped with an independent power unit and electrical control system, the press adopts centralized push-button control and supports three operation modes: manual, semi-automatic and automatic. It is available with two pressing modes: pressure setting and stroke setting. Operation Sequence: Motor start → Main cylinder piston rapid no-load downstroke → Low-speed pressurization → Pressure holding (holding time adjustable) → Pressure relief → Slide return stroke → Work stop → Total stop Mainframe The mainframe adopts a vertical three-beam four-column structure, consisting of an upper beam, a slide, and a lower beam connected by four columns, which are fastened with nuts to form a closed rigid frame. All major structural components of the mainframe are fabricated from welded steel plates using CO₂ gas shielded welding. After welding, the entire frame undergoes vibration stress relief to eliminate internal residual stresses. Key components are machined on advanced equipment such as gantry milling machines, large floor-type boring and milling machines, and large precision lathes, ensuring high overall accuracy of the machine. The mainframe is pre-tensioned using hydraulic nuts. The slide is connected to the piston rod of the main cylinder and moves up and down guided by the columns. T-slots are provided on the lower surface of the slide and the upper surface of the movable worktable for die mounting. The columns are made of high-quality 45 carbon steel with hard chrome plating on the surface; the column guide sleeves are made of composite material, offering excellent wear resistance and self-lubricating properties.

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: COMBO (Plasma, Drilling, OXY-Fuel, Bevel), Equipment: CE marking, documentation/manual, * COMBO offers customers the most innovative technological solutions and features a wide range of models. * It is a highly advanced machine equipped with a 6- and 12-station automatic tool changer ISO 40 drilling system, offering capabilities such as drilling, tapping, countersinking, plasma cutting, OXY cutting, and ±45° bevel cutting. * The COMBO has a working range from 1,500 mm x 3,000 mm up to 4,000 mm x 24,000 mm and can be equipped with high-capacity plasma power sources. * Plasma Cutting * Drilling * Tapping * Countersinking * OXY-Fuel Cutting * Fully welded, heavy-duty machine frame. * High-durability cutting table designed for easy replacement. * Dual drive system with linear rails, rack and pinion. Itjdpoyy Rn Sjfx Aayjk * Compliance with CE standards. ISO 40 Drilling System * 6-station automatic tool changer (optional 12-station). * CNC-controlled automatic coolant spraying system during cutting. * 26 kW spindle motor power. * Drilling capacity: Ø M5 to Ø M40 (HSS, UDRILL). * Drilling depth: 100 mm * Drilling speed: 0.15 – 0.35 mm/rev. * Spindle speed: 1,500 rpm * Hypertherm / Thermal Dynamics power sources. * Hypertherm / Eurosoft CNC controls. * Possibility to import .dxf and .dwg files via Pronest / Cut-Expert CAD-CAM.

Condition: ready for operation (used), Year of construction: 1965, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,150 mm, spindle speed (max.): 6,000 rpm, table load: 6,000 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 1,600 mm Iedpfx Aaszuzpasyetk Travel range, Y-axis: 1,200 mm Travel range, Z-axis: 1,150 mm Spindle speed: 20–6,000 rpm Work table: 1,200 × 1,400 mm Table load: max. 6 t Please note the following: The height and weight of the asset must be taken into account when selecting the transport vehicle. There is no loading dock on site. However, a forklift or an overhead crane is available for loading. If the asset is not collected on time, a storage fee of €20.00 per lot and per day (or part thereof) will be charged. The fee must be paid before collection. The sale is made without any warranty or guarantee. The information on the technical data is based on the original offer. No liability is accepted for typographical or measurement errors. In case of doubt, please compare the information with the provided photos or inspect the item on site before the auction ends.

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Ijdpfx Aaowuz Ekjyjtk Total number of drilling spindles: 16 Total number of tool changer positions: 16

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm Iododkx Anspfx Aaystk - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm Isdov S Iqcopfx Aayjtk total power requirement 4 kW

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree Itodpfx Aertrx Reayek B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: good (used), *FOR SALE: Cincinnati Milacron PTC 40 Column Drill – 1982* *Price:* €2,200 – Negotiable *Location:* Les Ponts-de-Cé, 49130, Pays de la Loire *Description:* Industrial column drill *CINCINNATI MILACRON PTC 40*, manufactured in 1982. French made. Very robust machine for drilling and tapping in mechanical and sheet metal workshops. Column with cross table mounted on slides. Remote control + foot pedal. Complete and fully operational machine. *Specifications:* Iodpfxezvgr Ao Aayetk - *Make / Model*: CINCINNATI MILACRON PTC 40 380V - *Year*: 1982 - Serial No. 45117 - *Type*: Column drill on a base - *Table*: Cross table mounted on slides - *Feed*: Spindle descent via handwheel + lever - *Equipment*: Remote electrical cabinet, Foot pedal, Vises - *Mounting*: On a pallet for removal

Condition: good (used), Year of construction: 2007, *Description:* Industrial column drill press *CINCINNATI CA NC320V*, year 2007. Made in France. High-end machine for precision drilling in a mechanical workshop. Column-mounted spindle with mechanical speed variation in 2 ranges. Cross table + vise included. Complete machine, available for inspection. *Specifications:* - *Make / Model*: CINCINNATI CA NC 320V 380 - *Year*: 2007 - Serial number 320838 Ijdozvgn Rjpfx Aayjtk - *Speeds*: 2-range variable speed: 80-625 rpm and 385-3000 rpm - *Spindle*: CM3 or CM4 taper, to be confirmed - *Table*: Cross table + vise, as shown in the photo - *Column*: Column with rack and pinion for motorized up/down movement - *Equipment*: Emergency stop, speed chart *Condition*: Very good condition. Recent and robust machine. On a pallet for removal. Testing possible on site. Removal by carrier.

Condition: good (used), functionality: fully functional, drilling depth: 600 mm, workpiece weight (max.): 2,000 kg, travel distance X-axis: 750 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 3,000 rpm, drill diameter: 35 mm, drill spindle length: 600 mm, spindle mount: MK 2, spindle stroke: 600 mm, number of spindles: 1, Equipment: rotational speed infinitely variable, Driling capacity: Ø 35 mm Driling depth: 600 mm X-axis: 750 mm Y-axis: 630 mm Z-axis: 300 mm Spindle speeds: 0 - 3000 rpm Tabel size: 1100 x 650 mm Load on table: 2000 kg max Turning table: 360° Controller: Degen AE30 Including: - Cabinet + pallet with drills - Coolingunit Itsdpfozu Sp Rjx Aayjk - Machine manuals Country of origin: Germany Motor power: 11,2 kVA Machine LxWxH: 350 x 120 x 175 cm Machine weight: 1300 kg

Condition: excellent (used), Year of construction: 1994, tool diameter: 60 mm, spindle mount: MK 5, rotational speed (max.): 1,460 rpm, total width: 1,100 mm, total length: 2,300 mm, total height: 2,400 mm, table width: 580 mm, table length: 1,400 mm, overall weight: 2,700 kg, Arm length: 1200 mm Iedpezvfn Njfx Aayotk Max. drilling diameter in cast iron: 60 mm Max. tapping diameter: 40M Max. drilling diameter in steel: 50 mm Stroke of quill: 110 mm Max. distance spindle to table: 1165 mm Min. distance spindle to table: 300 mm Floor/table area: 1400 x 580 mm Speeds/ranges: 1460 rpm Spindle taper: 5ISO/BT/MK Length: 2300 mm Width: 1100 mm Height: 2400 mm Weight: 2700 kg

Condition: used, Year of construction: 1994, bore capacity in steel (diameter) 35 mm throat 300 mm bore stroke 180 mm turning speeds 55 - 1450 U/min taper MK 4 column diameter 145 mm total power requirement 2,2 kW weight 500 kg dimensions 800 x 1000 x 2000 mm Features: - Heavy-duty pillar drill - Infinitely variable speed control (V-belt) - Automatic spindle feed * with electromagnetic engagement - Pole-changing motor - Right/left rotation of the drill spindle - Fixed drilling depth stop - Machine table with 2 T-slots * height-adjustable via hand crank - Coolant system - Machine vise Ijdpszu Tk Njfx Aayotk - Drill chuck - Emergency stop

Condition: new, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 2,000 mm, position of the milling head: Universal-Diagonal-Fräskopf, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, spindle speed (max.): 6,000 rpm, pivoting range: 1 °, table length: 7,500 mm, table width: 1,100 mm, torque: 1,178 Nm, table load: 42,000 kg, coolant supply: 36 bar, spindle motor power: 53 W, Equipment: rotational speed infinitely variable, LAGUN CM 6 – available for immediate delivery The LAGUN CM 6 is a powerful traveling column milling machine for the precise machining of long and bulky workpieces with the highest demands on accuracy, stability and flexibility. Itedjvrv Suspfx Aayek Its advantages: ✔ Delivery and commissioning by JMT technicians included ✔ Original spare parts available directly from stock ✔ Technical support and on-site service in Germany ✔ Training and instruction of operating personnel included ✔ Financing and lease purchase options available upon request ✔ 24 months warranty Technical equipment: Control system: ✔ Two HEIDENHAIN TNC 7 digital path controls – one on the front of the machine and one at the rear in the cabin ✔ Two HEIDENHAIN TFT screens 24" ✔ HEIDENHAIN motors, measuring systems and electronic handwheel HR-510 Cooling: Internal coolant supply (IKZ) 36 bar Tool changer: Automatic tool changer (ATC), 60-position Chip disposal: Hinged belt conveyor Preparation: Preparation for rotary table / 4th axis Enclosure: Three-sided perimeter enclosure Accuracy: Positioning accuracy: ±0.040 mm Repeatability: ±0.008 mm Contact us – we will be happy to advise you and prepare a customized offer for you.

Condition: new, 6-sided drilling machine Manufacturer: Quick Type: KQ-63E New machine Technical data: - Workpiece length: 70 - 2800 mm - Workpiece width: 50 - 1220 mm - Workpiece thickness: 9 - 60 mm - Min. workpiece to be processed: 70 x 50 mm - Feed rate in X: 135 m/min - Feed rate in Y: 90 m/min - Feed rate in Z: 25 m/min - Individually controllable spindles: Top: 2 x 12 vertical, 4 horizontal / Bottom: 1 x 7 vertical - Machine control: Higerman (German) - Milling spindle (top): 9 kW, 24000 rpm - Tool changer (top): 5-position - Milling spindle (bottom): 3.5 kW, 18000 rpm - Motors: Brushless servo motors - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 Optional: Itsdpfx Aajzvgn Dsysk - Machine with workpiece return Quickly found Offer machines Register for newsletter Unsubscribe from newsletter Contact us Overview

Condition: new, Six-sided drilling machine Manufacturer: Quick Type: KQ-62Lite New machine Technical data: - Workpiece length: 70 - 2,400 mm - Workpiece thickness: 9 - 60 mm - Workpiece width: 30 - 1,220 mm - Min. processing size: 50 x 70 mm - Transport speed in X: 138 m/min - Transport speed in Y: 90 m/min - Transport speed in Z: 28 m/min - Machine control: Higerman - Working height: 890 mm - Milling spindle: 2 x 3.5 kW, 18,000 RPM, manual tool change Itedpfx Aajzvgndeyek - Drilling unit: Top 9 vertical and 4 horizontal / Bottom 7 vertical - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 - Power consumption: 25.8 kW Optional - Machine including workpiece return Other configurations available upon request.

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. Ijdpfszvduusx Aaystk 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm - Feed rate: 25 m/min - Spindle speed: 3600 RPM - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting - CE compliant Optional against additional charge

Condition: ready for operation (used), Year of construction: 1960, Available immediately ex-works: Bench drilling machine, Scharmann Type FB 125 b Year of manufacture 1960 Complete retrofit in 2010 Spindle 125 mm Metric 80 / SK 50 spindle mount Quill stroke 800 mm Table 1600 x 1200 mm Table traverse 2000 mm Spindle / table installation height 1400 mm Table longitudinal travel 2500 mm Spindle speeds 5 – 740 rpm, 7.5 – 1100 rpm For Wohlhaupter machining: 5 – 74 rpm 3-axis Heidenhain digital display Itjdozu I Euepfx Aaysk Vertical head Large Wohlhaupter boring head Various other accessories Weight 21 tons Price: EUR 9,500.00 plus VAT, ex-works.

Condition: like new (used), Year of construction: 2011, machine/vehicle number: MA10110002, functionality: fully functional, SPECIFICATION Drilling capacity in mild steel 18mm Motor 0.45kW 415 volt Spindle 2MT Drive Belt, stepped pulleys Spindle speeds rpm 50Hz 400-700-1200-2100-3600 Spindle travel 75mm Throat depth 185mm Column diameter 70mm Table -working surface 250 x 164mm Table – slots width & centres 13 x 125mm Base – overall 240 x 360mm Max. distance chuck to table 330mm Overall height 865mm Overall width 280mm Overall depth 600mm Iedpfozmuntox Aayotk Approx. Nett weight 77Kg Machine equipped with Chuck guard Table adjustment by rack Drill chuck

Condition: good (used), Year of construction: 1980, functionality: fully functional, Gear-driven drill press, no belt changes required Very quiet and smooth operation - Drilling capacity in steel ST 60: 30 mm - Drill spindle mount: MK 3 - Drill spindle stroke: 160 mm - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots - Table dimensions, swiveling: 500 x 450 mm - Table dimensions, base plate: 350 x 400 mm - Distance from base plate to spindle nose: 1100 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Column diameter: 120 mm Iedpfszuxxfjx Aayetk - Drive: 380 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 670 mm - Weight: approx. 350 kg - Includes drill chuck

Condition: used, Year of construction: 2014, Used Machine Year of manufacture: 2014 Condition: The machine has been factory-overhauled by Ganner Features and Technical Specifications: Complete standard configuration including: - Support with linear guide consisting of: 1 single-spindle horizontal drilling unit, 0.65 kW motor, 70 mm stroke Tool speed selectable via operator software (3000/5000/8000 rpm) 1 blow-out, gluing, and dowel-driving station for dowels Ø 8 mm, dowel length 25–50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC-controlled, with working length 1300 mm, travel speed max. 105 m/min. - Z-axis manually adjustable via mechanical digital counter, position adjustable via support table 5–40 mm - Dowel drive-in overhang adjustable from 7–20 mm via a mechanical digital counter; drilling depth from 0–35 mm (for drill bit length GL 70 mm) is automatically adjusted with the drive-in overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GLUE/WATER selector switch for flushing the glue system, each with: 1 stainless steel tank for 7.5 kg of glue and 7.5 l of water - Indicator light showing remaining glue levels in the glue tank - 1 left side stop, 1 right side stop, and 1 center stop (all removable) - 4 start buttons for individual processing of 1–4 workpieces - 4 pneumatic 10° angle clamping cylinders for workpiece thicknesses up to 80 mm, workpiece length (Y) min. 70 mm - 1 extraction funnel, connection Ø 80 mm - 1 TCT control unit with: Built-in industrial PC, including Beckhoff TWINCAT soft PLC, operating temperature range 0–50°C, 15-inch capacitive TFT industrial touchscreen, operating system: WINDOWS 7 - Programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensions, automatic workpiece mirroring and operation optimization, 4 work areas assignable to different programs, graphical workpiece display, parametric programming, zero-point offset, programmable worklists, error diagnosis with plain text Optional equipment: - 1 electronic, optical glue monitoring system G.I.C. Itjdpfx Aezlbrvjayek (Glue Insert Control) for 1 glue nozzle - 1 Z-axis with NC-controlled, dynamic positioning for height adjustment of the drilling and dowel-driving station (programmable from 5–40 mm), travel speed max. 30 mm/sec. - 1 single-spindle vertical drilling unit drilling from the TOP, 0.65 kW, (3000/5000/8000 rpm), position (Y) manually adjustable via a mechanical digital counter from 5–40 mm, drilling depth (Z) max. 30 mm (with drill bit length GL 57 mm), Workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (including drilling depth compensation, e.g., for Häfele Minifix) - 4 vertical 10° angle clamping cylinders with mount - 1 keypad with mount Availability: available shortly Location: DE-63934 Röllbach

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm weight of the machine ca.: 500 kg dimension machine approx.LxWxH: 0,73 x 0,56 x 0,22 m · Heavy, solid cast construction · Automatic gear lubrication via oil pump · Smooth running due to ground gearbox gears operating in an oil bath · High concentricity thanks to hardened and ground main spindle · Thread cutting device · Lockable main switch and motor protection switch · Optidrill B 40GSM additionally with automatic quill feed · Electric Iedpfx Ajyli Sfoayotk · 2 feed rates: 0.1 / 0.2 mm/rev · Coolant system · Drilling depth stop · 18 speeds: 50 – 1,450 rpm · 9 selectable speeds via gearbox lever on the front of the drill head *
