Used Star Micronics Cnc Automatic Lathe for sale (30,143)

Condition: new, Year of construction: 2022, functionality: fully functional, TAKAMAZ CNC Compact loader FC60 Lathe with automatic loader unloader quickest loading system in the world loading time new part 2,8 sec. loading cap. till 60 mm diameter. loading lenght max 50 mm max weight 1 kg per side loading feed 120 m min include part turning for loading Bwodpfxom E I D He Ad Aol Fanuc Control full warranty 2 year Lathe spec. Spindle motor 7,5/5,5 kw turning diameter max 180 mm turning lenght 240 mm bar cap. 35 mm collet chuck 173E till 40 mm diameter spindle nose A2-5 spindle speed 4500 rpm tool pos 8 stations tool shank 20x20 mm boring holder 25 mm diameter rapid speed X/Z 18/24 meter machine dimension 1,36 x 1,37 meter height 1,7 meter weight 2,7 ton total power 14 KVA Price is EXW (Stock Europe), Include loaded on truck. Transport, installation, commissioning, training, and yearly service contracts are available upon request for an additional fee. Installation and training is always done by our high qualified Service team in 3 locations in Europe. Netherlands, Germany, Romania.

Condition: used, Year of construction: 2006, functionality: fully functional, Operating voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Power: 14 kVA Rated current: 20 A Travel (axis stroke): X1: 170 mm Bwedpfx Ajy Ipyijd Aol Z1: 200 mm X2: 110 mm Z2: 395 mm X3: 110 mm Z3: 170 mm Y: +/-40 mm Rapid traverse speed: X1: 24 m/min Z1: 24 m/min X2: 18 m/min Z2: 24 m/min X3: 20 m/min Z3: 24 m/min Y: 12 m/min Max. tool shank diameter with driven tool holder: Drill shank or tap: diameter 7 mm, diameter 10 mm, diameter 13 mm, diameter 63 x diameter 16 mm for slot cutters. Max. thread cutting diameter with driven tool: M10 Tool spindle speed: 45 - 4500 rpm Max. clamping diameter of the sub-spindle: 42 mm Max. workpiece length for front machining in the sub-spindle: 120 mm Max. workpiece overhang from the sub-spindle: 80 mm Max. axial thread cutting diameter, rear machining: 12 mm diameter Max. thread cutting diameter, rear machining: M10 Sub-spindle speed: 60 - 6000 rpm Sub-spindle speed feed rate: stepless Sub-spindle C-axis accuracy: 0.001° Sub-spindle indexing angle: 15° Number of tool holders per turret: 12 pcs Number of turret divisions: 36 All turret stations are driven Tool size: 16 x 16 x 90 mm Tool holder: VDI 20 Max. machining diameter: 42 mm / 140 mm Min. material diameter: 10 mm Max. machining length: 75–120 mm depending on workpiece shape Max. diameter of axial bore: 16 mm Max. diameter of axial threading: M12 Spindle through-hole diameter: 43 mm Main spindle speed: 80–8000 rpm Main spindle accuracy: C-axis: 0.001° Max. drilling diameter with driven tool: 10.5 mm. In addition to the C-axis, there is a 15° tilt, programmed via the S-axis. The machine is equipped with a KNOLL chip conveyor and an FMB TURBO 5-55 bar feeder. It is also supplied with numerous VDI 20 tool holders, including approx. 10 driven tool holders.

Condition: excellent (used), Year of construction: 2015, CNC Lathe Brand: Spinner Model: TC 600-65-SMCY Year of manufacture: 2015 Bodpjy Iywxefx Ad Aewl Machine number: AT0805 Operating hours: Distance between centers: 650 mm Center height: 300 mm Swing diameter over bed: 600 mm Swing diameter over cross slide: 400 mm Bar capacity: 65 mm Chuck bore: 66 mm Control: Siemens 840D SolutionLine Speed range: up to 6,000 rpm Equipment: Star turret 16 driven tools C-axis for both spindles Y-axis +50 / -40 mm Extraction unit Connection: approx. 50 kW Dimensions: mm Weight: 5.7 t Condition: very good

Condition: excellent (used), Year of construction: 2015, Control MITSUBISHI M 700 Bar passage 37.5 mm 2 x 12-position turrets with driven tools Bwodjy I Diljpfx Ad Asl 2 x C-axis 2 x Y-axis Main / sub-spindle FMB bar loading magazine turbo 3-36 Knoll coolant filtration system KF 10 Chip conveyor Renishaw measuring probe Parts catcher Conveyor belt for finished parts Air filter 2 x collet chucks Tool holders and collets

Condition: used, Year of construction: 2000, Turret 1 - facing/length turning 155/280 mm Turret 2 - facing/length turning 82/120 mm Spindle bore (main spindle) 79 mm ((w/collet chuck 65 mm) Spindle bore (sub spindele 65 mm (w/collet chuck 42 mm) Spindle speeds (25-5000 rpm (main spindle) C-axis - 5000 rpm. Turret w/8 stations Bsdpfoy Hppzjx Ad Aewl Control: Siemens Sinumerik 840 C Equipped with: Magazine bar feeder Manuf. Simag model 65.1 - 3200 mm - built 2000 Chip conveyor Various tool holders

Condition: used, Technical details: turning diameter over bed: 830 mm turning dia. over face-slide: 540 mm turning length: 3000 mm turning diameter over support: 540 mm centre distance: 3000 mm faceplate diameter: 800 mm Rapid feed X axis: 4 m/min. control: MTC K (Monforts) range of revolution per miute: 2 -1.600 U/min spindle passage: 88 mm tailstock taper ISO: MK6 tailstock quill stroke: 200 mm max. workpiece weight between centers: 1250 kg max. workpiece weight -without tailstock: 3000 kg turning dia. in gap: 1.200 mm length of gap: 310 mm Weight approx.: ca. 6.85 (ohne Späneförderer und Kühlmittelbehälter) t dimension machine xH: 2,55 x 1,1 x 1,29 m Cycle lathe Machine overhauled in 2010 Operation via control panel Thread cutting by calculation Interpolator of NC control Chip conveyor manufacturer Cable drag Three-jaw chuck D=500mm without clamping jaws Various accessories * Bwjdowmlknjpfx Ad Ajl

Condition: good (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 93200, turning length: 500 mm, turning diameter: 270 mm, spindle bore: 70 mm, spindle speed (max.): 3,600 rpm, spindle speed (min.): 36 rpm, travel distance X-axis: 180 mm, travel distance Z-axis: 510 mm, overall weight: 4,200 kg, Working length 500 mm Max. working diameter 270 mm Bjdpfx Asy Ibiped Aswl Swing over bed 440 mm Spindle speeds 36 - 3600 rpm Spindle bore 70 mm Number of tools 8 pcs X-axis travel 180 mm Z-axis travel 510 mm Control MAZATROL T - 32

Condition: excellent (used), Year of construction: 2008, TECHNICAL DATA Clamping units Collet machine with main and sub spindle: 26 mm Max. turning length with workpiece gripper: 67 mm Maximum part length: Max. 300 mm / Ø 26 Bsdpfx Adewqz Haj Aowl Clamping cylinder L/R spindle: stationary Max. drilling diameter L/R spindle: Ø 12.00 mm Max. thread diameter L/R spindle: M8 Spindle Motor power: VAC 2.2/3.7 kW Speed range L/R spindle: 80 ~ 8,000 rpm L spindle travel Z1-axis: 70.00 mm R spindle travel X2-axis: 180.00 mm R spindle travel Z2-axis: 238.00 mm Tool slide Tool slide: Vertical linear slide Number of tool positions: 16.00 Number of tool positions slide 1: 6/4 Tool shank size: 16.00 mm Internal holder tool: Ø 20.00 mm Travel X1-axis: 135.00 mm Travel Y1-axis: 260.00 mm Number of turning tools (L-spindle) X-/Y-unit: 2/2 (Use for L/R spindle) Z-unit: 2+2 Speed range: 100 ~ 4,000 rpm Turning tool motor: 0.5 kW / 0.5 kW Powered tools max. drill: 8.00 mm Turning tool motor max. drilling diameter: M6 Tool slide 2 Tool slide: Vertical linear slide Number of tool positions: 7.00 Number of tool positions slide 2: 3/4 Tool shank size: 16.00 mm Internal holder tool: Ø 20.00 mm Travel Y2-axis: 215.00 mm Machine dimensions Machine height: 1,670.00 mm Floor space (WxD): 2,320 mm×1,335 mm Machine weight: 3,000.00 kg SCOPE OF SUPPLY Among others: (list not exhaustive): Miyano BX-26S CNC lathe (year of manufacture: 2008) Tool holder (see photo of machine interior) Fire extinguishing system Control for high frequency spindle High frequency spindle Chip conveyor Oil mist separator Exact scope of supply as per photo series No guarantee is given for the correctness, completeness and up-to-dateness of the information.

Condition: good (used), Year of construction: 2008, Colchester Harrison Alpha 1400U CNC lathe Footprint: 1.7 x 3.1 m Height: Approx. 1500 mm Weight: 3200 kg Equipment: Electrically interlocked chuck guard, full safety guard, coolant tank and pump 100 l, fully extendable chip tray, machine lighting Machining length: 1250 mm Turning diameter: 400 mm Center distance: 1250 mm Spindle bore: 54 mm Turret, number of tools: 8 Tool size: Standard: 20 x 20 mm Bwsdpfsrnkdyox Ad Aol Boring bar: 32 mm No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: excellent (used), Year of construction: 2009, turning height: 1,280 mm, total height: 5,600 mm, total width: 3,850 mm, total length: 4,260 mm, rotary table diameter: 1,400 mm, workpiece diameter (max.): 1,600 mm, overall weight: 21,500 kg, CNC Vertical lathe Fremtas - 16FR3 MACH-ID 9467 Make: Fremtas Type: 16FR3 Control: FAGOR 8055 TC Year: 2009 Work load 6300 Kg Cross rail adjustment 660 mm Feed rate cross rail 0 - 400 mm/Min Feed rate 0 - 3000 mm/Min Rapid feed 0 - 8000 mm/Min Central lubrication Chip conveyor RAM with Sandvik COROMONT C8 Tooling C8 with double connector Ca 10 units CAPTO Tool system 4 extra heavy duty jaws Max. turning Ø: 1600mm Table Ø: 1400mm Bwsdpfxey Htils Ad Ajl Horizontal movement support:1000mm Speeds / ranges: 1 - 200Rpm Power: 75kW Maximum turning height: 1280mm Vertical movement support: 700mm Length: 4260mm Width: 3850mm Height: 5600mm Weight: 21500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2007, functionality: fully functional, Control: SIEMENS 840D PL ManualTurn turning diameter: 1.140 mm turning lenght: 4.200 mm turning diameter over slide: 800 mm faceplate diameter max.: 1.000 mm Support Length of the bed slide: 1.000 mm Bwjdjy Ifd Dspfx Ad Aol Travel of the cross slide: 650 mm Width of the cross slide: 425 mm bed width: 710 mm Main Spindle spindle bore: 120 mm spindle diameter in front bearing: 190 mm Accessories 1 piece fix steady rest 10 pieces Multifix quick-change steel holder Typ D The machine has been general overhauled in 2007.

Condition: used, Year of construction: 2006, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Bwsdjy Ifaxopfx Ad Ael Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600

Condition: used, Year of construction: 1998, functionality: fully functional, turning diameter over cross slide: 250 mm, turning length: 500 mm, turning diameter: 250 mm, spindle bore: 71 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 215 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, total height: 1,800 mm, total length: 4,000 mm, total width: 1,900 mm, overall weight: 5,000 kg, CNC Fanuc 18i - T CAPACITY: Max bar working diameter: mm 54 Max turning diameter (re-chucking): mm 250 Max turning length: mm 500 Max swing diameter: mm 520 MAIN SPINDLE: Speed range: rpm 40 – 4,000 Spindle nose: ASA 6’’ Spindle bore: mm 80 Chuck diameter: mm 250 Motor power: kW 11/15 (50%) SUB-SPINDLE: Speed range: rpm 40 – 4,000 Spindle nose: ASA 5’’ Spindle bore: mm 52 Chuck diameter: mm 165 Motor power: kW 5.5/7.5 (50%) BI-DIRECTIONAL TURRET: Number of stations: 12 Indexing time: sec 0.6 LIVE TOOLS: Number of stations: 6 Speed range: rpm 50 – 3,000 Motor power: kW 3.7 (50%) C AXIS: Type: CS (direct) Minimum programmable increment: 0.001° Max rapid speed: rpm 80 AXES: X axis travel: mm 210 + 5 Z axis travel: mm 500 + 10 B axis travel: mm 510 + 5 Rapid traverse X: m/min 20 Rapid traverse Z: m/min 20 Bsdpey I A Imsfx Ad Ajwl Rapid traverse B: m/min 24 COOLANT: Tank capacity: L 200 Pump flow rate: L/min 100 DIMENSIONS: Overall dimensions with chip conveyor: mm 4,000x1,900x1,800 h Weight with chip conveyor: kg 5,000 Machine equipped with: • Drilling kit with B-axis sub-spindle operating simultaneously with turning • 9 bar pump • Part catcher L 150 mm • Monitoring system • Spindle bore mm 71 • Collet holder, simple cone 42 • Chuck diameter mm 165 • Instruction manuals and CE declaration

Condition: excellent (used), Year of construction: 2006, Doosan Puma 700L Turning Centre with Fanuc Series 21i-TB CNC Control, 600mm Diameter Powered 3 Jaw Chuck, Bsdpfx Adey Akdlj Ajwl 3000mm Between Centres, Swing 1030 mm Turning dia 900 mm Fixed steady included Chip conveyor Spindle motor 45 kw Power requirements 62.2 kva Dims 7.1 x 2.2 x 2.2 m 10 Position Tool Turret, Tailstock, Machine Weight 21500kg. S/No. P60L0377 (2006) Machine is in excellent used condition Videos can be sent on request

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 100277, turning diameter: 340 mm, spindle speed (max.): 4,500 rpm, travel distance X-axis: 280 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 500 mm, TECHNICAL DETAILS X-axis: 280 mm Y-axis: 120 mm Z-axis: 500 mm C-axis: 360° (0.0001°) Spindle speed: 4,500 rpm Bjdpfex I Axrsx Ad Ajwl Spindle bore: 62 mm Chuck diameter: 10 inches MACHINE DETAILS Control: OSP U 100 L Weight: 6,000 kg EQUIPMENT Driven tools Chip conveyor Transformer Manuals

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning length: 225 mm, turning diameter: 260 mm, travel distance X-axis: 170 mm, travel distance Z-axis: 335 mm, rapid traverse X-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, rotational speed (max.): 5,000 rpm, quill diameter: 60 mm, quill stroke: 80 mm, ATTENTION: A total of 3 machines available. There are 2 additional identical machines with the same equipment (chip conveyor, etc.). EQUIPMENT - Chip conveyor for side mounting and chip bin - Short bar loader magazine - Interface for bar feeder device - Workpiece catch tray (parts catcher) - Chuck confirmation switch (open/close) - C-axis indexing - Driven tools - Programmable tailstock - Linear guides - Manuals Control: Fanuc 0i-TD Control power-on hours: 30,811 h Machining time: 7,738 h Spindle motor power: 15/7.5 kW Feed motor power X/Z-axis: 3.0/1.8 kW Milling spindle motor power: 3.7/2.2 kW Max. turning diameter: 260 mm Max. turning length: 225 mm Chuck size: 6" Swing diameter over bed: 550 mm X-axis travel: 170 mm Z-axis travel: 335 mm Rapid traverse X/Z-axis: 36 m/min Main spindle Spindle nose (ASA): A2-5 Max. spindle speed: 6,000 rpm Spindle bore diameter: 56 mm Max. bar capacity diameter: 45 mm Turret Number of turret stations: 12 positions Turret indexing time: 0.15 s Tailstock Bjdpfx Adey Hrnge Aewl Quill diameter: 60 mm Quill stroke: 80 mm Taper bore/tailstock mounting: MT 4 Milling Spindle Max. spindle speed: 5,000 rpm Bar feeder magazine Model: Fedek Machine Co. DH-65 Bar length min./max.: 280/1,200 mm Bar diameter: 5-65 mm Dimensions Dimensions (L x W x H): approx. 1,620 × 1,200 x 1,400 mm

Year of construction: 2002, condition: ready for operation (used), A lathe Spinner requiring repair is available. Travel X/Z: 96mm/245mm, max. turning length: 245mm, max. swing diameter: 120mm, turning diameter over bed: 290mm, spindle bore: 42mm, speed: 6000rpm, rapid traverse: 15m/min, tool stations: 12, tool holder: VDI16, bar passage: 42mm. Machine dimensions X/Y/Z: approx. 4400mm/1200mm/2200mm, weight: approx. 3000kg, control: Siemens Sinumerik ShopTurn. Including bar feeder and drawer contents. The machine has the following problems: high measuring inaccuracy, problems with the handwheel and measuring arm as well as measurement deviation. Documentation available. An on-site inspection is possible. Bsdpfx Aoy Igbwjd Aowl

Condition: used, 4 Axis Year Of Manufacture: 1998 8” Chuck 2 Turrets – Turret 1 – 12 Stations Turret 2 – 8 Stations Programable Tailstock Bwjdpfxjy Drune Ad Ael 750mm Between Centres Live Tooling C Axis Touch setter Y axis Swarf Conveyor Okuma OSP 7000L Control

Condition: good (used), Colchester / Harrison / 600 Lathes TORNADO 300 CNC lathe TECHNICAL DATA Spindle power: 18 / 22 kW Spindle connection: A2-8 Spindle bore: 90.5 mm Chuck sizes (A type): 265 mm Drawtube diameter: 82 mm Front bearing (inner diameter): 130 mm Max. Spindle speed: 4000 rpm X-axis: 240 mm Bwodpfernkhyjx Ad Asl Travel over center of rotation: 213 mm Under turning center: 27 mm Working stroke Z-axis: 500 mm Feed speeds: Rapid traverse X-axis: 10 m/min Rapid traverse Z-axis: 20 m/min Min. feed step: 0.001 mm Tool carrier: Turret, number of tools: 12 Tool holder mounting: VDI 3425 / 40 Turning chisel, shank size: 25 x 25 mm Max. Drill rod diameter: 40 mm Tailstock quill diameter: 95 mm Quill inner cone: No. 5 MK Quill stroke: 125 mm Tailstock travel: 485 mm Max. Tailstock quill axial force: 7860 N Swing diameter: 530 mm Turning diameter over cross slide: 330 mm Max. Machining diameter: 300 mm Max. Turning length: 500 mm Height of turning center above floor: 913 mm Bed width Z-direction: 750 mm Bed width X-direction: 393 mm Bed width tailstock guide: 255 mm Cross slide width: 256 mm Bed slide inclination: 600 mm Installation area: 3.26 m2 Weight: 3300 kg We assume no liability for the accuracy, completeness and up-to-dateness of the information provided

Condition: excellent (used), Year of construction: 2004, Maier ML 26 E CNC lathe TECHNICAL DATA Number of axes: 11 Spindle bore: 32 mm Path speed: 32 m/min Control: Maier Pro GE-Fanuc Guide bush: 451.001 Main spindle Clearance: 26 mm C-axis: Yes Mechanical indexing 5°: Yes Headstock stroke: 220 m Main spindle, speed: 0 - 6000 rpm Power: 3.7 kW / 5.5 kW (7.5 kW) Collet chuck: 161E Counter spindle Clearance: 26 mm C-axis: Yes Mechanical indexing 5°: Yes Max. travel (Z): 220 mm Counter spindle, speed: 0 - 6000 rpm Main spindle, power: 1.1 kW Collet chuck: 161E Cross machining Basic holder for turning rings 5 pcs. 16 x 16: Yes Number of driven tools: 4 Power of the driven tools: 0.5 kW Back machining Drive power: 0.5 kW Number of tools: 4 of which driven tools: 4 Collets: ER16 Tool turret Number of tools: 16 Number of driven tools: 8 Drive power: 0.5 kW C-axis: 360 ° Z-axis: 175 mm X-axis: 200 mm Bodpeu S Rivofx Ad Aewl Collets: ER16 SCOPE OF OFFER U.A: (list not exhaustive): Maier ML 26 E CNC lathe Oil mist separator transformer Chip conveyor High pressure pump / belt filter system Fire extinguishing system LNS bar feeder Complete operating documentation Exact scope of offer according to photo gallery No responsibility is taken for the accuracy, completeness and timeliness of the information

Condition: good (used), Year of construction: 2005, CITIZEN K12 CNC lathe TECHNICAL DATA Bodpfx Asvrz H Rjd Aewl Max. machining diameter: 12 mm Max. machining length: 200 mm Max. extension length: 80 mm Max. front drilling diameter: 10 mm Max. front thread diameter: M8 Spindle diameter: 16 mm Spindle speed: 15000 rpm Max. machining diameter of the counter spindle: 12 mm Max. machining length of the counter spindle: 40 mm Max. drilling diameter for rear machining: 6 mm Max. thread diameter for rear machining: M5 Spindle speed, counter spindle: 10000 rpm Tool attachment, number of tools: 8 Speed of the driven tools: 6000 rpm X1 axis: 122 mm Z1 axis: 200 mm Z2 axis: 150 mm Weight: 1950 kg SCOPE OF OFFER Among other things: (list not exhaustive) Citizen K12 CNC lathe Chip tray Transformer Complete operating documentation Exact scope of offer according to photo gallery We assume no liability for the accuracy, completeness and timeliness of the information

Condition: good (used), Year of construction: 2002, TRAUB TNL 12/7 CNC sliding headstock automatic lathe TECHNICAL DATA Bar capacity: 12 mm Main headstock strokes: 130 / 80 mm Spindle power: 4 kW Speed, main spindle: 12`000 rpm Upper turret: 6 positions Lower turret: 6 positions Number of driven tools, turret: 6 Max diameter, counter spindle: 12 mm Speed, counter spindle: 12`000 rpm Dimensions: 2850 x 1100 x 1480 mm SCOPE OF OFFER U.A: (list not exhaustive): Traub TNL 12/7 CNC lathe Meyrat high-frequency spindles, 2 pieces Tool holders (driven and non-driven) FMB Minimag 3200 C bar loader Hydraulic unit High pressure pump Chip conveyor Exact scope of supply according to photo gallery Bodpjt E Dbyefx Ad Ajwl No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: excellent (used), Year of construction: 2013, Traub TNL 18-7B CNC Automatic Lathe Base machine: 2441 x 1396 mm Weight: 3800 kg Spindle height above floor: 3800 mm Connected power: 24 kW Main spindle Max. bar capacity: 18 mm Max. speed: 12,000 rpm Cross-cut speed: 5,000 rpm Z stroke: 205 mm Rapid traverse: 40 m/min Z measuring system resolution: 0.001 mm Feed force: 3000 N Spindle head / short taper: Traub short taper mount Max. clamping force: 1400 daN Max. clamping pressure: 40 bar Min. clamping pressure: 7.5 bar Piston area: 40 cm2 Total cylinder travel: 5 mm Clamping tube thread: M25 X 1 Counter spindle Workpiece diameter: 21 mm Workpiece clamping depth: 180 mm Bodpfxowg Take Ad Ajwl Max. speed: 12,000 rpm Strokes: X: 120 mm Y: -20/+40 mm Z: 250 mm Rapid traverse: X: 20 m/min Y: 20 m/min Z: 40 m/min Max. clamping pressure: 30 bar Min. clamping pressure: 10 bar Top tool turret with B-axis Number of stations: 8 Shank cross-section, turning tool: 16 x 16 mm Stroke: X: 120 mm Y: -25/+40 mm Z: 250 mm Rapid traverse: X: 20 m/min Y: 20 m/min Z: 40 m/min Chip-to-chip time: 0.5 sec Measuring system resolution: X: 0.0005 mm Y: 0.0005 mm Z: 0.001 mm Lower tool turret Number of stations: 7 + counter spindle Shaft cross-section, turning tool: 16 x 16 mm Stroke: X: 120 mm Y: -20/+40 mm Z: 250 mm Rapid traverse: X: 20 m/min Y: 20 m/min Z: 40 m/min Chip-to-chip time: 0.5 sec Measuring system resolution: X: 0.0005 mm Y: 0.0005 mm Z: 0.001 mm Tool drive for upper tool turret Number of driven stations: Max. 8 Drive power: 2 kW Max. speed: 12,000 rpm Torque: 3.9 Nm Tool drive for lower tool turret Number of driven stations: 7 + counter spindle Drive power: 3.4 kW Max. speed: 12,000 rpm Torque: 7.3 Nm Tool drive for the rear unit Number of stations: 7 Number of driven stations: max. 3 Pitch spacing: 46 mm Drive power: 2 kW Max. speed: 7,500 rpm Torque: 4.7 Nm Drive power: 2 kW Max. speed: 4,000 rpm Torque: 11.8 SCOPE OF OFFER INCLUDES (list is not exhaustive): Traub CNC lathe Tool holders, driven and non-driven High-pressure and belt filter system Oil mist separator Fire extinguishing system Chip conveyor Bar loader Operational documentation For the exact scope of offer, see the photo gallery No liability is assumed for the accuracy, completeness, or timeliness of the information provided.

Condition: good (used), Year of construction: 2001, Tsugami BS12-III CNC sliding headstock automatic lathe TECHNICAL DATA Bsdpfx Aoq H Ea Uod Ajwl turning diameter: 3-12 mm Turning length: 170 mm Max. Bore diameter: 7 mm Max. Internal thread diameter: M6 Speed: 12`000 rpm Speed, counter spindle: 6`000 rpm Number of axes: 6 Dimensions: approx. 190 x 130 x 220 mm Weight: 2200 kg No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: used, Year of construction: 2002, functionality: fully functional, turning diameter over cross slide: 380 mm, turning length: 3,000 mm, turning diameter: 630 mm, spindle bore: 90 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 2 rpm, travel distance X-axis: 355 mm, travel distance Z-axis: 3,000 mm, spindle motor power: 10 W, rapid traverse X-axis: 8,000 m/min, rapid traverse Z-axis: 5,000 m/min, total width: 1,850 mm, quill travel distance: 180 mm, quill diameter: 100 mm, quill stroke: 180 mm, workpiece weight (max.): 3,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, POREBA CNC TRP 63 Year of manufacture: 2002 Condition: used Machine under power, inspection possible Technical data: • Type: TRP 63 MN • Control: SIEMENS SINUMERIK 810D • Serial number: 7402-09-03006-03 • Centre height: 325 mm • Centre distance: 3000 mm • Spindle bore: Ø 90 mm • Main drive: 10 kW • Power supply: 3 × 380 V / 50 Hz Equipment: • MULTIFIX C tool turret (without holders) • Tailstock with manual quill feed • 2 electronic handwheels Bsdpfoyhp Eksx Ad Aowl • Chip conveyor • Coolant system (pump integrated in chip conveyor) • Rear safety guard
