Used Wittmann Linear Robot for sale (4,844)

Condition: good (used), Year of construction: 2007, functionality: unexamined, machine/vehicle number: 2601-0324, The Sprint 42 Linear from DMG Gildemeister is a CNC turning/milling center with 6 linear axes and 2 C-axes. Direct drives enable high acceleration and precise machining operations. It is suitable for demanding series production of parts with a bar diameter of up to 42 mm. Year: 2007 Spindles: Main and counter-spindle, each up to 6,500 rpm; bar passage through main spindle 42 mm, counter-spindle 38 mm. Tool capacity: 26 stations, including up to 11 driven tools; turret with Y-axis for milling and threading operations. Axes / Travels: Slide 1: X1 = 65 mm, Z1 = 350 mm, Y1 = 120 mm Slide 2: X2 = 326 mm, Z2 = 320 mm, Y2 = 265 mm Rapid traverse rates: up to 30 m/min (X1, Z1, X2, Z2), Y2 up to 18 m/min Control system: FANUC 160i-TB with 15" DMG SlimLine panel Including IEMCA Boss 545-E bar feeder The IEMCA Boss 545-E bar feeder (Type 32 LL, year of manufacture 2007) is included in the scope of supply and enables the continuous feeding of material up to Ø 42 mm. It operates with 400 V / 50 Hz and requires 6 bar of air pressure; its own weight is approximately 860 kg. Main spindle newly bearing: The main spindle has already been overhauled (new bearing). Lhsdpfjzkgqzsx Altek Inspection & Collection: An on-site inspection is possible. If you are interested or have questions about technical details, please do not hesitate to contact us.

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, load capacity: 240 kg, KUKA KR240 R2700 prime KRC4 robot – mechanical unit only Serial number: 623863 + 623865 Year of manufacture: 10/2012 Max. payload: 240 kg Max. working range: approx. 2700 mm Scope of delivery: Robot mechanical unit without accessories Used – normal signs of wear and tear. Further details, article numbers and images available upon request. Two-week commissioning guarantee. No further warranty. In addition, spare parts are constantly available from stock. The robot is fully functional and can be inspected at any time. Lhodpszly Ebsfx Altok Free loading / ex works. The selling price is per robot mechanical unit. The stated amount is net. The legally required value-added tax of 19% will be added at checkout. You will receive a proper invoice with the value-added tax shown. Collection on site in 74722 Buchen/Hainstadt. Shipping or freight costs vary depending on the quantity, weight, and desired delivery conditions. Shipping costs to foreign countries on request – please specify country, city, and postal code. Freight costs on request – please specify the delivery address.

Condition: new, Year of construction: 2018, functionality: fully functional, machine/vehicle number: RA0060194, Kawasaki RA006L robot, E-Controller, new, original packaging, serial number RA0060194 Year of manufacture: 02/2018 Controller: FE1 E-Controller Max. payload: 6 kg Max. working range: approx. 1650 mm Serial number: RA0060194 Standard configuration consisting of: • Robot kinematics • Controller (10m cable to the robot kinematics) • Teach pendant (10m cable to the controller) Interfaces: • RS232 • 2x Ethernet (separately configurable) Lsdpfszlyyfex Altshk • 2x USB • 32 digital inputs / 32 digital outputs (freely assignable) • User interface on the robot’s upper arm R series 12E / 8A / 2x air (10mm) (The signals of the user interface are available in addition to the 32E and 32A.) Scope of delivery: Robot, controller, cables, teach panel, operating manual, circuit diagrams. Used item – normal signs of wear. Further details, article numbers, and images available upon request. Two-week commissioning guarantee. No further warranty. In addition, spare parts are constantly available in stock. The robot is fully functional and can be inspected. Free loading / ex works. The stated amount is net. The legally required VAT of 19% will be added at checkout. You will receive a proper invoice with VAT shown. Collection on site in 74722 Buchen/Hainstadt. Shipping or freight costs vary depending on the number of items, weight, and desired delivery conditions. Shipping costs to foreign countries available upon request – please specify country, city, and postal code. Freight costs available upon request – please specify the delivery address.

Condition: used, Vibratory hopper, dosing hopper, storage bunker, linear vibratory feeder, sorting device Vibratory bowl feeder, spiral feeder / vibratory feeder Vibratory bowl, screw feeding with vibratory feeder for screwdriving technology Feeding system, feed device Manufacturer: MÜLLENDERS Type: MLF-G2 Year of manufacture: approx. 2000 Hopper capacity: approx. 4 liters Vibration frequency: 6000 Hz Control voltage: 24 volts DC (an external power supply is required) Mains connection: 230 volts, 50 Hz - An external 24 VDC power supply is required for the start/stop signals (the controller does not have an internal 24 VDC power unit). - REO control unit, type Reovib RS6 439-459, for adjustable vibration speed - Stainless steel hopper, hopper open to the rear Ljdpfx Asy E T Dteltshk - Base frame made from aluminum profile system Required space L x W x H: 380 x 210 x 700 mm Weight: 20.5 kg Good condition

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: F16/56XPA1/A/01, overall weight: 126 kg, arm reach: 800 mm, controller manufacturer: Stäubli, controller model: CS8C-TP80, Equipment: documentation/manual, Stäubli TP80 SCARA robot including original Stäubli CS8C controller – manufactured in 2016 We are offering a used Stäubli TP80 SCARA robot, including the original Stäubli CS8C controller, for sale. Technical specifications: Manufacturer: Stäubli Model: TP80 Controller: CS8C-TP80 Year of manufacture: 2016 4-axis SCARA robot Payload: 0.5 kg Reach: 800 mm Condition: Used Total weight (with controller) = 126 kg Robot weight: 68 kg Scope of delivery: Stäubli TP80 robot Original Stäubli CS8C-TP80 controller Connection cable Operating manuals Scope of delivery as shown in the photos The robot comes from an industrial research and development environment and was in use until it was dismantled. The system was carefully maintained and is ideally suited for automation, assembly, pick-and-place, or packaging applications. Ledpfx Ajzlkf Soltshk Inspection is possible by appointment. We will gladly send you further photos or technical information upon request.

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: F16/56XTA1/A/01, overall weight: 1,120 kg, load capacity: 100 kg, input voltage: 400 V, type of input current: three-phase, Stäubli TX200 industrial robot including CS8CHP controller and Stäubli teach pendant – manufactured in 2016. We are offering a used Stäubli TX200 industrial robot for sale, including the original Stäubli CS8CHP controller. Technical specifications: Lsdpfszli Husx Altshk Manufacturer: Stäubli Model: TX200 Controller: CS8CHP Year of manufacture: 2016 Payload: 100 kg Condition: Used Scope of delivery: Stäubli TX200 robot Original Stäubli CS8CHP controller Stäubli teach pendant Connection cable Operating manuals Scope of delivery as shown in the photos The robot comes from an industrial research and development environment and has been carefully maintained. The system was in operation until it was dismantled. Inspection is possible by appointment. We will gladly send you further photos or technical information upon request.

Year of construction: 2017, condition: used, current 70 A capacity 95 Ah Payload 200 kg weight of the machine ca. 190 kg dimensions of the machine ca. 1420x450x260 m These can be automatically connected and disconnected using a system consisting of lifting bolts and snap locks in conjunction with an RFID reader for overcarriage detection. The maximum tensile load is approx. 1,500 kg. Forward and reverse travel possible. 7" touch display for easy operation. AGV operating voltage: 24 DC V Charging station operating voltage: 48 DC V Charging time at 48V / 32A: 4 hours (may vary) Nominal voltage of energy unit: 24 V Gobijru Ezloc S H Efjtt Capacity: 95 Ah Maximum current: 70 A Operating temperature range: 5-30 °C Positioning accuracy: + / - 10 mm (may vary) Min. turning radius: 1 m Maximum speed: 1.0 m/s (may vary) Continuous running time without load: 800 min (may vary) Housing material: Powder-coated aluminum, steel-reinforced base plate Dimensions (L/W/H): 1420/450/260 mm AGV weight: 190 kg Lhsdpfx Aloyapfnjtek Weight of additional plates (for pulling tasks): 68 kg Load capacity: 200 kg (may vary)

Condition: used, DIVERSE ROBOTER DREHTISCH EXPERT 7 PIECIES Lsdpfx Aedkq Ehsltehk

Condition: refurbished (used), Year of construction: 2015, machine/vehicle number: R-00631, load capacity: 20 kg, arm reach: 3,110 mm, controller manufacturer: R-30iB A-Size, teach pendant manufacturer: A05B-2518-C202#EGN, Refurbished FANUC M-710iC/20L manufactured in 2015.11. The robot comes with an R-30iB A-Size controller including iPendant.   Our experts extensively tested the robot, after which we conducted a maintenance service according to the manufacturers’ specifications. The grease is examined for the amount of iron particles, indicating the corresponding axes' condition. Only robots in excellent mechanical condition will be completely refurbished, ensuring a long-term solution for our customers. This enables us to deliver our robots with a warranty term of 12 months as standard! Lsdpozrz Dfsfx Altjhk   Brand: FANUC Model: M-710iC/20L Model Number: A05B-1125-B205 Year of Manufacture Robot: 2015.11 Warranty term (months): 12   Payload (kg): 20 Reach (mm): 3110 Repeatability (mm): ± 0.11 Controlled Axes: 6-axis Installation Type: Floor, Upside-down, Wall, Angle Mount Weight (kg): 540   Controller: R-30iB A-Size Year of Manufacture Cabinet: 2015.10 RCC Length (m): 7   Teach Pendant: A05B-2518-C202#EGN Teach Pendant Cable Length (m): 10

Condition: excellent (used), Year of construction: 2011, KUKA KR 30-3 robotic welding cell + positioner + Fronius system Robot: KUKA KR 30-3 Controller: KRC2 Robot year of manufacture: 2011 Cell year of manufacture: 2011 2 robots CMT welding power sources: 2 Manufacturer of welding power sources: Fronius Type: Trans Synergic 4000 Wire feeder: VR7000CMT Control box: RCU 5000i 2 torch cleaning stations Rotary table 2 riveting stations Ledpfxsy Ia S Ne Altjhk Manufacturer of riveting stations: Böllhoff Microprocessor control: Proface Rotary table for assembly Storage racks Storage platforms.

Condition: used, Year of construction: 2020, functionality: fully functional, product height (max.): 610 mm, Equipment: double-sided, FICEP NOZOMI 601 RAZ - ROBOTIC PLASMA CUTTING SYSTEM FOR STRUCTURAL STEEL | YEAR 2020 The Ficep NOZOMI 601 RAZ is a fully automatic robotic plasma cutting system for three-dimensional thermal processing of steel profiles and beams. An anthropomorphic 9-axis articulated robot machines all four profile faces without re-clamping, replacing layout, thermal cutting, coping and grinding with one automated work cell - less handling, shorter throughput times, reproducible quality from CAD/CAM data. CONDITION Used - technically sound. The machine is currently in productive operation. Year 2020 - a comparatively young machine of its class on the used market. - Inspection UNDER POWER during ongoing production possible by appointment. - Handover as preferred: directly from ongoing production (cleaned and serviced) or - at additional cost - reconditioned by ASM. - Details on the technical condition are disclosed individually upon serious interest. FUNCTION & APPLICATION The NOZOMI 601 RAZ combines plasma cutting, coping, bevel cutting, weld-seam preparation and marking in a single pass. The non-contact laser scanner measures the profile surfaces and determines the torch start position automatically. The system processes H-beams, U-channels, L-angles and flat bar. Typical applications: structural steel, bridge and plant construction, series production of connection and node details. Plasma processing uses the Hypertherm True Hole process. TECHNICAL DATA - Manufacturer: Ficep | Model: NOZOMI 601 RAZ | Year: 2020 | S/N: 36291 - Machine type: Robotic plasma cutting system (thermal profile processing) - Condition: used, technically sound - Profile size min.: 80 x 10 mm - Profile size max.: approx. 610 mm profile height (flange width to be confirmed during inspection) - Profile types: H-beams, U-channels, L-angles, flat bar - Machining sides: 4 | Clamping: automatic - Number of CNC axes: 9 | Design: anthropomorphic articulated-arm robot - Profile measurement: laser scanner, non-contact, fully automatic (multi-surface) - Cutting process: plasma | Plasma cutting heads: 1 - Plasma technology: Hypertherm True Hole - Bevel cutting: 45-degree bevels, copes, weld-seam preparation - Marking function: yes (orientation marks, weld symbols, labelling) Lhsdpfx Ajxq Rpnoltok - Software: Steel Projects PLM (licence transfer on request), free vector programming, automatic nesting - Infeed length: 16 m | Outfeed length: 16 m - Extraction: integrated particle filter system Machine weight, electrical connection values and max. plasma cutting thickness are confirmed on request. SCOPE OF DELIVERY - 1 x Ficep NOZOMI 601 RAZ robotic thermal cutting system (year 2020) - 1 x anthropomorphic 9-axis articulated-arm robot - 1 x plasma cutting head (Hypertherm True Hole compatible) | 1 x automatic torch changer - 1 x laser-scanner measuring system (non-contact, multi-surface) - 1 x infeed roller conveyor (16 m) | 1 x outfeed roller conveyor (16 m) - 1 x automatic clamping device | 1 x integrated extraction system LOGISTICS & LOCATION Location: Ulft (Netherlands), directly at the German border. Dismantling, transport, installation and commissioning by ASM by arrangement - individually calculated upon request. ABOUT ASM Arendsen Steel Machinery (ASM) is a specialist for Ficep structural-steel machinery. Further machines on request. CONTACT / INQUIRY Arrange an inspection under power | Price on request. Sale exclusively to commercial customers (B2B).

Condition: used, EPSON EH85DS robot SRC 320 controller Industrial Robot Robot Lhsdpothcv Ajfx Altjk OPU-320

Condition: used, Kuka robot KR 210 R2700 prime, KRC 4, KCP 4, industrial robot, robot. Robot control cabinet, panel, cable. Ledjznkg Ijpfx Altjhk 3 units in stock.

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, overall weight: 1,412 kg, load capacity: 240 kg, arm reach: 2,700 mm, controller manufacturer: KUKA, controller model: KRC2, Equipment: documentation/manual, For sale is a KUKA KR 240-2 2000 industrial robot in good used condition. The robot comes from an industrial application and is fully functional. Before delivery, the robot will be thoroughly tested again to ensure proper operation. This guarantees that you will receive an immediately deployable and reliable solution for your automation tasks. An inspection while the robot is powered on can be arranged at any time. Scope of delivery: - Mechanical components (manipulator) - Control cabinet / controller - Operating panel (teach pendant) Lhedpfxozdihde Altok - Connection cable

Condition: ready for operation (used), Year of construction: 2019, operating hours: 6,000 h, functionality: fully functional, load capacity: 12 kg, arm reach: 1,850 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Load capacity: 12 kg Reach: 1,850 mm MACHINE DETAILS Operating hours: 6,000 h Lodjznh Tfopfx Altohk Scope of delivery: Robot + Controller + Control cabinet + Flex pendant and ProfiNet I/O Slave software

Condition: like new (used), Year of construction: 2007, operating hours: 690 h, functionality: fully functional, machine/vehicle number: F-87459, input voltage: 400 V, type of input current: three-phase, This robot is a 'lazy dog'. Despite its age, it has just 70 hours of operating time. It served as a test robot and was not actually used in production. Nevertheless, it has received regular maintenance from Fanuc. Its condition is almost as new. It can be mounted on the floor, wall, or ceiling. The machine has been inspected and has undergone a trial run. If interested, the robot can be viewed at our facility. Delivery and initial commissioning are also possible. Lsdjw Tl S Depfx Altehk

Condition: ready for operation (used), Year of construction: 2002, operating hours: 63,040 h, functionality: fully functional, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Machine configuration Upper linear slides: 2 units Milling unit: 1 unit Transverse drilling units: 2 units Rigid front spindle: 1 unit Machining units Drum 6: Movable only in the X-axis Front position 1: Rotationally rigid spindle, movable only forwards and backwards Front positions 2 to 4: Rotationally fully controllable spindles Front position 5: Internal machining axis for processing internal contours and radii Front position 6: Driven indexing spindle with rear machining slide and two tools, movable towards the viewing side Full electronic equipment Electronically connectable auxiliary drives on the front positions and six drum slides MACHINE DETAILS Operating hours: 98,119 h Spindle hours: 63,040 h EQUIPMENT Chip conveyor Ledpfozrgnpsx Altshk High-pressure coolant unit Bar loader Milling unit Two transverse drilling units Collets Spare parts Electronic components for the control cabinet New rigid front spindle

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, warranty duration: 3 months, Equipment: documentation/manual, Complete Package Including: Zoom 90 R 5'' Robotic Total Station WinCE AiM360, TRack360 and Scout360, 5", accXXess10 EDM 1000M, Long-range Bluetooth 500m, User manual in French, Li-Ion battery 4.4Ah, Lhedpfxszq Hu Ho Altok Li-Ion battery charger, Lead-free optical tribrach, Industrial-grade SD card, 1GB, Notebook holder, 360° prism, Touchscreen tablet, X-Pad topographic software included. Calibration certificate. Suitable for Civil Engineering, Surveyors, Topographers, Construction, and Public Works. The Zoom90 robotic total station is an ultimate single-person system, offering up to 20% more automated performance, extended 1000m reflectorless measurement capabilities, STReAM360, accXess technologies, and open Windows CE connectivity. OPEN CONNECTIVITY Connect your preferred software and data logger to perform remote control tasks without reducing productivity. The Zoom90 uses the Windows CE operating system, which allows the execution of many powerful field software applications. Full VGA color touchscreen, ensuring optimal performance and graphics capabilities. TOPOGRAPHY ADVICE Alternative solutions in terms of measurement and software. #Topography #TotalStation #Leica #LeicaGeosystems #TopographicEquipment #UsedTopography #Surveyor #Geomatics #3DScanner #GPS #Theodolite #Monitoring #PublicWorks #ConstructionSite #LaserScanner #Mapping

Condition: good (used), Year of construction: 2007, functionality: fully functional, load capacity per storage section: 11,500 kg, total length: 390,000 mm, total height: 7,000 mm, total width: 1,000 mm, shelf height: 7,000 mm, support length: 2,700 mm, shelf length: 51,300 mm, load capacity: 1,000 kg, load capacity per stand: 11,500 kg, frame height: 7,000 mm, load per truss pair (max.): 3,000 kg, frame width: 85 mm, axle spacing: 2,700 mm, mesh size: 2,700 mm, number of shelf rows: 7, pallet spaces: 1,845 euro pallets, construction width: 27,003,600 mm, Approx. 390 linear meters of STOW / Link 51 / Allclick pallet racking – approx. 1,600 pallet spaces Used pallet racking system in good condition, see pictures and video. Total length approx. 390 linear meters Height approx. 7,000 mm Approx. 136 racking bays Approx. 1,600 pallet spaces including ground level Beams mostly approx. 2,700 mm, partially approx. 3,600 mm The system mainly consists of STOW pallet racking, with additional sections of Link 51 and Allclick. Negotiable price: €32,000 net The offer includes approx.: 136 racking bays Lhodpjzugtdofx Altek 145 racking frames 958 beams total of which 113 bays are STOW 16 bays are Link 51 7 bays are Allclick Locking devices End-of-aisle protection various racking accessories Of the 958 beams, approx. 156 are additional STOW beams, which are not currently installed in the assembled system. Additionally available: Rear panel mesh covering an entire row of racking approx. 51,300 mm length approx. 7,000 mm height corresponds to approx. 18 bays at 2,850 mm each The entire racking system was assembled until just before the start of dismantling and was documented with photos, videos and drone footage. The dismantling will be carried out professionally. The material will be sorted according to racking system and component type. Partial sale or sale of individual racking systems is possible by arrangement. Quantities, dimensions and pallet spaces are approximate. Minor deviations are possible. Assembly throughout Europe is possible for an extra charge! Looking forward to hearing from you or receiving your call! Best regards, Michal Stasiak

Condition: like new (used), Year of construction: 2006, load capacity: 300 kg, arm reach: 3,150 mm, controller manufacturer: KUKA, controller model: KRC2 ED05, ROBOT ARM MANUFACTURER: KUKA MACHINE TYPE: KR 300 PA TECHNICAL SPECIFICATIONS PAYLOAD: 300 kg REACH: 3150 mm Lsdpszulm Aofx Altehk CONTROLS: KRC2 ED05

Condition: like new (used), load capacity: 200 kg, arm reach: 2,400 mm, ROBOT ARM Lhedpfozulyiox Altek MANUFACTURER: KUKA MACHINE TYPE: KR200 COMP. TECHNICAL SPECIFICATIONS PAYLOAD: 200 kg REACH: 2400 mm CONTROLLER: KRC2 ED05

Condition: good (used), Year of construction: 2005, Universal machining center Machine type: DMG DMU 50 Evo linear Control: Heidenhain iTNC 530 Year: 2005 Lhsdpfx Alezi Dzhetsk SPECIFICATIONS 5-axis-simultaneous Travel X-Axis: 500 mm Y-Axis: 450 mm Z-Axis: 400 mm B-Axes: 108° C-Axis: 360° Rapid motion: (X/Y/Z): 80 / 50 / 50 m/min. Amount of controlled axes: 5 Spindle speeds: 18.000 rpm Tool: SK 40 Toolchanger Tool capacity: 30 NC-panning and rotary Table Table size: 500 x 380 mm Power consumption: 52 kVA KW Machine weight: 6,5 kg Req. space (LxBxH): 5,4 x 6,5 m Equipment No cooling through spindle No chip conveyor: Spänewanne Caliper Working mode: 4

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,110 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 90 m/min, rapid traverse Y-axis: 90 m/min, rapid traverse Z-axis: 90 m/min, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, rotational speed (max.): 28,000 rpm, overall weight: 14,000 kg, spindle speed (max.): 28,000 rpm, operating hours of spindle: 10,000 h, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 5-axis continuous machining center Linear motors 28,000 rpm spindle with HSK 63A, recently replaced Lsdpszmxmtjfx Altehk Rotary table, 950mm diameter Wireless workpiece probe MH Laser presetter for tool inspection Optical scales Remote handwheel Chip conveyor NO coolant supply through the spindle Complete with manuals Disconnection scheduled for August 25th Removal scheduled for August 26th

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 20,000 rpm, controller model: Heidenhain TNC 530, TECHNICAL DETAILS Work Area Table surface: 2,300 x 1,600 mm T-slots: 22 mm Distance between T-slots: 200 mm Workpiece weight with optimal distribution: max. 6,000 kg/m² Distance between columns: 2,700 mm Distance between table surface and spindle center: max. 1,220 mm Travel / Axes Travel X-axis: 2,200 mm Travel Y-axis: 1,500 mm Travel Z-axis: 1,000 mm Feed rate X/Y-axis: 0 - 60 m/min Feed rate Z-axis: 0 - 40 m/min C-axis rotation: ± 370° A-axis rotation: ± 105° A-axis torque: max. 830 N·m C-axis torque: max. 1,200 N·m Milling Head / Spindle Milling head: TOE 29 T, 5-axis orthogonal milling head Spindle connection: HSK 63 A Spindle power: 29 / 37 kW Spindle torque: 92 / 115 Nm Spindle speed: max. 20,000 rpm Constant torque range: 0 - 3,000 rpm Tool Changer Tool changer: Automatic tool changer Tool holder: HSK 63 A-100 Magazine capacity: 42 stations Tool diameter: max. 80 mm Tool length: max. 350 mm Tool weight: max. 8 kg MACHINE DETAILS Control model: Heidenhain TNC 530 Cooling / Measuring Systems Tool coolant supply through the spindle: 20 bar Coolant flow rate: 25 l/min Measuring system X/Y/Z-axis: Heidenhain glass scales Lsdjzhnk Dopfx Altehk Measuring system C-axis: Heidenhain angle measuring system EQUIPMENT Heidenhain TNC 530 CNC control 5-axis orthogonal milling head TOE 29 T Electro spindle HSK 63 A Automatic tool changer with 42 stations Tool coolant supply through the spindle Laser tool presetting BLUM Heidenhain glass scales on X, Y and Z axes Heidenhain angle measuring system on the C-axis Thermal insulation and stabilization of the crossbeam Central lubrication 2 chip conveyors Portable handwheel Heidenhain HR 520 15" TFT color monitor with soft keys Full enclosure with CE safety standard Control cabinet with air conditioning Rinsing gun Sliding roof for loading and unloading Note: The operating hours can be found in the last picture.

Condition: ready for operation (used), Year of construction: 2007, operating hours: 11,421 h, functionality: fully functional, machine/vehicle number: 29100009074, travel distance X-axis: 640 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, workpiece diameter (max.): 140 mm, spindle speed (max.): 16,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS Travel range X-axis: 640 mm Travel range Y-axis: 600 mm Travel range Z-axis: 500 mm Clamping area length: 850 mm Clamping area width: 600 mm T-slots: DIN 650-14 Loading height, top edge of table: 850 mm Table load max.: 600 kg Spindle manufacturer: Franz Kessler GmbH Speed: 1,600 - 4,700 / 4,700 - 16,000 rpm Number of magazine slots: 30 Slot coding: Fixed slot coding Load weight max.: 90 kg Chip-to-chip time without free travel logic t3/t2: 6.8 s Chip-to-chip time without free travel logic t1 (30): 7.9 s Chip-to-chip time with free travel logic t3/t2: 8.3 s Chip-to-chip time with free travel logic t1 (30): 9.3 s TOOLS AND TOOL MAGAZINE Diameter, standard tool max.: 100 mm Diameter, special tool with free neighboring slots max.: 140 mm Tool length max.: 300 mm Tool weight max.: 6 kg FEED Feed force X, Y, and Z axes: 7,000 N Feed rate X, Y, and Z axes max.: 40 m/min Rapid traverse speed Y and Z axes: 40 m/min Rapid traverse speed X axis: 70 m/min Ball screw diameter/pitch: 40/15 mm POSITIONING SYSTEMS Positioning accuracy, direct measuring system X-axis: 0.008 mm Positioning accuracy, indirect measuring system Y and Z axes: 0.020 mm Positioning accuracy, direct measuring system (option): 0.010 mm Resolution: 0.001 mm Input fineness X, Y, and Z axes: 0.001 mm MACHINE DETAILS Operating hours: 11,421 h Power-on time: 32,054 h Connected power: 33 kVA Lodpfxezpxqdo Altehk Nominal current max.: 58 A Fuse rating: 63 A Mains voltage: 400 V Mains frequency: 50/60 Hz Control voltage: 230 V Control voltage: 24 V COOLANT AND CHIP MANAGEMENT Chip box container capacity: 150 l Pump capacity, external coolant supply: 50 l/min Pressure, external coolant supply: 2.0 bar Pump capacity, chip flushing: 90 l/min Pressure, chip flushing: 1.9 bar Pump capacity, flushing gun: 50 l/min Pressure, flushing gun: 2.0 bar
