Used Vertical Belt Grinding Machine for sale (78,534)

Condition: excellent (used), Year of construction: 2021, operating hours: 4,300 h, DOOSAN T3600D VERTICAL MACHINING CENTRE YEAR: 2021 CONTROL: FANUC i PLUS X TRAVERSE: 520.0mm Y TRAVERSE: 360.0mm Z TRAVERSE: 350.0mm Kdedpfx Aoz R T D Uog Aju MAX. SPINDLE SPEED: 12,000 rpm TAPER: BT30 X-Y RAPIDS: 48.0m/min Z RAPID: 56.0m/min MAX.CUTTING FEED RATE: 28.0m/min TABLE SIZE: 2 X 650 X 375.0 mm

Year of construction: 2023, condition: new, We sell a new double belt grinder. The contact wheels can be purchased in different dimensions. Technical data: Weight: approx. 350 kg Electrical connection: see type plate of the respective drive motor Compressed air connection: 3 - 8 bar Noise level: > 85 dB(A) Contact wheels: max. Ø 350 mm x 110 mm grinding belts: max. 120 mm x 3500 mm length Suction connection: Ø 160 mm If you have any further questions, please do not hesitate to contact us! Kodpfxsk D Ex Te Ag Asdu

Condition: used, Year of construction: 1976, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 400 mm table speed: 2 - 18 m/min magnetic plate size: 600 x 200 mm Max. Table-movement horizontal: 700 mm Max. Table-movement across: 230 mm table adjustment: Quervorschub: 0,1 - 2 mm/Hub ° table speed: 2 - 18 m/min dimensions of grinding wheel: max. Ø 200 x 20 x Ø 51 mm grinding spindle speed: 2800 U/min feed of spindle: vertical 0,01 total power requirement: 3,0 kW weight of the machine ca.: 1,0 t Kdjdpfx Asu Ngl Djg Asu dimension machine xH: 1,8 x 1,2 x 1,9 m dimension coolant device LxWxH: 0,8 x 0,4 x 0,2 m Currently there is a grinding wheel size Ø 160 x 18mm on the machine. There is a dressing device (without diamond) on the spindle. Magnetic clamping plate progress type FE 200/600; 220V / 110V coolant tank div. foot blocks Toothed rail 1000mm *

Year of construction: 2022, condition: new, Robot - Belt Grinding Machine is a belt grinding machine for robotic machining with a contact wheel for grinding parts made of aluminum, steel, brass and zinc die casting. Technical data: Kdjdpfxsgxug Tj Ag Asu Contact wheel: max. Ø 400 mm grinding belt length: 3500 mm grinding belt width: max. 150 mm Suction connection: Ø 160 mm dimensions (LxWxH ): 900 x 700 x 1800 mm Weight: approx. 350 kg Electrical connection: 3 x 400 V, 4 kW Compressed air connection: 6 - 8 bar Noise level: > 85 dB(A) spindle diameter: 35 mm Buffer: 50 mm Belt grinding unit for grinding belts max. 150 mm x 3500 mm length with pneumatic belt tension, belt tear control, 4 kW drive power, frequency controlled, for contact wheels max. DM 350 mm x 150 mm, drive and deflection rollers, with buffer 50 mm

Year of construction: 2022, condition: new, Robot - Belt Grinding Machine is a belt grinding machine for robotic machining with a contact wheel for grinding parts made of aluminum, steel, brass and zinc die casting. Technical data: Contact wheel: max. Ø 400 mm grinding belt length: 3500 mm grinding belt width: max. 150 mm Suction connection: Ø 160 mm dimensions (LxWxH ): 900 x 700 x 1800 mm Weight: approx. 350 kg Electrical connection: 3 x 400 V, 4 kW Compressed air connection: 6 - 8 bar Noise level: > 85 dB(A) spindle diameter: 35 mm Kdedpfx Agsgxug Nj Aou Belt grinding unit for grinding belts max. 150 mm x 3500 mm length with pneumatic belt tensioning, belt tear control, 4 kW drive power, frequency controlled, for contact wheels max. DM 350 mm x 150 mm, drive and deflection rollers

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, overall weight: 6,800 kg, spindle speed (max.): 12,000 rpm, We offer in good conditon Hurco VMX42i with BT40 spindle and Winmax software. X-Axis travel: 1067mm Kjdpfxs Aa Dd Io Ag Ajdu Y-Axis travel: 610mm Z-Axis travel: 610mm

Condition: like new (used), Year of construction: 2006, operating hours: 671 h, functionality: fully functional, total height: 2,992 mm, total length: 3,980 mm, total width: 2,580 mm, overall weight: 8,500 kg, operating hours of spindle: 671 h, number of slots in tool magazine: 48, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, We offer this as new Quaser MV154 APC/P vertical machining center, year of construction 2006. The machine has 9039 power-on hours, but only 671 spindle-hours, this has been confirmed in the parameters aswell. The machine has seen very little usage. When i bought this machine the linear guides for the X & Y axis was worn out as they had not been lubricated properly and with the incorrect grease. These have been swapped for brand new ones, aswell as most of the air and coolant hoses. All the lubricating lines for the X & Y guides and ballscrews have also been renewed. There are some tools in the 48 tool magazine aswell. It also has a 3D Taster. The chip conveyor also has new bearings and seals. Two Hilma vices could also come with the machine. I have done a ballbar test and checked the machine to be in great working order. The size of the machine also makes transportation easy, as it will fit inside a standard curtain semitrailer. Kdodpfjzxz Dfjx Ag Aou If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: good (used), Machine spindle, precision spindle, double bench grinder spindle, precision spindle for belt drive, belt drive spindle, grinding spindle -Manufacturer: Voumard, Grinding spindle Precision spindle -Type: C 40-9 D Kjdowub Ifjpfx Ag Aedu -Recording: M6 -Max. speed: 40,000 rpm -Dimensions: Ø 90 x 335 mm -Transport dimensions box: 480/320/H225 mm -Weight: 17.8 kg.

Condition: used, Year of construction: 1987, Technical details: grinding length: 600 mm grinding width: 350 mm workpiece height: 600 mm feed: 1 - 30 m/min magnetic plate size: 610 x 255 mm distance table - spindle center: min./max. 150 / 420 mm grinding spindle speed: 3000 U/min stroke of the table: min./max.: 200 / 650 mm total power requirement: ca. 4,0 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,5 x 1,9 x 2,0 m dimension coolant device LxWxH: 0,63 x 0,40 x 0,65 m Headstock: -vertical travel Y = 0.002 - 0.06 mm -adjustment = 0,001 - 2mm Cross slide: -transverse travel Z = 360mm -feed adjustment = 1 - 60mm/stroke -rapid traverse = 1.2 m/min. Dressing manual Cooling water unit with capacity 140Liter Equipment: -3x support feet -machine lighting accessories: -alignment device for grinding wheel holder * Kdedpfxeu Ngics Ag Aou

Year of construction: 2021, condition: new, for grinding belts Kjdpfx Aogxuhmsg Aodu max. 80 mm x 2000 mm length with 3 kW drive power, for contact wheel max. diameter 80 mm x 80 mm

Condition: good (used), Hydraulic cylindrical grinding machine Center height 100 mm Center width 500 mm Grinding wheel diameter min./max. 200 - 300 mm 3 grinding wheel revolutions 2,250 - 2,420 - 2,680 rpm Kdsder E Azijpfx Ag Aeu Workpiece spindle head: 8 workpiece speeds, adjustable 30 - 750 rpm. Spindle taper or inner taper of the workpiece spindle MK 4 Tailstock: Inner taper of quill MK 3 Quill travel 30 mm Table: Maximum table inclination +/- 6° Table speed, adjustable 0.1 - 6.0 m / min. Motor power 3 kW Dimensions L x W x H 1650 x 1350 x 1400 mm Weight 1900 kg Accessories / Special features: - Manual or automatic operation - Automatic infeed - Grinding wheel flange with grinding wheel - Wet grinding device Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund-Wambel

Condition: new, The tube linishing / satin finishing machine – ML100 – is the perfect choice for finishing the surface of round, oval and elliptical tubes. The ML planetary system enables the work without rotating the tube - delivering the best results on both bent and curved tubes. The auto feeding system transports straight tubes safety and automatically through the finishing station, enabling a consistent and high productive tube polishing quality. Minimum tube vibration even on the biggest lengths: With the ML Planetary System the tube is not spinning. The abrasive belts rotate around the tube while it is safely transported by the feeding systems. Straight or curved tubes polishing: ML100 was designed to finish either straight tubes (automatically) or bent tubes (manually). Quick set-up: Simple to work with ML100 tube polishing machine. Automatic feeding is hinge mounted and easily removable for bent tube finishing. Low heat: The soft contact with abrasive belts with ML Planetary System has a very low heat on the tube surface, unlike other conventional systems. Oval tubes: Oval or elliptical tubes polishing or simply out-of-round tubes can be safety and consistently finished with ML100 Finishing after tube drilling: Kdjdpfed Hfnbsx Ag Aou Maximum adaptability of the abrasive belt to holes or graps in the material surface. Technical Details - ML100: Working capacity (Ø mm) 10 - 114 No. Stations 1 Abrasive belt dimensions (mm) (2x) 50x940 Abrasive belt speed (m/s) 3-22 Feeding speed (m/m) 1-5 Abrasive belts motor (kw) 3 Wheel motor (kw) 1.5 Feeding motor (kw) (2x) 0.12 Total power (kw) 5 Consumption (A) 11 Dust extraction connection (Ømm) 80 Dimensions (mm) 750x1000x1300 Weight (kg) 250

Condition: good (used), Year of construction: 2015, Traverses X Y Z: 1050 x 530 x 510mm, Table 1300 x 550mm, Spindle speed 0 - 12000 rpm, Spindle taper Din 40, Spindle Motor 18.5kW, 30 station ATC, Mazak Matrix Nexus 2 control, Kodez Sqwmjpfx Ag Aedu swarf conveyor, coolant, Low Volt light

Condition: ready for operation (used), Year of construction: 1990, Available immediately from university surplus: Kdodpfxj Aa Ilco Ag Aou Vertical milling machine LAGUN Type FVA 3 LA Year of manufacture 1990 Table 1600 x 400 mm Travel X/Y/Z 1600/360/420 mm Spindle taper SK 50 Automatic quill feed 127 mm Spindle speeds 28 – 1400 rpm Drive power 12.5 hp Weight 4.5 tons Numerous accessories included: collets, milling cutters, hydraulic vise Price: Euro 1,500.00 plus VAT, ex works

Condition: used, Year of construction: 1975, functionality: fully functional, max. bore diameter to be ground 6 bis 100 mm stroke - stepless adjustable 550 mm Kedpfx Agjucgwko Aedu grinding depth ca. 250 mm workpiece weight 150 kg total power requirement 15 kW weight of the machine ca. 4.300 kg dimensions of the machine ca. 2,7 x2,4 x 2,2 m

Condition: used, Year of construction: 1976, Technical details: table surface area: 1300 x 190 mm range of revolution per miute: 60 - 4000 Stufenlos U/min feed continuous: Pinole: 0,06 / 0,12 / 0,24 mm/U quill stroke vertical: 140 mm Kdodeu Sq Emspfx Ag Aju spindle taper: SK 40 spindle head swivable left - right: 90° und 45° ° total power requirement: 3,0 kW weight of the machine ca.: 1620 kg machine dimensions LxWxH: 2,7 x 2,3 x 2,4 m Milling machine with universal milling head Spindle run right/left Table specifications: X/Y/Z travel: 860/380/460mm. feed X/Y/Z: 40 - 400mm/min. continuous rapid traverse 400mm/min. max. workpiece weight 30kg Equipment 3-way measuring display Mitutoyo with beam machine lighting Coolant tank with pump X- and Y-axis feed adjustable incl. accessories comparable to the picture *

Condition: excellent (used), Year of construction: 2019, Traverses XYZ: 762 x 508 x 508mm, Ksdpez Sqqmjfx Ag Aodu 500mm x 500mm table, max table weight 300kg, table tilt +110°, -35°, 22.4kW, 15000rpm, BT40, 40 station tool changer, Through spindle coolant, Tool Setter, Programmable coolant,

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Technical details spindle diameter 135 mm x-travel 1000 mm y-travel 700 mm z-travel 300 mm cross rail adjustment - vertical 780 mm distance between table/spindle 1000 mm table surface area 1100 x 842 mm distance between columns 1100 mm table load 1500 kg tool taper SK 45 spindle turning speed range 2400 U/min spindle drive 5,9 kW feed range 1 - 6000 mm/min weight of the machine ca. 10,6 t Kjdo Aa N Tbopfx Ag Aodu Additional information Retrofit / overhauling in May 2005 (with geometric measurement): - New Heidenhain iTNC-530 control - New electronics - New Siemens servomotors - Heidenhain glass scales - Revision of drilling spindle unit (total costs 118,436.00 EUR) Equipment: Infrared measuring probe m&h 38.10-MINI Electron. Handwheel Various tool holders Transport dimensions: - Machine (LxWxH) 3500 x 2600 x 2750 mm - Control cabinet (LxWxH) 2300 x 600 x 2300 mm - Hydraulic (LxWxH) 800 x 600 x 1000 mm

Condition: good (used), Year of construction: 2011, XYZ: 760 x 610 x 610mm, Ksdpfxsz Rz Nqo Ag Ajdu Table 900 x 600mm, 21kW, Heidenhain TNC530, 12000 rpm, 30 station ATC, BT40 taper, swarf conveyor, through spindle coolant,

Condition: good (used), Year of construction: 1995, travel distance X-axis: 1,000 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, 4-axis machine X-axis travel: 1000 mm Y-axis travel: 600 mm Z-axis travel: 600 mm Control system: Heidenhain TNC 426 Spindle nose: 100-700 mm Kodpj Aaygxofx Ag Aedu Work table: 1,080 x 580 mm Maximum workpiece weight: 550 kg T-slots: 7 T-slot width: 14 mm Tool magazine with: 36 positions Maximum tool weight: 8 kg Maximum tool length: 340 mm Machine weight (approx.): 6.2 t Space requirement (approx.): 4,790 x 5,330 x 2,905 mm

Condition: used, Year of construction: 1973, Technical details: grinding length: 400 mm grinding width: 200 mm workpiece height: 300 mm dimensions of grinding wheel: 275 - 315 mm magnetic plate size: 400 x 200 mm max. table load: 200 kg Kdsdpoxu Dv Aefx Ag Asu weight of the machine ca.: 1,6 t dimension machine xH: 1,55 x 1,45 x 2,20 m

Condition: used, Year of construction: 2017, functionality: fully functional, center height: 180 mm, total width: 1,650 mm, total length: 4,900 mm, total height: 1,800 mm, overall weight: 3,900 kg, grinding length 1500 mm centre height 180 mm Kedpfx Agowm Rqgj Ajdu weight of the machine ca. 3,9 t dimensions of the machine ca. L: 4900 x 1650x 1800 m

Condition: used, XYZ 2-OP Compact Vertical machining Centre Year 2017 Pro-Track TMX Control Table Size: 457 x 381 mm X/Y/Z Travels: 355 x 305 x 455 mm Spindle Speeds: 50- 6,000 rpm Spindle BT 30 Kedpfx Agszu Ni Us Aodu Spindle 3hp 8 Station Tool Changer Machine Weight: 1,100 kg Footprint: 760 x 1,220 mm

Condition: used, Year of construction: 1964, Technical details: shaft diameter: max. 120 mm work piece - max.: 800 mm height of profile: Tiefe: max. 90 mm grinding spindle speed: nicht bekannt U/min Table dimensions: Ø 150 mm voltage: 380 V total power requirement: 1,1 kW weight of the machine ca.: 0,675 t dimension machine xH: 0,75 x 0,70 x 2,0 m Application: vertical internal cylindrical grinding of shafts face, and center grinding with shaft grinder. Spindle head technical details: -equipment shank grinder Ø 13mm 60°; clamping element Ø 6mm shank clamping head. -travel=vertical 950mm by handwheel and transversal 80mm by crank handle -abrasive device with diamond, adjustment crosswise= 80mm. Table other specifications: -with fixed tip holder 60°. -speed 63 / 125 rpm. -adjustment vertical 600mm, in height 1.100mm, operation manual. Kdodpfou Ngr Dox Ag Aju centering block: -prismatic guide accessories: -fixed tip L=180mm -fixed tip L=300mm -div. shank grinder -div. clamping and auxiliary tools *

Condition: good (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 560 mm, controller manufacturer: Mazatrol, controller model: 640M, total height: 2,700 mm, total length: 3,445 mm, total width: 3,301 mm, table width: 550 mm, table length: 1,300 mm, table load: 1,500 kg, rotational speed (min.): 25 rpm, rotational speed (max.): 6,000 rpm, overall weight: 8,900 kg, coolant supply: 15 bar, number of slots in tool magazine: 30, Equipment: chip conveyor, We are pleased to offer this very well-maintained Mazak MYV 515/40N vertical machining centre, manufactured in 2006. The machine is fitted with the Mazatrol 640M control system. This machine impresses with its stability and suitability for heavier machining operations. Technical specifications: Table dimensions: 1300 x 550 mm Table load capacity: 1,500 kg Number of pallets: 1 X-axis travel: 1,050 mm Y-axis travel: 510 mm Z-axis travel: 560 mm Ksdpfx Agez Rmb Eo Aedu Spindle speed: 25 – 6,000 rpm Spindle mount: MAS BT 50 Spindle motor: 18.5/15 kW Positions in tool magazine: 30 We realise that you may wish to receive further information or view the machine. In that case, please contact us, providing your company details so that we can get in touch with you. About Mamach Machinehandel: With over 40 years experience in the CNC machinery sector, we are now one of Europe’s leading suppliers of metalworking machinery. Our success is based on high quality, customer-focused service and a strong international network. Discover our wide range of used CNC lathes and machining centres – we’d be happy to advise you personally!
