Used Wmw Surface Plate for sale (17,065)

Condition: used, Technical details: weight of the machine approx.: auf Anfrage kg Diese Spannmittel werden im kg-Preis bei Gesamtabnahme verkauft. Bitte beachten Sie die Ausweisung auf den Fotos! Njdpfx Akju N D N Hjuowg *

Condition: used, Technical details: diameter: 250 mm passage: 80 mm width: 80 mm revolution per minute: 2400 U/min dimensions: Ø 250 x B: 180 mm incl. 3 clamping jaws mounted, max. clamping range outside: Ø 60 - 188 mm and max. clamping range inside: Ø 17 - 192 mm with base plate Ø 303 x 48 mm; outer pitch circle Ø 280 mm with 4x M16 holes; inner pitch circle Ø 134 mm with 4x M12 holes; T-slot 3x lengthwise and 3x crosswise, T-slot spacing = 64 mm Flange = Ø 248 x 13 mm Accessories: with chuck key 1 set of soft jaws Nedpovgbhksfx Akuowg *

Condition: used, Technical details: diameter: 250 mm passage: 80 mm width: 80 mm weight of the machine approx.: 23 kg dimension L-W-H: Ø 250 x 130 mm 4 jaw chuck with flange - width of the main body 80mm - with clamping jaws for internal /external - flange size Ø 250 x 18 mm, thread 4 x M16 ; pitch circle of the bolts = Ø 170 mm Other 3- and 4-jaw chucks and face plates in stock. Please inquire! Nwjdpfxsu Nlfij Akusg *

Condition: used, Accessories for e.g. a bench drill BFT 130: The spindle head and swivel angle can be swivelled 360° around their own axes. Two swivel planes The set angles can be read off on circumferential scales Speed max. 600 rpm. Spindle taper ISO 50 Weight approx. 270kg incl. connecting piece to the drive SK 50 pinoler/head Nwsdpfeu Nlgysx Akueg *

Condition: used, Technical details: length: 1000 mm width: 1100 mm height: 610 mm weight of the machine approx.: 1139 kg Drill cube material made of cast steel. Nwjdeu Nva Depfx Akujg Bohrwürfel Material aus Stahlguss. T-Nuten nach DIN 650m - Spannfläche vertikal: LxT: 1000 x 610mm - Spannfläche horizontal: LxB: 1000 x 1100mm *

Condition: used, Year of construction: 1981, Technical details: x-travel: 400 mm Nsdpsu Nc Hkofx Akuswg y-travel: 420 mm z-travel: 380 mm table surface area: 710 x 400 mm max. table load: 120 kg range of revolution per miute: 45 - 2240 / 18 step U/min feed continuous: 6,3 - 600 / 2 steples mm/min quill stroke vertical: 100 mm quill stroke: horizontal: 100 mm spindle taper: vertical/horizontal: SK 40/SK40 spindle head swivable left - right: 90 ° distance table/horizontal spindle: min./max.: 200 / 325 mm distance table/vertical head: min./max.: 150 / 730 mm total power requirement: 5,5 kW weight of the machine ca.: 1,95 kg machine dimensions LxWxH: 1,7 x 1,4 x 1,9 m dimensions electric cabinet: 850x500x1500 mm The milling machine is equipped with a 3-measuring path display. incl. machine feet and operating instructions *

Condition: used, Technical details: grinding wheel diameter: 240 mm saw blade diameter: 600 mm Nsdpfx Aeu Ng Edjkuswg total power requirement: 1,1 + (0,37 kW) kW weight of the machine approx.: 600 kg Saw Blade Sharpening Machine Machine performs grinding process automatically saw blade continue to move automatically grinding wheel diameter: max.: 240 mm driving motor for feed (0,37 KW) *

Condition: used, Technical details: table length: 2000 mm Nwsdou N D Szepfx Akusg table width: 1800 mm table load: 12,5 t table adjustment - longitudinal: 1250 mm table rotating: 360 ° table positioning: 4x90 ° feeds - longitudinal: 0,63 - 2.000 mm/U total power requirement: 6 kW weight of the machine ca.: 7,6 t machine dimensions LxWxH: 3,82 x 2,25 x 0,92 m Rotary table conventional *

Condition: used, Technical details: pressure: 25 t stroke: 500 mm daylight dimension : table/slide up: 800 mm throat: 360 mm ram stroke: 500 mm ram speed - forward: 0,100 m/s ram speed - reverse: 0,45 m/s Table dimensions: 630 x 500 x 75 mm passage inside table: Ø 180 mm surface area of ram: 450 x 360 mm Nodpfevc Awxjx Akujwg mortise hole in ram: Ø 32 mm height over floor: 710 mm total power requirement: 8,75 kW weight of the machine ca.: 2,2 t dimension machine xH: 1,7 x 1,1 x 2,95 m Operation via two-hand control panel. (and one-hand operation) *

Condition: used, Technical details: turning diameter over bed: 350 mm turning diameter over support: 200 mm turning length: 560 mm centre height: 170 mm spindle bore: Ø 32 mm range of revolution per miute: 36...1.800 / 8 step U/min Nodpsvadd Iefx Akuswg range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Working stroke longitudinal support=580mm; plan support=170mm; top support 130mm; -Workpiece support via 3-jaw chuck Niles Ø 160mm, speed 2,800 rpm. -Tool holder quick change steel holder Multifix. Equipment: Cooling water pump 4 pieces machine feet Copying device *

Condition: used, Technical details: table length: 870 mm table height: 420 mm table width: 680 mm Nsdpfx Asu N Dgxskuswg weight of the machine ca.: auf Anfrage t dimensions L x W x H: 0,91 x 0,71 x 0,42 mit Untergestell m Central hole Ø 180mm T-groove in accordance with DIN 650: a=22mm; h=38mm; b=40mm; c=16mm with foot support *

Condition: used, Technical details: table length: 3600 mm table width: 3600 mm table load: 50 t table travel: 2000 längs / longitudinal mm table height over floor: 1350 mm Nwodpfx Asu N D Rqokuog table speed: ca. 1000 mm/min table rotating: 360 ° total power requirement: 14 kW weight of the machine ca.: 38,5 t dimension machine xH: 5,5x3,7x1,4 m space requirements of the machine approx.: 6,2x3,7x1,4 m Main areas of application: -Multi-sided machining -Supplement for travelling column milling machines or boring mills Electric and mechanics of the Rotary Table have been overhauled. - newly equipped with a digital measuring system (DRO) for x-travel and rotation - control via control panel - table clamping plate 14t weight - table load capacity 50t 11 pcs T-slots according DIN 650: - a=42mm - h=75mm - b=70mm - c=31mm Rotary Table can be inspected under power! Following work has been proceeded: - Integration of a Digital Read Out (DRO) for the x axis and a rotary encoder for C-axis - integration of a control via a control panel - renewal of hydraulic pipes / hoses, screw connections, manometers, flow chokes and filters - bearing of both axis transmissions - control cabinet and complete machine cabling has been renewed - end positions cleaned, checked, adjusted and defective replaced by new ones - frequency converter for continuous speed retrofitted - preparation of the necessary documentation (operating instructions, electrical and hydraulic diagram) - cracked gearbox housing repaired via casting lock - renewal of the guideway wipers - processing of the guideway cover including new wipers - machine has been repainted - renewal of axis drives - feed gear cleaned and resealed - feed motor new bearing installed *

Condition: used, Technical details: floor-plate length: 3880 mm Nwsdsu Nkl Iepfx Akujg plate width: 1390 mm plate height: 300 mm number of T-slots: 4 Stück weight of the machine ca.: 3,2 t space requirements of the machine approx.: L:3,7xB:1,4xH:0,3 m dimensions L x W x H: 3,7 x 1,4 x 0,3 m distance of t-slots=250mm T-slot size: a=28mm b=50mm c=24mm h=52mm *

Condition: used, Year of construction: 2004, Technical details: table length: 4000 mm table width: 2000 mm Max. sheet thickness: 100 mm table height over floor: ca. 860 mm total wight: 5,6 + 0,5 t dimensions LxWxH: 4,0 x 2,2 x 0,1 m Njdpfx Akju Nkxuouswg Welding table / Pricing 0.50 EUR/kg with substructure and 6 base stands *

Condition: used, Technical details: table length: 500 mm table width: 300 mm width:: 500 depth: 300 mm height: 400 mm dimension L-W-H: 500 x 300 x 400 mm Njdpfxowbhdmj Akuswg weight: ca. 55 kg with slotted holes Cast steel material Surface finished *

Condition: used, Technical details: floor-plate length: 4600 mm plate width: 1450 mm plate height: 300 mm Plate thickness: 300 mm weight of the machine ca.: 7,2 / Platte t 2 clamping plates ( price per plate) Material cast steel Finished surface T-slots according to DIN 650: Nwjdpswtctgefx Akueg a=40; h=66; b=71; c=29 mm Center stand 300mm 6x through holes Ø 41.0 mm *

Condition: used, Technical details: z-travel: 400 mm range of revolution per miute: max. 3.000 / steples U/min feed continuous: keine Angaben Nedev A S Efepfx Akujwg quill stroke vertical: 100 mm spindle taper: MK2 table surface area: 445 x 315 mm distance table - lower edge spindle: max. 520 mm table travel: längs: 250 mm table travel: quer: 330 mm table height over floor: 920 mm total power requirement: 1,6 kW weight of the machine ca.: 1500 kg machine dimensions LxWxH: 1,3 x 1,1 x 2,0 m Application: Milling and drilling slotted holes There is a precision dial gauge for depth display on the drill spindle head. 5x T-slots to DIN 650: a=10; h=18; b=18; c=8mm Features: Two-way digital ACU-RIDE display *

Condition: used, Technical details: z-travel: 1250 mm swing diameter over bed: 260 mm workpiece dia. over bed: 500 mm workpiece dia. over support: 250 mm center height over bed: 260 mm hobbing length: 2000 mm module max. : 8 / 12 total power requirement: 9,5 kW weight of the machine ca.: 3,8 t Nwjdpfx Ajv U Un Hokujg

Condition: used, Technical details: pressure: 100 t daylight dimension : table/slide up: 800 mm throat: 360 mm ram stroke: 500 mm ram speed - forward: 200 m/s ram speed - reverse: 200 m/s Table dimensions: 750 x 560 x 90 mm passage inside table: Ø 26 mm Nwsdpfx Akjvc Ax Nousg clamping surface ram: BxT: 530 x 400 mm mortise hole in ram: Ø 50 mm cylinder diameter: Ø 250 mm height over floor: 720 mm total power requirement: 17,0 kW weight of the machine ca.: 5,5 t dimension machine xH: 1,8 x 1,2 x 3,2 m

Condition: used, Technical details: table length: 2000 mm table width: 1800 mm table load: 12,5 t table adjustment - longitudinal: 1250/1400 mm table rotating: 360 motorisch ° table positioning: 4x90 ° Nwedju N Ebdopfx Akujg feeds - longitudinal: 0,63 - 2.000 mm/min. height over floor: 920 mm voltage: 380 V total power requirement: 6 kW weight of the machine ca.: 7,6 t machine dimensions LxWxH: 3,8 x 2,25 x 0,95 m Rotary table conventional Bohrwerkstisch konventionell, Bedienung über Schalttafel T-Nuten nach DIN 650: a=28mm; h=49mm; b=52mm; c=21mm *

Condition: used, Year of construction: 1989, Technical details: table length: 1600 mm table width: 920 mm height over floor: 200 mm weight of the machine ca.: 0,69 t Clamping table with 4x through holes Ø 22 mm Material cast steel Nsdpju N Ebqefx Akuowg T-slot according to DIN 650: T-slot spacing 250mm T-slot outer spacing (right and left) 120 mm a=22; h=38.5; b=40; c=18 mm T-slot length = 1380 mm *

Condition: used, Technical details: width: 190 mm depth: 200 mm Nwsdpfx Aju N Ecbekusg height: 335 mm weight of the machine ca.: 29 kg

Condition: used, Technical details: pressure: 160 t throat: 760 mm slide stroke: 32...140 mm distance between table / ram: 400 mm ram adjustment: 100 mm no. of strokes: 50 Hub/min table:: 760x1000x95 Njdpou Nfhqofx Akuewg passage opening in table: 400x350 mm clamping surface ram: 630x850 mm clamping plate: 760x1010x92 mm total power requirement: 15 kW weight of the machine ca.: 6,2 t dimension machine xH: 2,9x1,2x3,4 m dimensions electric cabinet LxWxH: 0,8x0,45x2,1 m - via two hand control - copy of documents digital available Machine can be demonstrated under power. *

Condition: used, Year of construction: 1960, Technical details: pressure: 10 t throat: 255 mm max. ram stroke: 400 mm ram speed - reverse: 0,180 m/sec. m/sec. Njdpfxou Nfuds Akuewg ram speed - forward: 0,080 m/sec. m/sec daylight dimension : table/slide up: 630 mm daylight dimension : table/slide low: 230 mm table clamping surface:: 420 x 400 mm passage opening in table: 220 mm surface area of ram: 200 x 200 x 65 mm total power requirement: 1,6 kW weight of the machine ca.: 1,1 t dimension machine xH: 1,1 x 0,5 x 2,1 m

Condition: used, Technical details: faceplate diameter: 500 mm width: 100 mm Nedpfx Akju Nk Hfeuowg boring diameter: 90 mm total power requirement: - kW weight of the machine ca.: 0,07 t face slide with 4 clamping chucks (clamping travel 60mm) clamping area internal: 145-500mm and external 140-420mm flange intake size= dia. 200mm with clamping bolts equipment: socket wrench *
