Used Bomac Parallel Lathe for sale (6,172)

Condition: used, Technical details: turning diameter over bed: 350 mm turning diameter over support: 200 mm turning length: 560 mm centre height: 170 mm spindle bore: Ø 32 mm range of revolution per miute: 36...1.800 / 8 step U/min range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Working stroke longitudinal support=580mm; plan support=170mm; top support 130mm; -Workpiece support via 3-jaw chuck Niles Ø 160mm, speed 2,800 rpm. Nedpfx Akevadd Ieusct -Tool holder quick change steel holder Multifix. Equipment: Cooling water pump 4 pieces machine feet Copying device *

Condition: used, Year of construction: 2010, Technical details: spindle passage: 92 mm turning length: 1000 mm z-axis: min.: 404 mm z-axis: max. 1130 mm facing movement (x-axis): min./max.:15 / 335 mm control: Sinumerik SL840D max. torque on the spindle: 2500 Nm tool turret: 12 tools axial operating pressure: 6,0 bar rapid traverse: 20 m/min total power requirement: 88 kVA dimension machine xH: ca. 4,45 x m dimensions of the bar loader L-W-H: ca. L: 5,7 x B: 2,65 x H: 2,4 m CNC lathe with bar loader - inclined bed lathe -SL 840D control with NCU software 2.6, system software 1.4, store turn software 6.4, with one orientable C-axis, without driven tools -KNCS 260-72 chuck, SMW Autoblok -Clamping force generator via clamping cylinder VNK-200/86 / SMW Autoblok -Measuring system Fa. Heidenhain -Sauter VDI50 tool disk turret, electric drive Bar loaderMaster 80HF, type 33LL: -Dimension round material min./max.: Ø 20mm / 80mm -Minimum length of the workpiece: 33-38-43 to 1000mm -Maximum length of the workpiece: 33 - 3300mm / 38 - 3800mm / 43 - 4300mm -Feed speed (adjustable) 150mm/sec. - Return speed (adjustable) 950mm/sec. -max. offcut length: Ø 8+65mm = 400mm / Ø 66+80mm = 250mm -min. remnant 120mm Chip conveyor / hinged belt from Richter, type SP 450/63 -Discharge height = 1000mm, discharge side right Accessories: -div. tool holders VDI 50 -sizing adapter SK50-> VDI 50 -Power chuck Hainbuch Toplus Kombi Ax-zug GR100 Ncsdewf Nrajpfx Akuot -div. sleeves, guide jaws for bar loader Ø 20 - 75mm i.D. *

Condition: used, Year of construction: 1998, Technical details: Njdpfxeu Ngcio Akuoct internal diameter: 63 mm swing diameter: 320 - 800 mm grinding depth: 380 mm total power requirement: ca. 1,1 kW feed:: 0,05 - 0,40 mm/U / 8 step U/min weight approx.: 1060 kg dimension machine xH: 1,1 x 1,1 x 1,4 m Brake Drum Grinding Machine - turning Ø max./min.: 800 / 320mm - brake drum holder: 63mm, quill stroke 120mm - turning support: longitudinal travel 380mm; transverse travel 200mm - steel holder holder: 180 x 140mm, steel holder 58mm, turning tool for insert holder 20 x 20mm - operation via control panel *

Condition: used, Year of construction: 2014, Technical details: turning diameter over bed: 660 mm turning dia. over face-slide: 460 mm turning length: 1650 mm centre distance: ca. 2200 mm swing over bed: 660 mm swing diameter over slide rest: 460 mm swing diameter: in Kröpfung: 960 mm centre height: 320 mm control: Siemens 828 D ShopTurn x-axis: ca. 350 (plan) mm spindle bore: Ø 105 mm range of revolution per miute: 26-224 / 225-670 / 671-2.000 stufenlos U/min feed continuous: X: 0,5 - 3.000 mm/min feed continuous: Z: 1 - 3.000 rapid traverse x + z axis: 6 m/min tailstock taper MT: MK 6 quill stroke: 300 mm total power requirement: ca. 23 kW dimension machine xH: 4,2 x 2,3 x 2,3 m dimension swarf conveyor LxWxH: 2,3 x 1,7 x 1,3 m Chip conveyor includes cooling water tank with pump 3-speed manual gearbox with electronic gear shifting Ncedpfju Ix Nrsx Akujt Tool holder according to/with Silent Tool Technology equipped (Capto C6) Manual control unit Foot switch Control panel Hydraulics automatic door closing (pneumatic) Accessories see comparable in the photo. *

Condition: used, Year of construction: 1998, Technical details: turning diameter over bed: 600 mm turning diameter over support: 400 mm turning length: 2000 mm center height over support: 300 mm centre distance: 1600 mm Ncodpfow Rkt Iex Akujt revolution per minute: 3 - 2.500 U/min tailstock taper MT: MK 5 spindle bore of work spindle: 62 mm quill stroke: 190 mm longitudinal feeds:: ca.0,001-10 einstellbar mm/U cross feed: ca. 0,001-5 einstellbar mm/U Rapid feed X axis: bis zu 5000 m/min. total power requirement: 40 KVA weight of the machine ca.: 5,6 t dimension machine xH: 4,0 x 2,0 x 1,9 m incl. accessories see picture *

Condition: used, Year of construction: 2000, Technical details: turning diameter over bed: 340 mm Nsdpfx Aksylt Nzsuoct turning dia. over face-slide: 158 mm turning length: 300 mm facing movement (x-axis): 300 mm longitudinal traverse (z-axis): 300 mm control: Siemens 810T revolution per minute: 60 - 4.000 U/min max. torque on the spindle: 106 - 145 Nm external spindle dia. in forward position: 80 mm feed motor: 8500 N rapid motion - x-axis: 6 m/min tool turret - number of stations: 8 tailstock adjustment: 120 mm Main spindle capacity: 11/15 kW electrics - voltage/frequency: 380/50 V/Hz total power requirement: 20 KVA

Condition: used, Year of construction: 1997, Technical details: turning diameter over bed: 550/500 mm turning dia. over face-slide: 290 mm Ncsdpoyya H Djfx Akuot turning length: 1500 mm turning diameter over support: 290 mm centre distance: 1500 mm spindle passage: 68-70 mm control: Fanuc/Siemens range of revolution per miute: 3 - 2800 U/min tailstock quill stroke: 160 mm Weight approx.: 3,3 t dimension machine xH: 3,33 x 1,55 x 1,79 m Multiflex quick-change holder size C *

Condition: used, Technical details: turning diameter over bed: 460 mm turning diameter over support: 350 mm turning length: 1500 mm centre height: 250 mm Ncedpjwa Nwfefx Akuet spindle bore of work spindle: 52 mm range of revolution per miute: 35 -1800 U/min tailstock quill adjustment:: 230 mm tailstock taper MT: MK4 weight of the machine ca.: 2,7 t dimension machine xH: 2,88 x 1,2 x 1,5 m Coolant pump with feed to manual valve Accessories: Steady rest D=130mm closed 3 Jaw chuck D=315mm from Forkhardt F315 *

Condition: used, Year of construction: 1975, Technical details: faceplate diameter: 3150 mm working area: Ø 4000 mm centre distance: 8000 mm center height: 2240 mm spindle bore: 100 mm revolution per minute: 1,4 ... 71 U/min max. torque on the spindle: 6300 kpm / ca. 61.781 Nm kpm / Nm feed range: plan+längs: 0,355 ... 31,5 / 14 step / R20/3 mm/min rapid traverse speed: 2,0 m/min tailstock quill taper MT: Größe 100 tailstock travel: 400 mm max. workpiece weight between centres: 20.000 kg max. workpiece weight -without tailstock: 8.000 kg main drive motor: 34 kW Nodpovbhiqsfx Akujct weight of the machine ca.: 44,1 t space requirements approx. LxWxH: 8,0 x 4,7 x 2,72 m Delivery consists of the following components: Headstock with faceplate and main drive 2x support Tailstock Plate fields (3x3.0 meters in a row and 4 additional plate fields) 1x steady rest Ø approx. 350mm 1x steady rest Ø approx. 650mm Support travel (large) X=550mm and X0=220mm / Z=2600mm and Z0=400mm Support travel (small) X=170mm and Z=340mm i.D. *

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, CAZENEUVE lathe with OPTIMAX 590 control system, manufactured in 2005. CNC NUM control. Diameter over bed: 583 mm. Distance between centers: 1800 mm. Diameter over cross slide: 300 mm. Spindle bore: 82 mm. Speed: 2500 rpm - 22 kW. MULTIFIX turret. Nsdpfx Aksy T R Npjujct

Condition: good (used), functionality: fully functional, !!!ON-SITE SALE, D-74219 MÖCKMÜHL!!! 2-axis CNC turning machine NAKAMURA SUPERTURN ST-2 with automatic tailstock Control system: Fanuc Nsdpoy Ucidofx Akuect Machine is fully functional.

Condition: good (used), Working area Maximum turning diameter 400 mm Maximum turning length 5000 mm Swinging diameter over bed 840 mm Swinging diameter over carriage 530 mm Spindle speed 14.6 – 1250 rpm Drive power 18.5 kW Dimensions 8.0 × 1.9 × 1.7 m Ncsdpfsy Ug U Djx Akust Weight approx. 6.3 – 8.2 t

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Number of counter-spindles : 1 SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 8.5/15 [kW] NUMERICAL AXES - Slide unit 1.1 : X and Z axes controlled by NC - Slide unit 1.2 : X and Z axes controlled by NC - Slide unit 2.1 : X and Z axes controlled by NC - Slide unit 2.2 : X and Z axes controlled by NC - Slide unit 3.1 : X and Z axes controlled by NC - Slide unit 3.2 : X and Z axes controlled by NC - Slide unit 4.1 : X and Z axes controlled by NC - Slide unit 4.2 : X and Z axes controlled by NC - Slide unit 5.1 : X and Z axes controlled by NC - Slide unit 5.2 : X and Z axes controlled by NC - Slide unit 6.1 : Z axis controlled by NC - Slide unit 6.2 : X and Z axes controlled by NC Ncedpfxjyzi Umj Akuot POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 77 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3329 x 2032 [mm] - Machine height : 2654 [mm] - Machine weight : 7100 [kg] MACHINE HOURS - Number of hours under power : 36508 [h] - Number of working hours : 26721 [h] - Number of spindle hours : 20860 [h] EQUIPMENT - CNC : Siemens 840D SL - Double NCU - Cutting force monitoring: ARTIS - Chips conveyor - Coolant tank * with high-pressure pump : 80 [bars] - Bar loader : IEMCA SIR mS22P/33 - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: excellent (used), Year of construction: 2017, XYZ SLX555 x 3m ProtoTRAK Control Gap Bed Centre Lathe ProtoTRAK SLX Control (2017) Max. Distance Between Centres 3000mm Max. Swing over Bed 560mm Max. Swing over Gap 935mm Max. Swing over Cross slides 350mm Max. Cross slide Travel 290mm Spindle Nose D1-11 Spindle Bore 104mm Spindle Speeds 30 – 1800rpm Spindle Motor 15Hp Quick Change Tool Post Tailstock MT7 Tailstock Dia’ 75mm Tailstock Travel 160m Nsdpfx Ajy R Rdhskusct Manufactured | 2012 Dimensions: L x D x H 5220 x 2150 x 1950 mm Weight 7400 kg Supplied with: 3 Jaw Chuck Indexing Toolpost Machine Handbooks TRAKing®. Constant Surface Speed. Rapid Traverse with Joy Stick. 3 Point Fixed Steady Travelling Steady Interlocking Guards Auto Lubrication. Coolant. Worklight We can offer delivery & installation, operator training and warranties. *For sale with Jet Machinery Ltd* Jet Machinery Stock No: #79001 Machine Serial Number: SLM00072 £55,000.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 2006, control Heidenhain greates pass round over bed 280 mm swing diameter over face slide 140 mm centre distance 500 mm x-axis 200 mm spindle tunring speed 10 - 5.000 U/min In our estimation, the machine is in good used condition and can be inspected under power by appointment. Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale! Nedpfx Ajy T Scdskuoct

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, machine/vehicle number: 21KX287100001, turning length: 135 mm, turning diameter: 120 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 4,500 rpm, number of spindles: 2, number of tool turrets: 2, Equipment: documentation/manual, MW120GT, year of manufacture 2021 – Dual-gantry loader. The machine is powered on and in production. Technically well maintained. Price: negotiable. On-site inspection possible by appointment. Sold from its current location. If you are interested or would like more photos/details, please contact us. Ncodpfx Aksy T Ilhoust

Condition: excellent (used), turning diameter over cross slide: 300 mm, turning length: 510 mm, Model: 2100 LYB Control: Fanuc i Series Year: 2019 Turning Diameter: 300mm Turning Length: 510mm ‘X’ Axis Travel: 205mm ‘Y’ Axis Travel: 105mm ‘Z’ Axis Travel: 560mm Njdpey N Uqijfx Akujct Spindle Speed: 4500 RPM Spindle Power: 15KW Spindle Torque: 169N-M Machine With: 200mm Power Chuck Driven Tools (1-AxiaL -1- Radial) Tool Eye Parts Catcher Filtermist Dimensions: 2880 x 1711 x 1921 High Weight: 3900 Kgs

Condition: excellent (used), Year of construction: 1997, turning diameter over cross slide: 210 mm, spindle bore: 40 mm, turning diameter: 330 mm, turning diameter over bed slide: 330 mm, turning diameter over top slide: 210 mm, Model: Student 2500 Gap Bed Lathe Swing Over Bed: 330mm Swing Over Topslide: 210mm Swing In Gap: 480mm Distance Between Centres: 1000mm Spindle Speeds: 40-2500 RPM Spindle Bore: 40mm Nsdjy N Uplopfx Akujct Motor: 2.2 KW Machine with: 3 Jaw Chuck Collet Chuck and Collets Digital Readout Quick Change Toolpost with Holders Dimensions: 2130 x 1020 x 1450mm High Weight: 800 KGS

Condition: excellent (used), turning length: 635 mm, turning diameter: 330 mm, spindle bore: 38 mm, spindle speed (max.): 2,400 rpm, spindle speed (min.): 40 rpm, turning diameter over bed slide: 210 mm, Model: M300 Swing Over Bed: 330mm Swing Over Top Slide: 210mm Swing In Gap: 480mm Distance Between Centres: 635mm Spindle Speeds: 40-2400 RPM Spindle Bore: 38mm Motor: 2.2 KW Machine with: 3 Jaw Chuck Njdpoy N Unnjfx Akuoct 4 Jaw Chuck 2 Axis Digital Readout Coolant Light Chuck Guard Quick Change Toolpost with Holders Dimensions: 1700 x 900 x 1470mm High Weight: 600 KGS

Condition: excellent (used), Year of construction: 1998, turning diameter over cross slide: 270 mm, turning length: 1,500 mm, turning diameter: 460 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 20 rpm, Model: Alpha 460 Plus Year: 1998 Control: Fanuc GE Ncsdpfey N Ulmox Akuet Swing Over Bed: 460mm (18 ½ ”) Distance between Centres: 1500mm (60”) Swing Over Top Slide: 270mm (10.8”) Spindle Speeds: 20 – 2000 RPM Machine With: 3 – Jaw Chuck 4 – jaw Chuck Fixed Steady Quick change Toolpost Coolant Pump and Fittings

Condition: excellent (used), Year of construction: 2007, operating hours: 1,000 h, functionality: fully functional, turning diameter over cross slide: 196 mm, spindle bore: 42 mm, turning diameter: 350 mm, turning diameter over bed slide: 350 mm, turning diameter over top slide: 196 mm, center height: 175 mm, turning length: 650 mm, Model: Multiturn 1000 Control: Fanuc Oi-TC Year: 2007 S/No.: N91013 Swing Over Bed: 350mm Njdpfx Asy N Uk Nekusct Swing In Gap: 535mm Swing Over Top Slide: 196mm Distance Between Centres: 650mm Spindle Speeds: 1-3500 RPM (3 Ranges) Spindle Bore: 42mm Motor: 7.5 KW Machine with: 150mm 3 Jaw Chuck Duplumatic 8 Station Turret Turret Tool Holders Tail Stock Coolant Pump

Condition: used, Year of construction: 1969, turning diameter over bed 500 mm turning diameter over slide rest 330 mm turning diameter in the gap 600 mm turning length 3000 mm bed width 505 mm spindle bore 72 mm spindle head DIN 55022 Gr. 8 Nedpfxsy Tyy De Akujct taper in tailstock MK 5 turning speed range 22,4- 1120 U/min power requirement 18,5 kW dimensions 5,3 x 1,75 x 1,53 m weight of the machine ca. 5,2 t used lathe in nice condition with digital scale - 2 axis digital scale - 4 jaw chuck Ø 250 mm - 3 jaw chuck Ø 260 mm - Multifix "C" toolholder system - some toolholders - steady

Condition: used, Year of construction: 1963, turning diameter over bed 390 mm turning diameter over slide rest 190 mm turning length 1000 mm turning dia. in gap 460 mm spindle head DIN 55026 Gr. 6 spindle bore 52 mm turning speed range 11,2 - 2240 U/min power requirement 7,5 kW bed width 355 mm dimensions 2,8 x 1,3 x 1,6 m weight of the machine ca. 1,9 t Equipment: Njdpfx Akjy Tyyqousct - Multifix "B" with 5 pic. toolholders - 3-jaw-chuck Ø 250 - coolantsystem - 2-axis digital readout Heidenhain - some jaws

Condition: good (used), 1999 MURATEC MT12 CNC lathe. Ncodpfx Ajy Ta Stokuet

Condition: good (used), Year of construction: 1999, 1 CNC lathe, MT12 model, manufactured by MURATEC in 1999, including: 1 STAUBLI RX90 robot. Nodpfjy Ta Sgsx Akusct
