Used Foradia Radial Drilling Machine for sale (67,417)

Condition: good (used), Alzmetall AC 32 Turret Double-Head Drilling Machine An extremely robust and rare double-head drilling machine based on two Alzmetall AC 32 drilling head units. This machine is a high-quality industrial design intended for highly efficient series or multi-stage machining. Instead of simple spindles, this machine is equipped with two separate tool turrets. This enables fully automatic machining cycles (e.g., centering, drilling, countersinking, threading) without the need for manual tool changes. Technical data & equipment (per head / overall machine): Manufacturer of drilling head units: Alzmetall (Germany) Model: AC 32 (Electronically controlled with digital display) Drilling capacity: max. 32 mm in steel Threading capacity: max. M 24 / M 30 Tool changer: 2 x pivoting turrets with multiple stations Machine table: Solid, ground cast iron table with T-slots for flexible setup Godpfx Aeznic Uefujbu Safety: Complete enclosure of the working area (protective cabin) with viewing windows for optimal chip and splash protection Additional functions: Integrated coolant system, compressed air blow-off gun, central counterweight system for easy vertical adjustment of the entire beam More items – new and used – can be found in our shop! International shipping costs on request!

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 50 mm arm length 1250 mm workpiece height max. ca. 1150 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 25 - 2000 U/min Godpfevh Nbhex Afusbu feeds 0,06 - 0,5 mm/U crossrail adjustment vertical 620 mm column diameter 350 mm total power requirement 7,5 kW weight of the machine ca. 4,6 t dimensions of machine L x W x H 2,50 x 1,08 x 2,50 m Accessories: box table 1100 x 700 x 550 mm, coolant pump

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 32 mm arm length 1000 mm workpiece height max. 1400 mm total power requirement 6 kW Gbodjt H Smyjpfx Afuou weight of the machine ca. 3.700 kg dimensions of the machine ca. m

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm Gbedpfodkx Anjx Afuou - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Condition: well-maintained Features and technical specifications: Gbedpfx Afezk Nuisuou - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: from below & from the front - Swivel range: 0–90 degrees via handwheel - Pneumatic workpiece clamps: 3 pcs. - Passage dimensions: max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see images) Availability: at short notice Storage location: Röllbach

Condition: good (used), Mikron WF 41C CNC Universal Milling and Drilling Machine Professional, extremely robust CNC universal milling and drilling machine MIKRON WF 41C Due to its stable design, the machine is ideal for workshops, prototype construction, maintenance, or demanding toolmaking. The machine is equipped with the proven HEIDENHAIN TNC 155 path control system. Thanks to its clear-text dialogue guidance, it can be programmed extremely easily directly on the machine, supports graphic simulations, and allows easy loading of external CNC programs via the serial interface (ideal for CAD/CAM applications). Gsdozcqf Iepfx Afuebu Technical data at a glance CNC control Model: HEIDENHAIN TNC 155 Operating modes: Manual operation (like digital display), positioning with manual input, single block, sequence of blocks, program test (graphic simulation) Interface: V.24 / RS-232-C for data transfer Feed drives & travels Travel in X-axis (table longitudinal, automatic): 630 mm Travel in Y-axis (spindle carriage transverse, automatic): 500 mm Travel in Z-axis (table vertical, automatic): 460 mm (p. 1) Feed rate: continuously adjustable from 1 – 3000 mm/min in all 3 axes Rapid traverse rate: X and Y axes: 6000 mm/min | Z axis: 4000 mm/min Max. vertical installation height: 559 mm (between vertical milling head and rotary table) Milling spindle drive Working spindle speeds: 21 gear stages Speed range: 31.5 – 3150 rpm Spindle motor power: 6.0 / 8.0 kW Tool holder: ISO 40 / M 16 with draw-in groove (SK 40 DIN 2080) Arbor movement (vertical): 90 mm Table geometry & workpiece capacity Rotary table clamping surface: 500 x 1000 mm T-slots: 7 pieces (distance: 63 mm, width: 14-H7 mm) Clamping surface perpendicular: 397 x 550 mm (with 4 x 4 threaded holes M16, distance 90 mm) Max. recommended workpiece weight: 500 kg Electrical system & cooling Electrical connection power: 13.5 kW Coolant tank volume: approx. 100 liters Dimensions & weights Net machine dimensions: 1745 mm (L) x 1501 mm (W) x 2124 mm (H) Max. space requirement during operation (including control console): 2930 mm (L) x 2115 mm (W) x 2125 mm (H) Machine weight (net): 3100 kg (including vertical milling head and rotary table) Product video “Everything from one source: We would be happy to offer you a suitable bank financing option for your project.” More articles - new and used - can be found in our shop! International shipping costs on request!

Condition: good (used), Mikron WF31D Precision Milling and Drilling Machine Machine with chip and splash guard enclosure Equipped with a Heidenhain TNC355 control system Technical Specifications The WF 31 D is a precision milling and drilling machine for series production and CNC training. Drive via an automatically switchable stepped gearbox and Poly-V belt. Vertical spindle can be extended by 90 mm; conversion from vertical to horizontal machining is possible. Ball screws with DC drives enable simultaneous feed movements. Guides are protected against dust, chips and coolant. Technical Data Manufacturer: Mikron Type WF31D Control system: Heidenhain TNC 355 Longitudinal movement (X): 560 mm Transverse movement (Y): 500 mm Vertical movement (Z): 400 mm Drive power: 3.3/4.0 kW Speed range: 40-4000 rpm Feed rate: 2-3000 mm/min Rapid traverse rate X/Y: 6000 mm/min, Z: 5000 mm/min Electrical Equipment Total installed rated power: 10.0 kW Installed useful power: 7.3 kW Operating voltage: 3 x 380 V - 50/60 Hz Protection class: IP 54 Max. permissible ambient temperature: +35 °C Relative humidity: 75 %. Dimensions and Weights Width: 2450 mm Length: 2800 mm Height: 2000 mm Net weight of the machine: approx. 2570 kg. Heidenhain TNC355 Operating Manual Heidenhain TNC355 Programming Examples Gedpfswiucfjx Afuobu Heidenhain TNC 355 Service Manual More items - new and used - can be found in our shop! International shipping costs available upon request!

Year of construction: 1963, condition: used, Radial drilling machine, drilling machine, boom drilling machine, universal drilling machine, milling machine -Projection: 645 mm -Taper mount: MK3 -Speeds: 95 - 1050 rpm -Columns: Ø 190 mm Gbsdpfx Afjdvnbxsuou -Spindle stroke: 195 mm -automatic feed: 0.05/0.10/0.20 mm/rev -Clamping table: 735 x 520 mm -Dimensions: 1350/705/H2170 mm -Weight: 1100 kg

Condition: not inspected (used), Year of construction: 1970, - Drilling diameter: 5-30 mm Gedpsxzz Hjfx Afujbu - Drilling depth: 750 mm - Filter - Pump

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Gbjdpfx Aertrx Rsfueu Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: used, Year of construction: 1998, Number of spindles in the hole row: 11 Number of horizontal spindles: 3 Pot-band drilling head: yes, Hettich Drill spacing: 32mm Power consumption: 2.2kW Godpfjz I Ivdox Afusbu Drilling unit: swiveling

Condition: as good as new (ex-display), Year of construction: 2013, machine/vehicle number: F130507, functionality: fully functional, input voltage: 400 V, spindle mount: MK 3, drilling depth: 135 mm, height adjustment type: mechanical, total width: 510 mm, total length: 870 mm, total height: 2,050 mm, throat depth: 320 mm, table width: 450 mm, table length: 500 mm, drilling capacity: 30 mm, column diameter: 120 mm, spindle speed (max.): 2,600 rpm, spindle speed (min.): 65 rpm, Dear Sir or Madam, We are offering a demonstration pillar drill "HXMC model Z5030A" with paint damage. We are happy to answer any questions. Gbsdpfxov T Atns Afusu This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Please check the information in the PDF. No returns accepted.

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 39200 € 748.72 € 50 mm MK 5 350 - 1.600 mm 56 - 1.450 (12) U/min Stahl/Guß: M40/M50 2670 mm 1120 mm 2410 mm Gbjdpfxsynmt Sj Afuju 3300 kg 465 - 1.420 mm 0,06 - 0,2 (3) mm/min 3.7 kW 320 mm 270 mm 2.550 x 970 x 200 mm 1,5 kW 630 x 500 x 500 mm 2760 mm 0,75 kW left/right rotation automatic feed drilling depth limit manual headstock adjustment with hydraulic clamping electric height adjustment of extension arm andhydraulic clamping hydraulicclamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Features and technical specifications: - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: Bottom & end face - Swivel range: 0–90 degrees via handwheel Gbjdszn Ah Rspfx Afusu - Pneumatic workpiece clamps: 3 pcs. - Opening: Max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see pictures) Availability: at short notice Storage location: 63934 Röllbach

Condition: used, Second-hand machine Second-hand Ganner Compact 30 row drilling machine Features and technical specifications: 2 drilling beams, each with 15 spindles Pitch 32 mm Drilling unit position adjustment 0–650 mm Distance between rows of drill holes: at least 190 mm Spindle speed 2800 rpm Gsdpfszk Nwdox Afusbu Motor power 2 x 0.75 kW Maximum workpiece clamping height: 70 mm Working height 850 mm Compressed air connection 6 bar Availability: by arrangement Location: Solingen

Condition: ready for operation (used), functionality: fully functional, Radial braiding machines, radial braider, carbon fiber, RF1-48-120-K Gbedpfxez Iucdj Afusu 4 units in stock.

Condition: good (used), power: 1.1 kW (1.50 HP), overall weight: 200 kg, Prebomat, drilling head for fitting operations, with 7 spindles, in very good condition. Gbodpsz N T Uiofx Afuou

Condition: used, Used Machine Gbodpfxozyy Dye Afueu Features and Technical Specifications: - Fully automatic pneumatic control with control panel - Clamping, drilling, and unclamping; electric intermittent operation - Drilling unit: Number of spindles, pitch 32 mm: 23 Speed: 2,800 rpm Motor power: 1.5 kW/380 V Drill chuck for tools with a 10 mm h6 x 20 shank and flat Adjustment range for position settings: 0–60 mm Drill hole depth for drills with a total length of 57 mm: 0–30 mm Drill hole depth for drills with a total length of 77 mm: 0–50 mm Drill hole depth for drill bits with a total length of 95 mm: 0–70 mm - Passage width: max. 800 mm - Clamping height: max. 80 mm - Working height: 850 mm - Space requirement without stop ruler: 1200 x 900 mm - Compressed air connection: 6 bar - Sound level: less than 82 dB(A) - Weight: approx. 400 kg

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Facom foratrice Through-hole drill f-v3r-2l-3f+2tagr1 used 2015 Brand: Facom foratrice Model: Through-hole drill f-v3r-2l-3f+2tagr1 Description: Through-feed drill F-V3R-2L-3F+2TAGR1 All heads and saws are screw-adjustable with mechanical indicators. Drilling depth is controlled electronically. Minimum workpiece length: 300-350 mm Maximum: 2000 mm Automatic feeder Bsbtt Sov U Uw Ujx Nteda Double-sided cutting with angle adjustment Double-sided drilling with angle setting 3 drill heads top + 2 wheels + 2 rear All heads have angle adjustment Electronic position markers I can send a video via WhatsApp The machine is operational and connected; you can test it 2015 Year: 2015 Gjdpfx Ajx Rd Elofujbu

Condition: good (used), Used horizontal boring mill/drilling machine by Cornac Type BS 65 Spindle diameter 65 mm Gsdpfx Afoz Iarqeuebu Table dimensions approx. 600 x 1000 mm X / Y / Z = 1000 / 800 / 650 mm

Condition: good (used), Year of construction: 1987, travel distance X-axis: 11,500 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 2,000 mm, feed length W-axis: 1,600 mm, x-travel 11,500 mm y-travel 4,500 mm w-axis 1,600 mm Gbjdpfx Aoz Rny Nefueu z-axis 2,000 mm Spindle diameter 200 mm Rotary table 3,000 x 4,000 mm Bed length of rotary table 4,600 mm Tool holder SK50 Workpiece weight on rotary table 80 t Total power requirement 83 kW Additional information incl. 15 plates

Condition: new, Drilling capacity in steel ----- 50 mm Motor ----- 4 kW Speed range ----- 25 ~ 2000 rpm Spindle stroke ----- 315 mm Overhang ----- 350 ~ 1600 mm Spindle taper ----- MK5 Spindle feed ----- 0.04 ~ 3.2 mm/rev Cube table ----- 630 x 500 x 500 mm Column diameter ----- 350 mm Base ----- 2400 x 1000 x 200 mm Maximum distance spindle - base ----- 350 ~ 1220 mm Weight ----- 3500 kg INCLUDED Gsdjga Ty Nopfx Afuobu * Hydraulic clamping system! * Cooling system * CE plug * SCHNEIDER electrical components

Condition: ready for operation (used), functionality: fully functional, ARBOGA UM 3008 / Drilling and Milling Machine -Spindle speeds / 8 stages / 105 - 3020 rpm -Gear / Gear head / Swiveling and tilting -Tool holder MK 3 -Drilling capacity / Steel max. 30mm Gedpfoz Hy Hrox Afujbu -Drilling depth / Quill stroke approx. 130mm -Max. distance - Spindle / Table approx. 600mm -Cross table 585x245mm, adjustable via crank Dimensions: L x W x H 0.9 x 0.8 x 1.9 meters / Weight approx. 600 kg Errors and omissions excepted.

Condition: new, Drilling capacity in steel ----- 40 mm Motor ----- 3 kW Speed range ----- 25 ~ 2000 rpm Spindle travel ----- 315 mm Overhang ----- 300 ~ 1300 mm Spindle taper ----- MK4 Spindle feed ----- 0.04 ~ 3.2 mm/rev Cube table ----- 630 x 500 x 500 mm Column diameter ----- 350 mm Base ----- 2400 x 1000 x 200 mm Maximum distance spindle - base ----- 350 ~ 1250 mm Weight ----- 2500 kg Gbsdpega T Dtsfx Afuju INCLUDED * Cooling system * CE plug * SCHNEIDER electrical components * LED lighting

Condition: as good as new (ex-display), Year of construction: 2013, machine/vehicle number: I1305008, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, spindle mount: MK 3, drilling depth: 130 mm, height adjustment type: mechanical, throat depth: 250 mm, overall weight: 320 kg, drilling capacity: 25 mm, column diameter: 110 mm, spindle speed (max.): 2,880 rpm, spindle speed (min.): 125 rpm, Dear Sir or Madam, We are offering a demonstration pillar drill "HXMC model Z5025" with paint damage. We are happy to answer any questions. Gbedpfx Asv T Anrsfueu This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Please check the information in the PDF. No returns accepted.
