Used Gleason-Hurth Gear Shaving Machine for sale (70,069)

Condition: ready for operation (used), Year of construction: 1981, Stankoimport gear hobbing machine 5K328A Year of manufacture: 1981 Max. diameter of the gear wheel: - with counterbeam: 800 mm - without counterbeam: 1250 mm Max. module: 12 mm Max. width of the gear wheel: 560 mm Min. number of teeth: 20 Helix angle: +/- 60 degrees Table diameter: 935 mm Max. weight on the table: 2000 kg Hob arbor taper: Morse 6 Hob arbor speed range: 32 - 200 RPM Working feeds: - vertical: 0.5 - 5.6 mm/rev - radial: 0.22 - 2.6 mm/rev - tangential: 0.07 - 2.58 mm/rev Hodpfx Anozq Sq Hsyou Main electric motor power: 10 kW Net weight of the machine: 14 tons Change gears, arbors, and support available! Video of the machine in operation available!

Condition: excellent (used), Module range: 0,1 – 2 mm Centre distance range: 25 – 85 mm Vertical stroke of master gear slide: 40 mm Diameter of measured gear, max. (clamped on arbor): 120 mm Diameter of measured gear, max. (clamped between centers): 80 mm Maximum distance between centers for clamping of measured part: 200 mm Weight of measured gear, max.: 0,5 kg Measuring force adjustment, manually adjustable: 0 – 8 N Standard master gear arbor, diameter: 12,7 mm Hedewkgr Iopfx Anyou

Condition: used, Year of construction: 2006, workpiece diameter 5 - 1.000 mm module range 0,2 - 25 helix angle < 90 ° Control Wenzel GearTec faceplate diameter 750 mm x-axis 1.200 mm y-axis 550 mm z-axis 1.000 mm total power requirement 6,5 kW weight of the machine ca. 11 t dimensions of the machine ca. 3,30 x 3,15 x 2,70 m Software: BMain, FPDFPPostAction, GrafTool, TAlign, Hodpfx Anszkvvyoyeu TAnalyse, TApplication, TCali, TCut_INPUT, TCut_MEAS_EVAL, TGear_INPUT, TGear_MEAS_EVAL, THob_INPUT, THob_MEAS_EVAL, TMesblatt, TPlot, TRoot_INPUT, TShaft_INPUT, TShaft_MEAS_EVAL, TStat, TStylus, WMI, wingeco.

Condition: good (used), Year of construction: 1984, max. wheel diameter 250 mm gear width 275 mm max. module 6 weight of the machine ca. 5,5 t Hodev T Nqaspfx Anyeu The gear hobbing machine ZFWZ 250 is suitable for the economical production of all hob-processable cylindrical gear types, such a: - spur and helical gear, wormgears and worms, splined shafts, keyed shafts, serrated profiles, chain wheels and ratchet wheels,as well as conical and crowned spur and helical gears. Interchangeable wheels and milling accessories Technical data: - Workpiece diameter (max): 250 mm - Module (max): 6 mm - Axial feed travel (max): 275 mm - Tangential feed travel (max): 100 mm - Tooth helix angle (max): 45 degrees - Milling cutter diameter (max): 145 mm - Milling cutter length (max): 170 mm - Table clamping surface (min): 195 mm - Table clamping surface (max): 470 mm Power Milling cutter speeds - Stepped in 2 ranges: 56 ... 250 rpm - (Standard version): 90 ... 400 rpm - Infinitely variable in 2 ranges: 63 ... 180 rpm - (special version DC motor): 140 ... 400 rpm Weights - Machine net: approx. 5000 kg - Electrical cabinet: approx. 800 kg - Hydraulic unit + coolant tank + chip transport: approx. 700 kg Overall dimensions (with oil mist filter) - Length: Standard version: 3950 mm DC drive: 3450 mm (or 3350 mm according to table) - Width: 3300 mm - Height: Machine: 1980 mm Machine with DC drive: 2150 mm Electrical cabinet: 2200 mm

Condition: used, Year of construction: 2015, Technical details: Hodpfx Anel Ha Ubsyeu weight of the machine ca.: 4 t

Condition: like new (used), functionality: fully functional, workpiece weight (max.): 3 kg, feed length X-axis: 100 mm, feed length Y-axis: 100 mm, feed length Z-axis: 200 mm, workpiece diameter (max.): 180 mm, milling length: 200 mm, overall weight: 5,000 kg, rotational speed (max.): 3,000 rpm, rotational speed (min.): 400 rpm, tool diameter: 80 mm, Equipment: documentation/manual, rotational speed infinitely variable, This machine is completely dismantled and rebuilt from the ground up. During the overhaul, it undergoes comprehensive modernization with state-of-the-art technology and the latest premium-quality components. Following refurbishment, the machine is presented in a technical and visual condition equivalent to new – reliable, high-performance, and future-proof. Hedpfx Anex Af A Heyju The equipment and configuration can be tailored individually to your requirements, ensuring maximum productivity in your production environment.

Condition: refurbished (used), Year of construction: 2027, functionality: fully functional, wheel width: 200 mm, stroke length: 230 mm, feed length X-axis: 500 mm, type of input current: three-phase, total height: 2,900 mm, table load: 2,750 kg, table diameter: 1,005 mm, overall weight: 12,000 kg, input frequency: 50 Hz, total width: 3,300 mm, total length: 3,800 mm, distance table to spindle center: 640 mm, gear diameter: 1,000 mm, distance table center to spindle nose: 640 mm, workpiece diameter (max.): 1,000 mm, controller manufacturer: Siemens Sinumerik ONE, drive type: Siemens Sinamics S120, control type: CNC control, stroke rate (min.): 15 1/min, stroke rate (max.): 510 1/min, The universal machine for gearings that cannot be milled: The Lorenz LS 1000 CNC machines internal and external toothed spur gears up to 1000 mm in diameter – hollow gears for planetary gearboxes, gear rings, couplings, gears with a flange or chamfer. Completely modernized with Siemens Sinumerik ONE, new electrical system, hydraulics and lubrication, designed for maximum performance and accuracy in flexible manufacturing. Acceptance according to DIN and manufacturer's standards with a protocol. Offered by Serwema Retrofit Solutions, Chemnitz. The LS 1000 was developed as a universal machine for construction machinery, wind turbine and machine tool gearboxes, mining technology, aerospace and textile machines, and is suitable for both single parts, small series and large series. The main application is the hobbing of straight-toothed and – with a helical guide and matching cutting wheel – helical-toothed spur gears with internal or external teeth. With software options, the machine can also process non-circular gears, grooves and cams; with special cutters, couplings as well as involute and spur gears are produced. The Sinumerik ONE with electronic gear unit guides the user through workpiece and tool data using masks, without the need for programming. Hsdoz E H Rnepfx Anyju

Condition: used, Year of construction: 1999, max. wheel diameter 280 mm Hsdpot Hwu Ajfx Anyju gear width 330 mm max. module 5 min. module 1 Control LIEBHERR CNC total power requirement 28 kW weight of the machine ca. 12 t dimensions of the machine ca. m

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 weight of the machine ca.: 15 t table diameter: 180 mm table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 Hodpfoxc E H Ssx Anyju *

Condition: used, Year of construction: 1996, workpiece diameter 240 mm centre distance 0 mm Hodpfx Anjt Hwvmjyeu honing length max. 500 mm max. module 5 total power requirement 12 kW weight of the machine ca. 5000 kg dimensions of the machine ca. m

Condition: used, Year of construction: 1963, Technical details: max. wheel diameter: 900 mm max. module: 10 weight of the machine ca.: 8200 kos. hob dia. - max.: 190 mm cutter length max.: 320 mm Hsdpfovkpu Hjx Anyou milling spindle speeds (infinitely variable): 13-80 U/min workpiece length - max.: 750 mm max. workpiece diameter: 150 mm Counter holder milling mandrel is missing *

Condition: used, Year of construction: 2024, overall weight: 17,000 kg, workpiece length (max.): 500 mm, workpiece height (max.): 1,200 mm, workpiece diameter (max.): 800 mm, MAXIMUM Ø800 PROFILE GRINDING. OPERATIONAL CONDITION. Hsdpfezrzwfjx Anysu

Condition: ready for operation (used), Horizontal gear hobbing machine with master hob, Precimo model HR 3-ND-15. Maximum workpiece diameter: 250 mm. Maximum module: 7. Maximum diameter for module 7: 135 mm. Maximum diameter 250 mm for module 5. Maximum hobbing length: 335 mm. Minimum number of teeth to cut: z6. Maximum distance between centers: 735 mm. Maximum hob speed: 435 rpm. Estimated weight: 3500 kg. Hedey Swl Ujpfx Anyju

Condition: good (used), ø max. Gear 250 with 3" cutter module 5,5 hobbing length 70 cutter module 5,5 outside ø max. Acknowledged 300 mm ø spindle 85 mm ø hole table 39 mm Hodpfx Ajgq Dgdonyju ø table External centering Ø139,75 power tool motor (b) 4 Cv high 1.800 mm long 1.450 mm weight 2.450 Kg width 1.000 mm

Condition: ready for operation (used), Year of construction: 1989, AUTOMATIC GEAR GRINDER – 2 units available Manufacturer: CSEPEL Model: FKA 326-10 THE MACHINE USES THE FASSLER DRESSING METHOD. • Gear diameter: 320 mm • Module range: 0.5 – 6 • Slide stroke: 180 mm • Number of teeth: 10 – 260 Hsdpfxjzxzlio Anyeu • Max. workpiece weight: 80 kg • Clamping length: 420 mm THE MACHINES ARE COMPLETE WITH NUMEROUS ACCESSORIES: GRINDING WHEELS, WHEEL HOLDER, FASSLER DRESSING TOOL, CHANGE GEARS.

Condition: good (used), Gear hobbing machine, milling machine, tool milling machine, vertical milling machine, roller milling machine, gear hobbing machine, gear hobbing machine, high-performance hobbing machine -Manufacturer: Liebherr, high-performance gear hobbing machine type SS 5-K/500 -Working area: Ø max. 500 mm -Max. cutter diameter: 186 mm Accessories: Includes extensive accessories (see photos) -Not included: Template for helical gearing -Machine dimensions: 2300/1460/H1870 mm -Accessory dimensions: Pallets 1420/1300/H300 / 1200/800/300 mm Hsdpfjv Dtmmsx Anyju -Weight: 5300 kg plus 535 kg accessories

Condition: used, max. wheel diameter 600 mm gear width 250 mm max. module 10 min. module 1 weight of the machine ca. 0,9 t Hjdpfez Dk Alsx Anyeu dimensions of the machine ca. 1,8 x 1,4 x 1,4 m 2 brushes. prepared for 2 grinding units.

Condition: excellent (used), max. wheel diameter 5 - 630 mm gear width 500 mm max. module 20 min. module 0,5 workpiece weight 350 kg Control IBH Macro max. workpiece diameter 630 mm clamping length 1050 mm total power requirement 1,8 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 2,0 x 0,7 x 2,4 m Spur gear software for internal and external gearing Profile inspection standard crowning head - root relief K - profile Direction test standard crowning head - root relief K - profile graduation test Hjdpfx Aneyyqtzeyju Axis position correction for on-the-fly measurements up to 0.2 mm axis position error Snail software 3 carriers for gears, 1 carrier block, calibration device, Windows 7

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 180 mm max. module: 5 min. module: 1 weight of the machine ca.: 14 t dimensions of the machine ca.: 4,5 x 2,84 x 2,8 m min. number of teeth: 7 Hedpfx Aswv Ug Renyou toolpiece turning speed range: 4000-10000 U/min tool length: 210 mm With tail stock No dressing device Only CBN *

Condition: excellent (used), Year of construction: 1980, Horizontal gear hobbing and threading machine for gears, splined shafts, worm screws, threads, and pinions up to 5 meters in length, complete with 3 milling heads models APFW, APGS, APG, set of gears, various steadies, and indexing device. Hedpfeyba Rwsx Anyou

Condition: used, Year of construction: 2007, max. wheel diameter 380 mm gear width 540 mm max. module 7 Control SINUMERIK 840 D Axial travel 600 mm table diameter 317 mm table speeds 100 U/min milling head -swivable + / - 35 Grad milling spindle drive 27,00 kW milling spindle speeds (infinitely variable) 1500 U/min diameter of hob 160 mm cutter length max. 330 mm cutter speeds max. 3000 1/min hob dia. - max. 160 mm swarf cutter lenght - max. 330 mm tangential travel max. 300 mm 10.000 mm/min tangential speed max. 3000 mm/min 7.500 mm/min oil volume 100 l Hjdpfx Asyt Rvhonyju coolant capacity 780 l Counterholder movement 540 mm total power requirement 50,00 kW weight of the machine ca. 16,00 t dimensions of the machine ca. 6,00 x 4,50 x H3,50 m for the following processes: axial hobbing, individual part milling, Worm wheel milling, roofing, deburring; NC tailstock

Condition: used, Year of construction: 2003, Control BWO tip circle diameter max. 700 mm Hedpfx Anjxt Ur Seyou root circle diameter min. 50 mm height of profile max. 35 mm number of spindle speeds 0 - 5400 min-1 table load capacity max. 500 kg Overall size 370x220x300 cm Total weight, approx. 15000 kg Number of working hours 94082 h Equipment: BWO control system All axes CNC controlled Oil mist extraction Coolant cleaning system with cooling unit Dittel balancing unit Accessories: Grinding wheels Ø400mm incl. Grinding wheel flanges 1 diamond dressing roller, manufacturer Dr. Kaiser, Ø160mm Counterholder tip Control cabinet: Width 70 cm x length 280 cm x height 220 cm Machine: Width 220 cm x length 370 cm x height 300 cm Coolant system: Width 170 cm x length 240 cm x height 250 cm

Condition: used, Year of construction: 2013, max. wheel diameter 260 mm gear width 320 mm max. module 4,5 min. module 0,5 Control SIN 840D max.helical angle +/- 45 ° total power requirement 68 kW weight of the machine ca. 15,50 t dimensions of the machine ca. 3,25 x 3,25 x 3,30 m Fire extinguishing system Siemens Sinorix TM Knoll Filtering system VL1500/8000 year 2017 Hjdpfx Anox R U Hgjyeu Wekal loading cell

Condition: used, Year of construction: 1989, max. wheel diameter 400 mm gear width 275 mm max. module 6 Overall size 300x310x245 cm weight of the machine ca. 5,0 t Specifications: - Maximum wheel diameter: 400 mm - Min. module: 1 - Max. module: 6 - Table diameter: 370 mm - Maximum wheel diameter: with counter support: 340 mm / without counter strut: 400 mm - Max. axial offset: 275 mm - Max. tangential adjustment: 100 mm - Max. tooth helix angle: 45 degrees - Max. cutter diameter: 145 mm - Max. hob length: 170 mm Performance - Cutter speed: 50-200 rpm - Axial feed continuously adjustable: 0.2-10 mm/rev - Tangential feed continuously adjustable: 0.1-5 mm/rev - Radial for spur gears: 0.1-4 mm/rev - Radial for worm gears: 0.025-1 mm/rev - Rapid traverse axial: 500 mm/min - Rapid traverse tangential: 250 mm/min - Radial for spur gears: 400 mm/rev - Radial for worm gears: 100 mm/rev - Motor power: 7.4 kW Hsdpfxeu A I Els Anyou Gewicht - Machine 5000 kg - Electrical cabinet approx. 800 kg - Hydraulic unit, coolant tank, chip conveyor approx. 700 kg Dimensions - Length with chain drive (normal) 2950 mm with DC drive 3350 mm - Width: 3100 mm - Height Machine: 1980 mm Electrical cabinet approx.: 2200 mm Machine with DC drive approx.: 2150 mm

Condition: used, Year of construction: 2008, max. wheel diameter 700 mm max. module 10 (18) min. module 1 table diameter 530 mm Table speed max. 350 1/min Hodpoyv Ipfefx Anyeu Distance of shafts 50 - 680 0 workpiece weight 4.000 kg Axial travel 1.000 mm tangential adjustment 300 mm pivoting angle + / - 45 Grad power capacity 32 kW spindle turning speed range 3.500 - 12.000 U/min tool diameter 320 mm total power requirement 80 kW weight of the machine ca. 25,00 t
