Used Bacci Bacci Double Machining Center for sale (76,623)

Condition: used, Year of construction: 2006, BACCI DOUBLE is a double head CNC machining center with 10 interpolated axes, numerically controlled, equipped with automatic hopper feeder. DOUBLE is designed for joinery operations as: tenoning, finger jointing, boring, mortising, milling, both at the ends of the elements and also between the ends. • Serial number AB 059, • 380 V, 50 Hz, 50 kW, • OSAI control, • Axes o X-axis 2400 mm, o Y-axis 650 mm, o Z-axis 1000 mm, o A-axis 360°, o B-axis 260°, • Machining dimensions: L min. 150 mm, L max. 2400 mm, W max. 250 mm, H max. 100 mm, • Input speed X, Y and Z axes 50 m/min, • Max. tool diameter 200 mm, • 4 tool positions per machining side, Lajdex Dib Nopfx Ammoc • 2 pneumatic clamps, • Spindle taper ER 32, • Spindle information right side: Speed 12000-24000 rpm, Power 7.4 kW, • Spindle information left side Page: Speed 12000-24000 RPM, Power 7.4 kW,

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Double table machining center Working range X 2,590 mm Working range Y 2,260 mm Working range Z 400 mm Number of milling spindles 2 Liquid-cooled spindle Main motor 19.2 kW Max rotational speed 24,000 rpm Aggregate heads 4 C-axis Tool clamping system HSK-F63 Tool change positions central magazine 24 Tool change on each head from 12 positions Boring heads vert. 20 (for each head) Horizontal boring heads X 8 Horizontal boring heads Y 8 Blade for grooves in X, in Y 2 Platens Number 4 360 m³/h vacuum pumps T Jet system for chip blowing Nesting Manual labeling Bar code reader Tool length measurement Laedpfjuqw E Nex Ammjc Software BIESSE BIESSEWORKS ADVANCED, BIESSE B_NEST Weight 17,900 kg

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTC530, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 2 x 750 mm Travel Y-axis: 500 mm Travel Z-axis: 600 mm Rapid traverse X / Y direction: 25 m/min Rapid traverse Z direction: 20 m/min Laodpfoymz D Nsx Ammjc Feed force: 9 kN Spindle speed range: 30-12,000 rpm Tool changer: 22-position Tool holder: SK40 Maximum tool length: 400 mm Maximum tool diameter: 85 mm (135 mm with adjacent stations empty) Tool change time: 4.0 s Clamping area: 2 x 1,350 mm x 500 mm Maximum table load per table: 550 kg MACHINE DETAILS Control model: Heidenhain iTC530 Drive power: 30/20 kW Total power requirement: 55 kVA Dimensions & Weight Dimensions (L x W x H): 6.0 x 3.5 x 3.5 m Machine weight: 10,000 kg EQUIPMENT Internal cooling Coolant system with paper band filter Documentation

Year of construction: 2009, condition: ready for operation (used), Travel X/Y/Z: 2200mm/520mm/510mm, rapid traverse X/Y/Z: 40m/min, number of spindles: 2, speed: 10000rpm, spindle power: 22kW, spindle bearing: 95mm, max. torque: 300Nm, tool holder: HSK A100, max. milling capacity: 500cm³, max. drilling diameter: 50mm, max. thread diameter: M36. Table dimensions X/Y: 2x 1250mm/250mm, spindle table distance min./max.: 250mm/760mm, max. workpiece weight: 2x 1500kg, max. tool length: 320mm, tool positions: 2x 21, tool clamping: 45000N. Dimensions X/Y/Z: approx. 4000mm/6500mm/3800mm, weight: approx. 11000kg, operating hours: 37771h. Including sheet metal technology SHA KMB 900, volume: 900l, and magnetic plate. Documentation available. Lodpfx Amst E Tp Tomjac

Condition: good (used), Year of construction: 2002, Travel paths X/Y/Z: 2350(2x710)/520/520 mm Maximum spindle speed: 12,000 rpm Tool holder: HSK A 63 Tool changer positions: 2 x 32 CNC control: Heidenhain Lasdpfx Ameyg Dz Remoc

Year of construction: 2006, operating hours: 82,068 h, condition: good (used), functionality: fully functional, machine/vehicle number: 258-22, Moving column machine in steel-concrete composite construction with workpiece changing device. Low-maintenance model from the world-renowned manufacturer CHIRON. Double spindle - vertical - machining center incl. chip conveyor KNOLL AE 1058.009 and a compound unit (already dismantled). Prescribed maintenance intervals for plant and plant parts have always been observed. TECHNICAL DETAILS Laodpfsmt A Ivsx Ammoc Drilling capacity in steel: 60: 2 x 6 36 mm (with insert drill) Guides: with long term grease lubrication speed range: 20-12.000 rpm CNC control: SIEMENS 840D spindle distance in X-axis: 250 mm X-axis: 300 mm Y-axis: 400 mm Z-axis: 425 mm (with variable tool change plane) rapid traverse speed 60 m/min in X-, Y- and Z-axis Main spindle drive: 1 piece with 2 AC motors power at 100 % ED: 9,5 kW power at 15 % ED:14,0 kW Drive: digital direct drives with indirect absolute path measuring system (no reference point approach) tool places: 212 Tool diameter: max. 65 mm Tool diameter with free neighboring places: max. 175 mm Tool weight: max. 2.5 kg (5.0 kg at 2 stations) Tool change time: approx. 0.9 s (depending on control) Chip-to-chip time: approx. 2.1 s (control-dependent) Workpiece changing device: 0 / 180 Tool holder: HSK A 63 1 MACHINE DETAILS type of current: 3 / N / PE - 50/60 Hz operating voltage: 400 V power: 44 kVA rated current: 63 A Coolant system HL 450 / 900 LATE CONVEYOR Manufacturer: KNOLL Type: AE 1058.009 Year of manufacture: 2006 EQUIPMENT - CHIRON maintenance manual on screen - Operating hours and piece counter - Socket 230 V - Socket for portable mini handwheel - Control cabinet cooler as door-mounted unit - Signal lamp - splash guard cladding - chip conveyor - mini control panel - Rinsing gun - Central pneumatic connection - Fixture flushing - 70 bar HP pump - 1 internal cooling package with suction unit - Fully enclosed working chamber - Extraction unit with air cleaner - Extraction capacity 800 m³/h - CHIRON mold life monitoring with: - Automatic loading door of the splash guard - "opening" and "closing", actuation via two-hand start release - Integrated IWW 0/180° workpiece changing device - Chiron Lasercontrol Single F500 - Ethernet connection RJ45 at the control cabinet instead of in the control panel - Pneumatic and hydraulic connections - Central hydraulic and pneumatic connection prepared for max. 20 connections, 6 connections are designed including connection couplings, 4 of them for hydraulics, max. 210 bar and 2 for uncontrolled pneumatics. - 4 Additional hydraulic connection(s) - Hydraulic power unit - 2 Hydraulic aggregate extension for further clamping circuits

Condition: good (used), BACCI DOUBLE JET The BACCI DOUBLE JET machine with a KUKA robot is an advanced, automated CNC machining center dedicated to the production of wood and wood-based components. The KUKA robot works with the machine's integrated feeder to automatically feed material for processing, significantly increasing efficiency and minimizing the need for manual operation. After the milling and grinding process is complete, the robot automatically retrieves finished parts and places them on pallets, streamlining production logistics and enabling continuous operation without interruptions for manual reloading. Lsdpfxsxr Ddue Ammjac This system ensures seamless integration of the robot with the BACCI DOUBLE JET machine, which features dual machining heads and 12 interpolated axes, enabling simultaneous and precise machining of components. Automated material loading and unloading and the integrated feeder system increase efficiency and production repeatability while reducing labor costs and improving operator safety. This machine is primarily used in the furniture and carpentry industries, where high standards of quality and efficiency are required.

Condition: good (used), BACCI DOUBLE JET The BACCI DOUBLE JET machine with a KUKA robot is an advanced, automated CNC machining center dedicated to the production of wood and wood-based components. The KUKA robot works with the machine's integrated feeder to automatically feed material for processing, significantly increasing efficiency and minimizing the need for manual operation. After the milling and grinding process is complete, the robot automatically retrieves finished parts and places them on pallets, streamlining production logistics and enabling continuous operation without interruptions for manual reloading. Ledpoxr Dcwofx Ammeac This system ensures seamless integration of the robot with the BACCI DOUBLE JET machine, which features dual machining heads and 12 interpolated axes, enabling simultaneous and precise machining of components. Automated material loading and unloading and the integrated feeder system increase efficiency and production repeatability while reducing labor costs and improving operator safety. This machine is primarily used in the furniture and carpentry industries, where high standards of quality and efficiency are required.

Condition: good (used), Year of construction: 1997, functionality: fully functional, We offer an nice condition Matsuura with tools and accessoriess, very atractive machine for a serious work. Description Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. Spindle Chiller WASTE CONVEYOR with Yasnac i80M Control 20 Position: ATC BT40 : Taper Specifications Manufacturer MATSUURA Model MC600VF Year 1997 Condition Used Serial Number 970112285 Table size 870 x 400mm Coolant tank X = 600 Y = 410 Z = 470mm Spindle speeds 30 – 15000 rpm. Lsdpjvkx Rksfx Ammoac

Condition: used, functionality: unexamined, machine/vehicle number: ML944E08, spindle speed (max.): 8,000 rpm, type of input current: three-phase, overall weight: 5,500 kg, input voltage: 400 V, CHEVALIER QP2033-L vertical machining center. The machine is available for inspection in Riga, Latvia. The machine is currently powered on and can be inspected by appointment. Ljdpfx Aozfgmxommjac Additional photos and technical information are available upon request.

Condition: new, Year of construction: 2025, table length: 900 mm, table width: 450 mm, number of spindles: 1, spindle speed (min.): 8,000 rpm, table load: 500 kg, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Machine weight 4000 kg It is also possible to supply CNC milling machines, machining centers with other table sizes: Lsdpfx Ajxc I Dgemmjac VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm VMC 1680 table 1700x800 mm VMC 1890 table 2000x900 mm

Condition: good (used), Production line consisting of: - BACCI FC 8 - BACCI DOUBLE JET - KUKA robots BACCI FC 8 The automatic copying-shaping-sanding machine executes milling and sanding operations on components of chairs, tables, armchairs, sofas, beds, furniture, frames, with the best finish and highest output. Laedpfxot Tw S Us Ammsc Max working length: 2700mm Max working height: 180mm Max working width: 500mm Max working width with round end: 350mm Max speed working table: 15m/min Max table return speed: 50-100m/min BACCI DOUBLE JET DOUBLE-JET is double machining centre with 6+6 interpolated CN axis, equiped with hopperfeeder system for automatic loading/unloading of the pieces.

Condition: good (used), Production line consisting of: - BACCI FC 8 - BACCI DOUBLE JET - KUKA robots BACCI FC 8 The automatic copying-shaping-sanding machine executes milling and sanding operations on components of chairs, tables, armchairs, sofas, beds, furniture, frames, with the best finish and highest output. Ledpjt Txfpofx Ammjac Max working length: 4000mm Max working height: 180mm Max working width: 500mm Max working width with round end: 350mm Max speed working table: 15m/min Max table return speed: 50-100m/min BACCI DOUBLE JET DOUBLE-JET is double machining centre with 6+6 interpolated CN axis, equiped with hopperfeeder system for automatic loading/unloading of the pieces.

Condition: used, Year of construction: 2016, machine/vehicle number: ab197, functionality: fully functional, workpiece length (max.): 3,000 mm, rotational speed (max.): 24,000 rpm, Equipment: documentation/manual, SECOND HAND 5+5 AXIS CNC WORKING CENTER BACCI MOD. DOUBLE JET - 5+5 interpolated axes - N. 2 independent working tables - N. 3+3 pneumatic clamps - N. 2 automatic loaders - Max working length 3000 mm - 2 high-performance working heads with 2+2 spindles each (4+4 tools) - Rpm 0-24.000 Ljdox Rcm Uopfx Ammeac - Osai control - Drivers YASKAWA - Pitagora software - S/N AB197 - Safety nets - CE rules - Year 2016

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: W261, repeat accuracy: 0.05 mm, workpiece weight (max.): 6,300 kg, working length: 4,000 mm, working width: 2,250 mm, working height: 230 mm, No minimum price – guaranteed sale to the highest bidder! The machine’s last inspection was carried out by a specialist company at the end of 2025! The machine can be inspected while powered on. TECHNICAL DETAILS Working area X: 4,000 mm Working area Y: 2,250 mm Working area Z: 230 mm Working area for round part machining, diameter max.: 440 mm Working area for round part machining, length max.: 3,700 mm Number of cutting heads: 1 to 4 Cutting carriage distance: max. 1,150 mm Positioning speed, axis-parallel X, Y max.: 60 m/min Positioning speed, simultaneous max.: 84 m/min Cutting speed max.: 50 m/min Travel speed min.: 0.001 m/min Laedpfx Aozcwupsmmsc Machine tolerance according to VDI/DGQ 3441: ± 0.1 mm/axis Repeatability: ± 0.05 mm/axis Load capacity of the frame max.: 7,000 kg Load capacity per grating bar: 110 kg Number of grating bars max.: 70 Workpiece weight, flat part max.: 6,300 kg Workpiece weight, round part max.: 500 kg MACHINE DETAILS Waterjet source: Bypump 50 APC Operating pressure: max. 3,800 bar Flow rate: 0 to 5 l/min Nozzle size in single-head operation: max. Ø 0.4 mm Nozzle size in dual-head operation: max. Ø 0.3 mm Nozzle size in dual-head operation: recommended Ø 0.28 mm Dimensions & Weight Machine dimensions (L x W x H): approx. 9,000 mm x 7,550 mm x 2,050 mm Weight: approx. 10,000 kg Operating Hours Operating hours: approx. 41,130 h Cutting hours Head 1 / Head 2: 13,720 h / 956 h EQUIPMENT CNC rotary axis Motorized cutting carriage distance adjustment Four-jaw chuck Abrasive hopper Spare parts PC with pre-installed programming software Note: The second head has been removed, and the cutting mechanism has been mounted on Head 1 as a spare part. However, after acquiring a new cutting head, the system can operate with two abrasive tools. The drilling spindle is seized. The crane and lifting device are not included in the scope of sale.

Condition: ready for operation (used), Year of construction: 2007, operating hours: 36,012 h, functionality: fully functional, travel distance X-axis: 635 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 510 mm, controller model: 3D Heidenhain i TNC 530, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 635 mm Travel range, Y-axis: 460 mm Travel range, Z-axis: 510 mm Spindle speed range: 20 - 10,000 rpm Table dimensions: 790 x 560 mm Table load capacity: 600 kg Tool holder: SK 40 Ledpfx Amszb Dzmomjac Number of tool magazine slots: 20 MACHINE DETAILS Control system: 3D Heidenhain i TNC 530 Total power consumption: 13.9 kW Operating hours (according to counter) Spindle hours: 36,050 h Power-on hours: 91,000 h Dimensions & Weight Dimensions (L x W x H): 3,000 x 2,000 x 2,150 mm Machine weight: 3.6 t

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 80.4308.0097, travel distance X-axis: 900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 970 mm, controller model: FANUC Professional 3, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 900 mm Travel range, Y-axis: 800 mm Travel range, Z-axis: 970 mm Pallet size: 630 mm × 630 mm Number of pallets: 2 Max. workpiece weight: approx. 1,200 kg Spindle connection: HSK-A100 Max. spindle speed: 12,000 rpm Tool magazine: 188 positions Laodpfxezb Efys Ammec Tool change time: approx. 1.7 s Rapid traverse: up to 50 m/min MACHINE DETAILS Control system: FANUC Professional 3 Machine weight: approx. 18 t EQUIPMENT Dual-pallet system Large 188-position tool magazine Automatic tool changer Through-spindle coolant / coolant system Chip conveyor NC rotary table Network/DNC connection Note: The machine was previously connected to a pallet loading station. The pallets can, of course, also be loaded manually.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, table load: 1,200 kg, rotational speed (max.): 8,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,660 mm Travel range Y-axis: 760 mm Travel range Z-axis: 660 mm Table size: 760 x 2,000 mm Table load capacity max.: 1,200 kg Tool holder: SK 40 Tool changer: 2 x 24 Tool diameter max.: 80 mm Tool diameter with free adjacent slot max.: 110 mm Tool length max.: 350 mm Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min Ljdjzb D N Ropfx Ammjac MACHINE DETAILS Control system: MAZATROL M-PLUS Dimensions & Weight Space requirement: approx. 6.0 x 4.0 x 3.5 m Machine weight: approx. 8.1 t Total power requirement: 32.8 kVA The machine has been regularly serviced.

Condition: ready for operation (used), Year of construction: 2002, machine/vehicle number: 0-250-08-1590, functionality: fully functional, travel distance X-axis: 3,250 mm, travel distance Y-axis: 1,220 mm, travel distance Z-axis: 125 mm, controller model: Homatic 2000 IPC, number of spindles: 28, spindle speed (max.): 24,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working area X-axis: 200 – 3,250 mm Working area Y-axis: 70 – 1,220 mm Working area Z-axis: 12 – 125 mm (clearance 150 mm) Tool changer positions: 18 Spindles Total number of drilling spindles: 28 Vertical drilling spindles: 22 Horizontal drilling spindles in X-axis: 4 Horizontal drilling spindles in Y-axis: 2 Milling spindle power: 12 kW Milling spindle max. speed: 24,000 rpm C-axis: 360° interpolation MACHINE DETAILS Vacuum pump capacity: 100 m³/h Control model: Homatic 2000 IPC Laedezcda Sspfx Ammjc Control software: WoodWop 4.5 incl. MDE and production list software FEATURES 4 axes Console table 8 manually adjustable supports in X direction 3 vacuum cups per console Vacuum connection for templates Laser positioning aid for vacuum cups Laser projection for cup positioning Liquid circulation cooling Operator terminal Note: The sale does not include the pictured adapter units, tools, or HSK holders.

Condition: used, Year of construction: 2005, machine/vehicle number: 107.32.99.158, travel distance X-axis: 530 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! The machine spindle was replaced in July 2025! TECHNICAL DETAILS Travel range X-axis: 530 mm Travel range Y-axis: 450 mm Travel range Z-axis: 450 mm Laodpjzara Uefx Ammec Rotary table Table diameter: 400 mm Table load: 200 kg Swivel range: degrees Swivel speed: 20 rpm Rotational speed: 30 rpm Tool holder: SK40 Maximum speed: 12,000 rpm Recommended maximum working feed rate: 15 m/min Rapid traverse speed: 22 m/min Feed force X and Y/Z: 5,000 N Magazine capacity: 30 Maximum tool diameter: 90 mm Maximum tool length: 250 mm (manually 350 mm) Maximum tool weight: 6 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 with digital control Positional tolerance according to DIN/ISO 230-2/97: 0.008 mm Machine weight: 6,500 kg EQUIPMENT RENISHAW MP 12 measuring probe Blum tool monitoring system

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 18,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 700 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 500 mm Spindle speed: 1 - 18,000 rpm Tool holder: HSK-A63 Tool magazine capacity: 70 Tool-to-tool change time: 2.5 s Acceleration: 20 m/s² Travel speed: 120 m/min MACHINE DETAILS Laedpezd R R Ejfx Ammoc Number of pallets: 6 EQUIPMENT Integrated workpiece changer system High-dynamic 5-axis machining Weight-optimized kinematics Linear motor drives

Condition: excellent (used), Year of construction: 2021, operating hours: 11,514 h, functionality: fully functional, machine/vehicle number: 20210202, travel distance X-axis: 670 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain TNC 640, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel X-axis: 670 mm Travel Y-axis: 820 mm Travel Z-axis: 600 mm Spindle speed (min.): 18,000 rpm Spindle operating hours: 11,514 h Coolant supply: 40 bar MACHINE DETAILS Apparent power rating: 90 kVA Control manufacturer: Heidenhain Control model: TNC 640 Total weight: 20,000 kg Input voltage: 400 V Full load current: 125 A Max. current load: 200 A Short-circuit resistance: 25 kA Voltage: 400.50 V/Hz Lodpfxezb A Eks Ammsac Net weight: 20,000 kg Machine number: 20210202 EQUIPMENT Documentation/Manual Chip conveyor

Condition: ready for operation (used), Year of construction: 1998, operating hours: 26,000 h, functionality: fully functional, machine/vehicle number: J0124, travel distance X-axis: 1,800 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 750 mm, controller model: Heidenhain iTNC 426, rotational speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,800 mm Travel range Y-axis: 850 mm Travel range Z-axis: 750 mm Spindle nose to table distance range: 200 mm - 950 mm Spindle center to column distance: 920 mm Table dimensions X: 2,000 mm Table dimensions Y: 800 mm Max. table load: 2,200 kg Tool interface: SK50 Magazine capacity: 30 Spindle speed: 6,000 rpm Feed rate: 5 m/min Rapid traverse: 12 m/min MACHINE DETAILS Control system: Heidenhain iTNC 426 Dimensions & Weight Dimensions (L x W x H): approx. 5,700 x 3,850 x 3,350 mm Weight: approx. 16,500 kg Operating Hours Total operating hours: approx. 51,000 h Lodpfszdpqwox Ammsac Spindle operating hours: approx. 26,000 h EQUIPMENT 4th axis installed as a rotary table Documentation/Manual Spindle speed infinitely adjustable Chip conveyor Coolant system Vices

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 15744, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, table load: 1,500 kg, TECHNICAL DETAILS Travel range, X-axis: 800 mm Travel range, Y-axis: 600 mm Travel range, Z-axis: 600 mm Table length: 1,000 mm Table width: 560 mm Table load: max. 1,500 kg Spindle connection: HSK63 Tool changer: 30 positions Rapid traverse rate: 35 m/min Acceleration: 5 m/s² MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 4,200 x 2,500 x 2,800 mm Weight: 7,200 kg Lajdpfxszcymzo Ammec Total connected load (including cooling unit): 42 kVA

Condition: ready for operation (used), Year of construction: 2004, operating hours: 61,297 h, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 800 mm, controller model: HEIDENHAIN TNC 426, Equipment: chip conveyor, No minimum price – guaranteed sale to the highest bidder! In January 2025, a new spindle was installed by the manufacturer! The machine has been regularly maintained! Previous use: The machine was primarily used for precision machining. Roughing operations were only carried out to a limited extent. TECHNICAL DETAILS Travel range X-axis: 2,800 mm Travel range Y-axis: 2,200 mm Travel range Z-axis: 800 mm Feeds Rapid traverse: 35,000 mm/min Spindle speed S1 (continuous operation) Vertical: 10,000 rpm Spindle speed S1 (continuous operation) Universal swivel head 2-axis: 18,000 rpm Vertical milling head: TVS 10,000 Swivel milling head: TU 18,000 Tool holder: HSK 63 A Tool changer: 40 tool positions MACHINE DETAILS CNC control: HEIDENHAIN iTNC 530 Electrical data Supply voltage: 400 V (-15 %, +10 %) Frequency: 50 Hz Lodpfezb D Aqsx Ammoac Current consumption: 101.1 A Installed total power: 59.8 kW Operating hours Power-on hours: 99,222 h Program run time: 61,297 h EQUIPMENT High-rigidity gantry design Precise linear guides and ball screws Generous working area with 2.8 m X-axis travel High feed rates for efficient machining Ideal for tool, mold, and machine construction Documentation and acceptance certificate according to ISO standards Tool changer Coolant system Chip conveyor Swiveling milling head with 4th/5th axis Maintenance and service documentation
