Used Centerless Circular Grinding Machine for sale (66,409)

Condition: ready for operation (used), Year of construction: 1983, Process: centerless plunge grinding, max. workpiece diameter: 20mm, max. workpiece length: 80mm, without automation by vibratory bowl. An on-site inspection is possible. Kodpfxow U T Txs Andona

Condition: used, Year of construction: 1975, functionality: fully functional, total height: 2,000 mm, total width: 1,200 mm, total length: 2,000 mm, type of input current: three-phase, overall weight: 3,800 kg, workpiece diameter (max.): 60 mm, input voltage: 400 V, LIDKÖPING 2C – Centerless cylindrical grinding machine (for through-feed and plunge-cut grinding), manufactured in 1975. Manufactured in 1975 · For through-feed and plunge-cut grinding · 14 grinding wheels and 4 regulating wheels, 28 support rails. Centerless cylindrical grinding machine from Lidköpings Mekaniska Verkstads AB (Sweden) for through-feed and plunge-cut grinding. Classic mechanical-hydraulic design without CNC: cast iron bed, grinding wheel and regulating wheel with a support rail in between, belt drive with two speed stages that can be switched using variable pulleys. The machine was in operation until recently at a Swabian precision manufacturing company and was used there approximately once a month; it was sold solely due to lack of space. An unusually complete set of accessories is included: 14 grinding wheels and 4 regulating wheels, 4 mounting flanges, and 28 support rails – making the machine ready for use without any further procurement. For the 2C series, service, spare parts, and overhauls are still available today in Germany and from the brand owner in Sweden. EQUIPMENT Knedpfozvh Ulsx Andea - Regulating wheel spindle with support rail - Feed trough for through-feed operation - Separate hydraulic unit (ASEA motor) - Separate control cabinet with relay control and compressed air maintenance unit - Variable pulley drive, 2 speed stages - 14 grinding wheels, 4 mounting flanges, 4 regulating wheels - 28 support rails in a wooden crate TYPICAL APPLICATIONS - Pins, bolts, dowel pins, and drift pins – through-feed grinding to final diameter - Shafts, axles, and round bars in series, also as preparation for centerless grinding - Rollers, sleeves, and bushings – external cylindrical grinding in one pass - Tubes and bar stock to size and roundness - Parts with a flange or shoulder – in plunge-cut operation - Rework and repair of precision parts in tool and contract manufacturing operations

Year of construction: 2009, condition: ready for operation (used), A G+H precision cylindrical grinding center is available. Distance between centers: 600mm, center height: 140mm, max. swing diameter: 275mm, max. workpiece weight overhung/between centers: 30kg/100kg, X/Z feed rate: 8m/min, workhead taper: MT4, tailstock quill stroke: approx. 35mm, tailstock taper: MT4, grinding wheel dimensions X/Y/Z: 400mm/50mm/127mm, max. speed: 1425rpm, internal grinding spindle speed: 16800rpm, max. grinding wheel diameter: 100mm, filter capacity: 300l, filter flow rate: 100l/min, chuck: three jaw chuck, chuck diameter: 160mm. Machine dimensions X/Y/Z: approx. 3000mm/2700mm/2050mm, weight: approx. 4500kg, operating hours: approx. 350h. Including chuck, magnetic fixture and dressing unit. Documentation vorhanden. An on-site inspection is possible. Kodpfx Ajzlt Ntendsna

Condition: ready for operation (used), Offered is a used high-precision Studer S35 CNC cylindrical grinding machine. Center distance: 1000mm, center height: 175mm, swing diameter max. approx. 350mm, workpiece weight: approx. 80kg, resolution: measuring systems glass scales range 0.0001mm 0.1µm. Inspection by appointment possible. Kjdpfxoykuucj Andjna

Year of construction: 1994, condition: ready for operation (used), Grinding length: 650mm, center height: 125mm, grinding wheel dimensions X/Y/Z: 406mm/60mm/127mm, peripheral speed: 45m/s, spindle power: 4kW, travel X/Z: 210mm/810mm, feed rate: 8m/min, table swivel: 8°, speed: 5000rpm, tool spindle head swivel: -30°/90°. Machine dimensions X/Y/Z: approx. 3600mm/2850mm/2200mm, weight: approx. 4000kg, control: Siemens Sinumerik. The X-axis spindle and the scale were renewed. Including Movomatic measuring system and accessories. Documentation available. On-site inspection is possible. Kodpfxeyf I Hbs Andjna

Year of construction: 2024, condition: ready for operation (used), An almost like-new and high-precision CNC centerless grinding machine Monzesi is available. Grinding wheel outer diameter min./max.: 406mm/280mm, inner diameter: 152mm, max. width: 200mm, speed: 2100rpm, power: 11kW. Regulating wheel outer diameter min./max.: 160mm/254mm, inner diameter: 115mm, max. width: 200mm, speed: 285rpm. Workpiece diameter: 100mm, workpiece length: 200mm, regulating wheel axial adjustment: +/-10mm, taper setting: -2°/6°, tilt adjustment: +/-5°, accuracy: 0.0001mm. Machine dimensions X/Y/Z: approx. 3800mm/2000mm/21500mm, weight: approx. 4500kg, control: CNC Fanuc 35i-B Digital, operating hours April/2026: 481h. Documentation available. An on-site inspection is possible. Expected to be available from end of July/August 2026. Knedpfsyyb Tlex Andea

Year of construction: 2009, condition: ready for operation (used), A Junker CNC cylindrical grinding machine overhauled in 2019 is available. Grinding length: 150mm, center height: 100mm, max. workpiece weight: 5kg, max. grinding diameter: 500mm, orbital diameter: 80mm, grinding wheel diameter: 400mm. Machine dimensions X/Y/Z: approx. 2850mm/1450mm/2000mm, weight: approx. 2000kg, control: Siemens Sinumerik. Including BKW chiller, Knoll VL 1000/4000 cooling lubricant system with 6500l container and Hyfra industrial recooler. Documentation available. On-site inspection is possible. Knodpfx Ajwtg Eyendea

Year of construction: 2013, condition: ready for operation (used), A CNC cylindrical grinding machine GSN Schleiftechnik including automatic paper belt filter, center point, diamond dressing tiles and grinding wheel changing aid is available. Workpiece length: 1500mm, max. workpiece diameter: 250mm, max. workpiece weight: 150kg, machine dimensions X/Y/Z: approx. 6300mm/2500mm/2500mm, weight: approx. 9000kg, control: Siemens Sinumerik 840D powerline. Documentation available. On-site inspection is possible. Ksdpfx Aowxxwrsndjna

Year of construction: 2021, condition: ready for operation (used), A universal external and internal cylindrical grinding machine Tachella, refurbished in 2021, is available. Center distance: 600mm, center height: 120mm, max. grinding diameter: 240mm, max. grinding length: 600mm, X/Z travel: 600mm/250mm, max. workpiece weight: 100kg/40kg. Machine dimensions X/Y/Z: approx. 2700mm/1900mm/1700mm, weight: approx. 2500kg. Documentation available. An on-site inspection is possible. Kedpfszhnuisx Andena

Year of construction: 2012, condition: ready for operation (used), A CNC cylindrical grinding machine GP Basis Karstens with rotating grinding headstock is available. Grinding length: 650mm, center height: 250mm, workhead: MK4, tailstock: MK4, wheel diameter: 400mm, spindle diameter: 80mm, sleeve length: 250mm, speed: 3000rpm, spindle power: 1.5kW, control: Siemens and Balance System VM25. Documentation available. On-site inspection is possible. Ksdpfou Nlk Sox Andena

Year of construction: 2013, condition: ready for operation (used), A centerless CNC cylindrical grinding machine Tschudin is available. Workpiece diameter min./max.: 1.5mm/100mm, max. grinding length: 250mm, grinding wheel diameter outside/inside: 400mm/203.2mm, grinding wheel peripheral speed: 50m/s, grinding wheel power: 11kW, control wheel diameter outside/inside: 225mm/127mm, speed: 265rpm, inclination: +/-5°, power: 3.7kW. Machine dimensions X/Y/Z: approx. 2000mm/2400mm/1900mm, weight: approx. 6000kg, control: Fanuc 21i-MB. Including Knoll Micro Pur 240 F ultra-fine filter, Streuli SHSRT300-TL142/180 lifting station and Kraft & Bauer FB703S-UV3-TFM70° fire extinguishing system. Documentation available. On-site inspection is possible. Kedowwllgopfx Andjna

Condition: ready for operation (used), Weight: 2.2t, including documentation. Knedpfx Asmqly Ujndsa

Condition: used, Year of construction: 1990, grinding diameter max. 1-150 mm Kedpfeztfz Djx Andena regulating wheel width 100-200 mm weight 5 t

Condition: used, Year of construction: 2005, grinding diameter max. 500-600 mm regulating wheel width 100-200 mm weight 5 t grinding diameter 1-150 mm grinding wheel width 150–250 mm mm with water treatment Knsdpfx Asztfzqjndea

Condition: good (used), Year of construction: 2001, functionality: fully functional, Grinding wheel 508x254 (305) mm, regulating wheel 330x254 (305) mm, regulating wheel speed 0-115 rpm, grinding wheel rotation speed 45 m/sec, grinding diameter 2-150 mm, grinding wheel drive 45 kW, machine weight 6.5 tons, space requirement approx. 3.0x1.5 m The machine will be equipped with a new Siemens S7 control system with new control panel, dressing quill SS electrically controlled via servo motor. Machine will be completely checked, defective parts repaired or replaced. Knedpfeuy Ifgsx Andoa Various options possible (KM system, infeed/outfeed, workpiece rulers etc.)

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, grinding wheel width: 150 mm, grinding wheel diameter: 305 mm, year of last overhaul: 2025, Grinding wheel diameter 305x150 mm, workpiece diameter 1-40 mm, machine for plunge and through-feed grinding, PLC control, coolant system, hardened and ground guideways, grinding and regulating spindles with hydraulic slide bearings via three-point bearings, hydraulically adjustable dressers for grinding and regulating wheels, regulating wheel drive adjustable via AC motor, new German-made electrical system with Siemens components, Siemens S7 control system Knjdpfxswi H Uaj Andsa

Condition: new, Year of construction: 2024, Grinding wheel D x B 455 x 255 mm, workpiece diameter 1 - 60 mm, regulating wheel D x B 255 x 255 mm, regulating wheel speed 10 - 100 rpm, drive power 11 kW, weight approx. 3.7 tons, dimensions approx. 2,700 x 1,700 mm Knodpfx Aedlgq Uendoa Machine suitable for continuous and plunge grinding, hardened and ground guideways, grinding and regulating spindle with hydrodynamic three-point bearing, central lubrication for slides and feed spindles, regulating wheel drive via DS motor, frequency-controlled, hydraulic dressing devices for grinding and regulating wheel, electrical equipment predominantly with Siemens components, electrical control cabinet assembled in Germany, GC 1810-NC with stepper motor and Siemens S7 control for plunge and feed movement. Very economical price/performance ratio.

Condition: used, Brand and Model: ACME GOZUA RC 2-75 Type: CENTERLESS HYDRAULIC CYCLES Intermitten ( with stop at the end of the cycle.) Total time for fast feed, slow grinding feed, and stop at the feed carriage setting ( adjustable by timer) 1 to 100 sec.. DIAMOND CUTTING Maximum diameter difference in copy: 8 mm Total tMaximum copy taper : 30º COOLING EQUIPMENT Pump flow rate : 45 l /min Tank capacity: 100 l Knedpozq Sfksfx Andsa Decanting compartments : 4 EXTERNAL AND MAIN DIMENSIONS Total machine length: 2.350 mm Total machine width : 1.560 mm Total machine height: 1.450 mm Height of the grinding wheel axes 1.050 mm. External dimensions of shipping packaging : 2.400x1.700x1.600 mm Shipping packaging volume: 6.53m3 WEIGHTS Net: 2.340 kg Gross with cage packaging : 2.445 kg Gross with shipping packaging: 2.485 kg

Condition: ready for operation (used), Year of construction: 2015, GIUSTINA R 114 CNC Fanuc Centerless Grinding Machine Knodjzdnx Topfx Andoa CNC Control: FANUC Series 18i - MB - 6-axis - X, Y, Z, W, U, V Grinding capacity: Ø 1.5 to 500 mm Operating grinding wheel: Ø 610 x 508 mm Conductive grinding wheel: Ø 355 x 508 mm Weight: approximately 15 tons.

Condition: ready for operation (used), 440-20 CINCINNATI-MILACRON 'DE' Twin Grip Centerless Grinder Capacity – 254 mm Grinding Wheel Diameter – 609.6 mm Grinding Wheel Power – 29.8 kW Regulating Wheel Diameter – 355.6 mm Knsdpfx Asxwm E Ssndja Regulating Wheel Power – 1.5 kW Regulating Wheel Speed – 300 RPM Approximate Weight – 14 tons Video of machine under power available

Condition: reconditioned (used), functionality: fully functional, Herminghausen SR2 High-precision and conventional centerless cylindrical grinding machine. The machine is suitable for grinding workpieces up to 40 mm in diameter. High machine and grinding stability due to a robust cast iron bed and hydrodynamic segmental chuck bearing. Its low height provides excellent access to all important functions. Quick and easy changeover for different workpieces and materials. Kedpozpf H Sefx Andjna Overhauled: July 2026 Workpiece diameter: 0.5 - 40 mm Grinding wheel dimensions (D x W x H): 290 x 100 x 150 mm Regulating wheel dimensions (D x W x H): 200 x 100 x 120 mm Total weight: 1,200 kg Total power: 5.5 kW / 400 V / 50 Hz

Year of construction: 2013, condition: ready for operation (used), A CNC external cylindrical grinding machine Roweig requiring repair is available. Center height: 310mm, max. swing diameter: 600mm, max. grinding length: 1410mm, max. clamping length: 1500mm, max. grinding diameter: 600mm, max. workpiece weight: 500kg/120kg. Workhead speed: 500rpm, spindle taper: MT6, center point: MT5, swivel angle: -30°, tailstock cylinder compensation: +/-0.15mm, scale division: 0.001mm, max. dressing relief: 25mm, table speed: 10m/min, max. table travel: 1680mm. Wheelhead travel: 600mm, infeed speed: 10m/min. Grinding wheel dimensions X/Y/Z: 630mm/100mm/304.8mm, power: 11kW, max. speed: 50m/s, grinding spindles: 2, workpiece swivel angle: -30°/195°, spindle setting angle: -30°/15°. Machine dimensions X/Y/Z: approx. 5250mm/2450mm/2200mm, weight: approx. 7500kg, control: Siemens Sinumerik 802D sl. Spindle cooling defective. Documentation available. An on-site inspection is possible. Knedpfx Anjzmylqjdsa

Condition: used, Year of construction: 2002, Centerless Grinding Machine BOCCA MALANDRONE R 80/200 CNC Knodjhzvkdspfx Andja GENERAL CHARACTERISTICS: Grinding Wheel Dimensions: Ø610xØ304,8x300 mm Regulating Wheel Dimensions: Ø355xØ152,4x300 mm

Condition: used, Manufacturer: CINCINNATI Knodpfewrpykjx Andsa

Condition: used, Year of construction: 1973, grinding diameter max. 30 mm regulating wheel width 12 mm max. width of grinding wheel mm total power requirement kW weight of the machine ca. t Kedpfst Hwwwox Andona dimensions of the machine ca. m
