Used Column Drilling Machine/Alzmetall Ab 3 Es for sale (107,942)

Condition: ready for operation (used), functionality: fully functional, Pillar drill / ALZMETALL AB 3 ES from a vocational school - Well-maintained, original condition - Drilling capacity / steel max. 35mm - Arm reach 280mm - Table size 600x470mm - Drilling stroke 180mm - Morse taper MK 3 - Stepless speed control - Drilling depth stop - Speed indicator - Drill chuck - Documentation Dimensions: L x W x H 1.2 x 0.8 x 2 meters / Weight 500 kg Errors and omissions excepted. Crsdpfx Aoz Iht Nodrsh

Condition: ready for operation (used), Bench drill – ALZMETALL AB 35 S - Drilling capacity in steel approx. 45 mm - Drilling capacity in cast iron approx. 48 mm - Spindle mount MK 4 - Arm reach approx. 350 mm - Drilling stroke approx. 180 mm - Spindle speeds / 2 stages / 65 - 1450 rpm (VARIABLE) - Automatic feed rates 0.1-0.2-0.3-0.4 mm/rev - Drilling depth stop - Table clamping surface approx. 600x460 mm - Table adjustment approx. 600 mm Codpfx Adsznlf Ejrerh - Table height adjustable via crank - Column diameter approx. 200 mm - Motor power approx. 3.5 kW - Coolant system - Work light - Speed indicator Dimensions: L x W x H 1.1 x 0.7 x 2.1 meters / Weight approx. 1200 kg Errors and omissions excepted.

Condition: ready for operation (used), Bench drill / ALZMETALL AB 40 ST -Drilling capacity in steel approx. 50mm -Threading capacity max. M30 -Tool holder MK 4 -Spindle stroke approx. 160mm -Automatic feed rate 0.1-0.2-0.3-0.4mm/rev Crodezm Tb Espfx Adrjh -Overhang approx. 300mm -Continuously variable speed adjustment (variator) -Right/left rotation -Height-adjustable work table via hand crank -Work table size approx. 740x460mm -Motor power approx. 3 kW Dimensions: L x W x H 1.2 x 0.8 x 2.2 meters / Weight approx. 1200 kg Errors and omissions excepted.

Condition: new, Year of construction: 2024, ALZMETALL pillar drilling machine AB 34 iTRONIC, drilling capacity in steel 34mm, spindle speeds: 100-1800 rpm, short spindle MK4, spindle stroke: 160mm, overhang: 300mm, column diameter: 145mm, machine table usable support area: 615x430mm, with T-slots 2 x 14mm x 224mm, spindle-table distance min./max. 138/688mm, machine table height adjustment via hand crank, feeds 0.1-0.2-0.3-0.4 mm/rev, machine height without options: 1865mm, net weight: 470 kg. Standard equipment: 7" TFT-LCD display with touch function Threading device Infinitely adjustable speed Spindle guard Three separate buttons for right-hand rotation – left-hand rotation – stop Mushroom button Main switch Right and left rotation Control voltage 24 volts Protection class IP 54 Motor insulation class "F" (155°) Electromagnetic feed overload protection Initial filling of machine oil Paint finish: DD structural paint signal white RAL 9003, PANTONE 7545c, black Cedpfxoiqyixs Adrorh including the following options: LED machine lamp, item no. 12 Coolant system A, item no. 24 Foot switch for threading, item no. 20.5 Delivery time: ex stock Waiblingen Beinstein The machine can be inspected by appointment.

Condition: ready for operation (used), Alzmetall AB 3 ESV Drill press, pillar drill Pinole stroke: approx. 170 mm Table: 620 mm x 480 mm Clamping area: 500 mm x 375 mm Infinitely variable speed: 55 - 1450 rpm / Pneumatic speed adjustment Feed rate: 0.1; 0.2; 0.3 Left/right rotation Drilling capacity in steel (Ø): approx. 30 mm Cedpfx Aezx Rnajdrjrh Overhang (spindle to column/table): approx. 290 mm. You are welcome to visit us for an inspection. We would be happy to arrange an affordable shipping service for you! You will receive a proper invoice. For foreign customers, a net invoice can also be issued. A valid VAT identification number is required. Subject to prior sale. Visit our shop and check out our other offers. The company names and trademarks mentioned are the property of their respective owners and are used solely for identification and description of the products. Deviations in technical data and errors in the description of the item may occur and are subject to change.

Condition: used, Column Drilling Machine ALZMETALL Type AB 3 ES Machine No. 21703 Year of manufacture: 1981 Drilling capacity: 32 mm Spindle taper: MK 3 - long quill Throat depth: 290 mm Quill stroke: 160 mm Table size: 510 x 300 mm Column diameter: 115 mm Spindle speed: 55 - 1450 rpm, stepless Motor power: 0.9 and 1.3 kW, pole-changeable - Spindle speed via 2 gearbox stages, 2 motor speeds, and stepless through variator gearbox - Intermediate gear stage for high torque at low speeds - RPM counter for spindle speed - Table height adjustable by handwheel - Machine lamp - Emergency stop via foot switch and kick switch - Quick-action drill chuck 1 to 13 mm Space requirement L x W x H: 1200 x 650 x 1900 mm Weight: 400 kg Very good condition Crodpevu Dv Hjfx Adrjh Machine tested with 30 mm drill diameter in steel - runs very well

Condition: good (used), Stock number: 3075 Manufacturer: Alzmetall Machine number: 11495 Codpfx Aeyifmwjdrerh Type / Model: AB3 ES Quill stroke: 180 mm Spindle taper: MK3 Drilling capacity: 30 mm Speed range: 160 to 1,420 rpm, stepless Throat: 280 mm Table diameter: 450 mm Clamping surface diameter: 360 mm Table height adjustment: – mm Column diameter: 110 mm Footprint: 450 x 650 mm Total connected load: 2 kW Accessories/Equipment: Condition: good Weight: 0.3 t Machine dimensions: 600 x 900 x 1,850 mm

Condition: good (used), Alzmetall AC 32 Turret Double-Head Drilling Machine An extremely robust and rare double-head drilling machine based on two Alzmetall AC 32 drilling head units. This machine is a high-quality industrial design intended for highly efficient series or multi-stage machining. Cjdpfxoznic Us Adrjrh Instead of simple spindles, this machine is equipped with two separate tool turrets. This enables fully automatic machining cycles (e.g., centering, drilling, countersinking, threading) without the need for manual tool changes. Technical data & equipment (per head / overall machine): Manufacturer of drilling head units: Alzmetall (Germany) Model: AC 32 (Electronically controlled with digital display) Drilling capacity: max. 32 mm in steel Threading capacity: max. M 24 / M 30 Tool changer: 2 x pivoting turrets with multiple stations Machine table: Solid, ground cast iron table with T-slots for flexible setup Safety: Complete enclosure of the working area (protective cabin) with viewing windows for optimal chip and splash protection Additional functions: Integrated coolant system, compressed air blow-off gun, central counterweight system for easy vertical adjustment of the entire beam More items – new and used – can be found in our shop! International shipping costs on request!

Condition: used, Column drilling machine ALZMETALL, type AB 3 ESV Machine no. 15967, year of manufacture 1977 Drilling capacity 32 mm Spindle mount MK 3 – short quill Distance from spindle nose to table 545 mm (short quill) Distance from spindle adapter to table 395 mm (MK adapter) Overhang 290 mm Quill stroke 160 mm Table size Ø 545 mm Column diameter 220 mm Spindle speed 55 – 1450 rpm, continuously variable Motor power 1 / 1.6 kW Power connection 380 volts, 50 Hz - Spindle speed controlled via 2 gear stages, 2 motor speeds, and continuously variable via a variator gearbox - Pre-selection stage for high torque at low speeds - MK adapter from MK3 to MK4 - Automatic feed 0.1 - 0.2 - 0.3 mm/rev Credpfx Asharwvsdrsh - Rotatable drilling table - Table height adjustment via hand crank - Heavy machine base with machined workpiece support surface (not original Alzmetall) - Lighting for the work area Space requirement L x W x H 1150 x 650 x 2000 mm Weight 850 kg Good condition

Condition: ready for operation (used), Year of construction: 1979, machine/vehicle number: 20945, Drill diameter: 28/35 mm Spindle mount: MK 3 Overhang: 293 mm Table size: 400 x 400 mm Table can be swiveled on a round column and its height can be adjusted using a hand crank and rack and pinion mechanism. Large distance between table and drill chuck: 630 mm Chuck travel: 180 mm Spindle speeds, infinitely adjustable in 4 groups: 65 - 1750 rpm Drive motor: 380 V, 0.9/1.5 kW Weight: 340 kg Cedpfx Adezh H I Uororh Space required: 600 x 920 x 1880 mm

Condition: good (used), functionality: fully functional, spindle mount: MK 3, rotational speed (max.): 1,450 rpm, rotational speed (min.): 55 rpm, table width: 600 mm, table length: 470 mm, For sale is an Alzmetall column drill press in good used condition, as shown in the photos. Technical specifications: • Manufacturer: Alzmetall • Model: AB3-ESV Codpfx Adey Uxhiorerh • Speed: approx. 55–1,450 rpm • Spindle stroke: approx. 180 mm • Feed rates: 0.1/0.2/0.3 mm/rev • Table dimensions: approx. 600x470 mm • T-slot width: approx. 14 mm • Year of manufacture: 1977 • Condition: Used, in working order Shipping costs via freight forwarder: approx. €190 International buyers are welcome! You will receive an invoice with VAT shown. Viewing/pickup is possible by appointment in 42855 Remscheid. Sale from location 42855 Remscheid, loaded ex works. Subject to errors in technical data and prior sale.

Condition: used, Year of construction: 1980, machine/vehicle number: 17209, functionality: fully functional, power: 1.5 kW (2.04 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, spindle mount: MK 3, height adjustment type: mechanical, rotational speed (max.): 1,750 rpm, rotational speed (min.): 130 rpm, total height: 2,000 mm, throat depth: 290 mm, Equipment: rotational speed infinitely variable, Used column drill press Manufacturer: Alzmetall Type: AB 3 ESV Machine number: 17209 Year of manufacture: 1980 Drilling capacity in cast iron: Ø 35 mm Drilling capacity in steel (diameter): 28 mm Spindle speed via 2 gear stages, 2 motor speeds, and continuously variable via a variator gear 130 - 1750 rpm Spindle taper: MK 3 Feed rate: 0.1; 0.2; 0.3 manually/automatically mm/rev Distance spindle/table min/max: 80 - 680 mm Table clamping surface: 500 x 370 mm Table rotatable: 360° Drill table adjustment: 600 vertical mm Overhang: 290 mm Quill stroke: 165 mm Column diameter: Ø 120 mm Crjdpfx Adozldqusrsh Equipment: - Coolant system - Speed indicator - Work light - Röhm Spiro quick-change chuck 1-13 mm - Ejector on chain - Emergency stop button Machine weight approx.: 285 kg Machine dimensions approx.: 0.9 x 0.6 x 1.9 m (LxWxH)

Condition: good (used), Column Drilling Machine ALZMETALL AB3 ESV Spindle: CM3 Rotation: 1 range 220 -800 RPM + 1 range 800-2900 RPM Table size: Length 615 mm x Width 470 mm Spindle travel: 160 mm Throat depth: 280 mm Speed adjustment by belt drive Rotative table at 360° Automatic Descent 3 speeds: 0,006 - 0,12 - 0,18 mm/min. Lubricant pump Crsdpszzv Uwsfx Adreh Voltage: 380 V Width: 800 mm Depth: 1300 mm Total height: 1900 mm Weight: approx 800 kg

Condition: used, Year of construction: 1980, machine/vehicle number: 18798, Item No. 25046 High-performance pillar drill Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling capacity in steel ST 60: 32 mm - Drill spindle mount: MK 3 long spindle - Drill spindle stroke: 180 mm - Continuously variable drill spindle speeds - Adjustable – Stage 1: 65 – 240 rpm - 130 – 480 rpm - Stage 2: 240 – 875 rpm - 480 – 1750 rpm - Overhang: 290 mm - Max. distance table – drill spindle: 620 mm - Table with 2 T-slots: 450 x 450 mm - Table with reversible function and permanently mounted machine vise Cedpfezxdhaox Adrorh - Table height adjustment via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement: approx. W 660 x H 1900 x D 700 mm - Weight: approx. 300 kg - Includes: - Quick-change drill chuck 1-13 mm

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, Alzmetall pillar drilling machine AB 35 S MK 4 Spindle speeds: 130 - 3500, stepless with 2 gear stages Right and left rotation 3-step feed Original paint Table: 620 x 470, no pre-drilled holes Overhang: 300 Column: 150 Drilling stroke: 180 Coolant system, quick-action drill chuck, emergency stop, tachometer – all in working order. Dimensions: H 1.97m, D 0.95m, W 0.62m Credpfez I N Tqsx Adroh Weight: approx. 600 kg Condition: original, runs smoothly and quietly, excellent runout. Free loading at D-88433 Schemmerhofen.

Condition: ready for operation (used), spindle mount: MK 4, rotational speed (max.): 3,500 rpm, rotational speed (min.): 130 rpm, throat depth: 300 mm, Alzmetall AB 35 / S Drill press, column drill Codpfxozqy I Ts Adrerh Pinole travel: 180mm Overhang: 300mm Spindle: MK 4 Drill chuck: 3-16mm Variable speed: 130 - 3500 rpm Feed rate: 0.1 - 0.2 - 0.3 mm/rev Threading device Coolant unit Vise You are welcome to visit us for an inspection. We will gladly arrange cost-effective shipping for you! You will receive a proper invoice. For foreign customers, a net invoice can also be issued. A valid VAT identification number is required. Subject to prior sale. Visit our shop and view our other offers. The company names and trademarks mentioned are the property of their respective owners and are used only for identification and description of the products. Deviations from technical data and errors in the description of the item may occur and are subject to change.

Condition: good (used), Year of construction: 1975, machine/vehicle number: 16344, Offer 25511 Technical data: - Drilling capacity in steel ST 60: 28 mm - Maximum drilling performance in steel ST 60: 32 mm Credpfxoy Rz Dfe Adrsh - Thread cutting device - Drill spindle mount: MK 3 long spindle - Drill spindle stroke: 180 mm - 10 spindle speeds: 250 – 2100 rpm - Throat approx.: 290 mm - Max. distance table – spindle approx.: 620 mm - Table with 2 T-slots, height adjustable: 520 x 450 mm - Drive: 400 V / 1.0 / 1.3 kW - Required space approx.: W 600 x H 1850 x D 700 mm - Weight approx.: 280 kg

Condition: good (used), Year of construction: 1979, functionality: fully functional, spindle mount: MK 3, For sale is a column drill press made by Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB3-ES • Speed: approx. 65 - 1,750 rpm • Quill stroke: approx. 180 mm Crodszvrt Sjpfx Adroh • Table size: approx. 515 x 415 mm • Year of manufacture: 1979 • With coolant pump • Condition: Used, functional The machine can be inspected and tested at any time! If interested, two identical machines are available! Shipping costs via freight carrier: approx. €190 Phone number: 01575 2236716 You will receive an invoice with VAT shown. Inspection/collection is possible by arrangement in 42855 Remscheid. Sale ex works 42855 Remscheid, free loading. Subject to errors in technical data and prior sale.

Condition: good (used), Year of construction: 1987, machine/vehicle number: 640, Offer 26231 Crjdpfx Ajzwm Uysdreh Technical specifications: - Drilling capacity in steel St 60: 45 mm - Drilling capacity in steel St 60: 55 mm - Drill spindle mounting: long spindle, MK 4 - Drill spindle speeds: infinitely variable in 2 speed ranges via AZ gearbox - 40 - 760 rpm - Drill spindle stroke: 140 mm - Overhang: 300 mm - Column diameter: 145 mm - Table with 2 T-slots: 460 x 420 mm - Distance table-drill spindle min / max: 35 / 640 mm - Distance drill spindle – processed base plate: approx. 1150 mm - 3 feed rates: 0.10 - 0.20 mm/rev - Drive: 400 V / 1.8 / 2.9 kW - Quick-change drill chuck - Machine vise - Space required: approx. W 600 x H 1800 x D 950 mm - Weight: approx. 380 kg

Condition: excellent (used), Year of construction: 1976, ALZMETALL AB 3ES Pillar Drill Drilling capacity in steel St 60 28 mm Drilling capacity in cast iron GG 20 35 mm Drilling capacity in St 60 35 mm Spindle mount MT 3 Throat 290 mm Quill stroke 160 mm Table stroke 592 mm Column diameter 115 mm Clamping area 510 x 300 mm Crodpfxjwg Hdve Adroh Spindle speed 130-1750 rpm Machine weight approx. 400 kg Year of manufacture 1976 With coolant system!

Condition: good (used), Year of construction: 1986, machine/vehicle number: 5122, Offer 26250 Technical data: Crsdpfsz I Sd Ssx Adreh Drilling capacity in steel ST 60: 32 mm Drilling capacity in steel ST 60: 40 mm Long spindle, MK 3 Drilling spindle speeds, continuously variable: 160 - 2250 rpm Drilling spindle stroke: 120 mm Overhang: 293 mm Column diameter: 115 mm Machined base plate with T-slots: 400 x 400 mm Max. distance from base plate to spindle: 600 mm Emergency stop button Space requirement: approx. W 450 x H 1250 x D 900 mm Weight: approx. 250 kg Quick-change drill chuck Table stand

Condition: used, Year of construction: 1990, bore capacity in steel (diameter) 35 mm throat 330 mm bore stroke 180 mm Crsdpfoz Euv Ejx Adrjh table surface area 765 x 620 mm

Condition: good (used), Year of construction: 1979, bore capacity in steel (diameter) 35.0 / 40.0 mm throat 300 mm bore stroke 180 mm turning speeds 110 - 1450 U/min table-size Ø 455 mm column diameter 155 mm Cjdjzl E Tkopfx Adrorh feed 0.1 / 0.2 / 0.3 m/min spindle taper MT 4 MK engine output 1.5 kW weight 450 kg range L-W-H 800 x 650 x 1850 mm Features: - Heavy-duty column drill press (V-belt drive) - Automatic spindle feed - Infinitely variable speed control - Fixed depth stop - Round machine table with T-slots * Height-adjustable via hand crank * Rotatable - Emergency stop button on the front - Coolant system with separate reservoir - Operatorâ??s manual

Condition: used, Bench drill, gear drill ALZMETALL Type AB 40 ST Production drill Manufacturer No. 750 Year of manufacture 1994 Drilling capacity 40 mm Spindle mount MK 4 - short quill Overhang 325 mm Quill stroke 200 mm Table size 740 x 460 mm Height adjustment of drill head 700 mm Distance spindle-table max. 1015 mm Spindle speed 56 - 2500 rpm 12 gear stages Automatic feed 0.15 - 0.2 - 0.3 - 0.36 mm/rev Motor power 4 kW Mains connection 380 Volt, 50 Hz - Spindle speed via 12 gear stages - Drilling and threading device with right and left rotation - Electric foot switch for switching the direction of rotation to left for thread cutting interruption - Rapid traverse via hydraulic quill movement - Semi-automatic operating sequence: rapid traverse - working feed - rapid return - Drill head height adjustment via hand crank - Table height adjustment via hand crank (table height from 740 to 1170 mm) - Coolant system - Control cabinet on the back of the machine - Mounted on a steel plate (1300 x 750 x 15 mm) with machine feet - Quick-change drill chuck METABO 3 to 16 mm Crjdeza Hzgepfx Adreh - Operating manual and electrical diagram Overall height with drill head at the top 2750 mm Space requirement L x W x H 1400 x 850 x 2300 mm Weight 1250 kg Good condition

Year of construction: 1970, condition: good (used), machine/vehicle number: Unbekannt, OFFER Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling capacity in steel ST 60: 32 mm - Drill spindle mount: MK 3, long spindle - Drill spindle stroke: 180 mm - Drill spindle speeds, stepless: approx. 140 - 1600 rpm - 3 feed rates: 0.1; 0.2; 0.3 mm/rev - Overhang: 290 mm - Max. distance, table to drill spindle: 620 mm - Rotary table with 2 T-slots: 450 mm Cjdpfx Aohglvkodrorh - Height adjustable via rack and pinion with hand crank - Coolant system - Drive: 380 V / 0.9 / 1.3 kW - Space requirement: approx. W 750 x H 1900 x D 700 mm - Weight: approx. 280 kg
