Used Danobat Danobat P1631 for sale (16)

Condition: ready for operation (used), Year of construction: 2005, punching force: 31 t, sheet thickness (max.): 6 mm, controller manufacturer: FAGOR, controller model: CNC 8070 Compact, CNC Punching Machine manufactured in 2005. This DANOBAT P1631 features a punching force of 30 tons and can handle a maximum sheet thickness of 6 mm. It includes an automatic loading system, servo-driven axes, and a hydraulic punching system. If you are looking to get high-quality punching capabilities, consider the DANOBAT P1631 machine we have for sale. Contact us for further details. • Machine features: • Servo-driven axes • Hydraulic punching system • Bosch hydraulic axis system • Sercos bus communication • Central lubrication system • Automatic indexing system • Scrap extraction system • Scrap suction unit • Optical safety barriers • Automatic clamps: 3 pcs • Sheet thickness measuring system • Encoder feedback on servo axes • Axes: • X axis • Y axis • Y1 axis • T Punch axis • T Die axis • C Punch axis • C Die axis • U2 loading axis • V axis (hammer rotation) • Z3 axis (sorting axis vertical up/down movement) • U3 axis (sorting arm lateral movement) • V3 axis (sorting arm lateral movement) Hjdpezbt Ayefx Aitsnn • W3 axis (sorting arm lateral movement) • X3 axis (sorting system translation axis) • Electrical data: • Voltage: 3x400V + PE • Frequency: 50/60 Hz • Main transformer: 30 kVA • 24V / 20A power supply Additional equipment • Automatic sheet loader (automatic loading system) • Automatic sheet elevator • Vacuum sheet handling system • Vacuum suction cups • Sheet separator blowing system • Ultrasonic height detector • Automatic centering system • OMRON inverter system • Electrical cabinet cooling fan

Condition: used, Year of construction: 2000, max swing 700 mm, X/Y 255/520 mm, 12-position upper tool turret and 8-position lower tool turret with driven tools, measuring head, tailstock, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 45kW, weight 15 t Hsdpfx Asym Sx Djitenn

Condition: used, Year of construction: 2000, max swing diameter 700mm, X/Y 255/520mm, tailstock, 12-position tool turret, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 45kW, weight 12t Hodpfsym Sm Uex Aitjnn

Condition: used, Year of construction: 2001, Control GE Fanuc Power Mate workpiece dia. 1,5 - 120 mm grinding length 254 mm dimensions of grinding wheel 610 x 254 x 304,8 mm Grinding wheel peripheral speed 35/50 m/s 305 x 254 x 127 mm engine 22/30 kW weight ca. 6.500 kg Hnodpfx Aszbvmbjitsn range L-W-H 4,10 x 2,25 x 2,40 m In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: good (used), Working wheel dimensions (od x id x width) Ø610x80xØ304.8 mm Brand CNC FANUC Model CNC 21 Oi TB Maximum length between points 1060 mm Max. travel Z axis 750 mm Max. length to be ground 600 mm Point height 225 mm Ø min/max to be ground 10 - 300 mm Max. weight of the piece 125 Kg Max. travel X axis 325 mm Grinding wheel speed 45 m/s Main motor power 11 Kw Working head speed 30 to 1000 rpm Working head cone MORSE 5 Working head motor power 12 Nm Tailstock cone MORSE 4 Tailstock quill travel 70 mm Tailstock hydraulic movement 150 mm Total power 22 Kw Length 2300 mm Height 1900 mm Width 2634 mm Hnodpfx Aetrgugsitjn Weight 7750 Kg Accessories Cooling equipment with paper filter; MARPOSS meter, positioner and balancer;

Year of construction: 2011, operating hours: 30,000 h, condition: ready for operation (used), travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, controller manufacturer: FAGOR, controller model: 8070, number of axes: 3, This 3-axis DANOBAT CHROMA 30 was manufactured in 2011. It features a punching force of 30 t, a maximum sheet thickness of 6 mm, and a working area of 3000 x 1500 mm. The machine operates at a punching speed of 1000 strokes/min and includes a tooling system valued at €20,000. If you are looking to get high-quality punching capabilities, consider the DANOBAT CHROMA 30 cylindrical grinding machine we have for sale. Contact us for further details. • Punching force: 30 t (300 kN) • Max sheet thickness: 6 mm (currently up to 4 mm galvanized steel) • Stroke: 35 mm • Punching speed: 1000 strokes/min • X-axis speed: 120 m/min • Y-axis speed: 80 m/min • Working pressure: 6 bar • Working area: 3000 x 1500 mm • Clamping system: 3 clamps with automatic repositioning/change • Number of stations: 27 (including 4 auto-indexed stations) • Tooling system: GOITI • Drive: Servo-electric (electric striker) • CNC: Fagor 8070 • Automatic clamp repositioning • Climate-controlled electrical cabinet • Apparent power: 7 kVA • Voltage: 400 V • Frequency: 50/60 Hz • Working hours: 30,000 • Maintenance: Annual inspections by manufacturer • Status: In operation • Demonstration: Can be seen running Additional equipment Hedpfx Asy Rzbkjitenn • Tooling set included (valued at €20,000)

Condition: good (used), Year of construction: 1999, Technical specifications Hsdpjv Tzxvsfx Aitsnn Ø: 1100 mm Rectangular: 1300 x 1100 mm

Condition: ready for operation (used), Year of construction: 2008, total height: 2,275 mm, total width: 4,040 mm, overall weight: 13,400 kg, product length (max.): 7,033 mm, number of axes: 2, Centerless grinding machine manufactured in 2008. This DANOBAT 327 MDA features a maximum wheel width for plunge grinding of 500 mm and a peripheral wheel speed of 50 m/s. It has a grinding wheel motor power of 55 kW and a regulating wheel speed that is infinitely variable from 10 to 225 min⁻¹. If you are looking to get high-quality grinding capabilities, consider the DANOBAT 327 MDA machine we have for sale. Contact us for further details. • Gross mass: 14,500 kg (including packaging) • Opening between wheels: 3 to 200 mm (with new wheels) Hnodpfxsyvfvhs Aitjn • Maximum wheel width for plunge grinding: 500 mm • Wheel axis height from floor: 1150 mm • Grinding wheel dimensions (OD x width x ID): 650 x 500 x 304.8 mm • Minimum grinding wheel OD: 510 mm • Peripheral wheel speed: constant 50 m/s • Regulating wheel dimensions (OD x width x ID): 350 x 500 x 203.2 mm • Minimum regulating wheel OD: 275 mm • Regulating wheel speed: stepless 10 to 225 rpm • Regulating wheel head inclination (part feed): -5° to +5° • Regulating wheel carriage swivel (taper correction): -2° to +5° • Maximum wheel profile depth: 12 mm • Maximum profile inclination (via tracer template): 30° • Dresser feed rate (grinding wheel): 100 to 300 mm/min • Regulating wheel dressing speed: 225 rpm • Dresser height adjustment: mm • Grinding wheel motor power: 55 kW • Regulating wheel motor torque: 8 Nm • Dresser motors (each): 0.55 kW • Grinding head lubrication pump motor: 0.37 kW • Grinding head lubrication system: 100 l capacity, 6 l/min flow, 2 MPa (20 bar) safety valve, oil FD-5 (ISO 3498) • General lubrication system: 6 l capacity, oil G-68 (ISO 3498)

Condition: excellent (used), MANUFACTURER: DANOBAT S. Coop. Ltda. YEAR OF CONSTRUCTION: 1988 SERIAL NO.: 35 POWER IN KW: 28 Table size: 2000 x 600 mm Indexing table: 600 mm Automatic Feed / Creep / Cycle X-travel: 3000 mm Y-travel: 1 mm Z-travel: 650 mm Table length: 3000 mm Table width: 1000 mm Hjdpeyr S Tlsfx Aitonn

Year of construction: 2007, condition: ready for operation (used), travel distance X-axis: 650 mm, controller manufacturer: SIEMENS, controller model: 840D, overall weight: 29,000 kg, number of axes: 4, This 4-axis DANOBAT HG 91-3000-B8 was manufactured in 2007. It features a CNC control system by SIEMENS 840 D, a maximum grinding length of 3,000 mm, and can handle workpieces up to 5,000 kg. The machine offers a swivel angle from -30º to +180º and a cutting speed of 45 m/s. Consider the opportunity to buy this DANOBAT HG 91-3000-B8 cylindrical grinding machine. Contact us for more information about this machine. • Center height over floor: 1,604 mm • Center height: 525 mm Hnsdpfx Aijycuiwoton • Max grinding length: 3,000 mm • Max grinding diameter: 850 mm • Max workpiece weight (between centers): 5,000 kg • Total machine weight: 29,000 kgX-axis (transversal carriage) • Effective travel: 650 mm • Max programmable speed: 6,000 mm/min • Min programmable speed: 0.01 mm/min • Min programmable increment (in diameter): 0.001 mm • Motor torque: 22 N·mZ-axis (longitudinal carriage) • Max programmable speed: 6,000 mm/min • Min programmable speed: 0.01 mm/min • Min programmable increment: 0.001 mm • Motor torque: 42 N·mB8 wheelhead • Swivel angle: -30° to +180° • Wheel dimensions: Ø760 x 80(100) x Ø304.8 mm • Cutting speed: 45 m/s • Power: 22 kWWorkhead • Spindle speed range: 10–120 rpm • Center cone: Morse 6 • Motor torque: 42 N·mHydraulic tailstock • Max taper correction: ±0.20 mm • Max center travel: 100 mm • Center cone: ASA 4Dresser • Location: Positioned on workhead and tailstock

Condition: excellent (used), Year of construction: 2001, center height: 525 mm, workpiece weight (max.): 5,000 kg, grinding length: 4,000 mm, grinding wheel diameter: 1,060 mm, The machine underwent a retrofit in 2024. Control: Siemens Sinumerik 840D. Hnsdpfx Aisw Ngm Ujten

Year of construction: 2007, condition: good (used), Danobat CNC Drilling / Sawing Line – Year 2007 Single Rotating Spindle. 18 metres In- Feed Rollers. 12 metres Out- Feed Rollers. Pincher Unit Feed. Infeed Cross Transfers. Outfeed Cross Transfers. Hnsdpfx Aieig T Ameton 750mm Capacity. Sawing Capacity: Round cutting capacity(without vertical jaws, angle 0 degrees) 520 mm. Rectangular cutting capacity (without vertical jaw, angle 0 degrees) 700mm X 500 mm. Maximum capacity with vertical jaws 700 X 500 mm. Round cut capacity with 45 degree turn, 450 mm. Rectangular cutting capacity with 45 degree turn, 450 X 500 mm.

Condition: used, Magnetic table surface: 1600 mm x 800 mm Hsdpfxjydxrle Aitsnn Maximum grinding length: 1600 mm Maximum grinding width: 900 mm Maximum grinding height: 800 mm Grinding wheel dimensions (od x id x width): Ø504 x Ø203.2 x 100 mm Weight: 12,500 kg

Condition: excellent (used), Year of construction: 1988, Magnet table 1.800 x 450mm, cross travel 580mm. New CNC Fagor 8037M 2018. Paper filter with magnet separator Hodpfjtqt Idsx Aitenn

Condition: used, functionality: unexamined, Danobat Universal Grinder model 1200 RP with automatic diamond dressing device, capable of working in automatic cycle, maximum grinding diameter 270mm, maximum wheel diameter 400mm, maximum wheel width 60mm, head power 12 HP. Hnjdpfx Aijw Iv Huoton

Condition: used, Year of construction: 2013, x-travel 30000 mm y-travel 3600 mm z-travel 1900 mm Control Heidenhain type TNC 530 i turning speeds 4000 U/min conus taper DIN 69871+AD mm Feed 10000 mm/min spindle drive 46 kW Rapid movement 25000 mm/min chip conveyor 2 St. Plate area 31000x2500 mm total power requirement 85 kW Soraluce No. 5619 Load hours 9332 On-time hours 27960 Panel array consists of: 1 panel 7000x2500 mm 4 panels 6000x2500 mm Optional: 4x clamping angles Tool package Clamping table The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are Hsdpfx Aieyqtnnetonn possible by appointment. We look forward to your visit. Your Markus Hirsch Team
