Used Doosan Used ​​Lathe Vertical for sale (50,456)

Condition: refurbished (used), Year of construction: 2008, functionality: fully functional, turning length: 1,000 mm, turning diameter over cross slide: 1,270 mm, turning diameter: 1,100 mm, spindle motor power: 55 W, spindle speed (min.): 5 rpm, spindle speed (max.): 850 rpm, travel distance X-axis: 580 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, workpiece weight (max.): 2,000 kg, total height: 4,012 mm, total length: 3,555 mm, chuck outer diameter: 800 mm, total width: 2,850 mm, spindle nose: ASA 15, overall weight: 22,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Used ​​2-axis vertical lathe "DOOSAN mod. Puma VT1100" with CNC Fanuc 21i-TB Kdedpfxjwrdqke Afdek

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 Kedpfx Afoxpqm Redjdk 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, type of input current: three-phase, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, workpiece weight (max.): 800 kg, number of slots in tool magazine: 30, controller manufacturer: Fanuc, total height: 2,700 mm, total length: 4,080 mm, total width: 2,400 mm, overall weight: 7,000 kg, table length: 1,200 mm, table width: 510 mm, controller model: Oi-MC, coolant supply: 15 bar, spindle motor power: 15,000 W, number of spindles: 1, rapid traverse Z-axis: 30 m/min, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, spindle nose: BT40, spindle speed (max.): 12,000 rpm, table load: 800 kg, Equipment: chip conveyor, rotational speed infinitely variable, Doosan NM510 Vertical Machining Centre Machine Type: 3 Axis Vertical Machining Centre Kdodpev Iq Ezefx Afdek Year: 2008 Control: Fanuc Series Oi-MC Condition: Very Good Includes Swarf Conveyor Chiller MCF20 Coolant Filter Autolube 6 x Tool Holders Notes Vice and clamping block in photos not included Technical Specifications Table Size: 1200 x 510mm Table Load: 800kg Travel (X-Axis): 1020mm Travel (Y-Axis): 510mm Travel (Z-Axis): 510mm Max Spindle Speed: 12,000rpm Spindle Power: 18.5/15/11kW Spindle Taper: BT 40 Rapid Traverse (X/Y/Z): 36/36/30m/min Tool Storage Capacity: 30 tools Tool Change Time (T-T/C-C): 1.7/3.5sec Machine Dimensions: 4080 x 2400 x 2700mm Machine Weight: 7,000kg Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: 23087A, SPECIFICATION Maximum grinding surface 140 x 300mm Distance between column and wheel axis 300mm Max.distance between table and wheel 280mm Rapid feed per turn of handwheel 2mm Micrometric feed by small handle 0.01mm Size of cup wheel 2.2kW Wheel speed 2840rpm Approximate weight 400kg MACHINE EQUIPPED WITH 260mm x 140mm x75mm (thickness) magnetic chuck Kjdevntguopfx Afdjdk Coolant system Guarding

Condition: used, Doosan Model S 550L CNC Lathe Control Fanuc 21T Swing over bed 710.0 mm Max turning dia 550.0 mm Max turning length 1130.0 mm Chuck dia 400.0 mm Spindle bore 102.0 mm Spindle nose 6 mt Spindle speed 30 – 2500 rpm Spindle motor power 22 kw Turret 12 stations, Feeds 0.001 – 133 mm/rev Rapid X 20m/min Z 24m/min Bar capacity 90.0 mm Kjdeyka Syepfx Afdedk Tailstock Swarf conveyor Manuals

Condition: excellent (used), Year of construction: 2011, machine/vehicle number: 6V0146, MACHINE SPECIFICATION Height of centres 170mm Swing over bed 350mm Swing over cross slide 196mm Swing in gap 535mm Width in front of faceplate 165mm Bed length between centres 650mm Spindle speeds (infinitely variable) 15-3250rpm Spindle nose mounting (Camlock) D1-4 Spindle bore 42mm Spindle motor 7.5kW Width over bedways 318mm Travel of cross slide 250mm Travel of top slide 100mm Travel of tailstock barrel 145mm Taper in tailstock barrel No. 4 MT Machine in Metric execution   MACHINE EQUIPPED WITH Acu-Rite 2 axis DRO System 3 Jaw chucks Quick change toolpost and 2-off toolholders Chuck guard Saddle mounted chip guard Kdodpswmm S Tjfx Afdek Coolant system Lighting Rear splashguard NB Machine ex display Dyson apprentice training facility, in excellent condition

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25728, Equipped with: Hydraulic Unit Sinumerik 840D sl CNC Control Slim Line Operator Panel OP012 W/12 TFT-Color Display 19" Machine Control Panel 20 Tool ATC CAPTO C6 Multifunctional Tool Carrier For Turning and Driven Tools One Fixed Tool Unit Assembled To The Compound Slide W/Coolant Thru The Turning And Drilling Tools, Coolant For The Driven Spindle From The Outside Drilling Spindle Additional Drill Spindle For Orientation Chip Conveyor Coolant Equipment -Including piping and shut-off valve and flow control switch -To supply coolant to tools for coolant and flushing through the cutting tools -To supply coolant for flushing the work piece and chuck -To supply coolant for flushing the working area Paper Band Filter Immersion Cooler High Pressure Coolant Pump, 40 Bar Through Tools Flushing Pistol, Hand Held Air Cleaner - Mechanical Separation "Mist Collector" Tool Life Display Remote Diagnostics Signal Lamp Automatic Door For Loading W/Shuttle Load and Unload Shuttle Swivel Loader Automation Cell Tuned for Part Pallet Conveyor For 20 Raw And Finished Parts Pallets Pallets Designed for Part 596500 Handling System SPC Station (Maximum O 270 mm, Maximum H 150 mm, Maximum Wt. 12 kg) NIO Station (Closing forward leading gravity) Skiving Software (Hardware: Software and user surfaces for skiving technology) Measuring Probe (For measuring diameters and length of the workpiece in the machine) Measuring Software for Teeth Measuring (MDK and Flank Line, Software and User) Measuring Program (Automatically measuring program for measure the position of the two gears to each other, after using sister tools) SPC (Every X workpieces the MDK needs to be measured) Tool Changer (Precut, measurer and final cut) Skiving Tool Identification (Hardware, software for the identification of the skiving tool after tool change) Hydraulic Diagrams Coolant Diagrams Lubrication Diagrams Electrical Wiring Diagrams Hardcopy of Diagrams CF Certificates Specifications: Workpiece Spindle: -Speed: 0-7000 l/min -Power: 55,2 - 59,7 kW Tool: Capco C6 Tool Spindle: -Speed: 0-6000 l/min -Power: 29 - 41 kW Machine Weight, Floor Space and Voltage Supply: -Operating Voltage: 400V, 3 Phases, 50 Hz -Control Voltage: 24 V -Lighting Voltage: 240 V, 50 Hz -Floor Space: 2,700 x 2,600 mm -Height: 4,000 mm -Total Weight, Approximate: 16,000 kg Longitudinal, Z-Axis: -Stroke: 800 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Transverse, X-Axis: -Stroke: 900 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Tool Spindle, B-Axis: -Range: -20 / +90 Degree Y-Axis for Spindle Unit: -Stroke: 200 mm -Rapid Rate: 12 m/min -Feed Force: 6 kN C-Axis Main Spindle: -Positioning Accurace: 9" Kedsw Iqumopfx Afdsdk Multifunctional Tool Carrier: -Power: 29 kW at 100% ED -Power: 41 kW at 44% ED -Torque: 141 Nm at 100% ED -Torque: 212 Nm at 44% ED -Spindle Speed: 0-6000 min-1 -B-Axis for Stepless Motion in a Range Of: -20/+90 Degree Tool Magazine: -Maximum Tool Diameter: 100 mm -Approximate Tool Length: 300 mm -Approximate Tool Weight: 12 kg Swivel Loader: -Maximum Workpiece Diameter: 270 mm -Height: 150 mm -Weight: 16 kg

Condition: good (used), Vertical lathe BERTHIEZ Brand: BERTHIEZ Table diameter: 2550 mm Max. turning diameter: 2800 mm Machinable height: 2300 mm Max. load: 25 t Kedpey Egb Sjfx Afdodk Speeds: 1 - 160 rpm Floor dimensions: 4000 x 4000 mm

Year of construction: 2014, condition: used, Empty weight: 4.050 kg Dimensions (LxBxH): 299 x 178 x 275 cm Serial number: ML0032-000444 Swing diameter above bed: 651 mm Swing diameter above slide: 461 mm Recommended swivel diameter: 254 mm Max. Turning diameter: 370 mm Max. Turning length: 712 mm Hollow spindle: 76 mm Kdsdpfxjy D Ex Ts Afdjk X-axis displacement: 255 mm ( 185 + 70) Z-axis displacement: 790 mm Spindle speed: 3500 rpm Tool changer: 12 positions Rapid traverse (X/Z axis): 30 / 24 m/min Control system: Siemens Sinumerik 828D Weight: 4050 kg Dimensions (LxWxH): 2993x1785x2750 mm Equipped with: tool setting device, parts catcher, chip removal, oil mist extraction and documentation Online auction of well maintained metalworking machines (a.o. 2015 DOOSAN LYNX, 2015 DOOSAN DNM500-II, UNISIGN, GILDEMEISTER, MORI SEIKI, KELLENBERGER, OKUMA, SUNNEN etc.), grinders, (overhead) cranes and rolling stock (a.o. 2x HYSTER forklifts) originating from the recent bankruptcy of NPL Machinefabriek BV, manufacturer of gears and technical components for machine building, in Hengelo, The Netherlands. The online auction opens Wednesday 1 April and closes Thursday 23 April. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Friday 17 April Pickup days are on: - Monday 4 May - Tuesday 5 May Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with confidence. Unlike general auction houses, Dome Auctions specializes in selling complete industrial assets directly from factories, ensuring quality and reliability. With a commitment to transparency, industry expertise, and tailored service, we streamline the sales process and maximize value for all parties. As online auctions continue to grow in the European industrial market, Dome Auctions offers a professional and efficient solution for companies seeking high-quality machinery at competitive prices.

Condition: excellent (used), Faceplate: 2500 mm Kdsdpfx Afsy D Tw Dedsk Max. turning diameter: 2800 mm Max. turning height under tool edge: 1500 mm Spindle speed: 110 rpm Workpiece weight: 10 tons Digital readout Jaw boxes

Condition: good (used), Year of construction: 1999, Ref. -No.: 10638 Manufacturer: TOS HULIN Type: SKA 12 CNC Year of construction: 1999 Type of control: CNC Control: Sinumerik 840 C Storage location: Halberstadt Country of origin: Czech Republic Turning Diameter: 1450 mm Turning Height: 1450 mm Tool Taper: SK50 Power Capacity: 60 kW Planar disk: 630 RPM Planar disk: Ø 1250 mm Head Magazine: 30 academic subject Plate magazine: 24 academic subject Further information: Kdedpfx Afey Ed Suodjk - Hydraulically operated power chuck - Drive for rotary tools - Third controlled C-axis - Heidenhain linear scales in X and Z - Chip conveyor and extraction system - Renishaw for tool control The machine can be viewed under power by arrangement.

Condition: good (used), Year of construction: 2018, Ref. -No.: 10531 Manufacturer: HONOR SEIKI Type: VL - 400CM Year of construction: 2018 Type of control: CNC Control: Siemens SINUMERIK 840D Storage location: Halberstadt Country of origin: Taiwan Machine-No.: 79XXX C-Axis: Yes C-axis speed: 50 - 2250 RPM Turning Height: 2370 mm Table Diameter: 4000 mm Rapid Travel Speed X-Axis: 10 m / min Rapid Travel Speed Z-Axis: 10 m / min Rotate table rotation speed: 1 - 85 RPM Max. Workpiece Weight: 30 kg Max. Turning diameter: 4 mm Distance between faceplate and crossbar support: 820-3320 mm Work feed: mm / min Number of tools in the chain magazine: 24 Kdsdoy Ed Ezspfx Afdok Crossbar adjustment: 300 x 300 mm Spindle motor drive: AC60/75/100 kW Servo motors (X/Z axes): 5,5 / 5,5 kW Machine length: 9 mm Machine width: 7000 mm Machine Height: 8000/9100 mm Weight Of The Machine Ca.: 115 t Further information: - 2-stage gear change - ATC (Automatic Tool Change) 16/20/24 - Tool size 25 x 32 x 40 - Driven tool motor AC15/18.5 Machine is still in production and can be inspected by appointment.

Condition: good (used), Year of construction: 2013, operating hours: 44,500 h, EMAG VL5i vertical turning machine (2013) Manufacturer: EMAG Type: VL5i Year of manufacture: 2013 Kodpfx Ajy Ef Hmsfdjdk Operating hours: 44.500 Condition: good, used, in production Control SIEMENS 840 D SL Emulsion mist extraction chip conveyor Further information will follow

Condition: good (used), Year of construction: 1990, FOR SALE: Kdedpfxeyr Irqs Afdok BERTHIEZ TFM 160 N Vertical Lathe (Rebuilt) Description: For sale: High-performance vertical lathe from the French brand BERTHIEZ, model TFM 160 N. This benchmark machine, renowned for its exceptional rigidity, is ideal for machining large-diameter, heavy circular parts. History and Maintenance: Origin: Made in France Technical Specifications (Standard BERTHIEZ TFM 160): Table diameter: 1,600 mm Maximum swing diameter: approx. 2,000 mm Maximum height under cross rail: approx. 1,500 mm Maximum admissible table load: approx. 10 to 15 tons Type: Vertical lathe with NUM CNC control.

Condition: used, Year of construction: 2009, faceplate diameter 1800 mm swing diameter 2000 mm turning height 1500 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min power capacity - table 100 kW Torque 31784 Nm total connected load 218 kW weight of the machine ca. 55 t Turning- and Boring heads: - 4 x Turning heads + steelholders - 3 x Turning heads for Capto - 1 x Boring head (driven) - 2 x angular boring heads (Manufacturer Benz) Dimensions: - Turning diameter on the faceplate 2000 mm - Faceplate diameter 1800 mm - Turning height with turning head L100 1500 mm Power on the ram: - Clamping force of tool holder or accessories 120,000 N - Max. Feed force Z and X axis 30,000 N - Drive power of the milling, drilling and grinding spindle 37 kW - Speeds for turning 10 - 3000 rpm Travels: - Axis X, horizontal support on the crossbeam -2270/+2275 mm - Axis Z, vertical support on crossbeam 1250 mm - Axis C, table rotation 360° Feed speeds: - Axis X 15,000 mm/min - Axis Z 15,000 mm/min - Axis C 3.25 rpm Coolant system: - Coolant system filter system 1500 l Chain tool magazine with 80 places: - max. tool weight 30 kg - Max. tool diameter with free auxiliary slots 250 mm Disk magazine with 12 slots: - max. weight of tool holders/accessory units 150 kg - max. length of tool holders 500 mm - max. magazine load 1000 kg Pallet changer with 2 pallets: - Pallet diameter 1800 mm - Pallet load capacity (centered) 5000 kg - Pallet load capacity (on center) 4000 kg Equipment / accessories: - 1x pallet with claw boxes, diameter 1800 mm - 1x hydraulic chuck with base jaws, diameter 1800 mm Kjdpfxovylilo Afdedk - Various drilling and milling heads - Various turning tool holders - 2x measuring probes

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece weight (max.): 60,000 kg, wheel width: 4,300 mm, feed length X-axis: 2,200 mm, feed length Y-axis: 2,500 mm, feed length Z-axis: 1,500 mm, position of the milling head: 0,02, table diameter: 3,500 mm, feed rate X-axis: 10 m/min, feed rate Z-axis: 6 m/min, total length: 6,000 mm, wheel diameter: 4,300 mm, total height: 7,000 mm, total width: 5,000 mm, workpiece diameter (max.): 4,300 mm, milling spindle length: 2,500 mm, type of input current: three-phase, milling length: 2,500 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 1 rpm, Vertical Turning and Milling Lathe VL 40 CNC Turning Center’s Specifications Nominal Turning Envelope Faceplate Diameter 3.500 mm Machining Diameter: -maximum -minimum 4.000 mm 0 mm Kdedpfey Dfraex Afdok Swing diameter 4.000 mm Machining Heights 2.000 mm Work Piece Weight 60,000 kg Nominal Turning Travels X - Axis Ram Carriage From -100 mm To 2.250 mm + ATC travel Z - Axis Ram 1.500 mm Work Table WorkTable Diameter 3.500 mm Normal face plate with T-slots Work Table Speed: -for machining 1 - 110 rpm Power Continuous S1/ S6 57/75 kW Torque Continuous S1 / S6 70,000 / 90.000 Nm Turning main drive mechanism Gear box reducer and belt transmission, C axis drive Work Table Milling Speed 0.02 to 2 rpm Milling Torque Continuous S1 43,000 Nm Locking Table Torque (hydraulic double side devices) 60,000 Nm Z - Axis Ram Turning & Milling Ram Ram Size 300 x 300 mm Tool shank size: Shank 32*32 / 40*40 mm automated tool clamping Ram Speed 0 to 2.500 rpm Power Continuous S1 22 kW Torque Continuous S1 1.400 Nm Driving mechanism ZF gearbox, two stages, belt transmission ZF gearbox and main spindle bearing sets are supplied with coolant systems, individually for each. Tool taper BT 50 DIN 69871 / automated tool clamping Tool Storage Number Of Tool Magazines two ATC -one for left side, 20 turning/milling/drilling stations -one for right side 20 milling/drilling and part probe Tool Storage 20 + 20 ATC turning capabilities: Maximum Singular Tool Weight – turning toolholder Maximum Singular Tool Weight – milling/drilling toolholder Total Tool Weight Maximum tool size – turning Maximum tool size – milling Maximum tool size - drilling Maximum length 50 kg 25 kg 600 kg 250 x 150 mm Dia. 300 mm Dia. 120 mm 600 mm Axes Drives X and U - Axes Ram Carriage Power Continuous S1 5.5 kW Thrust Continuous S1 40,000 N Z-Axis Ram Power Continuous S1 5.5 kW Thrust Continuous S1 40,000 N Power Continuous S1 11 kW Axes Rates X And Z - Axes Feed Rates 0.02 to 6,000 mm/min X And Z -Axes Rapid Rates 10,000 mm/min Coolant System Coolant Tank Capacity 2.000 L Coolant Pressure / Flow Rate: -internal coolant (turning) -internal coolant (milling) / pressure adjustments steps Filtration unit: -type 6 bar at 100 LPM 30 bar at 60 LPM Cartridge type Chips conveyor Conveyor type Hinged , frontal placed

Condition: ready for operation (used), functionality: fully functional, turning height: 2,000 mm, turning diameter: 5,000 mm, faceplate diameter: 2,500 mm, rotary table diameter: 2,500 mm, overall weight: 38,000 kg, The machine is connected to power and, following modernization in 2008, can be inspected and tested by prior arrangement. CNC system Siemens Sinumerik. Kdodpfjy Ef A Isx Afdsk

Condition: good (used), Year of construction: 2007, travel distance X-axis: 6,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 200 mm, - Speed range: [rpm]: 6,000 - Torque: [Nm]: 480 - Max. turning diameter over bed: 290 mm - Chuck diameter: 200 mm - Turret: 12-position, VDI 40, Sauter - Driven tools: 7.8 kW - Travel: - X-axis: 550 mm - Z-axis: 200 mm - Rapid traverse (X/Z) [m/min]: 30 / 20 - Feed (X/Z): [m/min.] 11 kN Ksdpfxoy Dc Ifo Afdsdk - Features: - Left-hand chip conveyor; 300 mm wide; ejection height 800 mm - Probe; direct linear measuring system; glass scales on all axes - Heidenhain circulating pickup tape - Machine with feed belt for part loading - Specification: - Overhauled in 2007 for approx. €50,000, complete headstock replaced. - Feed unit exchanged.

Condition: used, Year of construction: 2007, faceplate diameter 2500 mm max. swing diameter over bed 2700 mm turning height 2500 mm Control Siemens 840D CNC workpiece weight max. 30 t workpiece dia. 2500 mm Crossbar travel distance every 100 mm 1200 mm Piston rod 1500 mm ram diameter 250 x 250 mm traversing speed 8 m/min Max. vertical feed rate 6000 mm/min Max. cross feed 8000 mm/min Speed of the machine table 180 U/min tool changing time 1 min cutting speed 140 m/min Cutting depth 14 mm Power Capacity of main drive 100 kW weight of the machine ca. 47 t dimensions of the machine ca. 12,5 x 8,0 x 6,7 m Features/Accessories: - Crossbars every 100 mm, including locking mechanism - 2 ram units with a cross-section of 250 x 250 mm; travel distance 1500 mm - Both ram units can be moved through the center (100 mm each, i.e., both ball screws Kedsy Dvlwopfx Afdjdk are offset from each other with collision protection - ZF gearbox for main drive: AC 100 kW / S1 Siemens, speed 0–180 rpm - 2 tool changers, each with 16 stations - Max. tool weight 50 kg; max. 800 kg in the tool changer - 2 Renishaw touch probes with zero-point touch - Renishaw touch probe for workpiece measurement

Condition: used, swing diameter 2000 mm turning height 1800 mm Control Siemens Sinumerik 840 Dsl turning speeds range 2,8-315 U/min cross rail adjustment - vertical 1200 mm cross rail adjustment - horizontal +/- 1150 mm 1500 mm bit feeder section 240 x 240 mm Minimum immersion diameter 340 mm cutting capacity 50 kN max. torque on the faceplate 50000 Nm speed range step 1 2,8 - 80 U/min Kdedpfx Afsy Dvlqodek speed range step 2 12 - 315 U/min Max. clamping weight 12000 Kg power capacity faceplate 105 kW weight of the machine ca. 33 t dimensions of the machine ca. 10 x 5 x 6,5 m Further technical data: - Feed range of three-phase servo motors: 1–3000 mm/min; 0.01–50 mm/rev - Crossbeam travel speed: 425 mm/min Features/Accessories - Increased turning height (+600 mm) - Z-axis extended to 1500 mm - Magazine capacity: 20 positions - Magazine type: disc magazine - Max. tool length: 525 mm - Chip conveyor - Workpiece measurement - Renishaw probe - Coolant tank capacity: approx. 2000 litres - Coolant pump flow rate: 60 litres/min at 2 bar Overhaul: - Extensively overhauled in 2012 by Siemens Industry Munich - Items overhauled included: control system, cabling, motors, measuring systems, etc. - Further information can be found in the PDF

Condition: ready for operation (used), Year of construction: 2018, CNC vertical lathe, 4 axes Brand: UMARO Model: SC27 Kedpow Add Eefx Afdjdk Year: 2001 / 2018 (retrofit) CNC: FANUC 0i Specifications: Turning capacities: Max pass-through diameter: 2650 mm Max turning diameter: 2600 mm Max turning height: 1900 mm Table: Diameter: 2500 mm Max load: 15 t Turning speed (2 ranges): 1 to 112 rpm Main motor power: 75 / 60 kW Cross rail carriages: Vertical travel of right carriage: 760 mm Vertical travel of left carriage: 580 mm Cross rail: Vertical travel: 1600 mm Dimensions (W x D x H, fully extended): 5 x 4.8 x 4.8 m Equipped with: Grinding spindle on left carriage Set of 4 jaws

Condition: used, Year of construction: 2020, controller manufacturer: Siemens, controller model: 840 Dsl, _____ Description: Year of manuf. : 2020 Control : Siemens 840 Dsl Turning diam. : 140 mm Turning length : 700 mm In General: Max. workpiece diameter:140 mm Chuck diameter:250 mm Max. turning length:700 mm Track I: Tool carrier I:Tool turret (X/Z) Tool drive:9,600 rpm, 44 Nm Tool holder:BMT Number of stations:11 + 1 Part gripper X-axis:310 mm Z-axis:1,115 mm Position sensors (X/Z):Direct scales Track II: Main spindle (OP10):Travelling direct drive spindle Speed:5,000 rpm Power:33.9 kW Torque:231 Nm Chuck:Collet chuck Clamping cylinder:Hydraulic clamping cylinder Support control:Pneumatic W-axis:772 mm C-axis:0.01° Position sensor (W):Direct scale : Sub-spindle (OP20):Direct drive spindle Speed:5,000 rpm Power:33.9 kW Torque:231 Nm Chuck:2+2-jaw power chuck Clamping cylinder:Hydraulic clamping cylinder C-axis:0.01° Track III: Tool Carrier II:Tool turret (X/Y/Z) Tool drive:9,600 rpm, 44 Nm Tool holder:BMT Number of stations:11 + 1 Part gripper X-axis:310 mm Y-axis:50 mm mm) Z-axis:1,115 mm Position sensors (X/Z):Direct scales Kdedpfx Aoy A U I Isfdsk Track IV: Main spindle (OP30):Travelling motor spindle Speed:5,000 rpm Power:33.9 kW Torque:231 Nm Chuck:Collet chuck Clamping cylinder:Hydraulic clamping cylinder Support control:Pneumatic W-axis:988 mm C-axis:0.01° Position sensor (W):Direct scale : Tailstock:Fixed arrangement Quill:Hydraulic with position control Track V: Tool Carrier III:Milling/turning turret (X/Z) Tool drive:1,000 rpm, 240 Nm Tool holder:HSK-63 Number of stations:5 + 1 Part gripper X-axis:310 mm Z-axis:1,115 mm Position sensors (X/Z):Direct scales Automation: Feed conveyor:O-type, 18 base carriers Discharge conveyor:O-type, 18 base carriers Part transfer:3 grippers on tool turret Max. workpiece diameter:140 mm Max. workpiece height:630 mm Workpiece weight:max. 20 kg Equipment: Position measurement systems:Direct (glass scales) Chip removal:Chip conveyor Workpiece measurement:Renishaw OMP Coolant supply:Internal coolant with filter, 17 bar Coolant temperature control:Immersion recooler Emulsion mist separator:Mechanical Software option I:Turning/milling operation Software option II:Automatic retraction Software option II:Sister tool management

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Kdodsyzy Tyjpfx Afdek Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 Kdedpfx Afovb Dcasdek cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to dimensions of the machine ca.: 9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor *

Condition: used, Technical details: faceplate diameter: 1800 mm swing diameter: 2000 mm turning height: 1170 mm z-axis: 1000 mm cross rail adjustment - vertical: 800 mm faceplate speeds:: 2,5 - 280 workpiece weight: 12 t feeds: 1 - 6000 mm/min Kodpfx Asvb Db Nofdedk max. torque on the faceplate: 50000 Nm total power requirement: 85 kW weight of the machine ca.: 41 t dimensions of the machine ca.: 5,6 x 4,8 x 4,6 m Machine retrofit and overhould in 2005 with SIEMENS 840 D powerline control - 6 jaw hydraulic power chuck - tool changer for 12 tools - chip conveyor, coolant attachment, splash housing - various tool holders *
