Used Gendron External/Internal Cylindrical Grinding for sale (15,952)

Condition: used, Year of construction: 1990, External/Internal Cylindrical Grinding TARDUGNO RIBON type MODULE 2A Between points: 1000 mm Centre height: 180 mm Workpiece holder spindle CM4 Maxi grinding diameter: Ø 360 mm Workpiece holder rotation: from 35 to 310 RPM Year of construction: 1990 Tilting table - 9° / + 6° Grinding wheel dimensions: Ø 406 mm x thickness 60 mm Scale on table X Nwodpozww Siefx Afvok Spindle speed: 1500 - 1730 RPM Grindstone motor: 5,5 CV Hydraulic tailstock CM3 Auto wheel advance Internal grinding spindle: Max speed 20000 RPM Maxi boring: from 14 to 75 mm Lubricant tank+ paper filter Diamond system Tilting grindstone holder trolley Supplied with grinding wheels + steadies Voltage: 380 V Dimensions (L x W x H): 3800 x 2000 x 2200 mm Weight: approx 3,2 T

Condition: used, External/Internal Cylindrical Grinding GENDRON RU 28.100 Between points: 1000 mm Maxi grinding diameter: Ø 290 mm Tool holder rotation: from 70 to 370 RPM 4-jaws Ø 200 mm chuck Njdpfx Afozww Rfjvswk Grinding wheel: Ø 300 mm Auto pass plug Swivel table External hydraulic group External lulbricant tank Voltage: 380 V Dimensions (L x W x H): 3000 x 1900 x 2000 mm Weight: approx 3 T

Condition: used, External/Internal Cylindrical Grinding JONES-SHIPMAN type 1310 Nwsdpfx Aozww I Rsfvjk Capacity: Ø 200 x 450 mm (8'' x 18'') Tilted table Grinding wheel: Ø 300 mm x thickness 25 mm x bore Ø 125 mm Drive wheel speed: 1750 and 2300 RPM Rotary grindstone holder support Supplied without internal grinding spindle Equipped with 1 lubricant tank Voltage : 380 V Length: 1800 mm Depth: 1600 mm Total height: 1900 mm Weight: approx 2 T

Condition: refurbished (used), Year of construction: 2025, Studer S30 Maximum distance between centers: 125 mm Distance between centers: 650 mm Workpiece weight: 80 kg Additional optional features: - Completely new control cabinet with basic PLC and panel - Conversion to ball screw drive incl. PLC Pro (cycle-controlled) Nwedpfxod Hdxwo Afvjk - "Workpiece memory" PLC Pro for 10/15/30/50 workpieces - Glass scale in X and Z axes - Swivelable internal grinding device - Motor spindle for internal grinding device - Frequency converter for external grinding spindle - Frequency converter for internal grinding spindle - In-process grinding sensor - Guard for external grinding spindle - Safety door - manually operated - Grinding wheel flange - LED spotlight with flexible arm - Matching coolant system

Condition: like new (used), Year of construction: 2023, operating hours: 200 h, functionality: fully functional, center height: 175 mm, center width: 650 mm, The machine was accepted by Studer and has never been put into operation. Njdpfjyttcqex Afvowk

Condition: ready for operation (used), Year of construction: 1983, functionality: fully functional, machine/vehicle number: 8151, rotary table diameter: 800 mm, grinding height: 750 mm, workpiece weight (max.): 800 kg, total height: 4,100 mm, total width: 26,650 mm, total length: 44,000 mm, feed length Y-axis: 750 mm, feed length Z-axis: 550 mm, overall weight: 13,000 kg, grinding wheel diameter: 400 mm, disc diameter: 400 mm, grinding spindle speed: 1,460 rpm, grinding diameter: 800 mm, control cabinet width: 650 mm, type of input current: DC, control cabinet height: 1,900 mm, control cabinet length: 1,800 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 1,460 rpm, table load: 900 kg, workpiece diameter (max.): 850 mm, grinding wheel width: 60 mm, table width: 1,240 mm, power: 35 kW (47.59 HP), rapid traverse X-axis: 2 m/min, rapid traverse Y-axis: 100 m/min, rapid traverse Z-axis: 2 m/min, space requirement height: 4,100 mm, space requirement length: 5,100 mm, space requirement width: 2,655 mm, Good day, For sale is a well-preserved and completely functional Sielemann cylindrical grinding machine for the following applications: surface grinding, internal grinding and external grinding. The machine has a swivel stand with 3 different sanding heads for the respective area of application. Complete machine documentation is available and can be presented upon inspection. The Sielemann offered here has always been serviced and maintained, most recently the components listed below were replaced: - 3x New weight compensation cylinders - 1x new hydraulic unit (complete) - New guideway covers - Revised rotary table group Technical data Machine length: 4.400mm Machine width: 2,655mm Machine height: 4.100mm Machine weight: 13.000Kg Nsdsrntirspfx Afvswk Control cabinet width: 650mm Control cabinet height: 1.900mm Control cabinet length: 1.800mm Grinding table diameter: 800mm Grinding table load capacity: 800kg Grinding table drive power: 0.21 - 14.5KW Grinding table speed: 100 1/min (both directions) Grinding table workpiece clamping: Magnetic clamping plate incl. T-slots Z-axis travel (grinding table): 550mm Maximum grinding height (Y): 750mm Lubrication pump Masch. Bed: 0,18KW Lubrication pump Masch. Column: 0,1KW Leak oil pump: 0,065KW Hydraulic pump: 1.5KW 1) External round grinding head Spindle drive power: 11KW Spindle speed: 1,450 1/min Grinding wheel: 400x50mm Cone grinding spindle mount: D=65mm Taper pitch: 1:5 Feed speed (Y): 100 mm/min 2) Internal round grinding head Spindle drive power: 5.5KW Grinding wheel: Variable Feed speed (Y): 100 mm/min 3) Flat-round sanding head Spindle drive power: 11KW Spindle speed: 1,800 1/min Grinding wheel: 400x50mm Cone grinding spindle mount: D=65mm Taper pitch: 1:5 Feed speed (Y): 100 mm/min Viewing appointments possible at short notice by arrangement !!! With kind regards R.Suckow / Managing Director UNITTOOL Werkzeugmaschinen GmbH 33758 Schloß Holte Stukenbrock Görlitzerstraße 9

Year of construction: 1979, condition: ready for operation (used), Components: headstock, main spindle, faceplate flange, taper, table, guideway, longitudinal guide, cross guide, tailstock, workpiece holder, tailstock taper, workpiece spindle. With documentation and records. An on-site inspection is possible. Nwsdpoyln Dtsfx Afvjk

Year of construction: 2016, condition: ready for operation (used), Grinding wheel diameter: 220mm, grinding wheel width: 5mm, base body width: 20mm, bore diameter: 52mm. Test piece: diameter: 100mm, width: 300mm, profile height: 35mm. Small workpiece: Outer diameter: 400mm, bore diameter: 205mm, wheel width: 100mm, torque: 20Nm, weight including mandrel: 200kg. Large workpieces: Outer diameter: 700mm, bore diameter: 350mm, disk width: 300mm, torque: 800Nm, weight: 250kg. Accuracy: Repeat accuracy: less than 2µm, axial and radial run-out accuracy (large spindle): less than 2µm at 400mm diameter, axial and radial run-out accuracy (small spindle): less than 2µm at 200mm diameter, parallelism over 300mm between test piece and workpiece axis: less than 2µm. Tool spindle speed: 10000rpm, small workpiece spindle: 23000rpm, large workpiece spindle: 6000rpm, test piece spindle: 1000rpm. Nwjdjv T Aqgjpfx Afvsk

Condition: ready for operation (used), Workpiece diameter with/without steady rest: 400mm/250mm, max. workpiece length: 750mm, spindle head load: 400kg, max. internal grinding diameter: 350mm, max. grinding depth: 500mm, travel X/Z: 300mm/1000mm, max. traverse speed: 15m/min, control system: Siemens Sinumerik. Documentation available. On-site inspection is possible. Nwodsx Uq T Dopfx Afvjk

Condition: excellent (used), Center height 300 mm Distance between centers 3500 mm Nedpfx Afjtpgnhsvowk Grinding wheel 760 x 305 x 100 mm With DRO With measuring control MARPOSS Misc.accessories MARCELS MASCHINEN AG

Year of construction: 1958, condition: ready for operation (used), Grinding length: 1500mm, center height: 175mm, max. workpiece diameter: 350mm, max. workpiece weight: 300kg, grinding wheel diameter: 450mm, grinding wheel width: 80mm, bore: 203mm. Machine dimensions X/Y/Z: approx. 3600mm/1900mm/1900mm, weight: approx. 4000kg. Documentation available. An on-site inspection is possible. Nwedpoyg Nvmsfx Afvjk

Condition: refurbished (used), Year of construction: 2023, operating hours: 3,000 h, functionality: fully functional, center height: 180 mm, workpiece weight (max.): 200 kg, grinding length: 1,000 mm, center width: 1,000 mm, grinding wheel diameter: 500 mm, total width: 2,600 mm, total length: 4,700 mm, total height: 2,200 mm, grinding diameter: 300 mm, workpiece weight between centers: 200,000 g, type of input current: three-phase, workpiece diameter between centers: 300 mm, workpiece length between centers: 1,000 mm, grinding wheel width: 100 mm, spindle speed (max.): 1,200 rpm, spindle speed (min.): 10 rpm, feed length X-axis: 320 mm, feed length Z-axis: 1,100 mm, feed rate X-axis: 1,000 m/min, feed rate Y-axis: 1,500 m/min, grinding spindle speed: 1,700 rpm, overall weight: 7,500 kg, pivoting range: 30 °, warranty duration: 12 months, year of last overhaul: 2023, input frequency: 50 Hz, rapid traverse X-axis: 1,000 m/min, rapid traverse Z-axis: 1,500 m/min, input voltage: 400 V, Schaudt PF43 U1000, manufactured in 1994, retrofitted (premium refurbished) by GSN in 2023. Siemens Sinumerik 840 D SL control system. Low operating hours, approximately 3000 hours since the retrofit. MK4 workpiece spindle, MK4 tailstock. Grinding travel: 300mm Workpiece length, including clamping devices, at maximum grinding travel: 450mm Grinding wheel dimensions: 500x100mm Bore diameter: 203.2mm Controlled workpiece circumferential speed (WUG) SUG external cylindrical grinding spindle: 45m/s Freely positionable, automatic B-axis Machine with new, fully enclosed splash guard GSN measuring head Diatronic 22 including C2 and W axes/turret Touch probe sensor with hydrophone (water jet) including collision monitoring Tailstock retrofitted with automatic cylinder error compensation Clamping/unclamping adjustable via hydraulic clamping device Nsdpfx Aezcfnqjfvewk Upgrade to a 15" screen on the control panel NEW PRICE GROSS 2023: €407,432.20 plus additional tools, etc.

Condition: ready for operation (used), A Joerg CNC precision cylindrical grinding machine for tools and rotationally symmetrical precision parts is available. Workpiece diameter range: 0.1mm-16mm, Speed: 10000rpm, Workpiece holding: W20/W25, Max. workpiece length: 250mm. Machine dimensions X/Y/Z: approx. 1900mm/2000mm/1950mm, Weight: approx. 3000kg. Documentation available. An on-site inspection is possible. Nwsdjzhb Ebopfx Afvek

Condition: used, Manufacturer: Gendron Type: RU 28-100 Max. grinding length: 1000mm Nedpfx Ajwnhkmofvewk Max. grinding diameter: 280mm Center-height: 155mm Table: 1660x150mm Grinding wheel: 300mm Machine-dimensions: 2700x1550x1500mm - Documentation available: No - CE certificate present: No Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2022, functionality: fully functional, machine/vehicle number: 6861-0024, workpiece weight (max.): 250 kg, grinding length: 500 mm, grinding wheel diameter: 300 mm, total width: 4,600 mm, total length: 4,650 mm, total height: 3,580 mm, type of input current: three-phase, spindle speed (max.): 12,000 rpm, feed length X-axis: 500 mm, feed length Y-axis: 650 mm, feed length Z-axis: 650 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, grinding spindle motor power: 50,000 W, grinding spindle speed: 12,000 rpm, overall weight: 9,000 kg, input frequency: 50 Hz, rapid traverse X-axis: 50,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, input voltage: 400 V, space requirement height: 3,580 mm, MFG: Magerle (United Grinding) Model: MFP51 (MFP-51-50.65.65) Linear Axes Max X Travel = 500 mm Max X Travel Speed = 50000 mm / min Max Y Travel = 650 mm Max Y Travel Speed = 30000 mm / min Max Z Travel = 650 mm Max Z Travel Speed = 30000 mm / min Spindle Max. spindle power = 50 kW Max. speed = 12000 RPM Max. grinding wheel diameter = 300 mm Max. grinding wheel width = 60 mm Swivel Axles Swivel Range A = 210° Swivel Range B = 360° Swivel Range C = 360° Nwjdpfx Afezwugdjvjk Automatic 68-position tool change magazine portal magazine with inspection window and electromechanically interlocked loading station for manual loading of the tools. Ready to ship from Bangkok, Thailand

Year of construction: 2002, condition: refurbished (used), On behalf of a client and for their account, I am offering a VOUMARD 150 CNC L 1300. The machine is equipped with: 4-position turret, 3 internal tool stations, 1 empty station for external tools pneumatically swiveling tool rest Maximum diameter 350 mm Nsdjgigv Depfx Afvswk Maximum length 1,300 mm CNC Fanuc 32i extensive range of accessories, including several hydraulic steady rests, power chucks, etc. See "Documents" for details. The machine can be inspected in the owner's workshop while it is running. The machine was completely overhauled in 2016. In addition, I am offering 2 Voumard VMX 90 A grinding spindles, one new and one completely overhauled. These can also be purchased separately.

Condition: used, FEIN Support Grinder Serial No.: G 95304 Model MB 406 Max. grinding wheel diameter: 100 mm Max. grinding wheel width: 20 mm Grinding wheel mounting: Ø 20 mm Motor speed: 6,800 rpm Motor power: 350 Watts Nwodpfx Afex A Imbovjk Mains connection: 220 Volt, 50 Hz - Grinding spindle driven by flat belt - 1 universal grinding wheel Ø 98 x 20 mm included Weight: 11 kg Good condition

Condition: good (used), Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Max. shaft diameter: 320 mm -Max. grinding length: 345 mm Nwsdpfsduiw Aox Afvok -Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg -functionally tested

Condition: used, Support grinder for lathe FEIN Type: MB 2101 Ident No.: 2287997 Grinding wheel diameter: max. 150 mm Grinding wheel width: max. 20 mm Mounting taper: Ø15.5 - Ø13 mm, length 21 mm Motor speed: 4400 rpm Motor power: 550 Watt Electrical connection: 380 Volt, 50 Hz Nwodpex A Imhofx Afvek - Grinding spindle drive via flat belt - 1 pc. grinding wheel mount Ø 32 mm - 1 pc. universal grinding wheel Ø 146 x 20 mm Support grinder weight: 19 kg In good condition

Year of construction: 1955, condition: ready for operation (used), A conventional internal cylindrical grinding machine Fortuna is available. Center distance: 1500mm, center height: 225mm, max. workpiece diameter: 450mm, max. workpiece weight: 300kg, grinding wheel diameter: 450mm, grinding wheel width: 80mm, bore: 203mm, speed: 265rpm, machine dimensions X/Y/Z: approx. 3450mm/1450mm/1550mm, weight: approx. 4000kg. Documentation available. On-site inspection is possible. Nwedpfx Afjyg Nvtjvek

Condition: excellent (used), KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE TYPE: 600 U YEAR OF MANUFACTURE: 2003 PARTIAL OVERHAUL: 2026 (Technical data see attached documents) Center height: 175 mm (without height adjustment) Grinding length: 600 mm Equipment: - Standard accessories - Internal grinding device for D: 80 mm max. incl. coolant supply through the workpiece spindle - Grinding wheel equipment left for D: 400 x 50 x 127 mm (standard) - Grinding wheel equipment right for D: 300 x 40 x 127 - Grinding wheel flange for wheels D: 400 x 50 x 127 mm (left) and D: 300 x 40 x 127 (right), balancing weights outside (3 pieces left, 2 pieces right) - Variable spindle drive with Danfoss frequency converter - Balancing device for dynamic balancing, type ELASO MANOBALANCE 750/EB 2000 - RENAUD internal grinding spindle type REN 828 (grease-lubricated with compressed air lock) - Various internal grinding mandrels for REN 828 – 1235, 1645, 2060, 2575 (4 pieces) - Various chucks HJNZ 28 for HJN 828 with 2 collets D: 3 mm and D: 6 mm - Tailstock standard MK 5 with adapter flange DIN 55027 size 5” Bore D: 38.2 mm (standard) - Sine bar on the tailstock - Tailstock with manual retraction for quill travel - Micrometer adjustment on the tailstock - Pneumatic relief of the tailstock - FORKARDT planetary three-jaw chuck D: 200 mm - REISHAUER wedge-bar three-jaw chuck D: 160 mm - Permanent magnet chuck D: 200 mm - Collet chuck for Schaublin B32 - Set of 59 collets Schaublin B32, D: 1.0 – 30.0 mm, graduation 0.5 mm - Set of 8 workpiece supports incl. holder - Three-jaw steady rest, 175 mm, foldable, D: 3-120 mm - Swiveling dressing tool for dressing during external, surface or internal grinding - Side and angled dressing tool for side and angled dressing of the grinding wheels - Dial indicator stop for table swiveling with dial indicator 1/100 mm - Dial indicator stop for table longitudinal movement with dial indicator 1/100 mm - Dressing stop for internal grinding Nwodpszhma Djfx Afvsk - HEIDENHAIN Digital length measuring system for the X and Z axes - STREULI paper band filter SPB 3, 90 l/min at 0.26 bar, tank volume 240 l - WALDMANN machine lamp - Set of vibration-damping pads - Three-color paint finish (light gray RAL 7035/blue RAL 5012/dark gray RAL 7016) - New acceptance test report according to KELLENBERGER standard - CE conformity - Documentation Condition: very good, machine geometrically and mechanically overhauled (see geometry report)

Condition: refurbished (used), Year of construction: 2025, Schaudt PS51 S600 - Premium Refurbished - Grinding length: 600 mm - Center height: 180 mm - Grinding wheel width: 220 mm (More possible as an option) - Workpiece weight: 200 kg Nwodpfxsfg Utde Afvok Additional options that can be freely selected: - Completely new control cabinet with Siemens Sinumerik One or Fanuc 0iTF-Plus - Quick setup via GSN operator interface - In-process measuring control DMK / LMK - Grinding spindle for diamond form wheel - Balancing and truing sensor system - Hydraulic clamping/releasing of the tailstock - Automatic Siemens door drive - Remote maintenance - Conversion to needle nozzles - Matching coolant / extraction system - Automation preparation - and more We would be happy to refurbish your existing machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella and more.

Condition: used, DVS UGRIND 800 is a CNC external and internal grinder, engineered for precision, high accuracy and reliability. Handles workpieces Ø 130–500 mm; Z axis 1200 mm, X axis 250 mm. Grinding spindle 25 kW; workpiece spindle motor 24 kW; speeds 0–500 t/min stepless; supply 50 Hz 3x 400 V; weight ~7000 kg; L2850×W2490×H2290 mm; operating time 12000 Heures. Accessories: coolant system, coolant filter system, measuring feeler gauge, set of flanges for internal grinding, set of flanges, lamp, tool cabinet, electronic handwheel. Capable of achieving tight tolerances; typical applications: automotive, machine tools, aerospace, medical, watchmaking. Njdpfx Asyxnuaofvswk

Condition: used, Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinder, center grinder Nsdpfjd Atx Djx Afvowk -Image below: MK5 -grinding wheel mount: -Motor data: 0.3 kW 1380 rpm -Dimensions: 370/180/H480 mm -Weight: 36 kg

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 027.0149, CNC internal and external cylindrical grinding machine S33 CNC – undergoing refurbishment. Nsdozcuwbjpfx Afvswk Delivery time: approximately 14 weeks. Technical data and accessories as per the attached PDF. Photo = sample photo only.
