Used Gildemeister Component for sale (8,072)

Condition: ready for operation (used), Year of construction: 2008, operating hours: 51,226 h, functionality: fully functional, turning length: 1,175 mm, spindle speed (max.): 5,000 rpm, controller model: HEIDENHAIN Plus iT, number of slots in tool magazine: 36, TECHNICAL DETAILS Maximum spindle speed: 5,000 rpm Turning length: 1,175 mm Turning length with tailstock: 1,100 mm Fjdjzqfvvepfx Akhspk Tool holder: HSK 63A according to DIN 69893 Number of tool magazine positions (disc magazine): 36 MACHINE DETAILS Control system: HEIDENHAIN Plus iT with Turn Plus

Condition: used, Gildemeister CTX 320 Linear V6 with Y axis New 2005. FANUC 18T . Please note that the collet chuck shown in the image will not be included, the original 3 jaw chuck will be supplied. there is also the option to supply a bar feed unit which is compatible for the machine, however currently not set up. Fpsdpfx Akjztb Tcehok

Condition: excellent (used), Year of construction: 1995, Centre height: 330 mm Centre distance: 2000 mm Working area: Max. turning diameter over bed cover: 650 mm Max. turning diameter over cross slide: 360 mm Main spindle: Spindle diameter in front bearing: 140 mm Spindle bore: 107 mm Main drive: 58.5 kW 2-stage speed range: 4 – 750 rpm / 750 – 3060 rpm Feed drive: Rapid traverse X/Z axis: 10/10 m/min Turret: Number of tool stations: 12 Of which driven tool stations: 6 Tool shank holder: VDI 50 mm Dimensions / Weight: Required floor space (L x W x H): approx. 6400 x 2150 x 2000 mm Weight: 9400 kg Accessories / Special Features: • CNC path control HEIDENHAIN TurnPlus EP 90 with color display • Spindle orientation, C-axis • 12-position turret, VDI 50, including 6 driven tool stations in turret, manufacturer SAUTER, DIN 5482 B 20x17, max. speed 3000 rpm • Hydraulic 3-jaw chuck Ø 315 mm with various clamping jaws • Hydraulic tailstock with drag device • Hydraulic quill actuation • Extraction unit, manufacturer LTA • Various tool holders VDI 50 Fpedpfxsx Sx Hts Akhsk • CE-compliant In 08/2025, GILDEMEISTER service replaced the following parts: 1 servo motor, 1 AC servo controller inverter power module for 2 axes, 1 Simodrive power module, 1 line-commutated return module, 1 control insert for 1 axis, 1 controller module for 2 axes inverter servo drive, 1 Simodrive power module for 1 axis motor. Total repair cost: EUR 17,000.00 net Important note: On this very well-maintained CNC turning and milling center GILDEMEISTER CTX 600-2000 (year 1995), the positioning of the C-axis does not function and the driven milling unit rotates but does not engage. Otherwise, the machine is in perfect condition. A demonstration under power is possible at any time by prior appointment. Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: ready for operation (used), Gildemeister 852.14.00-00.21 circuit board (851.75.00-00.21), used, normal signs of wear, 100% functional. Fodpfsi D U S Ujx Akhspk

Condition: used, Year of construction: 2002, turning diameter 0455 mm turning length 2000 mm control CNC Pilot Heidenhain swing diameter max. over bed cover 670 mm swing diameter above cross guideway 455 mm travel -x axis 320 mm travel -z axis 2080 mm spindle head 220 h5 spindle bore 107 mm turning speed range - spindle 4 - 2.800 U/min max. Torque 2.000 Nm drive capacity - spindle motor 30 kW turret (x-stations) 12 tool taper VDI 50 diameter of quill 120 mm pressure max. 14 KN quill stroke 120 mm tailstock taper MT 5 total power requirement 58 kVA weight of the machine ca. 10 t dimensions of the machine ca. 6,7 x 2,4 x 2,3 m CNC - Lathe Fjdezgw Tfjpfx Akhopk GILDEMEISTER - CTX 600 E Serie 2 With 3 jaw chuck and self centering steady.

Condition: ready for operation (used), Year of construction: 1990, Offered for sale is a Gildemeister tool presetter. Max. tool diameter: approx. 350mm, max. tool length: approx. 350mm, tool holders: ISO 40 / ISO 50. Foot pedal included. The control was replaced with Orion in 2021. Calibration and maintenance in 2023. Dimensions X/Y/Z: approx. 1100mm/650mm/840mm. An on-site inspection is possible. Fodpoztzqhefx Akhspk

Condition: used, Year of construction: 1998, Spindle bore 56 mm (main spindle) Spindle speed (main) 31-6300 rpm Spindle speed (Sub) 5000 rpm Movements: Slide 1 - X/Z - 155/280 mm Slide 2 -X/Z - 82/130 mm Fpodpfszr Dn Hox Akhek Turret 1: 8 stations (4 rotating/live) - 120 rpm (C-axis) Turret 2: 8 stations Control: Siemens Sinumerik 840 C Equipped with: Chip conveyor 30 pcs. tool holders 8 rotating tool holders Magazine bar feeder model Simag 65.1 - 3200 mm

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Crosses slides, in position : 1,2,4,5 - Max. travel of transverse slides : 28 [mm] Fjdpfswvvrbsx Akhjpk - Max. travel of crossed slides : 45 [mm] - Max. travel of front spindles : 63 [mm] SPINDLES - Max. bar diameter : 16 [mm] - Spindle speeds : 400 - 6000 [rpm] - Spindle power : 15 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 43 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.800 x 1.100 [mm] - Machine height : 2.300 [mm] - Machine weight : 4200 [kg] EQUIPMENT - Double mechanical cut and return slide, in position : 6 - Rotary front spindles, in position : 1,2,3,5 - Parts catcher - Parts conveying strip - Bar waste chute - Chips conveyor - Coolant tank - Bar loader : Iemca PRA 40/31/P - Bar holder and stand - Bar holder housing

Condition: used, Multispindle lathe GILDEMEISTER GM 20 AC Fpsdpfxozpzm Us Akhek

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 Fpedpju E U Ufjfx Akhjk - Number of axes : 2 MAIN SPINDLE - Spindle speeds : 6500 [rpm] - Max. bar diameter : 42 [mm] - Max. turning diameter : 120 [mm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Spindle speeds : 6500 [rpm] - Max. bar diameter : 42 [mm] - C axis indexing precision : 0.1 [°] POWER SUPPLY - Supply voltage : 230 [V] - Total installed power : 7.5 [kW] WEIGHT & DIMENSIONS - Machine floor space : 5.400 x 1.900 [mm] - Machine height : 2.000 [mm] - Machine weight : 5.000 [kg] MACHINE HOURS - Number of hours under power : 33912 [h] - Number of working hours : 21069 [h] EQUIPMENT - CNC : FANUC 160i - Coolant tank - Chips conveyor - Parts catcher - Parts conveying strip

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Crosses slides, in position : 1,2,4,5 - Max. travel of transverse slides : 28 [mm] - Max. travel of crossed slides : 45 [mm] - Max. travel of front spindles : 63 [mm] SPINDLES - Max. bar diameter : 16 [mm] - Spindle speeds : 400 - 6000 [rpm] - Spindle power : 15 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 31 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.800 x 1.300 [mm] - Machine height : 2.100 [mm] - Machine weight : 4400 [kg] Fjdpfxowvvrho Akhepk EQUIPMENT - Double mechanical cut and return slide, in position : 6 - Rotary front spindles, in position : 1,2,3,4,5 - Parts catcher - Parts conveying strip - Bar waste chute - Chips conveyor - Coolant tank - Bar loader : Iemca PRA 40/33/P - Bar holder and stand - Bar holder housing

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Number of counter-spindles : 1 - Max. travel of front spindles : 120 [mm] - Max. bar feed : 130 [mm] SPINDLES * Max. bar diameter : 35 [mm] Fpodpju Habgofx Akhjk * Spindle speeds : 218-4000 [rpm] COUNTER-SPINDLE - Single-acting hydraulic counter-spindle - Counter-spindle position : 6 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 5950 x 1680 x1980 [mm] - Machine weight : 10500 [kg] EQUIPMENT - Standard cutting carriage, in position : 6 - Hydraulic cylinder for rear attachment, in position : 6 - Fixed front spindles, in position : 1,2,3,4,5 - Thread milling and polygon unit - Combing unit - Recessing : Push over - Parts catcher - Chips conveyor - Coolant tank - Bar loader : Pietro Cucchi - Oil mist extractor : Donaldson

Condition: used, TECHNICAL DETAILS - Spindle number : 6 - Max. bar diameter : 20 [mm], 25 [mm] in option - Cross slides number : 4 - Max. supply length : 100 [mm] - Spindle rotation speed : 420 - 5000 [Rpm] - Indexing time : 0,7 [s] - Machining time : 1,4 - 60 [s] - Power : 11 [kW] - Dimensions : 5800 x 1500 [mm] - Weight : 6000 [kg] Fodouharrepfx Akhspk EQUIPMENT - 4 cross slides posts 1 2 4 5 - 1 chip conveyor - 5 drillers - 1 IEMCA PRA41/31/P feeder DBMS-36 (1995)

Condition: used, Multispindle lathe GILDEMEISTER GM16-6 Fedpfxezhcp Ue Akhepk

Condition: used, Multispindle lathe GILDEMEISTER GS20/6 Fjdpfx Aozq Hrlokhspk

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Number of counter-spindles : 1 - Max. travel of front spindles : 120 [mm] - Max. bar feed : 130 [mm] SPINDLES * Max. bar diameter : 35 [mm] * Spindle speeds : 218-4000 [rpm] COUNTER-SPINDLE - Single-acting hydraulic counter-spindle - Counter-spindle position : 6 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 5950 x 1680 x1980 [mm] - Machine weight : 10500 [kg] - Number of working hours : 10946 [h] EQUIPMENT Fedpsu Habmofx Akhspk - Standard cutting carriage, in position : 6 - Hydraulic cylinder for rear attachment, in position : 6 - Fixed front spindles, in position : 1,2,3,4,5 - Thread milling and polygon unit - Parts catcher - Parts conveying strip - Chips conveyor - Coolant tank - Bar loader : Iemca PRA 40/42F - Bar holder and stand - Bar holder housing - Oil mist extractor : Donaldson

Year of construction: 2003, operating hours: 10,975 h, condition: used, total length: 4,500 mm, total width: 2,500 mm, total height: 2,300 mm, Colour: White Empty weight: 6.500 kg Price: On request - Year: 2003 - Documentation available: Yes - CE marking present: Yes - CE certificate present: Yes - Serial number: - Operating hours: 10975 - Drive system: CNC - Control system brand: Siemens - Control system type: Sinumerik 840D SL - Power [kW]: 25.0 - Centre height [mm]: 340 - Swing over bed [mm]: 680 - Carriage turning diameter [mm]: 565 - Distance between centres [mm]: 600 - Spindle bore [mm]: 65 - Min. spindle speed [rpm]: 0 - Max. spindle speed [rpm]: 5000 - Options: Chip conveyor, Three-jaw chuck Fpsdpfezrxifsx Akhek - X-axis travel [mm]: 260 - Y-axis travel [mm]: 635 - Transport dimensions: 4500mm x 2500mm x 2300mm (l x w x h) - Transport weight [kg]: 6500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2014, turning diameter 200 mm turning length 450 mm control Siemens 810D ShopTurn spindle bore diameter 51 mm number of controlled axis 3 turning speed range 0 - 5.000 U/min power requirement 16,5 / 11 kW rapid speed 30 m/min number of tapers in turret head 12 VDI 30 number of driven tools in turret 6 Spindel speed of driven tools 4500 U/min Spindelpower on driven tool 8,4 kW tail stock Ja/ Yes weight 3,2 t dimensions 4,4 x 2,05 x 1,8 m CNC-Lathe with driven tool Only 3950 h spindle time! Equipment: - chipconveyor - 3-jaw chuck Kitagawa Ø 210 mm - some toolholders VDI 30 - 1 + 1 driven toolholder - programmable tailstock - DMG SLIMline Panel with ShopTurn - Signal lamp - tool measuring Fsdpfx Aozr Rntskhopk - programmable tailstock

Condition: good (used), Year of construction: 2021, Turning center GILDEMEISTER/DMG Sprint 20-8 with DMG FANUC Series 32i Model B control, serial number 8104000418B, year of manufacture 2021, operating hours estimated by management at approximately 7,240 hours, chip conveyor, bar feeder FMB Turbo 2-20, serial number 21-301797, year of manufacture. Fodpfx Akoztdhiehspk

Condition: good (used), Year of construction: 2007, Turning center GILDEMEISTER/DMG Sprint 42 linear with DMG FANUC 160 control, serial number 2601-0386, year of manufacture 2007, operating hours estimated by management at approximately 41,295 hours, chip conveyor, bar feeder FMB Turbo 5-55. Fpodpsztc Syofx Akhok

Condition: used, Year of construction: 2007, Technical details: turning diameter: 160 mm turning length: 300 mm control: Siemens 840D Spindle 1 Power: 22 kW Spindle 1 RPM: 5000 1/min Spindle 1 max. bar diameter: 65 Spindle 1 Torque: 150 Nm Spindle 2 power: 16,8 kW Spindle 2 RPM: 5000 1/min Spindle 2 torque: 100 Nm Travel for pick up of 2nd Spindle: W2=690 mm dimensions of the machine ca.: ´4,5x2,0x2,3 m weight of the machine ca.: 9 t Accerories Spindle 1 Collet chuck Spindle 2 Collet Chuck Chip Conveyor Parts catcher CNC turning center with 3 turrets with rotary tool drives and 2 spindles. Fpodpfxjzd Tcwj Akhek There is an internal coolant system for the turrets with individual pumps *

Condition: used, Year of construction: 2003, Technical details: turning diameter: 640 / 400 mm turning length: 1500 mm control: Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z: 550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis): ±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z: 40/24/60 m/min RPM milling spindle: 12000 1/min power capacity - milling spindle: 12 / 23 kW Torque of milling spindle: 100 Nm Tool magazine for milling spindle (turret 1): 120 HSK-A 63 Tool change time tool/tool, milling spindle: 1,6 s Spindle 1 RPM: 4000 1/min Spindle 1 power: 36/ 45 kW Spindle 1 Torque: 730 Nm Spindle 1 max. bar diameter: 90 Spindle 2 RPM: 4000 1/min Spindle 2 power: 36 / 45 kW Spindle 2 torque: 730 Nm Spindle 2 max. bar diameter: 90 c-axis: 0,001 ° Travel turret 2 x: 225 mm Travel Turret 2 z: 1595 mm Fodpoyv Dnkofx Akhepk RPM of rotary tools turret 2: 4000 1/min no. of tools in turret 2: 12 VDI 40 high-pressure pump: 20 bar total power requirement: 110 kVA weight of the machine ca.: 24 t dimensions of the machine ca.: 9,3 x 4,6 x 3,1 m Accerories Chip conveyor Automatic door High performance turning and milling center with milling head (X, Y, Z, B-Axis), tool magazine with 120 pos. HSK-A 63. Excellent for manufacturing excentric parts. Coolant system with 1000 l tank and coolant system 4 kW. Both spindles have differencial pressure clamping system Steayrest for lower turret dia 8-101 mm. Parts gripper for turret No. 2 with 3-jaw chuck for parts with max. dia. 140 mm. Conveyor belt for finished parts. Preparation for 3D-probe Toolmonitor Artis Machine can be shown under power. *

Condition: used, Year of construction: 2007, Number of working hours 20456 h spindle hours 75180 h control FANUC 310 i chuck diameter 175 mm turning speeds 5.000 min-1 Fedpfx Akjydfq Iehspk weight of the machine ca. 8800 kg dimensions of the machine ca. 4500 x 1990 x 2300 mm Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm

Condition: used, Year of construction: 2008, chucking diameter 200/250/315 mm bar material dia. 65/90 mm spindle bore 79/100 mm control Siemens 840D powerline weight of the machine ca. 6 t dimensions of the machine ca. 4350x2460x2080 m Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Fodpoya Iirsfx Akhjpk Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: used, Year of construction: 2008, bar material dia. 65 mm turning speeds 5.000 min-1 Number of working hours 34979 h spindle hours 72260 h control FANUC 310 i weight of the machine ca. 8800 kg dimensions of the machine ca. 4500x1990x2300 mm Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Fjdpfx Ajyat Hvjkhspk X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm Translated with (free version)
