Used Gleason Curvic Coupling 130 for sale (8,671)

Condition: good (used), Year of construction: 1989, piece diametre 1500MM Rcedpfxefl Aaqj Ankod max coupling 914MM poids 15 tonnes

Condition: excellent (used), Year of construction: 2002, max. wheel diameter 130 / 80 mm gear width 180 mm max. module 4 min. module 0,5 spindle turning speed - stepless 300 - 3000 U/min control Siemens 840 D x-travel 200 mm Rjdpfxsxlug He Ankjcd y-travel 170 mm z-travel 250 mm milling head -swivable +/- 45 ° table diameter 168 mm table hole 65 mm clamping length max. 245 mm table turning speeds 0 - 1000 U/min total power requirement 51 kW weight of the machine ca. 9,2 t dimensions of the machine ca. 4,5 x 4,0 x 3,2 m

Condition: ready for operation (used), Three milling heads for different machines of the brand Pfauter-Gleason are available. 1) Milling head for Gleason Genesis 130H. 2) Milling head for Pfauter P200, without counter bearing. 3) Milling head for Pfauter PE250. An on-site inspection is possible. Rodpfx Anexl Upzskjcd

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 13230, wheel width: 25 mm, wheel diameter: 130 mm, controller model: Siemens 840D, spindle diameter: 85 mm, stroke rate (max.): 2,500 1/min, TECHNICAL DETAILS Wheel diameter max.: 130 mm Wheel width: 25 mm Module max.: 3 Module min.: 0.5 Ram spindle diameter: 85 mm Stroke rate: 500 - 2,500 strokes/min (continuously adjustable) Stroke: 30 mm MACHINE DETAILS Control model: Siemens 840D Total power requirement: 48 kVA Dimensions & Weight Rodpfx Ajzb Dtcjnkocd Space requirement (L x W x H): 4,700 x 3,000 x 3,300 m Machine weight approx.: 11.5 t EQUIPMENT Tailstock with point Chip conveyor Hydraulically actuated tailstock arm and linear guides

Condition: excellent (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 25734, wheel diameter: 700 mm, gear diameter: 1,000 mm, wheel width: 152 mm, workpiece spindle speed (max.): 67 rpm, feed length X-axis: 610 mm, feed length Y-axis: 610 mm, feed length Z-axis: 725 mm, pivoting range: 95 °, spindle bore: 203 mm, travel distance X-axis: 610 mm, travel distance Z-axis: 725 mm, Equipment: rotational speed infinitely variable, Equipped with: Fanuc 150MB Control Hydraulic Chucking Work Spindle Large Bore Work Spindle #80 Taper Stock Divider Helical Motion Modified Roll Hansen Coolant Chiller & Filtration Coolant Tank & Pumps Chip Conveyor Chip Hopper Reven Mist Collector Hydraulic System Transformer Cutter Bolt Work Light Operator Platform Hand Tools Documentation Specifications: Extreme Ratio: Face Milling: 10:1, Face Hobbing: 10:1 Full Depth: Maximum: Face Milling:1.25" (31.75mm), Face Hobbing: 0.93" (23.50mm) Rodexaqa Sopfx Ankscd Face Width: Maximum: Face Milling:6.00" (152.00mm),Face Hobbing: 3.00" (76.20mm) Range of Tooth Numbers: 1-300 Inclusive Gear Pitch Diameter, Maximum: 1000 mm (39.37") Cutter Size, Maximum: 18" (diameter) Face Milling Cutter Size, Maximum: 350 mm (radius) Face Hobbing Root Angle Range (B-Axis) 5 deg.to 90 deg., Face Hobbing:5 deg. to 90 deg. Machine Center to Work Spindle Face:9.00"Fixed, 229mm (Fixed) A-Work Spindle: 0 to 67 RPM, 0 to 333 RPM B-Swinging Base: 0 to 30 deg./sec, N/A C-Cutter: 0 to 500 deg., Same X-Horizontal: +/-305mm (+/-12") Y-Vertical: +/-305 mm (+/-12") Z-Sliding Base: -25/+700mm (-1/+28") B-Root Angle: -5 Degree/+90 Degree Diameter of Taper Hole at Large End: 8" (#80 Taper) to 6" (#60 Taper) Taper Per Foot:3/4", Same Depth of Taper Front:6", 152.40 mm Depth of Bore: 678 mm (26.7") Diameter of Taper Bore: 140 mm (5.5") Diameter Through Spindle of Hole:7.125", 180.98 mm MACHINE DIMENSIONS: Length x Width:233"x 209", 5920 mm x 5310 mm Height: 129", 3280 mm Weight: 65,000 lbs., 29,484 kg

Condition: like new (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 25582, Equipped with: Fanuc 30ia Control Hydraulic System Coolant System Chip Conveyor Pneumatics Lube System Jib Crane Change Gears Mist Collector Transformer Work Light Stack Light Specifications: Extreme Ratio: 10:1 Root Angle Range (B-Axis): -5 deg. TO 90 deg. Equivalent Root Angle Range: -8 deg. to 90 deg. Rcsdszn Aymspfx Anksd (Equivalent refers to cradle type machine.) Face Hobbing: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -152 mm TRI-AC Cutter w/13 Blade Groups Max. Full Depth: 0.550" Max. Face Width: 1.6" Face Milling: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -7.5" Diameter Cutter Max. Full Depth: 0.625" Max. Face Width: 1.6" Max. Swinging Base Travel (B-Axis): -5 deg. to 90 deg. Max. Vertical Travel (Y-Axis): -4" to 7" Max. Horizontal Travel (X-Axis): -6" to 4" Sliding Base Travel (Z-Axis): 2" to 12" Machine Center to Work Spindle Face (Fixed): 4.5" Tooth Number: 5 to 200 Inclusive Cutting Diameters: Conventional Face Milling: 1.1" to 7.5" Helixact: 100mm to 200mm Fine Pitch: 102mm to 152mm Coarse Pitch: 152mm only Speeds: B-Axis--Swinging Base (Degrees per Second): 30deg./sec. A-Axis--Work Spindle (Face Milling)(RPM): 0-75 A-Axis--Work Spindle (Face Hobbing)(RPM): 0-375 C-Axis--Cutter Spindle (RPM): 30-500 X-Axis--Horizontal (Inches per Second): 4.92"/sec. Y-Axis--Vertical (Inches per Second): 4.92" Z-Axis--Sliding Base (Inches per Second): 4.92"/sec. Work Spindle: Diameter of Taper at Large End (#39 Taper): 3-29/32" Taper per Foot: 39/64" Depth of Taper: 3" Floor Space: 95.75" x 63.5" Height (less mist collector): 90.75" Approx. Weight: 22,000 lbs

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Rodpfx Anjruakgekocd Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm -Maximum Internal Diameter: 100 mm Tool: Rsdpfxsrtrvys Ankecd -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg

Condition: used, Year of construction: 1977, machine/vehicle number: 19909, Equipped with: Index Plate Geneva Cam Cutter Body Hydraulic Work Clamping Coolant Pump & Tank Chip Conveyor Additional Cutter Bodies, Index Plates & Geneva Cams Available Specifications: Minimum Outside Cone Distance: 2.75" Maximum Cone Distance: 10" Maximum Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 Deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Rjdpfxexdfaze Ankjcd Depth of Taper: .625" Cutter Speeds: 15.6 to 87.7 RPM Feeds (seconds/tooth): 5 to 34.3 Main Motor: 10hp, 1800 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approximate Floor Space: 118" x 86.5" Needed Overall Height: 70" Approximate Net Weight: 18,820 lbs Shipping Weight Boxed for Export: 20,500 lbs

Condition: used, Year of construction: 1973, machine/vehicle number: 24109, Equipped with: Stock Divider Hydraulic Work Clamping Chip Conveyor Cutter Clamping Bolt Index Plate Change Gears Hydraulic System Coolant System Specifications: Min. Outside Cone Distance: 2.75" Max. Cone Distance: 10" Max. Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 6.8 to 16.5 RPM Feeds (seconds/tooth): 3 to 9 Main Motor: 5hp, 900 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approx. Floor Space: 118" x 86.5" Needed Overall Height: 70" Redpfjxdfa Ujx Ankscd Approx. Net Weight: 16,000 lbs Shipping Weight Boxed for Export: 17,000 lbs

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Rcedpfsrtrzdex Ankod Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: good (used), gear diameter: 508 mm, total height: 1,780 mm, total length: 2,990 mm, total width: 2,200 mm, MODEL 610 GLEASON GEAR ROUGHER/FINISHER Equipped with: Hydraulic Workholding Pendant Control Rcsdpfx Aertrykonkjd Chip Conveyor Index Plate Geneva Cam Change Gears Hydraulic System Coolant System Manuals Specifications: Maximum Gear Pitch Diameter: 20" Cutter Diameters: 9", 10.5", 12",14",16", 18" Whole Depth: 1.250" Root Angle: 60 to 80 deg. Face Width: 3.0" Extreme Ratio (Minimum): 2.25 to 1 Number of Teeth: 20 to 75 Diameter of Taper Hole at Large End: 3-27/64" Cutter Speeds (Per Minute) for Roughing: 15.6' to 87.7' Feeds (Seconds Per Tooth) for Roughing: 3 to 35 Cutter speeds (Per Minute) for Finishing: 6.8' to 20.5' Feeds (Seconds Per Tooth) for Finishing: 3 to 9 Floor Space: 118" x 86.5" x 70" H Weight: 17,500 lbs.

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 min. module 0,1 Control Siemens 840 D SL Number of working hours 9598 h total power requirement 45 kW weight of the machine ca. 7,8 t dimensions of the machine ca. 4,40x3,95x3,01 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Rodov Ehbbopfx Ankjcd Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Weight of the machine approx. 7,000 kg with robot cell

Condition: excellent (used), Capacity M16 module Table diameter: 1,200 mm Redpfx Ajzql Ufonkjcd Maximum workpiece diameter: 1,500 mm Milling slide travel: 600 mm Table center hole diameter: 250 mm

Condition: used, Year of construction: 2005, Technical details: workpiece diameter: 63,5 mm centre distance: 350 mm honing length max.: mm total power requirement: kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,70x2,x2,60 m Technical data G0504 working space Length of the clamping surface mm 1550 Number of T-slots mm 2 Width of the T-slots mm 18 Distance between T-slots mm 180 Center height (tailstocks) mm 350 Swivel range of the fine wheel head (U-axis) degrees Center distance - tailstock / fine wheel min./max. mm 120/225 Input resolution (all NC axes) mm / degrees Delivery slide Movement range (= Z-axis travel) mm 105 Input resolution mm tool Outside diameter min./max. mm 225/275 Hole diameter mm 160 Width mm 60 workpiece Outside diameter min./max. mm 40-150 Module min./max. mm 1.25-4.0 Tooth width max. Mm 45 weight Weight of the machine approx. Kg 5500 Operating fluid requirements Cooling lubricant recommendation, see chap. 8th Hydraulic fluid HLP D 46 approx. Itr 100 Speeds and feeds Tool speed (continuously adjustable) max. 1 / min 2000 Feed rates Rapid traverse / feed Z direction up to m / min 2 X direction up to m / min 2 U-direction up to m / min 2 V-direction up to m / min 2 C3 direction max.degree / sec 12 Electrical equipment Operating voltage V 400 Control voltage / lighting voltage V DC / AC 24/2 Frequency Hz 50 Power requirement approx. KVA 27 If the electrical installation has to be carried out according to customer specifications, only the information in the electrical documentation applies. Motor data Servo drives: Nm 1 / min Tool drive C1 27.0 00 Workpiece drive C2 27.0 00 X-axis 20.0 00 Z-axis 20.0 00 U-axis 6.0 00 Rcodpswrh H Nefx Anked Vertical portal (V1 axis) 6.0 00 Portal horizontal (U1 axis) Gripper axis of rotation C3 5.0 00 Loading slide (X1 axis) 5.0 00 Three-phase motors: KW 1 / min Hydraulic motor 1.5 1410 Central lubrication 0.07 Coolant pump 4 2840 Hydraulic equipment Delivery rate Itr / min 21 System pressure bar 50 Clamping pressure for: headstock max. Bar 35 Clamping tailstock min./max. bar 20 Only available if required. Not all limit values ??can necessarily be reached at the same time. If several maximum values ??come together in a processing task, performance restrictions must be expected! We reserve the right to make changes to the specified constructions, dimensions and weights *

Condition: used, TECHNICAL DETAILS - Part diameter : 100 [mm] - Nominal module * gear hobbing : approx. 3.0 [mm] * endless screw milling : approx. 5.0 [mm] - Max. axial movement : 320 [mm] - Cutting head orientation : -45 / + 115 [°] - Main mill max. diameter : 118 [mm] - Max. cut out length of the mail mill : 180 [mm] - Max. mill movement (Shifting) : 160 [mm] - Max. part-holder spindle speed : 3000 [t/mm] - Min./max. distance between axes : 10/100 [mm] - Cutting head motor power : 14 [kW] - Main mill speed : 50-12000 [t/mm] - Weight : 5000 [kg] EQUIPMENT - CNC Siemens 840D - Cooling tank Redpfx Aox Ed A Ronkecd - Chip conveyor

Condition: good (used), 130 linear meters of shelving system from Schäfer, type R3000 Used, like new, see pictures. Height: 2.5 m Depth: 80 cm Load capacity per shelf: 250 kg Field width: approx. 128 cm Rsdpfx Ansd Nftxskecd Negotiable price: €26,800 net ex warehouse The offer includes: 101 pcs. uprights or frames, 2.5 m, galvanized 600 pcs. shelves, 250 kg load capacity per shelf, galvanized 34 pcs. cross braces for bracing. 6 levels per field (more levels are possible for an additional charge) Also available with a field width of 100 cm! Other configurations are possible. Heights of 2.5 m or 3.5 m are available. The goods are in stock. Transport and assembly are possible upon request. Inspection possible at any time by appointment. Further information on request. We have over 5000 linear meters of pallet racking systems from numerous manufacturers in stock. (Subject to changes and errors in technical data, information and prices, as well as prior sale! See our terms and conditions, all prices excl. VAT ex warehouse) Lenox Trading – Top storage technology & heavy-duty shelving used & new Description: Are you looking for high-quality storage shelves to buy? With around 100 of our own employees, Lenox Trading is one of the largest dealers for new and used storage technology in the entire DACH region (Austria, Germany, Switzerland). ⚡ IMMEDIATELY AVAILABLE: • Over 10,000 linear meters of shelving available for immediate delivery • 20,000 m² of storage platforms & steel construction platforms immediately available • Weekly 30–50 semi-trailer truckloads of goods turnover for maximum selection 📦 OUR RANGE (BUY ONLINE AT A GOOD PRICE): Whether it's pallet racking, heavy-duty shelving, high-bay racking, shelving systems, tire racks, or shelving for IBC containers – we deliver and assemble throughout Europe with our OWN team! Including CAD planning, transport, dismantling and assembly. 🏭 TOP BRANDS USED & FROM INSOLVENCY / BANKRUPTCY LIQUIDATION: • SSI Schäfer (Schäfer storage technology, R 3000, PR 600, PR 300) • Jungheinrich (Type MPB, Type E, heavy-duty shelving Jungheinrich) • Wezsuisse Euronorm, Bito RK 4209, Schäfer EK 113, Schäfer RK 521, Schäfer LF 533, Familog SP 6428, R-KLT 4315, RL-KLT 6147, Schäfer KLT 3214, UTZ SILAFIX 3Z, EF 3120, EF 6420 • Cantilever racking (Elvedi cantilever racking, Schäfer, Ohra) • Stow, Meta, Bito, Galler, Nedcon, Voest, SLP, Palflex, Ramada, Bauer, Ohrner 🔨 OUR SECOND PILLAR: ONLINE AUCTIONS & LIQUIDATION For dismantling and clearance orders, we offer a complete all-round service package: 1. Flat-rate purchase: Purchase of merchandise, equipment & complete inventory including a thorough clearance. 2. Commission-based auction: Conducting auctions on behalf of customers. Our full service provided by our own employees: cataloging, office preparation, inspection, goods delivery, logistics, dismantling and thorough handover. Whether you became aware of us through heavy-duty shelving or are looking for galvanized heavy-duty shelving / heavy-duty shelving system, we guarantee the best conditions. Contact us for a non-binding offer!

Condition: ready for operation (used), Year of construction: 2001, controller manufacturer: SIEMENS, controller model: 840, overall weight: 11,500 kg, number of axes: 5, This 5-axis Gleason PFAUTER G320 CNC + Promot Automation was manufactured in 2001. It features a Siemens 840 control unit, a maximum workpiece diameter of 380 mm, and a module range of 0.5-7.0. The system includes Promot Automation handling, a robotics system, and a cooling belt system. If you are looking to get high-quality gear grinding capabilities consider the Gleason PFAUTER G320 CNC machine we have for sale. Contact us for more information about this machine. • Operator panel: included • Module range: 0.5–7.0 • Workpiece diameter: min 10 mm, max 380 mm • Number of teeth: 10–600 • Axis travels: Z (vertical) 200 mm; X (horizontal) 230 mm; Y (tangential/shift) 135 mm • Clamping head swivel (A): ±45° • Tailstock stroke: 125 mm • Dressing travels: V (tangential) 180 mm; U (radial) 110 mm • Grinding wheel speed: up to 3000 rpm, stepless • Linear axis speed: 10,000 mm/min • Max. table rotation speed: 240 rpm • Table resolution: 0.001° • Feeds: machining and working feeds stepless Rcjdsyf E R Djpfx Ankod • Grinding wheel dimensions: diameter 270–350 mm; width up to 104 mm; bore 160 mm • System weight: approx. 11,500 kg • Space required (machine): approx. 3.7 m × 2.4 m × 2.75 m Additional equipment • Promot Automation handling unit (robotics handling) • Operator panel/handheld (for automation) • Conveyor belt • Cooling belt system • Hydraulic unit • Space required (automation): approx. 4.5 m × 1.6 m × 4.0 m • Accessories as shown in photos

Condition: used, TECHNICAL DETAILS - Maximum workpiece diameter : 80 [mm] - Z-axis travel : 220 [mm] - Max module : 2.5 Rsdsyuzggjpfx Ankocd - Max workpiece-holding spindle speed : 3000 [rpm] - Max dimensions of the hob (diameter x length) : 118 X 120 [mm] - Speed of the hob-holding spindle : 200-5000 [rpm] - Shifting travel : 140 [mm] - Angular travel of hob-holding headstock : -45/+115 [°] - Machine floor space : 2700/2180 [mm] - Machine height : 2310 [mm] - Machine weight : 4800 [kg] EQUIPMENT - CNC : Siemens 840D PowerLine - Loading manipulator

Condition: used, TECHNICAL DETAILS - Maximum workpiece diameter : 80 [mm] - Z-axis travel : 220 [mm] - Max module : 2.5 - Max workpiece-holding spindle speed : 3000 [rpm] - Max dimensions of the hob (diameter x length) : 118 X 120 [mm] - Speed of the hob-holding spindle : 200-5000 [rpm] - Shifting travel : 140 [mm] - Angular travel of hob-holding headstock : -45/+115 [°] - Machine floor space : 2700/2180 [mm] - Machine height : 2310 [mm] - Machine weight : 4800 [kg] EQUIPMENT Redpfx Aoyuzgaenkecd - CNC : Siemens 840D PowerLine - Loading manipulator

Condition: excellent (used), For sale: a SEW-Eurodrive WA20DT63L4/B03 worm gear motor with a 0.25 kW three-phase motor. The unit is fully functional, tested, and ready for operation. The gear motor is in good technical and visual condition. It shows normal signs of use, as visible in the photos. A power cable with a plug is included. Technical specifications: Manufacturer: SEW-Eurodrive Model: WA20DT63L4/B03 Motor power: 0.25 kW Power supply: 3× 230/400 V, 50 Hz Motor speed: 1300 rpm Output speed: 130 rpm Gear ratio: i = 10.25 Output torque: 16 Nm Protection class: IP54 Insulation class: B Operating mode: S1 Brake: 230 V AC Weight: 10.55 kg Rcjdpfx Aezmy Sdjnkjd Manufacturer: SEW-Eurodrive, Germany The scope of sale includes exactly what is shown in the photos.

Condition: used, functionality: fully functional, The bevel gear testing machine Gleason-Welter 2000 T was designed as a universal machine and is used by manufacturers of gears and transmission technologies for the single flank rolling test process of bevel and crown gears. Technical Data Diameter: 2000 mm Spindle bore: 310/250 mm Test speed: 5-100 rpm Dimensions: approx. 4,200 x 4,500 x 2,300 m Machine weight: approx.12,500 kg *Specifications and data are non-binding, subject to prior sale Special Features: Angle-hypoid test device, suitable for testing larger sizes of bevel and hypoid gears with a diameter of up to 2,000 mm and shaft angles from 0 to 360 degrees, as well as straight, helical, and internal gearing. Deviations in gear geometry, machining errors through defective tools, as well as damage to the gears, can thus be identified and eliminated before assembly. The following parameters can be measured here: - Single flank rolling deviation Fi', fi', fl', fk' - Pitch deviations Fp, fp, fu - Runout and roundness - Runout error Fr - Backlash - FFT analysis Rjdewn D Uhspfx Ankscd For technical questions and further information, you can contact us at any time.

Condition: excellent (used), Year of construction: 2008, Siemens Sinumerik 840 D, 5 axes controlled. Wheel diameter max 2000 mm 700 mm wheel width Rcedpfx Aneza Egbsked Machine weight 35,000 kg Space requirements approx. 6.9 x 8.4 x 3.7 m

Condition: used, Year of construction: 1980, max. wheel diameter 1010 mm gear width 0 mm max. module min. module total power requirement 15 kW weight of the machine ca. 9,5 t dimensions of the machine ca. m Max. depth of tooth 10 mm Max. workpiece Ø (for clearance) 1,010 mm Redpjt Hwniofx Ankjcd Max. external Ø of coupling 610 mm Sliding base withdraw 216 mm Max. distance from grinding wheel to workpiece nose 90 - 430 mm Max. weight of workpiece, including clamp 500 kg No. of teeth 32 to 150 Grinding wheel Ø, approx 152 - 320 mm Grinding wheel speeds, infinitely variable 0 - 3,600 rpm Work spindle bore 60 mm Total electrical load, approx. 15 kW - 380 V - 50 Hz Weight, approx. 9,500 kg Accessories / Special Features * Automatic roughing and finishing process via pre-settable counter and built-in feed cam. * Counter for number of teeth. * Counter for number of dressing cycles. * 2 built-on dressing units with three dressing diamonds for radius dressing, side dressing and wheel end dressing. * Built-on index plate for 48 teeth. * Separate coolant device with band filter. * Separate hydraulic unit. * Separate TRION oil mist exhaust. * Various small parts.

Condition: used, Year of construction: 1997, max. wheel diameter 215 mm gear width 40,65 mm max. module total power requirement 20 kW weight of the machine ca. 10 t Max. external Ø of workpiece 215 mm Tooth profile, height x width 16 x 40.65 mm No. of teeth 5 - 200 Max. tooth ratio 1 : 10 Grinding wheel Ø 51 - 190 mm Grinding wheel speeds 1,000 - 6,000 rpm X Axis (horizontal) 152 mm Y Axis (vertical) 178 mm Z Axis (slide base plate) 304 mm Distance from middle of machine to middle of workspindle 115 mm Axial speed 125 mm/sec Workpiece speeds 0 - 30 rpm Workspindle bore, conical 3 29/32 inch Total electrical load 20 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features * FANUC CNC Control, Model 150 MB, for 7 axes, with monitor and direct input. Automatic calculation of all workpiece and grinding parameters. * Extensive coolant equipment with filter system, band filter, etc. * Driven grinding wheel dressing device with CNC dressing control for automatic compensation of form and diameter after every dressing. * Gear grinding is effected either in single component operation using a conical cup wheel (Gleason 30°), or with a cylindrical cup wheel. These grinding wheels can be made of CBN, or of traditional "dressable" aluminium oxide material (question of cost). Grinding with a conical grinding wheel is of advantage with regard to heat build-up and quality of tooth contact pattern. Therefore these pairs of bevel gears (for automotive industry) can be generated in high quality with consistent accuracy, economically, and with short set-up times. Condition : Very good - machine can be inspected here under power Rcedpfet Hwxhex Ankod Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.
