Used Gleason-Hurth Zh 125 for sale (4,021)

Condition: used, Year of construction: 2004, workpiece diameter 125 mm module 4 Dedpfx Ajx Szm Aebfeuu control SIEMENS SINUMERIK travel -x axis 105 mm travel -y axis 40 mm travel -z axis 500 mm workpiece diameter 17 - 39,5 mm workpiece height 6 - 15 mm Gear Honing Machine | GLEASON-HURTH - ZH 125 The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZH125 | ZH-125

Condition: used, Year of construction: 2005, Technical details: workpiece diameter: 63,5 mm centre distance: 350 mm honing length max.: mm total power requirement: kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,70x2,x2,60 m Technical data G0504 working space Length of the clamping surface mm 1550 Number of T-slots mm 2 Width of the T-slots mm 18 Distance between T-slots mm 180 Center height (tailstocks) mm 350 Swivel range of the fine wheel head (U-axis) degrees Center distance - tailstock / fine wheel min./max. mm 120/225 Input resolution (all NC axes) mm / degrees Delivery slide Movement range (= Z-axis travel) mm 105 Input resolution mm tool Outside diameter min./max. mm 225/275 Hole diameter mm 160 Width mm 60 workpiece Outside diameter min./max. mm 40-150 Module min./max. mm 1.25-4.0 Tooth width max. Mm 45 weight Weight of the machine approx. Kg 5500 Dsdpfewrh H Nex Abfouu Operating fluid requirements Cooling lubricant recommendation, see chap. 8th Hydraulic fluid HLP D 46 approx. Itr 100 Speeds and feeds Tool speed (continuously adjustable) max. 1 / min 2000 Feed rates Rapid traverse / feed Z direction up to m / min 2 X direction up to m / min 2 U-direction up to m / min 2 V-direction up to m / min 2 C3 direction ree / sec 12 Electrical equipment Operating voltage V 400 Control voltage / lighting voltage V DC / AC 24/2 Frequency Hz 50 Power requirement approx. KVA 27 If the electrical installation has to be carried out according to customer specifications, only the information in the electrical documentation applies. Motor data Servo drives: Nm 1 / min Tool drive C1 27.0 00 Workpiece drive C2 27.0 00 X-axis 20.0 00 Z-axis 20.0 00 U-axis 6.0 00 Vertical portal (V1 axis) 6.0 00 Portal horizontal (U1 axis) Gripper axis of rotation C3 5.0 00 Loading slide (X1 axis) 5.0 00 Three-phase motors: KW 1 / min Hydraulic motor 1.5 1410 Central lubrication 0.07 Coolant pump 4 2840 Hydraulic equipment Delivery rate Itr / min 21 System pressure bar 50 Clamping pressure for: headstock max. Bar 35 Clamping tailstock min./max. bar 20 Only available if required. Not all limit values ??can necessarily be reached at the same time. If several maximum values ??come together in a processing task, performance restrictions must be expected! We reserve the right to make changes to the specified constructions, dimensions and weights *

Condition: excellent (used), Year of construction: 2004, Technical Specifications – ZS 130 T Gearwheel Shaving Machine Gear Specifications: * Gear diameter: 20 – 145 mm * Tooth width: 40 – 45 mm * Module range: 1.25 – 3.5 Working Area: * Swivel range of the shaving head: -23° to +90° * Taper adjustment (B-axis): +2° / -2° * Horizontal adjustment (X-axis travel): 160 mm * Swivel range of rotary table (E-axis): ±20° * Input resolution for all NC axes: 0.001 mm / degree Slide Travel (Z-Axis): * Travel range (Z-axis): 300 mm * Input resolution: 0.001 mm Shaving Cutter Dimensions: * Outer diameter: 230 – 256 mm * Bore diameter: 63.5 – 100 mm * Shaving cutter width: 50.8 – 0.2 mm Workpiece Parameters: * Outer diameter: 20 – 145 mm * Module: 1.25 – 3.5 * Gear width: up to 40 mm Rotational Speeds: * Tool spindle speed (infinitely adjustable): up to 600 rpm * Workpiece speed (machining): up to 3000 rpm * Workpiece speed (spin): up to 4500 rpm Feed Rates: * A-axis: up to 3.3 rpm * B-axis: up to 0.5 rpm * C0-axis: up to 60 rpm * X-axis feed: 10 – 10,000 mm/min * Z-axis feed: 10 – 10,000 mm/min Machine Weight: * Approx. 5,600 kg --- Machine Description: The ZS 130 T is a high-performance gearwheel shaving machine designed for the precise finishing of cylindrical gears after hobbing or shaping. Shaving is a crucial process in gear manufacturing, used to correct profile and lead deviations and to improve surface finish, ensuring quiet operation and extended gear life. This machine is capable of processing gears with modules from 1.25 to 3.5 and diameters up to 145 mm. With its CNC-controlled axes and flexible swivel and taper adjustment capabilities, the ZS 130 T allows for a wide range of gear geometries and high production efficiency. Dedpfxokwc Tfs Abfsuu The machine is ideal for manufacturers requiring high precision, consistency, and productivity in gear finishing processes. Typical Applications: * Finishing of gears for automotive transmissions and gearboxes * Shaving of helical and spur gears * Volume production in automotive and industrial gear manufacturing * Correction of tooth profile and lead errors before heat treatment The ZS 130 T combines robust construction, high-speed capability, and flexible adjustment options, making it a reliable solution for demanding gear shaving applications.

Year of construction: 2019, condition: as good as new (ex-display), Rolling burr tool Make Gleason - Hurth Type:CH7M5R - 7B340-B1A 200 mm diameter unused is delivered in a wooden box Djdpfofgwt Eox Abfsuu Weight 9,5 kg

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 300 mm gear width: 100 mm max. module: 5 workpiece turning speeds: min work piece - max.: 1100 mm workpiece clamping: auto. tension device number of spindle speeds: 1/min. Dodpfxsyzh Rae Abfjuu spindle bearing diameter: 100 mm diameter of spindle flange: 120 mm tailstock travel: 80 mm weight of the machine ca.: 3500 KG dimensions: 1200 x 1450 x 2250 mm total power requirement: 10 kVA The Gear Tooth Deburring machine WERA, ZEM 300 for deburring of splines gear wheels and shafts, with Pointing Facility. *

Condition: used, Year of construction: 2002, Technical details: Duedpfx Abeyud Tpofeu max. wheel diameter: 150 mm gear width: * mm max. module: 3,5 min. module: 1,25 total power requirement: * kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,35 x 2,10 x 2,35 m Width of teeth: 45 mm boring diameter: 100 mm surface area: 1300 x 300 mm

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 150 mm gear width: * mm max. module: 3,5 min. module: 1,25 total power requirement: * kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,35 x 2,10 x 2,35 m Width of teeth: 45 mm boring diameter: 100 mm surface area: 1300 x 300 mm Dusdpeyud Tisfx Abfsu

Condition: as good as new (ex-display), PRICE ON REQUEST! - as good as new - completely measured - gear backlash axle 4 - 0,01 WM axis 5 - 0,015 WM axle 6 - 0,01 WM - Central hand readjusted Duedpsg A Iucjfx Abfsu - Endurance test 8 hours at 100 % load - Delivery in a special box (insured shipping) - Central hand in exchange (without exchange on request) - Gearbox overhaul of axles 1-6 - 12 months warranty 18 months possible for extra charge IMMEDIATELY more than 100 central hands in stock, different models. Just ask! Also an express overhaul of your KUKA central hand possible - from delivery 48 - 72 hours. In addition, we also offer the repair of ABB wrists.

Condition: used, Year of construction: 2016, load capacity: 16,000 kg, LOGLIFT F 125 ZT 93 Short Timber Crane • Year of manufacture 2016 • Loading capacity between 3,150 and 970 kg • Timber grapple • Rotary servo! • High seat • Crane is (still) mounted on a 2017 Scania R 580 6x2, sold separately! - German crane! - Ready for use and fully functional! Subject to errors and prior sale! Dujdpfx Ajwmn Rwobfeu = Further information = Odometer reading: 1,250 km Usable material: Wood Emission class: Euro 1

Condition: used, mileage: 532,000 km, first registration: 08/2017, Year of construction: 2017, SCANIA R 580 6x2 Timber Truck with LOGLIFT 125 ZT 93 Crane Chassis: • EURO 6 • Axle configuration: 6x2 • Lift/steer axle (3rd axle) • Intarder • Automatic climate control • Auxiliary heater • OPTICRUISE automated transmission with clutch pedal • Differential lock • Hill start assist • Beacon lights • Light bar with additional spotlights • Exhaust emission reducer • Adaptive cruise control Dusdpowmpiuefx Abfju • Lane departure warning system • Emergency braking assistant • Multifunction steering wheel • Comfort passenger seat • Refrigerator • Airbag • SCANIA navigation / radio / CD player • 1 bunk • 2 x aluminum tanks: 600 + 250 liters • Gross weight: 26,000 kg (30,000 kg technically possible) • Unladen weight: 14,865 kg • Gross combined weight: 53,000 kg! • Wheelbase: 5,000 mm Tyres: • Front axle: 385/55 R22.5 • Rear axle: 315/70 R22.5 • Lift axle: 385/55 R22.5 • Tyre tread depth: 8/8/9/6/10/6/5/3 mm Crane: • LOGLIFT type F125 ZT 93, year of manufacture 2016 • incl. timber grapple • Double rear outriggers - German vehicle! - One owner! - TÜV / roadworthiness inspection / safety inspection: New upon request, at extra cost! Errors and prior sale excepted!

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 13230, wheel width: 25 mm, wheel diameter: 130 mm, controller model: Siemens 840D, spindle diameter: 85 mm, stroke rate (max.): 2,500 1/min, TECHNICAL DETAILS Wheel diameter max.: 130 mm Wheel width: 25 mm Dedpfx Aszb Dtcjbfouu Module max.: 3 Module min.: 0.5 Spindle bore diameter: 85 mm Stroke rate: 500 - 2,500 strokes/min (continuously variable) Stroke: 30 mm MACHINE DETAILS Control model: Siemens 840D Total power requirement: 48 kVA Dimensions & Weight Footprint (L x W x H): 4,700 x 3,000 x 3,300 m Machine weight approx.: 11.5 t EQUIPMENT Tailstock with point Chip conveyor Hydraulically actuated tailstock arm and linear guides

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Duederuakgepfx Abfou Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 min. module 0,1 Control Siemens 840 D SL Number of working hours 9598 h total power requirement 45 kW weight of the machine ca. 7,8 t dimensions of the machine ca. 4,40x3,95x3,01 m Gleason 100S gear shaping machine Dujdpfxev Ehbbo Abfsu for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Weight of the machine approx. 7,000 kg with robot cell

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm -Maximum Internal Diameter: 100 mm Tool: -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 Dedpfx Aertrvyobfouu -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg

Condition: used, Year of construction: 1996, functionality: fully functional, machine/vehicle number: 25734, Equipped with: Fanuc 150MB Control Hydraulic Chucking Work Spindle Large Bore Work Spindle #80 Taper Stock Divider Helical Motion Modified Roll Hansen Coolant Chiller & Filtration Coolant Tank & Pumps Chip Conveyor Chip Hopper Reven Mist Collector Hydraulic System Transformer Cutter Bolt Work Light Operator Platform Hand Tools Documentation Specifications: Extreme Ratio: Face Milling: 10:1, Face Hobbing: 10:1 Full Depth: Maximum: Face Milling:1.25" (31.75mm), Face Hobbing: 0.93" (23.50mm) Face Width: Maximum: Face Milling:6.00" (152.00mm),Face Hobbing: 3.00" (76.20mm) Duodpfxoxaqa Se Abfsu Range of Tooth Numbers: 1-300 Inclusive Gear Pitch Diameter, Maximum: 1000 mm (39.37") Cutter Size, Maximum: 18" (diameter) Face Milling Cutter Size, Maximum: 350 mm (radius) Face Hobbing Root Angle Range (B-Axis) 5 deg.to 90 deg., Face Hobbing:5 deg. to 90 deg. Machine Center to Work Spindle Face:9.00"Fixed, 229mm (Fixed) A-Work Spindle: 0 to 67 RPM, 0 to 333 RPM B-Swinging Base: 0 to 30 deg./sec, N/A C-Cutter: 0 to 500 deg., Same X-Horizontal: +/-305mm (+/-12") Y-Vertical: +/-305 mm (+/-12") Z-Sliding Base: -25/+700mm (-1/+28") B-Root Angle: -5 Degree/+90 Degree Diameter of Taper Hole at Large End: 8" (#80 Taper) to 6" (#60 Taper) Taper Per Foot:3/4", Same Depth of Taper Front:6", 152.40 mm Depth of Bore: 678 mm (26.7") Diameter of Taper Bore: 140 mm (5.5") Diameter Through Spindle of Hole:7.125", 180.98 mm MACHINE DIMENSIONS: Length x Width:233"x 209", 5920 mm x 5310 mm Height: 129", 3280 mm Weight: 65,000 lbs., 29,484 kg

Condition: used, Year of construction: 1977, machine/vehicle number: 19909, Equipped with: Index Plate Geneva Cam Cutter Body Hydraulic Work Clamping Coolant Pump & Tank Chip Conveyor Djdpfx Abexdfazjfsuu Additional Cutter Bodies, Index Plates & Geneva Cams Available Specifications: Minimum Outside Cone Distance: 2.75" Maximum Cone Distance: 10" Maximum Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 Deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 15.6 to 87.7 RPM Feeds (seconds/tooth): 5 to 34.3 Main Motor: 10hp, 1800 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approximate Floor Space: 118" x 86.5" Needed Overall Height: 70" Approximate Net Weight: 18,820 lbs Shipping Weight Boxed for Export: 20,500 lbs

Condition: used, Year of construction: 1973, machine/vehicle number: 24109, Equipped with: Stock Divider Dusdoxdfa Uspfx Abfsu Hydraulic Work Clamping Chip Conveyor Cutter Clamping Bolt Index Plate Change Gears Hydraulic System Coolant System Specifications: Min. Outside Cone Distance: 2.75" Max. Cone Distance: 10" Max. Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 6.8 to 16.5 RPM Feeds (seconds/tooth): 3 to 9 Main Motor: 5hp, 900 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approx. Floor Space: 118" x 86.5" Needed Overall Height: 70" Approx. Net Weight: 16,000 lbs Shipping Weight Boxed for Export: 17,000 lbs

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Dusdpfx Aortrzdobfeu Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: good (used), gear diameter: 508 mm, total height: 1,780 mm, total length: 2,990 mm, total width: 2,200 mm, MODEL 610 GLEASON GEAR ROUGHER/FINISHER Dodpfx Absrtrykefouu Equipped with: Hydraulic Workholding Pendant Control Chip Conveyor Index Plate Geneva Cam Change Gears Hydraulic System Coolant System Manuals Specifications: Maximum Gear Pitch Diameter: 20" Cutter Diameters: 9", 10.5", 12",14",16", 18" Whole Depth: 1.250" Root Angle: 60 to 80 deg. Face Width: 3.0" Extreme Ratio (Minimum): 2.25 to 1 Number of Teeth: 20 to 75 Diameter of Taper Hole at Large End: 3-27/64" Cutter Speeds (Per Minute) for Roughing: 15.6' to 87.7' Feeds (Seconds Per Tooth) for Roughing: 3 to 35 Cutter speeds (Per Minute) for Finishing: 6.8' to 20.5' Feeds (Seconds Per Tooth) for Finishing: 3 to 9 Floor Space: 118" x 86.5" x 70" H Weight: 17,500 lbs.

Condition: used, Year of construction: 2014, Technical details: max. wheel diameter: 150 mm gear width: 350 mm Duedpfoxtbmisx Abfju max. module: 4 total power requirement: 48 kW weight of the machine ca.: 13 t dimensions of the machine ca.: 4,88 x 4,40 x 3,56 m spindle turning speed range: 100-1000 U/min Infeed and outfeed chain conveyor, with tool holders, chip conveyor, hydraulic unit and air conditioning. *

Condition: good (used), Technical data for the pallet rack traverse: Rack system: Stow Type: Pal Rack NS Included in delivery are: 01x pallet rack traverse, used Material color: RAL 2004 orange box profile: 125 x 50 mm Dsdpfxelvrg Rs Abfouu type of cross beam: PNB0485/1.5 agraffe: 4 HK (hooks) clear width: 3.600 mm max. load per truss pair 1.832 kg, with evenly distributed load 02x safety pins, used design: compl. galvanized To secure the longitudinal beams against unintentional lifting out

Condition: used, cone distance min./max. 0-108 mm Pitch angle min/max 5°/84° Control GE Fanuc Series 0-GC Pitch diameter (1:1 ratio) 152 mm Djdpjyh Rmmefx Abfjuu pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Face width gear wheel max. 35 mm Knife spindle - Speed range 41-121 U/min working spindle speed range 0-33.33 U/min weight 9025 kg dimensions of the machine ca. 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: - 18-piece cutter set - Chip conveyor - Technical documentation

Year of construction: 1976, condition: used, Technical details: diameter: 500 mm workpiece weight: 30 kg test dia. min.: 200 mm total power requirement: 0,03 kW weight of the machine ca.: 1000 kg dimensions of the machine ca.: 1x0,5x1,06 m Dusdpfx Aoyyapxobfou

Condition: good (used), functionality: fully functional, rotational speed (min.): 2,840 rpm, volume flow: 3,240 m³/h, pressing: 10,000 Pa, power: 18 kW (24.47 HP), High pressure centrifugal fan, dust extraction fan, pressure fan, vacuum fan, centrifugal fan, high pressure fan Spellna VRU 15-125-30H3 Condition: used impeller: forward curved steel, direct drive. 700mm Drive motor:18 kW p1:1,2kg/m3 pressure:9500-12000Pa Number of revolutions:2950rpm air transport:3240m3/h Volume output:0.9m³/s Print pt:100 mbar Connection input:Ø 300 mm Connection output:Ø 200mm Dimensions: 1400x1400x960mm Dodpfx Ajticdlebfsuu Mass: 350

Condition: excellent (used), Year of construction: 2006, Siemens Sinumerik 840 D, 5 axes controlled. Dsdpfjza Egbjx Abfjuu Wheel diameter max 2000 mm 700 mm wheel width Machine weight 35,000 kg Space requirements approx. 6.9 x 8.4 x 3.7 m
