Used Gleason-Pfauter Gear Hobbing Machine for sale (71,125)

Condition: excellent (used), functionality: fully functional, I would be happy to add technical data to the document for you. Gear Hobbing Machine conventional Country of origin: Germany Technical specifications Details max. wheel diameter 600 mm gear width 250 mm max. module 8 total power requirement 2.2 kW machine weight approx. 2000 kg Nodjzmqaljpfx Agrjdb machine dimensions approx. 2500 x 1600 x 1900 mm cutter diameter max. 250 - 285 mm clamping table diameter 460 mm table hole 70 mm accessories: various Control unit conventional Additional information Documents I would be happy to add technical data to the document for you. I would be happy to add technical data to the document for you. Gear Hobbing Machine

Condition: excellent (used), Capacity M16 module Njdpjzql Ufjfx Agrodb Table diameter: 1,200 mm Maximum workpiece diameter: 1,500 mm Milling slide travel: 600 mm Table center hole diameter: 250 mm

Condition: used, Year of construction: 2007, control Siemens Sinumerik 840 D weight 57.000 kg voltage 400 V Gleason PFAUTER CNC gear hobbing machine P 2400/2800 for gear cutting of cylindrical and worm gears as well as all other regularly occurring rollable profiles and shapes on the cylindrical workpiece circumference. Large gear hobbing machines from Gleason offer maximum productivity for roughing and finishing cylindrical gears for many industries: wind turbines, industrial gearboxes, mining and shipbuilding, gear machining and many more. The power range of the drive takes future tool developments into account. Of course, the gear hobbing head drive is also backlash-free. These machines are particularly well suited for use with state-of-the-art, cutting materials, regardless of whether dry or wet machining is preferred. The machine can be used for dry or wet machining and is also equipped with the appropriate chip conveyor for both machining methods. The machine is equipped with an internal profile milling head as a motorised milling head. --> Working range and technical data Nominal workpiece diameter: 2.400 mm --> Largest millable diameter approx.: 2.800 mm --> Smallest/largest distance between cutter and workpiece axis: 100/1.200 mm Nedpfx Agewzyp Isrjdb --> Largest axial slide travel (special design): 1.300 mm --> Largest clampable cutter (internal milling head): --> Diameter max: 440 mm --> Max. cutter width: 90 mm --> Swivel range of the internal profile milling head/vertical axis: +/- 15° --> Milling mandrel taper: HSK-B160 --> Maximum milling cutter travel: 300 mm --> Table diameter: 2.500 mm --> Part wheel diameter: 2.200 mm --> Table bore --> Diameter: 800 mm --> Depth: 875 mm --> Maximum table load approx.: 40.000 kg --> Max. feed and rapid traverse speeds: --> axial (Z-axis): 4.000 mm/min --> radial (X-axis): 3.000 mm/min --> tangential (Y-axis): 3.000 mm/min --> Milling cutter cooling lubrication device/electric centrifugal pump: approx. 150 l/min --> Increased drop height of magnetic chip conveyor: 1,600 mm --> Increased main stand: 1,300 mm axial slide travel --> Internal profile milling head as motor milling head instead of standard motor milling head --> Max. millable profile depth in steel with approx. 600 N/mm² strength: approx. 65 mm --> Infinitely variable milling speed: 50 - 150 min?¹ --> Max. milling cutter diameter: 440 mm --> Min. milling cutter base circle diameter: 310 mm --> Max. milling cutter width: 90 mm --> Min. internal diameter at 0° bevel angle: 800 mm+) --> Max. workpiece height at 0° bevel angle: 600 mm --> Max. workpiece ring thickness (including clamping device): 500 mm >> Wet and dry, 2 chip conveyors, table diameter 2500 mm

Condition: excellent (used), Year of construction: 1983, functionality: fully functional, Max diam 750mm, Z axial travel 900mm, X Radial travel 380mm, table 630mm, CNC Siemens 802D in Z and X. Weight ca 14.000kg Nedpozbt Iiofx Agrjdb

Condition: good (used), Year of construction: 1976, max. wheel diameter 2300 mm gear width 1000 mm max. module 22 min. module 1 total power requirement 45 kW weight of the machine ca. 22 t Ndsdpfezr Rpdjx Agrob dimensions of the machine ca. 5x3x4 m

Year of construction: 1984, condition: ready for operation (used), A Pfauter vertical CNC gear hobbing machine is available. Modules min./max.: 1/3, max. workpiece diameter: 150mm, max. tooth width: 150mm, milling head tilt: +/-45°, milling cutter axis-table axis distance: 10mm-160mm, table diameter: 160mm, table bore: 63mm. Tool holder: SK40, max. cutter diameter: 130mm, max. cutter length: 220mm, speed: 600rpm, feed: 1500mm/min, tangential path: 170mm, rapid traverse: 3m/min. Machine dimensions X/Y/Z: approx. 4000mm/3000mm/2500mm, weight: approx. 6500kg. On-site inspection is possible. Ndsdpfx Ajwkih Eegrob

Condition: used, Year of construction: 2018, max. wheel diameter 450 mm max. module 4 mm Control Siemens 840 D sl internal diameter 100-300 mm weight of the machine ca. 11 t dimensions of the machine ca. 5,85 x 8,30 x 3,80 m GLEASON-PFAUTER 300 PS Gear Skiving Machine – Year 2018 For sale is a high-performance CNC gear skiving machine type GLEASON-PFAUTER 300 PS, built in 2018. The machine is ideally suited for the precise machining of internal gears and offers excellent dynamics, advanced CNC technology, and a robust machine design. Equipped with a powerful Siemens 840D sl CNC control, this machine provides Ndjdpfx Aszupl Nogrjb optimal conditions for efficient and repeatable gear manufacturing processes. Technical Specifications - Max. gear diameter: 450 mm - Max. module: 4 mm - Internal diameter range: 100 – 300 mm - Max. allowable skiving cutter diameter: 175 mm - Mounting surface diameter: 125 mm - Axis Travels: X-axis travel: 350 mm Y-axis travel: 300 mm Z-axis travel: 440 mm - Max. skiving head swivel angle: ±25° - Workpiece table outer diameter: 570 mm - Max. table load capacity: 5 kN - Feed Rates and Speeds X-axis feed rate: 12,000 mm/min Y-axis feed rate: 5,000 mm/min Z-axis feed rate: 8,570 mm/min - Tool speed: 0 – 3,000 rpm - Workpiece table speed: 0 – 1,500 rpm Additional Equipment / Information - CNC Siemens 840D sl - Swivel gripper slide travel: 180° - Operating voltage: 400 V - Machine weight: approx. 11 t - Space requirement: approx. 5.85 × 8.3 × 3.8 m - Hydraulic oil capacity: 150 l - Coolant capacity: 850 l - Motor and hydraulic cooling: 100 l The machine is in very good condition and is ideally suited for demanding series production and high-precision gear manufacturing applications. Inspection by appointment possible.

Condition: used, Year of construction: 1989, max. wheel diameter 120 mm gear width 400 mm max. module 10 min. module 1 total power requirement 40 kW Ndjdpfx Aez Drcaogrjb weight of the machine ca. 7 t dimensions of the machine ca. 3,840 x 5,025 x 2,490 m

Condition: good (used), Year of construction: 1995, functionality: fully functional, The perfect retrofit machine! Mechanically in phenomenal condition! This machine can be inspected under power until 12.05.2026 and will then be dismantled due to space constraints. Please refer to the attached KLINGELNBERG inspection reports available for download. Gleason P 800 Year of manufacture: 1995 Control: SIEMENS 840 C (discontinued) Condition: Mechanically in excellent condition Functionality: Fully operational Inspection: Available under power Technical Data: Nominal workpiece diameter: 800 mm Max. workpiece diameter: 800 mm Max. workpiece diameter, special version: 1,200 mm Nominal module: 20 / 30 mm Nominal module, special version: 25 / 35 mm Drive power: 35 kW Drive power, special version: 52 kW Cutter head speed range: 20 - 200 rpm Cutter head speed range, special version: 26 - 265 rpm Additional cutter head speed range, special version: 36 - 360 rpm Cutter head swivel range: +30 / -45 degrees Cutter head dimensions (standard cutter head), diameter/length: 350 / 375 mm Min./max. center distance workpiece/tool: 50 / 600 mm Center distance workpiece/tool, special version: 50 / 800 mm Max. axial slide travel: 700 mm Max. axial slide travel, special version: 1,000 mm Max. axial slide travel, special version: 1,300 mm Lowest cutter head position above table: 450 mm Table diameter: 800 mm Table bore diameter: 245 mm Table bore depth: 875 mm Max. table speed: 15 rpm Max. table load: 10,000 kg Machine dimensions: Width A: 5,800 mm Length B: 6,900 mm Height C: 4,700 mm Machine weight: 22,000 kg Ndjdpoy Hfm Nsfx Agreb Regarding the current KLINGELNBERG gear inspection data BEFORE grinding: "Pitch and lead are inconspicuous. One measurement shows a borderline or slightly out-of-tolerance fHα deviation in the profile. Please check whether this value is permissible according to the drawing/customer approval or if correction/rework is required. The gears were always forwarded for grinding to the RZ 1000 REISHAUER and processed accordingly. Nevertheless, overhaul of the C-axis is recommended. A cost estimate from GLEASON PFAUTER LUDWIGSBURG is available. Estimated cost: 10,000 EUR."

Condition: repair required (used), Year of construction: 1987, functionality: unexamined, Max. diameter with counter support: 1450 mm Max. diameter without counter support: 2100 mm Ndodpfxez Df A To Agrob Diameter of the clamping table: 1800 mm Total weight: 38 tons The clamping table has been disassembled and overhauled.

Condition: refurbished (used), Year of construction: 2013, operating hours: 50 h, functionality: fully functional, workpiece weight (max.): 500 kg, table diameter: 450 mm, total length: 7,200 mm, gear diameter: 500 mm, total height: 3,300 mm, total width: 4,500 mm, input frequency: 50 Hz, type of input current: three-phase, milling length: 240 mm, spindle speed (max.): 450 rpm, table bore: 125 mm, spindle speed (min.): 100 rpm, travel distance X-axis: 325 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 400 mm, overall weight: 16,800 kg, distance table to spindle center: 710 mm, controller manufacturer: Siemens Sinumerik 840D sl, drive type: Sinamics S120, control type: CNC control, Equipment: documentation/manual, A Pfauter PE 500 for the economical production of straight and helical spur gears up to module 12 and 500 mm in diameter – completely overhauled by SerWeMa with Siemens Sinumerik 840D sl, equipped with a gripper unit and a 32-position workpiece storage for unmanned operation. The machine is ready for operation in our hall in Chemnitz: you can inspect it under power, and if desired, we will mill your own sample part and you can take delivery of the machine here. No delivery time, no risk. Sold by Serwema Retrofit Solutions, the company that carried out the overhaul and knows the machine inside out. The general overhaul included complete geometric overhaul by grinding and scraping, new roller bearings in the main drive and in the milling head, measuring and reconditioning the worm gear, overhauled or new ball screw drives, overhaul of hydraulics, lubrication and coolant system, and new electrical equipment with Sinumerik 840D sl, Sinamics S120 and new axis motors. An electronic generating gear controls all generating and single-part machining processes, and an NC-controlled crash recovery protects the tool and workpiece in the event of a power or phase failure. New paint in RAL 7035/5015 with oil and coolant resistant two-component paint, acceptance of geometry according to SerWeMa protocol based on DIN ISO 6545. The machine controls six CNC axes: X radial, Y tangential, Z axial, A milling head swivel, B milling cutter drive and C table drive. The SerWeMa gear cutting software guides you through workpiece and tool data via masks, without the need for programming: up to three position-oriented gearings per workpiece, each with its own tool, up to three cuts per gearing with simultaneous or counter-rotating movement, form corrections for convex, conical and convex-conical profiles, lead-in and lead-out phase correction, chamfer milling, dimension correction via tooth width, two-roll or two-ball gauge, measuring stop, shift strategy with defect management per generating cutter and cutting force monitoring with automatic retraction. Technologies: generating milling, single-part milling and worm gear milling both radially and tangentially. A hand-held device with a handwheel allows setup directly in the working area. Technical data: max. workpiece Ø 500 mm, max. module 12, max. milling cutter Ø 200 mm, max. milling cutter length 240 mm, shift travel 200 mm, milling cutter speed 100–450 rpm, swivel angle +25°/−45°, travel radial 325 mm (axis distance 25–350 mm), travel axial 400 mm (310–710 mm), table diameter 450 mm, table bore 125 mm, connection power approx. 60 kVA. Installation dimensions incl. automation approx. 7.2 × 4.5 × 3.3 m, weight approx. 16.8 t. Nsdpfsz Et E Ejx Agredb Equipment: machine enclosure, chip conveyor, gripper unit with two grippers, workpiece storage with 32 positions, preparation for emission extraction (150 mm nozzle, Harting connector on the machine roof). Documentation complete in German: operating manual, electrical diagrams with parts lists, hydraulic and lubrication diagrams. Serwema optionally offers: trial part milling in our factory, additional milling arbors, assembly and commissioning at your location, operator training and a control system upgrade to Sinumerik ONE. Spare parts and service come from a single source, worldwide, even after the purchase.

Condition: used, Year of construction: 2008, control Siemens 840D Hobbing Machines for Large Gears Flexible and Versatile Gear Hobbing Gleason’s large hobbing machines offer maximum productivity for roughing and finishing operations on cylindrical gears for many industries: wind turbines, industrial gearboxes, mining, and shipbuilding, gear machining, and many more. The guideways are wide and feature hydraulically preloaded guides, which are used in combination with a separate linear guide and backlash- free rollers. This ensures precise slide movements with every feed. The design of the worktable ensures optimal conditions for absorbing and transferring cutting forces to the machine base. The use hydrostatic table bearings, combined with the proven backlash-free Ndedpjwzypnefx Agrsb double-worm gear, guarantees precise table movements and the highest flatness and concentricity accuracies of the worktable. This holds true regardless of significant fluctuations in workpiece weight and/or high machining forces. The motorized gear hobbing heads for external and internal gear cutting are designed to meet the requirements of modern cutting tools. All machine sizes can be equipped with both external and internal gear hobbing heads. The power range of the drive takes future tool developments into account. Naturally, the gear hobbing head drive is also backlash-free. These machines are particularly well-suited for use with state-of-the-art cutting materials. >> dry only, 1 chip conveyor, table diameter 1,870 mm

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler Ndsdpfsw Rrb Hjx Agrjb - Technical documentation

Condition: good (used), Year of construction: 2009, operating hours: 41,994 h, functionality: fully functional, GLEASON-PFAUTER P 1600/2000 – Internal and external gear cutting – Ø 2,000 mm – 2009 Machine data Field | Information Manufacturer | GLEASON-PFAUTER Type | P 1600/2000 Year of manufacture | 2009 Machine type | CNC gear hobbing machine / gear cutting machine Machining process | Internal and external gear cutting Workpiece nominal diameter | 1,600 mm Max. workpiece diameter | 2,000 mm Nominal module | 20 / 30 mm Module, special version | 25 / 35 mm Tool head swivel range | +30° / −45° Tool diameter max. | 350 mm Tool length max. | 375 mm Tool speed | 20–200 min⁻¹ Further speed ranges according to manufacturer | 26–265 / 36–360 min⁻¹ Tool head drive power | 35 kW Special version according to manufacturer | 52 kW Distance between workpiece and tool axes | 100–1,000 mm Special version | 100–1,200 mm Axial slide travel, standard | 700 mm Lowest tool head position above table | 450 mm Table diameter | 1,460 mm Table bore Ø | 500 mm Table bore depth | 875 mm Table speed max. | 8 min⁻¹ Table load max. | 20,000 kg Machine width | approx. 6,900 mm Machine length | approx. 8,400 mm Ndjdpfx Asz Au Rtogrob Machine height | approx. 4,700 mm Machine weight | approx. 33,000 kg Electrical data for the specific machine Field | Value Operating voltage | 400 V Frequency | 50 Hz Connected power | 100 kVA Rated current | 155 A Fuse rating | 160 A Control voltage | 24 V Description for machine search GLEASON-PFAUTER P 1600/2000 CNC gear cutting machine, year of manufacture 2009 Heavy-duty vertical CNC gear cutting machine for machining large gear components. The machine is equipped for machining both external and internal gears and features a very large working area up to Ø 2,000 mm. The massive workpiece table has a diameter of 1,460 mm and is designed for workpiece weights up to 20,000 kg. The tool head can be swiveled from +30° to −45°. Maximum tool diameter 350 mm, maximum tool length 375 mm. Of particular interest is the existing configuration for internal gear cutting, which distinguishes the machine significantly from a classic external gear cutting machine. The machine is particularly suitable for the production of large: Gears, internal gear rings, bevel gears, large gearbox components, industrial gearboxes, wind turbine gearboxes, planetary gearboxes, and heavy-duty drive components. Technical key data: Workpiece diameter up to 2,000 mm, module up to 25/35 mm according to manufacturer's specifications, table Ø 1,460 mm, table load 20 t, machine weight approx. 33 t. Technical data according to available manufacturer documentation and nameplate. Subject to prior sale and errors.

Condition: good (used), Year of construction: 1976, max. wheel diameter 1250 mm Nsdpfxozr Rpkj Agredb gear width 1000 mm max. module 16 shifting 250 mm milling spindle speeds (infinitely variable) 32 - 200 U/min min. number of teeth 12 table hole 255 mm total power requirement 32 kW weight of the machine ca. 20 t dimensions of the machine ca. 5,1 x 3,2 x 3,7 m Top condition! 2 cut cycle, change gears, arbors, chip conveyor. Following hob arbors are with the machine: Diameter: 32 , 40 , 50 , 60 mm

Condition: excellent (used), functionality: fully functional, I would be happy to insert the technical data into the document for you. Nodpsy Rh Hyefx Agrsdb Gear Hobbing Machine WMW MODUL ZFWZ 500 x 5 conventional Country of origin: Germany Technical specifications Details max. wheel diameter 500 mm gear width 250 mm max. module 5 min. module 12 mm total power requirement 2.2 kW weight of the machine approx. 1920 kg dimensions of the machine approx. 2500 x 1600 x 1900 mm cutter diameter max. 250 - 285 mm clamping table diameter 460 mm table hole 70 mm accessories: various Control unit conventional Additional information Documents

Condition: ready for operation (used), Equipment: documentation/manual, Lieberr - Lorenz S800 / Gear Hobbing Machine -Well-maintained machine with extensive accessories -1 pallet / Change gears -1 pallet / Hobbing cutters -1 pallet / Clamping arbors DOCUMENTATION -Max. workpiece length with counter support 600mm -Max. workpiece length with retracted counter support 800mm -Max. travel of the milling slide 360mm Ndjdpfx Agezv Ed Dereb -Largest millable pitch with the largest workpiece 5 PI / Normally 8 PI -Taper for spindle - Milling spindle MK 5 -Milling arbors / 22 / 27 / 32 / 40 mm -Max. cutter diameter 186mm -Max. cutter length 170mm -Max. cutter feed 80mm -Cutter speeds 40 - 220 rpm -Feeds infinitely adjustable / Horizontal -Feeds infinitely adjustable / Vertical -Feeds infinitely adjustable / Tangential -Clamping table without water trough 550mm -Clamping table bore 100mm -Clamping arbor taper MK 4 Dimensions: L x W x H 3.6 x 1.8 x 1.9 meters / Weight: 5000 kg Errors and omissions excepted.

Condition: refurbished (used), Year of construction: 2027, functionality: fully functional, total length: 6,100 mm, gear diameter: 180 mm, total height: 3,500 mm, total width: 3,000 mm, input frequency: 50 Hz, milling length: 170 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 300 rpm, travel distance X-axis: 100 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 300 mm, overall weight: 8,400 kg, controller manufacturer: Siemens Sinumerik ONE, drive type: Sinamics S120, control type: CNC control, Equipment: documentation/manual, A high-performance machine for series production: the horizontal Gleason-Pfauter P 210 L, built in 2003, mills shafts, pinion shafts, and small gears up to module 4 and 180 mm in diameter at speeds of up to 4,000 rpm on the cutter and 1,000 rpm on the workpiece – designed for short cycle times and dry machining. Serwema Retrofit Solutions, Chemnitz, completely overhauls the machine and delivers it with Siemens Sinumerik ONE, the latest generation of control systems with full spare parts and support availability. Modern Gleason-Pfauter kinematics, new electrical system, new drives, new safety technology: you get the performance of a new machine at a fraction of the price, and we will inspect it together with you in Chemnitz. The horizontal design makes the P 210 L ideal for shaft machining: workpieces up to 830 mm are clamped between the spindle and tailstock, with 300 mm of axial travel and 100 mm of radial travel (center distance 30–130 mm). The milling head pivots by ±40°, and the tangential travel of 160 mm utilizes the full cutter length of 170 mm for long tool life. The high workpiece speed allows for multi-tooth hobbing cutters and thus the cutting performance required in the gearbox and automotive component supply sector. The machine is prepared for connection to a loading portal or a robot. Technical data: max. workpiece diameter 180 mm, max. module 4, working area radial 100 mm (30–130 mm), axial 300 mm (260–560 mm), tailstock 350 mm (480–830 mm), max. cutter diameter 180 mm, max. cutter length 170 mm, tangential travel 160 mm, cutter speed 300–4,000 rpm, max. workpiece speed 1,000 rpm, swivel angle ±40°, total connection value 50 kVA. Installation dimensions approx. 6.1 × 3.0 × 3.5 m, weight approx. 8.4 t. Nodpfxsz Et Rzo Agrsdb The machine will be delivered with a new Siemens Sinumerik ONE control system and Sinamics S120 drives in an air-conditioned control cabinet manufactured in-house. The user-friendly interface makes setup and programming possible without in-depth G-code knowledge. Geometry acceptance is carried out according to the manufacturer's standard or DIN with a protocol. The scope of delivery also includes the complete machine enclosure with state-of-the-art safety technology, a new coat of paint in RAL 5015/7035, a magnetic chip conveyor, circulation and loss lubrication, a hydraulic unit, a coolant system, and the operating manual.

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, Fully reconditioned milling head from a Gleason Pfauter P210L – manufactured in 2004. Nodpfxszr Hd Rj Agrsdb

Condition: used, Year of construction: 2008, Maximum workpiece outer diameter 3420 mm workpiece diameter nominal 2400 mm max. module 30 mm control Siemens Sinumerik 840 D Minimal workpiece - internal diameter 630 mm Maximum workpiece outer diameter 3420 mm Maximum workpiece tooth width 600 mm max. rim strength 500 mm Maximum permissible head circle diameter 440 mm Hob/disc cutters – Maximum length 90 mm Milling arbour diameter 80 mm milling head -swivable +15/-15 Grad workpiece table outer diameter 1870 mm Workpiece table bore 600 mm Workpiece table – Maximum permissible load 300 kN rapid traverse X-axis 3000 mm/min rapid travel z-axis 4000 mm/min Workpiece table speed 0-6 U/min Tools speed 18-180 U/min weight of the machine ca. 38 t dimensions of the machine ca. 8,41 x 9,05 x 5,19 m total connected load 100 kVA Equipment/accessories: - IFK2 internal milling head Ndedpfx Asztz Ruogrsb - Milling arbor with spacer discs - Chip conveyor - Oil mist extraction - Dry machining only - Technical documentation

Condition: good (used), functionality: fully functional, Tos OFP-32, Serial No. 0427441 Condition: 8/10 Ndedpfx Agezxqdzsrjb Max. module: 7 / 9 Max. diameter: 320 mm Max. length: 200 mm Vertical gear hobbing machine

Condition: like new (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 25582, Equipped with: Ndjdpfx Agszn Aymorob Fanuc 30ia Control Hydraulic System Coolant System Chip Conveyor Pneumatics Lube System Jib Crane Change Gears Mist Collector Transformer Work Light Stack Light Specifications: Extreme Ratio: 10:1 Root Angle Range (B-Axis): -5 deg. TO 90 deg. Equivalent Root Angle Range: -8 deg. to 90 deg. (Equivalent refers to cradle type machine.) Face Hobbing: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -152 mm TRI-AC Cutter w/13 Blade Groups Max. Full Depth: 0.550" Max. Face Width: 1.6" Face Milling: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -7.5" Diameter Cutter Max. Full Depth: 0.625" Max. Face Width: 1.6" Max. Swinging Base Travel (B-Axis): -5 deg. to 90 deg. Max. Vertical Travel (Y-Axis): -4" to 7" Max. Horizontal Travel (X-Axis): -6" to 4" Sliding Base Travel (Z-Axis): 2" to 12" Machine Center to Work Spindle Face (Fixed): 4.5" Tooth Number: 5 to 200 Inclusive Cutting Diameters: Conventional Face Milling: 1.1" to 7.5" Helixact: 100mm to 200mm Fine Pitch: 102mm to 152mm Coarse Pitch: 152mm only Speeds: B-Axis--Swinging Base (Degrees per Second): 30deg./sec. A-Axis--Work Spindle (Face Milling)(RPM): 0-75 A-Axis--Work Spindle (Face Hobbing)(RPM): 0-375 C-Axis--Cutter Spindle (RPM): 30-500 X-Axis--Horizontal (Inches per Second): 4.92"/sec. Y-Axis--Vertical (Inches per Second): 4.92" Z-Axis--Sliding Base (Inches per Second): 4.92"/sec. Work Spindle: Diameter of Taper at Large End (#39 Taper): 3-29/32" Taper per Foot: 39/64" Depth of Taper: 3" Floor Space: 95.75" x 63.5" Height (less mist collector): 90.75" Approx. Weight: 22,000 lbs

Condition: excellent (used), Year of construction: 2018, max. wheel diameter 450 mm max. module 4 mm internal dia. - min. 100 mm internal dia. - max. 300 mm Maximum permissible peeling wheel diameter 175 mm Diameter of the installation area 125 mm slide travel X-axis 350 mm slide travel Z-axis 300 mm slide travel Z-axis 440 mm Largest swivel range of the peeling head ±25 Grad workpiece table outer diameter 570 mm Workpiece table – Maximum permissible load 5 kN Feed - X 12000 mm/min Feed - Y 5000 mm/min Nsdpfozfqikox Agrsdb Feed - Z 8570 mm/min Tools speed 0-3000 U/min Workpiece table speed 0-1500 U/min voltage 400 V weight of the machine ca. 11 t dimensions of the machine ca. 5,85 x 8,3 x 3,8 m Technical specifications: - CNC Siemens 840 sl - Swivel grab travel: 180 degrees Fluids: - Hydraulic: 150 l - Coolant: 850 l - Engine and hydraulic cooling: 100 l - Grease lubrication: 2 kg

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens 840D max. workpiece dia. 1600 mm max. module 20 mm tip circle diameter 350 mm weight of the machine ca. 33500 kg dimensions of the machine ca. 10,53 x 6,38 x 4,68 m Nedpfewzypuox Agrsdb Technical details: - x-travel: 900 mm - y-travel: 300 mm - z-travel: 1000 mm - Control system: Siemens Sinumerik 840D - Workpiece diameter - max.: 1600 mm - Module - max.: 20 mm - Head circle diameter: 350 mm - Milling spindle diameter: 375 mm - Total power consumption: 80 kVa - Machine weight approx.: 33500 kg - Space requirement approx.: 10.530 x 6.375 x 4.680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in 1/min: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - Motor milling head M 2 - Milling mandrels - Oil cooler - Technical documentation

Condition: excellent (used), max. wheel diameter 175 mm gear width 350 mm max. module 3 min. module 0,5 Ndodpfxeznnits Agreb weight of the machine ca. 0,9 t dimensions of the machine ca. 1,2 x 0,8 x 1,4 m
