Used Ibarmia Vertical Machining Center for sale (69,609)

Condition: new, Year of construction: 2025, table length: 900 mm, table width: 450 mm, number of spindles: 1, spindle speed (min.): 8,000 rpm, table load: 500 kg, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Machine weight 4000 kg Nwsdjxc I Dgepfx Ag Def It is also possible to supply CNC milling machines, machining centers with other table sizes: VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm VMC 1680 table 1700x800 mm VMC 1890 table 2000x900 mm

Condition: good (used), Year of construction: 1997, functionality: fully functional, We offer an nice condition Matsuura with tools and accessoriess, very atractive machine for a serious work. Description Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. Spindle Chiller WASTE CONVEYOR with Yasnac i80M Control 20 Position: ATC BT40 : Taper Specifications Manufacturer MATSUURA Model MC600VF Nedpfjvkx Rkox Ag Dewf Year 1997 Condition Used Serial Number 970112285 Table size 870 x 400mm Coolant tank X = 600 Y = 410 Z = 470mm Spindle speeds 30 – 15000 rpm.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: M242-06206013CFA, travel distance X-axis: 610 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 610 mm, table width: 510 mm, table length: 760 mm, TECHNICAL DETAILS Travel X-Axis: 610 mm Travel Y-Axis: 508 mm Travel Z-Axis: 610 mm Spindle Nose to Table: 152 - 762 mm Table Clamping Surface: 760 x 510 mm T-Slots (DIN 650): 5 x 18 H8 x 100 Table Load Capacity (evenly distributed): 1,500 kg MACHINE DETAILS AC Voltage: 400 V Phases: 3 Frequency: 50 Hz Connected Load: 18 kVA Largest Motor: 7.5 kVA Nwsdpfxjy Dglne Ag Djf

Condition: ready for operation (used), Year of construction: 2013, operating hours: 13,672 h, functionality: fully functional, machine/vehicle number: 1237361A51A, travel distance X-axis: 610 mm, travel distance Y-axis: 430 mm, travel distance Z-axis: 570 mm, controller model: Fanuc 0-MD, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel X-axis: 610 mm Travel Y-axis: 430 mm Travel Z-axis: 570 mm Table length: 650 mm Table width: 450 mm Tool holder: BT40 Main spindle power: 15 kW Max. spindle speed: 10,000 rpm Number of axes: 3 MACHINE DETAILS Control: Fanuc 0-MD Tool magazine: 24 positions Nsdpfxjy Avucj Ag Dewf Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,200 x 2,450 mm Net weight: 9,000 kg Shipping units: 2 Operating hours: 13,672 h Power consumption: 11 kW EQUIPMENT External cooling system Chip conveyor Pallet milling machine Spindle cooling Changeover table Tool magazine Note: The robot shown in the video is not included in the scope of delivery or sale.

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 1,016 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 635 mm, table load: 1,360 kg, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Njdpfx Asy A Ip Sjg Dswf Travel X axis: 1,016 mm Travel Y axis: 660 mm Travel Z axis: 635 mm Max. spindle speed: 12,000 rpm Spindle power: 22.4 kW Table size: 1,372 x 610 mm Max. table load: 1,360 kg Rapid traverse X axis: 30 m/min Rapid traverse Y axis: 30 m/min Rapid traverse Z axis: 30 m/min MACHINE DETAILS Control: HAAS CNC control Tool changer: 20 + 1 positions Tool holder: SK40 EQUIPMENT Documentation/manual Chip conveyor Tool changer Coolant system Work area lighting Electronic handwheel Network / USB interface

Condition: ready for operation (used), Year of construction: 2010, operating hours: 47,512 h, functionality: fully functional, travel distance X-axis: 2,230 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 850 mm, controller model: HEIDENHAIN iTNC 435, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS X-axis travel: 2,230 mm Y-axis travel: 1,400 mm Z-axis travel: 850 mm Table dimensions: 2,000 mm × 1,250 mm Maximum table load: 6,000 kg Spindle speed: 6,000 rpm Tool holder: SK50 Tool magazine capacity: 40 positions Rapid traverse in X / Y / Z directions: 12 m/min MACHINE DETAILS Control model: HEIDENHAIN iTNC 435 Spindle drive power: 38 kW Dimensions & Weight Dimensions (L × W × H): 6,135 mm × 4,338 mm × 4,150 mm Machine weight: 22,000 kg Operating hours (machine): 72,846 h Operating hours (program run): 48,891 h Operating hours (spindle running time): 47,512 h EQUIPMENT Coolant system Internal coolant supply (IKZ) Electronic handwheel Nwsdpoy Dgy Eofx Ag Dsf Touch probe Automatic workpiece measurement Chip flushing Chip conveyor

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 550 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 10,000 rpm, The machine spindle was replaced in 2022! TECHNICAL DETAILS Traverse path X-axis: 800 mm Traverse path Y-axis: 520 mm Traverse path Z-axis: 550 mm Spindle type: SK40 Spindle speed: 10,000 rpm Tool changer: 24-position Table size: 950 x 520 mm MACHINE DETAILS Njdpfx Agoy E Hqtj Djwf Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (LxWxH): approx. 2.60 x 2.60 x 2.70 m Weight: 6,800 kg Operating Hours Machine on-time: approx. 47,000 h Program run time: approx. 5,700 h Spindle: approx. 4,800 h EQUIPMENT IKZ (internal coolant supply) Hexagon probe Note: NC clamps and tool holders are not included in the offer.

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL Nwsdpoyzkdvjfx Ag Djf FULL ENCLOSURE LEVEL PADS TURN MILL DRIVE EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE TOOL GAUGING - BLUM LASER

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based Nsdpfx Aoyzkdceg Dowf What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 670 mm, travel distance Z-axis: 625 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 30 m/min, feed length X-axis: 1,270 mm, feed length Y-axis: 670 mm, feed length Z-axis: 625 mm, nominal power (apparent): 37 kVA, controller manufacturer: Fanuc, controller model: i Series, workpiece weight (max.): 1,000 kg, total height: 2,815 mm, total length: 3,350 mm, total width: 3,760 mm, table width: 650 mm, table length: 1,300 mm, table load: 1,000 kg, overall weight: 8,500 kg, spindle speed (max.): 12,000 rpm, coolant supply: 20 bar, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 30, tool length: 300 mm, tool diameter: 125 mm, tool weight: 8 g, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Doosan DNM 650 Vertical Machining Centre – 2011 Fanuc i-Series Control | 12,000 RPM | 4th Axis Ready 2011 Doosan DNM 650 Vertical Machining Centre with Fanuc i-Series control. 12,000 RPM BT40 spindle, rebuilt spindle, 4th axis ready, 30-tool ATC, TSC, chiller & swarf conveyor. Available from Used Machine Tools Ireland. Manufacturer: Doosan Model: DNM 650 Machine Type: 3 Axis Vertical Machining Centre with 4th Axis preparation Year: 2011 Control: Fanuc i Series Condition: Very Good - spindle rebuilt in 2026 Availability: March 2026 We are pleased to offer this 2011 Doosan DNM 650 Vertical Machining Centre, a highly regarded and extremely rigid VMC, ideal for precision subcontract machining, toolmaking, and production environments. This machine is equipped with a Fanuc i-Series control and benefits from a newly rebuilt spindle, ensuring excellent performance, reliability, and long service life. The machine is prepared for a 4th axis with Nikken interface, making it an ideal platform for future rotary or multi-axis work. Key Specifications Manufacturer: Doosan Model: DNM 650 Year: 2011 Control: Fanuc i-Series Spindle Speed: 12,000 RPM Tool Taper: BT 40 Nwsdsyfh Ixopfx Ag Def X / Y / Z Travels: 1270 / 670 / 625 mm Table Size: 1300 × 650 mm Maximum Table Load: 1000 kg Rapid Traverse Rates: X / Y: 36 m/min Z: 30 m/min ATC: 30 Places Max Tool Diameter: Ø80 mm with adjacent tools / Ø125 mm without Max Tool Length: 300mm Max Tool Weight: 8 kg Machine Dimensions (Approx): 2760 x 3350 x 2815mm Machine Weight (Approx): 8500kg Features & Equipment Newly rebuilt spindle Nikken 4th Axis preparation 30-station Automatic Tool Changer (ATC) 20 bar through-spindle coolant (TSC) Coolant chiller LNS swarf conveyor Data server / networking capability Fully enclosed, heavy-duty construction Please Note No tool holders, vices, or swarf bin included Ideal For Precision engineering CNC subcontract machining Automotive & aerospace components General and high-speed milling applications The Doosan DNM 650 is known for its exceptional rigidity, accuracy, and reliability, making it one of the most popular vertical machining centres in its class. Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2002, HAAS VF10 X AXIS 3048 MM Nwedpey Epkmjfx Ag Def Y AXIS 813 MM Z AXIS 760 MM TABLE WEIGHT MAX 1800 KGS 3 AXIS HAAS CONTROL THIS IS ALL THE DETAILS I HAVE AT THE MOMENT MORE WILL FOLLOW CHEAP MACHINE - MUST BE LOADED FROM SITE AND STRAIGHT ON TO NEW DESTINATION . MORE PHOTOS AND A VIDEO IS AVAILABLE

Condition: used, Year of construction: 2019, functionality: fully functional, Equipment: chip conveyor, 2019 Brother Speedio M140 X2 (5 Axis 4+1) Plus 2019 Brother Feedio. Nodpfx Asy Ewf Ujg Dswf Brother M140 CNC Machining Centre – 5 Axis – Available Immediately. The Brother M140 CNC machining centre is a compact, high-speed 5-axis machine designed for precision component manufacturing. Built in 2019, this machine offers excellent productivity with a high-speed spindle, 22 tool capacity and through-spindle coolant, making it ideal for subcontract machining environments. The machine has a full service history and is available immediately for inspection. Machine Details Machine: Brother M140 CNC Machining Centre Year: 2019 Control: Brother C Control Axis Configuration: 4+1 / 5 Axis Tool Capacity: 22 Tools Spindle: 16,000 rpm Face & Taper Through Spindle Coolant: 35 Bar CTS Equipment & Options Rear exit swarf conveyor NOP pumps for washdown and flood coolant Bag filtration system Air bench mist extraction Additional Information Full service history High-speed machining capability Feedio Robotic Machine Tending System with ABB 6 Axis Robot – Available Immediately The Feedio robotic machine tending system is an automated loading and unloading solution designed to improve productivity and reduce manual handling in machining environments. Built in 2019, this system is equipped with a 6-axis ABB robot and twin-head loading capability, allowing efficient automated part handling. The system includes 4 metre conveyors and is suitable for integration with CNC machines for fully automated component loading and unloading. System Details System: Feedio Robotic Machine Tending System Year: 2019 Robot: 6 Axis ABB Robot Conveyor Length: 4 Metres Loading System: Twin Head Load / Unload Features Automated machine loading and unloading Twin-head handling for increased efficiency 6-axis robotic flexibility Integrated conveyor system for part flow Ideal for CNC production automation This system is well suited for subcontract machining environments looking to increase automation and production efficiency. For further information, pricing, or to arrange an inspection, please get in touch.

Condition: good (used), Year of construction: 2007, Traverses X Y Z: 1270 x 660 x 635mm, Table 1321 x 584mm, Spindle Speed 0 – 7500rpm, Spindle taper BT 40, Spindle Motor 20Hp, Nwjdpoy Eyauefx Ag Dsf HAAS Control, 20 Station tool change, coolant

Condition: good (used), Year of construction: 2016, Traverses X Y Z: 610 x 508 x 610mm, Table 762 x 508mm, Spindle speed 40 – 8000 rpm, Spindle taper CAT40, Nodpfx Asy Ex Hasg Djwf 24 ATC, Rapid feedrate 24/30m/min, Spindle motor power 12/9kW, Low volt light, Hurco control, coolant.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Machining centre Mori Seiki Type NV5000 Nwjdpfxoy Hq Rge Ag Dof Year 2006 3 phases CNC Fanuc

Condition: excellent (used), Year of construction: 2020, Traverses X Y Z 3048 x 1016 x 762mm, Table size 3048 x 711 mm, Maximum workpiece weight 1814 kgs Spindle speed 8,100rpm, Spindle taper BT40, Nwodpfx Agsy Emyuo Djf Motor 30HP, Haas control, 30 station ATC

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: SMK00004, SPECIFICATION X Travel 1020mm Y Travel 610mm Nwedpfx Ajy E I A Djg Def Z Travel 620mm Table size 1200 x 600mm Spindle to table 140 – 760mm Spindle speed 12,000rpm Spindle motor 15kW Spindle taper BT40 Tool magazine capacity 24 Machine weight 8000Kg Footprint (W x D x H) 3650 x 2900 x 2900mm approx. MACHINE EQUIPPED WITH: - Siemens 840D CNC control (with Shopmill) Swarf conveyor 4th axis Renishaw tool setting probe Through spindle coolant system Lighting Enclosed guarding

Condition: like new (used), Year of construction: 2018, operating hours: 11,010 h, functionality: fully functional, machine/vehicle number: 0696, travel distance X-axis: 900 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 520 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, controller model: Heidenhain, table load: 400 kg, rotary table diameter: 520 mm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 11,010 h, spindle motor power: 35 W, input voltage: 230 V, KOVOSVIT MAS MCV 1000 5AX (S) CNC Machining Centre We are selling the machine as we need to free up space in the factory. Vertical 5-axis simultaneous machining centre. High precision for complex parts and 3D machining. Tilting/rotary table enables complete machining in a single setup. High-speed spindle for efficient production. Heidenhain CNC control, ideal for precision work. Nwsdpfx Agsyt Nw Rs Djf

Condition: like new (used), Year of construction: 2009, operating hours: 20,929 h, functionality: fully functional, machine/vehicle number: 23500, travel distance X-axis: 3,320 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 760 mm, feed rate X-axis: 24 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, controller model: Heidenhain, table width: 3,400 mm, table length: 700 mm, spindle speed (min.): 10,000 rpm, spindle speed (max.): 24,000 rpm, operating hours of spindle: 20,929 h, input voltage: 230 V, We are selling the machine because we need to free up space in the factory. CNC Machining Centre TVMC-3000 (L) Table: up to 3400 × 700 mm (maximum load 4,000 kg). Travel X/Y/Z: up to 3320 × 710 × 610 mm. Spindle: BT40 taper, speed up to 14,000 RPM. Automatic tool changer: 24 positions. Nedpfeyt Np Tjx Ag Dswf Rapid traverse: up to 30 m/min. Precision: positioning ±0.005 mm / 300 mm. CNC control available: Heidenhain.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 6,023 h, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, spindle speed (max.): 8,000 rpm, number of axes: 4, TECHNICAL DETAILS Travel X-axis: 1,020 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Table length: 1,150 mm Table width: 500 mm Tool holder: BT40 Main spindle power: 11 kW Max. spindle speed: 8,000 rpm MACHINE DETAILS Control: CNC Number of axes: 4 Power: 15 kW Dimensions & Weight Dimensions (L x W x H): 3,500 x 2,000 x 2,500 mm Net weight: 5,000 kg Transport packages: 1 Operating hours: 6,023 h EQUIPMENT Chip conveyor Nwjdpoy Hh Iiofx Ag Dsf External cooling Tool magazine

Condition: excellent (used), Year of construction: 2016, 5-Axis Machining Center Hedelius RS605 K -1200 Control: Heidenhain iTNC530 Year of manufacture: 2016 Internal machine no. 11 Travel paths: X-axis: 1,200 mm Y-axis: 650 mm Z-axis: 520 mm Fixed machine table: X-axis: 570 mm Y-axis: 650 mm Z-axis: 520 mm Number of T-slots: 7 (each 14 mm wide) Feed rate X/Y/Z: 0 – 45 m/min Clamping area: 760 x 600 mm Rotary-swivel table: Clamping area: Ø 520 mm Taper: SK 40 Tool magazine: 30 positions Spindle speed: 50 - 12,000 rpm Accessories: Kinematic Opt Handheld control unit Sieve filter system KM500 ICS 25 bar Nwjdpfjyk S Sxsx Ag Dsf Chip conveyor Air blow gun Rinse gun M&H workpiece probe M&H table radio probe prepared

Condition: good (used), Year of construction: 2008, functionality: fully functional, The Depo/ZPS machining center features an overhead gantry, meaning that all machine movements are performed by the tool. As a result, the mass of the workpiece and clamping device remains constant during machining. Year of manufacture: 2008 Spindle hours approx. 3,500 h (after spindle replacement in 2023) Control system: - Heidenhain iTNC 530 - Heidenhain HR 410 handwheel - Swiveling control panel with 15.1" monitor - Integrated Ethernet interface Technical Data Travel ranges: X 1,000 mm, Y 900 mm, Z 600 mm Work table: - 1,200 mm x 1,000 mm - Max. workpiece weight: 3,000 kg - Max. workpiece size: 1,000 mm x 800 mm x 700 mm Milling spindle: - Continuous power: 30 kW - Speed range: 1-18,000 rpm - Torque S1/100%: 80 Nm Njdpfxjy Hp Rrj Ag Dswf - Tool holder: HSK 63 form A - Main spindle jacket cooling - Air through spindle center for tool cooling (ILZ) - Coolant with 40 bar through the spindle (IKZ) Axes feed rates: - X, Y, Z axis feed up to 40 m/min - X, Y, Z axis rapid traverse up to 40 m/min Tool changer with double-arm gripper: - Number of tools in drum magazine (outside working area): 38 - Max. tool diameter: 80/115 mm - Max. tool length: 250 mm Tool and workpiece measurement for automatic tool and part size adjustment: - Tool radius and length measurement - Tool breakage detection - Blum laser for component measurement (Inspect) Disposal system: - Gooseneck slat conveyor - (Chip cart to be provided by buyer) Additional equipment: - Minimum quantity lubrication Minibooster 2 - Machine enclosure with full-area protective covers - Crane loading possible by unhooking the chip protection device at the front - Workspace lighting with two fluorescent lamps on the side walls Machine data: - Space requirement including service areas (LxWxH): approx. 5,000 mm x 4,220 mm x 3,830 mm - Machine weight incl. additional units: approx. 13,000 kg - Connected load: 45 kVA, 400V, 50 Hz This machining center is located in a precision tool and mold making shop. It is exceptionally well-equipped with practical features and is in very good condition. The Depo/ZPS Dynamic 1009 operates precisely and reliably. There is no maintenance or repair backlog.

Condition: used, Year of construction: 2007, functionality: fully functional, Turning diameter 108 mm Turning length 330 mm Serial number ML 27 108 Turning diameter over the slide Nwjdpfx Asy Hqg Isg Def 530 mm X-axis travel 210 mm Z-axis travel 310 mm Integrated C-axis Yes Control GE Fanuc Series 18i-TB Tool changer stations 16 Number of tool positions 10 Number of controlled axes 3 Spindle bore 27 mm Spindle speed range 0–8000 rpm Total power requirement 7.5 kW Twin-spindle Turning diameter over bed: 530 mm Turning length: 330 mm X-axis travel: 210 mm Z-axis travel: 310 mm Rapid traverse speed: 30 m/min Spindle speed: 8000 rpm Spindle configuration: A2-4, 5C Spindle bore: 27 mm Turret type: VDI 25 Driven tool speed: max. 6000 rpm Number of turret positions: 16 Control: GE Fanuc Series 18i-TB Includes various tool holders, including 6 driven tool holders Note: No tools supplied Bar feeder: BARLOAD Type: Hydrafeed BA 65 Serial number: 16080043 Year of manufacture: 2009 Bar length: 1200 mm Bar diameter: 5–65 mm Bar capacity: 10 pieces (65 mm) Dimensions: 1910 × 1000 × 1250 mm Weight: 320 kg

Condition: used, Year of construction: 2007, functionality: fully functional, Z travel: 460 mm X travel: 635 mm Y travel: 510 mm CNC control: Siemens 840D - Powerline Nsdpfx Aey Hqd Tjg Dowf Table size (L x W): 790 x 560 mm Taper: SK 40 Tool changer positions: 30 Spindle power: 13 kW Spindle torque: 83 Nm Speed range: 10,000 rpm Rapid traverse: 30 m/min Work table: Clamping area: 790 x 560 mm Table load capacity (max.): 600 kg Equipment/Accessories: Chip removal: Chip conveyor Coolant removal: High-pressure through-spindle coolant system with paper belt filter Oil mist extraction: Mechanical separator Setup mode: Electronic handwheel Additional equipment: Air gun Transport dimensions: Machine: 2,800 x 2,000 x 2,700 mm, approx. 4,100 kg Chip conveyor: 3,000 x 1,000 x 1,650 mm, approx. 450 kg Coolant unit: 1,800 x 1,300 x 1,800 mm, approx. 450 kg

Condition: used, Year of construction: 2008, operating hours: 50,745 h, functionality: limited functionality, machine/vehicle number: 15115223254, travel distance X-axis: 2,200 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 720 mm, controller manufacturer: Siemens, controller model: Siemens 840D, workpiece weight (max.): 2,200 kg, overall weight: 12,000 kg, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Deckel Maho DMF 220 Linear – 3-Axis Machining Center – Used For sale is a used 3-axis machining center, model Deckel Maho DMF 220 Linear. 18,400 spindle hours 50,745 power-on hours The machine was actively used in series production until recently and was mainly employed for machining steel and aluminum. Due to investments in new equipment, the machine will no longer be overhauled and is therefore being sold as is. Condition: The machine is generally operational, but has a spindle defect. The spindle needs to be repaired. Features: - Partition wall for setup time optimization (parallel machining/setup in one half of the enclosure) - Conveyor belt filtration system for coolant processing - Automatic tool changer - Spacious working area for complex components Terms of sale: - Price ex foundation - Transport and loading to be arranged by the buyer - Viewing by appointment only Nwsdpjy Hqufsfx Ag Djf Note: The machine was in productive use until a few weeks ago, right up to its decommissioning. Price is negotiable.
