Used Knoll Chip Conveyor for sale (11,634)

Condition: ready for operation (used), Chip conveyor, chip transporter, Knoll 320 S-1/200, Used Machine Manufacturer: Knoll Type: 320 S-1/200 Overall Dimensions: Width: 6200 mm Depth: 1300 mm Ijdjxtwqdjpfx Apcjia Height: 1610 mm Belt Specifications: 480 x 130 x 60 x 310 mm Belt Speed: 1.8 m/min Year of Manufacture: 2015 Discharge Opening Size: 550 x 530 mm Hopper Opening: 3120 x 410 mm Slat Pitch: 315 mm

Condition: new, Year of construction: 2018, Chip conveyor including pump, suitable for CTV 160 Iodpey Amhyofx Apceia

Condition: good (used), Year of construction: 2016, Chip conveyor by Knoll for INDEX ABC. In good used condition. Year of manufacture: 2016. Iiodpfeyz Thwox Apcoa

Condition: excellent (used), Chip conveyor for DMC 635 V including pump Iodpfxsyz Iico Apceia

Year of construction: 2002, condition: good (used), Hinge width 300 mm Slide-in width - / height 390 x 100 mm Insertion length 4615 mm Height from floor to lower edge of chip ejector 700 mm Hinge drive 0.37 kW Transport dimensions L x W x H approx. 5965 x 750 x 1010 mm (height without feet!) Weight approx. 500 kg Foot height adjustable yes This hinged chip conveyor manufacturer TEKNICALDE model TC 1 ½ 300 was used on a CNC bed milling machine MTE Kompakt. Iisdpomdqx Hefx Apcja Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: like new (used), Year of construction: 2011, Lehmann chip conveyor Iiodpoyypgmofx Apcja Unused 400 V 50 Hz

Year of construction: 1990, condition: good (used), Throwing fan ideal for wood chips, with feed conveyor belt approximately 3 m long. Blade span 900 mm, equipped with 11 kW motor. Iedjyy Uzcjpfx Apcoia

Condition: ready for operation (used), Year of construction: 2001, total length: 3,600 mm, total height: 1,300 mm, conveyor belt width: 320 mm, delivery head: 1,000 mm, ejection height: 1,000 mm, conveying length: 1,900 mm, conveyor belt length: 1,900 mm, installation height: 180 mm, Knoll 240 S-1 chip conveyor for sale Good condition. Iedpfxsyxxf No Apceia Installation width: 320 mm Conveyor belt length up to discharge: 1900 mm Conveyor height: 180 mm If you have any further questions, we are at your disposal.

Condition: good (used), Year of construction: 2020, functionality: fully functional, travel distance X-axis: 215 mm, travel distance Z-axis: 520 mm, quill diameter: 72 mm, quill stroke: 110 mm, overall weight: 3,070 kg, swing diameter over bed slide: 500 mm, swing diameter over top slide: 220 mm, Equipment: chip conveyor, CNC lathe OPTIturn S600 slant bed with Sinumerik 828 D control system, including the following options: - Safety Integrate - Remnant material detection and processing - Shopturn step programming - Network drive management - 3-D simulation - Real-time drawing/track back - 15.6-inch color display, multitouch - Spindle mount DIN ISO 702-1 No. 6; chuck through-hole Ø 65mm; hydraulically operated chuck Ø 215mm; tailstock mount MK4 - Hydraulic tool turret LS200 with 12 tool stations, max. holder height 25mm - 30° slant bed for especially large machining diameters - Dimensionally stable linear guides ensure long service life through maximum static and dynamic rigidity - Handwheels for manual movement - Heat exchanger on control cabinet - Includes machine feet - Hydraulic unit 1500W, 60 liters - Foot pedal for hydraulic chuck clamping/release - Foot pedal for tailstock with hydraulic quill - Halogen work lamp - Siemens servo motors on all axes - Chip conveyor - Chip trolley - Device for manual tool measurement - Portable electronic handwheel - Renishaw tool probe - Includes machine feet - Electrical connection, 31 KVA three-phase 400V ~ 50 Hz - Control upgrade PPU290 SW8 Iodpfxow U Rv Ds Apcjia - Sauter turret VDI30-12T - Automatic tailstock movement - Through-spindle coolant 20 bar - Oil skimmer - Coolant pump 5 bar - Automatic tool measurement - Automatic parts catcher - Axial driven tool holder - Radial driven tool holder

Condition: used, functionality: unexamined, total length: 8,200 mm, total height: 750 mm, total width: 450 mm, conveyor belt width: 400 mm, ejection height: 700 mm, -KOM 1561- Offered is a well-maintained scraper conveyor with high discharge. All further data and dimensions can be taken from the pictures. Note: The unit is located in our warehouse and can be inspected under power. The hinged belt is in good condition. Iedpsyvh I Isfx Apcsia

Condition: used, functionality: unexamined, total width: 300 mm, conveyor belt width: 290 mm, -KOM 1550- Offered here is a magnetic belt conveyor. The technical data can be found in the images and on the nameplates. Note: Iisdeyvfqljpfx Apcea The chip conveyor is available from our stock and can be inspected under power. Motor: Manufacturer: SEW Eurodrive Type: R43-VU01

Condition: used, functionality: unexamined, total length: 1,600 mm, total height: 1,500 mm, total width: 460 mm, conveyor belt width: 400 mm, ejection height: 1,290 mm, -KOM 1606- We offer you a scraper conveyor here. The machine can be viewed at our warehouse and tested under power. We have several chip conveyors for sale. We would be happy to provide you with a package price as well. Iisdjyvfnqjpfx Apcja

Condition: used, total length: 2,100 mm, total height: 1,500 mm, total width: 650 mm, conveyor belt width: 620 mm, ejection height: 1,000 mm, -KOM 1607- We are offering you here a scraper belt conveyor from May – Fran GMBH Essen. Dimensions can be found in the attached sketch. Iedjyvfi Ispfx Apcsia The machine can be inspected and tested under power at our warehouse. We offer several chip conveyors and would be happy to provide you with a package price.

Condition: used, functionality: unexamined, machine/vehicle number: 4059/74, General / technical data: well preserved chip conveyor & high discharge for CNC lathe or similar machines Remark: The equipment is in our stock and can be inspected under power. The hinge is in good condition. Iiodpfxsgg Sbvo Apcea

Condition: used, Chip conveyor, scraper conveyor with coolant tank KNOLL type 750 K-3/650 Scraper belt conveyor Serial no.: 346919 Order no.: 200725773 Year of construction 2007 Metal link width approx. 670 mm Distance between flights approx. 550 mm Length of possible chip removal 330 to approx. 3000 mm Insertion length approx. 2700 mm Insertion height approx. 400 mm Iiodophvl Tjpfx Apcoa Insertion width approx. 860 mm Conveyor height - ejection height 1800 mm Belt speed approx. 20 mm/sec. = 1.2 m/min. Motor power belt drive 0.55 kW Motor power coolant pump 3.0 kW Coolant pump flow rate 40 liters/min. Mains connection 400 Volt, 50 Hz - Scraper chain drive via gear motor - Coolant tank with integrated pump - Coolant pump, BRINKMANN centrifugal pump, type TS 24/180 - Steel cover plates with drop handles for lifting, chequer plate can be used Space requirement L x W x H 6100 x 1150 x 2320 mm dead weight approx. 2000 kg good condition The conveyor is for transporting chips from a milling machine, lathe or machining center.

Condition: used, Chip conveyor, scraper conveyor with coolant tank BMF Type KF 200 K17 Ident. No.: Order No.: 915979 Year of manufacture: 1992 Metal link width: 200 mm Pitch between scrapers: approx. 380 mm Possible chip removal length: 1100/2100 mm Insertion length: approx. 1350 mm Insertion height: 370 mm Insertion width: 460 mm Hopper width (top): 400 mm Hopper width (bottom): 170 mm Conveying height - discharge height: approx. 1250 mm Motor power belt drive: 0.37 kW Power supply: 400 Volt, 50 Hz - Scraper chain driven by geared motor - Coolant tank without coolant pump Required space (L x W x H): 3800 x 1300 x 1650 mm Weight of chip conveyor: approx. 500 kg Good condition Iiodpjhwt H Ajfx Apcsa The chip conveyor comes from a GILDEMEISTER CNC lathe. The conveyor is suitable for chip transport from a milling machine, lathe, or machining center.

Condition: like new (used), Year of construction: 2016, operating hours: 1,000 h, functionality: fully functional, Drag chain conveyor systems (5 units) in excellent condition (used only for a few months) Iedeyc Nfgepfx Apcoia

Condition: used, Year of construction: 2013, Chip conveyor, manufacturer BMF - BÜRENER, with filter system and high-pressure pump. Chip conveyor dimensions: Neck width: 600 mm, neck height: 200 mm, conveyor length: 3000 mm. Ijdpfjiicnkex Apcjia

Condition: good (used), Year of construction: 1982, Chip conveyor, Manufacturer: SILISTRA, Type: TCA 280X4710, year 1982, with coolant pump. Was previously connected to a CNC boring mill. Overall length: 5200 mm Neck width: 410 mm Neck height: 220 mm Neck length: 4700 mm Discharge height: 800 mm Total height: 1100 mm Ijdpfx Apswnpngocjia Weight approx. 1200 kg. In good condition.

Condition: like new (used), Year of construction: 2022, operating hours: 1 h, functionality: fully functional, total length: 5,595 mm, total height: 2,031 mm, total width: 680 mm, delivery head: 1,550 mm, ejection height: 1,400 mm, type of input current: three-phase, conveying length: 2,750 mm, input voltage: 380 V, transport height: 450 mm, conveyor belt length: 5,595 mm, input current: 1 A, input frequency: 50 Hz, Deburring conveyor technology for dry operation Type: P-40 Design: Z-shape Chain pitch: 40 mm Conveyor width (standard): 680 mm Container width: 680 mm Loading length: 2,750 mm Ijdpfx Aewvgpkjpcsia Loading height: 240 mm Loading area: 2,750 mm Incline angle: 30° Discharge height: 1,550 mm Discharge height above floor: 1,400 mm Discharge length: 450.0 mm Total conveyor length: 6,157 mm Lifting eyes: Yes Inclined section covered: Yes Loading hopper: Yes Covers in loading area: Smooth sheet steel Discharge chute: Yes Discharge chute height: 150 mm Reach-in protection per EN618: Yes, conveyor CE-compliant Castors: Yes Adjustable feet: Yes Drive: Gear motor Drive position: Right side Brand: SEW Power consumption: 0.25 kW Overload protection via limit switch (slip ring)

Year of construction: 1987, condition: good (used), With a blister! Product: RUEZ Iiodpfx Apjgxqfcjcsa Type: SFWW2 / 306DAU Year of production: 1987 Metal chain width: 200 mm Distance guide lanes: approx. 300 mm Chip outlet length 700/1300 mm Insertion length: approx. 1000 mm Insertion height 260 mm Total length: 3000 mm Transport height - ejection height: 800 mm Belt speed 26 mm / sec. = 1.6 m / min Engine power: 0.25 kW Mains connection was 400, 50 Hz Enclosure size: H x W x D; 1900 x 900 x 1300 mm Weight 300 kg Set of 2 pcs.

Year of construction: 1990, condition: good (used), With a blister! Product: RUEZ Type: SFWW2 / DAS406 Year of production: 1990 Iiedpfx Apsgxqgzscoa Metal chain width: 330 mm Distance guide lanes: approx. 300 mm Chip outlet length 2000/1000 mm Insertion height 260 mm Total length: 3000 mm Transport height - ejection height: 1100 mm

Year of construction: 1999, condition: good (used), Product: BMF Year of production: 1999 Metal chain width: 200 mm Long-distance guide lanes: approx. 300 mm Chip outlet length 900/1250 mm Insertion length: approx. 1000 mm Insertion height 260 mm Insertion width 350 mm Total length: 3600 mm Transport height - ejection height: 800 mm Iiedohq Hz Hjpfx Apcsa Belt speed 26 mm / sec. = 1.6 m / min. Engine power: 0, 25 kW Mains connection was 400 volts, 50 Hz Enclosure size: H x W x D; 8700 x 900 x 1500 mm Weight 400 kg

Condition: used, Chip conveyor, chip elevator, inclined conveyor belt, used machine Manufacturer: Mayfran Type: POO.96M3806.01 Overall dimensions: Width: 6300 mm Iodpfx Aoydbzvjpcsia Depth: 1050 mm Height: 1820 mm Belt size: 6600 × 330 mm Electrical data: 400 V Slat size: 30 mm Slat pitch: 245 mm

Condition: excellent (used), Chip conveyor from the manufacturer MAYFRAN, model 40.6GS-HR/SP20, conveyor belt length 4200 mm, in very good technical and optical condition, labeling of the control buttons can be relabeled in German or English on request. Iijdpewk Igaofx Apcoa
