Used Mair Multihead Tube Cutting Machine Tra3000/7/7/Car ... for sale (88,389)

Condition: used, MULTIHEAD TUBE CUTTING MACHINE MAIR TRA3000/7/7/CAR + RA1 SCOPE OF SUPPLY 1 Loading table with: - Motorised slings loader, to load the complete bundle - Lateral chain transport conveyor, to introduce the tube 1 by 1 - Top support with vertical adjustment (to avoid loading of 2 tubes when working with small diameters) - Length stop and tube loader 2 Cutting machine TRA3000 with: - 7 independent cutting heads - All cutting heads can be lifted independently - Linear guide with scale for positioning of the cutting heads - Centralised tube transport system with production cycle adjustment 3 Single collecting cradle RA1, with: - Independent cradles, to collect the cut tubes - Lateral separators between cradles, to adapt the cradle length to the tube length - Motorised endless slings for soft tube collection. 4 Main electrical cabinet and operator control panel Dkodpfx Aoymax Eekten 5 Safety barriers around the machine & photelectric barriers & emergency line. Note: Safety barriers were installed by owner to have the machine under “safety conformity” TECHNICAL SPECIFICATIONS Manufacturer: MAIR Model: TRA 3000/7/7/CAR +RA1 Yearly maintenance: made by MAIR Spain Max. input tube length: 7000 mm Bundle Loader: 3 Tn Max. loading capacity: 3000 Kg Round tubes (outer Ø): 12-60 mm Square tubes (HxW): 12x12-50x50 mm (see note) Rectangular tubes (HxW): 12x16-60x40 mm (see note) Thickness Min-Max.: 0.8 - 4.0 mm (depending on yield) Cutting lengths: 330-6900 mm Max. straightness tolerance: 1 mm/m Number of cutting heads: 7 Motors power: 2.2 kW Cutting disc diameter: 300 mm Voltage: 380 / 50 V/HZ, 3 phases Compressed air: It must be supplied filtered and lubricated 6 bar Total installed power: Aprox. 21kW – 50Amp Manufacturer: MAIR Model: TRA 3000/7/7/CAR +RA1 Yearly maintenance: made by MAIR Max. input tube length: 7000 mm Bundle Loader: 3 Tn Max. loading capacity: 3000 Kg Round tubes (outer Ø): 12-60 mm Square tubes (HxW): 12x12-50x50 mm (see note) Rectangular tubes (HxW): 12x16-60x40 mm (see note) Thickness Min-Max.: 0.8 - 4.0 mm (depending on yield) Cutting lengths: 330-6900 mm Max. straightness tolerance: 1 mm/m Number of cutting heads: 7 Motors power: 2.2 kW Cutting disc diameter: 300 mm Voltage: 380 / 50 V/HZ, 3 phases Compressed air: It must be supplied filtered and lubricated 6 bar Total installed power: Aprox. 21kW – 50Amp

Condition: used, MULTIHEAD TUBE CUTTING MACHINE MAIR TRA3000/7/8 Dkedpfx Asymaw Uoktjn Scope of supply: 1 Loading table with: - Motorised slings loader, to load the complete bundle - Lateral chain transport conveyor, to introduce the tube 1 by 1 - Top support with vertical adjustment (to avoid loading of 2 tubes when working with small diameters) - Length stop and tube loader 2 Cutting machine TRA3000 with: - 7 independent cutting heads - All cutting heads can be lifted independently - Linear guide with scale for positioning of the cutting heads - Centralised tube transport system with production cycle adjustment 3 Double collecting cradle RA3, with: - Independent cradles, to collect the cut tubes - Lateral separators between cradles, to adapt the cradle length to the tube length - Motorised endless slings for soft tube collection. Note: with the double craddle system, it is possible to make the bundling and strapping in collecting craddle nº1, while production continues, without machine stop. 4 Main electrical cabinet and operator control panel NOTE:  This machine has worked very few hours.  Mechanical condition is very good.  It only requires cleaning & repainting to be “as new” Max. input tube length: 8000 mm Bundle Loader: 3 Tn Max. loading capacity: 3000 Kg Round tubes (outer Ø): 12-60 mm Square tubes (HxW): 12x12-40x40 mm Rectangular tubes (HxW): 12x16-50x30 mm Thickness Min.-Max.: 0.8 - 3.0 mm (depending on yield) Cutting lengths: 330 - 7900 mm Max. straightness tolerance: 1 mm/m Number of cutting heads: 8 Motors power: 2.2 kW Cutting disc diameter: 300 mm

Condition: used, Multihead cutting machine TRA2000/7/7, made by MAIR Including: Dkodpfsymaypjx Aktjn 1) Loading table 2) Cutting machine with 7 cutting heads 3) Operator control panel 4) Unloading bin Optional to be build new upon requirement : 5) Double output craddle 6) New electrical control panel with frequency converters for cutting motors 7) Sound and safety protection cover Max. tube length: 7.500 mm Max. loading capacity: 2.000 kg Round tubes (outer ø): 12 – 50 mm Square tubes (hxw): 12×12 – 40×40 mm Rectangular tubes (hxw): 12×16 – 50×30 mm Max. thickness: 2,5 mm Length of tubes to be cut: 330 – 7.400 mm Number of cutting heads: 7

Year of construction: 2019, condition: used, Automatic high-precision tube cutting machine TS72, made by ADIGE Cuts round, square, rectangular, and flat-oval tubes up to 102 mm in diameter. Efficient production: - Program up to 4 different cut lengths per tube - Continuous measurement changes for small batches Organized unloading: - Program up to 3 different unloading positions plus a scrap container. Non-Stop unmanned production: - Automatic production changes without tools. - High-capacity bundle loader holds up to 4000 kg of material. Superior Cutting Quality: High precision, efficiency, and versatility for tube cutting - Independently operated hydraulic material clamps ensure precise clamping and high cut accuracy. - Blade and clamps detach during return movement to prevent wear. TECHINCAL DATA Dodpfx Akeymangetskn Working range - Round tube cutting: from 8 to 102 mm - Square tube cutting: from 10x10 to 80x80 mm - Bar cutting: Up to 40 mm - Cutting length: From 20 mm to 3.000 mm Loading - Loading from bundle: Fully automatic - Unloading positions: 3 + 1 (scrap) Tools - Cutting blade diameter: From 200 to 350 mm General - Total installed power: 20 kW Round tube cutting: from 8 to 102 mm Square tube cutting: from 10x10 to 80x80 mm Bar cutting: Up to 40 mm Cutting length: From 20 mm to 3.000 mm Loading from bundle: Fully automatic Unloading positions: 3 + 1 (scrap) Cutting blade diameter: From 200 to 350 mm Total installed power: 20 kW

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: automatic, actuation type: electric, laser type: fiber laser, laser power: 12,000 W, sheet thickness (max.): 30 mm, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Supports 12m steel pipe cutting Equipped with fully automatic combined loading and unloading system One-stop intelligent loading, cutting and unloading, increasing production efficiency by 200% Supports multiple processes such as beveling, locking, cutting, punching, opening welding holes, cutting bolt holes, marking and marking Laser power 12,000 W – 20,000 W X-axis travel 1,600 mm Y-axis travel 1,900 mm Z-axis travel 900 mm A-axis rotation ±90° C-axis rotation ±90° Dodpfx Aksw A H T Astskn U-axis travel 30 mm V-axis travel 13,000 mm Positioning accuracy ±0.1 mm Max. workpiece section 1,000 × 400 mm Max. supported weight 5 T Supported profiles H-beam, channel steel, I-beam

Condition: new, functionality: fully functional, Year of construction: 2025, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Series: NS-HG Type: Heavy pipe machine Beveling function: Optional Power range: Round pipe processing: 50mm~560mm Square pipe processing 50mm~560mm Chuck maximum 30r/min Machine weight: 29t Power specification: 380VAC, 50Hz Optional loading rack: Three-chuck chain automatic loading rack Optional unloading rack: Three-chuck chain automatic unloading rack Dksdpfsww Upzox Aktsn Standard: System 5000A, including nesting, supports servo (beveling) Zero tail material rear card hollow dust removal Optional: Weld detection, safety fence (light curtain), radiation-proof glass

Condition: new, functionality: fully functional, Year of construction: 2025, control type: CNC control, laser type: fiber laser, laser power: 3,000 W, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Type: Two chucks Groove function: Standard Power range: 3KW, 6KW Round tube processing range: 10mm~160mm Square tube processing range: 10mm~160mm Chuck maximum speed: 130r/min Machine weight: 3T Power specification: 380VAC, 50Hz Optional loading rack: G16pro-automatic loading, G16pro-semi-automatic loading Dsdpfxewwz Dlo Aktokn Optional unloading rack: servo unloading rack, cylinder unloading rack Standard: System 3000DE-DH, including nesting, supports servo, dustproof (Y axis), dustproof (X axis), dustproof (Z axis), rear card hollow dust removal, short tail material Optional: safety fence (light curtain), radiation-proof glass

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: semi-automatic, actuation type: hydraulic, controller manufacturer: SIEMENS, laser type: fiber laser, laser source manufacturer: MAX Photonics, laser source model: CE, laser power: 3,000 W, sheet thickness (max.): 8 mm, sheet thickness steel (max.): 8 mm, sheet thickness stainless steel (max.): 6 mm, sheet thickness aluminum (max.): 6 mm, sheet thickness brass (max.): 6 mm, sheet thickness copper (max.): 6 mm, pipe diameter (max.): 260 mm, pipe length (max.): 6,050 mm, table length: 6,050 mm, working length: 6,000 mm, power: 3,000 kW (4,078.86 HP), input current: 32 A, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, Equipment: CE marking, centralized greasing system, cooling unit, dust extraction, emergency stop, fume extraction, safety light barrier, ACME LT-6026TFA Tube Laser System – Maximum Productivity for Tube Processing The ACME LT-6026TFA is a powerful tube and profile laser system for companies that require the highest precision, high processing speeds, and maximum automation in tube processing. Thanks to state-of-the-art fiber laser technology and automatic loading and unloading, the system is ideally suited for series manufacturers, metal fabricators, mechanical engineers, and industrial tube processors. Your advantages at a glance ✔ Fully automatic tube processing for maximum efficiency ✔ Suitable for round, square, rectangular, and special profiles ✔ High cutting quality with minimal post-processing effort ✔ Automatic loading and unloading system for short cycle times Dkodpozb Um Tofx Akten ✔ Powerful fiber laser technology for economical cutting ✔ High positioning and repeatability accuracy ✔ Intelligent clamping technology for safe material transport ✔ Optimized for series production and high utilization Technical highlights Tube lengths up to 6,000 mm Tube diameters up to 260 mm Powerful 3 kW fiber laser Automatic loading and unloading system Precise machining of complex contours and holes Fast changeover times for different tube geometries Modern CNC control system with intuitive operation For which applications is the LT-6026TFA suitable? The system is the ideal solution for: Steel construction Metal construction Mechanical engineering Vehicle construction Furniture industry Agricultural machinery construction Contract manufacturing Tube and profile processing By combining high cutting performance, automated material handling, and reliable process safety, the ACME LT-6026TFA significantly increases productivity while reducing manufacturing costs. Why a tube laser system from ACME? The LT-6026TFA impresses with its robust machine construction, high availability, and economical production. Companies benefit from short cycle times, precise cutting results, and a future-proof automation solution for modern tube processing. Laser Handels und Service GmbH Your partner for tube lasers, flatbed lasers, laser welding technology, spare parts, and service. Consulting, installation, training, and technical support from Germany.

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: semi-automatic, laser source manufacturer: Max Photonics, laser power: 3,000 W, sheet thickness (max.): 12 mm, sheet thickness steel (max.): 12 mm, sheet thickness stainless steel (max.): 8 mm, sheet thickness aluminum (max.): 8 mm, sheet thickness brass (max.): 2 mm, sheet thickness copper (max.): 2 mm, pipe diameter (max.): 250 mm, pipe length (max.): 6,000 mm, # ACME Tube & Profile Laser System – Year of Construction 2026 ## Highest Precision. Maximum Productivity. Future-Proof Manufacturing. Invest in state-of-the-art tube and profile processing technology and sustainably increase your competitiveness. The new ACME Tube & Profile Laser System (year of construction 2026) was developed specifically for demanding industrial applications and impresses with its highest precision, high dynamics, and maximum efficiency. Thanks to the innovative machine concept with vertically arranged guides, the system combines a particularly compact design with high stability and exceptional cutting accuracy. The result is optimal processing results with minimal space requirements. --- ## Technical Highlights * Tube and profile processing up to Ø 250 mm or 250 x 250 mm * Modern 2-chuck clamping system for precise workpiece guidance * High-dynamic servo drive technology * Vertical guide structure for maximum stability * Fully automatic central lubrication * CE-compliant design according to current European safety standards * Powerful fiber laser for the highest cutting quality * Semi-automatic loading system for efficient material feed --- ## Available as an option * 45° laser head for weld preparation, miter cuts, and complex contours * Extended automation solutions * Various laser powers depending on the application area * Individual material handling systems --- ## Your advantages at a glance ✔ Precise processing of tubes and profiles of various geometries ✔ High productivity thanks to fast positioning and cutting speeds ✔ Reduced downtime due to semi-automatic loading ✔ Space-saving machine design ✔ Low maintenance effort thanks to automatic central lubrication ✔ High process reliability and dependable continuous operation ✔ Easy operation and short training times ✔ German-speaking service and professional online support ✔ Fast supply of spare parts and technical support from our own service team --- ## Areas of application * Steel construction * Metal construction * Machine and plant engineering * Railing and stair construction * Vehicle and commercial vehicle construction * Job manufacturing * Tube and profile processing Dkjdpfxozb Itaj Aktjn --- ## Availability Condition: New Year of construction: 2026 Delivery time: approx. 3 months after order placement --- ## Inspection and demonstration Convince yourself of the performance of the ACME Tube & Profile Laser System. An inspection or demonstration at one of our reference customers is possible at any time after prior arrangement. We will gladly prepare an individual offer for you and advise you on the selection of the optimal configuration for your production. ACME Tube & Profile Laser Systems – Produce efficiently. Cut precisely. Secure the future.

Condition: new, functionality: fully functional, Year of construction: 2026, control type: PLC-controlled, degree of automation: semi-automatic, actuation type: electric, laser type: fiber laser, laser source manufacturer: Max Photonics, laser power: 6,000 W, sheet thickness (max.): 15 mm, pipe diameter (max.): 240 mm, pipe length (max.): 6,050 mm, working length: 6,050 mm, working width: 240 mm, working height: 240 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 6,800 mm, travel distance Z-axis: 250 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 100 m/min, feed rate Z-axis: 60 m/min, positioning accuracy: 0.05 mm, repeat accuracy: 0.03 mm, workpiece weight (max.): 300 kg, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, compressed air connection: 8 bar, total length: 16,000 mm, total width: 4,470 mm, total height: 2,450 mm, warranty duration: 12 months, Equipment: CE marking, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, # Tube Laser LT6025G – High-Performance Tube Laser Cutting System with 3-Chuck Technology and Zero-Tailing System ## Precise Tube and Profile Processing at the Highest Level The LT6025G tube laser cutting system was developed for economical and highly precise processing of tubes and profiles. Thanks to state-of-the-art 3-chuck technology, powerful servo drives and an intelligent zero-tailing function, the system enables maximum material utilization while simultaneously ensuring the highest cutting quality. The machine is ideally suited for steel construction, metal construction, mechanical engineering, plant engineering, as well as for job shops and series manufacturers with the highest requirements for productivity and precision. --- ## Technical Data * Model: LT6025G * Tube Length: up to 6,000 mm * Tube Diameter: approx. Ø 10 – 250 mm * Clamping System: 3 fully automatic pneumatic chucks * Acceleration: up to 1.2 G * Positioning Accuracy: ± 0.05 mm / 1,000 mm * Repeatability: ± 0.03 mm / 1,000 mm * Cutting Gases: Oxygen, Nitrogen, Compressed Air * Drive System: High-dynamic Servo Drive Technology * Automatic Central Lubrication * Professional Tube Nesting Software * Robust Machine Construction for Continuous Industrial Use --- ## Processable Materials and Profiles The LT6025G processes a wide variety of tube and profile shapes: * Round Tubes * Square Tubes * Rectangular Tubes * Oval Tubes * Angle Steel * U-Profiles * Channel Profiles * Open Profiles * Special Profiles Dksdpozb Irvefx Aktjn --- ## Zero-Tailing Technology The innovative zero-tailing system reduces the unavoidable scrap section to a minimum, thereby significantly increasing material utilization. This is particularly advantageous with high-priced materials, resulting in a noticeable reduction in production costs and sustainably improving profitability. --- ## Your Advantages at a Glance ✔ Modern 3-chuck clamping system for maximum precision ✔ Minimized material waste thanks to zero-tailing technology ✔ High dynamics and productivity through 1.2 G acceleration ✔ Excellent cutting quality and clean cut edges ✔ Precise drilling, contours and cutouts in a single operation ✔ Fast changeover for different profile shapes ✔ Reduction of rework and grinding effort ✔ High process reliability in series production ✔ Suitable for single-part, small-batch and large-batch production ✔ Economical production with high flexibility --- ## Typical Applications * Steel Construction * Metal Construction * Mechanical Engineering * Plant Engineering * Vehicle Construction * Commercial Vehicle Construction * Furniture and Profile Manufacturing * Job Shop Manufacturing * Tube Processing --- ## Inspection and Demonstration An inspection of the system and a test run with your components are possible at any time by prior appointment. We will gladly provide you with further technical documentation, videos, sample parts or an individual offer.

Condition: new, functionality: fully functional, Year of construction: 2026, laser type: fiber laser, laser source model: Max Photonics, laser power: 12,000 W, sheet thickness (max.): 30 mm, sheet thickness steel (max.): 30 mm, sheet thickness stainless steel (max.): 25 mm, sheet thickness aluminum (max.): 25 mm, sheet thickness brass (max.): 5 mm, sheet thickness copper (max.): 5 mm, pipe diameter (max.): 550 mm, pipe length (max.): 12,000 mm, warranty duration: 12 months, Equipment: CE marking, centralized greasing system, cooling unit, dust extraction, emergency stop, fume extraction, safety light barrier, Maximum performance for modern tube and profile processing Dodpfx Akszb Irpotskn The ACME tube and profile laser system was developed for the highest demands in industrial manufacturing and combines precision, productivity, and flexibility at the highest level. Thanks to its powerful design and intelligent automation, it is ideally suited for steel construction, mechanical engineering, plant engineering, metal processing, and demanding job-shop operations. The innovative machine concept with four high-precision chucks, three movable clamping systems, and vertically arranged guides ensures exceptionally stable workpiece guidance. This allows even long, heavy, or complex tube and profile geometries to be processed with the highest accuracy. The system is available in various versions for tube diameters of Ø 280 mm, Ø 360 mm, Ø 550 mm, Ø 640 mm, and Ø 800 mm and can be optimally adapted to individual production requirements. With available laser powers from 3 kW to 20 kW and processing lengths of up to 12 meters, the ACME tube laser system offers maximum performance reserves for a wide range of applications – from thin-walled profiles to heavy structural tubes. Your advantages at a glance ✔ Four high-precision chucks for maximum processing accuracy ✔ Three movable clamping systems for optimal workpiece guidance ✔ Vertical guide structure for maximum stability and dynamics ✔ Tube diameters up to Ø 800 mm available ✔ Processing lengths up to 12,000 mm ✔ Laser powers of 3 kW, 6 kW, 12 kW and up to 20 kW ✔ Innovative 45° laser head for weld preparation and complex contours ✔ Semi-automatic loading and unloading for efficient production processes ✔ Integrated small parts conveyor for automatic parts removal ✔ High process reliability thanks to high-quality brand-name components ✔ Full CE compliance according to European safety standards ✔ German-speaking service and professional online support Technical highlights Powerful tube processing Tube diameter: Ø 280 mm to Ø 800 mm Processing length: up to 12,000 mm Four-chuck technology Remainder optimization through intelligent clamping technology High dynamics with maximum positioning accuracy Advanced cutting technology Laser powers from 3 kW to 20 kW Precise contour and miter cuts 45° laser head for weld preparation Optimal cut quality for a wide range of materials Automation for maximum productivity Semi-automatic loading and unloading system Automatic small parts disposal via conveyor Reduced downtime Higher output with less personnel Typical application areas Steel and hall construction Mechanical and plant engineering Metal and tube processing Vehicle and commercial vehicle construction Agricultural technology Facade and railing construction Furniture and profile manufacturing Job-shop operations Quality and safety The ACME tube and profile laser system meets all relevant European safety requirements and is delivered CE-compliant. High-quality components from leading manufacturers ensure a long service life, high availability, and maximum investment security. ACME tube and profile laser system More performance. More precision. More possibilities. The intelligent solution for economical and highly productive tube and profile processing in modern manufacturing.

Condition: used, Year of construction: 1997, Fully automatic index cutting machine Equipped with: Feeding Opening Counting/cutting 1 Counting/cutting 2 Printing station 1. colour Printing station 2. colour Delivery Technical data: Max. size: 185 x 130 mm Min. size: 50 x 60 mm Book thickness max. 15 mm (depending on product) Binding category: all standard binding sorts Cover bendable (no hardcover) Cut form angular cut Types Printing European/Arabic index combined indexes double and multiple indexes Printing: one or two colours letters and words Dedpfx Aksy Syuljtskn Dürrer promotional/explanatory video:

Condition: as good as new (ex-display), Year of construction: 2024, operating hours: 24 h, Make: DURMA Type: HD-TC 60170 Fiber Year of construction: 2024 Automatic loading unit 6000 mm Unloading system 4000 mm Dksdpsdx Nfwsfx Aktsn Laser power: 2000 Watt Control: Siemens Sinumerik 840D Operating hours: 24 h Max. pipe diameter: 170 mm Min. pipe diameter: 20 mm (12 optional) Max. Square profile dimensions: 120x120 mm Max. Dimensions of rectangular profiles: 150x100 mm Max. Profile length: 6500 mm Min. profile length: (for automatic feed) 3000 mm Max. Profile weight: 37.5 kg/m Max. Material thickness: (for 2 kW) 8 mm Min. material thickness: 0.8 mm Length of the last inserted part: 185 mm Positioning accuracy: +/- 0.20 mm Repeat accuracy: +/- 0.05 mm Max. Loading capacity: 3000 kg Profile types: round, square, rectangular, elliptical H,C,U,L *Installation area L/W/H: approx. 16000x7400x2350 mm * Weight: approx. 20000 kg * depending on equipment variant Standard equipment Sinumerik 840D control system Autofocusing PRECITEC Procutter cutting head F150 focus Manual unloading table Manual loading Laser diode for defining position points Central lubrication Chip conveyor External user interface for the output of analog values (power-speed-pressure) External CAD/CAM programming software Lantec with autonesting Work area lighting Warning light Various laser cutting options selectable Remote control: remote maintenance access via LAN connection or WLAN CE marking Extended equipment IPG fiber laser source 2000 Watt (incl. cooler) Automatic loading unit 6000 mm Unloading table 4000 mm Filter, compact dust extraction - Vanterm The machine can be viewed and demonstrated at any time by appointment at our demonstration center in Staufenberg. Further machines are available for demonstration in Staufenberg. We will be happy to send you further information on request.

Condition: as good as new (ex-display), Year of construction: 2024, Make: DURMA Type: HD-TC 60170 Fiber Year of construction: 2024 Automatic loading unit 6000 mm Unloading system 4000 mm Laser power: 2000 Watt Control: Siemens Sinumerik 840D Operating hours: 24 h Max. pipe diameter: 170 mm Min. pipe diameter: 20 mm (12 optional) Max. Square profile dimensions: 120x120 mm Max. Dimensions of rectangular profiles: 150x100 mm Max. Profile length: 6500 mm Min. profile length: (for automatic feed) 3000 mm Max. Profile weight: 37.5 kg/m Max. Material thickness: (for 2 kW) 8 mm Dksdpfxjd Tt Atj Akten Min. material thickness: 0.8 mm Length of the last inserted part: 185 mm Positioning accuracy: +/- 0.20 mm Repeat accuracy: +/- 0.05 mm Max. Loading capacity: 3000 kg Profile types: round, square, rectangular, elliptical H,C,U,L *Installation area L/W/H: approx. 16000x7400x2350 mm * Weight: approx. 20000 kg * depending on equipment variant Standard equipment Sinumerik 840D control system Autofocusing PRECITEC Procutter cutting head F150 focus Manual unloading table Manual loading Laser diode for defining position points Central lubrication Chip conveyor External user interface for the output of analog values (power-speed-pressure) External CAD/CAM programming software Lantec with autonesting Work area lighting Warning light Various laser cutting options selectable Remote control: remote maintenance access via LAN connection or WLAN CE marking Extended equipment IPG fiber laser source 2000 Watt (incl. cooler) Automatic loading unit 6000 mm Unloading table 4000 mm Filter, compact dust extraction - Vanterm The machine can be viewed and demonstrated at any time by appointment at our demonstration center in Staufenberg. Further machines are available for demonstration in Staufenberg. We will be happy to send you further information on request.

Condition: new, Year of construction: 2024, The Durma HD-TC 60220 pipe laser stands for maximum precision and efficiency in the processing of pipe materials. With its impressive maximum pipe diameter of Ø220 mm and the ability to cut both square profiles of 160 x 160 mm and rectangular profiles of 200 x 100 mm, this pipe laser offers exceptional flexibility for a wide range of applications. Thanks to the advanced automatic loading system, which can handle tubes up to Ø170 mm in diameter, and the ability to process materials up to 6500 mm in length, the HD-TC 60220 is ideal for projects that require fast production with consistently high quality. The minimum material length for automatic loading is 3000 mm, which further increases the efficiency of the machine and reduces processing time. Max. Tube diameter: Ø220 mm Laser power: 3 kW Max. Dimensions of the square profile: 160 x 160 mm Max. Dimensions of the rectangular profile: 200 x 100 mm Min. pipe diameter: 20 mm (12 mm with manual loading) Max. Tube diameter for automatic loading: Ø170 mm Max. Profile dimensions for automatic loading: 150 x 100 mm, 120 x 120 mm Max. Material length: 6500 mm Min. material length for automatic loading: 3000 mm Length of the last piece: 4000 / 6000 mm Unloading length: 150 mm Max. Material weight per meter: 52 kg/m Max. Material weight (total length): 340 kg Max. Loaded weight: 3000 kg Profile types: Round, Square, Rectangular, Elliptical Dkjdpfx Aksq Tpkyotjn Types of open profiles: L, U

Condition: new, Year of construction: 2025, Model: K110 K230 K360 Working Area: from 8649×1398×1811mm to 10000×3500×2100mm Laser Output Power: 3000w/2000w/1500w/1000w X/Y-axis positioning accuracy: 0.05mm X/Y-axis repositioning accuracy: 0.03mm X/Y-axis Max. linkage speed: 60m/min 1. Integrated full protection cover Integrated full protection cover design, installing in place, greatly reducing installation time. 2. Bodor Genius T needle nose auto-focusing laser head Bodor Genius T needle nose auto-focusing laser head, applicable for all kinds of tubes such as angle steel, channel steel, I-beam, etc. 3. Rectangular Tube Welded Bed Simple structure and flexible layout. 4. Bodor Thinker 3.0 System The dedicated control system of tube cutting machine integrated with the most advanced technology, can cut angle steel and channel steel directly without nesting and returning home. 5. Applicable to smaller clamping diameter The rear jaws can clamp the pipe to go through the front chuck, which greatly shortens the physical distance between the cutting head and the rear chuck jaws. Tail length is reduced to 70mm and the material utilization rate is increased to 99%. 6. Ergonomics Dodpfog Rgt Ujx Aktokn Loading and operating on both sides; and humanized interaction interface, convenient and smooth operation, and favorable user experience. 7. Integrated design Integrated design of electric control cabinet and main body, saving the space occupied, standardizing the line installation.

Condition: new, functionality: fully functional, Year of construction: 2026, control type: PLC-controlled, degree of automation: semi-automatic, actuation type: electric, controller manufacturer: Siemens, laser source manufacturer: Max Photonics, laser source model: Max Photonics 6kW mit CE, laser power: 6,000 W, sheet thickness (max.): 10 mm, sheet thickness steel (max.): 10 mm, sheet thickness stainless steel (max.): 8 mm, sheet thickness aluminum (max.): 6 mm, sheet thickness brass (max.): 6 mm, sheet thickness copper (max.): 6 mm, pipe diameter (max.): 240 mm, pipe length (max.): 6,050 mm, working length: 8,050 mm, working width: 250 mm, working height: 250 mm, travel distance X-axis: 400 mm, travel distance Y-axis: 6,500 mm, travel distance Z-axis: 280 mm, feed rate X-axis: 116 m/min, feed rate Y-axis: 131 m/min, feed rate Z-axis: 30 m/min, positioning accuracy: 0.03 mm, repeat accuracy: 0.05 mm, workpiece weight (max.): 100 kg, power: 6,000 kW (8,157.72 HP), input voltage: 380 V, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, compressed air connection: 8 bar, overall weight: 5,000 kg, total length: 12,500 mm, total width: 2,400 mm, total height: 2,550 mm, warranty duration: 12 months, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, With a fully redesigned machine concept, it unites maximum stability, highest efficiency, precise processing, and intelligent automation in one system. This makes it optimally suited for processing a wide variety of metal tubes and profiles – flexible, reliable, and powerful. A patented, innovative design combined with an exclusive automatic loading and unloading system significantly boosts productivity. The system operates faster, more stably, and more intelligently, and is available in different configurations to suit your individual requirements. Thanks to enhanced dynamics and increased performance, the machine delivers outstanding results across all processing operations – whether cutting, drilling, or complex contour cutting. The cutting quality is of the highest standard: smooth surfaces, minimal thermal impact, and virtually no residue or rework required. Numerous patented core technologies ensure consistently high processing accuracy and perfect results – even in demanding continuous operation. Even after many years of intensive use, the system’s performance remains at an exceptionally high level. This makes your investment a sustainable, future-proof solution for your production. Cutting power: 6000W Laser source: MAX Photonics Laser head: BOCI Autofocus Dodpfxey R I R Ej Aktjkn Max. tube length: 6500mm Tube diameter: 240mm Acceleration: 1.2G

Condition: new, functionality: fully functional, Year of construction: 2026, control type: PLC-controlled, degree of automation: semi-automatic, actuation type: electric, controller manufacturer: Siemens, laser source manufacturer: Max Photonics, laser source model: Max Photonics 3kW mit CE, laser power: 3,000 W, sheet thickness (max.): 8 mm, sheet thickness steel (max.): 8 mm, sheet thickness stainless steel (max.): 6 mm, sheet thickness aluminum (max.): 4 mm, sheet thickness brass (max.): 4 mm, sheet thickness copper (max.): 4 mm, pipe diameter (max.): 240 mm, pipe length (max.): 6,050 mm, working length: 8,050 mm, working width: 250 mm, working height: 250 mm, travel distance X-axis: 400 mm, travel distance Y-axis: 6,500 mm, travel distance Z-axis: 280 mm, feed rate X-axis: 116 m/min, feed rate Y-axis: 131 m/min, feed rate Z-axis: 30 m/min, positioning accuracy: 0.03 mm, repeat accuracy: 0.05 mm, workpiece weight (max.): 100 kg, power: 3,000 kW (4,078.86 HP), input voltage: 380 V, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, compressed air connection: 8 bar, overall weight: 5,000 kg, total length: 12,500 mm, total width: 2,400 mm, total height: 2,550 mm, warranty duration: 12 months, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, With a completely redesigned machine concept, it combines maximum stability, highest efficiency, precise processing, and intelligent automation in a single system. It is optimally suited for processing a wide range of metal tubes and profiles—flexible, reliable, and powerful. A patented, innovative design combined with an exclusive automatic loading and unloading system ensures a significant increase in productivity. The system operates faster, more stably, and more intelligently and is available in various configurations to precisely match your individual requirements. Thanks to improved dynamics and increased performance, the machine delivers outstanding results across all processing operations—whether cutting, drilling, or complex contour cutting. The cutting quality is of the highest standard: smooth surfaces, minimal thermal impact, and virtually no residues or reworking required. Dsdpfx Asy R I Rxektjkn Numerous patented core technologies guarantee consistently high machining accuracy and perfect results—even during demanding continuous operation. Even after many years of intensive use, the system’s performance remains at an exceptionally high level, making it a sustainable, future-proof investment for your production. Cutting power: 3000 W Laser source: MAX Photonics Laser head: BOCI Autofocus Maximum tube length: 6500 mm Tube diameter: 240 mm Acceleration: 1.2G

Condition: new, functionality: fully functional, Year of construction: 2026, control type: PLC-controlled, degree of automation: semi-automatic, actuation type: electric, laser type: fiber laser, laser source manufacturer: Max Photonics, laser power: 6,000 W, sheet thickness (max.): 15 mm, pipe diameter (max.): 240 mm, pipe length (max.): 6,050 mm, working length: 6,050 mm, working width: 240 mm, working height: 240 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 6,800 mm, travel distance Z-axis: 250 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 100 m/min, feed rate Z-axis: 60 m/min, positioning accuracy: 0.05 mm, repeat accuracy: 0.03 mm, workpiece weight (max.): 300 kg, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, compressed air connection: 8 bar, total length: 16,000 mm, total width: 4,470 mm, total height: 2,450 mm, warranty duration: 12 months, Equipment: CE marking, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, Tube Laser LT6025G – High-Performance 3-Chuck Tube Laser with Zero-Tailing Technology For sale is a modern tube laser model LT6025G featuring a powerful 3-chuck system for highly precise and efficient cutting of tubes and profiles. This machine is ideally suited for metal fabricators, steel construction, contract manufacturers, mechanical engineering, and series production. The tube laser quickly and accurately processes round tubes, square tubes, rectangular tubes, oval tubes, as well as special profiles such as angle steel, U-profiles, or open profiles. The zero-tailing function minimizes material waste to an absolute minimum. Technical Highlights - 3-chuck tube laser system - Zero-tailing technology - Tube length up to 6,000 mm - Tube diameter approx. Ø10 – Ø250 mm Dkodpfx Aoy Rxunjktjn - High dynamics up to 1.2G acceleration - Positioning accuracy ±0.05 mm / 1000 mm - Repeatability ±0.03 mm / 1000 mm - Automatic pneumatic chucks - Capable of cutting round, square, rectangular, and special profiles - Supports angle steel, channel steel, and custom profiles - Professional tube nesting software - Automatic lubrication - High-performance fiber laser - Cutting gases: oxygen / nitrogen / compressed air - Industrial servo drive technology - Very stable steel construction Machine Advantages - Extremely economical operation thanks to minimal offcuts - High cutting speed and clean cut quality - Ideal for series production and flexible custom fabrication - Quick setup for different profiles - Precise drilling, notching, and contouring capabilities - Reduced reworking and grinding efforts - High process reliability The machine impresses with its robust design, high dynamics, and versatile applications in tube processing. Inspection and test runs possible by appointment. If interested, we will be happy to send you further technical details, videos, or a quotation.

Condition: good (used), functionality: fully functional, Year of construction: 2003, laser type: CO₂ laser, laser power: 2,700 W, X working area max.: 6500 mm Laser power: 2700 watts Control: SINUMERIK 840D Standard equipment TRUMPF loading unit: - Tube feeder for round, square, and rectangular tubes via buffer section with X-stop for tube lengths min. 3 m and max. 6 m - Semi-finished product length measurement - Transfer unit to the machine - Tube magazine with tube separation, alignment, and transfer to tube feeder, max. bundle weight 4000 kg - Good parts removal up to max. 3,000 mm with chip conveyor - Additional tube supports - Tube handling unit: Rotating and feed station: Rotating clamping unit with pneumatically actuated clamping jaws for tube lengths up to 6000 mm and tube diameters of d = 20 - 150 mm, 2 clamping ranges: d = 20 - 85 mm and d = 85 - 150 mm - Carriage unit with linear guidance - Feed station with motor drive, including connection for extraction - Tube support: Between tube support and traverse chuck, five automatically retractable support elements with form shells are provided - Traverse chuck: With a passage of d = 150 mm - The tubes are positioned via the clamping jaws centrally in the Y and Z axes relative to the rotational axis for the cutting process - 2 sets of clamping jaws for round, square, and rectangular tubes (simple design), clamping range 20 - 85 mm, 85 - 150 mm - Good part removal (unloading cabin for round and rectangular tubes) - Sorting options: 2 finished parts (front and rear), 1 flat - Scrap conveyor; programmable sorting; max. scrap length 300 mm (collection container, scrap belt) - Finished part length up to 3000 mm can be automatically unloaded (front and rear) Safety equipment: - Compact extraction unit Filter system designed for the separation of airborne particles produced during laser cutting of metals - Light barrier: Loading area secured by light barriers - Protective cabin: In the area of the cutting head, a Macrolon sheet metal Dedpfxoy Sanrs Aktskn combination is installed for laser radiation protection - Chip conveyor: Conveyor belt for discharging cut remnants - Operating manual

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: semi-automatic, actuation type: electric, controller manufacturer: Bodor, laser type: fiber laser, laser source manufacturer: Bodor, Effective Tube Cutting Length: 6500mm/9200mm Laser Output Power: 6000w/3000w/2000w/1500w Effective Round Tube Cutting Diameter: Φ20-230mm Effective Square Tube Cutting Diameter: □20*20-□160*160mm Edge Length: 20-170mm Outer Circle Diameter: ≤230mm Certification: CCC, CE, GS, ISO, Sgs Laser Source Brand: IPG/MAX Warranty: 3 years Power supply: 110V/220V/380V 50Hz/60Hz 1.Bigger than Bigger The maximum cutting diameter of T series is 30%longer than the mainstream products in the market ; The maximum cutting weight is 100% heavier than the mainstream products in the market. 2.Chuck position control, torque control function The position control CNC self-centering chuck with independent intellectual property rights can automatically clamp material according to the input tube size; Position monitoring in torque mode to ensure that the thick tube is not loosened and the small tube is not deformed;Brand new dust-proof structure, long-lasting use without lagging. 3.Edge-seeking, center-finding Dodpfx Asg Rgucoktekn Brand new function of edge-seeking, center-finding. Optimized edge-finding method and algorithm, higher cutting precision and stability

Condition: new, Year of construction: 2025, Model: C3T Working Area: 3048mm*1524mm Laser Output Power: 6000w/3000w/2000w/1500w Dodpfx Akjg D Nz Rjtekn Positioning accuracy: ±0.05mm Repositioning accuracy: ±0.03mm Max. linkage speed: 100m/min Max. acceleration: 1G 1. Double Fast Exchange Tables Fast exchange of two tables greatly improves efficiency. Chain-drive system has better rigidity and higher accuracy, saving feeding time. 2. Tenon-and-mortise Welded Bed Use Chinese traditional Tenon-and-mortise structure to provide stronger bearing capacity. Solder joint fixing and structural bearing ensure long-standing operation stability. Welded structure improves shock absorption effect, lowering deviation caused by shock, and offering more accurate cutting. 3. Double Automatic Centering Electric Chucks Double electric chucks with automatic centering function are easy to operate and require little maintenance. Brand new motor gives accurate control. Modular chuck components are independently developed and can be quickly replaced. 4. Automatic focusing function of laser head By setting perforation focal length and cutting focal length respectively, the cutting is more accurate. Suitable for multiple focal lengths, and focal position will be automatically adjusted based on thickness of different sheets.

Condition: new, functionality: fully functional, Year of construction: 2025, warranty duration: 60 months, Effective Tube Cutting Length: 6500mm Laser Output Power: 6000w/3000w/2000w/1500w Effective Round Tube Cutting Diameter: Φ20-360mm Effective Square Tube Cutting Diameter: □20*20-□254*254mm Edge Length: 20-300mm Outer Circle Diameter: ≤360mm Certification: CCC, CE, GS, ISO, Sgs Laser Source Brand: IPG/MAX Warranty: 3 years Power supply: 110V/220V/380V 50Hz/60Hz 1.Bigger than Bigger The maximum cutting diameter of T series is 30%longer than the mainstream products in the market ; The maximum cutting weight is 100% heavier than the mainstream products in the market. 2.Chuck position control, torque control function The position control CNC self-centering chuck with independent intellectual property rights can automatically clamp material according to the input tube size; Position monitoring in torque mode to ensure that the thick tube is not loosened and the small tube is not deformed;Brand new dust-proof structure, long-lasting use without lagging. 3.Edge-seeking, center-finding Dkodpfsg D Nziox Akten Brand new function of edge-seeking, center-finding. Optimized edge-finding method and algorithm, higher cutting precision and stability

Condition: new, functionality: fully functional, Year of construction: 2026, laser type: fiber laser, laser source model: Max Photonics, laser power: 12,000 W, sheet thickness (max.): 30 mm, sheet thickness steel (max.): 30 mm, sheet thickness stainless steel (max.): 25 mm, sheet thickness aluminum (max.): 25 mm, sheet thickness brass (max.): 5 mm, sheet thickness copper (max.): 5 mm, pipe diameter (max.): 550 mm, pipe length (max.): 12,000 mm, warranty duration: 12 months, Equipment: CE marking, centralized greasing system, cooling unit, dust extraction, emergency stop, fume extraction, safety light barrier, ACME Tube and Profile Laser System – Precision Meets Performance Dsdpfx Akoy Ix E Ietekn The ACME tube and profile laser system represents maximum efficiency and flexibility for modern tube and profile machining. Equipped with four high-precision chucks, vertically positioned guides, and three movable clamping systems, it ensures stable and precise processing of a variety of workpieces. The system is available with multiple machining diameters (Ø 280 mm, 360 mm, 550 mm, 640 mm, and 800 mm), providing maximum adaptability to diverse production requirements. With selectable laser powers of 3 kW, 6 kW, 12 kW, and up to 20 kW as well as a processing length of up to 12 meters, this machine meets the highest industrial demands. High-quality components from renowned manufacturers guarantee durability and process reliability. Of course, the system is CE-compliant and meets all common safety standards. Efficient production workflows are ensured by semi-automatic loading and unloading, complemented by an integrated small parts conveyor belt. The innovative 45° laser head also enables precise cuts even for complex geometries. ACME – Your solution for high-performance tube and profile laser processing at the highest level.

Condition: new, Year of construction: 2025, Effective Tube Cutting Length: 6500mm/9200mm Laser Output Power: 6000w/3000w/2000w/1500w Effective Round Tube Cutting Diameter: Φ20-230mm Effective Square Tube Cutting Diameter: □20*20-□160*160mm Edge Length: 20-170mm Outer Circle Diameter: ≤230mm Certification: CCC, CE, GS, ISO, Sgs Laser Source Brand: IPG/MAX Warranty: 3 years Power supply: 110V/220V/380V 50Hz/60Hz 1.Bigger than Bigger The maximum cutting diameter of T series is 30%longer than the mainstream products in the market ; The maximum cutting weight is 100% heavier than the mainstream products in the market. Dkodpfx Asg I H Npskten 2.Chuck position control, torque control function The position control CNC self-centering chuck with independent intellectual property rights can automatically clamp material according to the input tube size; Position monitoring in torque mode to ensure that the thick tube is not loosened and the small tube is not deformed;Brand new dust-proof structure, long-lasting use without lagging. 3.Edge-seeking, center-finding Brand new function of edge-seeking, center-finding. Optimized edge-finding method and algorithm, higher cutting precision and stability
