Used Oerlikon-Klingelnberg R30 for sale (592)

Condition: used, Year of construction: 2007, max. wheel diameter 400 mm workpiece dia. 36-300/400 mm axis distance 135-290 mm spindle turning speed - stepless 3000 1/min dist. between centers 100-550 mm Control Siemens 840D weight of the machine ca. 4000 kg dimensions of the machine ca. 2000x3055x2788 mm Test method: - Single flank rolling test - Double flank rolling test - Structure-borne noise test Kedpfey D T Susx Afdjdk - Heli testing in two-flank contact. Features: - Use of up to 6 test slides - Highest testing accuracy and repeatability - Machine table with workpiece drive - Swiveling pneumatic unit - Spray oil lubrication (type: Vogel) - Oil mist extraction (type: Elbaron)

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, wheel diameter: 400 mm, overall weight: 4,000 kg, distance between centers: 550 mm, spindle speed (max.): 3,000 rpm, controller model: Siemens 840 D, TECHNICAL DETAILS Kodpfsywg Hxsx Afdedk Max. wheel diameter: 400 mm Workpiece diameter: 36–400 mm Centre distance: 135–290 mm Max. spindle speeds (infinitely variable): 3,000 rpm Centre width: 100–550 mm MACHINE DETAILS Control: CNC Siemens 840 D Dimensions & Weight Space requirement: approx. 2,000 x 3,055 x 2,788 mm Machine weight: approx. 4,000 kg EQUIPMENT Single-flank rolling test Double-flank rolling test Structure-borne noise testing Helical contact testing (double-flank contact) Use of up to 6 test carriages Highest test accuracy and repeatability Machine table with workpiece drive Swivelling pneumatic unit Spray lubrication (Type: Vogel) Oil mist extraction (Type: Elbaron)

Condition: good (used), Year of construction: 2006, voltage 110 - 230 V frequency 50 - 60 Hz Power connection 0,5 kVA weight 150 kg dimensions of the machine ca. 1,0 x 0,8 x 1,75 m Stick blade profile control unit - Control via PC control with Windows XP operating system - Digital drive amplifiers, linear motors and measuring systems - Fully automatic position determination of the cutting edges and axis position of the stick blade - Measurement of almost all single-part and continuous processes required for spiral bevel gears and hypoid gears - Machine concept designed for the shortest set-up and changeover lines and maximum measuring accuracy Kedpfx Aoymfz Sofdodk - Combination probe for measuring tip and surface measurement - Integrated drawer for accessories - Keyboard integrated in flat drawer - Operating elements and PC protected against unauthorized access with lockable cabinet element

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the Ksdpfxew N S E Ae Afdsdk radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Year of construction: 2002, condition: used, z-travel 200 mm Clamping diameter of the cutter heads max. 550 mm Max. permissible cutter head weight 150 kg Mounting plate diameter for cutter heads 360 mm Mounting cone for cutter heads Nominal diameter 500 mm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m Cutter Head Set-Up- and -Measuring Machine In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Kdodpjy A S U Sefx Afdek Particularly in dry milling, high gear cutting quality and a long service life can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2006, voltage 110 - 230 V frequency range 50 - 60 Hz Power connection 0,5 kVA Kedpjyhq T Aefx Afdjdk Dimensions (HxWxD) 1000 x 800 x 1750 mm weight 150 kg Measuring machine for bar knives. Equipment/accessories: -Measuring tools -Clamping devices -Computer -Monitor -Printer -Cabin -Technical documentation

Condition: used, Year of construction: 2007, max. wheel diameter 500 mm Hypoid adjustment ±70 mm axial cross angle 90 ° Distance Y- 150 - 350 mm Distance Z-axis 120 - 340 mm turning speed range - stepless 0 - 5000 U/min max. torque on the spindle 57 Nm Cone 99,2 mm Pull-in force Tool clamping 23000 N Braking torque max. 93 Nm total connected load 20 kVA total power requirement 15 kW weight of the machine ca. 6 t Kjdpfx Ajukitxsfdjdk dimensions of the machine ca. 2,35 x 2,24 x 2,5 m

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, grinding wheel diameter: 200 mm, workpiece length (max.): 200 mm, TECHNICAL DETAILS Grinding wheel diameter: 100–200 mm Maximum workpiece length: 200 mm MACHINE DETAILS Control: Siemens 840D or equivalent CNC axes: 3–5 axes Drive power: 5–10 kW Coolant tank: 100–200 litres EQUIPMENT Coolant filtration system Universal applicability for different tool types and geometries High flexibility through CNC programming and adaptable clamping devices Process reliability thanks to integrated cooling and filtration system Kodpfxoya Dy Hj Afdjdk Easy maintenance due to modular design and central supply units

Condition: excellent (used), Year of construction: 2007, max. wheel diameter 400 mm weight of the machine ca. 4 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : KLINGELNBERG Single- and double-flank rolling test machine with structure-borne sound testing model R 30 year 2007 _____ Workpiece outer diameter min. / max. 36 / 300 mm Center distance between workpiece and counter wheel 135 - 290 mm Spindle speeds max. 3.000 rpm Drive torque max. up to 2196 rpm 20 Nm Drive torque max. 2196 – 3.000 rpm 14,7 Nm Spindle drive 4,62 kW Total drive approx. 10 kW - 400 V - 50 Hz Total weight approx. 4.000 kg Kdjdpfx Aoxvdryjfdjk Accessories / Special Features: • The machine is a universal rolling tester designed for the following testing procedures: o Single-flank rolling test o Double-flank rolling test o Structure-borne noise testing in single and double-flank contact o Helix testing in double-flank contact • WINDOWS PC control for measurement data acquisition and analysis with the NoisyS32 testing software • SIEMENS control panel for operating the machine and evaluating the test cycles • Complete enclosure with electrically monitored sliding doors • Attached control cabinet, various accessories, operating instructions • Unfortunately, the license dongle for activating the measurement software is currently missing. We hope to receive it from the supplier of the machine. Condition : very good condition ! Almost unused ! Soon : Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection gear machines – CNC or conventional - available. Please let us know your requirements.

Condition: good (used), Year of construction: 2007, max. wheel diameter 500 mm gear width 200-400 mm module 12 Kdsdsvr Hf Eopfx Afdsk turning speeds 0-3250 U/min bracke pressure bis max. 95 Nm inner taper Konus #39 Control Fanuc 16 total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2.350 x 2.240 x 2.500 mm HIGHLY FLEXIBLE TESTING OF HARD, FINISHED AND GREEN SPIRAL BEVEL AND HYPOID GEAR SETS The T 60 bevel gear testing machine is a CNC testing machine with three linear axes for the fully automatic hard and soft testing of spiral bevel and hypoid gear sets with a 90° axis angle. It offers versatile objective and subjective testing options with speeds up to 3,250 min and braking torques up to max. 95 Nm.

Condition: new, Year of construction: 2011, overall weight: 1,250 kg, volume flow: 630 m³/h, power: 15 kW (20.39 HP), type of cooling: water, rotational speed (max.): 2,930 rpm, protection type (IP code): IP5K5, For sale is a new vacuum pump in original packaging: OERLIKON LEYBOLD VACUUM Technical data: Forevacuum pump station with dry-compressing forepump EXTRUVAC III SP630F NOS – New old stock Electric motor, water-cooled With VEGA VEGABAR 52 pressure transmitter With spring-closing valve from AMG-Pesch Manual in German and English Further technical details: see images Kodpfx Aey D Rbmjfdedk

Condition: used, functionality: fully functional, Various used rack cutters / rack milling cutter groups from different manufacturers Manufacturer: Arnold Dold GmbH & Co. KG 24 rack milling cutters available Ksdpfxsytrh Es Afdsdk Module 0.5 – gang milling cutter Module 0.7 – gang milling cutter Module 0.9 – TiN coating Module 1 – 2 pcs available – gang milling cutter Module 1.25 – gang milling cutter Module 1.5 – TiN coating Module 1.75 – gang milling cutter Module 2 – 4-flute – minor damage Module 2 – TiN coating Module 2.5 – 8-flute – minor damage Module 3 – reground Module 3 – 7-flute – minor damage Module 3 – 7-flute – reground – BPIII – Ü Module 3 – TiN coating Module 5 – 4-flute – reground Module 5 – 4-flute – TiN coating Module 6 – 3-flute – TiN coating Module 6 – 3-flute – TiN coating – reground Module 7 – 3-flute – reground Module 8 – 3-flute – reground Module 10 – TiN coating Module 10 – reground – finish cutter Module 12 – TiN coating – finish cutter Module 12 – minor damage Module 13 – finish cutter Module 14 – reground Module 16 – reground Pressure angle: 20° BPII-Ü Bore diameter [mm]: 40; 50 Keyway [mm]: 10; 12 Width [mm]: 32.5; 45.5; 44; 17/21; 16/20; 14/18; 21/25; 18/22; 65/73; 48/57; 31; 66/72; 69/77; 70/78; 60/64; 60/66; 82; 72/80; 82; 40; 39; 47; 52; 56; 64 External Ø [mm]: 169; 140; 141; 200; 150; 198; 195; 199; 197; 201; 200; 219; 192; 191 Manufacturer: Saazor – Wälztechnik ZORN GmbH & Co. KG 7 rack milling cutters available Module 1 – 16-flute – TiN coating – minor damage Module 1.5 – 9-flute gang milling cutter; 9 teeth per row; 2 – tangential milling cutter; 6 – tangential milling cutter Module 10 – TiN coating Pressure angle: 20° DIN 3972 II - Ü or DIN 3972 II Cl. A - Ü Bore diameter [mm]: 40 Keyway [mm]: 10 Width [mm]: 52/60; 55/85; 60/90; 33/40 External Ø [mm]: 176; 200; 198; 199 Manufacturer: Klingelnberg – 6 rack milling cutters available Module 2.5; 2.75; 3.25; 3.75; 4.5 Pressure angle: 20° Bore diameter [mm]: 40 Keyway [mm]: 10 Width [mm]: 30/38; 28/36; 35/42; 39/47; 44/52 External Ø [mm]: 148; 149; 150 All technical data subject to errors and typographical mistakes. Price on request Sale exclusively to EU countries.

Condition: used, functionality: fully functional, load capacity: 2,000 kg, Equipment: foot remote control, 3-axis welding positioner, 2-ton load capacity, in good condition Incl. hand remote control (foot control available on request) Kdjdjyupgzepfx Afdsk Inclination and rotation speed continuously adjustable 0.05 - 1.0 rpm Clamping plate diameter: 1.0 meter Height tilted to center min. approx. 0.7 m, horizontal 0.9 m Height tilted to center max. 1.6 m, horizontal 1.8 m Length 2.2 m, width 1.35 m

Condition: used, Year of construction: 2002, max. wheel diameter 275 mm max. module 6 min. module 1,5 Control SINUMERIK 840 C tooth width 5,5 mm spiral angle min. 0 / max. 60 ° max. number of teeth 120 min. number of teeth 5 ratio of transmission 1:10 min. ratio of transmission 1:1 work piece spindle speed max. 110 U/min blade head turning speeds 20 - 110 U/min total power requirement 100 kW weight of the machine ca. 16,7 t dimensions of the machine ca. 5,20 x 2,30 x 2,40 m Internal deburring device U axis / Q spindle chip conveyor coolant device Electrostatic air purifier ELBARON Kodpfx Asvxwnwjfdsdk no tools No workpiece clamping device

Condition: used, Year of construction: 1991, max. wheel diameter --- mm gear width --- mm max. module --- min. module --- Control --- total power requirement --- kW Kdsdpoya Eqasfx Afdek weight of the machine ca. --- t dimensions of the machine ca. --- m

Condition: used, Year of construction: 1999, Technical details: max. wheel diameter: 5 - 260 mm gear width: 400 mm max. module: 15 min. module: 0,5 gear hobbing diameter - internal: 30 mm max. helix angle: > 85 ° Aussenverz. max. helix angle: > 45° Innenverz. Testing Range vertical: 400 mm dist. between centers: 5 - 600 mm table diameter: 260 mm max. table load: 100 kg speeds: 30 1/min total power requirement: 1,6 kVA weight of the machine ca.: 900 kg Kedpsqvcnnofx Afdsdk dimensions of the machine ca.: 200 x 1300 x 2150 mm CNC Gear Tester in good condition, out of OEM Test Lab. For measuring of spur and helical toothing, additional of rotationally symetric parts as true running, coaxiality, axial runout, etc. with tool changer ( 4 nos.) *

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, wheel diameter: 275 mm, wheel width: 150 mm, travel distance X-axis: 640 mm, travel distance Y-axis: 870 mm, workpiece diameter (max.): 275 mm, TECHNICAL DETAILS Wheel diameter: 275 mm Wheel width: 150 mm Maximum module: 6 Minimum module: 1.5 Workpiece diameter: 275 mm Maximum face width: 5.5 mm Spiral angle: 0 - 60° Number of teeth: 5 - 120 Kdodpfxsywgy So Afdjk Minimum gear ratio: 1:1 Maximum gear ratio: 1:10 Milling Depth Axis (X-Axis) Travel: -25 to 640 mm Max. traverse speed: 6 m/min Workpiece Positioning Axis (Y-Axis) Travel: 870 mm Max. traverse speed: 4.5 m/min Axis Shift (Z-Axis) Travel range: +/- 50 mm Max. traverse speed: 0.657 m/min Generating Rotation Axis (A-Axis) Swivel range: 315° Max. swivel speed: 40°/s Workpiece Spindle (B-Axis) Max. workpiece spindle speed: 300 rpm Outer cone (1:4) clamping diameter: 140 mm Inner cone (1:20): 99.218 mm Workpiece spindle bore: 90 mm Workpiece Swivel Axis (C-Axis) Swivel range: -8.5 to 98° Max. swivel speed: 21.5°/s Tool Spindle (D-Axis) Spindle speed: 60 to 350 rpm Tool Positioning Axis (E-Axis) Swivel range: 0 to 360° Max. swivel speed: 19.5°/s Machine Distance (V-Axis) Travel: 150 mm Max. traverse speed: 1.6 m/min MACHINE DETAILS Cutter drive motor Power: 20 kW Workpiece drive Power: 14.5 kW Total connected load: 62 kVA Dimensions & Weight Machine weight: approx. 12 t Space requirement: approx. 4,700 x 4,387 x 2,450 mm EQUIPMENT 13 cutters

Condition: used, max. wheel diameter 0-200 mm max. module 25 Kdedpfx Ajtuxa Ujfdek min. module 0,5

Condition: like new (used), max. width of grinding wheel 77 mm diameter / bore of grinding wheel 400 / 56 mm - Klingelnberg grinding disc holder (627.020.006) outer diameter Ø 260 mm / inner diameter Ø 56 mm - incl. grinding disc from Carborundum dilumit Outer diameter Ø 400 Kdodpfx Afjxgv Afedok see pictures technical drawing

Condition: ready for operation (used), welding circuit at 60% ED: 310 A welding circuit at 100% ED: 235 A Kodpfxed R S Dfs Afdsdk electrical connection: 400 V space needed: 1000 x 750 x 630 mm

Condition: like new (used), Rotary vane bacuum pump in oil bath. Available in stock. Completely overhauled pump. With warranty. Nominal flow: 300 m3 / h at 50Hz. Final vacuum: 0,1 mbar abs. Kjdpeftzzgofx Afdsdk Any clarification, do not hesitate to contact us.

Condition: good (used), Year of construction: 2002, max. wheel diameter 275 mm gear width 55 mm max. module 6 min. module 1 Control 840 C Siemens total power requirement 100 kW Kjdpfetumrpjx Afdsdk weight of the machine ca. 16,7 t dimensions of the machine ca. 5,2 x 2,3 x 2,4 m m

Condition: used, Year of construction: 1982, Center height: 400 mm Center width: 1250/1300 mm Swing diameter: over bed 440 mm Spindle bore: Spindle mount: Tailstock taper: 5 MK Spindle speeds: 11.2 - 2240 rpm Feeds: longitudinal/transverse 0.1-2.8/0.05-1.4 mm/rev Thread pitches: Electrical connection: 380 V, 11 kW Space required: 3400 x 1400 x 1300/1700 mm Kdedpfxsvzn Ito Afdok Weight: approx. 2700 kg

Condition: used, Year of construction: 2001, max. wheel diameter 400/500 mm CNC-Control GE FANUC Series 160i-M pinion diameter - max. 400 mm Kjdpfx Asyv Iplefdedk crown gear diamter max. 500 mm x-axis +/- 70 mm y-axis 200 mm z-axis 200 mm axis angle 90 Grad speeds: R T min rated current 30 kVA weight of the machine ca. 6,2 t dimensions of the machine ca. 3,2 x 2,5 x 2,3 m The Oerlikon T50 is a 3-axis CNC testing machine for fully automatic hard and soft testing of spiral and hypoid bevel gears with an axle angle of 90° Bevel gear analysis ROTEC T50 GA2 Color unit company Binks

Condition: used, Year of construction: 2012, operating hours: 7,500 h, functionality: fully functional, type of input current: three-phase, sheet thickness (max.): 35 mm, sheet thickness steel (max.): 35 mm, sheet thickness aluminum (max.): 30 mm, overall weight: 1,500 kg, input voltage: 400 V, total width: 4,000 mm, total height: 2,000 mm, total length: 8,000 mm, cutting height (max.): 110 mm, track width: 2,950 mm, Equipment: documentation/manual, Selling an Oerlikon plasma cutting system, Plasmatome 20 HPC, Nertajet HP 300 plasma source with CPM 400/450 torch heads for aluminum, steel, and stainless steel. Cutting range 2 x 6 m, cutting current 30-260 A, power consumption 80 kVA. Kodpfx Afsv I U Hcedsdk Material thickness of the sheets to be cut with piercing up to 35 mm, external thickness up to 50 mm. Sold without cutting table.
