Used Omniatec Cnc Machining Center Vertical for sale (72,018)

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 610 mm, controller model: WinMax, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Bdjdpfx Ahez Ahx Demsh Travel range, X-axis: 762 mm Travel range, Y-axis: 508 mm Travel range, Z-axis: 610 mm Spindle speed: 12,000 rpm Table area: 1,020 × 510 mm Table load capacity: 1,500 kg MACHINE DETAILS Control system: WinMax EQUIPMENT Internal cooling system (ICS) Fourth axis

Condition: used, Year of construction: 2001, functionality: unexamined, machine/vehicle number: 220 297-0151, travel distance X-axis: 2,030 mm, travel distance Y-axis: 810 mm, travel distance Z-axis: 810 mm, controller manufacturer: Heidenhain, table width: 780 mm, table length: 2,200 mm, overall weight: 11,600 kg, Equipment: chip conveyor, CNC vertical machining center TAJMAC-ZPS MCFV 2080 NT, year of manufacture 2001, Heidenhain control. Type MCFV 2080NT P26.00, No. 220 297-0151, weight 11,600 kg. Travel ranges X/Y/Z: 2,030 x 810 x 810 mm, table area 2,200 x 780 mm with 5 T-slots. Equipment: Full protective enclosure, chip conveyor with chip cart, electronic handwheel. Bdjdpfjz A Uf Uex Ahmoh Location: Homburg (Saar), Germany. Inspection by appointment only. Price on request, net plus VAT, ex location; dismantling and loading by arrangement. All information without guarantee.

Condition: used, Year of construction: 2018, workpiece weight (max.): 35,000 kg, total length: 15,600 mm, total height: 6,000 mm, total width: 6,000 mm, overall weight: 155,000 kg, The Pittler WMZ PV4000 / 1-2 is a heavy CNC vertical turning machine with a portal design, featuring one workpiece spindle and two independently movable tool carriers. The machine enables turning, drilling, milling, and grooving. The right tool carrier is designed as a swiveling multifunction head with a B-axis and driven tools. Two separate chain magazines provide a total of 94 tool positions. Technical Data Machine Number: ZV029 Machine Concept: Portal machine with one workpiece spindle and two tool carriers Machining Processes: Turning, drilling, milling, and grooving Maximum Swing Diameter: 3800 mm Maximum Workpiece Diameter: 3800 mm Maximum Workpiece Speed: 100 min-1 Bjdpfxszwa Rbs Ahmedh Rated Speed: 36.7 min-1 Workpiece Clamping: Manual Chuck: Röhm Tool Holder: Capto C8 Tool Magazines: 2 chain magazines Tool Positions: 2 x 47 Total Number of Tool Positions: 94 Maximum Tool Diameter: 120 mm according to the operating manual Maximum Tool Diameter: 150 mm according to the order confirmation with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Travel Paths X1-Axis Right Tool Carrier: 3200 mm X2-Axis Left Tool Carrier: 2800 mm Z1-Axis Right Tool Carrier: 1000 mm Z2-Axis Left Tool Carrier: 1000 mm Rapid Traverse X-Axes: up to 32 m/min Rapid Traverse Z-Axes: up to 20 m/min Workpiece Spindle Gear Reduction: 1 to 30 Maximum Speed: 100 min-1 Rated Speed: 36.7 min-1 Rated Power: 67.4 kW Short-Term Total Power: 202.2 kW Rated Torque: 52.65 kNm Maximum Drive Torque: 71.55 kNm Torque according to Order Confirmation: 67000 Nm at 40% duty cycle Motor Spindle Power according to Order Confirmation: 200 kW at 100% duty cycle Maximum Spindle Load Capacity including Chuck, Clamping Jaws, and Workpiece: 35000 kg Spindle Flange Diameter: 1900 mm Thrust Bearing Diameter: 1400 mm The workpiece spindle is designed as a water-cooled motor spindle with precision axial deep groove ball bearings. Tool Carrier and Multifunction Head The right tool carrier features a swiveling multifunction head with two Capto C8 holders for turning tools as well as drilling and milling tools. B-Axis for Stepless Positioning Swivel Range: 180 degrees Speed of Driven Tools: up to 6000 min-1 Tool Spindle Torque: approx. 120 Nm at 100% duty cycle Hydraulic Clamping Direct Measurement System Direct Coolant Supply High-Pressure Coolant Supply: up to 70 bar Tool Magazines Two chain magazines with 47 tool positions each Tool Holder: Capto C8 Maximum Tool Diameter: 120 mm Up to 150 mm with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Tool Cleaning with Blowing Air Manual Magazine Loading Coolant and Chip Disposal Two Knoll Chip Conveyors Type 600 S-2/120 Knoll Band Filter Type KF400-2300 Additional Equipment Röhm Chuck Spindle Cooling Hydac FLKS-4S Hydraulic Unit Hydac TBM20 Electrical Data Operating Voltage: 3 x 400 VAC Protection Class: IP55 Maximum Power Consumption: 280 kVA Component weight max.: 35,000 kg Swing: 3,800 mm Rotation height max.: 2,100 mm Weight approx.: 155,000 kg Dimensions (LxWxH) approx.: 15600 x 6000 x 6000 mm Table diameter: 3,800 mm Control: Siemens SINUMERIK 840D sl Year of construction: 2,018 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: used, Year of construction: 2001, functionality: unexamined, machine/vehicle number: 220 294-0059, travel distance X-axis: 1,650 mm, travel distance Y-axis: 810 mm, travel distance Z-axis: 810 mm, controller manufacturer: Heidenhain, table width: 780 mm, table length: 1,800 mm, overall weight: 11,400 kg, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, CNC vertical machining center TAJMAC-ZPS MCFV 1680 NT, year of manufacture 2001, Heidenhain control. Type MCFV 1680NT P26.00, No. 220 294-0059, weight 11,400 kg, connection 400 V, 100 A, 50 Hz. Travel ranges X/Y/Z: 1,650 x 810 x 810 mm, table area 1,800 x 780 mm with 5 T-slots. Equipment: full enclosure, chip conveyor with chip cart, electronic handwheel, signal light. Bsdpfx Aez A Uhpehmjdh Location: Homburg (Saar), Germany. Inspection by appointment only. Price on request, net plus VAT, ex works; dismantling and loading upon agreement. All information without guarantee.

Condition: used, Year of construction: 1998, functionality: unexamined, machine/vehicle number: 220 280-0324, travel distance X-axis: 1,016 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 760 mm, controller manufacturer: Heidenhain, table width: 590 mm, table length: 1,270 mm, overall weight: 6,700 kg, Equipment: chip conveyor, CNC vertical machining center ZPS MCFV 1060 NT, year of manufacture 1998, Heidenhain control. Type MCFV 1060NT P25.01, No. 220 280-0324, weight 6,700 kg. Travel ranges X/Y/Z: 1,016 x 610 x 760 mm, table area 1,270 x 590 mm with 5 T-slots. Bodpfx Ahez A Uglsmsdh Equipment: full protective enclosure, chip conveyor with chip trolley, electronic handwheel. Location: Homburg (Saar), Germany. Inspection by appointment. Price on request, net plus VAT, ex works; dismantling and loading by arrangement. All information without guarantee.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: M+ Mazatrol, table load: 1,000 kg, TECHNICAL DETAILS Travel in the X-axis: 1,660 mm Travel in the Y-axis: 510 mm Travel in the Z-axis: 510 mm Table dimensions: 2,000 × 510 mm Table load capacity: max. 1,000 kg Spindle speed: 7,000 rpm Tool holder: SK 40 Tool magazine: 48 tools Bodpfez Ahw Hex Ahmsdh MACHINE DETAILS Control system: M+ Mazatrol Machine weight approx.: 7,500 kg Space requirement approx.: 5 m² EQUIPMENT Chip conveyor: MAYFRAN 4th axis: Tilting rotary table: Rotamatik RM 100

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 2,300 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 2,300 mm Travel range, Y-axis: 800 mm Travel range, Z-axis: 600 mm Bdodpfxoz Epg Eo Ahmjh Work area, fixed table Work area, X-axis: 925 mm Work area, Y-axis: 800 mm Work area, Z-axis: 600 mm Clamping area: 1,400 × 750 mm Work area, rotary table Work area, X-axis: 780 mm Work area, Y-axis: 800 mm Work area, Z-axis: 600 mm Clamping area: 800 × 630 mm Tool holder: SK 40 Tool magazine: 30 positions Spindle speed: 50–12,000 rpm MACHINE DETAILS Control system: Heidenhain iTNC 530 Spindle: Kessler motor spindle EQUIPMENT 6th axis prepared Handheld control unit Internal cooling system with filter system Filter system: 500 l Chip conveyor Blum laser 2 extraction systems Machine hood

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 410 mm, controller manufacturer: Siemens, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range X: 560 mm Travel range Y: 410 mm Travel range Z: 410 mm Clamping area: 650 × 410 mm Table load: 250 kg Spindle speed: 12,000 rpm Tool holder: SK 40 MACHINE DETAILS Control system: Siemens Bedpfxoz Ahxqj Ahmedh

Condition: excellent (used), Year of construction: 2021, Table size 3500 x 820 mm, table load 2500 kgs, traverses XYZ 3000 x 800 x 720mm, Bdjdpfx Ahoz Ha H Semoh Rapid federate 50m/min, Spindle power 35Kw, spindle speed 18,000rpm, 30 station ATC, Spindle taper CT40, Mazak Smooth Control, B axis +/- 110 degrees, C axis 0.001 degrees, Through spindle coolant, swarf conveyor.

Condition: used, Year of construction: 2003, Used machine Year of manufacture 2003 New HSD milling spindle 2023 not yet in use New drilling gearbox 2020 Technical specifications: X-axis working area 3400 mm Y-axis working area 1300 mm Bodpfx Ahsw I Ulcjmedh Z-axis working area 130 mm Max. workpiece size 3000 x 1300 x 100 mm X-axis speed 25 m/min Y-axis speed 25 m/min Z-axis speed 20 m/min Milling spindle motor speed 0-24000 rpm Drill spindle motor speed 3400 rpm Milling spindle motor power 7 kW Drill spindle motor power Tool changer Interface 2.2 kW 5-way ISO-30 Brushless motor power X-axis 5.39 N/m Brushless motor power Y-axis 5.39 N/m Power Brushless motor Z-axis 2.39 N/m Number of drill spindles 15 Grooving saw diameter 120 mm Vacuum pump 100 m³/h Max. installed electrical power 15 kW Extraction hose connection diameter 120 mm Machine dimensions (L/W/H) 4500 x 2000 x 2500 mm Machine weight 2400 kg Location: Röllbach Availability: Upon request

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, controller manufacturer: MITSUBISHI, spindle speed (max.): 15,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 300 mm Travel range, Y-axis: 250 mm Travel range, Z-axis: 250 mm Spindle speed range: 60–15,000 rpm Spindle speed control: stepless Tool changer: vertical Magazine capacity: 12 Tool interface: SK 30 Workpiece clamping area: 400 × 250 mm MACHINE DETAILS Control system: MITSUBISHI Jaw width: 100 mm Bdedpfx Ajz Hxb Ujhmsh EQUIPMENT Fixed angular table Dual-pallet changer 4 × Allmatic vices Various tool holders SK 30 Electronic handwheel Full-protection enclosure with sliding doors and interior lighting Coolant system with paper band filter Coolant system Two-color signal light Chip conveyor 6 × Machine feet Operating manuals

Condition: good (used), Year of construction: 1997, functionality: fully functional, We offer an nice condition Matsuura with tools and accessoriess, very atractive machine for a serious work. Description Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. Spindle Chiller WASTE CONVEYOR with Yasnac i80M Control 20 Position: ATC BT40 : Taper Specifications Manufacturer MATSUURA Model MC600VF Year 1997 Condition Used Serial Number 970112285 Table size 870 x 400mm Coolant tank X = 600 Y = 410 Z = 470mm Bdodovkx Rkopfx Ahmsh Spindle speeds 30 – 15000 rpm.

Condition: ready for operation (used), X-travel: 500mm, y-travel: 250mm, z-travel: 145mm, table dimensions: 885x320mm, max. load: 250kg, rotational speed: 50-10,000/min, controls: HEIDENHAIN TNC 407, weight: 2.4t, operational hours counter: ca. 39,900h. Bdjdpfx Ahehcxfpjmoh

Year of construction: 1990, condition: ready for operation (used), Travel X/Y/Z: 3200mm/1400mm/500mm, table dimensions X/Y: 3000mm/1250mm, max. workpiece width: 1500mm. Speed: 10000rpm, spindle mount: CAT50, spindle power: 35hp, tool positions: 30, dimensions X/Y/Z: approx. 8000mm/4000mm/3500mm, weight: approx. 24000kg. On-site inspection is possible. Bodstx Dpfepfx Ahmodh

Condition: ready for operation (used), Year of construction: 1991, A CNC vertical machining center Emco is available. Travel X/Y/Z: 420mm/330mm/400mm, table dimensions X/Y: 650mm/320mm, max. table load: 150kg, tool positions: 12, tool holder: SK40, speed: 4500rpm, rapid traverse: 12m/min. Machine dimensions X/Y/Z: approx. 2400mm/2300mm/2450mm, weight: approx. 2750kg, control: Emcotronic TM02. An on-site inspection is possible. Bjdjy H I H Sspfx Ahmedh

Condition: used, overall weight: 5,500 kg, spindle speed (max.): 8,000 rpm, Highly efficient vertical machining center Chevalier QP2033-L, suitable for precision milling, drilling, and tapping of various materials Bedpfxozz H Ets Ahmsdh

Condition: ready for operation (used), Year of construction: 2012, A CNC vertical machining center is offered. Travel X/Y/Z: 1000mm/500mm/570mm, table dimensions X/Y: 1200mm/500mm, max. workpiece weight: 800kg, distance from spindle nose to table: approx. 120-690mm, tool holder: SK40, max. spindle speed: 10000rpm, tool magazine: 24, max. tool diameter: approx. 80mm, max. tool length: approx. 300mm, max. tool weight: approx. 7kg, rapid traverse X/Y: 24m/min, rapid traverse Z: 20m/min, positioning accuracy: approx. 8-12µm, control: Heidenhain TNC 620. Machine dimensions X/Y/Z: approx. 2700mm/2550mm/2770mm, machine weight: approx. 5100kg. Inspection possible by appointment. Bodjzipgpopfx Ahmodh

Condition: ready for operation (used), Year of construction: 2012, A CNC vertical machining center is offered. Travel X/Y/Z: 1000mm/500mm/570mm, table dimensions X/Y: 1200mm/500mm, max. workpiece weight: 800kg, distance from spindle nose to table: approx. 120-690mm, tool holder: SK40, max. spindle speed: 10000rpm, tool magazine: 24, max. tool diameter: approx. 80mm, max. tool length: approx. 300mm, max. tool weight: approx. 7kg, rapid traverse X/Y: 24m/min, rapid traverse Z: 20m/min, positioning accuracy: approx. 8-12µm, control: Heidenhain TNC 620. Machine dimensions X/Y/Z: approx. 2700mm/2550mm/2770mm, machine weight: approx. 5100kg. Inspection possible by appointment. Bodpfszipgiox Ahmedh

Condition: used, Year of construction: 1994, functionality: fully functional, machine/vehicle number: 308, travel distance X-axis: 1,300 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 660 mm, rapid traverse X-axis: 18,000 m/min, rapid traverse Y-axis: 18,000 m/min, rapid traverse Z-axis: 15,000 m/min, table width: 1,600 mm, table length: 650 mm, table load: 1,850 kg, overall weight: 13,000 kg, - Year of manufacture: 1994 - Single owner, used exclusively in-house - Fully operational, powered, ready for demonstration - Control: Fanuc 0MC - X-axis machining range: 1300 mm - Y-axis machining range: 650 mm - Z-axis machining range: 660 mm - Table working surface: 1600 x 650 mm - Max. permissible workpiece weight: 1850 kg - Number and width of T-slots: 5 x 18 mm - Spindle speed range: 20 - 6000 rpm - Rapid traverse speed: 18000 (X) x 18000 (Y) x 15000 (Z) mm/min - Tool holder: SK50 / MAS BT50 - Tool magazine: 30 stations - Machine weight: 13,000 kg - Serial number: 308 Net price ex location Luckenwalde (Germany), not loaded, without transport Bsdpfoxp Hu Djx Ahmjdh

Year of construction: 2022, condition: ready for operation (used), A CNC vertical machining center Akira Performa with a counter bearing on the A-axis is available. Travel X/Y/Z: 2060mm/850mm/815mm, spindle-table distance: 120mm-935mm, table dimensions X/Y: 2150mm/800mm, max. table load: 3240kg. Spindle power: 42kW, speed: 8000rpm, tool holder: BT50, rapid traverse X/Y/Z: 36m/36m/30m/min, positioning accuracy: 0.015mm, repetition accuracy: +/-0.005mm. Tool positions: 28, max. tool diameter: 100mm/200mm, max. tool length: 350mm, max. tool weight: 15kg. Machine dimensions X/Y: approx. 5000mm/3550mm, weight: approx. 14500kg, control: Siemens 828, documentation available. On-site inspection is possible. Bdjdpfxsv Ubqbs Ahmjh

Condition: ready for operation (used), Year of construction: 2013, operating hours: 10,649 h, functionality: fully functional, machine/vehicle number: 101161, travel distance X-axis: 1,020 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 920 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 14,000 rpm, A new spindle was installed one year ago! TECHNICAL DETAILS Travel in X-axis: 1,020 mm Travel in Y-axis: 620 mm Travel in Z-axis: 920 mm Swivel range of B-axis: +30° to -120° Spindle speed range: 1–14,000 rpm Tool holder: SK 40 Tool magazine capacity: 40 Clamping surface of rotary table: 1,200 × 610 mm Bsdpfx Ahez Hwutomedh Diameter of rotary table: 500 mm MACHINE DETAILS CNC control: Heidenhain iTNC 530 Operating voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Power: 75 kVA Rated current: 100 A Main fuse: 120 A Machine weight: 8,740 kg Operating hours (according to counter) Spindle running time: 10,649 h Program running time: 11,159 h Machine operating hours: 24,317 h Control operating hours: 26,901 h EQUIPMENT Fixed rotary table NC rotary table WALTER B-axis swivel head with torque drive Vertical tool changer 3D measuring probe Heidenhain Electronic handwheel Fixed full protective enclosure with interior lighting Internal cooling system Coolant system Oil mist extraction Chip conveyor Operating manual

Condition: used, CNC Vertical Machining Center FEHLMANN Type PICOMAX 60 CNC Control System: HEIDENHAIN TNC 426 Serial No.: 14599641 Year of manufacture: 1999 Travel paths X: 500 mm, Y: 350 mm, Z: 610 mm Feed rate: 1 - 20,000 mm/min Rapid traverse: 20 m/min Bsdpfsy N Du Dex Ahmodh Feed force: 12,000 N Table clamping surface: 920 x 380 mm T-slots: 7 pcs, 12-H8 mm Table load capacity: max. 250 kg Table height: 1004 mm Distance spindle nose - table: 94 - 704 mm Overhang spindle - column: 405 mm Spindle speed: 50 - 18,000 rpm, stepless Spindle drive: 10.2 kW (60% duty cycle) Max. torque: 70 Nm (up to 1240 rpm) Spindle taper: SK 30 / DIN 69871A Pull stud: DIN 69872 Drilling capacity in steel: 25 mm Milling capacity in steel / aluminium: 100 / 700 cm³/min Thread cutting in steel / aluminium: M20 / M24 Tool changer: 24 positions Tool change time: approx. 6 sec. Chip-to-chip time: approx. 8 sec. Control: Heidenhain TNC 426 Power supply: 400 Volt, 50 Hz Connected load: 20 kW - Electronic handwheel Heidenhain HR410 - 3D probe Renishaw MP12 - Tool measurement system - TFT display - Direct path measuring system - Coolant system (200 liters, lateral) - Spindle cooling unit (lateral) - Central lubrication Vogel - Air supply: 6 bar, 40 - 200 l/min - Oil mist extraction - Operating hours: - Control on: 97,000 h - Machine on: 80,000 h - Program run: 42,000 h Required space (L x W x H): 2,000 x 1,700 x 3,000 mm Weight: approx. 3.2 t Good condition

Year of construction: 2012, condition: ready for operation (used), A CNC vertical machining center Akira Seiki is available. Travel X/Y/Z: 2060mm/850mm/815mm, spindle-table distance: 120mm-935mm, table dimensions X/Y: 2150mm/800mm, max. table load: 3240kg. Spindle power: 42kW, speed: 8000rpm, tool holder: BT50, rapid traverse X/Y/Z: 36m/36m/30m/min, positioning accuracy: 0.015mm, repetition accuracy: +/-0.005mm. Tool positions: 28, max. tool diameter: 100mm/200mm, max. tool length: 350mm, max. tool weight: 15kg. Machine dimensions X/Y: approx. 5000mm/3550mm, weight: approx. 14500kg, control: Mitsubishi 70, documentation available. On-site inspection is possible. Bdodpsv Ubqhsfx Ahmsh

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, Equipment: documentation/manual, CNC-controlled vertical machining center AXA VSC-3-3000-M Year of manufacture: 1995 Control system: Heidenhain TNC 407 Technical data: X-axis travel: 3000 mm Y-axis travel: 420 mm Z-axis travel: 480 mm Table size: approx. 3000 x 500 mm Spindle connection: SK40 Bjdpfxoy U Hy To Ahmedh Speed range: up to 6000 rpm 22-tool automatic tool changer Coolant system Heavy-duty frame construction Special features: Additional angular/universal milling head 4-/5-axis machining possible Flexible machining of complex workpieces Ideal for toolmaking, mechanical engineering and single-part production The machine is in good condition. Inspection under power is possible by arrangement.

Condition: used, Year of construction: 2020, workpiece weight (max.): 35,000 kg, total length: 15,600 mm, total height: 6,000 mm, total width: 6,000 mm, overall weight: 155,000 kg, The Pittler WMZ PV4000 / 1-2 is a heavy CNC vertical turning machine with a portal design, featuring one workpiece spindle and two independently movable tool carriers. The machine enables turning, drilling, milling, and grooving. The right tool carrier is designed as a swiveling multifunction head with a B-axis and driven tools. Two separate chain magazines provide a total of 94 tool positions. Technical Data Machine Number: ZV029 Machine Concept: Portal machine with one workpiece spindle and two tool carriers Machining Processes: Turning, drilling, milling, and grooving Maximum Swing Diameter: 3800 mm Maximum Workpiece Diameter: 3800 mm Maximum Workpiece Speed: 100 min-1 Rated Speed: 36.7 min-1 Workpiece Clamping: Manual Chuck: Röhm Tool Holder: Capto C8 Tool Magazines: 2 chain magazines Tool Positions: 2 x 47 Total Number of Tool Positions: 94 Maximum Tool Diameter: 120 mm according to the operating manual Maximum Tool Diameter: 150 mm according to the order confirmation with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Travel Paths X1-Axis Right Tool Carrier: 3200 mm X2-Axis Left Tool Carrier: 2800 mm Z1-Axis Right Tool Carrier: 1000 mm Z2-Axis Left Tool Carrier: 1000 mm Rapid Traverse X-Axes: up to 32 m/min Rapid Traverse Z-Axes: up to 20 m/min Workpiece Spindle Gear Reduction: 1 to 30 Maximum Speed: 100 min-1 Rated Speed: 36.7 min-1 Rated Power: 67.4 kW Short-Term Total Power: 202.2 kW Rated Torque: 52.65 kNm Maximum Drive Torque: 71.55 kNm Torque according to Order Confirmation: 67000 Nm at 40% duty cycle Motor Spindle Power according to Order Confirmation: 200 kW at 100% duty cycle Maximum Spindle Load Capacity including Chuck, Clamping Jaws, and Workpiece: 35000 kg Spindle Flange Diameter: 1900 mm Thrust Bearing Diameter: 1400 mm The workpiece spindle is designed as a water-cooled motor spindle with precision axial deep groove ball bearings. Tool Carrier and Multifunction Head The right tool carrier features a swiveling multifunction head with two Capto C8 holders for turning tools as well as drilling and milling tools. B-Axis for Stepless Positioning Swivel Range: 180 degrees Speed of Driven Tools: up to 6000 min-1 Tool Spindle Torque: approx. 120 Nm at 100% duty cycle Hydraulic Clamping Direct Measurement System Direct Coolant Supply High-Pressure Coolant Supply: up to 70 bar Tool Magazines Two chain magazines with 47 tool positions each Tool Holder: Capto C8 Maximum Tool Diameter: 120 mm Up to 150 mm with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Tool Cleaning with Blowing Air Manual Magazine Loading Coolant and Chip Disposal Two Knoll Chip Conveyors Type 600 S-2/120 Knoll Band Filter Type KF400-2300 Additional Equipment Röhm Chuck Spindle Cooling Hydac FLKS-4S Hydraulic Unit Hydac TBM20 Electrical Data Operating Voltage: 3 x 400 VAC Protection Class: IP55 Maximum Power Consumption: 280 kVA Component weight max.: 35,000 kg Weight approx.: 155,000 kg Rotation height max.: 2,100 mm Bdodpfx Ahjzu S U Hemsh Table diameter: 3,800 mm Swing: 3,800 mm Control: Siemens SINUMERIK 840D sl Dimensions (LxWxH) approx.: 15600 x 6000 x 6000 mm Year of construction: 2,020 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes
