Used Pyrolysis Furnace for sale (661)

Year of construction: 2008, condition: ready for operation (used), Loading chamber dimensions: 280x580mm, loading height: 700mm, max. load: 300kg, with protective housing and documentation, machine was functional until the end, complete maintenance would have to be carried out on the machine, inspection is possible. Nodpfx Aoqgfbgoa Hewk

Condition: like new (used), Chanber size: Nwjded Sm Dispfx Aa Hsk 280x180x500mm upper 280x130x450mm lower Max temperature: 700 C °

Condition: good (used), Year of construction: 2007, machine/vehicle number: 194354, Offer 26187 Technical data: - Nominal temperature / Continuous temperature, stepless, up to 900 °C - Temperature control via NABERTHERM Controller C 40 - Heating from both sides, back wall, door, and floor - Motorized lift-up door - T. max. approx. 120 min - Drive: 400 V / 59 kW - Internal dimensions approx.: W 1000 x H 550 x D 1900 mm - Usable volume approx.: 950 L - Space required approx.: W 2100 x H 2800 x D 2800 mm - Weight approx.: 2900 kg Nwodpfxszw D H He Aa Hok

Condition: used, Two dental furnaces are offered, one Zirkonzahn sintering furnace and one Nabertherm preheating furnace. 1) Zirkonzahn Keramikofen 1500 sintering furnace with control unit, firing chamber volume: approx. 0.6l, maximum temperature: 1500°C, power: 1500W, furnace weight: approx. 75kg, furnace dimensions X/Y/Z: approx. 390mm/690mm/490mm. 2) Nabertherm preheating furnace in need of repair with P 320 controller, program memory: 9 programs, program steps: 16, chamber volume: 9l, maximum temperature: 1100°C, when the Nabertherm furnace is switched on, an ERROR message with an error code appears, the exact cause of the fault is unknown. An on-site inspection is possible. Nwjdpfxjzww Sps Aa Hok

Condition: used, Year of construction: 2012, Technical details: max. temperature: 700° - übliche Temperatur: 400 - 650°C Grad size of opening: B: ca. 2200 x T: ca. 3800 x H: ca.1100 mm program control: Siemens S7/300 IM 151-7 interface: Ethernet container volume: Ofen-Volumen: 9,2 m³ l control voltage: 24 / 230 Volt current type: 1P/PEN; 50 Hz Voltage: 400 V elect. connected power requirement of heater: 3 x 3 x 21 kW = 189 kW flow rate: 3 x ca. 9.000 = 27.000 m³/h weight of the machine ca.: 8,0 t dimensions of the machine approx. HxWxD: ca. 3.9 x 3.8x 4.8 m dimensions electric cabinet: ca. B: 2.400 x T: 400 x H: 2.000 mm transport dimensions LxWxH: ca. 5,2 x 3,6 x 2,9 m Electrically heated circulation oven Electric annealing furnace whose housing is made of profiled sheet steel and lined with lightweight refractory bricks/ firebricks. Application/processes: mainly annealing of low-alloy and high-alloy wood cylinders (e.g. alloyed gray cast iron) Usual operating weight 5000kg max. 8000kg The parts are placed directly crosswise on the bogie hearth/grate in the flow device. (Height above floor approx. 750mm without grate) Heating integrated in oven ceiling Circulation fan (3 compact fans) on oven side wall, 3 x 4.0 kW = 12.0 kW Forced cooling (1 cooling air fan) Program control via 25 programs with 50 program sections per program Oven door/lifting door with SWE gear motor approx. 2.2 kW (frequency-controlled) Bogie hearth drive approx. 3.0 kW SEW geared motor (frequency-controlled) incl. center rail (chain drag) used, good condition Nsdsu R Dhxepfx Aa Hjwk *

Year of construction: 2002, condition: good (used), functionality: fully functional, Temperature max: 700° Celcius Opening LxH: 1.500 x 30 mm Country of origin: The Netherlands Electric power: 14 kW Machine LxWxH: 2.000 x 1.000 x 1.700 mm Njdpfxewi Ry Ho Aa Hewk Machine weight: 1500 kg

Condition: good (used), Chamber volume: approx. 72 liters (usable volume) Heating capacity: 18 kW Internal dimensions (W x D x H): approx. 400 x 600 x 300 mm Nwedpozwfwaefx Aa Hek Temperature: 1,200 °C Controller: G 400

Condition: used, Year of construction: 1975, functionality: fully functional, overall weight: 10,000 kg, total length: 2,745 mm, total width: 2,360 mm, total height: 2,700 mm, type of cooling: air, BBC BROWN BOVERI (nowadays ABB) – Pouromat, pouring furnace, type XCQ 44 TECHNICAL DATA - crucible capacity: 4.4t - tilting furnace - inductor 120kW - inductor voltage 380/425V - 2 operating modes: preheating, heating mode 1 - pouring rate: 1-20kg/s - dimensions:  height: approx. 2700mm  length: 2745mm  width: 2360mm - weight: approx. 10,000kg - furnace equipped with a bottom-pour stopper - average inductor lifespan: 12 weeks - average bottom-pour stopper lifespan: 1 week - average crucible lifespan: 4 – 6 months - furnace equipped with an additional device used to modify the liquid metal with ferrosilicon CONSTRUCTION The pouring furnace consists of four basic groups: - First group – longitudinal travel (orbit motor) - Second group – transverse travel, including the bottom-pour stopper - Third group – inductor with a power of 120 kW, voltage 380 V 50Hz, whose main task is to heat the liquid metal. The inductor is constantly air-cooled during operation. - Fourth group – switchboard with a built-in transformer, contactors and control station. POURING PROCESS Nwjdpfx Aozfyu Aea Hsk The pouring process proceeds as follows: DISAMATIC 2032 A displays the molds on the conveyor in the correct position. The correct position means that the open pouring basin in the mold is located in a position compatible with the bottom-pour stopper at the bottom of the crucible. If the desired position is achieved, the operator manually (by means of a lever) lifts the bottom-pour stopper in order to fill the mold, until the liquid metal is visible in the outflow. The speed of pouring the molds can be adjusted depending on the diameter of the ceramic block and the orientation of the bottom-pour stopper towards the ceramic block. CERAMICS The manufacturer, BBC, recommends using a two-layer firebrick lining, where one layer is permanent, but the second is expendable. The permanent lining consists of an insulating layer, which is a lightweight burned stone, and a sillimanite layer. The expendable layer consists of a corundum material, meaning a concrete with a high clay content (94%). Both parts are connected together by means of a special cement. The crucible inductor is located in a lining of Al₂O₃ or MgO and SiO₂, depending on the requirements. The material used to seal the bottom-pour stopper has the quality of chamotte with different clay content. The inductor is assembled to the pouring furnace by means of screws and a sealing compound with the proper plasticity and heat resistance. The entire device consists of three stopper rod sleeves, a bot, and a ceramic block, where the bot and stopper rod sleeves are connected together. The bottom-pour stopper is seated on a threaded bar. The bottom-pour stopper is continuously air-cooled. Recommended air pressure: 6 atm. CERAMICS LIFESPAN 1. crucible: approx. 4 – 6 months 2. inductor: approx. 12 weeks The lifespan of the ceramics depends on many factors. The most important are: production frequency, pouring temperature, cleanliness of the liquid metal, and alloy type. The lifespan of the upper cover and rotating cover is much longer because these parts have no direct contact with the liquid metal. PRICE *44,100 EUR *disassembly of the furnace, transportation costs, and assembly at the customer's location are paid by the Buyer; the price includes additional equipment: - additional (replaceable) inductors (without induction coil): 2 pcs.

Year of construction: 2003, condition: used, functionality: fully functional, machine/vehicle number: HWO 1/9-5.2​, - The system is located at the Geberit Keramik GmbH site in Wesel. - The system, including the associated safety technology, performs technical flash firing and re-firing and is prepared for this purpose. Nodpfx Aaszu Nvze Hewk - Maximum firing temperature [°C] = 1300 - Current operating temperature [°C] = 1238 - Number of burner groups = 10 - Number of burners = 38 - Number of kiln cars = 18 - Number of kiln cars in the kiln = 9 - Current firing cycle [h] = 17 - 23 - Gross energy consumption [kcal/kg] / [kWh/kg] = 785 / 0.912 - Specific energy consumption [kcal/kg] / [kWh/kg] = 1459 / 1.696 - Gas connection capacity [m³/h] = 770 - Usable waste heat [m³/h] = 4000 - Standard loading quantity [pieces] = 900-980 ceramic products Dimensions of the housing: - Length [m] = 14.4 - Width [m] = 6.4 - Height [m] = 5.7 - Volume density [m³] = 146.3 Dimensions of the kiln car: - Effective length [m] = 1.45 - Effective width [m] = 5.2 - Effective height [m] = 2.156 - Track gauge [m] = 1.5 (2x) Special features: In 2023, the kiln was completely overhauled and brought up to the latest state of the art. The following changes were made: - Renewal of the kiln roof: The fiber lining in the upper area was replaced with cordierite stones. - Renewal of the burners, including new nozzles, flame tubes and controllers. - Replacement of the media valves; installation of servo motors on the gas and air lines in front of the burners. - Installation of new software; the Simatec control panel was replaced – control is now exclusively via the PC. - Replacement of the O₂ control system; installation of a Zerox probe; installation of an O₂ analyzer for O₂ correction (to improve energy efficiency by approximately 12–14 %). - The system must be dismantled, packed and collected independently by the buyer.

Condition: excellent (used), Year of construction: 2014, Oven volume: 2.366 m³ Max. temperature: 750 °C Nwjdpfx Aajzvnkte Hek Power rating: 84 kW Weight: 3.7 t Transport and loading can be organized across Europe for an additional charge upon request. Prices are subject to VAT. Inspection possible by prior appointment. Please contact us—our team looks forward to assisting you. Machinery Purchase / Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, MACHINE TOOLS, AND MUCH MORE. Are you looking for a high-quality yet affordable machine for your production? Or looking to sell yours? For further information or contact options, please reach us via the contact form.

Condition: good (used), Year of construction: 2014, Overall dimensions: 12.4 x 18.8 m incl. safety fencing Nwjdpozvnk Hjfx Aa Hjk Number of baskets per oven: 2x 1,170 x 1,150 x 2,000 mm Reference load weight (net/gross): 1,285 / 2,185 kg Max. load weight (net/gross): 2,000 / 2,700 kg Load: 2,050 x 1,150 x 2,800 mm, external dimensions: 2,950 x 6,400 x 7,800 mm Max. temperature: 600 °C Operating temperature: 510 °C Total heating capacity: 2 x 81 kW = 162 kW electric Quenching water bath: Type = QT-24.16.57/71E Temperature bath max.: 70°C, chamfering volume = 20 m^3 2 ageing furnaces: Type = ADBF-24.16.30/250E External dimensions: 2,800 x 4,850 x 4,000 mm Oven temperature max.: 250°C Operating temperature: 180 °C Total output: 2x 40.5 kW = 81 kW Electrical storage/retrieval section, Gea cooling coil, protective housing, safety equipment, system control 1,056 annealing baskets with stanchion pallets System already dismantled, packed and stored

Condition: ready for operation (used), Year of construction: 1996, Useful dimensions: 700 x 650 x 1,100 mm Batch weight: 800 kg Temperature: max. 1,000 °C Heating: Natural gas heated Quench: Oil/Air Equipment: Control Siemens Simatic Nodpszvfnijfx Aa Howk

Condition: excellent (used), Year of construction: 2002, Consisting of: - 2 pieces hardening furnaces 10 Cg gross weight 400 kg - 1 piece of nitriding oven 8 Cg gross weight 400 kg - 1 piece spray washing machine - 2 pieces tempering furnaces - 1 piece of oil quench bath 5000 liters Nodpfx Ajzvfluea Hewk - 1 piece manipulator All technical data for the individual systems can be found in the attached pictures.

Condition: good (used), Year of construction: 1973, rust size: 700 x 650 x 1.100 mm batch weight: 1.000 kg Temperature: Max. 750 °C connected load: 78 kW Nodjzvfdqepfx Aa Hjwk Equipment: Incl. Control system (should be renewed) + Charging machine others: Furnace can be moved under nitrogen

Condition: ready for operation (used), Heraeus MR 260 Annealing Furnace Internal dimensions: 260mm x 500mm x 160mm (W x D x H) Space required: 1100mm x 700mm x 1560mm (L x W x H) Weight: 150 kg Rated temperature: 1000°C You are welcome to visit us for an inspection. We can arrange cost-effective shipping for you! You will receive a proper invoice. For international customers, a net invoice can also be issued. A valid VAT identification number is required. Subject to prior sale. Visit our shop and browse our other offers. Nwsdszu Natopfx Aa Hsk The company names and trademarks mentioned are the property of their respective owners and are used solely for identification and description of the products. Deviations from technical data as well as errors in the description of the item may occur and are subject to change.

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, operating hours: 200 h, power: 11.5 kW (15.64 HP), input voltage: 192 V, input current: 60 A, temperature: 1,350 °C, inner dimension length: 1,500 mm, inner dimension width: 100 mm, inner dimension height: 100 mm, total length: 2,000 mm, total width: 600 mm, total height: 600 mm, overall weight: 150 kg, number of chambers: 1, actuation type: electric, fuel type: electric, year of last overhaul: 2025, Equipment: CE marking, documentation/manual, Carbolite Gero Tube Furnace – 1350 °C, Ø 100 mm, Length 1500 mm – Fully Functional For sale is a high-quality tube furnace from Carbolite Gero in excellent technical condition. The furnace has only been operated for approx. 200 hours and was primarily used for sintering copper at around 1000 °C. Nedpfxey H E Nds Aa Hswk Thanks to the maximum temperature rating of 1350 °C, the system was never thermally overstressed and therefore remains in well-maintained condition. 🔧 Technical Specifications - Max. temperature: 1350 °C - Tube diameter: 100 mm - Tube length: 1500 mm - Temperature measurement: internal thermocouple → precise process control - Features: water-cooled flanges 🔩 Condition & Notes - Furnace is fully operational - Supplied ceramic tube shows signs of previous use Recommendation: - Replace with new ceramic tube for high-temperature applications - Alternatively, use cost-effective metal tubes for operations below 1100 °C 💡 Benefits - Highly accurate temperature control via internal measurement (i.e., furnace temperature and ramps are regulated by an internal thermocouple, ensuring optimal sample temperature) - Ideal for precise sintering processes, heat treatment, and materials development - Robust industrial design from a reputable manufacturer 📦 Areas of Application - Metallurgy (e.g. copper, steel, ceramics, glass-ceramics, powder metallurgy) - Research & Development - Laboratory and small-scale production applications 🚚 Other - Inspection possible by appointment - Collection only

Condition: ready for operation (used), A retort furnace PFS Anlagenbau UG for gas nitriding, nitrocarburizing, and tempering is available. Load weight range: 750kg-6000kg, max. operating temperature: 750°C, treatment chamber dimensions X/Y/Z: 1800mm/900mm/900mm, number of burners: 4, burner type: recuperative, burner output: 4×80kW, loading height: 1200mm, max. evacuation temperature: 350°C, retort material: 1.4841, circulator air volume flow: 10000m³/h, nitriding system manufacturer: Process-Electronic, vacuum pump capacity: 240m³/h, total pressure: below 0.7mbar, max. operating pressure: 1.45bar. Documentation available. An on-site inspection is possible. Nwedpfx Aoy N Uxgoa Hjk

Year of construction: 1992, condition: ready for operation (used), Gross combustion chamber: 800l, usable combustion chamber: 500l, combustion chamber dimensions X/Y/Z: 820mm/600mm/1015mm, connected load: 100kW, max. operating temperature: 1400°C, machine dimensions X/Y/Z: approx. 1450mm/1150mm/2100mm, weight: approx. 1500kg. Including fresh air blower and control cabinet with controller Jumo Imago 500. On site inspection is possible. Nwjdpfx Aajyfv N Re Hok

Year of construction: 1986, condition: ready for operation (used), A Herdieckerhoff pot annealing furnace for the heat treatment of ring tubes is available. Maximum temperature: 1000°C, operating medium: inert gas, max. net charge weight: 1200kg, support height: 3850mm, furnace diameter: 2200mm, furnace height: 4650mm. Including 3x vacuum-tight and water-cooled circulators and 3x circulation impellers. Documentation available. On-site inspection is possible. Njdpfx Aasvxvgro Howk

Condition: ready for operation (used), A Rohde chamber kiln is available. Volume: 600l, max. temperature: 1000°C, internal dimensions X/Y/Z: 710mm/870mm/920mm, power: 40kW, insulation layers: 2, heating directions: 4, heating element: grooved refractory brick. Machine dimensions X/Y/Z: approx. 1100mm/1500mm/2300mm, weight: approx. 1000kg. Documentation available. An on-site inspection is possible. Nedpfxjyvix Io Aa Hswk

Year of construction: 2018, condition: ready for operation (used), A Thermconcept high-temperature tube furnace is available. T. max.: 1700°C, heated length: 200mm, tube diameter/length: 60mm/600mm, power: 3.3kW, dimensions X/Y/Z: 460mm/530mm/830mm. Documentation available. Nwsdpfx Astxb Avoa Hsk

Condition: ready for operation (used), Year of construction: 2005, The system consists of two bell furnaces, maximum temperature: 1100°C, annealing chamber: 2x 1000mm, electrical connection: delta, current rating: 433A, connected load: 300kW, equipment: power control, temperature control, process monitoring, safety controller, emergency stop system, motorized drive for bell movement, air conditioning unit, electrical control cabinet, and control system. Inspection on site is possible. Nedpfx Aaszhw Sds Hswk

Year of construction: 2014, condition: ready for operation (used), An industrial Pyreg pyrolysis plant for the thermochemical utilization of biogenic residual materials is available. Fuel capacity: 500kW/module, max. fuel throughput capacity per module: 1375kg/year, min. fuel lower heating value on dry basis: 10MJ/kg, max. fuel moisture content: 50%, biochar production: 40kg/h, thermal heat output (exhaust gas heat): 150kW, power consumption: approx. 7.5kW. Plant dimensions X/Y/Z: approx. 9000mm/3000mm/3000mm, weight: approx. 10000kg, control system: PLC. Documentation available. An on-site inspection is possible. Nwodpfjx Sywgex Aa Hok

Year of construction: 2005, condition: ready for operation (used), Usable space: approx. 4m³, max. temperature: 400°C. The furnace is located in the outdoor storage area. Documentation available. An on site inspection is possible. Nsdpfx Asygw S Asa Hjwk

Year of construction: 1999, condition: ready for operation (used), Volume: 1000l, max. temperature: 750°C, heating capacity: 40kW, machine dimensions X/Y/Z: approx. 2500mm/1600mm/1900mm, weight: approx. 2000kg. Documentation available. An on-site inspection is possible. Expected to be available from October/November 2025. Nsdpfxew Emyze Aa Howk
