Used Rottler Machining Center - Universal for sale (69,107)

Condition: ready for operation (used), Year of construction: 2017, operating hours: 11,206 h, functionality: fully functional, machine/vehicle number: 20170708, travel distance X-axis: 670 mm, travel distance Y-axis: 830 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain 530, spindle speed (max.): 18,000 rpm, The machine underwent maintenance in April 2025, during which the rotary union was replaced at a cost of €8,600! TECHNICAL DETAILS Travel X-axis: 670 mm Travel Y-axis: 830 mm Travel Z-axis: 600 mm Iaedjy I Tvnjpfx Ab Nst Swivel range A-/C-axis: approx. -100 to +120° / -120 to +120° C-axis rotation range: 360° Table diameter: 800 mm T-slots (number x width): 9 x 90 mm Maximum table load: 1,200 kg Kessler spindle: 18,000 rpm Maximum tool length: 300 mm Maximum tool diameter: 75 mm Maximum tool diameter (with adjacent stations empty): 125 mm Maximum tool weight: 7 kg Tool change time: 3 s Rapid traverse X/Y/Z: 60 m/min Max. A-axis speed: 50 rpm Max. C-axis speed: 100 rpm Acceleration X/Y/Z: 7 m/s² Repeatability: 0.004 mm Positioning accuracy: 0.008 mm Rotational drive system: Integrated direct drives Tool holder: HSK 63 Tool stations: 96 MACHINE DETAILS Control: Heidenhain 530 Dimensions & Weight Weight: 19,000 kg Layout with accessories (L x W x H): 4,150 x 5,000 x 3,500 mm Tank capacity: max. 330 l Total coolant capacity: max. 425 l Operating Hours Control on-time: 20,248 h Machine on-time: 19,424 h Program run: 11,331 h Spindle hours: 11,206 h EQUIPMENT Spindle chiller Kessler swing, 800 mm turning diameter, fully utilizable with zero-point clamping system Note: The touch probe is not included in the offer. The holders, however, are part of the offer.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 61,082 h, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 800 mm, controller model: HEIDENHAIN TNC 426, Equipment: chip conveyor, Important information: Auction extended by 14 days. Controller has been subsequently identified as HEIDENHAIN iTNC 530. Previous specification: TNC 426. A new spindle was installed in January 2025! The machine has been regularly maintained! Iajdpey Dgyfefx Ab Njt TECHNICAL DETAILS Travel X-axis: 2,800 mm Travel Y-axis: 2,200 mm Travel Z-axis: 800 mm Feeds Rapid traverse: 35,000 mm/min Spindle speed S1 (continuous operation) vertical: 10,000 rpm Spindle speed S1 (continuous operation) universal swivel head 2-axis: 18,000 rpm MACHINE DETAILS CNC control: HEIDENHAIN iTNC 530 Electrical data Supply voltage: 400 V (–15%, +10%) Frequency: 50 Hz Current consumption: 101.1 A Installed total power: 59.8 kW Operating hours Power-on hours: 98,755 h Program run time: 61,082 h EQUIPMENT High-rigidity gantry design Precision linear guides and ball screws Generous workspace with 2.8 m X-axis travel High feed rates for efficient machining Ideal for tool, die, and machine building Documentation and acceptance certificate according to ISO standards Tool changer Cooling system Chip conveyor Swiveling milling head with 4th/5th axis

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, machine/vehicle number: F 36905, travel distance X-axis: 7,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,300 mm, spindle speed (max.): 2,000 rpm, controller model: HEIDENHAIN TNC 360, TECHNICAL DETAILS Ijdpfx Absy Rrbhs Noat Travel X-axis: 7,000 mm Travel Y-axis: 1,200 mm Travel Z-axis: 1,300 mm Rapid traverse x/y/z: 10 m/min Table size: 8,000 x 1,300 mm Table load capacity: max. 4 t/sqm Universal head: 5x90 plus manual 1 Tool holder: SK 50 Milling spindle speed range: 20 – 2,000 rpm Drive power: 30 kW Spindle torque: 2-speed gearbox, 750 Nm MACHINE DETAILS Control: HEIDENHAIN TNC 360 Total power requirement: 50 kW Dimensions & Weight Space requirements approx.: 9.0 x 3.8 x 4.6 m Machine weight approx.: 25 t EQUIPMENT Orthogonal milling head, water-cooled 3D radio probe M&H 20.41 Partition wall for parallel machining/setup Internal air blast Internal coolant supply 15 bar Adapter for high-speed milling spindles with torque support Operator platform travels with machine Chip conveyor Electronic handwheel HR 410 Monitored safety fences Various optional accessories (angle milling heads, clamps, etc.)

Condition: ready for operation (used), Year of construction: 2001, operating hours: 18,391 h, functionality: fully functional, machine/vehicle number: 11160000853, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-Axis Travel: 600 mm Y-Axis Travel: 700 mm Z-Axis Travel: 600 mm Maximum Spindle Speed: 12,000 rpm X-Axis Feed Rate: 20 – 15,000 mm/min Y-Axis Feed Rate: 20 – 15,000 mm/min Z-Axis Feed Rate: 20 – 15,000 mm/min Rapid Traverse X-Axis: 40 m/min Rapid Traverse Y-Axis: 40 m/min Rapid Traverse Z-Axis: 40 m/min Linear Scale Resolution X-Axis: 0.001 mm Linear Scale Resolution Y-Axis: 0.001 mm Linear Scale Resolution Z-Axis: 0.001 mm Input Increment X-Axis: 0.001 mm Input Increment Y-Axis: 0.001 mm Input Increment Z-Axis: 0.001 mm Positioning Accuracy X-Axis: 0.01 mm Positioning Accuracy Y-Axis: 0.01 mm Positioning Accuracy Z-Axis: 0.01 mm Iaodpfjy Ni Aaex Ab Njt Tool Holder: SK 40 NC Rotary Table Clamping Surface Diameter: 630 mm Max. Table Rotation Speed: 10.7 rpm Table Feed Rate: 3,600 /min Table Scale Resolution: 0.001 MACHINE DETAILS Control Manufacturer: Heidenhain Recorded Spindle Hours: 18,391 h Operating Voltage: 400 V Frequency: 50 Hz Rated Current: 80 A Connected Load: 44 kVA Dimensions & Weight Dimensions (L x W x H): 5,500 x 4,500 x 2,500 mm Machine Weight: 10,000 kg EQUIPMENT 60-station tool changer Chip conveyor Cooling system

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 540 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 32 m/min, feed rate X-axis: 32 m/min, feed rate Y-axis: 32 m/min, feed rate Z-axis: 32 m/min, controller manufacturer: Okuma, controller model: OSP P200M-H, rotary table diameter: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Okuma MU500VA CNC Vertical Machining Centre (2007) Equipped with OKUMA OSP P200M-H CNC CONTROL 20" ROTARY PLATEN 4TH AND 5TH AXIS BUILT IN TRUNION 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE TOOL LENGTH MEASURING Travels X-axis (saddle left/right) – 1250mm, Y-axis (pallet front/back) – 660mm, Z-axis (spindle up/down) – 540mm, A-axis – +20~-110 deg., C-axis – 360 deg., Table surface to spindle nose – 127~667mm Table Table size – ø500mm, Max work size – ø730xh500, Floor to table top – 1073mm, Max load capacity – 500kg Spindle Spindle speed – 15000rpm, Turning specification – C-axis table 1000rpm , No. of spindle ranges – Infinitely variable, Tapered bore – 7/24 taper No.40, Bearing dia – ø70mm Feed Rapid traverse – X-Y: 40m/min, Z:32m/min, Rapid traverse (A-C) – 18,000 deg/min, Cutting feed rate – X-Y-Z: 32m/min Motors Spindle (10min/cont) – 11/7.5kW Ijdpfoyf Ncqjx Ab Neat ATC Tool shank type – MAS BT40 Big plus, Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random ATC Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain 430, workpiece weight (max.): 800 kg, The machine was recently inspected by a technician, and the following minor repairs were carried out: New cable routing, replacement of the display, and replacement of the sensor cable for the tool changer. TECHNICAL DETAILS Travel range X-axis: 800 mm Travel range Y-axis: 700 mm Travel range Z-axis: 600 mm Iasdpfx Ajy Szq Ueb Njt B-axis: Automatic swivel milling head C-axis: NC rotary table (dimensions: 900 x 630 mm) Tool holder: SK40 Number of tool changer positions: 60 Maximum workpiece weight: 800 kg MACHINE DETAILS Control model: Heidenhain 430 EQUIPMENT Chip conveyor Internal cooling system (40 bar operating pressure) Handwheel Heidenhain TS 642 probe

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 15025703124, Used 5-axis machining centre with double table Manufacturer: DECKEL MAHO Ijdpfx Absyk S Hpe Njat Model: DMU 70VL Year of manufacture: 2001

Condition: used, Year of construction: 2003, functionality: fully functional, travel distance X-axis: 3,200 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 115 mm, feed length X-axis: 3,200 mm, feed length Y-axis: 150 mm, feed length Z-axis: 115 mm, spindle speed (max.): 18,000 rpm, We offer this used Tekna 426 universal machining center, year of manufacture 2003. Manufacturer: Tekna Model: 426 Year: 2003 Machining range: X-axis: 3200 mm Y-axis: 150 mm Z-axis: 115 mm C-axis: -90° to +90° Iaodpfx Abjyzfc Tj Nst The machine is currently operational. Various spare parts are included. If you have any questions or require more information, please feel free to send us a message or give us a call.

Condition: not inspected (used), Year of construction: 1986, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, overall weight: 6,000 kg, Heidenhain TNC 426 900x700 mm universal table Travel: 850x700x600 mm Ijdpfeyt Nxuex Ab Neat Max spindle speed: 6000 rpm Weight: 6000 kg

Condition: used, Year of construction: 2005, travel distance X-axis: 730 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 560 mm, table width: 500 mm, table height: 500 mm, spindle speed (min.): 10,000 rpm, We can offer you a 5-axis Mazak Variaxis 730-5X with Palletech system. Iedpfoy Ryylex Ab Njat Technical data: Maximum workpiece diameter x maximum workpiece height: 730 x 500 mm Pallet size: 500 x 500 mm Number of pallets: 12 (Palletech High-rise) X-axis travel: 730 mm Y-axis travel: 850 mm Z-axis travel: 560 mm A-axis (table tilt): +30/-120° C-axis (table rotation): 360° (indexing 0.001°) Spindle speed: 35–10,000 rpm Spindle motor: 30/22 kW Tool changer: 120 Tool type: BT 50 If you have any questions about the machine or would like to schedule an inspection, please do not hesitate to contact us by phone or email.

Condition: used, Year of construction: 2018, x-travel 750 mm y-travel 660 mm z-travel 650 mm Control Siemens spindle tunring speed 12.000 U/min tool taper HSK 63 The machine was used for machining aluminum and, in our assessment, is in good Iodeyrt A Iepfx Ab Njat used condition. It can be inspected under power by appointment. Technical features & accessories: - Twin spindle - 5-axis - Pallet changer Accessories, tools, and clamping devices shown are only included if explicitly stated in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2010, x-travel 500 mm y-travel 700 mm z-travel 500 mm A-axis 240 (-120/+120) ° C-Axis 360 ° control Siemens 840 D faceplate diameter 440 mm T-slot - width 14 mm T-slot - distance 75 mm max. table load 400 kg max. turning speeds 20.000 min/-1 tool taper HSK 63 A workpiece length 330 mm tool diameter 125 mm change-time chip to chip 4,5 sec weight of the machine ca. 10,5 t dimensions of the machine ca. 2,5 x 5,2 x 3,5 m In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories: - Kuka KR200-3 comp Robot Three identical machines are available. Iaodpfexq R E Nsx Ab Net Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: ready for operation (used), Year of construction: 2003, Immediately available ex works: 5-axis (3 plus 2) machining centre Deckel Maho Type DMU 35 M Year of manufacture: 2003 Siemens 810 D control Electronic handwheel Universal tilting/rotary table 400 x 290 mm Travel X/Y/Z: 350/240/340 mm Spindle taper SK 40 Spindle speeds: 20 – 6300 rpm Drive: 6.3/10 kW Table load: 100 kg Ijdjy R N U Sopfx Ab Nsat Rotation range: 360 degrees Swivel range: plus 105 / minus 15 degrees Distance spindle nose – table: 145/485 mm Feed rates up to 3000 mm/min Weight: 1750 kg Price: Euro 4,500.—plus VAT ex location

Condition: ready for operation (used), Year of construction: 2001, Immediately available ex-site: 5-Axis Machining Centre Deckel Maho Model: DMU 50 M Year of manufacture: 2001 Control system: Heidenhain TNC 124 5 axes (3 + 2) Manual rotary axes with B and C swivel rotary table B and C axes are displayed on the control Table size: 700 x 500 mm Isdpjy R N Uxjfx Ab Noat Travel paths X/Y/Z: 500 / 400 / 400 mm Table load capacity: 200 kg Spindle taper: SK 40 Spindle speeds: 20 – 4,500 rpm Drive power: 9 / 13 kW C-axis rotation range: 360 degrees Swivel range: plus 95 / minus 10 degrees Feed rate up to 5,000 mm/min Spindle speeds: 20 – 4,500 rpm Weight: 3 tonnes Coolant system Price: EUR 8,500.— net, ex-site, plus VAT.

Condition: used, Year of construction: 2014, x-travel 600 mm y-travel 500 mm z-travel 500 mm total power requirement --- kW weight of the machine ca. 9,6 t dimensions of the machine ca. --- m Iodeycxinspfx Ab Njat

Condition: used, Year of construction: 2014, x-travel 400 mm y-travel 400 mm z-travel 375 mm Iodpfjycxihsx Ab Neat total power requirement --- kW weight of the machine ca. 7,6 t dimensions of the machine ca. --- m

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, We offer you the following: Manufacturer: DMG MORI Model: DMU 50 3rd Generation Year of manufacture: 2019 Control system: Heidenhain TNC 640 Technical specifications: Travel distances: X-axis: 650 mm Y-axis: 520 mm Z-axis: 475 mm B-axis: -35 to +110° Ijdpjy Rx Stjfx Ab Njat C-axis: 360° Main spindle: Speed range: 0 – 20,000 rpm Drive power – main spindle (100/40%): 35 / 25 kW Torque: 130 / 86 Nm Worktable: Swivel rotary table, simultaneous operation: D 650 x 500 mm Tool changer: Tool holder: CAT 40 (conversion to SK 40 possible) Number of tool stations: 60 positions Operating hours: approx. 13,500 h Spindle hours: approx. 5,300 h Technical features & accessories: - Active spindle cooling - Direct position measuring system in X, Y, Z, B, C - Scraper-type chip conveyor - Internal coolant supply (ICS) 40/80 bar, consisting of: - Paper band filter - 980 l tank - Cabin roof - Rotary union in the spindle - Blowing air through the spindle center - Dual switch filter - Rotating inspection window - Rinsing gun for chip flushing - Oil and emulsion mist separator - Infrared measuring probe, make: Renishaw PP 60 optical (OMP 60) - Tool breakage control IRS2 - Preparation for 3D quickSET - MPC (Machine Protection Control) - Operating mode 4 - Coolant temperature control for ICS system Accessories, depicted tools, and clamping devices are only included in delivery if specified in the additional information. Subject to change and error in technical data and information as well as prior sale!

Condition: as good as new (ex-display), Year of construction: 2025, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,400 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, workpiece weight (max.): 6,000 kg, rotational speed (max.): 10,000 rpm, tool length: 800 mm, New machine HDC3000 with 6 axes • Travel ranges: X=3000 mm, Y=1500 mm, Z=1400 mm • Heidenhain iTNC 640 with handwheel • NC rotary table for 5-sided machining 1250 mm x 1600 mm • 2-axis NC universal drilling and milling head, fully simultaneous and positioning operation • Spindle 10,000 rpm HSK100, S1=220 Nm spindle torque • Tool change system HSK100 / 60 stations – 800 mm tool length • Chip conveyor • Optimized for 5-sided machining including deep hole drilling • Coolant supply system • Internal/external air blow-off device • ICS 60 bar for deep hole machining • Fully enclosed • Large interference circle 2300 mm Ijdpfjy Sl Ecsx Ab Neat • Including mounts • Including wash gun • Including warranty • Short delivery time, subject to prior sale

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, controller manufacturer: Heidenhain, Equipment: chip conveyor, rotational speed infinitely variable, DMU 75 monoBLOCK Year of manufacture: 2018 Control: Heidenhain TNC 640 Celos Axes: 5 simultaneous Main spindle Model: Speedmaster Speed: 20 – 20,000 rpm Tool changer Type: Chain magazine with double gripper Positions: 60 Travel distances X: 750 mm Y: 650 mm Z: 560 mm Ijdpey St Swsfx Ab Neat Equipment Oil mist extraction Rinsing gun Operating mode 4 Electronic handwheel IKZ 40 bar with belt and cartridge filter 3D measuring probe Chip conveyor

Condition: used, Year of construction: 2018, functionality: fully functional, travel distance X-axis: 1,520 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, rapid traverse X-axis: 32 m/min, rapid traverse Y-axis: 32 m/min, rapid traverse Z-axis: 32 m/min, controller manufacturer: SIEMENS, controller model: 840D, rotational speed (max.): 12,000 rpm, overall weight: 10,000 kg, spindle speed (max.): 12,000 rpm, spindle nose: ISO 40, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Year: 2018, CE compliant CNC: SIEMENS 840D with SHOP MILL 4+1 axes ONLY 18,300 power-on hours Worktable dimensions: 2-piece table - fixed 920x540 mm / rotary-tilting 650x500 mm (with extension ring) Longitudinal X-axis travel: 1520 mm Transversal Y-axis travel: 520 mm Vertical Z-axis travel: 420 mm Spindle taper type: ISO 40 Spindle speed: 12,000 rpm Automatic tool changer: 32 positions Spindle motor power: 15 kW Approximate net weight: 10,000 kg Accessories: Internal coolant Chip conveyor Full upper enclosure Pneumatic door opening BLUM tool presetting and workpiece probe capability Iasdpfjy Azcljx Ab Not

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Deckel Maho DMU 50 evo Linear with Heidenhain TNC 530 Control – TOP Condition Technical Data: >> Year of manufacture: 2006 >> Control: Heidenhain iTNC 530 >> Travel (X/Y/Z): 500 / 450 / 400 mm >> C-axis: 360 degrees >> B-axis: 0 to 161.955 degrees >> Tool holder: HSK A63 >> Max. spindle speed: up to 18,000 rpm >> Feed rate steplessly programmable in X, Y, Z: up to 20,000 mm/min C and B axes steplessly programmable up to rapid traverse speed >> Rapid traverse Y/Z axes: 50 m/min X-axis: 80 m/min (linear drive) B-axis: 40 rpm C-axis: 50 rpm >> Tool magazine: double gripper, 60 tool positions >> Clamping surface: Ø 500 x 380 mm Distance between T-slots: 63 / 14H7 >> Table load: 200 kg >> Dimensions and weight (approx.): Machine without control panel and accessories Depth: 3.0 m, Width: 2.4 m, Height: 2.6 m Weight: approx. 7,000 kg >> Operating voltage: 400 V >> Electronic handwheel: Heidenhain HR 410 >> Power connection: 17 kVA >> Chip conveyor >> Active spindle cooling >> Mist extraction unit >> High-pressure coolant supply (IKZ) 40 bar Iaodpfoy R Dgpex Ab Not >> Coolant purification system (fleece filter system) >> Rinse gun >> Visiport >> Measuring system with air purge >> Prepared for robot loading >> 3D probe Heidenhain TS640 >> 3D Quick Set >> Kinematics >> Blum laser for tool measurement and breakage control >> Complete documentation The following works have been carried out: >> Main spindle completely overhauled >> Complete maintenance: all cooling and pneumatic hoses replaced, new filters, fluids and belts replaced. Scrapers etc. fully cleaned. >> Geometrically measured (acceptance protocol available) About the machine: For sale is a Deckel Maho DMU 50 evo Linear machining center with Heidenhain TNC 530 3D path control. The machine is in excellent condition. The main spindle has been overhauled (exchange spindle), fully serviced, and an acceptance protocol is available. Invoices for the overhaul totaling €42,000 (net) are available. You are welcome to view and test the machine under power at our premises.

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 464-61, controller manufacturer: Siemens, controller model: Sinumerik, workpiece length (max.): 300 mm, workpiece diameter (max.): 200 mm, total height: 2,400 mm, total length: 3,200 mm, total width: 2,000 mm, overall weight: 22,000 kg, spindle nose: HSK-A32, number of slots in tool magazine: 12, mount diameter: 32 mm, tool length: 160 mm, tool diameter: 63 mm, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Very well-maintained machine from training workshop and demonstration. Fully functional and immediately ready for use. Equipped with NC indexing device, manufacturer: PEISELER, type: AWUP 100. Includes comprehensive machine documentation as well as 2 spare filters. Iedpfey Sghlex Ab Noat

Condition: not inspected (used), Year of construction: 2003, functionality: unexamined, machine/vehicle number: 182.012, controller model: Siemens Sinumerik 840D, total height: 2,900 mm, total length: 6,000 mm, total width: 2,700 mm, overall weight: 8,000 kg, input voltage: 400 V, Equipment: chip conveyor, rotational speed infinitely variable, This is an untested machine. Due to the partially dismantled enclosure, the machine is offered exclusively as a source of spare parts. Configuration Iedpey Sgb Esfx Ab Neat Siemens CNC control Automatic tool changer Chip conveyor Coolant lubrication system

Condition: used, Year of construction: 2012, x-travel 850 mm y-travel 700 mm Iedpfsyxy E Rox Ab Nsat z-travel 500 mm Control Siemens 840 D rotary table 800 mm c-axis 0.001º ( ±360º) 0 B-axis (table) º mm number of spindle speeds 18.000 U/min/rpm tool taper HSK 63 Tools changer 38 fach/tools Internal cooling system 80 bar total power requirement 43 kVA weight of the machine ca. 10,6 t Equipment- Paper belt filter – 200 l tank- Active control cabinet cooling- Infrared probe M&H (Heidenhain)- Laser tool measuring system Blum- Chip conveyor- Cleaning pistol with pump 2 bar / 40 l min- 3D Quick Set- Electronic handwheel

Condition: used, Year of construction: 2014, operating hours: 14,950 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Exclusive use in plastics processing – no heavy-duty machining, no steel, stainless steel, or titanium processing; resulting in reduced wear on the spindle, guides, ball screws, and rotary axes. Technical data: Control: Heidenhain iTNC 530 HSCI Travel distances: - X-axis travel: 600 mm - Y-axis travel: 500 mm Iajdpfxey Smm Ue Ab Net - Z-axis travel: 500 mm Main spindle: - Speed range: 20 – 18,000 rpm NC rotary table: - Table clamping surface: 600 x 500 mm - Loading capacity: 400 kg - B-axis: -5° to +110° - C-axis: 360° Tool holder: HSK-A63 Chip conveyor: not shown, but available. Operating hours: approx. 50,320 h Spindle hours: approx. 14,950 h
