Used Scm Wide-Belt Sander for sale (16,658)

Condition: used, SCM Sandya 10 RCS 110 Wide Belt Sander / Calibrating Sander Lhodpfez H Tpgex Amzon Specifications: Manufacturer: SCM Group, Italy Model: Sandya 10 RCS 110 Serial no.: AE/018941 Year: 1999 Working width: 1100 mm Working height: 3–160 mm 2 units: calibrating roller + roller with sanding pad Pneumatic belt oscillation Motorised thickness adjustment with digital display 2 feed belt speeds Ammeter Power supply: 400 V, 50 Hz, 3-phase Rated current: 32 A Compressed air: max. 6 bar Weight: 1584 kg

Condition: used, total width: 2,200 mm, total height: 2,680 mm, total length: 2,200 mm, Year of manufacture: 1999 Colour: Grey Empty weight: 1.900 kg Wide belt sander SCM Sandya 10S M2 110 Built in 1999 Sanding belt dimensions 2620x1115mm 380V 1st sanding unit Contact roll 180mm Engine 18.5kW 2nd sanding unit Combi aggregate with sanding pad Engine 11kW Sanding width max 1100mm Lodpfx Amez R A U Uozshn Sanding height Min/max 4/170mm Throughput speed 4.5-9 m/mins Dimensions 2300x2205x2500mm, weight 1850kg - Year: 1999 - CE marking present: Yes - Serial number: 101513 - Number of units [pcs]: 2 - └ Unit 1: - - Position: Bottom - - Type of unit: Contact roller - - Sanding belt length [mm]: 2500 - - Sanding belt width [mm]: 1100 - - Roller diameter [mm]: 180 - - Roller material: Rubber - - Motor power [kW]: 18.5 - └ Unit 2: - - Position: Bottom - - Type of unit: Combi - - Sanding belt length [mm]: 2620 - - Sanding belt width [mm]: 1115 - - Roller diameter [mm]: 180 - - Roller material: Steel - - Motor power [kW]: 11 - Max. working width [mm]: 1100 - Min. working height [mm]: 4 - Max. working height [mm]: 170 - Infeed table length [mm]: 350 - Outfeed table length [mm]: 375 - Feed motor [kW]: 1.5 - Min. feed speed [m/min]: 4.5 - Max. feed speed [m/min]: 9 - Voltage [V]: 400 - Current consumption [A]: 35 - Fuse [A]: 63 - Power [kW]: 10.0 - Transport dimensions: 2200mm x 2200mm x 2680mm (l x w x h) - Transport weight [kg]: 1900kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), CATALOGUE NUMBER 8021 TECHNICAL DATA - max. width of workpiece 1100mm - max. height of workpiece 150mm 2 units: 1) ribbed rubber roller for calibrating 2) ribbed rubber roller - motor power 11kW - brake - from above: - metal, sliding, split roller - pressure roller - unit - pressure roller - unit - pressure roller - cleaning brush - from below: - 2 metal, sliding rollers - conveyor belt - 2 metal, sliding rollers, output - new conveyor belt - pneumatic belt oscillation - electric table lifting - stepless feed rate adjustment - feed motor 1.5kW - grinding thickness potentiometer Lhsdpsztaqajfx Amzsn - working pressure 8-10 bar - diameter of dust extraction port 3x165mm, 1x140mm - overall dimensions L/W/H 1870x1850x2210mm - weight 2165kg ADVANTAGES – Made in Italy, SCM brand – new conveyor belt – 2 units – grinding thickness potentiometer – unpainted – used sander, very good condition Net price: 26900 PLN Net price: 6255 EUR, depending on the exchange rate of 4.30 EUR (Prices may vary due to higher fluctuations)

Condition: used, Technical data: Working width: 910 mm 1 sanding unit Roller diameter: 300 mm Workpiece height: 160 mm Extraction port diameter: 160 mm Electric height adjustment Analog height indicator Main motor power: 9 kW Voltage: 380 V Overall dimensions: Length: 1800 mm Width: 1500 mm Lhsdpfxezu An Ro Amzjn Height: 2150 mm

Condition: used, Year of construction: 2001, Number of belts: 2 pcs. Max. working width: 1100 mm Lhodpfxsz R Duvo Amzon Min. working height: 4 mm Max. working height: 170 mm 1st belt: Calibrating roller Abrasive belt length, 1st unit: 1900 mm Abrasive belt width, 1st unit: 1115 mm 2nd belt: Combination unit Abrasive belt length, 2nd unit: 1900 mm Abrasive belt width, 2nd unit: 1115 mm Material thickness measuring device: Yes Fixed feed rate: 4.5/9 m/min Control: Hand-operated control panel Belt oscillation: Yes Infeed height: Variable (lower table moves) Table stroke: Electro-motorized Table display: Digital Operating pressure: 6 bar Approximate weight: 1207 kg Motor power: 15 kW Dust extraction diameter: 2x160 mm Location:

Condition: ready for operation (used), functionality: fully functional, working width 950 mm calibrating unit with metallic roller combination unit with rubber roller and automatically engaged shoe star-delta start pneumatic oscillation controlled by photocells two conveyor feed speeds motor power 11 kW year of manufacture 2000 power supply 400V Ledpfezz Nkrex Amzehn weight 975 kg

Condition: excellent (used), functionality: fully functional, Working width: 900mm Steel calibrating roller Combination unit with a rubber roller Lhedezxp Npopfx Amzsn Motor power: 11kW Pneumatic shoe adjustment Pneumatic oscillation with a photocell Element thickness gauge Electric table adjustment Star/Delta start-up Power supply: 380V

Condition: excellent (used), SCM SANDYA uno wide-belt sander sanding width 900 mm, 1 combination sanding head with a metal roller, base 7.5 kW motor, star/delta starter, two feed speed settings, electric table adjustment, digital display of table position, oscillation the sander is in very good condition, ready for operation, machine dimensions: width 150 cm, length 160 cm, height 180 cm, weight approx. 750 kg. Lsdpfx Amsy S Rxbszohn

Condition: excellent (used), CATALOGUE NUMBER 8046 Technical specifications: - max width of the workpiece 900mm - max height of the workpiece 160mm 2 units: 1) ribbed rubber roller for calibrating 2) rubber roller + shoe + metal roller – from above: - slipping rubber roller I unit - 2 x slipping rubber rollers II unit - slipping rubber roller, smooth – from below: - conveyor belt - pneumatic belt oscillation - 2 types of feed speed 0.55kW - electric table lifting - main motor 7.5kW - operating pressure 6-8 bar - diameter of the dust extraction port 2x160mm - dimensions L/W/H 1300x1500x1950mm - weight 1100kg Advantages: – Italian-made, – unpainted – used grinder, very good condition Net price: 28900 PLN Net price: 6720 EUR, depending on the exchange rate of 4.30 EUR Ledpszx Rzyefx Amzehn (Prices may vary due to higher fluctuations)

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: AB00016224, overall weight: 1,672 kg, type of input current: three-phase, workpiece height (max.): 170 mm, input frequency: 50 Hz, input current: 40 A, input voltage: 400 V, workpiece width (max.): 1,100 mm, Equipment: double-sided, Machine in excellent condition. Vacuum table included. For sale due to new acquisition. Lhodpfoz Rzyvex Amzon

Condition: excellent (used), functionality: fully functional, working width 950 mm calibrating unit with metal roller combination unit with rubber roller and automatically adjusted sanding pad star-delta start pneumatic oscillation controlled by photocells two feed speeds of the conveyor motor power 7.5 kW year of manufacture 2000 power supply 400V Ljdpfx Amoz D Ackjzshn weight 976 kg

Condition: good (used), WIDE BELT SANDER SCM Sandya 10 Sanding width 1100 mm First unit with hard rubber calibrating roller Second combination unit with soft rubber roller and pad Single motor for both units - 18.5 kW Pneumatic oscillation Adjustable feed speed Electric table adjustment Ledpfx Amjyy Nnkszshn Table position display Thickness gauge Good condition, tested and ready for demonstration

Condition: excellent (used), functionality: fully functional, working width 1350 mm, calibration unit with metal roller, combination unit with two rubber rollers and multi-segment pad, oscillation by photocells, machine function activation from control panel, belt blow-off, stepless feed speed regulation for sanding belt on 2nd unit, pneumatically controlled multi-segment pad with adjustment, year of manufacture 2007, electric table adjustment, material thickness gauge, vacuum under-table. Lhsdpfx Amezz Nmmjzon

Condition: used, Wide Belt Sander SCM UNO RCS - used - Combination unit with contact roller and sanding pad, contact roller made of steel, rubber-coated contact roller, sanding belt oscillation, infeed and outfeed table extension. ----- Technical Specifications ----- Working width: 920 mm Number of belts: 2 units Sanding belt size: 930 x 1,525 mm Feed speed: 4.5 / 9 m/min Max. workpiece thickness: 160 mm Min. workpiece thickness: 3 mm Extraction port Ø: 2x160 mm Motor power: 11 kW Dimensions (LxWxH): 1,700 x 1,480 x 1,600 mm Weight: 1,175 kg Lsdpfxjy Dhude Amzohn

Condition: used, Year of construction: 2018, total width: 1,899 mm, total height: 2,264 mm, total length: 2,580 mm, working width: 1,350 mm, grinding width: 1,370 mm, overall weight: 1,890 kg, table height: 900 mm, Wide-belt sanding machine Manufacturer: SCM GROUP spa Brand: Casadei Type: Libra 55 RTC 135 Year of manufacture: 2018 Weight: 1,890 kg Technical specifications: Max. working width: 1,350 mm Working height (adjustable table): 4 to 170 mm Working height (optional fixed table): 4 to 200 mm Sanding belt width: 1,370 mm Sanding belt length: 2,620 mm Feed rate: 3 stages: 4, 5, and 9 m/min Power of feed motor: 0.45 / 0.8 kW Power of main motor: 11 kW (15 hp) Purchase price net: €30,000 plus applicable VAT. VAT will be shown separately on our invoice. Lhedpfx Aoz Ippxemzen Note: The equipment text or equipment description is taken from the original purchase invoice and has not been checked for accuracy or completeness. Deviations are possible! Financing available Upon request, we can arrange suitable financing through our company. Please feel free to contact us. Subject to changes, errors and prior sale.

Condition: excellent (used), Year of construction: 2001, Device description: working width 950 mm calibrating unit with a metal roller combined unit with a rubber roller and a shoe pneumatically adjustable shoe star-delta starter pneumatic oscillation controlled by photocells two feed speeds for the conveyor engine power 11 kW year of manufacture 2001 Lhjdjzxzg Hspfx Amzon power supply 400V weight 975 kg

Condition: used, Year of construction: 1995, Number of belts: 2 Max. working width: 920 mm Min. working height: 3 mm Max. working height: 160 mm 1st belt: Calibrating roller Design of 1st roller: Grooved steel roller Abrasive belt length 1st unit: 1525 mm Abrasive belt width 1st unit: 930 mm Abrasive belt speed 1st unit: 16 m/sec 2nd belt: Combination unit Design of 2nd roller: Grooved rubber roller Sanding shoe 2nd unit: rigid Abrasive belt length 2nd unit: 1525 mm Abrasive belt width 2nd unit: 930 mm Abrasive belt speed 2nd unit: 16 m/sec Material thickness measuring device: Yes Fixed feed rate: 4.5 + 9 m/min Lsdszxt Agepfx Amzjhn Control: Hand control panel Elec./pneumatic belt oscillation: Yes Infeed height: variable (lower table moves) Table stroke: electro-motoric Table display: mechanical digital display Operating pressure: 6 bar Weight approx.: 1100 kg Motor power: 11 kW Extraction diameter: 200 mm Storage location:

Condition: like new (used), Year of construction: 2021, operating hours: 30 h, functionality: fully functional, machine/vehicle number: AE00002612, grinding width: 1,350 mm, overall weight: 6,250 kg, grinding height: 170 mm, working height: 170 mm, table height: 900 mm, workpiece height (max.): 170 mm, The machine has only been in use for a few hours and is practically brand new. It is in perfect working order. See below for the full specifications: DMC system T5C 1350 PF170-4M Lifting unit for a fixed work table, 900 mm from the ground * Working thickness: 3 to 170 mm BL 16 Infeed panel with reading bar for 'epics' sectioned pads, pitch 16 mm, or with PWM3 POSITION 01 TIE-5000 Working unit for an extractable internal cross pad PE 16T 'EPICS' sectioned electronic sanding pad, pitch 16 mm Working pressure control of the sectioned pad via the Pro-Sand control system Motor driven by an inverter, power up to 15 kW POSITION 02 DO 19 Oscillating unit fitted with 19 rotating 125 mm disc brushes 1.1 kW main motor driven by an inverter Independent motor for controlling the oscillating movement Electronic auto-set for the unit Sliding movement with motor driven by an inverter POSITION 03 BF 300 Working unit for a brush roller, diameter 300 mm 4 kW main motor driven by an inverter Double rotating direction of the brushing roller Electronic auto-set for the brush roller Side oscillation of the brush roller POSITION 04 BF 300 Working unit for a brush roller, diameter 300 mm 4 kW main motor driven by an inverter Double rotating direction of the brushing roller Electronic auto-set for the brush roller Side oscillation of the brush roller POSITION 05 SC-2620 Operating unit for a superfinishing pad Lodezcmcvepfx Amzshn Sanding belt rotation against the conveyor feed direction Electronic sanding belt swing control Disc brake ◦ Chevron belt dimensions: 1370 x 2186 mm ◦ Sanding belt dimensions: 1370 x 2620 mm PE 16/C 'EPICS' sectioned electronic sanding pad, pitch 16 mm 16 mm center-to-center distance of sectors Double-action pneumatic cylinders with adjustable push/counter-push Graphite cloth with quick extraction device Total management of its functionality by the "Pro-Sand" electronic control Working pressure management of sectioned pad via the Pro-Sand control system Timed oscillating clearing blowers 15 kW motor driven by an inverter OUTSIDE THE MACHINE SB/U 200 Outfeed working unit for abrasive cloth-coated rollers, diameter 200 mm Roller rotation against the conveyor feed direction / Manual adjustment of the roller working position / Abrasive cloth-coated roller, diameter 200 mm, 'Ultra Fine' type with silicon carbide fibers / 2.2 kW motor / Side oscillation of the brush roller OTHER DEVICES Perforated worktop and conveyor belt with a vacuum motor powered by an inverter up to 7.5 kW, integrated into the machine frame Front supporting worktop equipped with five idler rollers Rear supporting worktop equipped with five idler rollers 4 kW feed belt motor driven by an inverter Console with integrated PC "eye-M" and "Maestro Pro-Sand" electronic control with Tele Service system 1999 working programs / Virtual keyboard for fast settings of the machine / Production report / Interactive trouble-shooting program and self-diagnosis of the electronic cards / Display of electric and pneumatic diagrams / Display of the user manual, spare parts catalog, electric and pneumatic diagrams Vision panel door positioned on the service side Internal LED lighting for the machine

Condition: repair required (used), Year of construction: 1996, MACHINING CAPACITIES: - Height (thickness): 3 to 160 mm - Maximum workpiece width: 1100 mm - Minimum workpiece length: 390 mm - Abrasive belt speed: 18 m/s - Conveyor feed speed: 4.5 – 9 m/min - Suitable belt dimensions: 2150 x 1115 mm MACHINE CONFIGURATION: Lhedjy I Srzopfx Amzon - 4 infeed rollers and 4 outfeed rollers - Table positioning with sensor - Vacuum conveyor system (perforated belt and motorized fan) - Pneumatic foot switch 1) Calibration 2) Calibration / sanding 3) Finishing sanding MACHINE SPECIFICATIONS: - Main power supply: 400V, three-phase, 50Hz - Automatic star-delta starter - Ammeter(s) for power consumption monitoring - Pneumatic tensioning, oscillation, and retraction of rollers - Pneumatic supply, working pressure: 6 bar - Dust extraction, 3 upper ports, Ø mm Recommended air flow: 2500 m³/h per hood Note: For optimal performance, please ensure that sanding belts are released when the machine is not in use, and avoid any moisture, including condensation, inside your facility during winter. Machine dimensions: 1920 x 2050 x h.2240 mm

Condition: good (used), Code: 0483 Brand: SCM Model: SANDYA UNO CCS Automatic compact 2-belt wide belt sander for furniture, custom-made furnishings, fixtures, doors, panels, composite materials and various Lsdoz Er Swopfx Amzehn Composition: 1° Group: Calibrating roller 2° Group: Combined Rubber Roller / Finishing Pad Automatic table lifting Working width mm 920 Working height mm 3 - 160 Abrasive belt dimensions mm 930 x 1525 Feed belt speed mt/min 4,5/9 Motor power Hp 10 Infeed and outfeed roller conveyors Automatic table positioning Oscillating belts Working pressure Atm 6 Exhaust hood diameter mm 160 Overall dimensions mm 1395 x 1110 x 1600 h Weight kg 1050 Overall dimensions mm 1395 x 1110 x 1600 h Weight kg 1050

Condition: like new (used), working width: 1100 mm unit with steel roller 2nd unit rubber with pad motor power: 11 kW oscillation via photocells 2 conveyor feed speeds pad automatically triggered with adjustment units switched on from the control panel material thickness sensor Lhodpfx Amezyaazozsn year of manufacture: 2002

Condition: used, Year of construction: 1989, With sanding units consisting of: - 1 calibration roller - 1 combination unit with rigid pad Lhodpey H N Taofx Amzsn Used Manufacturer: SCM Model: UNO C-CS Year of manufacture: 1989 Machine no.: AE005036 REF.: 030514 Sanding width: approx. 920 mm Pass-through height: approx. 3-160 mm Number of units: 2 pcs., 1x15 kW Units from above: 2 pcs Belt dimensions (L x W): 1525 x 930 mm 2x feed speed: 4.5 / 9.0 m/min 1 pc calibration roller - grooved / rubber-coated 1 pc combination unit with rigid sanding pad - rubber-coated roller Extraction connection: D 2 x 160 mm Required space: approx. 1600 x 1500 x 1800 mm Weight: approx. 1200 kg Location: 97447 Gerolzhofen, free loaded, unpacked Transfer in as-is condition as inspected, without warranty or guarantee

Condition: excellent (used), functionality: fully functional, Motor power 11 kW Lsdpfezz Nmyox Amzehn First calibration unit with steel roller Second unit with rubber roller Belt cleaning blow-off Working width 1100 mm Two feed speeds for sanding belts Stepless adjustable conveyor feed Electric table height adjustment Shoe with adjustable activation time Brush at workpiece outlet Pneumatic oscillation

Condition: new, Year of construction: 2023, functionality: fully functional, machine/vehicle number: AE00003735, overall weight: 4,300 kg, input frequency: 50 Hz, input current: 126 A, input voltage: 400 V, warranty duration: 12 months, Basic information Manufacturer: SCM Group / DMC Model: DMC Eurosystem M4 1350 Year of manufacture: 2023. Condition: unused, new Operating hours: 0 h Working width: 1.350 mm Working thickness: 3-200 mm Feed speed: 2-16 m/min Power supply: 400 V, three-phase, 50 Hz Rated current: 126 A Weight: approximately 4,300 kg Serial number: AE00003735 Location: Tenja, Croatia Availability: immediately Description; For sale is an unused SCM DMC Eurosystem M4 1350 automatic wide-belt sanding and calibrating machine, manufactured in 2023. The machine has never been used in production and has 0 operating hours. It is installed at our production facility and is available for inspection by prior appointment.   Working unit configuration 1st working position - sanding roller • R 320-2620 sanding unit • Roller diameter: 320 mm • R45 rubber-coated roller, 45 Shore hardness • 15 kW motor with frequency inverter • Oscillating abrasive-belt blowing and cleaning system 2nd working position - brush unit • BF 300 brush unit • SI 300-E helicoidal brush roller Lhedpezyghlofx Amzen • 3 kW motor with frequency inverter • Abrasive inserts, grit 180 and 240 • Automatic electronic brush position setting • Side oscillation and reversible brush-roller rotation 3rd working position - brush unit • BF 300 brush unit • SI 300-E helicoidal brush roller • 3 kW motor with frequency inverter • Abrasive inserts, grit 180 and 240 • Automatic electronic brush position setting • Side oscillation and reversible brush-roller rotation 4th working position - superfinishing sanding pad • S-2620 unit with superfinishing sanding pad • PE 32/L EPICS electronic sectional sanding pad • Segment pitch: 32 mm • 11 kW motor with frequency inverter • Electronic working-pressure control • Oscillating abrasive-belt blowing and cleaning system   Outfeed finishing unit • SB/U oscillating finishing unit • SB 200 UFC Ultra Fine brush roller • Silicon-carbide fibres • Rotating blowers for final workpiece cleaning Additional equipment • Fixed working height of 900 mm • BL 32 electronic infeed panel-reading bar • EPICS electronic sectional-pad system • Vacuum conveyor system with motor up to 7.5 kW • Perforated vacuum conveyor belt • Rubber-coated conveyor belt, 50 Shore hardness • 2.2 kW conveyor-belt drive motor • Front and rear roller support tables • Eye-M industrial PC • 21.5-inch Full HD touchscreen • Maestro Pro-Sand control software • Remote service capability • Operator interface in English and Croatian • CE-compliant version Inspection and terms of sale; The machine is available immediately and can be inspected by appointment at our production facility in Antunovac, Croatia. The machine is offered ex location. Dismantling, loading, transport and installation at the buyer's site will be agreed separately. All technical information is based on the original SCM quotation and the machine identification plate. The buyer may verify the specifications and condition during inspection. Additional photographs, videos, the original technical specification and the relevant SCM documentation are available to serious prospective buyers. Price; EUR 125,000 net, plus VAT - negotiable

Condition: excellent (used), Catalog number 8036 TECHNICAL DATA max. width of the workpiece 1100 mm max. height of the workpiece 170 mm 2 units: – from above: rubber roller, pressure roller, knurled 1) metal roller, knurled, for calibrating rubber roller, pressure roller 2) rubber roller, knurled + sequential shoe + metal roller rubber roller, pressure roller total power of the units 15 kW – from below: 2 rubber rollers, slip conveyor belt 2 rubber rollers, slip potentiometer for grinding thickness belt blowing pneumatic belt oscillation with photoelectric sensors electric table lifting + manual (for precise adjustment) 2 types of feed speed 0.3 kW with pneumatic brake operating pressure 6-8 bar diameter of the dust extraction nozzle 2x140 mm overall dimensions L/W/H 1840x1650x2000 mm weight 1160 kg – unpainted – made in Italy – automatic shoe – 2 units Lhedpfxezrnwlo Amzen – potentiometer for grinding thickness – DTR documentation – used grinder, very good condition Net price: 48900 PLN Net price: 11372 EUR, depending on the exchange rate of 4.30 EUR (Prices are subject to change due to higher fluctuations)
