Used Turret Lathe - Automatic for sale (26,916)

Condition: used, Automatic lathe Manufacturer: STROHM Model: M125 Isdpfx Aoyllr Ioi Rjtk

Condition: used, Year of construction: 1980, functionality: fully functional, machine/vehicle number: 24xx, For sale is a used but fully functional D6 with a turret; the machine was still in production up until it was shut down. The sale of the machine excludes any kind of guarantee or warranty! Sold as seen! Iedpfsx Nphcox Ai Rotk

Condition: used, Year of construction: 2009, functionality: fully functional, turning diameter: 50 mm, MIYANO ABX-51TH2 CNC Lathe, CNC automatic lathe MIYANO ABX-51TH2 FANUC Series 16i-TB (2009) Itjdexiv Elepfx Ai Rsk Turning diameter: 125 mm Bar diameter: 50 mm Chuck diameter: 150 mm X-1 axis travel: 190 mm Z-1 axis travel: 257 mm Y-1 axis travel: +/- 40 mm X-2 axis travel: 190 mm Z-2 axis travel: 500 mm X-3 axis travel: 190 mm Y-3 axis travel: +/- 40 mm Z-3 axis travel: 650 mm Spindle speed: 5000 rpm Bar pitch: 52 mm Main spindle motor: 15 kW Sub spindle motor: 11 kW Number of toolholder stations: 12+12 Automatic bar feeder LNS SPRINT 552-565 (2009) Currently still in use; selling only due to lack of space, as a larger machine will be arriving soon. Heinbuch heads (collets not included). Tooling shown in pictures not included.

Condition: good (used), Ward turret lathe Chuck diameter: 200 mm Turning diameter bed: 290 mm Support turning diameter: 170 mm Ijdpfxeq H Aqqs Ai Rotk Stroke: 185 mm Clearance: 32 mm Dimensions: 205x105x135 cm LxWxH

Condition: good (used), Year of construction: 1975, Turret lathe HESTIKA Type:HR42 built approx. 1975 Spindle capacity max : 42 mm with turret head and tool holder Multifix Type:B Spindle speed: 88 - 2800 rpm Collet chuck device, coolant device, machine documentation. Iodpjvgbqfsfx Ai Rstk Machine in good condition .

Condition: good (used), Year of construction: 1965, Turret lathe HESTIKA Type: HR32 built approx. 1965 Spindle capacity max: 32 mm with tool turret, collet chuck device, Spindle speed :200-3200 rpm with coolant device, machine documentation . Itodpfx Aievgbphs Rsk Good condition Ready for immediate use .

Condition: used, Technical details: spindle passage: 60 mm turning length: 45 mm turning diameter: max. 56 mm drill depth: max. 70 mm revolution per minute: 48 - 1500 (spindle) U/min Iodpfx Aisu Iwyis Rotk threading: Drehzahl: 24 - 750 U/min tool turret - number of stations: 8 total power requirement: 5,5 kW weight of the machine ca.: 2,4 t space requirement of the machine approx.: L:2,1x1,0x1,8 m Cam-controlled automatic lathe according to template. Workpiece is clamped via clamping cartridge. Turret head: disk turret Hahn&Tessky Esslingen, tool path 80mm, adjustment 36mm, distance collet/turret head min./max.: 72/188mm 2 pieces turning support, working stroke 45mm 2 piece cutting off support, working path approx. 40mm Cooling water system Machine is not connected. Sale at a low selling price. *

Condition: ready for operation (used), Machine in good operating condition Iodpsy Rnfvsfx Ai Retk

Condition: ready for operation (used), Machine in good operating condition Iedpfxoy Rnd Ej Ai Rotk

Condition: ready for operation (used), Machine in good operating condition. Itsdpsy Rnczofx Ai Rek

Condition: used, Year of construction: 1998, functionality: fully functional, We offer various lathes such as INDEX GS30, INDEX GSC42, cam-type automatics B and C, Mahr roundness measuring device, Mitutoyo profile projector ... Price on request. Itodjym Avmopfx Ai Rsk

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, WE OFFER AN VERY EXCELLENT CONDITION CNC LATHE PROTEO WITH TURNING MILLING INCLUDING BAR FEEDER BOSS 332 E YEAR:2013 NEW AND TOOLS -ACCESSORIESS MAX BAR 25mm Itjdpfevk R Sgex Ai Rjk FAGOR OPERATION CONTROLS

Condition: not inspected (used), Year of construction: 1994, operating hours: 8,000 h, functionality: unexamined, Machine in good condition Iedpfsv Im Sdsx Ai Retk

Condition: used, Technical details: table diameter: 4500 mm faceplate diameter: 4500 mm operating hours: 0 h swing diameter: 5000 mm turning diameter: 5000 mm workpiece height max.: 2500 mm control: Sinumerik 840D SL x-axis: 300 Hub/ram Slide mm x-axis: 2850 Hub / ram travel mm x-axis: 2850 working without tool mm x-axis: 5000 with tool changer mm w-axis: 1800 Querwegelevating cross rail mm tool holder / places: 12 tool taper: HSK 100 (spindle) workpiece weight: 100 t table speed: 1 - 50 U/min T-slots: 8 Stück (36 H12) stroke speed: fräsen ram speed: 4000 U/min rapid power traverse in X-and Z direction: 8000 mm/min Torque: fräsen: 100.000 Nm Torque: drehen: 200.000 Nm total power requirement: 80 (2x40) kW weight of the machine ca.: 140 t dimension machine approx.LxWxH: 11,5 x 6,6 x 8,4 m NEW CNC vertical turret lathe - manufactured upon official order and deposit. Iedsu Ix H Djpfx Ai Rstk The photos shown are of a newly built machine that we delivered to a customer. (The photos are for illustrative purposes only.) Application of the manufacturing processes: Turning, such as external longitudinal turning, internal and external facing and profile machining. Grooving, such as internal and external Drilling, such as short hole drilling and deep hole drilling Milling, such as face-corner profile and T-slot milling Thread cutting But also suitable for roughing and end machining. The machine bed, designed with a welded construction, absorbs extreme cutting forces. The table is made of high-strength meehanite cast iron. To withstand heavy loads, the part weight is supported by two high-precision tapered roller bearings. Furthermore, the table is equipped with hydrodynamic support for the workpiece. other features: automatic tool change jaw chuck (8 pieces with power clamping spindle and hardened jaws) incl. cooling system 40bar with filter unit hydraulic and lubrication equipment ATOS and Dropsa with measuring system of axes Heidenhain Renishaw NEW - with guarantee & service via WWM AG *

Condition: used, Year of construction: 2012, operating hours: 31,800 h, functionality: fully functional, CNC long-turn lathe Manufacturer: STAR Itodpfx Aiezu I Age Rjk Type: SR-32J Year of manufacture: 2012 with: FANUC 32i control system Back-end machining Synchronous spindle Powered tools C-axis Chip conveyor Parts conveyor belt Oil mist extraction system Fire extinguishing system Bar loader magazine FMB TURBO 3-36

Condition: used, Year of construction: 2000, faceplate diameter 3200 mm swing diameter 3500 mm turning height 2200 mm range L-W-H 7730 x 6240 x 6700 mm control Typ 840 D sl voltage 3 x 400 V frequency 50 Hz turning speeds 0,8 - 40 U/min max. turning diameter 3500 mm total power requirement 51 kW weight of the machine ca. 86 t Technical specifications Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ??ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm vertical supports Smallest axis distance between the vertical supports 470 mm Largest ram travel of the left vertical support 985 mm Largest ram travel of the right vertical support 985 mm Axis Feeds - Infinitely variable feed Max.: X1.2 3m/min max.: z1.2 2.5 m/min Plunger cannot be pivoted Support — crossbar Rapid feed of the cross beam 600 mm/min Larger distance of the cross beam to the faceplate 2,300 mm load sizes +Permissible turning force when turning workpieces with a turning diameter of 2,000 mm and a turning speed of 20 m/min. 8,000kg +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a turning speed of 20 m/min for all supports 45 mm² +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 2.5 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a turning speed of 20 m/min for all supports 120 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 22.5 mm² +Largest permitted workpiece weight at 0.8 - 3.15 rpm 17,500 kg +Largest permitted workpiece weight at 4 - 40 rpm 7,500 kg electric motors Main drive motor power and revolutions 51 kW Power of the feed motors of: - Vertical support beam (2 pieces) 16 Nm (gear 1:10) - Tappet (2 pieces) 16 Nm (gear 1:12) Power and revolutions of the drive motor of the hydraulic pumps (2 pieces) 3kW - 1,500 rpm Power and revolutions of the clamp hydraulic motor of the vertical support beam 1.5 kW - 1,500 rpm Iedpfx Aouddcgsi Retk Power and rotation for crossbar adjustment 15 kW - 1500 rpm 3.5 Information on the compressed air supply and other consumables Compressed air connection: 6 bar free of oil and water 3.6 Energy Consumption Conditions Voltage: 3 x 400V Control Voltage: 24V Frequency: 50Hz Fusing: 315 A Main dimensions and weight of the machine Length 7,730mm Width 6,240mm Height: 6,700mm Weight: 85,750 kg Tool: Capto 60 recording Not powered front panel Turning diameter of the front plate 3,200 mm Clamping disc diameter 3,400 mm Number of rotation levels of the front panel 3 (continuously adjustable) Front panel speed ranges 0.8 - 40 rpm Level I 0.8 - 3 rpm Level II 0.8 - 11 rpm Level III 0.8 - 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above ...

Condition: used, Year of construction: 1980, turning diameter 7000 mm faceplate diameter 3500 mm workpiece height 3000 mm 160 mm 1998 Control Siemens 840 C max. table load 60000 kg electr. connected load 400 V Serial number 11 33 0051 total power requirement 71 kW weight of the machine ca. / t required space 13 x 6 m The SCHIESS-FRORIEP 40 DV is a vertical lathe built in 1980. The machine was modernized and improved in 1998. Among other things, a driven tool system (C-axis) was installed. Itodpfx Aouddlzji Rek In addition, the control system was modernized to SIEMENS 840 C. The large open-sided vertical boring mills with travelling column - type DV - are particularly suited to situations where likely workpieces frequently change in diameter but where maximum workpiece dimensions are rare. Decisions in favour of this type of machine are generally due to minimum floor space requirement, universal adaptability and economical advantages. The modern design of these machines is characterized by rigid all-steel construction optimized by computer - SCHIESS can claim to have done much valuable pioneering work in this area of heavy-duty machine tool building.

Condition: used, Year of construction: 1962, faceplate diameter 2250 mm swing diameter 4500 mm turning height 2000 mm turning diameter 3150 mm Isdpfx Aisuc Alds Rjtk workpiece weight max. 25000 kg total power requirement 55 kW weight of the machine ca. ca. 32 t required space / m

Condition: excellent (used), Year of construction: 2016, operating hours: 15,000 h, functionality: fully functional, CNC long-turn lathe Manufacturer: STAR Type: SR-38 B Year of manufacture: 11/2016 with: FANUC 31i-B5 control system Synchronous spindle Powered tools X3-axis B-axis Itedpfxjzuwule Ai Rok Y2-axis Backworking capability Parts conveyor Fire extinguishing system Chip conveyor High-pressure pump Bar feeder magazine FMB LSK 38 Powered tools C-axis Backworking capability High-pressure pump Parts conveyor Chip conveyor Fire extinguishing system Bar feeder magazine FMB LSK 38 / 3200

Condition: good (used), Year of construction: 2006, functionality: fully functional, Max. machining diameter: 2,800 mm Min. machining diameter: 1,400 mm Max. machining height: 600 mm Itodpfx Aiszu Itro Rsk Max. workpiece weight: 5,000 kg Rotational speed of the chuck: 21–68 /min.

Condition: used, Year of construction: 1961, turning diameter Max. 4200 mm faceplate diameter 3700 mm turning height Max. 2600 mm workpiece weight Max. 35 t Power 80 PS DIGITAL CONTROL DISPLAY Largest diameter with the crossbeam supports: 4200mm Largest turning diameter with side support: 3900mm Largest turning height above faceplate: 2500 Side support 1 vertical grinding ram: 1200mm stroke (out of operation) 1 turning ram: 1400mm stroke Itjdpfsuddnvox Ai Rok

Condition: used, Year of construction: 1990, turning diameter 2400 mm faceplate diameter 2200 mm turning height 2100 mm control SIEMENS Sinumerik 850T workpiece weight 17 t Tol measurements 32 Werkzeuge Crossbeam travel: 700mm Crossbeam support Travel from centre of rotation to the right: 700mm Crossbeam support Travel from centre of rotation to the left: 700mm Machine table drive Main drive power: 80kW Number of gearboxes: 2 Step change: 3.84 Speed range of the 1st gear stage: 2-32-139 rpm Speed range of the 2nd gear stage: 9-125-500 rpm Max. Machine table load: 6 tonnes Feed drive Cross beam support Horizontal feed speed: 0.1 - 8 m/min Cross beam support Vertical feed speed: 0.1 - 8 m/min Cross beam support Rapid traverse speed horizontal/vertical: 8 m/min Cross beam adjustment speed: 425 mm/min Ijdpeygx D Hsfx Ai Rotk Tool system Tool system: 180.1 Cutting force on the turning tool: 30 kN

Condition: used, Year of construction: 1977, faceplate diameter 2500 mm swing diameter 2700 mm Itsdeuddpgspfx Ai Rjk turning height 2000 mm cross rail - adjustment 1500 mm workpiece weight max. 20.000 kg total power requirement 71 kW Control Siemens Sinumerik 840 Single-column vertical lathe 2000 x 2000mm Retrofit: 1997 Gr. turning diameter: 2700mm Gr. distance f. face plate to bottom of toolholder: 2150mm chisel holder: 2150mm Support swivelling up to 30° Chisel cross-section: 240x240mm small plunging diameter: 300mm Special equipment: Re-moulding, taper turning, thread cutting, constant cutting speed

Condition: used, Year of construction: 1990, Technical details: number of spindles: 8 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AFH130 with CNC Yob: 1990 eight-spindle automatic lathe 8 main spindles Chucker AFH130 for complete machining means front- and back side Control Siemens Sinumerik 840DI complete revising and new configuration of this machine in year 2010. loading arm, for loading and disloading Workpiece turn around station in pos. 4 position 4 with workpiece length control CNC compound slide in pos. 5 coolant pump with magnet candle filter delivered tooling: could be different like pictures option: Ergomat TBF42 for cutting off for half finnishing with FMB-Turbo Visiting under production condition is possible Please, contact us for getting more information and pictures on mail(at) or Isdezubyrepfx Ai Retk *

Condition: ready for operation (used), A CNC-controlled REM vertical lathe is available. Working diameter: 2500mm-7000mm, working height: 1000mm, control: Siemens 840D. Including driven tools. On-site inspection is possible. Isdpfx Ajvriq Dji Retk
