Used Weinig 5 Spindles Moulder for sale (65,522)

Condition: used, Technical specifications: Spindle diameter: 50 mm Replaceable spindle Spindle speed: 3/4.5/6/9 thousand RPM Spindle adjustment: up/down Starting method: star/delta Bdodpfx Aszilqwsphef Rotation direction: left/right Power supply: 380 V

Condition: used, Technical specifications: Spindle diameter: 35 mm Spindle height: 160 mm Speeds: 3000/4500/6000/8000/10000 rpm Bdedjzd Etuopfx Aphof Manual spindle height adjustment Manual spindle angle adjustment in the range of -5/+40 degrees Left/right rotation Spindle lock Dust extraction port diameter: 140/100 mm Work table dimensions: 850/1190 x 2500 mm Adjustable support arms Motor power: 5.5 kW Power supply: 380 V Overall dimensions: Length: 2600 mm Width: 1200/1540 mm Height: 1100 mm

Condition: excellent (used), functionality: fully functional, 5-spindles automatic planer with grooved table WEINIG PROFIMAT P 23 E with grooved plane ( removable ) second hand machine n.5 spindles working condition : Excellent CE mark : Yes volt. 380/50 grooved plane ( removable ) with tools : Yes , as in photos Composed by 5 spindles , 4 motors : 1° spindle : planer . motor power Hp 5,5 ( Kw 4 ) 2° and 3° spindles : right and left vertical . motor power Hp 10 ( Kw 7,5 ) 4° spindle : thickness planer . motor power Hp 7,5 ( Kw 5,5 ) 5° spindle : planer . motor power Hp 5,5 ( Kw 4 ) grooved plane ( removable ) Bdsdpfx Apezcx A Ishef Technical details : forward motor power Hp 4 ( Kw 3 ) spindle rotation speed rpm 6000 feed speed : from 5 to 24 mt./min max. useful working width mm. 230 max. useful working height mm. 120 shaft diameter mm.40 inlet length mm. 2000 lubrication system electric height adjustment set of service keys / documentation

Condition: excellent (used), Year of construction: 2008, machine/vehicle number: 0803024, functionality: fully functional, 4-SIDED PLANKER-MOULDER 5 REINFORCED MOTOR TOOL HOLDERS & 3.00 M CHROME TABLE Brand: LEADERMAC Type: SMARTMAC 523 Model: LMC-523SU Serial No.: 0803024 Year: 2008 (Photos taken before servicing & cleaning) MAKING CAPACITIES: - 4-sided planer and moulder - Max. cross-section: 130 x 230 mm - Thicknesses: 10 to 130 mm - Widths: 15 to 230 mm - Minimum length for single workpiece: 600 mm > 760 mm with use of the universal spindle Bsdov Tzw Eepfx Aphsdf - Adjustable infeeds: max. 10 mm - Spindle speed: 6000 rpm PLANKER COMPOSITION: - Robust frame Welded machine shop - Secure, soundproof, and fully panoramic enclosure on gas struts with interior lighting - Digital counters (Siko type) for precise manual adjustments of each operation - Raised control panel and operator face - Cast steel infeed table (LxW): 2980 x 255 mm Table height from ground: 900 mm - Side infeed spring-loaded pusher - Digital pass-taking indicators 1) Planer spindle 7.5 kW Tool holders Ø125 x L.230 mm 2 & 3) Right & left vertical spindle 12 kW Tool holders Ø125 x L.130 mm 4) Upper horizontal spindle with independent adjustment 11 kW Tool holders Ø125 x L.230 mm - Adjustable pressure shoe at the output 5) 360° universal spindle 11 kW Spindle Ø 50 x L. 240 mm - Vertical idler wheel presser DRIVE: - Feed with variable speed drive: 6 to 24 m/min Drive motor: 3 kW - Helical steel infeed roller in the table Cardan shaft drive - 7 pneumatic pressure rollers 2 notched steel rollers 3 (1 retractable) + 2 rubber-coated rollers - One smooth steel roller in the table at the planer outlet OTHER FEATURES: - Main power supply: 400V. Three-phase + T 50 Hz - Installed power: 53 kW (72 hp) IN 95.6 A - Automatic star-delta starting - Motors with brakes - Toothed belt drive - Electrical thickness adjustment by raising and lowering the beam. 0.37 kW motor - Shaft diameter: Ø50 mm - Minimum working air pressure: 6 bar - Suction: 5 x Ø 120 mm Recommended flow rate: 6100 m3/h Speed: 20 to 28 m/sec depending on the humidity of the wood being machined - CE marking - Padlockable contactor, mushroom stops Dimensions in operating order (W x H): 3000 x 2250 mm Dimensions: 5100 x 2000 x H 1810 mm Weight: 4300 kg Machine supplied with mounted sharpening irons, manual, spare parts list, and diagrams. Please contact us for consumables, accessories, and/or vacuum systems. Upon request, the machine will be serviced and brought into compliance, with inspection and dynamic functional testing. With a 3-month warranty and certificate of compliance. Ex-stock price excluding VAT. Delivery and additional services upon request.

Condition: good (used), - spindle diameter: 25 mm - working spindle height: 100 mm - interchangeable spindle - height adjustable (up/down) Bdjdpfx Apey Ivkuohjf - original cast iron fence - table dimensions: 1020x900 mm - motor: 5 kW

Condition: good (used), Year of construction: 2008, I sell the fourside moulder Weinig Unimat 300, year 2008 Feeding speed 5-30 m/min. Working width 230mm Working height 130mm 5 spindles Configuration: bottom - right - left - top - bottom Total power 28kW 3-zone pneumatical pressure Bdedpfx Aer Arr Ejphef Good condition Fully working! Available immediately

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, 5-SPINDLE MOULDER WEINIG MOD. UNIMAT 500- USED - Composition: 1st lower horizontal spindle 2nd right vert. 3rd left vert. Bdsdpfx Apeywflyshjf 4th upper horizontal spindle 5th lower horizontal spindle - Complete with MEMORY SYSTEM - Width 230 mm - PTO drive - Short workpiece device - Ribbed table - Year 2002 - CE standards

Condition: used, Year of construction: 1997, SECOND-HAND 5 SPINDLES MOULDER WEINIG MOD. PROFIMAT P23E - CE RULES - Horizontal bottom 5.5Kw - Vertical right/left 7.5Kw - Horizontal top 7.5Kw - Horizontal bottom 4Kw Bedswrxuwepfx Aphjdf - Year 1997 (CE)

Condition: used, Year of construction: 1994, SECOND-HAND 5 SPINDLES MOULDER WEINIG MOD. PROFIMAT 23 Bjdpfxorm Rxwj Aphedf - Working width 230 mm - Working height 120 mm. Composition : - horizontal bottom - vertical right - vertical left - horizontal top - horizontal bottom Year 1994 V 380/50

Condition: used, Year of construction: 2002, SECOND-HAND 5+1 SPINDLES MOULDER WEINIG MOD. PROFIMAT 23 FORTEC - CE RULES - ATS device - 1st horizontal botom - 2nd vertical right Bjdpfxowrx Nbe Aphodf - 3rd vertical left - 4th horizontal top - 5th horizontal bottom - 6th universal - Working width mm. 230 - Cardan feed - Year 2002

Condition: excellent (used), Year of construction: 2010, WEINIG HYDROMAT 2000 WITH FLOATING VERTICAL SPINDLES OPPOSED FEED MOTOR 22 KW FEEDRATE MAX 100 M/MIN 300MM WIDE MOULDER 1ST SPINDLE BOTTOM 30 KW WITH COUNTER BEARING 2ND SPINDLE TOP 30 KW WITH COUNTER BEARING 3RD SPINDLE LEFT 22 KW OPPOSED Bdsdpezmxmmefx Aphef 4TH SPINDLE RIGHT 22 KW OPPOSED VERTICAL SPINDLES FLOATING VERTICAL SPINDLES OPPOSED SPINDLES 6,000RPM WORKING WIDTH 300 MM PLANING HEIGHT 160 MM NUMBER OF SPINDLES 4 BOTTOM SPINDLES 1 SPINDLE DIAMETER 50 MM CONTINUOUSLY VARIABLE INVERTER DRIVE FEED FEED MOTOR 22 KW MAIN MOTOR POWER 30 KW SPINDLE(S) WITH COUNTERBEARING SEPERATE MOTOR PER SPINDLE MOTORIC ADJUSTMENT PROGRAMMABLE CONTROLLER INFEED TABLE LENGTH 700 MM TABLE ROLLERS DRIVEN LUBRICATION PUMP AUTOMATIC SHORT INFEED WITH 220MM TOP FEED ROLLERS CONFORMITY MARKING CE MARK TOTAL CONNECTION 126 KW

Condition: used, Year of construction: 1969, Used machine Year of manufacture: 1969 Runs perfectly Max. working width: 170 mm Max. working height: 130 mm 1st shaft: bottom 2nd shaft: right 3rd shaft: left 4th shaft: right 5th shaft: top Bjdsxavtqopfx Aphsdf Availability: short-term Storage location: Röllbach

Condition: used, Technical specifications: Bdsdpfx Apezguw Uehjf Max. planing width: 230 mm Max. planing height: 130 mm Spindle diameter: 40 mm Number of spindles: 5 Spindle arrangement: bottom, right, left, top, bottom Each spindle has its own motor Number of steel feed rollers: 4 Number of rubber feed rollers: 1 Diameter of dust extraction port: 2 x 120 mm Variable feed speed adjustment: YES Feed via universal joints: YES Lubrication pump for the work table: YES 1 smooth roller in the table Pressure: 6 atm. Electric lifting of the machine body Power supply: 400 V Total power: 29 kW Overall dimensions: Length: 3500 mm Width: 1700 mm Height: 1800 mm

Condition: used, Year of construction: 2000, machine/vehicle number: 90816, Technical specifications: 1st shaft: lower horizontal, 2nd shaft: right spindle moulder, 3rd shaft: left spindle moulder, 4th shaft: upper horizontal, 5th shaft: lower horizontal, 6th shaft: universal, ATS control, any width, maximum width: 230, maximum height: 120. Bjdjxp U R Hepfx Aphjdf

Condition: used, The machine is for sale together with all tools as shown in the pictures. Bjdjy Rumtspfx Aphsdf

Condition: excellent (used), Year of construction: 1995, Very well-preserved planer moulder with timed lifting spindles on the right and top, and glazing bead saw. Bdodpjx Htc Ssfx Aphjf Spindle arrangement: Bottom: 4 kW Right: timed lifting spindle Left: 7.5 kW (together with right spindle) Top: 5.5 kW timed lifting spindle Bottom: 5.5 kW Glazing bead saw: 3 kW Equipped with Centrofix planer heads and spare planer heads.

Condition: excellent (used), Year of construction: 1992, beautiful machine in good condition as it came from a small business with little use. with IV 68 tool is still in operation ready for demonstration Bedpfx Apju S Afcshsdf

Condition: good (used), Year of construction: 1995, Angle unit for window production , consisting of : Bdjdpfx Astqft Iephef Slotting unit for 8 tools with hydraulic stroke 75 mm (clamping height 600 mm) Milling unit for 4 tools with hydraulic stroke 80 mm (clamping height 320 mm) with return with IV 68 tools

Year of construction: 1998, condition: ready for operation (used), spindle motor power: 11,000 W, spindle speed (max.): 6,000 rpm, This Weinig Unicontrol 10-5 was manufactured in 1998. A robust used window manufacturing machine, it features a working width of 40-220 mm and motor powers up to 15 kW for various machining units. It includes advanced features like a synchronization device, electronic height adjustment, and an automatic turning system for efficient one-man operation. If you are looking to get high-quality milling capabilities, consider the Weinig Unicontrol 10-5 machine we have for sale. Contact us for more information. • Capacities • Working width: 40–220 mm • Working height (longitudinal machining): 40–100 mm • Working height (cross machining): 40–100 mm (counter wood height 80 mm) • Workpiece length (longitudinal): min. 220 mm + 2 x tenon length • Workpiece length (cross): min. 275 mm + 1 x tenon length with 320 mm tool diameter • Feed (cross machining) • Motor power: 0.3 kW • Feed speed: 3–25 m/min • Workpiece clamping: 2 clamping claws • Length stop: with scale and reading magnifier for frame or sash outer dimensions • Counter: pneumatically clocked, 4 positions (not for studio windows), up to wood height max. 80 mm • Double part package: single or double part feeding, with cross separation and retention system • 1st piece (lying on the stop) wood width: 55–90 mm • 2nd piece wood width: 130 mm • Feed (longitudinal machining) • Motor power: 2.2 kW • Feed speed: 4–18 m/min (infinitely variable via frequency converter) • Feed roller spacing: 100/120 mm • Feed roller width: 30/50 mm • Feed roller diameter: 95 mm • Machining units • Crosscut saw • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 2800 rpm • Tool swing: max. 400 mm • Axial adjustment: pneumatic against 4-fold turret • 1st spindle with tenon and slot Bodex S Sk Ejpfx Aphedf • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 3250 rpm • Tool swing: max. 320 mm • Tool clamping length: 320 mm • Axial adjustment range: 240 mm • Number of tools: 4 x 80 mm • Axial adjustment: hydraulic • 1st profiling spindle • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 6000 rpm • Tool diameter: max. 232 mm • Tool zero swing circle: 130–140 mm • Tool clamping length: 320 mm • Axial/radial adjustment range: 240/80 mm • Number of tool positions: 4 x 80 mm • Axial adjustment: hydraulic • 2nd profiling spindle • Motor power: 11 kW • Spindle diameter: 50 mm • Spindle speed: 6000 rpm • Tool diameter: max. 232 mm • Tool zero circle: 130–140 mm • Tool clamping length: 320 mm • Axial/radial adjustment range: 240/80 mm • Number of tool positions: 4 x 80 mm • Axial adjustment: hydraulic • Mechanical spindle brakes • For profiling spindle(s) • For crosscut saw and profiling/sawing units • Profile milling unit (horizontal, top; in front of last profiling spindle) • Radially indexed: 2 positions • Axially indexed: 2 positions • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 5850 rpm • Tool swing: 130 mm • Tool clamping length: 40 mm • Axial adjustment range: 52 mm • Radial adjustment range: 125 mm • Profile milling unit (vertical, right; at end of machine) • Radially indexed: 2 positions • Axially indexed: 2 positions • Motor power: 3 kW • Spindle diameter: 40 mm • Spindle speed: 5850 rpm • Tool swing: 210 mm • Tool clamping length: 160 mm • Axial adjustment range: 90 mm • Radial adjustment range: 100 mm • Length tenoning and slotting spindle (640 mm tool clamping length, instead of 320 mm spindle) • Motor power: 15 kW • Spindle speed: 2925 rpm • Number of tool positions: 8 x 80 mm

Condition: used, Number of boring spindles 5 St. Working width 230 mm Working height 120 mm Bsdpfxszqvpgo Aphjdf Length of the planing table 2.500 mm Feed motor 2,2 kW Weinig Profimat 23 automatic planer and moulder for four-sided planing and profiling of lumber, featuring a long dressing table. Spindle 1: Bottom / 4 kW / 40 mm Spindle 2: Right / 5.5 kW / 40 mm Spindle 3: Left / shared motor with #2 / 40 mm Spindle 4: Top / 5.5 kW / 40 mm Spindle 5: Bottom / 5.5 kW / 40 mm

Condition: used, Number of boring spindles 7 St. Working width 230 mm Working height 160 mm Weinig Unimat 23 automatic planing and grooving machine for four-sided planing and profiling of wood, featuring five driven rollers in the table and a universal spindle. Also ideal for machining wet wood. Spindle 1: Bottom / 5.5 kW / 40 mm Spindle 2: Right / 5.5 kW / 40 mm Spindle 3: Left / 11 kW / 40 mm Spindle 4: Right / 7.5 kW / 40 mm Spindle 5: Top / 11 kW / 40 mm Bdsdpfxozf Nr Ro Aphef Spindle 6: Bottom / 5.5 kW / 40 mm Spindle 7: Universal / 5.5 kW / 40 mm

Condition: used, Number of boring spindles 7 St. Working width 160 mm Working height 120 mm Length of the planing table 2.000 mm Feed motor 2,2 kW Weinig PFA 17 N (Unimat) automatic planing and chamfering machine for four-sided planing and profiling of wood, equipped with a universal spindle. Spindle 1: Bottom / 35 mm / 4 kW Spindle 2: Right / 35 mm / 3 kW Spindle 3: Left / 35 mm / 5.5 kW Spindle 4: Right / 35 mm / 7.5 kW Bjdpfx Apszb Rffehodf Spindle 5: Top / 35 mm / 5.5 kW Spindle 6: Bottom / 35 mm / 4 kW Spindle 7: Universal / 35 mm / 4 kW

Condition: used, Year of construction: 2000, Number of boring spindles 5 St. Bdsdpszqghtefx Aphof Working width 230 mm Working height 160 mm Feed motor 4 kW Feed speed 5-24 m/min.

Condition: used, Year of construction: 2000, Spindle swivels: Yes, -45 to +45° Height adjustment: electric Swivel adjustment: electric Stop adjustment: manual Height display: digital Swivel angle display: digital Milling stop display: digital Spindle diameter: 30 mm, 40 mm Speeds: 3000, 4500, 6000, 9000 Bsdpfozdzbzjx Aphedf Power consumption: 5 / 6 kW Motor brake: Yes, automatic Dust extraction port: 2 x 120 mm Machine length: 2500 mm Machine width: 1400 mm Weight: 1100 kg

Condition: used, Year of construction: 1988, Spindle swivels: Yes, -5 to 45° Height adjustment: electric Bjdpfxozq Dc Ie Aphsdf Swivel adjustment: electric Stop adjustment: manual Height indicator: scale Swivel angle indicator: scale Milling stop indicator: scale Spindle diameter: 30 mm Speeds: 3000, 4500, 6000, 8000, 10000 Motor power: 6 kW Motor brake: Yes, automatic Dust extraction connection: 2 x 120mm Machine length: 1,200 mm Machine width: 1400 mm Weight: 1100 kg
