Machining Center - Horizontal

MAKINO A 61

Condition: refurbished (used), Year of construction: 2007, Table size: 500 × 500 mm 2 pallets Max table load: 500 kg X-axis: 730 mm Y-axis: 650 mm Z-axis: 730 mm CNC control: Makino Professional 5 Rapid feed X/Y/Z: 60 m/min Spindle nose to pallet center distance: 70–800 mm Tool magazine: 60 positions Taper: HSK 63 Cedpfx Aexcmi Isbwsrh Max workpiece size on pallet: Ø800 × 1000 mm Max tool weight: 12 kg Max tool length: 360 mm Max tool diameter: 70 mm Options: High-pressure pump 15 Bar

Condition: used, Year of construction: 2005, Technical details: x-travel: 730 mm y-travel: 650 mm z-travel: 730 mm control: Professional 3 (Fanuc 18i) turning speeds: 12000 1/min spindle drive: 22 kW Torque: 166 Nm Number of tool station: 132 HSK-A 63 max. tool length: 360 mm max. tool diameter: 70 mm max. tool-dia with free toolbox: 140 mm max. tool weight: 12 kg tool changing time: 0,9 / 2,5 sec numbers of pallets: 2 Pallet dimension: 500x500 mm working diameter: 800 mm table load: 0,7 t distance spindle center to table: 80 - 730 mm Distance spindle nose - pallet centre: 70 - 800 mm rapid travel x/y/z: 50 m/min Feed x/y/z: 50 m/min total power requirement: 65 kVA Crsdpfswlgc Asx Abwoh Dimensions (L/W/H): 7 x 2,5 x 3,4 mm weight of the machine ca.: 9,5 t Custom Macro, Number of Variables: 600 program memory: 500 kB = 1280 m Accerories Chip conveyor Signal lamp 3 colors Coolant through spindle 30 bar 30 l/min Rotoclear window Tool breakage control in magazine High speed countour control No. of tool offset pairs 99 This very solid Makino A 61 has a full B-axis, coolant through spindle 30 bar. *

Condition: ready for operation (used), Year of construction: 2004, operating hours: 78,407 h, functionality: fully functional, machine/vehicle number: 80.4409.0001, travel distance X-axis: 730 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 730 mm, controller model: Fanuc CNC Professional 3, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis travel: 730 mm Y-axis travel: 650 mm Z-axis travel: 730 mm Rapid traverse (X, Y, Z): 60 m/min B-axis indexing: 360° (1° step) Max. spindle speed: 20 - 12,000 rpm Distance spindle nose - table surface: 70 - 800 mm Control: Fanuc CNC Professional 3 Work table & workpiece capacity Number of pallets: 2 Crjdpfx Ajv E Rq Esbwjh Pallet dimensions: 500 x 500 mm Max. workpiece weight: 700 kg Tool system Tool holder: HSK-A63 Number of tools in the magazine: 60 Max. tool diameter: 70 mm Max. tool length: 360 mm Max. tool weight: 12 kg MACHINES DETAILS Length: 4,800 mm Width: 2,800 mm Height: 3,000 mm Weight: 9,900 kg On time: 78,407 h Spindle hours: 26,825 h EQUIPMENT - Floor grid
