Automatic basket washer

Marwis MRS Wash 1200

Basket Washing Machine MRS - WASH 1200

Application:
The device is designed for washing components of various sizes and weights. The washer is equipped with a mechanically driven rotary basket powered by a motor and spray nozzles.

Operating Description:
After switching on the main power, the bath heating process begins. Once the set temperature is reached, the washing cycle can be started. The primary washing phase is the first step, and its duration can be continuously adjusted using the timer located in the control box. When the set time elapses, the bath will end automatically.

STANDARD EQUIPMENT OF THE WASHER:

* Safety cover switch that disconnects during opening in the washing process
* Liquid level sensor in the tank preventing dry operation
* Temperature sensor
* Single spray arm
* Mechanically rotated basket
* Double filtration system
* Coarse mesh filter for insoluble contaminants (1mm mesh)
* Drain valve

Technical Data:

Basket diameter: 1200mm
Working height: 500mm
Basket capacity: 300kg
Working time programmability: 0-99 min
Washing temperature: 60°C
Heater power: 12kW
Tank capacity: 400l
Spray performance: 200l/min
Spray working pressure: 4.5bar
Overall width: 1750mm
Overall depth: 1750mm
Overall height (closed/open): 1250/2400 mm
Power supply: 3~400V

OUR OFFER INCLUDES OTHER MODELS OF AUTOMATIC BASKET WASHERS FROM THE MRS WASH SERIES WITH SIZES 800, 1000, 1200, 1500, AND EVEN 1500 XL.
Guodpfx Asxnlpdsfpoh
PLEASE CONTACT US FOR OFFERS ON OTHER MODELS.
