Gear Hobbing Machine - Horizontal

MIKRON A 35/36 CNC

Condition: new, Year of construction: 2026, 540×250 Surface Grinder (MYS1022) is a compact machine designed for precision grinding of small and medium-sized metal components. Its robust construction and advanced technologies ensure high machining accuracy and reliable operation in demanding industrial environments. Main advantages of the 540×250 (MYS1022) surface grinder The 540×250 (MYS1022) magnetic surface grinder is an ideal solution for industrial facilities requiring precise machining in a compact format. Designed for professional users, it combines advanced technologies such as hydraulic feed in two axes and precision guideways with a solid construction, ensuring reliability and high machining efficiency. Its compact dimensions and high accuracy make it an excellent choice for smaller workshops and production facilities where space is limited. Key benefits include: High grinding precision – maximum grinding area of 540 × 240 mm and transverse feed accuracy of 0.02 mm ensure excellent surface finishing quality. Compact construction – dimensions of 1800 × 1400 × 1800 mm and a weight of 900 kg allow easy installation in smaller production facilities. Smooth hydraulic feed system – two-axis feed system enables precise movements with transverse speed up to 600 mm/min, ensuring efficient machining. Stability and durability – robust construction with double guideways minimizes vibrations, guaranteeing stable operation during intensive use. Easy maintenance – centralized guideway lubrication reduces manual maintenance requirements and increases machine availability. Ready for operation – the machine is fully equipped for immediate production, minimizing setup and downtime. Machine design and technology Robust construction and precision components The MYS1022 surface grinder features a heavy-duty construction weighing approximately 1000 kg, providing excellent stability during machining operations. Hardened and ground linear guideways eliminate vibrations, ensuring smooth table movement and high-quality surface finishes. The spindle, driven by a 1.5 kW motor, operates with a grinding wheel measuring 200 × 20 × 32 mm, enabling efficient processing of various metal materials. Technical specifications Parameter Value Table dimensions 500 × 250 mm Longitudinal / transverse travel 560 × 260 mm Maximum grinding area 540 × 240 mm Maximum distance from table to spindle centerline 490 mm Table guideways Double guideway Transverse movement per vernier scale division 0.02 mm Transverse movement per handwheel revolution 2.5 mm Vertical movement per vernier scale division 0.01 mm Manual vertical movement per handwheel revolution 1.25 mm Grinding wheel dimensions 200 × 20 × 32 mm Grinding wheel speed 2850 rpm Main motor power 1.5 kW Hydraulic oil tank capacity 80 L Hydraulic pump motor power 1.5 kW Coolant pump motor power 40 W Machine dimensions 1800 × 1400 × 1800 mm Iodokkcm Uepfx An Ijbc Weight 1000 kg Standard equipment Magnetic table Grinding wheel Grinding wheel holder Cooling system Chip separator with magnetic filter Halogen lighting system Technical documentation (DTR) CE declaration

Condition: used, Year of construction: 1991, workpiece diameter 30 mm threading length 110 mm thread pitch 0,5-2,75 mm/GG total power requirement 4,5 kW weight of the machine ca. 1,7 t dimensions of the machine ca. m Isdpfx Anjt Hwzcj Isbc

Condition: new, Precision surface grinding machine with automatic longitudinal and transverse feed. All castings, such as machine stand, table, etc., are made of MEEHANITE® quality cast iron and are therefore ideally suited for rough everyday work. Ideal for tool and mold making. Table size: 250 x 500 mm Installation height (max. distance spindle/table): 500 mm Max. Table load: 250 kg Motor power main spindle: 1,5 kW Connection: 400 V Dimensions (LxWxH), approx.: 2250 x 1400 x 1800 mm Weight, approx.: 1350 kg* * only machine without auxiliary units Features: - All castings, such as machine column, table, etc., made of MEEHANITE® quality castings. - All guideways hardened and ground - Automatic cross and longitudinal feed - NC-controlled automatic vertical infeed - Ergonomically arranged control panel - Automatic central lubrication - Separate hydraulic power pack - Grinding wheel - Grinding wheel flange - Manual dressing device - Balancing mandrel - Balancing scale - Dressing diamond - Demagnetizing device - Machine light - leveling elements - Operating tool - Operating instructions - CE Available options: - Elektromagent clamping plate (fine-pole) - Automatic demagnetization control for electromagent clamping plate - 2-axis digital display, accuracy 0.001 mm, X 450 / Y 500 mm - Coolant system with magnetic separator / magnetic separator Ibsdsp Dt T Njpfx An Iec - Partial enclosure with limit switch protected sliding doors - Full enclosure with limit switch protected sliding doors - Additional grinding wheel flange - Grinding wheel and flange for mild steel - Grinding wheel and flange for HRC55 - Ball screw for cross feed - Further options on request Pictures may show the machine with special accessories and with application examples.

Condition: used, Year of construction: 2000, Technical details: Ibedpfsyk Ur Ujx An Ijc max. wheel diameter: 180 mm gear width: * mm max. module: 4 total power requirement: 14 kW weight of the machine ca.: 8 t slide travel axial ( Z-axis ): 300 mm work piece - max.: 490-640 mm

Condition: ready for operation (used), Year of construction: 2007, A vertical cross grinding machine Sunnen is available. Bore diameter range: 3mm-65mm, max. workpiece length: 250mm, working area dimensions X/Y/Z: 150mm/150mm/150mm, slide speed range: 0.001mm-0.8mm/s, stroke rate range: 30-400, spindle speed: 4000rpm, feed force: 3800N, grinding oil tank volume: 280l. Machine dimensions X/Y/Z: approx. 2150mm/2200mm/2900mm, weight: approx. 2200kg, operating hours: approx. 5000h. Including indexing table and grinding oil tank with magnetic separator and filter. Documentation available. An on-site inspection is possible. Ijdpsy Ax Tnjfx An Ijbc

Condition: refurbished (used), Year of construction: 2027, functionality: fully functional, position of the milling head: Schwenkbar (40°), total length: 6,100 mm, gear diameter: 180 mm, total height: 3,450 mm, total width: 2,975 mm, input frequency: 50 Hz, type of input current: three-phase, spindle speed (max.): 4,000 rpm, spindle speed (min.): 300 rpm, travel distance X-axis: 100 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 300 mm, overall weight: 8,400 kg, tool diameter: 80 mm, controller manufacturer: Siemens Sinumerik ONE, drive type: Sinamics S120, control type: CNC control, Equipment: documentation/manual, rotational speed infinitely variable, A high-performance machine for series production: the horizontal Gleason-Pfauter P 210 L, built in 2003, mills shafts, pinion shafts, and small gears up to module 4 and 180 mm in diameter at speeds of up to 4,000 rpm on the cutter and 1,000 rpm on the workpiece – designed for short cycle times and dry machining. Serwema Retrofit Solutions, Chemnitz, completely overhauls the machine and delivers it with Siemens Sinumerik ONE, the latest generation of control systems with full spare parts and support availability. Modern Gleason-Pfauter kinematics, new electrical system, new drives, new safety technology: you get the performance of a new machine at a fraction of the price, and we will inspect it together with you in Chemnitz. The horizontal design makes the P 210 L ideal for shaft machining: workpieces up to 830 mm are clamped between the spindle and tailstock, with 300 mm of axial travel and 100 mm of radial travel (center distance 30–130 mm). The milling head pivots by ±40°, and the tangential travel of 160 mm utilizes the full cutter length of 170 mm for long tool life. The high workpiece speed allows for multi-tooth hobbing cutters and thus the cutting performance required in the gearbox and automotive component supply sector. The machine is prepared for connection to a loading portal or a robot. Ijdpfx Anez Et Rze Ijbc Technical data: max. workpiece diameter 180 mm, max. module 4, working area radial 100 mm (30–130 mm), axial 300 mm (260–560 mm), tailstock 350 mm (480–830 mm), max. cutter diameter 180 mm, max. cutter length 170 mm, tangential travel 160 mm, cutter speed 300–4,000 rpm, max. workpiece speed 1,000 rpm, swivel angle ±40°, total connection value 50 kVA. Installation dimensions approx. 6.1 × 3.0 × 3.5 m, weight approx. 8.4 t. The machine will be delivered with a new Siemens Sinumerik ONE control system and Sinamics S120 drives in an air-conditioned control cabinet manufactured in-house. The user-friendly interface makes setup and programming possible without in-depth G-code knowledge. Geometry acceptance is carried out according to the manufacturer's standard or DIN with a protocol. The scope of delivery also includes the complete machine enclosure with state-of-the-art safety technology, a new coat of paint in RAL 5015/7035, a magnetic chip conveyor, circulation and loss lubrication, a hydraulic unit, a coolant system, and the operating manual.

Condition: refurbished (used), functionality: fully functional, Equipment: documentation/manual, Universal involute gear grinding machine KOEPFER 150 P Wheel diameter – max. 145 mm Wheel width 110 mm Isdpszzf Dnjfx An Isbc Module – max. 2 Module – min. 0.3 Speed 112 – 1000 rpm Number of teeth – min. 6 Clamping length max. 150 mm Total power consumption 3.5 kW Machine weight approx. 1.3 t Space required approx. 1.3 x 0.8 x 1.4 m As new (used) The machine is suitable for use in precise prototyping and small-series production. Upon request, a workpiece of your choice can be set up on the machine and used as a test piece. If required, training for your staff can be provided at our facility. Further detailed information and prices are available upon request.

Condition: good (used), Gear Hobbing Machine Strausak 30 Workpiece diameter for manual loading: Ø 35 mm Workpiece diameter for magazine loading: Ø 15 mm Workpiece diameter for fully automatic loading: Ø 10–12 mm Maximum hobbing length: 12 mm Plunge feed at 42% of longitudinal feed: 22 mm Plunge feed at 25% of longitudinal feed: 14 mm Module in steel max.: 1.0 mm Module in non-ferrous metals max.: Solid material ø26 / ø35 mm Selectable number of teeth: 5–390 Cutter speeds: 1160–8550 rpm Plunge feeds per workpiece revolution: 0.0325–0.273 mm Longitudinal feeds per workpiece revolution: 0.033–0.65 mm Cutter diameter: 8–24 mm Machine weight: 600 kg Main motor: 0.8 HP at 3000 rpm Hydraulic motor: 0.25 HP at 1500 rpm Coolant motor: 0.25 HP at 1500 rpm Iodpfx Aox Dxu Son Iebc No guarantee is given for the accuracy, completeness or timeliness of the information provided.
