Tool grinder PCD/PCBN/CVD/MCD

OPMT Orginal Point 5X series

Condition: used, FOR SALE – Michael Deck Grinding Machines (S20 NUM, S22 NUM, S22 MTS) 3 different models of grinding machines, produced with Michael Deck quality and distinguished by their precision and durability, are offered for sale. All machines are in working order and their maintenance has been done regularly. They are suitable for mass production and special grinding needs. On-site inspection and technical support can be provided upon request. ⸻ 🔹 1. Michael Deck S20 NUM • Control Unit: NUM control system • Grinding Type: Cylindrical grinding (inner and outer diameter) • Distance Between Centers: 400 mm • Center Height: 100 mm • Grinding Motor: 3.7 kW • Accessories: Magnetic table, diamond center, cooling unit ➡️ It is ideal for delicate works in the workshop with its compact structure. Easy to use and high energy efficiency. ⸻ 🔹 2. Michael Deck S22 NUM • Control Unit: NUM digital control system Kedpfjwta Hqjx Ac Hjfa • Distance Between Centers: 500 mm • Center Height: 125 mm • Spindle Motor: 5.5 kW • Grinding Motor: High frequency, variable speed • Equipment: Internal grinding head, automatic lubrication, digital position indicator ➡️ Provides high repeatability in mold, tool and precision part production. Also suitable for heavy work thanks to its high torque motor. ⸻ 🔹 3. Michael Deck S22 MTS • Control: Manual / Servo-assisted hybrid system • Center to Center Distance: 600 mm • Center Height: 150 mm • Additional Features: • Linear ruler X-Z measurement • Automatic balancing system • Quick wheel change mechanism • Programmable positioning ➡️ Offering both manual and automatic control, this model is ideal for special grinding scenarios and flexible production environments. ⸻ 📍 Location: Turkey - Can be tested in a workshop environment. 📦 Status: Working, well-maintained and ready. 📄 Documentation: Technical documentation and past service records are available upon request.

Year of construction: 2000, condition: ready for operation (used), A Saacke CNC tool grinding machine including a Felsomat tool loader is available. Center height: 170mm, travel X: 580mm, feed X: 20m/min, table dimensions X/Y: 980mm/185mm, travel Z: 250mm, feed Z: 20m/min, travel Y: 250mm, feed Y: 10m/min. B-axis horizontal swivel: 240°, swivel speed: 120°/s, motor spindle diameter: 170mm, speed: 10000rpm, torque: 10.7Nm. Tool positions: 24, tool holder: HSK-C50, A-axis indexing accuracy: +/-15°, error at 100mm diameter: 8µm, workpiece holder: ISO 50, speed: 50rpm. Control: NUMROTOplus V.3.8.3m, resolution X/Y/Z: 0.0001mm, resolution A/B: 0.0001°. Includes Felsomat Robotal RE 01 loading unit with rotary indexing table, FB703 small extinguishing system, and Brinkmann FBS-238/50 screw spindle pump. Documentation available. An on-site inspection is possible. Kodpfxexdm Ugj Ac Hjfa

Condition: excellent (used), Year of construction: 2007, 5 controlled axes: X, Y, Z, A, and B Fully automatic grinding wheel changer NUM Axium Power 1050 control system with PC TOOL DATA Max. diameter: Ø 250 mm Max. diameter for complete machining: Ø 250 mm Max. length for complete machining (from front edge of workpiece support): 430 mm Ksdpfx Acext N Izj Hsfa Max. tool length between centers: 480 mm Center height: 195 mm X-axis grinding travel: 625 mm Z-axis cross slide travel: 305 mm Y-axis vertical slide travel: 305 mm All linear axes are driven by high-precision ball screw spindles with 2 preloaded nuts. The axes are guided on extremely robust recirculating roller shoes on hardened rails. GRINDING HEAD, B AXIS Swiveling range in the horizontal plane: 240° Rotational speed: 120°/s Liquid-cooled motor spindle: 150 x 150 mm Grinding wheel mount with automatic quick-clamping system HSK - C/E 50 Spindle speed infinitely variable: 2,000 - 10,000 rpm Max. grinding wheel diameter: 150 mm Grinding wheel changer with 4 magazine slots Second probe arranged on the workpiece holder for automatic grinding wheel measurement, including software CHAIN LOADING MAGAZINE with PICK-UP arm Capacity: 160 tools Maximum workpiece diameter: 32 mm Maximum workpiece length: 200 mm Maximum tool weight: 2.5 kg CNC-controlled steady rest TURBO separator (filter system)

Condition: refurbished (used), Year of construction: 2008, functionality: fully functional, spindle speed (min.): 12,000 rpm, power: 12 kW (16.32 HP), warranty duration: 6 months, Our machine is completely Liner-moving, machine maintenance has been done, we give 6 months warranty for the machine. Installation and training will be done by our company. Features X/Y/X linear motor A/C torque motor Glass rulers Haidenhein Kedpfx Aow Rpfvjc Hefa 5-piece stone change Eco robot (active) 400 mm helix opening feature All sizes of GunDrill can be connected and sharpened. 3D cutting tool simulation is available.

Year of construction: 1997, condition: ready for operation (used), Axes: 5, travel X/Y/Z: 580mm/250mm/250mm, center height: 170mm, workpiece holder: ISO50, tool holder: HSK, max. workpiece diameter: 250mm, max. workpiece length: 430mm, feed rate: 15m/min, rated power: 30kW, weight: approx. 6400kg. An on-site inspection is possible. Kfjdpfxoxl Uqfj Ac Hsa

Condition: new, Year of construction: 2025, functionality: fully functional, Technical description: see attached images Ksdpfsxwyb Hjx Ac Hjfa

Year of construction: 1997, condition: ready for operation (used), Main Drive Kfodpfx Acex D Hkhs Hea Number of axis 5 This 5-axis SAACKE UWIID grinding machine was manufactured in 1997. It operates on a 3 AC current type, with a frequency of 50 Hz and an operating voltage of 400 V. The machine features a rated power of 30 kW and a rated current of 52.9 A. Consider the opportunity to buy this SAACKE UWIID grinding machine. Contact us for more information. Application Types Grinding

Year of construction: 2001, condition: ready for operation (used), General Data Measurements width 2850 mm Measurements depth 4100 mm Kodpfx Acox D Hkbj Hjfa Measurements height 2350 mm Additional Equipment Automatic gripper clamping Various accessories and clamping devices Complete documentation Machine dimensions 4.1m x 2.85m x 2.35m / Dimensions of Felsomat workpiece loader 1.60m x 1.50m x 2.1m This 6-axis SAACKE UWIID grinding machine was manufactured in 2001. It features a NUM 1050 control, Num MDLU2 drives, a 24-pocket grinding wheel changer, and a Felsomat 70-slot workpiece loader. Equipped with CNC steady rest, automatic gripper clamping, and NUMROTO plus 3.8.1o software, it's ideal for manufacturing and resharpening. For more information about this grinding machine, please reach out to us. Application Types Grinding
