Optimierungs Kappanlage

Paul 11 KE

Condition: excellent (used), Year of construction: 2018, CNC cross-cutting system from the machine manufacturer PAUL for use in series production and industrial operations designed for small and medium cross-sections, high cycle rates use in sawmills, as well as in the flooring, box and furniture industries roller/belt feed Iolhccqsvn Ncrjqotg cross-cutting saw Paul type C11 saw blade diameter 500 mm bore diameter 70 mm speed 4300 /min cutting height [mm] 3 - 89 passage width [mm] 30 - 200 workpiece length min. [mm] 300 with manual feeding 1 300 with automatic feeding wood cross-section [mm] see cutting diagram fixed length min. (wood end) [mm] 130 (180)

Condition: good (used), Year of construction: 1999, Functionality: fully functional, CNC full optimization cross-cut saw line PAUL MKL 11 S/N 99 126515 Year of manufacture 1999 Manufactured by Paul Maschinenfabrik GmbH & Co. (more photos coming soon) Paul saw model 11 MKL optimizing and forgiving cross-cut saw: for soft and hard wood Wood input length 800- 4000 mm Wood width 30-180 mm Wood thickness 6-75 mm Minimum cross-section 30×15 mm or 45×6 mm Maximum cross-section 130x75 mm or 180×45 mm Shortest sections to be sawn 250 mm Saw blade diameter 500 mm, Saw motor 5.5 kW Saw cycles 0.4 s Saw stroke pneumatic Feed speed max. 200 m/min Conveyor belt length x width L x W 7500×200 mm, belt width 100 mm Measuring station with luminescence and light barrier for wood start and end detection 6 side shifters in the outfeed conveyor belt Length of the outfeed table 11500mm (with new conveyor belt) Power consumption 11.4 kW Control - software CNC MAXI 4.00 MV Itolhjtybqpjccqqjg Weight approx. 6000 kg

Condition: good (used), Year of construction: 2004, Consist of : TRANSLYFT 3000 x 1300 mm, 4 ton. lifting table PAUL 11 MKL saw line, 5000mm conveyer, laser unit, 5000mm conveyer, 2 x pusher stations, 10.000mm conveyer. Iolhccqjuyhxtsqotg Max. sawblade : 500 mm, total Kw : 11 SCM SUPERSET XL Moulder ( Year 2003 ) 6 spindles : bottum/right/left/top/top/bottum Working width : 230 x 120 mm Digital variable infeed speed : 5 - 25 Mtr/min Tools/heads on 4 spindles ( 2 x 180 + 2 x 100mm TERSA )

Condition: excellent (used), Cutting width max. mm: 180 Cutting height max. mm: 90 Blade diameter max. mm: 500 Feed speed max. 200 m/min Ielhccqsufumroqjtg Main motor Kw: 5,5 Control - PAUL MAXI 4.0

Condition: like new (used), Min. input length: 500 mm, max. 6 m. Cross section: max. 140 X 250 Motor: 5.5 kW Sawing stroke servo swing arm Feed by means of rollers, 6 pieces top, 6 pieces bottom CNC control Maxi 8.0 1 X sorting unit per 11.5 m Machine is set up according to your wishes Islhcer A Et Tocqqjtg

Condition: refurbished (used), Model 11 completely overhauled Itjlhcsb Rl I Hocqqsg Description: CNC cross-cut system Paul MKL or K or KE as desired Manufacturer: Paul Year of manufacture: General overhauled with newest technology Condition: As good as new Technical data: Cutting width 150 mm Cutting height 85 mm Saw blade diameter:450 mm Saw motor 5,5KW Input length as required CNC Maxi 5 control with optimization Sorting belt as desired Machine would be completely overhauled, all bearings new motors new with latest eff Class, new control, new swingarm.
