Gear cutting machine

pfauter P630

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm gear width 425 mm table hole 125 mm clamping table 550 mm max. module 10 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm Gusdpfxsw A Am Sj Afpoh no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm main drive motor 7,5 kW total power requirement 22,5 kVa weight of the machine ca. 8,2 t Machine equipment: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport --> Working range Largest module to be milled (in steel 600 N/mm²): 10 mm --> Straight gear teeth: --> Largest workpiece diameter: 630 mm --> Largest axial slide travel (Z-axis): 425 mm --> Smallest number of teeth to be milled: 8 --> Dimensions Diameter of workpiece table: 550 mm --> Diameter of table bore: 125 mm --> Diameter of workpiece mandrel: 36 mm --> Largest milling cutter that can be clamped: --> Diameter: 192 mm --> Width: 220 mm --> Diameter of milling cutter mandrels: 32 mm --> Centre distance between milling cutter and workpiece: --> Maximum distance: 425 mm --> Minimum distance: 50 mm --> Drive taper for cutter mandrels: Morse taper 5 --> Maximum cutter displacement: 200 mm --> Speeds and feeds Cutter speeds: 45 - 280 rpm --> Axial feed (Z axis): 0.40 - 6.30 mm/rev --> Radial feed (X axis): 0.10 - 1.60 mm/rev --> Tangential feed (Y axis): 0.14 - 2.24 mm/rev Translated with (free version)

Condition: good (used), max. wheel diameter 630 mm gear width 375 mm max. module 10 clamping table 550 mm table hole 125 mm milling spindle speeds infinitely variable 62 - 390 U/min taper MORSE 5 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm main drive motor 7,5 kW total power requirement 21 kVa weight of the machine ca. 8,2 t Equipment of the machine: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder Gjdpfsua It Uex Afpjuh - Magnetic chip transport - Year of construction approx. 1976
