Gear Hobbing Machine - Vertical

PFAUTER P 630

Condition: new, Year of construction: 2026, 540×250 Surface Grinder (MYS1022) is a compact machine designed for precision grinding of small and medium-sized metal components. Its robust construction and advanced technologies ensure high machining accuracy and reliable operation in demanding industrial environments. Main advantages of the 540×250 (MYS1022) surface grinder The 540×250 (MYS1022) magnetic surface grinder is an ideal solution for industrial facilities requiring precise machining in a compact format. Designed for professional users, it combines advanced technologies such as hydraulic feed in two axes and precision guideways with a solid construction, ensuring reliability and high machining efficiency. Its compact dimensions and high accuracy make it an excellent choice for smaller workshops and production facilities where space is limited. Key benefits include: High grinding precision – maximum grinding area of 540 × 240 mm and transverse feed accuracy of 0.02 mm ensure excellent surface finishing quality. Compact construction – dimensions of 1800 × 1400 × 1800 mm and a weight of 900 kg allow easy installation in smaller production facilities. Smooth hydraulic feed system – two-axis feed system enables precise movements with transverse speed up to 600 mm/min, ensuring efficient machining. Stability and durability – robust construction with double guideways minimizes vibrations, guaranteeing stable operation during intensive use. Easy maintenance – centralized guideway lubrication reduces manual maintenance requirements and increases machine availability. Ready for operation – the machine is fully equipped for immediate production, minimizing setup and downtime. Machine design and technology Robust construction and precision components The MYS1022 surface grinder features a heavy-duty construction weighing approximately 1000 kg, providing excellent stability during machining operations. Hardened and ground linear guideways eliminate vibrations, ensuring smooth table movement and high-quality surface finishes. The spindle, driven by a 1.5 kW motor, operates with a grinding wheel measuring 200 × 20 × 32 mm, enabling efficient processing of various metal materials. Technical specifications Parameter Value Table dimensions 500 × 250 mm Longitudinal / transverse travel 560 × 260 mm Maximum grinding area 540 × 240 mm Maximum distance from table to spindle centerline 490 mm Table guideways Double guideway Transverse movement per vernier scale division 0.02 mm Transverse movement per handwheel revolution 2.5 mm Vertical movement per vernier scale division 0.01 mm Manual vertical movement per handwheel revolution 1.25 mm Grinding wheel dimensions 200 × 20 × 32 mm Bdsdpfx Aokkcm Uehmsh Grinding wheel speed 2850 rpm Main motor power 1.5 kW Hydraulic oil tank capacity 80 L Hydraulic pump motor power 1.5 kW Coolant pump motor power 40 W Machine dimensions 1800 × 1400 × 1800 mm Weight 1000 kg Standard equipment Magnetic table Grinding wheel Grinding wheel holder Cooling system Chip separator with magnetic filter Halogen lighting system Technical documentation (DTR) CE declaration

Condition: not inspected (used), Please see technical details on photo. Bedpfx Ashvzxzjhmjdh

Condition: used, Year of construction: 1997, pressure 130 t chamfer lenght 3060 mm distance between columns 2690 mm column arm 410 mm stroke 365 mm dayligth 535 mm ajustment speed 200 mm/sec working feed 1.0 - 10.0 mm/sec return speed 135 mm/sec table width 120 mm table height 1050 mm tiltable up to +/- 10.0 mm Number of working hours ca. 31.800 h compressed air 5.0 - 7.0 bar oil volume 250 l operating pressure 340 bar voltage 400 V total power requirement 23.0 KVA weight of the machine ca. 12950 kg range L-W-H 3660 x 2310 x 2900 mm Machine in a well-maintained condition (!!) with only approx. 31.800 operating hours - in checked condition - machine video - ?v=PBV-MDtZnlE Equipment: - CNC electro-hydraulic press brake - DELEM CNC control model DA 65 * swiveling control panel, front left * 2D graphic programming & product display * Tool & program library * USB keyboard and mouse interface - CNC controlled axes: Y1 + Y2 / X1 + X2 / R1 + R2 / Z1 + Z2 / I axis - CNC controlled back stop (X1 + X2 axis) - CNC controlled height adjustment of the back stop (R1 + R2 axis) - CNC controlled adjustment of the stop fingers (Z1 + Z2 axis) - CNC controlled, pneumatic die displacement (I axis) - CNC WILA electro-motoric table crowning Bdjdexacfmepfx Ahmsh - TRUMPF hydraulic upper tool clamping - TRUMPF manuel Lower tool clamp - 1x freely movable 2-hand / foot control - Safety device at the rear (sliding door) - Safety device at the side (swinging door) - Original operating instructions + spare parts list

Condition: good (used), Year of construction: 1954, Ref. -No.: 10576 Manufacturer: VDF WOHLENBERG Bdsdpfx Asxmd U Aehmjh Type: VDF Year of construction: 1954 Type of control: Konventionell Control: n/a Storage location: Halberstadt Country of origin: Germany Machine-No.: 27XXX Turning Length: 4000 mm Spindle Diameter: Ø 80 mm Faceplate Speeds I: 355 RPM Turning diameter over cross slide: Ø 1000 mm Max. Turning diameter: Ø 1250 mm

Condition: used, Year of construction: 1992, max. wheel diameter 150 mm gear width 300 mm max. module 4,5 Bedpfx Aet Hwxbjhmedh min. module total power requirement 20 kW weight of the machine ca. 6 t dimensions of the machine ca. m

Condition: new, Year of construction: 2026, functionality: fully functional, power: 5.5 kW (7.48 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, grinding belt width: 150 mm, grinding belt length: 7,000 mm, height adjustment type: electric, total height: 2,200 mm, total length: 3,550 mm, total width: 2,000 mm, overall weight: 870 kg, grinding length: 1,500 mm, workpiece weight (max.): 80 kg, extraction connection diameter: 180 mm, grinding width: 950 mm, rotational speed (max.): 1,435 rpm, space requirement height: 2,200 mm, space requirement length: 3,550 mm, space requirement width: 2,000 mm, table height adjustment: 500 mm, Equipment: documentation/manual, Long-belt sanding machine MS92-150 3-cornered sanding belt 150x7100 for manual sanding, matting and polishing. For processing steel, stainless steel and brass. The scope of delivery includes - Machine stand with connecting elements - Infinitely variable belt drive - Pneumatic belt tensioning and manual belt tracking regulation - Sanding unit with contact roller - Electric table lift - Flat machine table - Workpiece stop ruler on the machine table - Original equipment sanding belt - Operating instructions + manufacturer's declaration - CE version The stable machine frame in welded steel construction results in very smooth machine operation. The two machine stands are equipped with an offset so that longer parts than the machine table can be sanded. The sanding belt guide via 3 belt deflection rollers results in the largest possible open working area for the operator and therefore good working conditions, especially with hand sanding blocks. The belt is driven by a three-phase motor with a balanced belt drive roller. The belt has adjustable pneumatic belt tension. The dust collection device is dimensioned so that the sanding dust is collected and directed to the extraction nozzle when connected to an appropriate extraction system. The sanding unit is mounted on backlash-free roller guides to ensure effortless operation. The machine table can be easily and quickly adjusted to the correct workpiece height using the electromotive table lift. The table lift guide elements are maintenance-free. For loading, the table can be extended so far that workpieces do not have to be pushed under the sanding belt when loading. The electrical controls for the main functions are arranged in the middle of the machine for ease of use. Machine color: RAL 9001 cream white and RAL 5003 sapphire blue Switch cabinets and small housing in " light gray " The machine is supplied as standard with an original equipment belt (W x L) 150 x 7100 mm and a contact roller approx. 50° Shore for 150 mm belt width. Additional accessories: Bsdpfx Ahetwb U Aomsdh 3-axis table with integrated handling device for turning and swiveling the workpieces. The handling device is mounted in the center of the table under the insertion frame. To work with the handling device, the insertion frame is removed from the machine table. The handling device is equipped with four vacuum suction cups to hold the workpieces and consists of: The bearing with the rotary axis, on which a brake disk is mounted at the rear. The swivel device is attached to the front of the rotary axis. This can be locked at 0°, 22.5°, 45°, 67.5° and 90°. An additional locking disk is attached to the swivel head, which is used for fine adjustment of the workpieces to the sanding belt. The rotary and swivel axes are unlocked pneumatically using a foot switch, while the rotary axes are moved manually. Workpiece weight when used as a flat table with the insert frame in place = 80 daN Workpiece weight when using the handling device in relation to the clamping plate = 25 daN or 120 Nm in relation to the center of the rotary axis.

Condition: used, Year of construction: 1991, workpiece diameter 30 mm threading length 110 mm thread pitch 0,5-2,75 mm/GG total power requirement 4,5 kW weight of the machine ca. 1,7 t dimensions of the machine ca. m Bedpfxjt Hwzcs Ahmjdh

Condition: good (used), centre height 220 mm table diameter 220 mm Bodpfx Asu Sbl Rohmodh 250mm - chuck - 3 jaws 80mm passage Can be used vertically and horizontally Standing tip height 220mm

Condition: new, Precision surface grinding machine with automatic longitudinal and transverse feed. All castings, such as machine stand, table, etc., are made of MEEHANITE® quality cast iron and are therefore ideally suited for rough everyday work. Ideal for tool and mold making. Table size: 250 x 500 mm Installation height (max. distance spindle/table): 500 mm Max. Table load: 250 kg Motor power main spindle: 1,5 kW Connection: 400 V Dimensions (LxWxH), approx.: 2250 x 1400 x 1800 mm Weight, approx.: 1350 kg* * only machine without auxiliary units Features: - All castings, such as machine column, table, etc., made of MEEHANITE® quality castings. - All guideways hardened and ground - Automatic cross and longitudinal feed - NC-controlled automatic vertical infeed - Ergonomically arranged control panel - Automatic central lubrication - Separate hydraulic power pack - Grinding wheel - Grinding wheel flange - Manual dressing device - Balancing mandrel - Balancing scale - Dressing diamond - Demagnetizing device - Machine light - leveling elements - Operating tool - Operating instructions - CE Bdsdpfxop Dt T Ns Ahmjh Available options: - Elektromagent clamping plate (fine-pole) - Automatic demagnetization control for electromagent clamping plate - 2-axis digital display, accuracy 0.001 mm, X 450 / Y 500 mm - Coolant system with magnetic separator / magnetic separator - Partial enclosure with limit switch protected sliding doors - Full enclosure with limit switch protected sliding doors - Additional grinding wheel flange - Grinding wheel and flange for mild steel - Grinding wheel and flange for HRC55 - Ball screw for cross feed - Further options on request Pictures may show the machine with special accessories and with application examples.

Condition: used, Year of construction: 2009, Technical details: rotor dia: 30-500 mm hobbing length: 500-1000 mm total power requirement: 80 kW weight of the machine ca.: 15 t dimensions of the machine ca.: 3,6 x 2,5 x 3,0 m max. module: 8 Max. module Et milling = 12 Max. module hobbing = 12 Max. axial travel = 110 to 1100mm Max. cutter speed = 300rpm Max. cutter displacement tangential = -350 to -55mm Max. table speed = 100rpm Bjdpfx Ajv Hrp Ejhmjdh Table drive: torque motor Filter system: chip conveyor is for magnetic materials, belt filter is for all suspended matter that floats in the oil Including milling mandrel *
