Machining Center - Vertical

QUASER MV 204 CPL/15

Condition: new, Year of construction: 2025, saw band length: 4,420 mm, saw band width: 34 mm, Double-column bandsaw, fully automatic Everising H-360 HB Cutting range round: 0 - 360mm Cutting range square: 360 x 360mm Bundle tension: Width: 180 - 280mm Bundle tension height: 50 - 160mm Drive power: 3.7 kW Saw blade dimensions: 4420 x 34 x 1.1mm Weight: 2310 KG Gsdpfx Aeq St U Necajiu Machine dimension 2500 x 2200mm The standard equipment of the machines is as follows: Solid steel construction in double column principle - NC feed system - Frequency-controlled cutting speed (infinitely variable, inverter-controlled) - Digital cutting speed display - Hydraulically controlled double horizontal clamping vices - Hydraulic saw blade tensioning - Saw band guides (incl. band back guide) made of carbide - Hydraulically pre-tensioned band guides - Precise PLC control (SPS) for all hydraulic and electrical components. - Cutting counter with automatic switch-off - Automatic out-of-stock switch-off - Multi-job function - Bundle clamping device - Driven chip brush - Automatic band breakage control incl. emergency stop - Chip flushing gun - Flexible work light - 2 meter roller conveyor - Tool box - Carbide function Special equipment included: - Variable clamping pressure reduction - Cutting process control Extensive complete German documentation.

Condition: used, Year of construction: 2011, Technical details: x-travel: 800 mm y-travel: 950 mm z-travel: 1020 mm control: Sinumerik 840D sl MDynamics Operate Gisdpfeyzza Iox Acasu turning speeds: 10.000 1/min Spindle power: 26/20 kW max. torque on the spindle: 340/262 Nm tool taper: HSK-A 100 tool change unit: 120 (2x60) Pos. Pallet changer 2x: 630 x 630 mm table load capacity: 800 kg weight of the machine ca.: 20 t dimensions of the machine ca.: 3,3 x 6,15 x 3,2 m 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don’t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis special hydraulic pump for fixture coolant through spindle (10-80bar), one channel with proportional valve for pressures 10-200 bar, electromech. tool-length measuring device GROB, BLUM laser for tool measuring, tool coding, chip conveyor, 3D touch probe M&H, el. handwheel Siemens HT8 coolant gun, coolant shower, air gun, oilskimmer, automatic door Remote diagnosis A 6th axis MAPAL Tooltronic U-axis system comes with the machine with two heads: 1. LAT125-HSK100 2. LAT160-HSK100 *

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, table length: 1,200 mm, table width: 600 mm, spindle speed (max.): 12,000 rpm, table height: 560 mm, table load: 900 kg, Machine with just revised spindle, never used after Connected to power and available for inspections and tests Lubrication through spindle 30 Tools Gjdpfx Ajrb Amljcajiu Heidenhain 530

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, year of last overhaul: 2023, Offered is a VSC 250 vertical turning center, which has been mechanically and electrically overhauled by EMAG. Giodpfx Asrq Damjcaou The control system was upgrated to Siemens Sinumerik One. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens Sinumerik One TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Condition: good (used), Year of construction: 2011, functionality: fully functional, number of driven tool stations in tool turret 1: 48, number of driven tool stations in tool turret 2: 12, Available immediately and can be viewed under power. Upper X Y Z ballscrews fully refurbished mid 2023 by UK company. Included as shown in pictures -- Live tooling turret NA44A/BMT44 -- Capto C4 milling -- Capto C4 turning holders -- Capto C4 extensions -- 3 x Dual Capto C4 for turret -- Various other turret holders as pictured -- See attached spreadsheet (PDF below), for included holders. -- Renishaw arm -- Part catcher arm + converyor (not used for a long time) -- Old version of CAMplete TurnMill with USB dongle TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 11 [kW] - Spindle speeds : 4500 [rpm] - Max. bar diameter : 65 [mm] - Max. turning diameter : 200 [mm] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Spindle nose : A2-5 - Spindle power : 11 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 51 [mm] - Max. turning diameter : 200 [mm] - C axis indexing precision : 0,001 [°] - Travel : 780 [mm] - Spindle / counter-spindle distance : 980 [mm] TURNING-MILLING SPINDLE - X/Z stroke : 570/1297 [mm] Gisdpfx Aeycl Epjcaou - Y stroke : +/- 100 [mm] - B Axis stroke : 190 (+/-95) [°] - Tool type : Capto C4 - Spindle speeds : 12000 [rpm] - Spindle power : 7,5 [kW]

Condition: ready for operation (used), Year of construction: 2015, A combined vertical CNC turning and cylindrical grinding center EMAG is available. Chuck diameter: 250mm, max. swing diameter: 260mm, travel X/Z: 680mm/200mm, rapid traverse X/Z: 45m/min/30m/min, grinding spindle speed: 45000rpm, tool stations: 12, basket dimensions X/Y: 400mm/600mm, basket stack: 3. Machine dimensions X/Y/Z: approx. 3200mm/1900mm/2650mm, weight: approx. 8000kg, control: Siemens 840DS, operating hours: approx. 35000h, program hours: approx. 22000h. Documentation available. An on-site inspection is possible with power. Giedpfex Dm Dzjx Acasu

Condition: excellent (used), Year of construction: 2009, operating hours: 29,000 h, functionality: fully functional, Equipment: documentation/manual, The INDEX C200 – manufactured in 2009 – is a powerful CNC production turning center with a FANUC 31i control, main and counter spindle, and a 65 mm bar capacity. The machine features a high-quality 3-turret design, with turrets 1 and 2 each equipped with X, Z, and Y axes, and turret 3 used for machining on the counter spindle. All three disc turrets are equipped with 10 stations and, with driven tools up to 6,000 rpm, enable highly flexible complete machining. With a portal parts handler, conveyor belt, C-axes on the main and counter spindles, and powerful spindle drives, the machine is particularly suitable for productive series production of complex turned/milled parts. Control: FANUC 31i Design: Machine with 3 tool holders / 3 disc turrets Bar capacity: 65 mm Machine bed: Vertically arranged gray cast iron machine bed Main spindle: Spindle 4 Counter spindle: Spindle 5 with Z-axis Spindles Main spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Z-axis: 700 mm travel Rapid traverse Z-axis: 50 m/min Tool holder / Turret Design with 3 disc turrets, each with 10 stations. Tool system with 10 stations: Cylindrical shank DIN 69880 – Ø30 x 55 mm. Tool holder 1 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 320 / 550 mm (according to documentation) Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 2 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 550 mm Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Gijdpfx Acoy Tmhzsasu Tool holder 3 X-axis 10 stations Used exclusively for machining on the counter spindle X-axis: 180 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Further technical equipment according to documentation Portal parts handling system with numerically controlled Z-axis Workpiece removal from main or counter spindle to conveyor belt Removal of scrap material from the main spindle into a scrap container Portal parts handler: Traverse speed: 100 m/min Traverse range: 70 mm Workpiece diameter max.: 90 mm Workpiece length max.: 250 mm Scrap length max.: 250 mm Workpiece weight max.: 3.5 kg Hydraulic system: Flow rate: 19 l/min System pressure: 90 bar Hydraulic tank: 40 l Coolant circuit: Flow rate: 19 l/min Coolant unit power: 13 kW Coolant system: Pump output: 80 l/min / 8 bar Tank capacity: 300 l Chip conveyor: Chip discharge height: 1,250 mm

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2014. It features a powerful main spindle drive with up to 28kW power at 40% duty cycle and a speed range of 0-4500 rpm. Equipped with a Siemens SINUMERIK 840Dsl control system and a robust 12-position EMAG flange turret, it ensures precise and efficient operations. Ideal for handling workpieces up to 6kg with its specialized hydraulic chuck. For more information about this vertical turning machine, please reach out to us. Additional equipment • Coolant tank capacity: 360 liters Machine Benefits Technical Machine Benefits • High working accuracy, rapid traverse speeds, high maximum speed of driven tools • Machine from single shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78db(a) Extra Information Machine still under power Technical Specification Through-spindle Coolant Yes Giedpfxjytfppo Acasu Dimensions Machine Depth 3900 mm
