CNC gear grinding machine with dresser

Reishauer RZ 362A

Condition: excellent (used), Year of construction: 1998, operating hours: 50,000 h, functionality: fully functional, Technical Data – Gear Grinding Machine Reishauer RZ 362A Machine type Dkodpfx Aex Sxbdjh Sog Gear Grinding Machine Manufacturer Reishauer AG, Wallisellen, Switzerland Model RZ 362A Year of manufacture 1998 Machine number 73889 Commission number 309 CE compliant Yes Electrical data Mains connection 3 x 400 V, 50 Hz Machine voltage 3 x 400 V, 50 Hz Control voltage 1 x 230 V, 50 Hz / 1 x 24 V DC Contactor voltage 1 x 24 V DC Valve voltage 1 x 24 V DC Electrical diagrams standard Grinding wheel dimensions Minimum / maximum outside diameter 280 / 350 mm Maximum width with limitations 84 / 104 mm Number of starts with limitations up to 3 Maximum usable width (with shifting motion) 90 mm For module > 7 or more than 3 starts, Reishauer guidelines apply Grinding wheel speeds During grinding 1,100 – 2,300 rpm During profiling 50 – 95 rpm During setup (special mode) max. 200 rpm Grinding infeed In grinding mode per grinding stroke 0.01 – 1.0 mm Total infeed (fx tot) 9.99 mm In setup mode (special mode) max. 2 m/min Grinding stroke Maximum grinding stroke 175 mm Automatic grinding wheel return stroke for workpiece change 65 mm Shifting movement Maximum shifting travel continuous shifting per 1 mm grinding stroke 0 – 1.0 mm Workpiece data Minimum workpiece pitch diameter depending on grinding wheel diameter Grinding wheel Ø 280 mm: 50 mm Grinding wheel Ø 320 mm: 10 mm Grinding wheel Ø 350 mm: 10 mm Automatic centering with sensor (RZ 362A only): 20 mm Maximum workpiece outside diameter 360 mm With “Felsomat” loader (optional, RZ 362A only): 300 mm With automatic centering using sensor (RZ 362A only): 320 mm Minimum distance from grinding wheel center to workpiece center 165 mm Maximum face width 175 mm For pitch diameters < approx. 150 mm, face width is reduced due to clamping chuck and tailstock design Maximum workpiece weight 60 kg With “Felsomat” loader (optional, RZ 362A only): 4 kg Center distance Fixed manual tailstock (optional): 645 mm Special manual tailstock (optional): 745 mm Hydraulic tailstock (optional, RZ 362A only): 515 mm (645 mm with reduced grinding stroke) Gear data Number of teeth minimum 6, maximum 600 Module without automatic centering minimum module 0.5 (DP 48) Module with automatic centering minimum module 0.8 (DP 32) Maximum module 7.0 (DP 3.5) Helix angle Minimum 10° Maximum 40° Maximum inclination angle left and right 45° Shifting limitations apply for large helix angles, especially above 30° Crowning and profile modification Tip relief and crowning height Crowning length and taper Maximum modification depends on profiling tool and process data Weights (without oil filling) Machine weight approx. 5,000 kg Electrical cabinet approx. 1,100 kg Hydraulic unit approx. 600 kg Grinding oil unit RTO 100 (optional) approx. 1,600 kg Grinding oil unit RTM 100 with magnetic pre-filter (optional) approx. 1,650 kg Grinding oil unit RTA 150 (optional) approx. 2,500 kg “Felsomat” gantry loader (optional, RZ 362A only) approx. 1,600 kg Loading unit approx. 1,000 kg Workpiece storage approx. 400 kg

Year of construction: 2018, condition: ready for operation (used), A gear flank grinding machine Reishauer, completely overhauled by Burri Werkzeugmaschinen, is available. Grinding spindle speed: 3500rpm, cutting speed: 63m/s, max. gear diameter: 360mm, module range: 0.1-7, number of teeth: 6-600, max. workpiece height: 160mm, max. helix angle: +/-45°, max. workpiece weight: approx. 60kg. Min. wheel root circle diameter: 250mm, grinding wheel dimensions X/Y/Z: 350mm/104mm/160mm, grinding worm diameter range: 270mm-350mm, max. grinding width: 175mm, max. workpiece speed: 800rpm. Includes profiling devices, balancing device, structure-borne noise contact control, compact filter system, cooling unit, cooling water recooler, robot automation, and transport trolleys. Documentation available. An on-site inspection is possible. Dedpfx Ahsw Rqwas Sokg

Condition: used, Year of construction: 1997, Technical details: Dkodpfxsx Aq Ege Ah Sjg max. module: 7 weight of the machine ca.: 5 t worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 max. top circle diameter: 360 mm max. workpiece weight: 60 kg without filter *

Year of construction: 2000, condition: like new (used), Spares, Grinding and Diamond Dressing tools to Reishauer RZ362A, RZ361S, RZS or Burri generating grinding machines, as well as used flanges for grinding wheels. The grinding wheels are pre-profiled and new. Please ask for module and number of starts? Dksdsk Npmuepfx Ah Seg Dressing tools are new or in good condition (at least 50% remaining life time). Please give us your profile requirements in order to select the correct dressing tool? We also have various new mechanical and electrical spare parts on stock. Please ask us?

Condition: good (used), Year of construction: 1999, operating hours: 16,000 h, functionality: fully functional, machine/vehicle number: 650341, Year 1999 with Fanuc 18 TB – 3 axes XZB Marposs E30/E20 Country of manufacture: Switzerland Voltage: 400V/50Hz/3ph Dimensions: 410 x 220 x 190 cm Net machine weight: 5,000 kg TECHNICAL SPECIFICATIONS CNC control: Fanuc 18TB Intermediate Section Fixed intermediate section: grinding head R Swiveling section with manual indexing 2.5°: R / RS / UR / URS -210° to +30° Swiveling section with automatic indexing 2.5°: R / RS / UR / URS -210° to +30° B axis, resolution 0.1'': R / RS / UR / URS -210° to +30° Standard workhead Swivel range: -10° to (+100°) Spindle speed (continuous): 6 – 600 rpm Internal taper: MT5 Reducing sleeve: MT5/MT4 Short external taper fitting: DIN 55026 / Size 5 Permissible torque: 160 Nm Guaranteed roundness for chuck work Standard: 0.5 µm Option: 0.2 µm Workpiece weight between centers: 150 kg Dedpfjw T Tb Hsx Ah Sekg Tailstock Taper fitting: MT4 Quill stroke: 50 mm / 2° Option: fine adjustment with correction (Ø +/- 150 µm) Grinding wheel data (max. speed) Diameter 300: 27 m/s Diameter 400: 35 m/s Diameter 500: 45 m/s UR Grinding Head Power: 9.2 kW / 12.5 HP Wheel mounting, left max.: Ø 500 x 80 mm Right, additional max.: Ø 400 x 63 mm Internal grinding device: spindle HJN 828 Lower table (Z axis) Distance between centers: 1000 mm Max. travel: 1150 mm Max. speed: 15 m/min Max. resolution: 0.1 µm Upper table Distance between centers: 1000 mm / swivel 0° to 9° Grinding carriage (X axis) Max. travel: 320 mm Max. speed: 7.5 m/min Max. resolution: 0.1 µm Pneumatics Min. connection: 6 bar Air consumption: approx. 0.6 m³/h Coolant Max. connection pressure: 3 bar Required space (version 1000): 3600 x 2000 mm Unless otherwise stated, technical data is provided without engagement and may be subject to errors or omissions.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 73866, workpiece weight (max.): 60 kg, rotational speed (max.): 2,300 rpm, overall weight: 5,000 kg, TECHNICAL DETAILS Module, max.: 7 Grinding worm diameter: 280–350 mm Grinding worm width: 84–104 mm Grinding worm speed (grinding): 1,100–2,300 rpm Grinding worm speed (profiling): 50–95 rpm Number of teeth, min.: 6 Number of teeth, max.: 600 Maximum permissible outside diameter: 360 mm Dksdpfxjxvrzij Ah Ssg Maximum workpiece weight: 60 kg Maximum grinding stroke: 175 mm Workpiece speed (grinding): max. 250 rpm MACHINE DETAILS Machine weight approx.: 5 t Electrical Data Mains connection: 3 × 400 V 50 Hz Machine voltage: 3 × 400 V 50 Hz Control voltage: 1 × 230 V 50 Hz / 1 × 24 V DC Contactor voltage: 1 × 24 V DC Solenoid valve voltage: 1 × 24 V DC

Condition: good (used), cylindrical grinding machine Djdpfstrgndox Ah Sokg

Condition: excellent (used), workpiece diameter 10 - 250 mm threading length 900 mm thread pitch 0,3 - 100 mm spindle turning speed range 72 / 1700 - 2540 U/min Dkodjw Rrhgepfx Ah Ssg relief of the tap 0,03 - 8 mm clamping length max. 1190 mm max. module 10 workpiece turning speeds 0,4 - 160 U/min total power requirement 13 kW weight of the machine ca. 7,4 t dimensions of the machine ca. 4,5 x 2,0 x 2,1 m Many accessories.

Condition: ready for operation (used), Centre height: 175mm, centre width: 1000mm, max. external grinding diameter: 350mm, max. grinding length: 1000mm, max. workpiece weight: 130kg, grinding wheel dimensions X/Y/Z: 400mm/80mm/127mm. Machine dimensions X/Y/Z: approx. 2700mm/1700mm/1700mm, weight: approx. 3300kg, operating hours: approx. 21315h. An on-site inspection is possible. Dsdpfx Ahjw Dfhbs Sekg

Condition: ready for operation (used), Workpiece diameter range: 2mm-320mm, max. grinding length: 500mm, center distance: 1000mm, max. workpiece weight: 150kg. On-site inspection is possible. Dkodpewmqxwofx Ah Sog
