Grinding- and Lapping Machine

ROLLOMATIC CNC 148 P4

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 605, rotational speed (max.): 3,000 rpm, grinding diameter: 12 mm, controller model: Robot CNC, workpiece height (max.): 100 mm, table diameter: 200 mm, TECHNICAL DETAILS Grinding capacity (diameter): Ø 0.025 – 12.7 mm Bar diameter: Ø 1.0 – 12.7 mm Grinding length: W15 (optionally W20) Number of wheels: 1 Table diameter: 200 mm Workpiece height: 100 mm Control system: Robot CNC Axes: 4 axes + 2 programmable robot axes Bodpfjxnzd Djx Ah Iswi Z-axis: 35 mm, resolution: 0.5 µm X-axis: 25 mm, resolution: 0.1 µm Y-axis: 286 mm, resolution: 0.5 µm U-axis: 15 mm, resolution: 0.1 µm Interpolation: Simultaneous linear interpolation of 4 axes, cylindrical interpolation of 2 robot axes Head Motor Power: 0.70 kW Speed: 300 – 3,000 rpm Rough Grinding Power: 1.5 kW Spindle diameter: Ø 60 mm Grinding wheel diameter: Ø 200 mm Cutting speed: 30 m/s Finishing Power: 0.75 kW Spindle diameter: Ø 100 mm Grinding wheel diameter: Ø 150 mm Cutting speed: adjustable MACHINE DETAILS Total power requirement: 6 kW Machine weight: approx. 1.8 t Space requirements (L x W x H): approx. 1.83 x 2.04 x 2.1 m EQUIPMENT - Robot for loading and unloading - Fire protection system

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 693068, overall weight: 7,300 kg, power: 30 kW (40.79 HP), Walter Helitronic Vision CNC Tool & Cutter Grinder with Pallet Loader Universal tool and cutter grinder (CNC controlled) Made by Walter, model Helitronic Vision, s/n 693068, year 2008 Description: Suitable to manufacture and regrind metal and woodworking tools of all kinds. Can be viewed under power. Specifications: • Longitudinal movement (X-axis) 480 mm • Y axis vertical movement 320 mm • Z-axis transverse movement 700 mm • Rotary table swivel range C-axis +/- 200 ° • Workpiece Holder ISO 50 • Max. Workpiece diameter 320 mm • Workpiece length circumferential grinding 370 mm • Workpiece length for face machining 320 mm • Accuracy linear resolution 0.0001 mm • Radial resolution 0.0001 ° • Diameter of the spindle 100 mm • Grinding wheel mount: HSK50 • Diameter of the grinding wheel 200 mm • Grinding spindle speed 0 – 12,000 rpm., • Top performance 30 kW • Connected load 35 kW (460 V / 60 Hz) • Weight approx. 7,100 kg • Dimensions L x W x H 3649 x 2490 x 2301 mm Accessories: • Does not include wheel opening stick fixture seen in the pictures • Stepless speed control, probe, pneumatic workpiece clamping • Electrostatic mist extractor • Fire extinguishing system • Oil collecting pan, 2 grinding wheel flanges, Complete set of Manuals • Turmoil Drive Chiller • Loader Pallets: 8pcs – 3/16”, 1/4”, 5/16”, 3/8”, 1/2”, 5/8”, 3/4”, 1-1/4” • 10pcs - HSK Wheel Arbors Software: • Windows XP Pro Svc Pack 3 • Tool Studio V3.3 Bodpeuqzdpofx Ah Iewi • The computer was upgraded & is very fast rendering tools in Tool Studio Condition: • Excellent condition, very accurate & consistent. October 2023 Y axis Complete rebuilt, Linear motor, rails, Compensation Cylinder, Festo Booster Pump done by United Grinding. • 1 Micron Filtration system was used on the machine (not included), so it’s been kept extremely clean • We can load onto a flatdeck for shipping for $1200. We can also provide shipping quotes if you would like & crating for Sea Freight shipping.

Year of construction: 2001, condition: excellent (used), Multispindle lathe Schütte AG20 Bwjdpfx Ajhrihyoh Iji

Condition: refurbished (used), Used modernised 3D CNC coordinate measuring machine. ZEISS Prismo 16 - second-hand system Equipment freely selectable . . Bodpewptpkefx Ah Ijwi Measuring machine in moving portal design Granite table Equipment can be arranged individually to your requirements. Further details on request Measuring range X =1600 mm - Y = 3000 mm - Z = 1000 mm Measuring accuracy: depending on the selected measuring system Price: on request - please let us know your equipment requirements ᐳᐳᐳ Single item - as long as available ᐸᐸᐸ Pease ask for our detailed offer. Of course, we provide all services such as installation, maintenance, service, training. Programming etc. as for a new machine

Condition: ready for operation (used), Year of construction: 2004, operating hours: 78,000 h, functionality: fully functional, machine/vehicle number: 216028, Sale only within Germany CNC Grinding Center UW I D With 5 controlled axes: X, Y, Z, A, B And fully automatic grinding wheel changer Control system: NUM 1050 M with PC Center height: 195 mm Max. tool diameter: 250 mm Grinding table X-axis Longitudinal travel: 625 mm Usable table area: 900 mm x 185 mm Cross slide Z-axis Bjdpfx Ahsx Hwyhe Iswi Cross travel: 305 mm Vertical slide Y-axis Vertical stroke: 305 mm Grinding head B-axis Swivels 240° Grinding wheel mount: HSK-C50 Spindle speed: 2,000 – 23,000 rpm Workpiece carrier A-axis Mount: ISO 50 Max. speed: 600 rpm A, X, Y, Z axes with direct measurement system B-axis with indirect measurement system Renishaw 3D measuring probe permanently mounted on grinding head Grinding wheel changer with 8 stations incl. 4 additional coolant nozzles Additional CNC-controlled slide unit (W-axis) Longitudinal travel: 380 mm Hydraulic vertical stroke: 40 mm Mounted on the grinding table For use with steady rest or tailstock 78,000 spindle hours 105,000 power-on hours Includes Kraft+Bauer fire extinguishing system Note: Another identical machine is also available for sale.

Condition: refurbished (used), functionality: fully functional, Used modernized 3D CNC coordinate measuring machine. The machine is fully modernized with REVO2, the new high-tech touch probe system from Renishaw, new controller, temperature compensation, new computer system with i7 processor, Windows 11 Pro operating system, and the latest version of the 3D software RationalDMIS V2025. Technical data: Measuring range: X = 1200 mm - Y = 2400 mm - Z = 1000 mm Measurement uncertainty: MPEE: 2.7+L/300 MPEP: 1.8 in compliance with the environmental conditions Bwodpfx Ahewptiwe Ioi specified by the manufacturer Machine weight: approx. 7,250 kg Permissible tool weight: 2,500 kg External dimensions of the measuring machine: Length: 3540 mm - Width: 2050 mm - Height: 3770 mm (minimum room height 3870 mm) Clearance around the machine 600mm on each side. The machine is ready for demonstration in our facilities. We would be happy to arrange an appointment for your visit to our premises so that we can demonstrate the system's performance to you.

Condition: good (used), Year of construction: 1997, Rollomatic CNC 600 X Tool Grinding Machine TECHNICAL DATA X-axis: 228 mm Y-axis: 177 mm Z-axis: 52 mm A-axis: -15 to 90° B-axis: -110 to 40° C-axis: 360° Resolution: 0.0001 mm Rapid traverse: 12 m/min Bwodpfewf Nn Ijx Ah Iei Grinding spindle angle: 105° Power: 4.1 kW Speed: 2000 – 7200 rpm Max. grinding wheel diameter: 150 mm Dimensions: 2060 x 2032 x 1880 mm Weight: 3500 kg SCOPE OF OFFER Among other things: (list not exhaustive): Rollomatic CNC tool grinding machine, year of manufacture: 1997 Rollomatic Pick and Place Robot Exact scope of supply as per photo gallery No liability is assumed for the accuracy, completeness, or timeliness of the information provided.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, spindle speed (max.): 12,000 rpm, feed length X-axis: 400 mm, feed length Y-axis: 400 mm, feed length Z-axis: 250 mm, type of input current: three-phase, rotational speed (max.): 12,000 rpm, grinding spindle speed: 12,000 rpm, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 250 mm, grinding spindle motor power: 10,500 W, power: 10.3 kW (14.00 HP), input current: 30 A, input frequency: 50 Hz, input voltage: 400 V, year of last overhaul: 2024, Equipment: rotational speed infinitely variable, For Sale: 2008 Schütte 305 Linear 5-Axis CNC Tool & Cutter Grinder | Siemens 840D | New Spindle | Medical-Grade Machine Now available at Used Machine Tools Ireland Ltd, this high-precision Schütte 305 Linear 5-Axis CNC Tool and Cutter Grinder (2008) is an exceptional solution for tool regrinding, complex geometry grinding, and high-volume production. Previously in operation at a leading medical device company, this machine has been meticulously maintained, with a brand-new spindle installed in 2024. This grinder is fully equipped with modern tooling support systems including fire suppression, Absolent mist extraction, Ebbco coolant filtration, and in-line chiller, making it production-ready for demanding grinding applications. 🔹 Manufacturer: Alfred H. Schütte 📅 Year of Manufacture: 2008 📍 Location: Ireland ⚙️ Condition: Very Good – Ex-medical device use 🚀 Availability: Immediate 🔧 Spindle: Replaced in 2024 🛠️ Technical Specifications: Machine: Schütte 305 Linear CNC Tool & Cutter Grinder Machine Type: 5 Axis CNC Grinder Model: 305 Linear Year: 2008 Control: Siemens 840D with Windows XP Axes: 5-Axis CNC X-Axis Travel: 400 mm X-Axis with Tailstock: 400 mm Y-Axis Travel: 400 mm Z-Axis Travel: 250 mm Spindle Motor Power: 14 HP Spindle Speed: Up to 12,000 RPM Software: SIGS – Schütte Integrated Grinding Software Condition: Very good – Ex-medical device industry Spindle Replaced: 2024 (new) ⚙️ Equipped With: 🔥 Fire Suppression Unit 🌫️ Absolent Mist Extraction System 💧 Ebbco Coolant Filtration Unit ❄️ Ebbco In-line Chiller 🧠 Advanced SIGS Grinding Software 🛡️ New Spindle (2024) 💡 Ideal Applications: Tool & cutter regrinding Bsdpfxow Nyc Ae Ah Iewi Custom tooling production Precision carbide & HSS grinding Medical, aerospace, and high-specification manufacturing Schütte 305 Linear for sale Used 5-axis CNC tool grinder Tool and cutter grinder Siemens 840D Schütte SIGS software grinder CNC tool regrinding machine Ireland Schütte tool grinder with mist extraction Medical-grade grinding equipment High-performance cutter grinder 5-axis

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Technical data see handout. All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Sales only within Europe, incl. Turkey Bjdpfx Ahsw A Axbs Iswi Price without packaging; Delivery condition: FCA (machine location) ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. No private sales.

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25653, Equipped with: -Automatic Central Lubrication System -Machine Guard -Indramat - MTX and Sercos CNC Control -The standard machine is equipped with CNC-control make Indramat - MTX and SERCOS-interface -Tool Dressing (Automatic dressing cycle of the dressing master and honing wheel tip diameter by a diamond coated dressing roll. The dressing cycle of workpieces can be pre-selected) -Electronic Indexing Unit -Operator and Maintenance Manual -All Electrical Drawings -PLC Language in English -Software and Hardware for Remote Diagnosis -High Precision Control of the Stock Allowance Material -Manual Loading on Spindle for Prototypes -Software for Infeed Optimized Cycle Type Reduction (Adaptive Honing) -Software for Vario Speed Dressing -Software for Calibration of Master Gears -Software for Timing Gears (including additional sensor for the hole of 4mm) -Software for Shortening of Workpiece Change-Over Time -Clamping Cylinder -RITTAL Cooling Unit -Lighting for Working Area -Installation of Vibration Detecting Sensors -Coolant Unit -Electrostatic Oil Mist Exhauster IFS With Rigid Piping -Internal Automation Bodjw Iquyjpfx Ah Ijwi -Pallet Ring Conveyor System FlexLink (L-form shape see approved layout) -Parallel - Double Gripper -Pick and Placer Between Pallet Conveyor and Internal Loader -Extended Loading Length of the Pick and Placer Specifications: Workpiece: -Part Diameter: 20-150 mm -Maximum Face Width: 70 mm -Part Weight: 20 kg -Number of Teeth: 6-150 -Module: 1-5 mm Workpiece Spindle: -Maximum Speed: 6000 1/min -Installed Power: Approx. 25 kW Tool: -OD of Honing Wheel: 270 mm -Widths of Honing Wheel: 20-70 mm -Honing Wheel Material: Ceramics Tool Spindle: -Maximum Speed: 2000 1/min -Installed Power: Approx. 25 kW Machine: -Total Connected Load, Approx: 70 kVA -Floor Space (w x l x H): -Total Weight, Approx: 11 Ton -Bosch Rexroth MTX Control CML 85 Longitudinal Slide, Z-Axis: -Linear Drive -Drive Torque: 3,700 Nm -Infeed Speed: 60 m/min -Theoretical Infeed: 200 m/min -Drive Length, Maximum: 400 mm Cross Slide, X-Axis: -Linear Drive -Drive Momentum: 2,150 Nm -Infeed Speed: 60 m/min -Theoretical Infeed: 200 m/min -Drive Length, Maximum: 1050 mm Swiveling Axis, W-Axis: -AC-Servo Drive: 10,000 1/min -Setable Gear Transmission: i=5000:1 -Swiveling Angle: -90 Degrees / +16 Degrees Workpiece Spindle, C-Axis: -Direct Drive, Maximum RPM: 7,000 1/min -Drive Power: 30 kW -Drive Torque: 112 Nm -Digital Measuring System Tool Spindle, B-Axis: -Direct Drive (hollow spindle drive), Maximum RPM: 2000 1/min -Drive Power: 30 kW -Drive Torque: 150 Nm -Digital Measuring System
