Plasma cutting machine

Sato plasma snijmachine

Year of construction: 2014, condition: ready for operation (used), A complete CNC double gantry plasma cutting system Microstep with oxyfuel torch for nesting, bevel cutting and tube processing is available. 1) Plasma cutting system, max. processing length: 16500mm, max. processing width: 2500mm, max. processing width including shaft: 3700mm, max. material thickness VA/structural steel: 20mm/40mm, number of gantries: 2. Gantry 1: with a plasma rotator and a Kjellberg HiFocus 280i neo plasma cutting source. Gantry 2: fully automatic oxy-acetylene torch for possible equipment of a second torch carriage. Pipe cutting device: pipe diameter range: 30mm-700mm, max. pipe length: 16500mm, operating hours: approx. 15000h. 2) Filter system Donaldson Cyclopeel DFPRO 16, volume flow: 16000m³/h, filter elements: 16. Documentation available. On-site inspection is possible. Expected to be available from the end of 2025/beginning of 2026. Pictures are from commissioning in 2014. Bsdpfjwmqwyjx Afcecw

Condition: good (used), Year of construction: 2017, V304 plate processing machine (including 1 gantry beam(s) of 6.500mm and side trucks) ◼ This V304 plate processing machine is capable of processing plates up to 3.050mm x 18.000mm for bevel plasma cutting and marking (needle marker, if attached) and 4.100 x 18.000 mm for oxy-fuel cutting and marking (needle marker, if attached) ◼ X-rail (21.000mm on both sides of the machine, including double linear guides, helical rack and pinion system and rubber covering band) ◼ Plasma cutting and extraction table (4.300mm x 18.720mm, 2 channel(s), 1 pcs, suitable for ≥ 350A cutting) ◼ Position 1: Plasma cutting unit Kjellberg SmartFocus400 (1 pcs, automatic gas console, complete with cutting parameter database) ◼ Plasma 3D bevel unit (1 pcs, including 5 NC-axis, Voortman height control, intelligent torch positioning system and 3D collision sensor, for x- ,y- , k- and v-weld preparations) ◼ Driven suspension (1 pcs, servo motor driven, including laser pointer) ◼ Dross inhibitor (1 pcs, including 1,2L reservoir) ◼ Arc Glare protection (1 pcs) ◼ Position 2: Plasma cutting unit Kjellberg SmartFocus400 (1 pcs, automatic gas console, complete with cutting parameter database) ◼ Plasma 3D bevel unit (1 pcs, including 5 NC-axis, Voortman height control, intelligent torch positioning system and 3D collision sensor, for x- ,y- , k- and v-weld preparations) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Dross inhibitor (1 pcs, including 1,2L reservoir) ◼ Arc Glare protection (1 pcs) ◼ Position 3: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) Bjdpsvpalajfx Afcocw ◼ Position 4: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Position 5: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Cables high instead of low ◼ Donaldson fume extraction unit DFO 4-48 - 200L (incl. frequency controller) ◼ Air conditioning for switch panel (up to an ambient air temperature of 55°C) ◼ Hardware and software (includes VACAM ‘Machine Edition’, VACAM ‘Office Edition’, VACAD editor software module, VANEST nesting software, Layout marking software module, online support) ◼ Post processor for SigmaNEST (SigmaNEST is provided by the customer) ◼ Safety devices (safety bumpers, emergency stop cord)

Condition: good (used), Year of construction: 2008, Machine-Details: Stock-No. 1022-E06337 Type of machine Flame-Cutting Machine Make SATO Bodpfx Afjyhbfvjcecw Type Satronik D4500 Year of manufacture 2011/2008 Type of control CNC Storage location Germany Country of origin Germany Delivery time Immediately Freight basis Ex site, loaded on truck Technical details: gangway length 14000 mm working width 3700 mm burner heads 6 Control CNC 802 Additional information: Used oxyfuel cutting machine with semi-automatic gas control and 6 oxyfuel torches Working width 3700 mm Track width 4500 mm Overall width 5320 mm Overall height 2100 mm Height above floor to bottom edge of torch support on track beam mounted 1300 mm, floor-mounted without beam 1000 mm Track length 16000 mm on HE 300 B beam Oxyfuel burner: 6 pieces with MS 832-250 blades Burner carriages: 6 pieces, maintenance arm mounted on round bar Burner height adjustment: 6 pieces E 260 with 260 mm stroke Maximum cutting thickness with 4 torches: 300 mm Maximum cutting thickness with 6 torches: 200 mm Feed speed: 12000 mm/min CNC 802 control with vibration-resistant flash memory Semi-automatic gas control via proportional valves 96 macros (modifiable standard shapes) Easy to learn USB interface CNC Cut software for importing and converting DXF files 15" screen behind shatterproof, scratch-resistant glass, operable even with gloves. Note: A burner table and an extractor are not included in the scope of delivery.
