Vertical Turret Lathe - Single Column

SCHIESS-FRORIEP 40Dv - CNC

Condition: used, Year of construction: 2018, control CELOS / F31iB5 / Mapps 4S max. turning diameter 670 mm turning length 1.538 mm bar passage max. 81 mm x1 axis 675 mm y-axis mm z1 axis 1.562 + 164 mm b-axis ° a-axis 1.542 mm x2-axis 200 mm y2-axis + / - 40 mm z2-axis 1.542 mm max. turning speeds 4.000 U/min power capacity 26 / 22 kW spindle passage Ø 91 mm max. turning speeds 5.000 U/min power capacity 22 / 18,5 kW spindle passage Ø 73 mm turning speed range 0 – 12.000 U/min power capacity 28/ 23 kW tool taper Capto C6 number of tool places 76 Pos. max. tool diameter Ø 70/ Ø 130 mm max. tool length 400 mm max. tool weight 8 kg Number of tool holders 10 pos. Shank length for square tool 20 mm Shank diameter for boring bars Ø 32 mm Bjdpeyfh R Hefx Ah Iold power capacity 5,5/ 5,5/ 3,7 kW torque 16,9/ 13,1/ 8 Nm x-axis 50 m/min y-axis 40 m/min z-axis 50 m/min A-axis 36 m/min x2-axis 25 m/min y2-axis 18 m/min z2-axis 40 m/min b-axis 100 U/min Hollow clamping device Ø 67 mm Number of working hours ca. 23.250 h spindle hours ca. 8. h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical Features & Accessories: - Kitagawa hollow chuck on main and counter spindles - Dual foot switch for spindle 1 and spindle 2 - Full indexing of the tool spindle - Turret tailstock function - Suitable coolant type: Water-soluble coolant - Chip conveyor - Coolant system 70 bar, Hydrajet brand - Compressed air on spindle 1 and spindle 2 - Automatic measuring arm on the main spindle - Workpiece ejection on the spindle - Parts unloader - Preparation for bar feeder - Interface for mist separator - 2 RotorClear units - 4-color indicator light - Multi-Dry filter - Automatic probing and tool correction - Memory expansion - Cycle for plane transformation - Coolant spray gun Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in technical data and specifications, and prior sale!

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Bsdeq U R T Nspfx Ah Iold Total weight of the machine: 84.000 Kg

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 Bsdpfxsvb Dcao Ah Iold cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to dimensions of the machine ca.: 9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor *

Condition: good (used), Year of construction: 2003, travel distance X-axis: 13,000 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 30,000 rpm, distance between stands: 6,500 mm, spindle nose: HSK A63, X-axis: 13.000 mm Y-axis: 4.500 mm Z-axis: 1.000 mm Distance between columns: 6.500 mm C-axis: 190º A-axis: 110º Positioning speed XYZ: 15.000 mm/min. Positioning speed AC: 10 tpm CNC Controller: Siemens 840D Spindle nose: HSK A63 Spindle speed: 30.000 rpm Spindle power: 20 kW Toolchanger: 20 Pockets Torrestool tables: 16x X-axis: 11.500 mm Y-axis: 3.500 mm Z-axis: 750 mm Bsdpfx Ahstt I Sfj Isld Country of origin: Spain Machine size LxWxH: 19.000 x 11.000 x 6770 mm Machine weight: 70.000 kg The Torresmill Gantry is a 5-axis CNC milling and drilling machine, specially designed to work on aeronautical materials (Composite, Aluminum, Titanium, Steel, ...). The Torresmill gantry is perfectly combined with the Torrestool universal clamping device, guaranteeing flexibility and process time.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 56,089 h, Swing diameter over bed/cross slide: 820mm/550mm, distance between centers: 2666mm, max. turning diameter: 610mm, max. workpiece length: 2500mm, travel X/Z: 410mm/2560mm, travel Y: -80mm/100mm, max. workpiece weight without/with tailstock: 500kg/1500kg, tool positions: 12, rapid traverse X/Z/Y: 24m/30m/12m/min, feed force X/Z/Y: 17kN/20kN/17kN. Machine dimensions X/Y/Z: approx. 5500mm/2250mm/2550mm, weight: approx. 15000kg, operating hours: approx. 56089. Documentation available. An on-site inspection is possible. Expected to be available from mid-2026. Blsdpfow Dfhujx Ah Isd

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of retrofit: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Bodpfx Ahsqc Umgo Ijld Main motor Siemens: 68 kW Spindle speeds: I gear: 3 - 202 rpm II gear: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (supporting sleeve □ 520 mm/travel 1200 mm + W axis 1200 mm) Mount: SK60 (SK50) Facing slide: yes Milling head: 2 units Prepared for CNC rotary table (4th axis) Without rotary table and clamping field (available separately) Full documentation Net weight: approx. 140 tons Video available!

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Bljdpfx Ahjv I T Ewo Isd Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: excellent (used), FANUC Professional 6 Control Working travels 900 x 900 x 1020 mm Tool changer with 136 Positions Spindle speeds -10'000 rpm Bsdpfx Ahox A E Enj Isld Spindle taper HSK100 2 paletts 630 x 630 mm B-axis 0.001° Palett changer FASTEMS FPC1500 Cooling through spindle 3D measuring taper Tool breakage control device Tool lenght measuring device Chip conveyor Misc. accessories MARCELS MASCHINEN AG

Condition: excellent (used), Year of construction: 2008, operating hours: 82,500 h, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,750 mm, feed rate X-axis: 65 m/min, feed rate Y-axis: 65 m/min, feed rate Z-axis: 65 m/min, spindle speed (max.): 20,000 rpm, rapid traverse X-axis: 65 m/min, rapid traverse Y-axis: 65 m/min, rapid traverse Z-axis: 65 m/min, torque: 63 Nm, overall weight: 90,000 kg, Equipment: rotational speed infinitely variable, First commissioning: 2008 Control system: Heidenhain iTNC 530 incl. HR420 handwheel X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,750 mm A-axis: -120 / +95° C-axis: ±360° Maximum workpiece dimensions 3,800 mm (X-direction) 1,800 mm (Y-direction) 1,150 mm (Z-direction) 5-axis machining is possible in a single setup with a 300 mm long tool (A-axis at 90° swivel). Machine operating hours: approx. 82,500 h Total spindle hours: approx. 36,500 h Clamping table No machine table is included in the delivery. However, we are happy to offer a customer-specific solution at extra cost. 2-axis fork-type milling head 5 Spindle power: 20 kW Spindle speed: max. 20,000 rpm Torque: max. 63 Nm Tool holder: HSK 63A Tool release: hydraulic Holding torque (clamped) A & C axis: 2,000 Nm Drives, linear axes Feed rate X, Y, and Z axis: up to 65 m/min Axis acceleration X, Y, and Z: up to 5 m/s² Connection data Voltage: 400 V Frequency: 50 Hz Bljdpfxoxl R Hve Ah Ijd Power requirement: 130 kW Dimensions, weight Space required machine without peripherals: approx. 7,500 x 8,500 x 6,600 mm Total weight: approx. 90,000 kg Colour Enclosure, portal, control cabinet: RAL 7035 light grey Milling head and applications: RAL 5002 aquamarine blue Additional equipment - Minimum quantity lubrication - 50-fold tool changer - Work area enclosure Optionally available at extra cost: - Renishaw RMP60 probe - BLUM LaserControl NT mini Condition of the machine Fully functional, in very good condition. Can be inspected under power until April 2026.

Condition: ready for operation (used), Year of construction: 1997, Model: TG20/2500 Bedpfx Ahexwp D Ds Isld CNC: SIEMENS 840 C Turning diameter: 2500 mm Table diameter: 2000 mm Turning height: 2000 mm Max. table load: 20,000 kg Max. table speed: 2–250 rpm Number of speed ranges: 4 Table motor power: 60–100 kW Z-axis travel: 1,500 mm Ram section: 250 x 250 mm Rapid traverses: 10,000 mm/min Milling speed: 0–4,000 rpm Milling motor power: 37 kW Driven tools
