Jig Boring Machine - Vertical

SIP MP - 53

spindle diameter 110 mm
x-travel 900 mm
y-travel 600 mm
z-axis 200 mm
table length 1020 mm
table width 860 mm
taper MK 40
Table size, approx. 1,020 x 860 mm
Max. weight of workpiece 800 kg
Cjdpfot Hwyxsx Advspu

Table travel, longitudinal, max. (X) 900 mm
Boring head travel, cross, max. (Y) 600 mm
Boring spindle stroke (Z) 200 mm
Vertical travel of cross beam (W) 635 mm

Vertical distance between table and boring spindle 15 - 850 mm
Distance between columns 950 mm
Spindle Ø 110 mm
Spindle taper internal/external ISO 40
18 spindle speeds 10 - 2,500 rpm

Milling feeds of table, infinitely variable 1 - 6,000 mm/min
4 milling feeds of boring head 30 - 180 mm/min
6 boring feeds 0.01 - 0.39 rpm
Accuracy of all 3 axes when the machine was new 0.003 mm
Quick feeds for table, boring head slide, and
boring spindle, max. 6,000 mm/min

Spindle drive 6.2 kW
Weight, approx. 9,000 kg
Total electrical load 15 kW - 380 V - 50 Hz

Accessories / Special Features
- BOSCH CNC Control, Model MICRO 8, in 3 axes, with monitor. Program input is either manual or via cassette, or via interface entry.
- Digital display for Z Axis.
- Separate switch cabinet.
- Various tools.
- Oil cooler for spindle lubrication.
